Agilent 8722ES with 2.4 mm test ports

Standard, Options 400, 0121, 089, or any combina­tion of these options.

Calibration kit: 85056A, 2.4-mm with sliding loads
Cables: 85133F 2.4-mm flexible cable set
IF bandwidth: 10 Hz
Averaging: None (8 during isolation calibration)

System dynamic range

0.05 to 0.84 GHz 67 dB

0.84 to 8 GHz 93 dB
8 to 20 GHz 91 dB
20 to 40 GHz 80 dB

2

Corrected measurement port specifications

Frequency range (GHz)

0.05 to 2 2 to 8 8 to 20 20 to 40

Directivity 42 dB 42 dB 42 dB 38 dB
Source match 42 dB 38 dB 38 dB 33 dB
Load match 42 dB 42 dB 42 dB 38 dB
Reflection tracking ±(0.005 dB + 0.03 dB/°C) ±(0.010 dB + 0.03 dB/°C) ±(0.010 dB + 0.04 dB/°C) ±(0.021 dB + 0.06 dB/°C)
Transmission tracking ±(0.020 dB + 0.03 dB/°C) ±(0.038 dB + 0.03 dB/°C) ±(0.048 dB + 0.04 dB/°C) ±(0.110 dB + 0.06 dB/°C)

Maximum output power

0.05 to 20 GHz: –5 dBm
20 to 40 GHz: –10 dBm

Measurement uncertainty

Reflection measurements

Magnitude Phase

Transmission measurements

Magnitude Phase

1. Internal test set not bypassed.

2. 3 dB less with Option 012.

6

Agilent 8719ES and 8720ES
with 3.5 mm test ports

Standard, Options 400, 0121, 089, or any combina­tion of these options.

Calibration kit: 85052D, 3.5-mm with broadband

loads

Cables: 85131F 3.5-mm flexible cable set
IF bandwidth: 10 Hz
Averaging: None (8 during isolation calibration)

System dynamic range

0.05 to 0.84 GHz 77 dB

0.84 to 20 GHz 100 dB

System performance, continued

Corrected measurement port specifications

Frequency range (GHz)

0.05 to 0.5 0.5 to 2 2 to 8 8 to 20

Directivity 42 dB 42 dB 38 dB 36 dB
Source match 37 dB 37 dB 31 dB 28 dB
Load match 42 dB 42 dB 38 dB 36 dB
Reflection tracking ±(0.006 dB + .02 dB/°C) ±(0.006 dB + .03 dB/°C) ±(0.006 dB + .03 dB/°C) ±(0.009 dB + .04 dB/°C)
Transmission tracking ±(0.028 dB + .02 dB/°C) ±(0.03 dB + .03 dB/°C) ±(0.096 dB + .03 dB/°C) ±(0.158 dB + .04 dB/°C)

Maximum output power

+5 dBm

Measurement uncertainty

Reflection measurements

Magnitude Phase

Transmission measurements

Magnitude Phase

1. Internal test set not bypassed.

7

Agilent 8722ES with 2.4 mm test ports

Standard, Options 400, 0121, 089, or any combina­tion of these options.

Calibration kit: 85056D, 2.4-mm with broadband

loads

Cables: 85133F 2.4-mm flexible cable set
IF bandwidth: 10 Hz
Averaging: None (8 during isolation calibration)

System dynamic range

0.05 to 0.84 GHz 67 dB

0.84 to 8 GHz 93 dB
8 to 20 GHz 91 dB
20 to 40 GHz 80 dB

2

Corrected measurement port specifications

Frequency range (GHz)

0.05 to 2 2 to 8 8 to 20 20 to 40

Directivity 42 dB 42 dB 34 dB 26 dB
Source match 40 dB 40 dB 30 dB 23 dB
Load match 42 dB 42 dB 34 dB 26 dB
Reflection tracking ±(0.006 dB + 0.03 dB/°C) ±(0.029 dB + 0.03 dB/°C) ±(0.029 dB + 0.04 dB/°C) ±(0.080 dB + 0.06 dB/°C)
Transmission tracking ±(0.022 dB + 0.03 dB/°C) ±(0.034 dB + 0.03 dB/°C) ±(0.116 dB + 0.04 dB/°C) ±(0.372 dB + 0.06 dB/°C)

Maximum output power

0.05 to 20 GHz: –5 dBm
20 to 40 GHz: –10 dBm

Magnitude Phase

Magnitude Phase

Measurement uncertainty

Reflection measurements

Transmission measurements

1. Internal test set not bypassed.

2. 3 dB less with Option 012.

