SMRT36
Megger Relay Test System
n
Small, rugged, lightweight and powerful
n
Operate with or without a computer
n
Intuitive manual operation with
Smart Touch View Interface
n
High current, high power output
(60 Amps/300 VA rms) per phase
n
Convertible channels provides 6 currents
n
Network interface provides IEC 61850
test capabilities
n
Optional transducer test capability
SMRT36
Megger Relay Test System
SMRT36 with optional
Transducer hardware
DESCRIPTION
For size, weight, and features the SMRT36 is conceivably the
smallest, lightest, highest output powered, complete three phase
relay test system in the world today. The test system may be
customized by adding the number of Voltage-Current, “VIGEN”,
modules needed for specific test applications. The SMRT36 has the
“smart” combination of high compliance voltage and high current
to test all electromechanical, solid-state and microprocessor-based
overcurrent relays, including voltage controlled, voltage restraint
and directional overcurrent.
The SMRT36 with three VIGEN Modules provides a complete threephase test system for commissioning of three phase protection
systems. With the voltage channels converted to currents, the same
unit can provide 6-phase current. The SMRT36 VIGEN modules also
provide high power in BOTH the voltage and current channels to
test virtually all types of protective relays.
n
Fully automated testing using
AVTS Software
The SMRT36 test system has the ability to be manually controlled
with Megger’s new Smart Touch View Interface™ (STVI). The STVI,
with its large, full color, high resolution, TFT LCD touch screen
allows the user to perform manual, steady-state and dynamic
testing quickly and easily using the manual test screen, as well as
using built-in preset test routines for most popular relays.
The STVI eliminates the need for a computer when testing virtually
all types of relays. Menu screens and touch screen function buttons
are provided to quickly and easily select the desired test function.
Tests results can be saved to the STVI for download to a memory
stick to transfer or print test reports.
For full automatic testing the SMRT36 may be controlled by Megger
Advanced Visual Test Software (AVTS). AVTS is a Microsoft
Windows® XP®/Vista™/7 compatible software program designed to
manage all aspects of protective relay testing using the new Megger
SMRT.
APPLICATIONS
Each current channel is rated for 30 Amps @ 200 VA continuous,
up to 60 Amps @ 300 VA for short durations. It has a unique flat
power curve from 4 to 30 Amps that insures maximum compliance
voltage to load at all times. Three currents in parallel provide up
to 180 Amps @ 900 VA for instantaneous tests. With a maximum
compliance voltage of 50 Volts per phase, with just two channels
in series provides 100 Volts of compliance voltage to test high
impedance relays.
®
SMRT36 with STVI
SMRT36
Megger Relay Test System
Each voltage channel can provide variable outputs of 0- 30/150/
300 Volts at 150 VA of output power, and has a unique flat power
curve from 30 to 150 Volts insuring maximum output power to the
load at all times. With the voltage channel converted to current, a
three channel unit can provide 6 currents for testing three phase
current differential relays, including harmonic restraint transformer
differential relays.
Using the Ethernet ports, the SMRT36 is literally a “plug-andplay” unit, where voltage and current outputs can be seamlessly
synchronized with other SMRT units outputs for testing more
complex test applications such as back-to-back tests, or 9 up to12
phase current test applications.
FEATURES AND BENEFITS
Constant Power Output – New higher powered Voltage-Current
amplifiers. The current amplifier delivers maximum compliance
voltage to the load constantly during the test, and range changing
is done automatically under load. This insures better test results,
and saves time by not having to turn the outputs off to change
ranges. Constant power output in many cases eliminates the need
to parallel or series current channels together to test high burden
relays.
High Output Current – Provides up 30 Amps at 200 VA per phase
continuous, or up to 60 Amperes at 300 VA with a 1.5 second duty
cycle. The three current amplifiers can be paralleled to provide a
maximum of 180 Amperes at 900 VA, for testing all instantaneous
overcurrent relays.
New PowerVTM Voltage Amplifier High Power Output –
The SMRT provides a new higher VA power output on the voltage
channel at the lower critical test voltages (from 30 to 150 Volts).
Customers who want to test a panel of relays at one time find it
impossible using lower VA rated voltage.
Convertible Voltage Channels – With a 3 channel SMRT36 unit,
convertible channels in conjunction with the three main current
channels, provides 6 currents for testing three phase current
differential relays. With all six currents in parallel the unit can
provide a maximum single phase output of 225 Amperes for short
durations.
High resolution and accuracy – Metered outputs provides
extremely high accuracy needed for testing a wide variety of
devices. With metered values, what you see is what you get.
Steady-State and Dynamic testing capability – The SMRT36
provides, either through manual control or computer control, both
steady-state and dynamic testing of protective relays. This includes
programmable waveforms with dc offset and harmonics.
Output current and voltage sine waves are generated
digitally – Outputs do not vary with sudden changes in input
voltage or frequency, which increases test accuracy and reduces
testing time.
Modular design – Output modules plug-in and out easily for
system re-configuration and maintenance.
Built-in Transducer Testing Capability – The SMRT36P
incorporates high accuracy amplifiers, an optional transducer DC
input and test algorithms to test transducers easily and effectively.
Digital binary inputs and outputs – The programmable binary
inputs, and programmable outputs provide timing and logic
operations in real-time with the output voltage and currents. Binary
Inputs can be programmed, using Boolean logic, for more complex
power system simulations. This provides a low cost, closed loop,
power system simulator.
Circuit breaker simulator – Binary outputs provide programmable
normally closed and normally open contacts to simulate circuit
breaker operation for testing reclosing relays. Sequence of
operation, timing, and lockout are easily tested.
Performs transient tests – Perform acceptance or troubleshooting
tests by replaying digitally recorded faults or EMTP/ATP simulations
in the IEEE- C37.111, COMTRADE Standard format.
