Asus ROG Strix Fusion 300 Instruction manual

Sales Kit

The ROG Strix Fusion 300 gaming headset features an exclusive airtight chamber design and 50mm ASUS Essence

drivers, delivering pure gaming audio with deep bass. Immerse yourself in rich sound with onboard 7.1-channel virtual

surround-sound wherever you go – no dongles or drivers needed! The Strix Fusion 300 is lightweight and comfortable,

and has wide compatibility with PC, Mac and game consoles.

ROG Strix Fusion 300

Exclusive airtight chamber

Helps deliver richer and more

spacious sound

On-board 7.1 virtual

surround

Exclusive ROG Hybrid ear

cushion

Reduces perspiration and provides

better sound insulation

Cross-platform compatibility

PC, mobile, PS4/Xbox console

compatible

Extra ear cushions for free!

Enjoy plug-and-play 7.1 virtual

surround whenever you go

50mm ASUS Essence

driver

Less distorted audio with punchy

bass

Free set of 100% protein-leather

ear cushions

ROG audio engineers have enlarged the sound chamber around the driver to provide a deep soundstage that

improves gaming immersion. The chamber has also been designed to be airtight, delivering tighter bass and

purer sound.

Airtight rubber seals the

chamber perfectly

The whole chamber has

been enlarged so there’s

more space for air to

circulate

How it works

>> Less varied frequency response with the Strix Fusion 300 airtight driver chamber

Testing result from the lab

Without airtight chamber With airtight chamber

Industry Standard Variation

Deviated off the industry standard variation

The graphs above show the frequency response of multiple Strix Fusion 300 headsets with and without the

sealing components installed in the driver chamber. The measurements were taken by placing each headset on

a dummy head that features an embedded microphone to measure frequency response.

From the left graph, we can see that unit to unit frequency response is more varied when the driver chamber

doesn’t utilize an airtight seal. The variance shown is typical of gaming headsets. Such variance can result in

two samples of the same headset sounding drastically different.

By utilizing an airtight chamber to house the Strix Fusion 300 drivers, the right graph reveals less headset to

headset variance, ensuring a consistent sound signature across multiple headset samples.

Unique pairing process

>> Delivers more consistent sound from both left and right ear cups

Type B

Type A

Type C Type D

The industry standard for driver variance is 3dB. This can result in headsets coming off the production line with up to
to 6dB of variance in frequency response, which leads to poor stereo imaging. Strix Fusion 300 drivers go through a
rigorous screening process to ensure each pair is tightly matched.

Driver characteristics are carefully studied, and like pairs are teamed to
ensure each Strix Fusion 300 headset meets strict standards.
