Atmel ATtiny2313/V Datasheet

Features

• Utilizes the AVR

• AVR – High-performance and Low-power RISC Architecture

– 120 Powerful Instructions – Most Single Clock Cycle Execution
– 32 x 8 General Purpose Working Registers
– Fully Static Operation
– Up to 20 MIPS Throughput at 20 MHz

• Data and Non-volatile Program and Data Memories

– 2K Bytes of In-System Self Programmable Flash

Endurance 10,000 Write/Erase Cycles

– 128 Bytes In-System Programmable EEPROM

Endurance: 100,000 Write/Erase Cycles
– 128 Bytes Internal SRAM
– Programming Lock for Flash Program and EEPROM Data Security

• Peripheral Features

– One 8-bit Timer/Counter with Separate Prescaler and Compare Mode
– One 16-bit Timer/Counter with Separate Prescaler, Compare and Capture Modes
– Four PWM Channels
– On-chip Analog Comparator
– Programmable Watchdog Timer with On-chip Oscillator
– USI – Universal Serial Interface
– Full Duplex USART

• Special Microcontroller Features

– debugWIRE On-chip Debugging
– In-System Programmable via SPI Port
– External and Internal Interrupt Sources
– Low-power Idle, Power-down, and Standby Modes
– Enhanced Power-on Reset Circuit
– Programmable Brown-out Detection Circuit
– Internal Calibrated Oscillator

• I/O and Packages

– 18 Programmable I/O Lines
– 20-pin PDIP, 20-pin SOIC, 20-pad QFN/MLF

• Operating Voltages

– 1.8 – 5.5V (ATtiny2313V)
– 2.7 – 5.5V (ATtiny2313)

• Speed Grades

– ATtiny2313V: 0 – 4 MHz @ 1.8 - 5.5V, 0 – 10 MHz @ 2.7 – 5.5V
– ATtiny2313: 0 – 10 MHz @ 2.7 - 5.5V, 0 – 20 MHz @ 4.5 – 5.5V

• Typical Power Consumption

– Active Mode

1 MHz, 1.8V: 230 µA

32 kHz, 1.8V: 20 µA (including oscillator)
– Power-down Mode

< 0.1 µA at 1.8V

®

RISC Architecture

8-bit
Microcontroller
with 2K Bytes
In-System
Programmable
Flash

ATtiny2313/V

Preliminary

Summary

Rev. 2543LS–AVR–08/10

Pin

(

5)

Figure 1. Pinout ATtiny2313

Configurations

(RESET/dW) PA2

(RXD) PD0

(TXD) PD1
(XTAL2) PA1
(XTAL1) PA0

(CKOUT/XCK/INT0) PD2

(INT1) PD3

(T0) PD4

(OC0B/T1) PD5

(TXD) PD1

XTAL2) PA1

(XTAL1) PA0

CKOUT/XCK/INT0) PD2

(INT1) PD3

PDIP/SOIC

1
2
3
4
5
6
7
8
9
10

GND

PD0 (RXD)

20

1
2
3
4
5

6 7 8 9 10

VCC

20

PB7 (UCSK/SCL/PCINT7)

19

PB6 (MISO/DO/PCINT6)

18

PB5 (MOSI/DI/SDA/PCINT5)

17

PB4 (OC1B/PCINT4)

16

PB3 (OC1A/PCINT3)

15

PB2 (OC0A/PCINT2)

14

PB1 (AIN1/PCINT1)

13

PB0 (AIN0/PCINT0)

12

PD6 (ICP)

11

MLF

PA2 (RESET/dW)

VCC

PB7 (UCSK/SCK/PCINT7)

PB6 (MISO/DO/PCINT6)

19

18

17

16

15
14
13
12
11

PB5 (MOSI/DI/SDA/PCINT
PB4 (OC1B/PCINT4)
PB3 (OC1A/PCINT3)
PB2 (OC0A/PCINT2)
PB1 (AIN1/PCINT1)

GND

(T0) PD4

(ICP) PD6

(OC0B/T1) PD5

(AIN0/PCINT0) PB0

NOTE: Bottom pad should be soldered to ground.

Overview The ATtiny2313 is a low-power CMOS 8-bit microcontroller based on the AVR enhanced RISC

architecture. By executing powerful instructions in a single clock cycle, the ATtiny2313 achieves
throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power con­sumption versus processing speed.

2

ATtiny2313

2543LS–AVR–08/10

Block Diagram

PROGRAM
COUNTER

PROGRAM

FLASH

INSTRUCTION

REGISTER

GND

VCC

INSTRUCTION

DECODER

CONTROL

LINES

STACK

POINTER

SRAM

GENERAL
PURPOSE
REGISTER

ALU

STATUS

REGISTER

PROGRAMMING

LOGIC

SPI

8-BIT DATA BUS

XTAL1

XTAL2

RESET

INTERNAL

OSCILLATOR

OSCILLATOR

WATCHDOG

TIMER

TIMING AND

CONTROL

MCU CONTROL

REGISTER

MCU STATUS

REGISTER

TIMER/

COUNTERS

INTERRUPT

UNIT

EEPROM

USI

USART

ANALOG

COMPARATOR

DATA REGISTER

PORTB

DATA DIR.

REG. PORTB

DATA REGISTER

PORTA

DATA DIR.