Perform End-to-End tests – Using AVTS software and a portable
GPS satellite receiver, the SMRT performs satellite-synchronized endto-end dynamic multi-state or playback transient COMTRADE files
either for commissioning or troubleshooting tests.
Wide-ranging output frequency – The output frequency of the
current and voltage channels can be set for any frequency from dc
to 1 kHz. Popular test frequencies such as 16.66, 25, 33, 50, 60,
100,120, 125, 150, 180, 250, 300 and 400 Hz are easily set and
controlled. Multi-purpose test system saves time and money.
USB 2.0 interface port – The USB port provides a PC interface for
automated control of the SMRT unit. Also provides secure isolation
when testing IEC 61850 devices (for customers who require secure
isolation from their IEC 61850 substation bus).
Three Ethernet ports – PC/OUT Ethernet Port is the primary PC
connection port. The IN/IEC61850 Ethernet Port provides interface
to multiple SMRT units, and may be used to connect to the IEC
61850 substation bus. The OUT Ethernet Port is primarily used to
interconnect multiple SMRT units together for synchronous multiunit operation. The STVI PoE (Power over Ethernet) port and is used
to connect to the STVI.
Bluetooth – Optional Bluetooth provides more flexibility. A wireless
interface between the PC and SMRT, in conjunction with the SMRT
IEC 61850 Ethernet port, provides the isolation required for a secure
substation access interface between the SMRT and the IEC 61850
substation network.
Universal input voltage – Operation from 90 to 264 Vac, 50/60
Hz, the SMRT can use virtually any standard source in the world.
Immediate error indication – Audible and visual alarms indicate
when amplitude or waveforms of the outputs are in error.
Optional Transducer Testing Capability – This optional hardware
feature (see Ordering Information) provides transducer DC Inputs to
test transducers easily and effectively. The STVI software is designed
to automatically recognize the Transducer DC Inputs, and thus
provide the Transducer Test Screen when selected. AVTS software
comes standard with Transducer Test Modules, which will provide
automatic transducer test capability in conjunction with the optional
hardware.
2
SMRT36
Megger Relay Test System
SMRT36 RELAY TESTER
4
5
3
2
1
6
17
16
7
15
8
12
9
1. Binary Outputs 1 and 2: Rated for 300 V at 8 Amps.
2. Binary Inputs 1 and 2: Rated 5 to 300 V AC/DC.
3. Transducer Input: (Optional) DC voltage and DC milliamp
input terminals.
4. Voltage Outputs: Up to 3 channels 300 V at 150 VA,
convertible to currents 15 A at 120 VA per phase.
5. Current Outputs: Up to 3 channels 60 Amps at 300 VA per
phase. Up 180 Amps at 900 VA single phase.
6. USB 2.0 Interface: Communication and control port.
7. Additional Binary Inputs: Provides 8 additional monitor
circuits.
8. Rugged Case: Fiberglass reinforced plastic.
9. PC/OUT: Ethernet Port is the primary PC connection port.
Ethernet Port used to chain multiple SMRT units together for
synchronous multi-unit operation.
10. Additional Binary Outputs: Adds 4 outputs. Binary Outputs 3
and 4 are rated for 300 V AC/DC, 8 amperes. Binary Outputs 5
and 6 are high speed and have an AC/DC voltage rating of 400
volts peak, 1 ampere.
11. IN/61850: This port may also be used for connecting to the IEC
61850 substation bus for testing IEC 61850 devices.
12. STVI: Ethernet Port is a PoE (Power over Ethernet) port and is
used to connect to the STVI for manual control.
13. Battery Simulator: Variable 5 to 250 Volts DC output at 100
Watts (4 amperes maximum).
14. Incoming Power/Line Cord Socket: 100 to 240 V,
50/60 Hz.
15. POWER ON/OFF Switch: Illuminates when power is on.
16. Protective Earth Ground Jack.
17. Bluetooth: Bluetooth© provides wireless control.
1110
14
13
APPLICATIONS SELECTION GUIDE
Protective Relays
by IEEE Device #
2 Time Delay
Distance Single
21
Phase
Distance Three
21
Phase Open Delta
Distance Three
21
Phase wye
24 Volts/Hz
25 Synchronizing
27/59 Under/Over Voltage
Directional Power
32
Single Phase
Directional Power
32
Three Phase
(Open Delta)
DC Under/Over
37/76
Voltage/Current
40 Loss of Field
Phase Balance
46
Current
Negative Sequence
46N
Overcurrent
Phase Sequence
47
Voltage
(Open Delta)
Instantaneous
50
Overcurrent
Time Delay
51
Overcurrent
55 Power Factor
Voltage/Current
60
Balance
(Open Delta)
Directional
67
Overcurrent
Ground Directional
67N
Overcurrent
78 Out of Step
79 Reclosing
81 Frequency
85 Carrier or Pilot Wire
87 Differential
Voltage Directional
91
(Open Delta)
Voltage and Power
92
Directional
(Open Delta)
94 Tripping
SMRT36
Single
Channel
n n n
n n n
n n n
n n n
n n n
n n n
n n n
n n n
n n n
Up to
75 Amps
Up to
35 Amps
n n n
Single
Phase
n n n
n n n
n n n
n n n
n n n
n n n
n n n
n n n
SMRT36
Two
Channels
n n
n n
(n) n
(n) n
Up to
150 Amps
Up to
70 Amps
(n) n
(n) n
(n) n
SMRT36
Three
Channels
n
Up to
225 Amps
Up to
105 Amps
3
SMRT36
Megger Relay Test System
SPECIFICATIONS
1
Input Power
The input voltage rating varies depending upon the style number.
