Features

Range - 9 kHz - 3 GHz

Resolution bandwidth - 9 & 120 kHz

Large TFT Color Display

Lightweight

Spectrum Analyzer

SPA-3000

Description

The SPA-9300 is a high performance, low cost, easy
to use, portable spectrum analyer for EMI testing.
It has wide frequency range and low noise fl oor to
enhances measurement range. Advanced easy to use
interface make your work simple. SPA-3000 offers
you the greatest performance-price ratio in the market.

User-oriented interface design allow easy operation of
complex functionalities. A high-resolution 6.4" color
TFT LCD provides high quality image display . T races
are drawn in different colors, allowing recognition of
small disparities at a glance. Split window mode deliv­ers the ability for monitoring two different bands on the
same display, making user have two alternate-sweep
spectrum analyzers in one single unit.

The SP A-3000 can be used as standalone measurement
device without PC connection. Users can defi ne their
own macros through the keypad on the front panel and
stored in 10 Sequence sets. Running sequence can be
paused for measured result observation or staff inter­vention. Repeat or Single run mode can be selected for
different applications. Sequence function can quite fi t
for EMC testing, production and education.

Application

The SPA-3000 Spectrum Analyzer is extremely valu­able for locating the EMI noise source on systems in
order to meet various regulatory agency requirements.
Its features and affordable price allows design engi­neers to use it to perform preliminary radiated and
conducted EMI testing.

Wide measurement range and state-of-the-art design,
SP A-3000's has outstanding noise fl oor level, -1 52dBm/
Hz @ 600MHz. This allow measurement of weak sig­nals during EMI emission testing. The sensitivity can
further increased by using the an optional preamplifi er.
It can also used with near fi eld probes, antennas and
Line impedance stabilization network for a complete
EMI testing solution.

The front panel has a USB USB fl ash drive for various
fi le transactions, such as setup info, trace data, and
display images. In addition, it also supports printers
with USB ports for direct print out.

The backpanel has a GPIB connector for remote
control using PC software.

Com-Power Corporation (714) 528 - 8800 www. com-power.com [e-mail]