REG. PORTA

PORTB DRIVERS

PB0 - PB7

PORTA DRIVERS

PA0 - PA2

DATA REGISTER

PORTD

DATA DIR.

REG. PORTD

PORTD DRIVERS

PD0 - PD6

ON-CHIP

DEBUGGER

INTERNAL
CALIBRATED
OSCILLATOR

ATtiny2313

Figure 2. Block Diagram

2543LS–AVR–08/10

3

The AVR core combines a rich instruction set with 32 general purpose working registers. All the
32 registers are directly connected to the Arithmetic Logic Unit (ALU), allowing two independent
registers to be accessed in one single instruction executed in one clock cycle. The resulting
architecture is more code efficient while achieving throughputs up to ten times faster than con­ventional CISC microcontrollers.

The ATtiny2313 provides the following features: 2K bytes of In-System Programmable Flash,
128 bytes EEPROM, 128 bytes SRAM, 18 general purpose I/O lines, 32 general purpose work­ing registers, a single-wire Interface for On-chip Debugging, two flexible Timer/Counters with
compare modes, internal and external interrupts, a serial programmable USART, Universal
Serial Interface with Start Condition Detector, a programmable Watchdog Timer with internal
Oscillator, and three software selectable power saving modes. The Idle mode stops the CPU
while allowing the SRAM, Timer/Counters, and interrupt system to continue functioning. The
Power-down mode saves the register contents but freezes the Oscillator, disabling all other chip
functions until the next interrupt or hardware reset. In Standby mode, the crystal/resonator Oscil­lator is running while the rest of the device is sleeping. This allows very fast start-up combined
with low-power consumption.

The device is manufactured using Atmel’s high density non-volatile memory technology. The
On-chip ISP Flash allows the program memory to be reprogrammed In-System through an SPI
serial interface, or by a conventional non-volatile memory programmer. By combining an 8-bit
RISC CPU with In-System Self-Programmable Flash on a monolithic chip, the Atmel ATtiny2313
is a powerful microcontroller that provides a highly flexible and cost effective solution to many
embedded control applications.

The ATtiny2313 AVR is supported with a full suite of program and system development tools
including: C Compilers, Macro Assemblers, Program Debugger/Simulators, In-Circuit Emulators,
and Evaluation kits.

4

ATtiny2313

2543LS–AVR–08/10

ATtiny2313

Pin Descriptions

VCC Digital supply voltage.

GND Ground.

Port A (PA2..PA0) Port A is a 3-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The

Port A output buffers have symmetrical drive characteristics with both high sink and source
capability. As inputs, Port A pins that are externally pulled low will source current if the pull-up
resistors are activated. The Port A pins are tri-stated when a reset condition becomes active,
even if the clock is not running.

Port A also serves the functions of various special features of the ATtiny2313 as listed on page

53.

Port B (PB7..PB0) Port B is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The

Port B output buffers have symmetrical drive characteristics with both high sink and source
capability. As inputs, Port B pins that are externally pulled low will source current if the pull-up
resistors are activated. The Port B pins are tri-stated when a reset condition becomes active,
even if the clock is not running.

Port B also serves the functions of various special features of the ATtiny2313 as listed on page

53.

Port D (PD6..PD0) Port D is a 7-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The

Port D output buffers have symmetrical drive characteristics with both high sink and source
capability. As inputs, Port D pins that are externally pulled low will source current if the pull-up
resistors are activated. The Port D pins are tri-stated when a reset condition becomes active,
even if the clock is not running.

Port D also serves the functions of various special features of the ATtiny2313 as listed on page

56.

RESET

XTAL1 Input to the inverting Oscillator amplifier and input to the internal clock operating circuit. XTAL1

XTAL2 Output from the inverting Oscillator amplifier. XTAL2 is an alternate function for PA1.

Reset input. A low level on this pin for longer than the minimum pulse length will generate a
reset, even if the clock is not running. The minimum pulse length is given in Table 15 on page

34. Shorter pulses are not guaranteed to generate a reset. The Reset Input is an alternate func-

tion for PA2 and dW.

is an alternate function for PA0.

2543LS–AVR–08/10

5

General Information

Resources A comprehensive set of development tools, application notes and datasheets are available for

downloadon http://www.atmel.com/avr.

Code Examples This documentation contains simple code examples that briefly show how to use various parts of

the device. These code examples assume that the part specific header file is included before
compilation. Be aware that not all C compiler vendors include bit definitions in the header files
and interrupt handling in C is compiler dependent. Please confirm with the C compiler documen­tation for more details.

Disclaimer Typical values contained in this data sheet are based on simulations and characterization of

other AVR microcontrollers manufactured on the same process technology. Min and Max values
will be available after the device is characterized.