Universal units, the input voltage may be from 100 to 240 VAC,
± 10%, 50/60 Hertz. CE Marked units, the input voltage may be
from 220 to 240 VAC, ± 10%, 50/60 Hertz. Total maximum output
power will be limited for CE marked units . Input current required
varies with the number of output modules in use, load, and input
voltage value. With three VIGENS, the maximum input power is
1800VA.
Outputs
All outputs are independent from sudden changes in mains voltage
and frequency, and are regulated so changes in load impedance do
not affect the output. All amplifier outputs are isolated or floating.
The SMRT units can be ordered with the amplifier common returns
tied to chassis ground as an option.
Output Current Sources
The SMRT36 with three VIGEN modules can provide up to
six current sources; three high current/high power, and three
convertible channels providing lower current/high power. The per
channel output current and power ratings are specified in AC rms
values and peak power ratings.
Output Current Power Max V/Duty Cycle
1 Ampere 15 VA 15.0 Vrms Continuous
4 Amperes 200 VA (282 peak) 50.0 Vrms Continuous
15 Amperes 200 VA (282 peak) 13.4 Vrms Continuous
30 Amperes 200 VA (282 peak) 6.67 Vrms Continuous
60 Amperes 300 VA (424 peak) 5.00 Vrms 90 Cycles
DC 200 Watts
With three currents in parallel:
Output Current Power Max V/Duty Cycle
12 Amperes 600 VA (848 peak) 50.0 Vrms Continuous
45 Amperes 600 VA (848 peak) 13.4 Vrms Continuous
90 Amperes 600 VA (848 peak) 6.67 Vrms Continuous
180 Amperes 900 VA (1272 peak) 5.00 Vrms 90 Cycles
Current Amplifier - Extended Power Range
The SMRT current amplifier provides a unique flat power curve from
4 to 30 Amperes per phase to permit testing of electromechanical
high impedance relays, and other high burden applications, with an
extended operating range up to 60 Amperes at 300 VA rms.
AC Voltage Output
Outputs are rated with the following Ranges:
Output Volts Power Max I
30 Volts 150 VA 5 Amps
150 Volts 150 VA Variable
2
300 Volts 150 VA 0.5 Amps
DC 150 Watts
Duty Cycle: Continuous
With two voltages in series
The output voltage and power doubles to provide 600 volts at
300 VA.
"PowerV" Voltage Amplifier Output Power Curves
“PowerVTM” Voltage Amplifier - Extended Power Range
The SMRT voltage amplifier provides a flat power curve from 30
to 150 Volts in the 150V range to permit testing of high current
applications such as panel testing.
Voltage Amplifier in Current Mode:
The voltage amplifier is convertible to a current source with the
following output capability. Output power ratings are specified in
rms values and peak power ratings.
Output Current Power Max V Duty Cycle
5 Amperes 150 VA 30.0 Vrms Continuous
(212 peak)
15 Amperes 120 VA 8.0 Vrms 90 Cycles
Phase Angle
Ranges: 0.00 to 359.99 degrees, Counter Clock Wise, or Clock
Wise rotation, or 0.00 to ±180.00 degrees
Accuracy: ±0.02° typical, ±0.25° max at 50/60 Hz
Current Amplifier Output Power Curve
With two currents in series:
The compliance voltage doubles to provide 4.0 Amperes at 100
Volts rms.
1
Megger reserves the right to change product specifications at any time.
2
PowerVTM voltage amplifier output current varies depending on the voltage setting on the 150 Volt range, see curve.
4
SMRT36
Megger Relay Test System
Frequency
The output modules provide a variable frequency output with the
following ranges and accuracy.
Ranges
DC
0.001 to 1000.000 Hz
Output amplifiers can provide transient signals with a range of
DC to 10 kHz for transient playback using COMTRADE files.
Resolution*: .0001/.001 Hz
Frequency Accuracy:
2.5 ppm typical
25 ppm 0° to 50° C, at 50/60 Hz Maximum
Total Harmonic Distortion
Less than 0.1% typical, 2% maximum at 50/60 Hz
Timer
The Timer-Monitor Input is designed to monitor and time-tag
inputs, like a sequence of events recorder. In addition, the binary
input controls enable the user to perform logic AND/OR functions,
and conditionally control the binary output relay to simulate circuit
breaker, trip, reclose and carrier control operation in real-time. The
Timer function displays in Seconds or Cycles, with the following
range and resolution:
Seconds: 0.0001 to 99999.9
(Auto Ranging)
Cycles: 0.01 to 99999.9
(Auto Ranging)
Accuracy: ±0.001% of reading, typical. ±2 least significant digit,
±0.005% of reading from 0 to 50° C maximum
Binary Input – Start/Stop/Monitor Gate
To monitor operation of relay contacts or trip SCR, continuity light
is provided for the input gate. Upon sensing continuity the lamp will
glow. In addition to serving as wet/dry contacts the Binary Inputs
may be programmed to trigger binary output sequence(s).
Input Rating: up to 300 V AC/DC
Binary Output Relays
SMRT36 has independent, galvanically isolated, output relay
contacts to accurately simulate relay or power system inputs to
completely test relays removed from the power system. The binary
output simulates normally open / normally closed contacts for
testing breaker failure schemes. The binary output can be configured
to change state based on binary input logic.
High Current Output Relays: The first two VIGEN Modules have
1 each and the P option add 2 more.
AC Rating: 400 V max., Imax: 8 amps, 2000 VA max.