8

Agilent 8719ES Option 400, 8720ES Option 400,
and 8722ES Option 400 with 3.5 mm test ports
using TRL

Includes instruments with Options 0121and/or 089.

Calibration kit: 85052C, 3.5-mm for TRL
Cables: 85131F 3.5-mm flexible cable set
IF bandwidth: 10 Hz
Averaging: None (8 during isolation calibration)

System dynamic range

Frequency range 8719ES/8720ES 8722ES

0.05 to 0.084 GHz 77 dB 67 dB

0.084 to 8 GHz 100 dB 93 dB
8 to 20 GHz 100 dB 91 dB
20 to 40 GHz — 80 dB

2

Maximum output power

8719ES/8720ES: +5 dBm
8722ES (0.05 to 20 GHz): –5 dBm

(20 to 40 GHz): –10 dBm

System performance, continued

Corrected measurement port specifications

8719ES/8720ES Frequency range (GHz)
Option 400

0.05 to 0.5 0.5 to 2 2 to 8 8 to 20

Directivity 48 dB 48 dB 50 dB 50 dB
Source match 40 dB 40 dB 50 dB 50 dB
Load match 48 dB 48 dB 50 dB 50 dB
Reflection tracking ±(0.006 dB + 0.02 dB/°C) ±(0.006 dB + 0.03 dB/°C) ±(0.005 dB + 0.03 dB/°C) ±(0.005 dB + 0.04 dB/°C)
Transmission tracking ±(0.013 dB + 0.02 dB/°C) ±(0.017 dB + 0.03 dB/°C) ±(0.06 dB + 0.03 dB/°C) ±(0.019 dB + 0.04 dB/°C)

8722ES Option 400 Frequency range (GHz)

0.05 to 2 2 to 8 8 to 20 20 to 26.5

Directivity 48 dB 50 dB 50 dB 50 dB
Source match 40 dB 50 dB 50 dB 50 dB
Load match 48 dB 50 dB 50 dB 50 dB
Reflection tracking ±(0.006 dB + 0.03 dB/°C) ±(0.005 dB + 0.03 dB/°C) ±(0.005 dB + 0.04 dB/°C) ±(0.005 dB + 0.06 dB/°C)
Transmission tracking ±(0.017 dB + 0.03 dB/°C) ±(0.013 dB + 0.03 dB/°C) ±(0.016 dB + 0.04 dB/°C) ±(0.023 dB + 0.06 dB/°C)

Magnitude Phase

Magnitude Phase

Measurement uncertainty

Reflection measurements

Transmission measurements

1. Internal test set not bypassed.

2. 3 dB less with Option 012.

9

Agilent 8719ES, 8720ES, and 8722ES Option 007
Agilent 8719ES, 8720ES, and 8722ES Option 085

Includes instruments with Options 0121and/or 089.

Option 007 replaces the standard solid-state
transfer switch with a mechanical switch to pro­vide higher output power.

Option 085 adds internally controlled 0 to 55 dB
step attenuators (5 dB steps) in the receiver path
of both ports, an RF loop that allows the addition
of an amplifier before the transfer switch, and RF
loops after the switch that allow insertion of isola­tors, required for measurements above 1 watt. An
internal reference channel switch is added and inter­nal bias tees are deleted. This system is capable of
full two-port calibrated measurements to 20 watts.
Measurements up to 100 watts may be possible
using specific configurations. Option 085 includes
direct sampler access (Option 012). Option 085 is
not compatible with Option 400.