6

ATtiny2313

2543LS–AVR–08/10

ATtiny2313

Register Summary

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page

0x3F (0x5F) SREG I T H S V N Z C 8

0x3E (0x5E) Reserved – – – – – – – –

0x3D (0x5D) SPL SP7 SP6 SP5 SP4 SP3 SP2 SP1 SP0 11

0x3C (0x5C) OCR0B Timer/Counter0 – Compare Register B 77

0x3B (0x5B) GIMSK INT1 INT0 PCIE – – – – –60

0x3A (0x5A) EIFR INTF1 INTF0 PCIF – – – – –61

0x39 (0x59) TIMSK TOIE1 OCIE1A OCIE1B – ICIE1 OCIE0B TOIE0 OCIE0A 78, 109

0x38 (0x58) TIFR TOV1 OCF1A OCF1B – ICF1 OCF0B TOV0 OCF0A 78

0x37 (0x57) SPMCSR –

0x36 (0x56) OCR0A Timer/Counter 0 – Compare Register A 77

0x35 (0x55) MCUCR PUD SM1 SE SM0 ISC11 ISC10 ISC01 ISC 00 53

0x34 (0x54) MCUSR – – – – WDRF BORF EXTRF PORF 37

0x33 (0x53) TCCR0B FOC0A FOC0B – – WGM02 CS02 CS01 CS00 76

0x32 (0x52) TCNT0 Timer/Counter0 (8-bit) 77

0x31 (0x51) OSCCAL – CAL6 CAL5 CAL4 CAL3 CAL2 CAL1 CAL0 26

0x30 (0x50) TCCR0A COM0A1 COM0A0 COM0B1 COM0B0

0x2F (0x4F) TCCR1A COM1A1 COM1A0 COM1B1 COM1BO

0x2E (0x4E) TCCR1B ICNC1 ICES1 – WGM13 WGM12 CS12 CS11 CS10 107

0x2D (0x4D) TCNT1H Timer/Counter1 – Counter Register High Byte 108

0x2C (0x4C) TCNT1L Timer/Counter1 – Counter Register Low Byte 108

0x2B (0x4B) OCR1AH Timer/Counter1 – Compare Register A High Byte 108

0x2A (0x4A) OCR1AL Timer/Counter1 – Compare Register A Low Byte 108

0x29 (0x49) OCR1BH Timer/Counter1 – Compare Register B High Byte 109

0x28 (0x48) OCR1BL Timer/Counter1 – Compare Register B Low Byte 109

0x27 (0x47) Reserved – – – – – – – –

0x26 (0x46) CLKPR CLKPCE – – – CLKPS3 CLKPS2 CLKPS1 CLKPS0 28

0x25 (0x45) ICR1H Timer/Counter1 - Input Capture Register High Byte 109

0x24 (0x44) ICR1L Timer/Counter1 - Input Capture Register Low Byte 109

0x23 (0x43) G TCCR – – – – – – – PSR10 81

0x22 (ox42) TCCR 1C FOC1A FOC1B – – – – – – 108

0x21 (0x41) WDTCSR WDIF WDIE WDP3 WDCE WDE WDP2 WDP1 WDP0 42

0x20 (0x40) PCMSK PCINT7 PCINT6 PCINT5 PCINT4 PCINT3 PCINT2 PCINT1 PCINT0 61

0x1F (0x3F) Reserved – – – – – – – –

0x1E (0x3E) EEAR – EEPROM Address Register 16

0x1D (0x3D) EEDR EEPROM Data Register 17

0x1C (0x3C) EECR – – EEPM1 EEPM0 EERIE EEMPE EEPE EERE 17

0x1B (0x3B) PORTA – – – – – PORTA2 PORTA1 PORTA0 58

0x1A (0x3A) DDRA – – – – – DDA2 DDA1 DDA0 58

0x19 (0x39) PINA – – – – – PINA2 PINA1 PINA0 58

0x18 (0x38) PORTB PORTB7 PORTB6 PORTB5 PORTB4 PORTB3 PORTB2 PORTB1 PORTB0 58

0x17 (0x37) DDRB DDB7 DDB6 DDB5 DDB4 DDB3 DDB2 DDB1 DDB0 58

0x16 (0x36) PINB PINB7 PINB6 PINB5 PINB4 PINB3 PINB2 PINB1 PINB0 58

0x15 (0x35) GPIOR2 General Purpose I/O Register 2 21

0x14 (0x34) GPIOR1 General Purpose I/O Register 1 21

0x13 (0x33) GPIOR0 General Purpose I/O Register 0 21

0x12 (0x32) PORTD

0x11 (0x31) DDRD

0x10 (0x30) PIND

0x0F (0x2F) USIDR USI Data Register 144

0x0E (0x2E) USISR USISIF USIOIF USIPF USIDC USICNT3 USICNT2 USICNT1 USICNT0 145

0x0D (0x2D) USICR USISIE USIOIE USIWM1 USIWM0 USICS1 USICS0 USICLK USITC 145

0x0C (0x2C) UDR UART Data Register (8-bit) 129

0x0B (0x2B) UCSRA RXC TXC UDRE FE DOR UPE U2X MPCM 129

0x0A (0x2A) UCSRB RXCIE TXCIE UDRIE RXEN TXEN UCSZ2 RXB8 TXB8 131

0x09 (0x29) UBRRL

0x08 (0x28) ACSR ACD ACBG ACO ACI ACIE ACIC ACIS1 ACIS0 149

0x07 (0x27) Reserved – – – – – – – –

0x06 (0x26) Reserved – – – – – – – –

0x05 (0x25) Reserved

0x04 (0x24) Reserved – – – – – – – –

0x03 (0x23) UCSRC

0x02 (0x22) UBRRH

0x01 (0x21) DID R – – – – – – AIN1D AIN0D 150

0x00 (0x20) Reserved

– PORTD6 PORTD5 PORTD4 PORTD3 PORTD2 PORTD1 PORTD0 58

– DDD6 DDD5 DDD4 DDD3 DDD2 DDD1 DDD0 58

– PIND6 PIND5 PIND4 PIND3 PIND2 PIND1 PIND0 58

– – – – – – – –

– UMSEL UPM1 UPM0 USBS UCSZ1 UCSZ0 UCPOL 132

– – – –

– – – – – – – –

–

– CTPB RFLB PGWRT PGERS SELFPRGEN 155

– –WGM01WGM00 73

– – WGM11 WGM10 104

UBRRH[7:0]

UBRRH[11:8]

133

133

2543LS–AVR–08/10

7

Note: 1. For compatibility with future devices, reserved bits should be written to zero if accessed. Reserved I/O memory addresses

should never be written.