DC Rating: 300 V max., Imax: 8 amps, 80 W
Response Time: <10ms
High Speed Output Relays: SMRT36 P Option adds 2
AC/DC Rating: 400 V peak, Imax: 1 amp
Response Time: <1ms typical
Battery Simulator
The SMRT36 with the P (Plus) option includes a battery simulator
with a variable DC output voltage ranging from 5 to 250 Volts at
100 Watts, 4 Amps max, providing capability to power up relays
with redundant power supplies. Voltage output is controlled via
the Smart Touch-View Interface, or through AVTS software. The
SMRT36 with the N option does not include a battery simulator.
Waveform Generation
Each output channel can generate a variety of output waveforms
such as: DC; sine wave; sine wave with percent harmonics at various
phase angles; half waves; square waves with variable duty cycles;
exponential decays; periodic transient waveforms from digital fault
recorders, relays with waveform recording capability or EMTP/
ATP programs, which conform to the IEEE C37.111 COMTRADE
standard format.
Metering
Measured output quantities such as AC Amperes, AC Volts, DC
Volts or DC Amperes, and Time may be simultaneously displayed
on the large, color TFT LCD touch screen. The AC and DC outputs
display the approximate voltage/current output prior to initiation of
the outputs. All accuracies stated are from 10 to 100% of the range
at 50/60Hz.
AC Voltage Amplitude
Accuracy: ±0.05 % reading + 0.02 % range typical,
±0.15 % reading + 0.05 % range maximum
Resolution: .01
Measurements: AC RMS
Ranges: 30, 150, 300V
AC Current Amplitude
Accuracy: ±0.05 % reading + 0.02 % range typical,
±0.15 % reading + 0.05 % range maximum
Resolution: .001/.01
Measurements: AC RMS
Ranges: 30, 60A
DC Voltage Amplitude
Accuracy: 0.1% range typical,
0.25% range maximum
Resolution: .01
Measurements: RMS
Ranges: 30, 150, 300V
DC Current Amplitude
Accuracy: ±0.05 % reading + 0.02 % range typical,
±0.15 % reading + 0.05 % range maximum
Resolution: .001/.01
Measurements: RMS
Ranges: 30A
5
SMRT36
Megger Relay Test System
Convertible Source in AC Current Mode
Accuracy: ±0.05 % reading + 0.02 % range typical,
±0.15 % reading + 0.05 % range or ±12.5 mA whichever is greater
Resolution: .001
Measurements: AC RMS
Range: 5, 15A
The DC IN input terminals
Range: 0 to ±10 V DC
0 to ± 20 mA DC
Accuracy: ±0.02% Typical
±0.05% Max FS
Measurements: Average
DC IN Inputs (Optional Transducer Feature)
DC IN Volts
Range: 0 to ±10 V DC
Accuracy: ±0.001% reading + 0.005% range Typical
±0.003% reading + 0.02% range Max
Resolution: .001
Measurements: Average
DC IN Amperes
Range: 0 to ±1 mA DC
4 to ±20 mA DC
Accuracy: ±0.001% reading + 0.005% range Typical
±0.003% reading + 0.02% range Max
Resolution: .001
Measurements: Average
Environmental
Operating Temperature: 32 to 122° F (0 to 50° C)
Storage Temperature: -40 to 158° F (-40 to 70° C)
Relative Humidity: 5 - 90% RH, Non-condensing
Unit Enclosure
The SMRT unit comes housed in a rugged, virtually indestructible,
lightweight and ergonomic enclosure. It features a large oversized
rubber cushioned handle, and removable lid for use in tight spaces.
Dimensions
With the lid on:
14.2 W x 7.6 H x 12.0 D in.
(360 W x 194 H x 305 D mm)
With the lid off:
14.2 W x 7.2 H x 12.0 D in.
(360 W x 180 H x 305 D mm)
IEC Enclosure Rating: IP30
Weight
With the transit lid on: 27.9 lb. (12.55 kg)
With the transit lid off: 25.8 lb. (11.6 kg)
Conformance Standards
Safety: EN 61010-1
Shock: MIL-PRF-28800F (30 g/11ms half-sine)
IEC 60068-2-27 (15 g/11 ms half-sine)
Vibration: MIL-PRF-28800F (10-500 Hz, 2.05 g rms)
IEC 60068-2-6 (10-150 Hz, 2 g)
Transit Drop: MIL-PRF-28800F (10 drops, 46 cm), ISTA 1A
Electromagnetic Compatibility
Emissions: EN 61326-2-1, EN 61000-3-2/3,
FCC Subpart B of Part 15 Class A
Immunity: EN 61000-4-2/3/4/5/6/8/11
Protection
Voltage outputs are protected from short circuits and thermally
protected against prolonged overloads. Current outputs are
protected against open circuits and thermally protected against
prolonged overloads.
Communication Interfaces
Ethernet (2)
USB 2.0
Bluetooth (optional)
SOFTWARE
AVTS – STVI Basic
Every unit comes with AVTS Basic software and the PC version
of the STVI Basic software packages. AVTS Basic version includes
Online Vector control (for single and multi-state timing tests), Online
Ramp control (for automatic ramping of voltage, current, phase
angles or frequency) and Online Click-On-Fault (for dynamic tests of
impedance relays). Test results may be exported directly to Microsoft
Word. AVTS software includes a database for saving test results,
which can also provide the necessary information needed for system
reliability audits. See AVTS bulletin for more information.
The PC version of the STVI software includes the ability to bring all
STVI test data (from other STVI units) into file folders for retrieval,
review and printing whenever needed. See STVI bulletin for more
information.
AVTS Advanced
The AVTS Advanced version includes all the feature in AVTS Basic
plus the powerful Test Editor, Dynamic Control (includes dynamic
end-to-end testing capability, and waveform recording capability),
ASPEN OneLiner™ or Electrocon CAPE™ SS1 File Converter for
dynamic testing, and easy to use programming Tools for creating
and editing test modules. See AVTS bulletin for more information.
