Asus P8Z77-V LX User Manual

Motherboard

P8Z77-V LX

ii

E8533

Fourth Edition (V4)
July 2013

Copyright © 2013 ASUSTeK Computer Inc. All Rights Reserved.

No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK Computer Inc. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.

Offer to Provide Source Code of Certain Software

This product may contain copyrighted software that is licensed under the General Public License (“GPL”)
and under the Lesser General Public License Version (“LGPL”). The GPL and LGPL licensed code in this
product is distributed without any warranty. Copies of these licenses are included in this product.

You may obtain the complete corresponding source code (as dened in the GPL) for the GPL Software,

and/or the complete corresponding source code of the LGPL Software (with the complete machine­readable “work that uses the Library”) for a period of three years after our last shipment of the product
including the GPL Software and/or LGPL Software, which will be no earlier than December 1, 2011, either
(1) for free by downloading it from http://support.asus.com/download;
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:

ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan

In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.

The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.

This offer is valid to anyone in receipt of this information.

ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source code
we would be much obliged if you give us a notication to the email address [e-mail], stating the
product and describing the problem (please do NOT send large attachments such as source code archives
etc to this email address).

iii

Contents

Safety information ...................................................................................................... vi

About this guide ........................................................................................................ vii

P8Z77-V LX specications summary ....................................................................... ix

Chapter 1: Product introduction

1.1 Welcome! ....................................................................................................1-1

1.2 Package contents

....................................................................................... 1-1

1.3 Special features

.......................................................................................... 1-2

1.3.1 Product highlights

........................................................................ 1-2

1.3.2

ASUS DIGI+ VRM Digital Power Design ...................................1-4

1.3.3 ASUS Exclusive Features ...........................................................

1-4

1.3.4

ASUS Quiet Thermal Solutions ................................................... 1-6

1.3.5 ASUS EZ DIY ..............................................................................

1-6

1.3.6 Other special features .................................................................

1-7

Chapter 2: Hardware information

2.1 Before you proceed ...................................................................................2-1

2.2 Motherboard overview ...............................................................................

2-2

2.2.1 Motherboard layout .....................................................................

2-2

2.2.2 Central Processing Unit (CPU) ...................................................

2-4

2.2.3 System memory ..........................................................................

2-5

2.2.4 Expansion slots .........................................................................

2-13

2.2.5 Jumper ......................................................................................

2-15

2.2.6 Onboard switches .....................................................................

2-16

2.2.7 Onboard LEDs ..........................................................................

2-18

2.2.8 Internal connectors

.................................................................... 2-19

2.3 Building your computer system .............................................................

2-25

2.3.1 Additional tools and components to build a PC system ............

2-25

2.3.2 CPU installation

......................................................................... 2-26

2.3.3 CPU heatsink and fan assembly installation .............................

2-28

2.3.4 DIMM installation

....................................................................... 2-30

2.3.5 Motherboard installation ............................................................

2-31

2.3.6 ATX Power connection ..............................................................

2-33

2.3.7 SATA device connection ............................................................

2-34

2.3.8 Front I/O Connector ..................................................................

2-35

2.3.9 Expansion Card installation

....................................................... 2-36

2.3.10 Rear panel connection ..............................................................

2-37

2.3.11 Audio I/O connections ...............................................................

2-39

2.4 Starting up for the rst time ....................................................................

2-41

2.5 Turning off the computer .........................................................................

2-41

iv

Contents

Chapter 3: BIOS setup

3.1 Knowing BIOS ............................................................................................3-1

3.2 BIOS setup program ..................................................................................

3-1

3.2.1 EZ Mode

...................................................................................... 3-2

3.2.2 Advanced Mode ..........................................................................

3-3

3.3 Main menu ..................................................................................................

3-5

3.4 Ai Tweaker menu ........................................................................................

3-7

3.5 Advanced menu .......................................................................................

3-13

3.5.1 CPU Conguration ....................................................................

3-14

3.5.2 PCH Conguration ....................................................................

3-17

3.5.3 SATA Conguration ...................................................................

3-18

3.5.4 System Agent Conguration

...................................................... 3-19

3.5.5 USB Conguration ....................................................................

3-20

3.5.6 Onboard Devices Conguration ................................................

3-21

3.5.7 APM ..........................................................................................

3-23

3.5.8 Network Stack ...........................................................................

3-24

3.6 Monitor menu ...........................................................................................

3-25

3.7 Boot menu ................................................................................................

3-28

3.8 Tools menu ...............................................................................................

3-30

3.9 Exit menu ..................................................................................................

3-32

3.10 Updating BIOS ..........................................................................................

3-33

3.10.1 ASUS Update utility

................................................................... 3-33

3.10.2 ASUS EZ Flash 2 utility .............................................................

3-36

3.10.3 ASUS CrashFree BIOS 3 utility

................................................. 3-37

3.10.4 ASUS BIOS Updater .................................................................

3-38

Chapter 4: Software support

4.1 Installing an operating system .................................................................4-1

4.2 Support DVD information ..........................................................................

4-1

4.2.1 Running the support DVD ...........................................................

4-1

4.2.2 Obtaining the software manuals

.................................................. 4-2

4.3 Software information .................................................................................

4-3

4.3.1 AI Suite II

..................................................................................... 4-3

4.3.2 TurboV EVO ................................................................................

4-4

4.3.3 DIGI+ VRM ..................................................................................

4-7

4.3.4 EPU .............................................................................................

4-8

4.3.5 FAN Xpert+ .................................................................................

4-9

4.3.6 Probe II

...................................................................................... 4-10

v

4.3.7 USB 3.0 Boost........................................................................... 4-11

4.3.8 Audio congurations

.................................................................. 4-12

4.4 Introduction to Intel

®

2012 Desktop responsiveness technologies .... 4-13

4.4.1 System Requirements for Intel

®

2012 Desktop responsiveness

technologies ............................................................................................... 4-13

4.4.2 Intel

®

Smart Response Technology ........................................... 4-15

4.4.3 Intel

®

Rapid Start Technology .................................................... 4-16

4.4.4 Intel

®

Smart Connect Technology .............................................. 4-22

4.5 RAID congurations ................................................................................

4-25

4.5.1 RAID denitions ........................................................................

4-25

4.5.2 Installing Serial ATA hard disks .................................................

4-26

4.5.3 Setting the RAID item in BIOS ..................................................

4-26

4.5.4 Intel

®

Rapid Storage Technology Option ROM utility ................4-26

4.6 Creating a RAID driver disk

..................................................................... 4-30

4.6.1 Creating a RAID driver disk without entering the OS ................

4-30

4.6.2 Creating a RAID driver disk in Windows

®

.................................. 4-30

4.6.3 Installing the RAID driver during Windows

®

OS installation ...... 4-31

4.6.4 Using a USB oppy disk drive ...................................................

4-32

Chapter 5: Multiple GPU technology support

5.1 ATI® CrossFireX™ technology ..................................................................5-1

5.1.1 Requirements ..............................................................................

5-1

5.1.2 Before you begin .........................................................................

5-1

5.1.3 Installing two CrossFireX™ graphics cards ................................

5-2

5.1.4 Installing the device drivers .........................................................

5-3

5.1.5 Enabling the ATI

®

CrossFireX™ technology ...............................5-3

Notices .................................................................................................................... A-1

ASUS Recycling/Takeback Services ............................................................A-2

Contents

vi

Safety information

Electrical safety

• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet

before relocating the system.