System dynamic range

Option 007 Option 085

Frequency
range (GHz) 8719ES/20ES 8722ES 8719D/20ES 8722ES

0.05 to 0.84 82 dB 72 dB 82 dB 72 dB

0.84 to 8 105 dB 98 dB 105 dB 98 dB
8 to 20 105 dB 96 dB 105 dB 96 dB
20 to 40 — 85 dB — 82 dB

Maximum output power

Option 007 Option 085

2

8719ES/8720ES +10 dBm +5 dBm
8722ES (0.05 to 20 GHz) 0 dBm –5 dBm
8722ES (20 to 40 GHz) –5 dBm –10 dBm

Supplemental characteristics (Option 085)

Maximum R-channel input level: 0 dBm
Minimum R-channel input level: –34 dBm
Maximum RF port input: +43 dBm
Attenuators: 55 dB maximum, 5 dB steps
Maximum test port power (no isolators): +30 dBm
Maximum test port power (with high power

isolators): +43 dBm

Mechanical
Transfer

switch

Source

B

R

A

Samplers

RF out

RF in

+43 dBm max

Customer supplied
booster amplifier
and coupler

Amplifier under test

R channel input
0 dBm max

+43 dBm max input

(20 watts)

+43 dBm max output

(20 watts)

Customer supplied isolation
(for output above +30 dBm)

-55 dB

-55 dB

R out

Reference
Signal
Switches

Option 085 block diagram and example
high power measurement setup

1. Internal test set not bypassed.

2. With jumper cable installed between RF out and RF in ports: that is, no external amplification.

10

Agilent 8719ES or 8720ES with Option 007 or 085

Calibration kit: 85052B 3.5-mm with sliding loads
Cables: 85131F 3.5-mm flexible cable set
IF bandwidth: 10 Hz
Averaging: None (8 during isolation calibration)

System performance, continued

Corrected measurement port specifications

Frequency range (GHz)

0.05 to 0.5 0.5 to 2 2 to 8 8 to 20

Directivity 48 dB 48 dB 44 dB 44 dB
Source match 40 dB 39 dB 32 dB 30 dB
Load match 48 dB 48 dB 44 dB 44 dB
Reflection tracking ±(0.006 dB + .02 dB/°C) ±(0.010 dB + .03 dB/°C) ±(0.030 dB + .03 dB/°C) ±(0.031 dB + .04 dB/°C)
Transmission tracking ±(0.011 dB + .02 dB/°C) ±(0.016 dB + .03 dB/°C) ±(0.066 dB + .03 dB/°C) ±(0.108 dB + .04 dB/°C)

Magnitude Phase

Magnitude Phase

Measurement uncertainty

Reflection measurements

Transmission measurements

11

Agilent 8719ES or 8720ES with Option 007 or 085

Calibration kit: 85052D 3.5-mm with fixed loads
Cables: 85131F 3.5-mm flexible cable set
IF bandwidth: 10 Hz
Averaging: None (8 during isolation calibration)

Corrected measurement port specifications

Frequency range (GHz)

0.05 to 0.5 0.5 to 2 2 to 8 8 to 20

Directivity 42 dB 42 dB 38 dB 36 dB
Source match 37 dB 37 dB 30 dB 28 dB
Load match 42 dB 41 dB 36 dB 34 dB
Reflection tracking ±(0.006 dB + .02 dB/°C) ±(0.01 dB + .03 dB/°C) ±(0.03 dB + .03 dB/°C) ±(0.31dB + .04 dB/°C)
Transmission tracking ±(0.018 dB + .02 dB/°C) ±(0.019 dB + .03 dB/°C) ±(0.080 dB + .03 dB/°C) ±0.141 dB + .04 dB/°C)

Magnitude Phase

Magnitude Phase

Measurement uncertainty

Reflection measurements

Transmission measurements

12

Agilent 8722ES with Option 007 or 085

Calibration kit: 85056A 2.4-mm with sliding loads
Cables: 85133F 2.4-mm flexible cable set
IF bandwidth: 10 Hz
Averaging: None (8 during isolation calibration)

System performance, continued

Magnitude Phase

Magnitude Phase

Measurement uncertainty

Reflection measurements

Transmission measurements

Corrected measurement port specifications

Frequency range (GHz)