AVTS Professional
The AVTS Professional version includes all of the features of the
Basic and Advanced versions plus some other powerful test tools
and features. It includes the DFR Waveform Viewer, One-Touch™
Test for fully automatic tests, Modbus communication test
capability, and Waveform Digitizer to digitize scanned waveforms of
electromechanical over current time curves. See AVTS bulletin for
more information.
IEC 61850 GOOSE
The SMRT with the GOOSE enabled, in conjunction with the Megger
GOOSE Configurator (MGC) software, can be used in the testing or
commissioning of IEC 61850 compliant devices. See AVTS bulletin
for more information.
6
STYLE NUMBER IDENTIFICATION
SMRT36
Megger Relay Test System
ORDERING INFORMATION
Model SMRT36 -
Voltage/Current Modules
Enter 1, 2 or 3
Reserved for Future Use
Base Unit Options
N = No Extra Binary I/O
P = Plus Binary I/O & Battery Simulator
Smart Touch View Interface Option
1 = With STVI;
0 = Without
Common Returns Option
F = Floating Ungrounded Common Return
G = Grounded Common Returns
C = CE Mark, 220-240V Input, Floating
E = CE Mark, 220-240V Input, Grounded
Bluetooth Option
1 = With Bluetooth
0 = Without
0
Test Leads Option
1 = With Leads
0 = Without Leads
Hardware Options
S = Standard unit
T = Transducer
IEC61850 Option
1 = With IEC 61850 GOOSE
0 = Without
Power Cord Option
A = North American Power Cord
I = International Power Cord
E = Continental Europe Power Cord
U = United Kingdom
DESCRIPTION OF SOFTWARE OPTIONS
Included Software Part Number
AVTS Basic with STVI Application CD 81302
Software Options
AVTS Basic with IEC 61850 Megger GOOSE Configurator, and STVI Application CD 1002-103
AVTS Advanced with STVI Application CD 81570
AVTS Advanced Test with IEC 61850 Megger GOOSE Configurator, and STVI Application CD 1001-106
AVTS Professional with STVI Application CD 81571
AVTS Professional Test with IEC 61850 Megger GOOSE Configurator, and STVI Application CD 1002-102
DESCRIPTIONS OF HARDWARE OPTIONS
Voltage/Current Module: The SMRT36 unit can have up to a total
of 3 voltage/current modules. Enter the number of desired Voltage /
Current modules 1, 2 or 3.
Future: 0, Reserved for future use.
Base Unit Options: The first two channels provide 1 binary input
and 1 binary output each. Enter N for No extra binary I/O or battery
simulator. For the user who requires the extra binary inputs, outputs
and/or the battery simulator enter P for Plus option.
Smart Touch View Interface Option: Enter the number 1 for the
unit to come with the STVI, or enter the number 0 for without.
Common Returns Option: The floating returns option provides
independent, isolated return terminals for each output channel.
The grounded common returns option, the return terminals are
interconnected internally and connected to chassis ground. The CE
Mark C and E units are designed to operate with an input voltage of
220 to 240 Volts. The F and G units are designed to operate with an
input of 100 to 240 V.
Bluetooth Option: For customers, who wish to have a wireless
control of the SMRT unit, enter the number 1 for the unit to come
with the Bluetooth option, or enter 0 for without.
Power Cord Option: Customers can choose which type of power
cord they want the unit to come with.
• AOption – NEMA 5-15 to IEC60320 C13 connectors,
UL & CSA approved for countries with NEMA outlets.
• I Option - International color coded wires (light blue, brown and
green with yellow stripe) insulation jacket stripped ready for male
connector with IEC 60320 C13 connector.
CE marked.
• EOption - CEE 7/7 “Schuko” plug to IEC 60320 C13 connector
is CE marked.
• UOption - United Kingdom power cord with IEC 60320 C13
connector, and 13 Amp fuse. CE Marked.
Bluetooth Option: For customers who wish to have a wireless
control of the SMRT unit, enter the number 1 for the unit to come
with the Bluetooth option installed. Enter 0 for without.
IEC 61850 Option: The SMRT36 in conjunction with the Megger
GOOSE Configurator (MGC) software can be used in the testing
or commissioning of IEC 61850 compliant devices. In order for the
SMRT36 to be able to subscribe as well as publish GOOSE messages,
the IEC 61850 feature needs to be enabled. Enter the number 1 for
the unit to come with the IEC 61850 option enabled. Enter 0 for the
unit without IEC 61850 enabled.
7
SMRT36
Megger Relay Test System
Hardware Options: S for Standard hardware. T for Transducer
enabled.
Test Leads Option: Enter the number 1 for the unit to come with
Test Leads. Enter 0 for the unit without Test Leads.
Test Leads and Accessories
All units come with a power cord (see Power Cord option), and
Ethernet communication cable, and instruction manual CD. All
other accessories varies depending on the options selected, see
Table of Accessories.
DESCRIPTION
Included Standard Accessories Part Number
Power Cord - Depending on the style number, the unit will come with one of the following,
Line cord, North American 620000
Line cord, Continental Europe with CEE 7/7 Schuko Plug 50425
Line cord, International color coded wire 15065
Line cord, United Kingdom 90002-989
Ethernet cable for interconnection to PC, 210cm (7 ft.) long (Qty. 1 ea) 90003-684
Instruction manual CD 80989
Table of Accessories
Accessories are supplied with the selection of the Test Leads Option,
and/or the Binary Input / Output / Battery Simulator Option, and/or
the STVI Option. With the Test Leads Option the number and type
Optional Accessories Descriptions
of leads varies depending on the number of channels ordered. If
desired, Test Leads and Accessories can be ordered individually, see
description and part numbers below.