• When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.

• Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.

• Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.

• Ensure that your power supply is set to the correct voltage in your area. If you are not sure
about the voltage of the electrical outlet you are using, contact your local power company.

• If the power supply is broken, do not try to x it by yourself. Contact a qualied service

technician or your retailer.

Operation safety

• Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.

• Before using the product, ensure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.

• To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.

• Place the product on a stable surface.

• If you encounter technical problems with the product, contact a qualied service

technician or your retailer.

vii

About this guide

This user guide contains the information you need when installing and conguring the motherboard.

How this guide is organized

This guide contains the following parts:

• Chapter 1: Product introduction

This chapter describes the features of the motherboard and the new technology it
supports.

• Chapter 2: Hardware information

This chapter lists the hardware setup procedures that you have to perform when
installing system components. It includes description of the switches, jumpers, and
connectors on the motherboard.

• Chapter 3: BIOS setup

This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.

• Chapter 4: Software support

This chapter describes the contents of the support DVD that comes with the
motherboard package and the software.

• Chapter 5: Multiple GPU technology support

This chapter describes the ATI® CrossFireX™ feature and shows the graphics card
installation procedures.

Where to nd more information

Refer to the following sources for additional information and for product and software updates.

1. ASUS websites

The ASUS website provides updated information on ASUS hardware and software
products. Refer to the ASUS contact information.

2. Optional documentation

Your product package may include optional documentation, such as warranty yers,

that may have been added by your dealer. These documents are not part of the
standard package.

viii

Conventions used in this guide

To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.

DANGER/WARNING: Information to prevent injury to yourself when

completing a task.

CAUTION: Information to prevent damage to the components when

completing a task

IMPORTANT: Instructions that you MUST follow to complete a task.

NOTE: Tips and additional information to help you complete a task.

Typography

Bold text Indicates a menu or an item to select.

Italics

Used to emphasize a word or a phrase.

<Key> Keys enclosed in the less-than and greater-than sign

means that you must press the enclosed key.

Example: <Enter> means that you must press the Enter or
Return key.

<Key1> + <Key2> + <Key3> If you must press two or more keys simultaneously, the key

names are linked with a plus sign (+).

ix

P8Z77-V LX specications summary

CPU LGA1155 socket for Intel® 3rd / 2nd Generation Core™ i7 / Core™ i5 / Core™

i3 / Pentium® / Celeron® processors
Supports 32nm and 22nm CPU
Supports Intel® Turbo Boost technology 2.0*
* The Intel® Turbo Boost technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel® CPU support list.

Chipset Intel® Z77 Express Chipset
Memory 4 x DIMMs, max. 32GB, DDR3 2400(O.C.) / 2200(O.C.) / 2133(O.

C.)/1866(O.C.) /1600/1333/1066 MHz, non-ECC, un-buffered memory*

Dual-channel memory architecture
Supports Intel® Extreme Memory Prole (XMP)
*Hyper DIMM support is subject to the physical characteristics of individual

CPUs. Please refer to Memory QVL (Qualied Vendors List) for details.

Graphics Integrated Graphics Processor - Intel® HD Graphics Support

Multi-VGA output support: HDMI, DVI, RGB port

- Supports HDMI 1.4a with max.resolution up to 1920 x 1200 @60Hz

- Supports DVI with max. resolution up to 1920 x 1200 @60Hz

- Supports RGB with max. resolution up to 2048 x 1536 @75Hz

- Maximum shared memory of 1696MB

Multi-GPU
support

Supports ATI® Quad-GPU CrossFireXTM Technology

Expansion
slots

1 x PCI Express 3.0* / 2.0 x16 slot (blue at x16 mode)
1 x PCI Express 2.0 x16 slot (black at x4 mode, compatible with PCIe x1

and x4 devies)
2 x PCI Express 2.0 x1 slots
3 x PCI slots
* PCIe 3.0 speed is supported by Intel

® 3rd

generation CoreTM processors.

Storage Intel® Z77 Express Chipset:

- 2 x Serial ATA 6.0 Gb/s ports (gray) with RAID 0,1,5,10 support

- 4 x Serial ATA 3.0 Gb/s ports (blue) with RAID 0,1,5,10 support

- Supports Intel® Smart Response Technology, Intel

®

Rapid Start

Technology, Intel® Smart Connect Technology*

*Support for Intel® Core® processor family with Windows 7 operating
systems.

LAN

Realtek® 8111E / 8111F Gigabit LAN controller

Audio Realtek® ALC887 8-channel* High Denition Audio CODEC

- Supports Jack-Detection, Multi-streaming and Front Panel Jack­Retasking

- Optical S/PDIF out ports at back I/O

* Use a chassis with HD audio module in the front panel to support an 8-

channel audio output

(continued on the next page)

x

(continued on the next page)

P8Z77-V LX specications summary

USB Intel® Z77 Express Chipset - supports ASUS USB 3.0 Boost UASP

Mode.*

- 4 x USB 3.0 /2.0 ports (2 ports at the mid-board and 2 ports at the
back panel)

- 10 x USB 2.0 ports (6 ports at mid-board, 4 ports at back panel)

*The USB 3.0 ports only support Windows 7® or later versions. UASP
standard only supports Windows® 8.

ASUS unique
features

ASUS DIGI+ VRM

- Digital Power Control: Digital power Design for the CPU and iGPU

- ASUS 4+1+1 Phase Power Design

ASUS Exclusive Features

- Network iControl featuring instant network bandwidth domination for

top network program in use

- USB 3.0 Boost featuring the latest USB 3.0 UASP standard

- MemOK!

- TurboV

- GPU Boost

- AI Charger

- Disk Unlocker featuring 3TB+ HDD support

- AI Suite II

- Anti Surge

- Low EMI Solution

- 100% Solid Capacitors

ASUS Quiet Thermal Solution

- ASUS Fanless Design: Stylish Heatsink solution

- ASUS Fan Xpert+

ASUS EZ DIY

- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 2

- ASUS My Logo 2

ASUS exclusive
overclocking
features

Precision Tweaker 2

- vCore: Adjustable CPU voltage at 0.005V increment

- vCCSA: 190-step system agent voltage control

- vDRAM Bus: 190-step Memory voltage control

- vPCH: 190-step Chipset voltage control

- iGPU: 127-step iGPU voltage control

SFS (Stepless Frequency Selection)

- BCLK/PCIE frequency tuning from 80MHz up to 300MHz at 0.1MHz

increment

Overclocking Protection

- ASUS C.P.R.(CPU Parameter Recall)

xi

P8Z77-V LX specications summary

Rear panel I/O
ports

1 x PS/2 keyboard / mouse combo port
1 x Optical S/PDIF out port
1 x HDMI port
1 x DVI port
1 x RGB port
1 x LAN (RJ-45) port
2 x USB 3.0/2.0 ports
4 x USB 2.0/1.1 ports
3-jack 8-channel audio I/O ports

Internal I/O
connectors

1 x USB 3.0/2.0 connector supports additional 2 USB ports (19-pin)
3 x USB 2.0/1.1 connectors support additional 6 USB ports
2 x SATA 6.0Gb/s connectors (gray)
4 x SATA 3.0Gb/s connectors (blue)
1 x COM port connector
1 x CPU Fan connector (4-pin)
2 x Chassis Fan connectors (4-pin)
1 x Power Fan connector (3-pin)
1 x Front panel audio connector
1 x S/PDIF Out Header
24-pin ATX Power connector
8-pin ATX 12V Power connector
1 x System Panel
1 x MemOK! Button
1 x GPU Boost switch
1 x Clear CMOS jumper

BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM

BIOS 2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2,
ASUS CrashFree BIOS 3, F12 PrintScreen, F3 Shotcut Function
and ASUS DRAM SPD (Serial Presence Detect) memory
information

Manageability

WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE

(continued on the next page)

xii

*Specications are subject to change without notice.