2. I/O Registers within the address range 0x00 - 0x1F are directly bit-accessible using the SBI and CBI instructions. In these
registers, the value of single bits can be checked by using the SBIS and SBIC instructions.

3. Some of the status flags are cleared by writing a logical one to them. Note that, unlike most other AVRs, the CBI and SBI
instructions will only operate on the specified bit, and can therefore be used on registers containing such status flags. The
CBI and SBI instructions work with registers 0x00 to 0x1F only.

4. When using the I/O specific commands IN and OUT, the I/O addresses 0x00 - 0x3F must be used. When addressing I/O
Registers as data space using LD and ST instructions, 0x20 must be added to these addresses.

8

ATtiny2313

2543LS–AVR–08/10

ATtiny2313

Instruction Set Summary

Mnemonics Operands Description Operation Flags #Clocks

ARITHMETIC AND LOGIC INSTRUCTIONS

ADD Rd, Rr Add two Registers Rd ← Rd + Rr Z,C,N,V,H 1

ADC Rd, Rr Add with Carry two Registers Rd ← Rd + Rr + C Z,C,N,V,H 1

ADIW Rdl,K Add Immediate to Word Rdh:Rdl ← Rdh:Rdl + K Z,C,N,V,S 2

SUB Rd, Rr Subtract two Registers Rd ← Rd - Rr Z,C,N,V,H 1

SUBI Rd, K Subtract Constant from Register Rd ← Rd - K Z,C,N,V,H 1

SBC Rd, Rr Subtract with Carry two Registers Rd ← Rd - Rr - C Z,C,N,V,H 1

SBCI Rd, K Subtract with Carry Constant from Reg. Rd ← Rd - K - C Z,C,N,V,H 1

SBIW Rdl,K Subtract Immediate from Word Rdh:Rdl ← Rdh:Rdl - K Z,C,N,V,S 2

AND Rd, Rr Logical AND Registers Rd ← Rd • Rr Z,N,V 1

ANDI Rd, K Logical AND Register and Constant Rd ← Rd • K Z,N,V 1

OR Rd, Rr Logical OR Registers Rd ← Rd v Rr Z,N,V 1

ORI Rd, K Logical OR Register and Constant Rd ← Rd v K Z,N,V 1

EOR Rd, Rr Exclusive OR Registers Rd ← Rd ⊕ Rr Z,N,V 1

COM Rd One’s Complement Rd ← 0xFF − Rd Z,C,N,V 1

NEG Rd Two’s Complement Rd ← 0x00 − Rd Z,C,N,V,H 1

SBR Rd,K Set Bit(s) in Register Rd ← Rd v K Z,N,V 1

CBR Rd,K Clear Bit(s) in Register Rd ← Rd • (0xFF - K) Z,N,V 1

INC Rd Increment Rd ← Rd + 1 Z,N,V 1

DEC Rd Decrement Rd ← Rd − 1 Z,N,V 1

TST Rd Test for Zero or Minus Rd ← Rd • Rd Z,N,V 1

CLR Rd Clear Register Rd ← Rd ⊕ Rd Z,N,V 1

SER Rd Set Register Rd ← 0xFF None 1

BRANCH INSTRUCTIONS

RJMP k Relative Jump PC ← PC + k + 1 None 2

IJMP Indirect Jump to (Z) PC ← Z None 2

RCALL k Relative Subroutine Call PC ← PC + k + 1 None 3

ICALL Indirect Call to (Z) PC ← ZNone3

RET Subroutine Return PC ← STACK None 4

RETI Interrupt Return PC ← STACK I 4

CPSE Rd,Rr Compare, Skip if Equal if (Rd = Rr) PC ← PC + 2 or 3 None 1/2/3

CP Rd,Rr Compare Rd − Rr Z, N,V,C,H 1

CPC Rd,Rr Compare with Carry Rd − Rr − C Z, N,V,C,H 1

CPI Rd,K Compare Register with Immediate Rd − K Z, N,V,C,H 1

SBRC Rr, b Skip if Bit in Register Cleared if (Rr(b)=0) PC ← PC + 2 or 3 None 1/2/3

SBRS Rr, b Skip if Bit in Register is Set if (Rr(b)=1) PC ← PC + 2 or 3 None 1/2/3

SBIC P, b Skip if Bit in I/O Register Cleared if (P(b)=0) PC ← PC + 2 or 3 None 1/2/3

SBIS P, b Skip if Bit in I/O Register is Set if (P(b)=1) PC ← PC + 2 or 3 None 1/2/3