STVI, or
Binary I/O
Bat SIM, or
Test Leads
Options
One (1)
Voltage
Current
Module
Two (2)
Voltage
Current
Modules
Three (3)
Voltage
Current
Modules
Binary I/O,
Simulator
Battery
Option
Accessory Carry Case: Use to carry power cord, Ethernet
cable, Optional STVI and test leads.
Sleeved Pair of Test Leads: Keeps the test leads in pairs
and from getting entangled.
Sleeved Test Leads, one red, one black, 200 cm (78.7”)
long, 600 V, 32 Amperes CAT II.
Cable/Spade Lug Adapter (Small): Small lug fit most new
relay small terminal blocks.
Lug adapter, red, 4.1 mm, use with test leads up to 1000
V/ 20 Amps CAT II.
Lug adapter, black, 4.1 mm, use with test leads up to 1000
V/ 20 Amps CAT II.
Jumper Lead: Used to common returns together on units
with floating ground returns, or parallel of current channels.
Jumper lead, black, 12.5 cm (5”) long, use with voltage /
current outputs, 600 V, 32 Amps CAT II.
Sleeved Combination Voltage Test Leads: Keeps the test
leads from getting entangled. Three common leads connect
to the test set, which are interconnected down to one black
common to connect to the relay under test. Sleeved Three
Phase Test Leads, three red and black, 200 cm (78.7”) long,
600 V, 32 Amperes CAT II.
Qty. 1 ea.
Part No.
2001-487
Qty. 3 pr.
Part No.
2001-394
Qty. 3 ea.
Part No.
684004
Qty. 3 ea.
Part
Number
684005
Qty. 6 pr.
Part No.
2001-394
Qty. 6 ea.
Part No.
684004
Qty. 6 ea.
Part
Number
684005
Qty. 2 ea.
Part
Number
2001-573
Qty. 2 pr.
Part No.
2001-394
Qty. 12ea.
Part No.
684004
Qty. 12ea.
Part
Number
684005
Qty. 4 ea.
Part
Number
2001-573
Qty. 1 ea.
Part
Number
2001-395
Qty. 3 pr.
Part No.
2001-394
Qty. 3 ea.
Part No.
684004
Qty. 3 ea.
Part
Number
684005
Sleeved Combination Current Test Leads: Keeps the test
leads from getting entangled. Three pairs of leads connect
to the test set, with three pairs to connect to the relay
under test. Sleeved Three Phase Test Leads, three red and
black, 200 cm (78.7”) long, 600 V, 32 Amperes CAT II.
Note that the sleeved combination leads only come with the three module configuration.
8
Qty. 1 ea.
Part
Number
2001-396
SMRT36
Megger Relay Test System
Descriptions of Software
Included Software – Every unit comes with AVTS Basic and the PC
version of the STVI Basic Test software packages
AVTS Basic with STVI Application
Software (PC Version) Part No.: 81302
AVTS Basic includes Online Vector, Online Ramp and Online ClickOn-Fault controls, with the ability to import, save and execute
relay specific test modules. The online tools of Vector and Ramp
provide automatic pickup, or dropout tests as well as timing and
multi-state dynamic tests. The Online Click-On-Fault tool is used to
automatically determine the reach characteristics of single or multizone Distance relays using shot for single point tests, or Ramp,
Pulse Ramp, or Binary Search tools along user defined search lines.
Includes enhanced Relay Test Wizards for; Overcurrent, Differential,
Voltage, Frequency and Distance relays.
The powerful STVI screens can be run directly from a PC providing
both manual and automatic test capabilities. Intuitive menu screens
and buttons are provided to quickly and easily select the desired
test function. The Manual Test Screen power-up preset default
values maybe automatically set from the user defined configuration
screen. The user can select from a variety of test options including
manual control using the cursor up down arrows or use the mouse
control wheel to vary outputs. In addition a dynamic sequence test
includes trip and reclose up to 9 operations. An automatic ramp,
pulse ramp, or pulse ramp binary search is built in to determine
pickup or drop out of relay contacts, or perform relay specific timing
tests using the Timing Test Screen. A vector graph indicates the
relative phase angles of all of the outputs. The user may select to
have all output amplitudes metered to provide real time verification
of all of the selected outputs, or have setting values displayed. The
PC version of the STVI software includes the ability to bring all STVI
test data (from other STVI units) into file folders for retrieval and
review whenever needed. Each copy of the PC version of the STVI
software is licensed for running on one PC. Additional run keys can
be purchased seperately.
Additional Software Options
AVTS Advanced with STVI Application Part No.: 81570
AVTS Advanced includes all of the features of AVTS Basic in
addition to the powerful Test Editor and test editor tools, which
includes the Dynamic Control (with dynamic end-to-end test
capability, and Recorder features) for developing sequential tests
for virtually any function or measuring element within digital relays.
In addition, it also includes SS1 File Converter for ASPEN and CAPE
dynamic test files, End-to-End DFR Playback test macros and basic
programming Tools for creating and editing test modules. Test files
created in Advanced Test can be used with AVTS Basic.
AVTS Professional with STVI Application Part No.: 81571
Professional Test includes all of the features of AVTS Advanced
Test version plus the following additional specialized test tools. The
DFR Waveform Viewer and Playback tools are used for viewing and
analyzing IEEE C37.111 COMTRADE Standard files from digital fault
recorders and microprocessor based relays. The DFR Waveform
Viewer includes tools to recreate the analog and digital channels for
playback into protective relays for troubleshooting or evaluation. It
includes the capability to extend the prefault data as well as start
the timer associated with the event to time relay operation. These
playback test files can also be used in end-to-end tests to recreate
the transient event and evaluate the protection scheme. Test files
created in Professional can be used with Advanced Test and Basic.