P8Z77-V LX specications summary

Accessories 2 x Serial ATA 6.0Gb/s cables

1 x User Manual
1 x I/O Shield
1 x Support DVD

Support DVD Drivers

ASUS Utilities
ASUS Update
Anti-virus software (OEM version)

Form Factor ATX Form Factor, 12”x 8.6” (30.5cm x 21.8 cm)

ASUS P8Z77-V LX 1-1

Chapter 1

Chapter 1: Product introduction

Chapter 1

1.1 Welcome!

Thank you for buying an ASUS® P8Z77-V LX motherboard!

The motherboard delivers a host of new features and latest technologies, making it another
standout in the long line of ASUS quality motherboards!

Before you start installing the motherboard, and hardware devices on it, check the items in
your package with the list below.

1.2 Package contents

Check your motherboard package for the following items.

• If any of the above items is damaged or missing, contact your retailer.

• The illustrated items above are for reference only. Actual product specications may

vary with different models.

User Manual

ASUS P8Z77-V LX

motherboard

User guide Support DVD

2 x Serial ATA 6.0 Gb/s

cables

1 x ASUS I/O Shield

1-2 Chapter 1: Product Introduction

Chapter 1

1.3 Special features

1.3.1 Product highlights

LGA1155 socket for Intel® 3rd / 2nd Generation Core™ i7/ Core™ i5/ Core™ i3
Processors

This motherboard supports Intel® 3rd/2nd generation Core™ i7 / i5 / i3 / Pentium® / Celeron®
processors in the LGA1155 package, with iGPU, memory and PCI Express controllers
integrated to support onboard graphics output with dedicated chipsets, 2-channel (4 DIMM)
DDR3 memory and 16 PCI Express 3.0/2.0 lanes. This provides great graphics performance.
Intel® 3rd / 2nd generation Core™ i7 / i5 / i3 / Pentium® / Celeron® processors are among the

most powerful and energy efcient CPUs in the world.

Intel® Z77 Express Chipset

The Intel® Z77 Express Chipset is a single-chipset designed to support socket 1155 Intel®
2nd / 3rd generation Core™ i7 / i5 / i3 processors. It provides improved performance by

utilizing serial point-to-point links, allowing increased bandwidth and stability. Additionally,

the Z77 chipset provides 4 USB 3.0 ports for 10 times faster data retrieval speed. Moreover,
Intel® Z77 Express Chipset can also enable iGPU function, letting users enjoy the latest Intel
integrated graphic performance.

Dual-Channel DDR3 2400(O.C.) / 2200(O.C.) / 2133(O.C) / 1866(O.C.) / 1600 / 1333 /
1066 Support

The motherboard supports DDR3 memory that features data transfer rates of 2400(O.C.) /

2200(O.C.) / 2133(O.C.) / 1866(O.C.)/ 1600 / 1333 / 1066 MHz to meet the higher bandwidth

requirements of the latest 3D graphics, multimedia, and Internet applications. The dual­channel DDR3 architecture enlarges the bandwidth of your system memory to boost system
performance.

* Due to CPU behavior, DDR3 2200/2000/1800 MHz memory module will run at DDR3 2133/1866/1600

MHz frequency as default.

Complete USB 3.0 Integration

ASUS facilitates strategic USB 3.0 accessibility for both the front and rear panel - 4 USB 3.0
ports in total. Experience the latest plug & play connectivity at speeds up to 10 times faster
than USB 2.0. The P8Z77-V LX affords greater convenience to high speed connectivity.

Quad-GPU CrossFireX™ Support

The motherboard’s powerful Intel® Z77 platform optimizes PCIe allocation in multiple-GPU
congurations of CrossFireX™. This allows you to enjoy a never before-experienced brand

new gaming style.

Intel® Smart Response Technology

SSD Speed with HDD Capacity

Intel® Smart Response Technology boosts overall system performance. It uses an installed
fast SSD (min 18.6GB available capacity required) as a cache for frequently accessed data.

Key benets include reduced load and wait times, and lower power consumption through the

elimination of unnecessary hard drive spin. This technology combines SSD performance with
hard drive capacity, operating up to 4X faster than a hard drive-only system, and an important
part of Green ASUS eco-friendly computing.

ASUS P8Z77-V LX 1-3

Chapter 1

* Intel® Smart Response Technology is supported by 2nd/3rd generation Intel® Core™ processor
family on Windows

®

7™ operating systems.
** Operating systems must be installed on the HDD to launch Intel® Smart Response Technology.
The capacity of the SSD is reserved for caching function.

Intel® Smart Connect Technology

Your computer can receive web updates with fresh content for selected applications, even
when the system is in sleep mode. This means less time waiting for applications to update

and sync with the cloud, leading to a more efcient computing experience.

Intel® Rapid Start Technology

Allows your computer to quickly resume from a low-power hibernate state in seconds.
Saving your system memory to the designed SSD, it provides your computer a faster wake­up response time, while still keeping the energy use low.

PCIe 3.0 Ready

PCI Express® 3.0 (PCIe 3.0) is the latest PCI Express bus standard with improved encoding
schemes that provide twice the performance of current PCIe 2.0. Total bandwidth for a x16
link reaches a maximum of 32GB/s, double the 16GB/s of PCIe 2.0 (in x16 mode). As such,
PCIe 3.0 provides users unprecedented data speeds, combined with the convenience and
seamless transition offered by complete backward compatibility with PCIe 1.0 and PCIe

2.0 devices. PCIe 3.0 will become a must-have feature for users who wish to improve and

optimize graphic performance, as well as have the latest technology available to them.

PCIe 3.0 speed is supported by Intel® 3rd generation processors.

S/PDIF out connector at the back I/O

This motherboard provides convenient connectivity to external home theater audio systems
via the optical S/PDIF (SONY-PHILIPS Digital Interface) out connector at the back I/O. The
S/PDIF transfers digital audio without converting it to analog format and keeps the best signal
quality.

Gigabit LAN solution

The onboard LAN controller is a highly integrated Gb LAN controller. It is enhanced with an

ACPI management function to provide efcient power management for advanced operating

systems.

8-channel high denition audio

The onboard 8-channel HD audio (High Denition Audio, previously codenamed Azalia)
CODEC enables high-quality 192KHz/24-bit audio output and jack-detect feature that
automatically detects and identies what types of peripherals are plugged into the audio
I/O jacks and noties users of inappropriate connection, which means there will be no more

confusion of Line-in, Line-out, and Mic jacks.

100% All High-quality Conductive Polymer Capacitors

This motherboard uses all high-quality conductive polymer capacitors for durability, improved
lifespan, and enhanced thermal capacity.

1-4 Chapter 1: Product Introduction

Chapter 1

ErP ready

The motherboard is European Union´s Energy-related Products (ErP) ready, and ErP

requires products to meet certain energy efciency requirements in regards to energy

consumptions. This is in line with ASUS vision of creating environment-friendly and energy-

efcient products through product design and innovation to reduce carbon footprint of the

product and thus mitigate environmental impacts.