BRBS s, k Branch if Status Flag Set if (SREG(s) = 1) then PC←PC+k + 1 None 1/2

BRBC s, k Branch if Status Flag Cleared if (SREG(s) = 0) then PC←PC+k + 1 None 1/2

BREQ k Branch if Equal if (Z = 1) then PC ← PC + k + 1 None 1/2

BRNE k Branch if Not Equal if (Z = 0) then PC ← PC + k + 1 None 1/2

BRCS k Branch if Carry Set if (C = 1) then PC ← PC + k + 1 N one 1/2

BRCC k Branch if Carry Cleared if (C = 0) then PC ← PC + k + 1 None 1/2

BRSH k Branch if Same or Higher if (C = 0) then PC ← PC + k + 1 None 1/2

BRLO k Branch if Lower if (C = 1) then PC ← PC + k + 1 None 1/2

BRMI k Branch if Minus if (N = 1) then PC ← PC + k + 1 None 1/2

BRPL k Branch if Plus if (N = 0) then PC ← PC + k + 1 None 1/2

BRGE k Branch if Greater or Equal, Signed if (N ⊕ V= 0) then PC ← PC + k + 1 None 1/2

BRLT k Branch if Less Than Zero, Signed if (N ⊕ V= 1) then PC ← PC + k + 1 None 1/2

BRHS k Branch if Half Carry Flag Set if (H = 1) then PC ← PC + k + 1 None 1/2

BRHC k Branch if Half Carry Flag Cleared if (H = 0) then PC ← PC + k + 1 None 1/2

BRTS k Branch if T Flag Set if (T = 1) then PC ← PC + k + 1 None 1/2

BRTC k Branch if T Flag Cleared if (T = 0) then PC ← PC + k + 1 None 1/2

BRVS k Branch if Overflow Flag is Set if (V = 1) then PC ← PC + k + 1 None 1/2

BRVC k Branch if Overflow Flag is Cleared if (V = 0) then PC ← PC + k + 1 None 1/2

BRIE k Branch if Interrupt Enabled if ( I = 1) then PC ← PC + k + 1 None 1/2

BRID k Branch if Interrupt Disabled if ( I = 0) then PC ← PC + k + 1 None 1/2

BIT AND BIT-TEST INSTRUCTIONS

SBI P,b Set Bit in I/O Register I/O(P,b) ← 1None2

CBI P,b Clear Bit in I/O Register I/O(P,b) ← 0None2

LSL Rd Logical Shift Left Rd(n+1) ← Rd(n), Rd(0)