Also included is the One-Touch Test Editor Control Tool for fully
automatic testing of microprocessor based relays using VB script
files or Modbus communications to automatically download relay
settings, and automatically test all the measuring elements within
the relay based upon those settings. The Waveform Digitizer
feature is also included in the Professional Test version of AVTS.
It provides tools to create digital time curves for virtually any
electromechanical relay time curve (that do not fit a time curve
algorithm). It can even be used for digitizing scanned waveforms
from a light-beam chart recorder.
IEC 61850 Megger GOOSE Configurator Software
The Megger GOOSE Configurator (MGC) provides easy to use tools
for testing relays and substations using the IEC 61850 protocol.
It is an optional software tool available with Basic, Advanced or
Professional versions of AVTS Software; see Descriptions of
Software Options above. The configurator provides relay test
engineers and technicians the capability to import parameters
from configuration files in the Substation Configuration Language
(SCL) format, and/or capture GOOSE messages directly from the
substation bus. All imported GOOSE messages will be unconfirmed
messages. Only captured messages are confirmed messages due to
the Capture feature of the MGC. Use the MGC Merge feature to
compare imported SCL and captured GOOSE messages to verify all
GOOSE messages needed to perform tests. Use them to configure
the SMRT to subscribe to preselected GOOSE messages by assigning
the data attributes to the appropriate binary inputs of the SMRT.
Use the configurator to assign the appropriate binary outputs of the
SMRT to publish GOOSE messages simulating circuit breaker status.
After the appropriate assignments of binary inputs and outputs
have been made, the test file can be saved for reuse. This provides
both manual and automatic testing of the relay using either the STVI
or AVTS software. Use standard test modules in AVTS to perform
automatic tests. Use the Dynamic Control in AVTS Advanced or
Professional to perform high speed trip and reclose tests, or use
to perform interoperability high-speed shared I/O tests between
multiple IED’s. The MGC provides mappings of Boolean and Bit
Strings and/or simulation of STRuct, Integer/Unsigned, Float and
UTC datasets.
9
SMRT36
Megger Relay Test System
Deluxe Test Leads and Accessories Kit Part No.: 1001-619
The Test Leads and Test Lead Accessories are an option. Test leads
and accessories can be ordered with the unit, or later as a kit. The
Deluxe Test Leads and Accessories Kit includes sleeved pairs of
leads for use with the extra binary inputs/outputs/battery simulator
option, as well as the three phase sleeved combination leads for
voltage and current channels. The following test leads and test lead
accessories are included in the Deluxe Test Leads and Accessories
Kit in quantities shown.
Description Part No.
Sleeved Combination Voltage Test Leads: Keeps the
test leads from getting entangled.
Sleeved Three Phase Test Leads, three red and black, 200
cm (78.7”) long, 600 V, 32 Amperes CAT II (Qty. 1 ea)
Sleeved Combination Current Test Leads: Keeps the
test leads from getting entangled.
Sleeved Three Phase Test Leads, three red and black, 200
cm (78.7”) long, 600 V, 32 Amperes CAT II (Qty. 1 ea)
Sleeved Pair Test Leads, one red, one black, 200 cm
(78.7”) long, 600 V, 32 Amperes CAT II, (Qty. 5 pair)
Jumper lead, black, 12.5 cm (5”) long, use with voltage /
current outputs, 600 V, 32 Amps CAT II (Qty. 4 ea.)
Cable/Spade Lug Adapter (Small): Small lug fits most
new relay small terminal blocks.
Lug adapter, red, 4.1 mm, use with test leads up to 1000
V/ 20 Amps CAT II (Qty. 15 ea.)
Lug adapter, black, 4.1 mm, use with test leads up to
1000 V / 20 Amps CAT II (Qty. 15 ea.)
Accessory Case, black, used to carry test leads and/or
STVI (Qty. 1 ea.)
Additional Accessories (Not Included in the SMRT36 Test Leads
Option or Deluxe Lead Kit)
Additional Optional Test Leads and Accessories can be ordered individually,
see description and part numbers below. The following accessories and
part numbers are in quantities of 1 each. Order the appropriate number
required.
Individual (Non-Sleeved) Test Leads: Excellent for widely separated
individual terminal test connections.
2001-395
2001-396
2001-394
2001-573
684004
684005
2001-487
Description Part No.
Alligator/Crocodile Clip: Excellent for test connections to terminal screws
and pins where spade lugs cannot be used.
Alligator clip, red, use with test leads up to 1000 V/32
Amps CAT III.
Alligator clip, black, use with test leads up to 1000 V/32
Amps CAT III.
Flexible Test Lead Adapter: Use with rail-mounted terminals or screw
clamp connections where spade lugs and crocodile/alligator clips cannot
be used.
Flexible test lead adapter, black, 1.8 mm male pin, use
with test leads up to 1000 V/32 Amps CAT III.
Flexible Test Lead Adapter with Retractable Insulated Sleeve: Use for
connection to old style non-safety sockets with retractable protective sleeve
on one end.
Retractable Sleeve Test Lead, red, 50 cm (20”) long, use
with test leads up to 600 V, 32 Amperes CAT II.
Retractable Sleeve Test Lead, black, 50 cm (20”) long, use
with test leads up to 600 V, 32 Amperes CAT II.
In-Line Fused Test Lead: Use with high speed binary outputs 5 or 6 (“P”
Option) to protect for accidental switching of currents higher than 1 Amp.
Test lead, blue, in-line 500 mA fuse protection,
200 cm long (78.7”).
684006
684007
90001-845
90001-843
90001-844
568026
Test Lead, red, use with voltage/current output, or binary
I/O, 200 cm long (78.7”) 600 V/32 Amps CAT II.