1.3.2 ASUS DIGI+ VRM Digital Power Design

Digital Power Control: Digital Power Design for the CPU and iGPU

All-new digital CPU power controls work perfectly together to match digital power signal

(SVID) requests from the CPU, with ultra-fast sensing and response efciently delivering

precision power. Accurate delivery reduces waste, and provides more stable CPU Vcore
voltages. Users can adjust CPU and its processor graphics (iGPU) voltages for various
overclocking scenarios, with accurate input through UEFI BIOS tuning or the exclusive ASUS
interface. This proprietary design increases overlocking headroom to push performance to its
full potential.

ASUS EPU

Tap into the world’s rst real-time PC power saving chip through the AI Suite II utility. Get
total system-wide energy optimization by automatically detecting current PC loadings and

intelligently moderating power consumption. This also reduces fan noise and extends
component longevity.

1.3.3 ASUS Exclusive Features

USB 3.0 Boost

Faster USB 3.0 Transmission with UASP

New ASUS USB 3.0 Boost technology supports UASP (USB Attached SCSI Protocol), the

latest USB 3.0 standard. With USB 3.0 Boost technology, a USB device’s transmission speed
is signicantly increased up to 170%, adding to an already impressive fast USB 3.0 transfer

speed. ASUS software automatically accelerates data speeds for compatible USB 3.0
peripherals without the need for any user interaction.

MemOK!

Any Memory is A-OK!

MemOK! quickly ensures memory boot compatibility. This remarkable memory rescue tool
requires a mere push of the button to patch memory issues. MemOK! determines failsafe
settings and dramatically improves your system boot success. Get your system up and
running in no time.

ASUS P8Z77-V LX 1-5

Chapter 1

Network iControl

Real-Time Network Bandwidth Control

With a one-click on/off button, the software currently in use is set as top priority over all other

network programs, dominating the network bandwidth with ease. Moreover, you can prioritize
your favorite software easily by conguring proles through the intuitive user interface. Within
the prole, programs can be pre-scheduled to run at a specic time period to avoid network

clogging, and long-waits on downloads. Auto PPPoE network gives a one-step setup, and an
intuitive network bandwidth control center.

GPU Boost

Go the Limit with iGPU Level Up!

GPU Boost accelerates the integrated GPU for extreme graphics performance. The user-

friendly interface facilitates exible frequency adjustments. It easily delivers stable system-

level upgrades for every use.

AI Suite II

One-stop Access to Innovative ASUS Features

With its user-friendly interface, ASUS AI Suite II consolidates all the exclusive ASUS features
into one simple to use software package. It allows you to supervise overclocking, energy
management, fan speed control, voltage and sensor readings, and even interact with mobile
devices via Wi-Fi. This all-in-one software offers diverse and ease to use functions, with no
need to switch back and forth between different utilities.

ASUS TurboV

Feel the adrenaline rush of real-time OC-now a reality with the ASUS TurboV. This easy OC

tool allows you to overclock without exiting or rebooting the OS; and its user-friendly interface
makes overclocking just a few clicks away. Moreover, the ASUS OC proles in TurboV

provide the best O.C. settings in different scenarios.

ASUS MyLogo2™

This feature allows you to convert your favorite photo into a 256-color boot logo for a more
colorful and vivid image on your screen.

Precision Tweaker 2

Allows you to ne-tune the VCore voltage in 0.005V steps and DRAM voltage in 0.00625V
steps to achieve the most precise setting for the ultimate overclocking conguration.

C.P.R. (CPU Parameter Recall)

The BIOS C.P.R. feature automatically restores the CPU default settings when the system
hangs due to overclocking failure. C.P.R. eliminates the need to open the system chassis and
clear the RTC data. Simply shut down and reboot the system, and the BIOS automatically

restores the CPU parameters to their default settings.

1-6 Chapter 1: Product Introduction

Chapter 1

1.3.4 ASUS Quiet Thermal Solutions

ASUS Quiet Thermal solution makes system more stable and enhances the overclocking
capability.

Fan Xpert+

ASUS Fan Xpert+ intelligently allows you to adjust the CPU fan speed according to different
ambient temperatures caused by different climate conditions in different geographic regions

and your PC’s loading. The built-in variety of useful proles offer exible controls of fan speed

to achieve a quiet and cool environment.

Fanless Design: stylish heatsink solution

The stylish heatsink features a 0-dB thermal solution that offers users a noiseless PC
environment. Not only the beautiful shape upgrades the visual enjoyment for motherboard
users, but also the heatsink design lowers the temperature of the chipset and power phase

area through high efcient heat-exchange. Combined with usability and aesthetics, the ASUS

stylish heatsink will give users an extremely silent and cooling experience with the elegant
appearance!

DO NOT uninstall the heat-pipe by yourself. Doing so may bend the tubing and affect the
heat heat dissipation performance.

1.3.5 ASUS EZ DIY

ASUS UEFI BIOS (EZ Mode)

Flexible and Easy BIOS Interface

ASUS UEFI BIOS offers the rst mouse-controlled graphical BIOS designed with selectable

modes, providing a user-friendly interface that goes beyond the traditional keyboard-only

controls. It also fully utilizes 2.2TB and larger hard drives in 64-bit operating systems with

native support.

ASUS exclusive interface

EZ Mode displays frequently-accessed info. Users can choose system performance settings,
and drag and drop boot priorities. Advanced Mode for performance enthusiasts includes
detailed DRAM settings via a dedicated memory info page for complete insight.

New upgrade! Quick and easy information for enhanced system control

- F12 BIOS snapshot hotkey for sharing UEFI information and troubleshooting

- New F3 Shortcut for most accessed information

- ASUS DRAM SPD (Serial Presence Detect) information for accessing memory

information, detecting faulty DIMMs, and helping with difcult POST situations.

ASUS EZ-Flash 2

ASUS EZ Flash 2 is a user-friendly utility that allows you to update the BIOS without using a

bootable oppy disk or an OS-based utility.

ASUS P8Z77-V LX 1-7

Chapter 1

1.3.6 Other special features

HDMI Support

Enjoy Full HD 1080p Multimedia Home-Theater Entertainment

High Denition Multimedia Surface (HDMI) is a set of digital video standards that delivers

mulit-channel audio and uncompressed digital video for full HD 1080p visuals through a
single cable. Supporting HDCP copy protection such as HD DVD and blu-ray discs, HDMI
provides you with the highest quality home theater experience.

ErP Ready

The motherboard is European Union’s Energy-related Products (ErP) ready, and ErP requires
products to meet certain energy efciency requirement in regards to energy consumptions.
This is in line with ASUS vision of creating environment-friendly and energy-efcient products

through product design and innovation to reduce carbon footprint of the product and thus
mitigate environmental impacts.

1-8 Chapter 1: Product Introduction

Chapter 1

ASUS P8Z77-V LX 2-1

Chapter 2

2.1 Before you proceed

Take note of the following precautions before you install motherboard components or change
any motherboard settings.

• Unplug the power cord from the wall socket before touching any component.

• Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.

• Hold components by the edges to avoid touching the ICs on them.

• Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that came with the component.

• Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.

Chapter 2: Hardware information

Chapter 2

2-2 Chapter 2: Hardware information

Chapter 2

2.2.1 Motherboard layout

Refer to

2.2.8 Connectors

and

2.3.10 Rear panel connection

for more information about

rear panel connectors and internal connectors.