LSR Rd Logical Shift Right Rd(n) ← Rd(n+1), Rd(7) ← 0 Z,C,N,V 1

ROL Rd Rotate Left Through Carry Rd(0)←C,Rd(n+1)← Rd(n),C←Rd(7) Z,C,N,V 1

← 0 Z,C,N,V 1

2543LS–AVR–08/10

9

Mnemonics Operands Description Operation Flags #Clocks

ROR Rd Rotate Right Through Carry Rd(7)←C,Rd(n)← Rd(n+1),C←Rd(0) Z,C,N,V 1

ASR Rd Arithmetic Shift Right Rd(n) ← Rd(n+1), n=0..6 Z,C,N,V 1

SWAP Rd Swap Nibbles Rd(3..0)←Rd(7..4),Rd(7..4)←Rd(3..0) None 1

BSET s Flag Set SREG(s) ← 1 SREG(s) 1

BCLR s Flag Clear SREG(s) ← 0 SREG(s) 1

BST Rr, b Bit Store from Register to T T ← Rr(b) T 1

BLD Rd, b Bit load from T to Register Rd(b) ← TNone1

SEC Set Carry C ← 1C1

CLC Clear Carry C ← 0 C 1

SEN Set Negative Flag N ← 1N1

CLN Clear Negative Flag N ← 0 N 1

SEZ Set Zero Flag Z ← 1Z1

CLZ Clear Zero Flag Z ← 0 Z 1

SEI Global Interrupt Enable I ← 1I1

CLI Global Interrupt Disable I ← 0 I 1

SES Set Signed Test Flag S ← 1S1

CLS Clear Signed Test Flag S ← 0 S 1

SEV Set Twos Complement Overflow. V ← 1V1

CLV Clear Twos Complement Overflow V ← 0 V 1

SET Set T in SREG T ← 1T1

CLT Clear T in SREG T ← 0 T 1

SEH Set Half Carry Flag in SREG H ← 1H1

CLH Clear Half Carry Flag in SREG H ← 0 H 1

DATA TRANSFER INSTRUCTIONS

MOV Rd, Rr Move Between Registers Rd ← Rr None 1

MOVW Rd, Rr Copy Register Word

LDI Rd, K Load Immediate Rd ← KNone1

LD Rd, X Load Indirect Rd ← (X) None 2

LD Rd, X+ Load Indirect and Post-Inc. Rd ← (X), X ← X + 1 None 2

LD Rd, - X Load Indirect and Pre-Dec. X ← X - 1, Rd ← (X) None 2

LD Rd, Y Load Indirect Rd ← (Y) None 2

LD Rd, Y+ Load Indirect and Post-Inc. Rd ← (Y), Y ← Y + 1 None 2

LD Rd, - Y Load Indirect and Pre-Dec. Y ← Y - 1, Rd ← (Y) None 2

LDD Rd,Y+q Load Indirect with Displacement Rd ← (Y + q) None 2

LD Rd, Z Load Indirect Rd ← (Z) None 2

LD Rd, Z+ Load Indirect and Post-Inc. Rd ← (Z), Z ← Z+1 None 2

LD Rd, -Z Load Indirect and Pre-Dec. Z ← Z - 1, Rd ← (Z) None 2

LDD Rd, Z+q Load Indirect with Displacement Rd ← (Z + q) None 2

LDS Rd, k Load Direct from SRAM Rd ← (k) None 2

ST X, Rr Store Indirect (X) ← Rr None 2

ST X+, Rr Store Indirect and Post-Inc. (X) ← Rr, X ← X + 1 None 2

ST - X, Rr Store Indirect and Pre-Dec. X ← X - 1, (X) ← Rr None 2

ST Y, Rr Store Indirect (Y) ← Rr None 2

ST Y+, Rr Store Indirect and Post-Inc. (Y) ← Rr, Y ← Y + 1 None 2

ST - Y, Rr Store Indirect and Pre-Dec. Y ← Y - 1, (Y) ← Rr None 2

STD Y+q,Rr Store Indirect with Displaceme nt (Y + q) ← Rr None 2

ST Z, Rr Store Indirect (Z) ← Rr None 2

ST Z+, Rr Store Indirect and Post-Inc. (Z) ← Rr, Z ← Z + 1 None 2

ST -Z, Rr Store Indirect and Pre-Dec. Z ← Z - 1, (Z) ← Rr None 2

STD Z+q,Rr Store Indi rect with Displacement (Z + q) ← Rr None 2

STS k, Rr Store Direct to SRAM (k) ← Rr None 2

LPM Load Program Memory R0 ← (Z) None 3

LPM Rd, Z Load Program Memory Rd ← (Z) None 3

LPM Rd, Z+ Load Program Memory and Post-Inc Rd ← (Z), Z ← Z+1 None 3

SPM Store Program Memory (Z) ← R1:R0 None -

IN Rd, P In Port Rd ← PNone1

OUT P, Rr Out Port P ← Rr None 1

PUSH Rr Push Register on Stack STACK ← Rr None 2

POP Rd Pop Register from Stack Rd ← STACK None 2

MCU CONTROL INSTRUCTIONS

NOP No Operation None 1

SLEEP Sleep (see specific descr. for Sleep function) None 1

WDR Watchdog Reset (see specific descr. for WDR/timer) None 1

BREAK Break For On-chip Debug Only None N/A

Rd+1:Rd ← Rr+1:Rr

None 1

10

ATtiny2313

2543LS–AVR–08/10

ATtiny2313

Ordering Information

Speed (MHz)

(3)

Power Supply (V) Ordering Code

ATtiny2313V-10PU
ATtiny2313V-10SU

10 1.8 - 5.5

ATtiny2313V-10SUR
ATtiny2313V-10MU
ATtiny2313V-10MUR

ATtiny2313-20PU
ATtiny2313-20SU

20 2.7 - 5.5

ATtiny2313-20SUR
ATtiny2313-20MU
ATtiny2313-20MUR

Notes: 1. These devices can also be supplied in wafer form. Please contact your local Atmel sales office for detailed ordering informa-

tion and minimum quantities.

2. Pb-free packaging alternative, complies to the European Directive for Restriction of Hazardous Substances (RoHS direc­tive). Also Halide free and fully Green.

3. For Speed vs. V

see Figure 82 on page 180 and Figure 83 on page 180.

CC,

4. Code Indicators:

– U: matte tin
– R: tape & reel

(4)

Package

(2)

Operation Range

20P3
20S
20S
20M1

Industrial

(-40°C to +85°C)

(1)

20M1

20P3
20S
20S
20M1

Industrial

(-40°C to +85°C)

(1)

20M1

Package Type

20P3 20-lead, 0.300" Wide, Plastic Dual Inline Package (PDIP)

20S 20-lead, 0.300" Wide, Plastic Gull Wing Small Outline Package (SOIC)

20M1 20-pad, 4 x 4 x 0.8 mm Body, Quad Flat No-Lead/Micro Lead Frame Package (MLF)

2543LS–AVR–08/10

11

Packaging Information

2325 Orchard Parkway
San Jose, CA 95131

TITLE

DRAWING NO.

R

REV.

20P3, 20-lead (0.300"/7.62 mm Wide) Plastic Dual

Inline Package (PDIP)

C

20P3

1/12/04

PIN

1

E1

A1

B

E

B1

C

L

SEATING PLANE

A

D

e

eB

eC

COMMON DIMENSIONS

(Unit of Measure = mm)

SYMBOL

MIN

NOM

MAX

NOTE

A – – 5.334

A1 0.381 – –

D 25.493 – 25.984 Note 2

E 7.620 – 8.255

E1 6.096 – 7.112 Note 2

B 0.356 – 0.559

B1 1.270 – 1.551

L 2.921 – 3.810

C 0.203 – 0.356

eB – – 10.922

eC 0.000 – 1.524

e 2.540 TYP

Notes: 1. This package conforms to JEDEC reference MS-001, Variation AD.

2. Dimensions D and E1 do not include mold Flash or Protrusion.
Mold Flash or Protrusion shall not exceed 0.25 mm (0.010").