Test Lead, black, use with voltage/current output , or
binary I/O, 200 cm long (78.7”) 600 V/32 Amps CAT II.
Cable/Spade Lug Adapter (Large): Large spade lug fits older relay
terminal blocks, or STATES
or General Electric test plugs with screw down terminals.
Lug adapter, red, 6.2 mm, use with test leads up to 1000
V/20 Amps CAT II.
Lug adapter, black, 6.2 mm, use with test leads up to
1000 V/20 Amps CAT II.
®
Company FTP10 or FTP14 Test paddles, ABB
620143
620144
684002
684003
In-Line Fused Test Lead: Use with (“P” Option) Battery Simulator output
to protect for accidental connection to substation battery.
Test lead, black, in-line 3.15 A fuse protection,
200 cm long (78.7”).
In-Line Resistor Test Lead: Use with old solid state relays with “leaky”
SCR trip gates.
Test lead, red, in-line 100 k Ohm resistor, use with test
leads up to 1000 V/ 32 Amps CAT III.
10
568025
500395
SMRT36
Megger Relay Test System
Description Part No.
STATES® 10 Pole Test Paddle: Use with STATES FMS Test Switch or ABB
FT-1 10 pole Test Switch.
Test paddle features knobs which also serve as insulated Ø
4 mm rigid socket accepting spring loaded Ø 4 mm plugs
with rigged insulating sleeve, or retractable sleeve. Use
with test leads up to 600 V, 32 Amperes CATII.
®
10 Pole Test Paddle Attachment: Use with STATES V1TP10
STATES
Test Paddle.
Test paddle attachment provides an additional 10
insulated connection points for front connection, as well
as the standard top connections for test leads. Adapter
can provide convenient parallel test connections of test
currents to two terminals at one time. Use with test leads
up to 600 V, 32 Amperes CAT II.
V1TP10
TPA10
Transit Case
Hard-Sided Transit Case: Includes custom designed foam inserts for the
SMRT unit and accessory case. Transit case includes retractable handle,
polyurethane wheels with stainless steel bearings, double-throw latches,
fold-down handles, and stainless steel hardware and padlock protection,
with O-ring seal making the case water-tight, with an IP 67 rating. Tested
and certified to US Department of Defense Standards for impact, vibration,
and low/high storage temperatures. The case is small, and weighs only 25
pounds (11.25 kg). With a three channel SMRT 36 it is light enough to
check as luggage on commercial airliners.
Rugged, hard-sided transit case (1ea).
1001-632
Description Part No.
Example Configurations
For customers in North America, Central America,
Japan, Philippines, South Korea, Taiwan, Thailand,
Venezuela, Virgin Islands, and other countries that
use standard NEMA type power outlets of 100, 110,
115 or 120 volts at 50/60 Hz. could order a unit with the
standard North American power cord. In this example
the unit is a SMRT36 three phase unit, with the extra
binary I/O and Battery Simulator, with the STVI1, without
grounded common returns, no Bluetooth, no IEC61850,
with the standard hardware, and with test leads.
For customers in Austria, Belgium, Finland, France,
Germany, the Netherlands, Norway, Portugal, Spain,
Sweden, Turkey, and other countries where the CEE 7
standard connector is used could order a unit with the
Continental European Power Cord with CEE 7/7 Schuko
plug. In this example the unit is a 3 phase unit, with the
extra binary I/O and Battery Simulator, without the STVI1,
with floating outputs, no Bluetooth, with IEC61850
enabled, with the standard hardware, and with test leads.
For customers in United Kingdom, Ireland, Anguilla,
Cyprus, Dominica, Gambia, Gibraltar, Malta,
Malaysia, Malawi, St. Lucia, St. Vincent, Zambia,
and other countries where the UK standard connector is
used could order a unit with the UK Power Cord. In this
example the unit is a 3 channel unit, with the extra binary
I/O and Battery Simulator, with the STVI-1, CE Marked
220-230 V input and floating commons, no Bluetooth,
with IEC61850 enabled, with standard hardware, and with
test leads.
The final example is for countries that have more unique
power connectors, which will require international color
coded wires ready for appropriate male connectors to
be installed like; Australia/New Zealand, Argentina,
China, Demark, India, South Africa, Ireland, Israel,
Russia, Switzerland, or the United Kingdom. These
countries are more likely to order the unit with the
international color coded power cord ready for mounting
the appropriate male connector. In this example the unit
is a 3 phase unit, with the extra binary I/O and Battery
Simulator, with the STVI1, with the floating outputs, with
Bluetooth, with IEC61850 enabled, with the standard
hardware, and with test leads.
The style
number
would be,
SMRT36 –
30P1F0A0S1
The style
number
would be,
SMRT36-
30P0F0E1S1
The style
number
would be,
SMRT36-
30P1C0U1S1
The style
number
would be,
SMRT36 –
30P1F1I1S1
11
SMRT36
Megger Relay Test System
UK
Archcliffe Road Dover
CT17 9EN England
T +44 (0) 1304 502101
F +44 (0) 1304 207342
UNITED STATES
4271 Bronze Way
Dallas TX 75237-1088 USA
T 800 723 2861 (USA only)
T +1 214 333 3201
F +1 214 331 7399
OTHER TECHNICAL SALES OFFICES
Norristown USA, Sydney AUSTRALIA,
Toronto CANADA, Trappes FRANCE,
Kingdom of BAHRAIN, Mumbai INDIA,
Johannesburg SOUTH AFRICA and
Conjure THAILAND.
ISO STATEMENT
Registered to ISO 9001:2008 Cert no. 510006.002
SMRT36_DS_EN_V08
www.megger.com
Megger is a registered trademark
Loading...