2.2 Motherboard overview

P8Z77-V LX

PCIEX16_1

PCIEX16_2

PCIEX1_2

PCIEX1_1

PCI1

PCI2

PCI3

USB910 USB78 USB56

USB3_34

PANEL

SPDIF_OUT

AAFP

CPU_FAN

CHA_FAN2

CHA_FAN1

PWR_FAN

Lithium Cell

CMOS Power

Super

I/O

DIGI

+VRM

ASM
1442

RTL
8111E/
8111F

TPU

COM1

8Mb

BIOS

SB_PWR

SATA3G_3 SATA3G_2 SATA3G_1

SATA3G_4 SATA6G_2 SATA6G_1

CLRTC

21.9cm(8.6in)

30.5cm(12.0in)

Intel

®

Z77

DDR3 DIMM_A1 (64bit, 240-pin module)

DDR3 DIMM_A2 (64bit, 240-pin module)

DDR3 DIMM_B1 (64bit, 240-pin module)

DDR3 DIMM_B2 (64bit, 240-pin module)

NCT

5535D

ALC

887

MemOK!

DRAM_LED

GPU_LED

GPU Boost

EATXPWR

LGA1155

AUDIO

KB_USB34

LAN_USB12

LAN3_12

SPDIFO

K_USB34

DVI_VGA

EATX12V

2 4

3

1

2

6

7

11

14

10

17 1618 15 1213

9

5

8

11

1

ASUS P8Z77-V LX 2-3

Chapter 2

Connectors/Jumpers/Slots Page

1.

CPU, Chassis and power fan connectors
(4-pin CPU_FAN, 4-pin CHA_FAN1/2, 3-pin PWR_FAN)

2-21

2.

EATX power connectors (24-pin EATXPWR, 8-pin EATX12V)

2-23

3.

Intel® CPU socket

2-4

4.

DDR3 DIMM sockets

2-5

5.

GPU Boost LED

2-17

6.

GPU Boost Switch

2-17

7.

MemOK! button

2-16

8.

DRAM LED

2-18

9.

USB 3.0 connector (20-1 pin USB3_56)

2-22

10.

Onboard LED (SB_PWR)

2-18

11.

Intel® Z77 Serial ATA 3.0 Gb/s connectors (7-pin SATA3G_1–4 [blue])

2-22

12.

Intel® Z77 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1/2 [gray])

2-19

13.

System panel connector (20-8 pin PANEL)

2-24

14.

Clear RTC RAM (3-pin CLRTC)

2-15

15.

USB connectors (10-1 pin USB5~10)

2-20

16.

Serial port connectors (10-1 pin COM1)

2-19

17.

Digital audio connector (4-1 pin SPDIF_OUT)

2-21

18.

Front panel audio connector (10-1 pin AAFP)

2-20

Layout contents

2-4 Chapter 2: Hardware information

Chapter 2

2.2.2 Central Processing Unit (CPU)

The motherboard comes with a surface mount LGA1155 socket designed for the Intel® 3rd /
2nd Generation Core™ i7/ i5/ i3 Processors.

• The LGA1156 CPU is incompatible with the LGA1155 socket. DO NOT install a
LGA1156 CPU on the LGA1155 socket.

• Upon purchase of the motherboard, ensure that the PnP cap is on the socket and
the socket contacts are not bent. Contact your retailer immediately if the PnP cap
is missing, or if you see any damage to the PnP cap/socket contacts/motherboard
components. ASUS will shoulder the cost of repair only if the damage is shipment/
transit-related.

• Keep the cap after installing the motherboard. ASUS will process Return Merchandise

Authorization (RMA) requests only if the motherboard comes with the cap on the

LGA1155 socket.

• The product warranty does not cover damage to the socket contacts resulting from
incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP
cap.

Ensure that all power cables are unplugged before installing the CPU.

P8Z77-V LX

P8Z77-V LX CPU socket LGA1155

ASUS P8Z77-V LX 2-5

Chapter 2

2.2.3 System memory

The motherboard comes with four Double Data Rate 3 (DDR3) Dual Inline Memory Modules
(DIMM) sockets.

Recommended memory congurations

A DDR3 module is notched differently from a DDR or DDR2 module. DO NOT install a DDR
or DDR2 memory module to the DDR3 slot.

We recommend that you install the memory modules using the blue slots for better
overclocking capability.

P8Z77-V LX

P8Z77-V LX 240-pin DDR3 DIMM sockets

DIMM_A1

DIMM_A2

DIMM_B1

DIMM_B2

2-6 Chapter 2: Hardware information

Chapter 2

Memory congurations

You may install 1GB, 2GB, 4GB and 8GB unbuffered non-ECC DDR3 DIMMs into the DIMM
sockets.

• The default memory operation frequency is dependent on its Serial Presence Detect
(SPD), which is the standard way of accessing information from a memory module.
Under the default state, some memory modules for overclocking may operate at a
lower frequency than the vendor-marked value. To operate at the vendor-marked
or at a higher frequency, refer to section

3.4 Ai Tweaker menu

for manual memory

frequency adjustment.

• For system stability, use a more efcient memory cooling system to support a full

memory load (4 DIMMs) or overclocking condition.

• You may install varying memory sizes in Channel A and Channel B. The system maps
the total size of the lower-sized channel for the dual-channel conguration. Any excess
memory from the higher-sized channel is then mapped for single-channel operation.

• Due to CPU behavior, DDR3 2200/2000/1800 MHz memory module will run at DDR3
2133/1866/1600 MHz frequency as default.

• According to Intel CPU spec, DIMM voltage below 1.65V is recommended to protect
the CPU.

• Always install DIMMs with the same CAS latency. For optimum compatibility, we
recommend that you obtain memory modules from the same vendor.

• Due to the memory address limitation on 32-bit Windows OS, when you install 4GB
or more memory on the motherboard, the actual usable memory for the OS can be
about 3GB or less. For effective use of memory, we recommend that you do any of the
following:

- Use a maximum of 3GB system memory if you are using a 32-bit Windows OS.

- Install a 64-bit Windows OS when you want to install 4GB or more on the

motherboard.
For more details, refer to the Microsoft® support site at
http://support.microsoft.com/kb/929605/en-us.

• This motherboard does not support DIMMs made up of 512Mb (64MB) chips or less
(Memory chip capacity counts in Megabit, 8 Megabit/Mb = 1 Megabyte/MB).

Visit the ASUS website for the latest QVL.

ASUS P8Z77-V LX 2-7

Chapter 2

P8Z77-V LX Motherboard Qualied Vendors Lists (QVL) DDR3 2400MHz
capability

P8Z77-V LX Motherboard Qualied Vendors Lists (QVL) DDR3 2200MHz
capability

P8Z77-V LX Motherboard Qualied Vendors Lists (QVL) DDR3 2133MHz
capability

P8Z77-V LX Motherboard Qualied Vendors Lists (QVL) DDR3 2000MHz
capability

Vendors Part No. Size S S /DSC h i p

Brand

C hi p
NO.

Timing Voltage DIMM socket support (Optional)

1 DIMM 2 DIMMs 4 DIMMs

G.SKILL F3-17600CL8D-4GBPS(XMP) 4GB(2x 2GB) DS - - 8-8-8-24 1.65V •

KINGMAX FLKE85F-B8KJAFEIH(XMP) 4GB(2x 2GB) DS - - - 1.5V-1.7V •

Vendors Part No. Size S S /DSC h i p

Brand

Ch ip
NO.

