I128SYSM+
PoE+ Indoor 1' x 2' Suspended Ceiling Mount IP Loudspeaker with Microphone
1/5
Features
Network Features
• Dynamic or Static IP Address
• IEEE802.3 10/100Base-T Ethernet
• IEEE 802.1q Tagging
• IEEE 802.11AT Compliant
VoIP Standard Audio
• G.711 u-law/a-law (64 kbit/s)
• G.729 Wideband Audio (64 kbit/s)
Auto Provisioning
• DHCP Option 66, 150, or TFTP Server
• DHCP Option 72 for HTTP Server
Auto Registration
• SLP for InformaCast
• DHCP Option 72 for SA-Announce or GCK
Static Configuration
• HTTP GUI for Static Configuration
• Cisco SRST
Audio Features
• Integrated Amplifier
• 15-Watt Tot al Power
• Primary Speaker Output 8Ω
• Aux Audio Line-In Unbalanced (2.8Vpp 10K)
• Aux Audio Line-Out Unbalanced (2.8Vpp 10K)
Additional Features
• 2 General Purpose Inputs
• 1 General Purpose Output (2A @ 30 VDC)
• Phone/Night Loud Ringer
• External Power Supply Option
• Highly Efficient Horn Loudspeaker Provides Greater Output
and Coverage
• Integrated Microphone Allows for Half-Duplex or Full-Duplex Paging
Based on Software Platform
©2016 Atlas Sound L.P. and Innovative Electronic Designs, LLC. All Rights Reserved. Atlas Sound is a trademark of Atlas Sound L.P. IED is a registered trademark of Innovative Electronic Designs, LLC. All other trademarks are the property of their respective owners.
All specs are subject to change without notice. ATS005405 RevA 2/16
General Description
AtlasIED I128SYSM+ is a 1' X 2' suspended ceiling mount IP
loudspeaker with integrated microphone. It leverages VoIP
communication to extend tele-presence with enhanced audio for
environments where network-wide communication is desired and
high-output loudspeakers are required to overcome high ambient noise
and/or large spaces.
Applications
AtlasIED I128SYSM+ registers as a communication endpoint directly
within InformaCast, GCK, and SA-Announce advanced notification
applications, supporting audio broadcast to enhance physical security
while improving day-to-day communications through advanced alerting,
bell schedules, pre-recorded & scheduled announcements, while
leveraging the WAN or LAN network architecture.
When used within a Cisco environment, the I128SYSM+ loudspeakers
can join Cisco’s Unified Survivable Remote Site Telephony (SRST)
as a supported device. Cisco’s SRST provides remote location
call-processing redundancy when access to the centralized Cisco
Unified Communications Manager is interrupted because of a WAN
outage. The ability of LAN communication between any combination
of phones and loudspeakers is particularly critical during an emergency
(which may be the actual cause of the WAN outage).
Where 3rd party notification applications are not required, the
I128SYSM+ suspended ceiling mount loudspeaker with integrated
microphone can register as SIP devices directly to a SIP server or
VoIP Communications Manager for critical alerts and public address
applications.
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
AtlasIED.com
System
Type PoE+ Indoor 1' x 2' Suspended Ceiling Mount IP Loudspeaker with Microphone
Operation Mode Self Powered
Indicators Network Status (On Back)
Operating Range (-10db) 70Hz - 15.5kHz
Frequency Response (+/- 5dB) 86Hz - 15.5kHz
Vertical Coverage 105° 800Hz - 4kHz
Horizontal Coverage 105° 800Hz - 4kHz
Directivity Factor (Q) 4.7 @ 2 kHz
Max SPL at 1 m (passive) 95 dB SPL Continuous / 98 dB SPL Peak
Recommended Signal Processing Built-In Processing
General Purpose Interface Two Trigger Inputs / One Relay Output (2A @ 30 VDC)
Transducers
Transducer Qty and Size 8"
Voice Coil Size 1"
Cone Material Curvelinear, Treated Industrial Paper
Driver Protection Built-In Limiter
Amplication
Type Single-Channel Class D Topology
AC Power Input PoE or PoE+ and External 24VDC
Power Rating (RMS) 15 Watts Max (802.3AT)
THD <.02%
Cooling Passive/Convection
Microphone
Sensitivity Minus 35 (±4dB) / (0db = 1V/pa, 1kHz)
Impedance Less than 2.2kΩ
Directivity Omnidirectional
Frequency Range 20Hz – 20kHz
Standard Operation Voltage 2V
Max. Operation Voltage 10V
Current Consumption Max. 0.5 mA
Sensitivity Reduction Within Minus 3dB @ 1.5V
S/N Ratio More than 62dB
Audio Inputs and Outputs
Input: Analog Audio Type(s) One Unbalanced Analog
Input: Analog Connectivity Secured Screw Terminal Block
Input: Network Audio Type(s) G.711 U-Law/A-Law and G.722 Capable
Input: Network Connectivity RJ-45 Female
Output: Analog Audio Type(s) One Unbalance Line Level
Output: Analog Connectivity Secured Screw Terminal Block
Output: Digital Audio Type(s) N/A
Output: Digital Connectivity N/A
Output: Loudspeaker Level 8Ω, 9W (802.3AF), 15W (802.3AT)
Output: Loudspeaker Connectivity Two x Secured Screw Terminal Block
Software
SA-Announce Compatible Versions 9.0.18+
InformaCast Compatible Version 8.0+
GCK Compatible Version 3.0+
Network
Ethernet IEEE802.3 10/100Base-T
POE IEEE802.3AF/AT Compliant
VLAN IEEE802.1q Tagging
©2016 Atlas Sound L.P. and Innovative Electronic Designs, LLC. All Rights Reserved. Atlas Sound is a trademark of Atlas Sound L.P. IED is a registered trademark of Innovative Electronic Designs, LLC. All other trademarks are the property of their respective owners.