20P3

12

ATtiny2313

2543LS–AVR–08/10

20S

ATtiny2313

2543LS–AVR–08/10

13

20M1

D

1

Pin 1 ID

2

3

E

TOP VIEW

D2

1

Pin #1

Notch

(0.20 R)

2

3

E2

b

L

e

BOTTOM VIEW

Reference JEDEC Standard MO-220, Fig. 1 (SAW Singulation) WGGD-5.

Note:

SIDE VIEW

A2

A1

A

0.08

C

COMMON DIMENSIONS

(Unit of Measure = mm)

SYMBOL

A 0.70 0.75 0.80

A1 – 0.01 0.05

A2 0.20 REF

b 0.18 0.23 0.30

D 4.00 BSC

D2 2.45 2.60 2.75

E 4.00 BSC

E2 2.45 2.60 2.75

e 0.50 BSC

L 0.35 0.40 0.55

MIN

NOM

MAX

NOTE

14

2325 Orchard Parkway

R

San Jose, CA 95131

ATtiny2313

TITLE

20M1, 20-pad, 4 x 4 x 0.8 mm Body, Lead Pitch 0.50 mm,

2.6 mm Exposed Pad, Micro Lead Frame Package (MLF)

DRAWING NO.

20M1

2543LS–AVR–08/10

10/27/04

REV.

A

Errata The revision in this section refers to the revision of the ATtiny2313 device.

ATtiny2313 Rev C No known errata

ATtiny2313 Rev B • Wrong values read after Erase Only operation

• Parallel Programming does not work

• Watchdog Timer Interrupt disabled

• EEPROM can not be written below 1.9 volts

1. Wrong values read after Erase Only operation

At supply voltages below 2.7 V, an EEPROM location that is erased by the Erase Only oper­ation may read as programmed (0x00).

Problem Fix/Workaround

If it is necessary to read an EEPROM location after Erase Only, use an Atomic Write opera­tion with 0xFF as data in order to erase a location. In any case, the Write Only operation can
be used as intended. Thus no special considerations are needed as long as the erased loca­tion is not read before it is programmed.

2. Parallel Programming does not work

Parallel Programming is not functioning correctly. Because of this, reprogramming of the
device is impossible if one of the following modes are selected:

– In-System Programming disabled (SPIEN unprogrammed)

– Reset Disabled (RSTDISBL programmed)

Problem Fix/Workaround

Serial Programming is still working correctly. By avoiding the two modes above, the device
can be reprogrammed serially.

ATtiny2313

3. Watchdog Timer Interrupt disabled

If the watchdog timer interrupt flag is not cleared before a new timeout occurs, the watchdog
will be disabled, and the interrupt flag will automatically be cleared. This is only applicable in
interrupt only mode. If the Watchdog is configured to reset the device in the watchdog time­out following an interrupt, the device works correctly.

Problem fix / Workaround

Make sure there is enough time to always service the first timeout event before a new
watchdog timeout occurs. This is done by selecting a long enough time-out period.

4. EEPROM can not be written below 1.9 volts

Writing the EEPROM at V

Problem fix / Workaround

Do not write the EEPROM when V

below 1.9 volts might fail.

CC

ATtiny2313 Rev A Revision A has not been sampled.

is below 1.9 volts.

CC

2543LS–AVR–08/10

15

Datasheet

Please note that the referring page numbers in this section refer to the complete document.

Revision
History

Rev. 2543L - 8/10 Added tape and reel part numbers in “Ordering Information” on page 215. Removed text

“Not recommended for new design” from cover page. Fixed literature number mismatch
in Datasheet Revision History.

Rev. 2543K - 03/10

1. Added device Rev C “No known errata” in “Errata” on page 219.

Rev. 2543J - 11/09

1. Updated template

2. Changed device status to “Not recommended for new designs.”

3. Updated “Stack Pointer” on page 11.

4. Updated Table “Sleep Mode Select” on page 30.

5. Updated “Calibration Byte” on page 160 (to one byte of calibration data)

Changes from Rev. 2543H-02/05 to Rev. 2543I-04/06

1. Updated typos.

2. Updated Figure 1 on page 2.
3 Added “Resources” on page 6.

4. Updated “Default Clock Source” on page 23.

5. Updated “128 kHz Internal Oscillator” on page 28.

6. Updated “Power Management and Sleep Modes” on page 30

7. Updated Table 3 on page 23,Table 13 on page 30, Table 14 on page 31,

Table 19 on page 42, Table 31 on page 60, Table 79 on page 176.

8. Updated “External Interrupts” on page 59.

9. Updated “Bit 7..0 – PCINT7..0: Pin Change Enable Mask 7..0” on page

61.

10. Updated “Bit 6 – ACBG: Analog Comparator Bandgap Select” on page

149.

11. Updated “Calibration Byte” on page 160.

12. Updated “DC Characteristics” on page 177.

13. Updated “Register Summary” on page 211.

14. Updated “Ordering Information” on page 215.

15. Changed occurences of OCnA to OCFnA, OCnB to OCFnB and OC1x to
OCF1x.

Changes from Rev. 2543G-10/04 to Rev. 2543H-02/05

16

ATtiny2313

1. Updated Table 6 on page 25, Table 15 on page 34, Table 68 on page 160
and Table 80 on page 179.

2. Changed CKSEL default value in “Default Clock Source” on page 23 to
8 MHz.

2543LS–AVR–08/10

Changes from Rev. 2543F-08/04 to Rev. 2543G-10/04

Changes from Rev. 2543E-04/04 to Rev. 2543F-08/04

ATtiny2313

3. Updated “Programming the Flash” on page 165, “Programming the

EEPROM” on page 167 and “Enter Programming Mode” on page 163.