Timing Voltage DIMM socket support (Optional)

1 DIMM 2 DIMMs 4 DIMMs

Apacer 78.AAGD5.9KD(XMP) 6GB(3 x 2GB) DS - - 9-9-9-27 1.65V • • •

CORSAIR CMZ4GX3M2A2000C10(XMP) 4GB(2 x 2GB) SS - - 10-10-10-27 1.50V • • •

CORSAIR CMT6GX3M3A2000C8(XMP) 6GB(3 x 2GB) DS - - 8-9-8-24 1.65V • •

G.SKILL F3-16000CL9D-4GBFLS(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.65V • • •

G.SKILL F3-16000CL9D-4GBTD(XMP) 4GB(2 x 2GB) DS - - 9-9-9-27 1.65V • • •

G.SKILL F3-16000CL6T-6GBPIS(XMP) 6GB(3x 2GB ) DS - - 6-9-6-24 1.65V • •

GEIL GUP34GB2000C9DC(XMP) 4GB(2 x 2GB) DS - - 9-9-9-28 1.65V

KINGSTON KHX2000C9AD3T1K2/4GX(XMP) 4GB(2x 2GB ) DS - - - 1.65V • • •

KINGSTON K H X 2 0 0 0 C 9 A D 3 W 1 K 2 /

4GX(XMP)

4GB(2x 2GB ) DS - - - 1.65V • •

KINGSTON KHX2000C9AD3T1K2/4GX(XMP) 4GB(2 x 2GB) DS - - 9 1.65V • • •

KINGSTON K H X 2 0 0 0 C 9 A D 3 W 1 K 3 /

6GX(XMP)

6GB(3x 2GB ) DS - - - 1.65V • •

KINGSTON KHX2000C9AD3T1K3/6GX(XMP) 6GB(3x 2GB ) DS - - - 1.65V • •

Transcend TX2000KLN-8GK(XMP) 8GB(2 x 4GB) DS - - - 1.6V • • •

Vendors Part No. Size SS /DSC h i p

Brand

Chip
NO.

Timing Voltage D IM M so c ke t s u pp or t

(Optional)

1 DIMM 2 DIMMs 4 DIMMs

A-DATA AX3U2133GC2G9B-DG2(XMP) 2GB SS - - 9-11-9-27 1.55~1.75V •

CORSAIR CMT4GX3M2A2133C9(XMP) 4GB(2x 2GB) DS - - 9-10-9-24 1.65V •

CORSAIR CMT4GX3M2B2133C9(XMP) 4GB(2x 2GB) DS - - 9-10-9-27 1.50V • •

GEIL GE34GB2133C9DC(XMP) 2GB DS - - 9-9-9-28 1.65V • •

GEIL GU34GB2133C9DC(XMP) 4GB(2 x 2GB) DS - - 9-9-9-28 1.65V • • •

KINGSTON KHX2133C9AD3T1K2/4GX(XMP) 4GB(2x 2GB ) DS - - - 1.65V • • •

KINGSTON KHX2133C9AD3X2K2/4GX(XMP) 4GB(2 x 2GB) DS - - 9-11-9-27 1.65V • • •

KINGSTON KHX2133C9AD3T1K4/8GX(XMP) 8GB(4 x 2GB) DS - - 9-11-9-27 1.65V • • •

KINGSTON KHX2133C9AD3T1FK4/8GX(XMP) 8GB(4x 2GB) DS - - - 1.65V • • •

Vendors Part No. Size S S /DSC h i p

Brand

C hi p
NO.

Timing Voltage D I M M s o c ke t s u p po r t

(Optional)
1 DIMM 2 DIMMs 4 DIMMs

Transcend TX2400KLU-4GK (381850)(XMP) 4GB(2x 2GB) SS - - 9 1.65V • •

2-8 Chapter 2: Hardware information

Chapter 2

P8Z77-V LX Motherboard Qualied Vendors Lists (QVL) DDR3 1866MHz
capability

P8Z77-V LX Motherboard Qualied Vendors Lists (QVL) DDR3 1600MHz
capability

Vendors Part No. Size S S /DSC h i p

Brand

Ch ip
NO.

Timing Voltage DIMM socket support (Optional)

1 DIMM 2 DIMMs 4 DIMMs

CORSAIR CMT4GX3M2A1866C9(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.65V • • •

CORSAIR CMT6GX3MA1866C9(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.65V • •

CORSAIR CMZ8GX3M2A1866C9(XMP) 8GB(2 x 4GB) DS - - 9-10-9-27 1.50V • • •

G.SKILL F3-14900CL9D8GBXL(XMP)

8GB(2 x 4GB)

DS -

- 9-10-9-28

1.5V

• •

•

G.SKILL F3-14900CL9Q8GBXL(XMP) 8GB(2GB x 4) DS - - 9-9-9-24 1.6V • • •

KINGSTON KHX1866C9D3T1K3/3GX(XMP) 3GB(3 x 1GB) SS - - - 1.65V • • •

KINGSTON KHX1866C9D3T1K3/6GX(XMP) 6GB(3 x 2GB) DS - - - 1.65V • • •

Vendors Paart No. Size SS /DSC h i p

Brand

Chip NO. Timing Voltage D IM M s oc ke t su pp or t

(Optional)
1 DIMM 2 DIMMs 4 DIMMs

A-DATA AM2U16BC2P1 2GB SS A-DATA 3C CD- 150

9A EL1126T

- - • • •

A-DATA AD31600E001GM(O)U3K 3GB(3 x 1GB) SS - - 8-8-8-24 1.65V-1.85V • •

A-DATA AX3U1600XB2G79-2X(XMP) 4GB(2 x 2GB) DS - - 7-9-7-21 1.55V-1.75V

A-DATA AM2U16BC4P2 4GB DS A-DATA 3 CCD -15 0

9A EL1126T

- - • • •

A-DATA AX3U1600GC4G9-2G(XMP) 8GB(2 x 4GB) DS - - 9-9-9-24 1.55V-1.75V • • •

A-DATA AX3U1600XC4G79-2X(XMP) 8GB(2 x 4GB) DS - - 7-9-7-21 1.55V-1.75V • • •

CORSAIR TR3X3G1600C8D(XMP) 3GB(3 x 1GB) SS - - 8-8-8-24 1.65V • •

CORSAIR CMD12GX3M6A1600C8(XMP) 12GB(6x2GB) DS - - 8-8-8-24 1.65V • • •

CORSAIR CMP4GX3M2A1600C8(XMP) 4GB(2 x 2GB) DS - - 8-8-8-24 1.65V • • •

CORSAIR CMP4GX3M2A1600C9(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.65V • • •

CORSAIR CMP4GX3M2C1600C7(XMP) 4GB(2 x 2GB) DS - - 7-8-7-20 1.65V • • •

CORSAIR CMX4GX3M2A1600C9(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.65V • •

CORSAIR CMX4GX3M2A1600C9(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.65V • • •

CORSAIR TR3X6G1600C8 G(XMP) 6GB(3 x 2GB) DS - - 8-8-8-24 1.65V • • •

CORSAIR TR3X6G1600C8D G(XMP) 6GB(3 x 2GB) DS - - 8-8-8-24 1.65V • • •

CORSAIR TR3X6G1600C9 G(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.65V • • •