All specs are subject to change without notice. ATS005405 RevA 2/16
2/5
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
AtlasIED.com
Protocols
C10A Polars (Normalized to Zero on Axis) (-6dB)
C10A Impedance
C10A Frequency Response
IP Addressing DHCP/Static
Auto-Provisioning HTTP/TFTP
Auto-Registration HTTP/Service Location Protocol/IEDNet
Time NTP
Telephony SIP
Enclosure
Color White
Grille Material Powder Coated Steel with 22-gauge Perforated Steel
Baffle Material 18-gauge Corrosion-Resistant Zinc Plated Steel
Mounting/Rigging Provisions Lay-In Into A Reflected Ceiling Grid
Safety Agency Ratings ETL Listed to Comply with UL-60950-1, and CAN/CSA-C22.2 No. 60950-1
Ingress Protection IP-XX (Not Rated)
Logo Blue and Removable
Product Dimensions (HxWxD) 11.94" (303mm) x 25.67" (652mm) x 5.06" (128.5mm)
Shipping Dimensions (HxWxD) 12.5" (318mm) x 25.25" (641mm) x 5.5" (140mm)
Net Weight - lbs 10 lbs (4.54kg)
Shipping Weight - lbs 12.8 lbs (5.81kg)
Warranty Coverage
Warranty Period 1 Year
3/5
NOTES:
1. Sensitivity: Half space pink noise measurement at 6 ft (1.8 m) at 20% power; extrapolated to 1 meter and an input of 2.83 volts RMS.
2. Watts: All wattage figures are calculated using the rated nominal impedance.
3. Frequency response and sensitivity are half-space measurements.
©2016 Atlas Sound L.P. and Innovative Electronic Designs, LLC. All Rights Reserved. Atlas Sound is a trademark of Atlas Sound L.P. IED is a registered trademark of Innovative Electronic Designs, LLC. All other trademarks are the property of their respective owners.
Ohms
SPL in dB
Frequency (Hz)
All specs are subject to change without notice. ATS005405 RevA 2/16
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
Frequency (Hz) Octave Smoothing = 30.0%
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
AtlasIED.com
Dimensional Drawings
ENCLOSURE
REMOVED
(-)
(+)
RJ45 NETWORK
AUX POWER
24VDC @ 1A
FORCE
DISCOVERY
JUMPERS A,B,C
SERVICE
SWITCH
IP SPEAKER
CONNECTOR
BLOCK (PIN1)
IP SPEAKER CONNECTOR BLOCK
PIN
FUNCTION
1
REMOTE BUTTON / GPI 2 (+)
2
REMOTE BUTTON / GPI 2 (-)
3
REMOTE BUTTON / GPI 1 (+)
4
REMOTE BUTTON / GPI 1 (-)
5
RELAY (-)
6
RELAY - NORMALLY OPEN (+)
7
LINE-IN (-)
8
LINE-IN (+)
9
LINE-OUT (-)
10
LINE-OUT (+)
11
PRIMARY SPEAKER (-)
12
PRIMARY SPEAKER (+)
13
SECONDARY SPEAKER (-)
14
SECONDARY SPEAKER (+)
8
7
6
5
4
3
2
1
1/2" & 3/4"
CONDUIT
DOUBLE KO
ENCLOSURE
REMOVED
FOR CLARITY
(-)
(+)
RJ45 NETWORK
AUX POWER
24VDC @ 1A
FORCE
DISCOVERY
JUMPERS A,B,C
SERVICE
SWITCH
IP SPEAKER
CONNECTOR
BLOCK (PIN1)
INCLUDES QTY 1 TEE BAR ADAPTER (2 FT)
FOR INSTALLATION INTO STANDARD DROP
CEILING
IP SPEAKER CONNECTOR BLOCK
PIN
FUNCTION
1
REMOTE BUTTON / GPI 2 (+)
2
REMOTE BUTTON / GPI 2 (-)
3
REMOTE BUTTON / GPI 1 (+)
4
REMOTE BUTTON / GPI 1 (-)
5
RELAY (-)
6
RELAY - NORMALLY OPEN (+)
7
LINE-IN (-)
8
LINE-IN (+)
9
LINE-OUT (-)
10
LINE-OUT (+)
11
PRIMARY SPEAKER (-)
12
PRIMARY SPEAKER (+)
13
SECONDARY SPEAKER (-)
14
SECONDARY SPEAKER (+)
8
7
6
5
4
3
2
1
MODEL
SCALE
ATLAS SOUND
A MITEK COMPANY
1601 JACK McKAY BLVD.
PH:972-875-8413 FAX:972-875-8416
REV.