4. Updated “DC Characteristics” on page 177.

5. MLF option updated to “Quad Flat No-Lead/Micro Lead Frame
(QFN/MLF)”

1. Updated “Features” on page 1.

2. Updated “Pinout ATtiny2313” on page 2.

3. Updated “Ordering Information” on page 215.

4. Updated “Packaging Information” on page 216.

5. Updated “Errata” on page 219.

1. Updated “Features” on page 1.

2. Updated “Alternate Functions of Port B” on page 53.

3. Updated “Calibration Byte” on page 160.

4. Moved Table 69 on page 160 and Table 70 on page 160 to “Page Size”

on page 160.

5. Updated “Enter Programming Mode” on page 163.

6. Updated “Serial Programming Algorithm” on page 173.

7. Updated Table 78 on page 174.

8. Updated “DC Characteristics” on page 177.

9. Updated “ATtiny2313 Typical Characteristics” on page 181.

10. Changed occurences of PCINT15 to PCINT7, EEMWE to EEMPE and
EEWE to EEPE in the document.

Changes from Rev. 2543D-03/04 to Rev. 2543E-04/04

Changes from Rev. 2543C-12/03 to Rev. 2543D-03/04

1. Speed Grades changed

- 12MHz to 10MHz

- 24MHz to 20MHz

2. Updated Figure 1 on page 2.

3. Updated “Ordering Information” on page 215.

4. Updated “Maximum Speed vs. V

5. Updated “ATtiny2313 Typical Characteristics” on page 181.

1. Updated Table 2 on page 23.

2. Replaced “Watchdog Timer” on page 39.

3. Added “Maximum Speed vs. V

4. “Serial Programming Algorithm” on page 173 updated.

5. Changed mA to µA in preliminary Figure 136 on page 207.

6. “Ordering Information” on page 215 updated.
MLF package option removed

” on page 180.

CC

” on page 180.

CC

2543LS–AVR–08/10

17

Changes from Rev. 2543B-09/03 to Rev. 2543C-12/03

Changes from Rev. 2543A-09/03 to Rev. 2543B-09/03

7. Package drawing “20P3” on page 216 updated.

8. Updated C-code examples.

9. Renamed instances of SPMEN to SELFPRGEN, Self Programming
Enable.

1. Updated “Calibrated Internal RC Oscillator” on page 25.

1. Fixed typo from UART to USART and updated Speed Grades and Power
Consumption Estimates in “Features” on page 1.

2. Updated “Pin Configurations” on page 2.

3. Updated Table 15 on page 34 and Table 80 on page 179.

4. Updated item 5 in “Serial Programming Algorithm” on page 173.

5. Updated “Electrical Characteristics” on page 177.

6. Updated Figure 82 on page 180 and added Figure 83 on page 180.

7. Changed SFIOR to GTCCR in “Register Summary” on page 211.

8. Updated “Ordering Information” on page 215.

9. Added new errata in “Errata” on page 219.

18

ATtiny2313

2543LS–AVR–08/10

ATtiny2313

2543LS–AVR–08/10

19

Headquarters International

Atmel Corporation

2325 Orchard Parkway
San Jose, CA 95131
USA
Tel: [phone]
Fax: [phone]

Atmel Asia

Unit 1-5 & 16, 19/F
BEA Tower, Millennium City 5
418 Kwun Tong Road
Kwun Tong, Kowloon
Hong Kong
Tel: [phone]
Fax: [phone]

Product Contact

Web Site

www.atmel.com

Literature Requests

www.atmel.com/literature

Atmel Europe

Le Krebs
8, Rue Jean-Pierre Timbaud
BP 309
78054 Saint-Quentin-en­Yvelines Cedex
France
Tel: [phone]
Fax: [phone]

Technical Support

[e-mail]

Atmel Japan

9F, Tonetsu Shinkawa Bldg.
1-24-8 Shinkawa
Chuo-ku, Tokyo 104-0033
Japan
Tel: [phone]
Fax: [phone]

Sales Contact

www.atmel.com/contacts

Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any
intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN ATMEL’S TERMS AND CONDI-

TIONS OF SALE LOCATED ON ATMEL’S WEB SITE, ATMEL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR STATUTORY
WARRANTY RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL ATMEL BE LIABLE FOR ANY DIRECT, INDIRECT, CONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDEN­TAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, OR LOSS OF INFORMATION) ARISING OUT
OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF ATMEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Atmel makes no

representations or warranties with respect to the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications
and product descriptions at any time without notice. Atmel does not make any commitment to update the information contained herein. Unless specifically provided
otherwise, Atmel products are not suitable for, and shall not be used in, automotive applications. Atmel’s products are not intended, authorized, or warranted for use
as components in applications intended to support or sustain life.

© 2010 Atmel Corporation. All rights reserved. Atmel®, Atmel logo and combinations thereof, AVR® and others are registered trademarks or
trademarks of Atmel Corporation or its subsidiaries. Other terms and product names may be trademarks of others.

2543LS–AVR–08/10