CORSAIR CMP8GX3M2A1600C9(XMP) 8GB(2 x 4GB) DS - - 9-9-9-24 1.65V • • •

CORSAIR CMZ8GX3M2A1600C7R(XMP) 8GB(2 x 4GB) DS - - 7-8-7-20 1.50V • • •

CORSAIR CMX8GX3M4A1600C9(XMP) 8GB(4 x 2GB) DS - - 9-9-9-24 1.65V • • •

Crucial BL25664BN1608.16FF(XMP) 6GB(3 x 2GB) DS - - - - • • •

G.SKILL F3-12800CL9D-2GBNQ(XMP) 2GB(2 x 1GB) SS - - 9-9-9-24 1.5V • • •

G.SKILL F3-12800CL7D-4GBRH(XMP) 4GB(2 x 2GB) SS - - 7-7-7-24 1.6V • • •

G.SKILL F3-12800CL7D-4GBRM(XMP) 4GB(2 x 2GB) DS - - 7-8-7-24 1.6V • • •

G.SKILL F3-12800CL8D-4GBRM(XMP) 4GB(2 x 2GB) DS - - 8-8-8-24 1.60V • • •

G.SKILL F3-12800CL9D-4GBECO(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 XMP 1.35V • • •

G.SKILL F3-12800CL9D-4GBRL(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.5V • • •

G.SKILL F3-12800CL9T-6GBNQ(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.5V~1.6V • • •

G.SKILL F3-12800CL7D-8GBRH(XMP) 8GB(2 x 4GB) DS - - 7-8-7-24 1.6V • • •

G.SKILL F3-12800CL8D-8GBECO(XMP) 8GB(2 x 4GB) DS - - 8-8-8-24 XMP 1.35V • • •

G.SKILL F3-12800CL9D-8GBRL(XMP) 8GB(2 x 4GB) DS - - 9-9-9-24 1.5V • • •

GEIL GET316GB1600C9QC(XMP) 16GB(4x 4GB) DS - - 9-9-9-28 1.6V • • •

GEIL GV34GB1600C8DC(XMP) 2GB DS - - 8-8-8-28 1.6V • • •

KINGMAX FLGD45F-B8MF7 MAEH(XMP) 1GB SS - - 7 - • •

KINGMAX FLGE85F-B8KJ9A FEIS(XMP) 2GB DS - - - - • • •

KINGMAX FLGE85F-B8MF7 MEEH(XMP) 2GB DS - - 7 - •

KINGSTON KHX1600C9D3P1K2/4G 4GB(2 x 2GB) SS - - - 1.5V • • •

KINGSTON KHX1600C9D3K3/12GX(XMP) 12GB(3x4GB) DS - - 9-9-9-27 1.65V • • •

ASUS P8Z77-V LX 2-9

Chapter 2

P8Z77-V LX Motherboard Qualied Vendors Lists (QVL) DDR3 1333MHz
capability

Vendors Paart No. Size SS /DSC h i p

Brand

Chip NO. Timing Voltage D IMM sock et suppo rt

(Optional)
1

DIMM2 DIMMs4 DIMMs

KINGSTON KHX1600C9D3T1BK312GX(XMP)12GB(3x4GB) DS - - 9-9-9-27 1.65V • • •

KINGSTON KHX1600C9AD3/2G 2GB DS - - - 1.65V • • •

KINGSTON KVR1600D3N11/2G-ES 2GB DS KTC D1288JPN

DPLD9U

11-11-11-28 1.35V-1.5V • • •

KINGSTON

KHX1600C7D3K2/4GX(XMP) 4GB(2x 2GB )

DS -

-

- 1.65V

• •

•

KINGSTON KHX1600C8D3K2/4GX(XMP) 4GB(2 x 2GB) DS - - 8 1.65V • • •

KINGSTON KHX1600C8D3T1K2/4GX(XMP) 4GB(2 x 2GB) DS - - 8 1.65V • • •

KINGSTON KHX1600C9D3K2/4GX(XMP) 4GB(2 x 2GB) DS - - 9 1.65V • • •

KINGSTON KHX1600C9D3LK2/4GX(XMP) 4GB(2 x 2GB) DS - - 9 XMP 1.35V • • •

KINGSTON KHX1600C9D3X2K2/4GX(XMP) 4GB(2 x 2GB) DS - - 9-9-9-27 1.65V • • •

KINGSTON KHX1600C9D3T1K3/6GX(XMP)

6GB(3x 2GB )

DS -

-

- 1.65V

• •

•

KINGSTON KHX1600C9D3K3/6GX(XMP) 6GB(3 x 2GB) DS - - 9 1.65V • • •

KINGSTON KHX1600C9D3T1BK3/6GX

(XMP)

6GB(3 x 2GB) DS - - 9-9-9-27 1.65V • • •

KINGSTON KHX1600C9D3K2/8GX(XMP) 8GB(2 x 4GB) DS - - 9-9-9-27 1.65V • • •

KINGSTON KHX1600C9D3P1K2/8G 8GB(2 x 4GB) DS - - - 1.5V • • •

Super Talent WA160UX6G9 6GB(3 x 2GB) DS - - 9 - • •

Transcend JM1600KLN-8GK 8GB(4GBx2) DS Transcend TK483PCW3 - - • • •

Asint SLZ3128M8-EGJ1D(XMP) 2GB DS Asint 3128M8-GJ1D 9-9-9-24 1.6V • • •

Elixir M2P2G64CB8HC9N-DG(XMP) 2GB DS - - - - • • •

Mushkin 998659(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.5~1.6V • • •

Vendors Part No. Size S S /DSC h i p

Brand

Chip NO. Timing Voltage D I MM s o ck e t s u pp o rt

(Optional)
1 DIMM 2 DIMMs 4 DIMMs

A-DATA AD31333001GOU 1GB SS A-Data AD30908C8D-151C

E0906

- - • • •

A-DATA AD3U1333C2G9 2GB SS A-DATA 3CCD-1509HNA1126L - - • • •

A-DATA AD63I1B0823EV 2GB SS A-Data 3CCA-1509A - - • • •

A-DATA AM2U139C2P1 2GB SS ADATA 3CCD-1509A EL1127T - - • • •

A-DATA AX3U1333C2G9-BP 2GB SS - - - - • • •

A-DATA AD31333G001GOU 3GB

(3 x 1GB)

SS - - 8-8-8-24 1.65-1.85V • • •

A-DATA AXDU1333GC2

G9-2G(XMP)

4GB
(2 x 2GB)

SS - - 9-9-9-24 1.25V-1.35V

(low voltage)

• • •

A-DATA AD31333G002GMU 2GB DS - - 8-8-8-24 1.65-1.85V • •

A-DATA AD63I1C1624EV 4GB DS A-Data 3CCA-1509A - - • • •

A-DATA AM2U139C4P2 4GB DS ADATA 3CCD-1509A EL1127T - - • • •

A-DATA SU3U1333W8G9-B 8GB DS ELPIDA J4208BASE-DJ-F - - •

Apacer 78.A1GC6.9L1 2GB DS Apacer AM5D5808DEWSBG - - • • •

Apacer 78.A1GC6.9L1 2GB DS Apacer AM5D5808FEQSBG 9 - • • •

Apacer AU02GFA33C9NBGC 2GB DS Apacer AM5D5808APQSBG - - • • •

Apacer 78.B1GDE.9L10C 4GB DS Apacer AM5D5908CEHSBG - - • • •

CORSAIR CM3X1024-1333C9 1GB SS - - 9-9-9-24 1.60V • • •

CORSAIR TR3X3G1333C9 G 3GB(3 x

1GB)