0.05 to 2 2 to 8 8 to 20 20 to 40

Directivity 42 dB 42 dB 42 dB 38 dB
Source match 40 dB 35 dB 34 dB 31 dB
Load match 41 dB 38 dB 37 dB 35 dB
Reflection tracking ±(0.011 dB + .03 dB/°C) ±(0.037 dB + .03 dB/°C) ±(0.039 dB + .04 dB/°C) ±(0.047 dB + .06 dB/°C)
Transmission tracking ±(0.021 dB + .03 dB/°C) ±(0.054 dB + .03 dB/°C) ±(0.085 dB + .04 dB/°C) ±(0.149 dB + .06 dB/°C)

13

Agilent 8722ES with Option 007 or 085

Calibration kit: 85056D 2.4-mm with fixed loads
Cables: 85133F 2.4-mm flexible cable set
IF bandwidth: 10 Hz
Averaging: None (8 during isolation calibration)

Corrected measurement port specifications

Frequency range (GHz)

0.05 to 2 2 to 8 8 to 20 20 to 40

Directivity 42 dB 42 dB 34 dB 26 dB
Source match 39 dB 36 dB 29 dB 23 dB
Load match 41 dB 38 dB 33 dB 26 dB
Reflection tracking ±(0.011 dB + .03 dB/°C) ±(0.046 dB + .03 dB/°C) ±(0.048 dB + .04 dB/°C) ±(0.090 dB + .06 dB/°C)
Transmission tracking ±(0.022 dB + .03 dB/°C) ±(0.053 dB + .03 dB/°C) ±(0.130 dB + .04 dB/°C) ±(0.367 dB + .06 dB/°C)

Magnitude Phase

Magnitude Phase

Measurement uncertainty

Reflection measurements

Transmission measurements

Agilent 8719ET and 8720ET
with 3.5 mm test ports

Standard or Option 004

Calibration kit: 85052B 3.5-mm with sliding loads
Cables: 85131F 3.5-mm flexible cable set
IF bandwidth: 10 Hz
Averaging: None (8 during isolation calibration)

System dynamic range

0.05 to 0.84 GHz 102 dB

0.84 to 20 GHz 104 dB

Power range:

Standard: –10 to +10 dBm
Option 004: –65 to +10 dBm

14

System performance, continued

Magnitude Phase

Measurement uncertainty

Reflection measurements

Magnitude Phase

Magnitude Phase

1. One-port or enhanced-response calibration

2. Enhanced-response or response-only calibration

3. Option 004 may degrade uncorrected source match as much as 2 dB.

Transmission measurements

Corrected measurement port specifications (3.5 mm)

Frequency range (GHz)

0.050 to 0.5 0.5 to 2 2 to 8 8 to 20

Reflection Measurements

1

Directivity 48 dB 48 dB 44 dB 44 dB
Source match 40 dB 40 dB 33 dB 31 dB
Load match

One-port Cal 22 dB 22 dB 22 dB 17 dB
Enhanced Reflection Cal 22 dB 22 dB 22 dB 17 dB

Reflection tracking ±(0.006 dB ±(0.006 dB ±(0.006 dB ±(0.008 dB

+0.02 dB/°C) +0.03 dB/°C) +0.03 dB/°C) +0.04 dB/°C)

Transmission measurements

2

Source match

Enhanced Response Cal 4 0 dB 40 dB 33 dB 31 dB
Response Only Cal 16 dB 20 dB 14 dB 11 dB

Transmission tracking

Enhanced Response Cal ±(0.014 dB ±(0.012 dB ±(0.027 dB ±(0.050 dB

+0.02 dB/°C) +0.03 dB/°C) +0.03 dB/°C) +0.04 dB/°C)

Response Only Cal ±(0.109 dB ±(0.069 dB ±(0.137 dB ±(0.339 dB

+0.02 dB/°C) +0.03 dB/°C) +0.03 dB/°C) +0.04 dB/°C)

Load match 22 dB 22 dB 22 dB 17 dB