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
MITEKCORP. ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
MITEKCORP IS PROHIBITED.
ENCLOSURE
REMOVED
FOR CLARITY
(-)
(+)
RJ45 NETWORK
AUX POWER
24VDC @ 1A
FORCE
DISCOVERY
JUMPERS A,B,C
SERVICE
SWITCH
IP SPEAKER
CONNECTOR
BLOCK (PIN1)
IP SPEAKER CONNECTOR BLOCK
PIN
FUNCTION
1
REMOTE BUTTON / GPI 2 (+)
2
REMOTE BUTTON / GPI 2 (-)
3
REMOTE BUTTON / GPI 1 (+)
4
REMOTE BUTTON / GPI 1 (-)
5
RELAY (-)
6
RELAY - NORMALLY OPEN (+)
7
LINE-IN (-)
8
LINE-IN (+)
9
LINE-OUT (-)
10
LINE-OUT (+)
11
PRIMARY SPEAKER (-)
12
PRIMARY SPEAKER (+)
13
SECONDARY SPEAKER (-)
14
SECONDARY SPEAKER (+)
D
6
5
4
3
2
1
E
F
D
4
3
2
1
E
F
IP SPEAKER CONNECTOR BLOCK
PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
FUNCTION
REMOTE BUTTON / GPI 2 (+)
REMOTE BUTTON / GPI 2 (-)
REMOTE BUTTON / GPI 1 (+)
REMOTE BUTTON / GPI 1 (-)
RELAY (-)
RELAY - NORMALLY OPEN (+)
LINE-IN (-)
LINE-IN (+)
LINE-OUT (-)
LINE-OUT (+)
PRIMARY SPEAKER (-)
PRIMARY SPEAKER (+)
SECONDARY SPEAKER (-)
SECONDARY SPEAKER (+)
FORCE
DISCOVERY
JUMPERS A,B,C
SERVICE
SWITCH
IP SPEAKER
CONNECTOR
BLOCK (PIN1)
4/5
(-)
(+)
AUX POWER
24VDC @ 1A
1/2" & 3/4"
CONDUIT
DOUBLE KO
4.92
ACCESS COVER
1/2" & 3/4"
CONDUIT
DOUBLE KO
1/2" & 3/4"
CONDUIT
DOUBLE KO
23.69
ENCLOSURE
REMOVED
FOR CLARITY
11.94
RJ45 NETWORK
©2016 Atlas Sound L.P. and Innovative Electronic Designs, LLC. All Rights Reserved. Atlas Sound is a trademark of Atlas Sound L.P. IED is a registered trademark of Innovative Electronic Designs, LLC. All other trademarks are the property of their respective owners.
All specs are subject to change without notice. ATS005405 RevA 2/16
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
AtlasIED.com
Architect and Engineer Specications
The unit shall be AtlasIED model I128SYSM+. The loudspeaker system
shall include factory assembled loudspeaker, integrated talkback
microphone, IP addressable PCB amplifier/ control, metal baffle and
loudspeaker back box. The loudspeaker shall be an 8" driver with a 10oz
(260g) ceramic magnet and seamless cone. The impedance shall be 8
ohm and a voice coil diameter of 1" (25mm). The loudspeaker dispersion
shall be 105° (800Hz - 4kHz) and frequency response of 86Hz – 15.5kHz
(±5dB). The max peak output at 1W/1m shall be 98dB SPL. The
loudspeaker shall have a mounting design so the entire assembly lays
into the reflected ceiling tile grid and replaces a portion of the ceiling tile.
The amplifier/control board shall be capable of producing 15-watts
RMS when using an IEEE 802.3at compatible PoE+ switch or 24VDC
local power supply and 9-watts RMS when used with an IEEE 802.3af
compliant PoE switch. Interconnect shall be via female RJ-45 connector
mounted to the PCB.
All control functionality shall be determined via software. The metal
loudspeaker baffle overall dimensions shall be 11.94" (303mm) x
23.6" (601mm) x 5" (128.5mm). Finish shall be neutral white
electrostatic powder coat.
5/5
©2016 Atlas Sound L.P. and Innovative Electronic Designs, LLC. All Rights Reserved. Atlas Sound is a trademark of Atlas Sound L.P. IED is a registered trademark of Innovative Electronic Designs, LLC. All other trademarks are the property of their respective owners.
All specs are subject to change without notice. ATS005405 RevA 2/16
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
AtlasIED.com
Loading...