SS - - 9-9-9-24 1.50V • • •

CORSAIR TR3X6G1333C9 G 6GB(3x

2GB)

SS - - 9-9-9-24 1.50V • •

CORSAIR CMD24GX3M6A

1333C9(XMP)

24GB(6 x
4GB)

DS - - 9-9-9-24 1.60V • • •

CORSAIR TW3X4G1333C9D G 4GB(2 x

2GB)

DS - - 9-9-9-24 1.50V • • •

CORSAIR CM3X4GA1333C9N2 4GB DS CORSAIR 256MBDCJ

GELC0401136

9-9-9-24 - • • •

CORSAIR CMX4GX3M1A1333C9 4GB DS - - 9-9-9-24 1.50V • • •

CORSAIR CMD8GX3M4A1333C7 8GB(4 x

2GB)

DS - - 7-7-7-20 1.60V • • •

P8Z77-V LX Motherboard Qualified Vendors Lists (QVL) DDR3 1600MHz
capability

2-10 Chapter 2: Hardware information

Chapter 2

Vendors Part No. Size S S /DSChip Brand Chip NO. Timing Voltage D I M M s oc k e t s u pp o rt

(Optional)
1 DIMM 2 DIMMs 4 DIMMs

Crucial CT12864BA1339.8FF 1GB SS Micron 9FF22D9KPT 9 - • • •

Crucial CT25664BA1339.16FF 2GB DS Micron 9KF27D9KPT 9 - • • •

Crucial BL25664BN13

37.16FF (XMP)

6GB
(3 x 2GB)

DS - - 7-7-7-24 1.65V • • •

ELPIDA

EBJ10UE8EDF0-DJ-F

1GB SS

ELPIDA

J1108EDSE-DJ-F -

1.35V(low
voltage)

•

•

•

ELPIDA EBJ21UE8EDF0-DJ-F 2GB DS ELPIDA J1108EDSE-DJ-F - 1.35V(low

voltage)

• •

G.SKILL F3-10600CL8D-

2GBHK(XMP)

1GB SS G.SKILL - - - • • •

G.SKILL F3-10600CL9D-2GBNQ 2GB(2 x 1GB) SS - - 9-9-9-24 1.5V • • •

G.SKILL F3-10666CL7T-

3GBPK(XMP)

3GB(3 x 1GB) SS - - 7-7-7-18 1.5~1.6V • • •

G.SKILL F3-10666CL8D-

4GBECO(XMP)

4GB(2 x 2GB) DS - - 8-8-8-8-24 XMP 1.35V • • •

G.SKILL

F3-10666CL7T­6GBPK(XMP)

6GB(3 x 2GB) DS

-

- 7-7-7-18

1.5~1.6V •

•

G.SKILL F3-10666C

L7D-8GBRH(XMP)

8GB(2 x 4GB) DS - - 7-7-7-21 1.5V • • •

GEIL GET316GB1333C9QC 16GB(4 x

4GB)

DS - - 9-9-9-24 1.5V •

GEIL GV32GB1333C9DC 2GB(2 x 1GB) DS - - 9-9-9-24 1.5V • • •

GEIL GG34GB1333C9DC 4GB(2 x 2GB) DS GEIL GL1L128M88BA12N 9-9-9-24 1.3V(low

voltage)

• • •

GEIL GV34GB1333C9DC 4GB(2 x 2GB) DS - - 9-9-9-24 1.5V • • •

GEIL GVP34GB1333C7DC 4GB(2 x 2GB) DS - - 7-7-7-24 1.5V • • •

Hynix HMT112U6TFR8A-H9 1GB SS Hynix H5TC1G83TFRH9A - 1.35V(low

voltage)

• • •

Hynix HMT325U6BFR8C-H9 2GB SS Hynix H5TQ2G83BFRH9C - - • • •

Hynix HMT125U6TFR8A-H9 2GB DS Hynix H5TC1G83TFRH9A - 1.35V(low

voltage)

• • •

Hynix HMT351U6BFR8C-H9 4GB DS Hynix H5TQ2G83BFRH9C - - • • •

KINGMAX FLFD45F-B8KL9 NAES 1GB SS KINGMAX KKB8FNWBFGNX-27A - - • • •

KINGMAX FLFE85F-C8KF9 CAES 2GB SS KINGMAX KFC8FMFXF-DXX-15A - - • • •

KINGMAX FLFE85F-C8KL9 NAES 2GB SS KINGMAX KFC8FNLXF-DXX-15A - - • • •

KINGMAX FLFE85F-C8KM9 NAES 2GB SS KINGMAX KFC8FNMXF-BXX-15A - - • • •

KINGMAX FLFE85F-B8KL9 NEES 2GB DS KINGMAX KKB8FNWBFGNX-26A - - • • •

KINGMAX FLFF65F-C8KL9 NEES 4GB DS KINGMAX KFC8FNLXF-DXX-15A - - • • •

KINGMAX FLFF65F-C8KM9 NEES 4GB DS KINGMAX KFC8FNMXF-BXX-15A - - • • •

KINGSTON KVR1333D3N9/1G(low

prole)

1GB SS ELPIDA J1108BDBG-DJ-F 9 1.5V • • •

KINGSTON KVR1333D3N9/2G(low

prole)

2GB SS Hynix H5TQ2G83AFRH9C 9 - • • •

KINGSTON KVR1333D3S8N9/2G 2GB SS Micron IID77 D9LGK - 1.5V • • •

KINGSTON KVR1333D3S

8N9/2G-SP(low prole)

2GB SS ELPIDA J2108BCSE-DJ-F - 1.5V • • •

KINGSTON KVR1333D3N9/2G(low

prole)

2GB DS ELPIDA J1108BFBG-DJ-F 9 1.5V • • •

KINGSTON KVR1333D3N9/2G 2GB DS KTC D1288JPNDPLD9U 9 1.5V • • •

KINGSTON KVR1333D3N9/2G 2GB DS ELPIDA J1108BDSE-DJ-F 9 1.5V • • •

KINGSTON KVR1333D3N9/2G-

SP(low prole)

2GB DS KTC D1288JEMFNGD9U - 1.5V • • •

KINGSTON KVR1333D3N9/2G-

SP(low prole)

2GB DS KINGSTON D1288JPSFPGD9U - 1.5V • • •

KINGSTON KHX1333C7D3K2/

4GX(XMP)

4GB(2 x 2GB) DS - - 7 1.65V • • •

KINGSTON KHX1333C9D3UK2/

4GX(XMP)

4GB(2 x 2GB) DS - - 9 XMP 1.25V •

KINGSTON KVR1333D3N9/4G(low

prole)

4GB DS ELPIDA J2108BCSE-DJ-F 9 1.5V • • •

KINGSTON KVR1333D3N9/4G(low

prole)

4GB DS ELPIDA J2108BCSE-DJ-F - 1.5V • • •

KINGSTON KVR1333D3N9/4G 4GB DS KTC D2568JENCNGD9U - 1.5V • • •

KINGSTON KVR1333D3N9/4G 4GB DS Hynix H5TQ2G83AFR - - • • •

KINGSTON KVR1333D3N9/4G-

SP(low prole)

4GB DS KINGSTON D2568JENCPGD9U - 1.5V • • •

Micron MT4JTF12864AZ-

1G4D1

1GB SS Micron OJD12D9LGQ - - • • •

Micron MT8JTF12864AZ-

1G4F1

1GB SS Micron 9FF22D9KPT 9 - • • •
