ASUS P42JC, P42F, P52JC User Manual

E5946
Notebook PC User Manual
September 2010
2
Notebook PC User Manual
Table of Contents
Chapter 1: Introducing the Notebook PC
Chapter 2: Knowing the parts
Chapter 3: Getting Started
Using AC Power ...............................................................................................26
Using Battery Power ......................................................................................28
Battery Care ......................................................................................................29
Powering ON the Notebook PC .................................................................30
The Power-On Self Test (POST) ..................................................................30
Checking Battery Power ...............................................................................32
Charging the Battery Pack ...........................................................................33
Power Options .................................................................................................34
Power Management Modes .......................................................................36
Sleep and Hibernate ......................................................................................36
Thermal Power Control .................................................................................37
Colored Hot Keys ............................................................................................38
Microsoft Windows Keys ..............................................................................40
Multimedia Control Keys (on selected models) ...................................42
Switches .............................................................................................................43
Status Indicators .............................................................................................44
Notebook PC User Manual
3
Chapter 4: Using the Notebook PC
Using the Touchpad .......................................................................................49
Touchpad Usage Illustrations .....................................................................50
Caring for the Touchpad ..............................................................................53
Automatic Touchpad Disabling .................................................................53
Flash Memory Card Reader .........................................................................55
Hard Disk Drive ................................................................................................56
Memory (RAM) .................................................................................................58
Network Connection .....................................................................................59
Wireless LAN Connection (on selected models) .................................61
Windows Wireless Network Connection ................................................63
Bluetooth Wireless Connection(on selected models) .......................65
ASUS Scene Switch ........................................................................................68
ASUS Secure Delete .......................................................................................69
PowerRecover ..................................................................................................71
Appendix
Optional Connections .................................................................................A-2
System BIOS Settings ..................................................................................A-4
Common Problems and Solutions .........................................................A-7
Using Recovery Partition ....................................................................... A-13
Using Recovery DVD (on selected models) ...................................... A-14
DVD-ROM Drive Information ................................................................. A-16
Internal Modem Compliancy ................................................................ A-18
Federal Communications Commission Statement ........................A-22
FCC Radio Frequency (RF) Exposure Caution Statement ............ A-23
Declaration of Conformity(R&TTE directive 1999/5/EC) .............. A-23
CE Marking ................................................................................................... A-24
IC Radiation Exposure Statement for Canada ................................. A-24
Wireless Operation Channel for Different Domains ...................... A-25
France Restricted Wireless Frequency Bands ..................................A-25
UL Safety Notices .......................................................................................A-27
Power Safety Requirement ....................................................................A-28
TV Tuner Notices ........................................................................................A-28
REACH ........................................................................................................ A-28
Nordic Lithium Cautions (for lithium-ion batteries) ...................... A-29
Optical Drive Safety Information .........................................................A-30
Laser Safety Information ......................................................................... A-30
Service warning label ............................................................................... A-30
CDRH Regulations ..................................................................................... A-30
Macrovision Corporation Product Notice ......................................... A-31
CTR 21 Approval(for Notebook PC with built-in Modem) .......... A-32
European Union Eco-label ...................................................................... A-34
Global Environmental Regulation Compliance and Declaration A-35
Takeback Services ...................................................................................... A-35
4
Notebook PC User Manual
Chapter 1:
Introducing the
Notebook PC
1
6
Notebook PC User Manual

About This User’s Manual

You are reading the Notebook PC User’s Manual. This User’s Manual provides information regarding the various components in the Notebook PC and how to use them. The following are major chapters of this User’s Manual:
1. Introducing the Notebook PC
Introduces you to the Notebook PC and this User’s Manual.
2. Knowing the Parts
Gives you information on the Notebook PC’s components.
3. Getting Started
Gives you information on getting started with the Notebook PC.
4. Using the Notebook PC
Gives you information on using the Notebook PC’s components.
5. Appendix
Introduces you to optional accessories and gives additional
information.
The actual bundled operating system and applications differ by models and territories. There may be differences between your Notebook PC and the pictures shown in this manual. Please accept your Notebook PC as being correct.

Notes for This Manual

A few notes and warnings are used throughout this guide, allowing you to complete certain tasks safely and effectively. These notes have different degrees of importance as follows:
WARNING! Important information that must be followed for safe operation.
IMPORTANT! Vital information that must be followed to prevent damage to data, components, or persons.
TIP: Tips for completing tasks.
NOTE: Information for special situations.
Notebook PC User Manual
7

Safety Precautions

The following safety precautions will increase the life of the Notebook PC. Follow all precautions and instructions. Except as described in this manual, refer all servicing to qualified personnel.
Disconnect the AC power and remove the battery pack(s) before cleaning. Wipe the Notebook PC using a clean cellulose sponge or chamois cloth dampened with a solution of nonabrasive detergent and a few drops of warm water and remove any extra moisture with a dry cloth.
DO NOT place on uneven or unstable work surfaces. Seek servicing if the casing has been damaged.
DO NOT expose to dirty or dusty environments. DO NOT operate during a gas leak.
DO NOT press or touch the display panel. Do not place together with small items that may scratch or enter the Notebook PC.
DO NOT leave the Notebook PC on your lap or any part of the body to prevent discomfort or injury from heat exposure.
DO NOT place or drop objects on top and do not shove any foreign objects into the Notebook PC.
DO NOT expose to strong magnetic or electrical fields.
DO NOT expose to or use near liquids, rain, or moisture. DO NOT use the modem during electrical storms.
Battery safety warning: DO NOT throw the battery in fire. DO NOT short circuit the contacts. DO NOT disassemble the battery.
8
Notebook PC User Manual
SAFE TEMP: This Notebook PC should only be used in environments with ambient temperatures between 10°C (50°F) and 35°C (95°F).
INPUT RATING: Refer to the rating label on the bottom of the Notebook PC and be sure that your power adapter complies with the rating.
DO NOT carry or cover a Notebook PC that is powered ON with any materials that will reduce air circulation
DO NOT use strong solvents such as thinners, benzene, or other chemicals on or near the surface.
such as a carrying bag.
DO NOT use damaged power cords, accessories, or other peripherals.
Incorrect installation of battery may cause explosion and damage the Notebook PC.
DO NOT throw the Notebook PC in municipal waste. This product has been designed to enable proper reuse of parts and recycling. The symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment and mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the battery in municipal waste. The symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste.
Notebook PC User Manual
9
Transportation Precautions
To prepare the Notebook PC for transport, you should turn it OFF and disconnect all external peripherals to prevent damage to the connectors. The hard disk drive’s head retracts when the power is turned OFF to prevent scratching of the hard disk surface during transport. Therefore, you should not transport the Notebook PC while the power is still ON. Close the display panel and check that it is latched securely in the closed position to protect the keyboard and display panel.
CAUTION! The Notebook PC’s surface is easily dulled if not properly cared for. Be careful not to rub or scrape the Notebook PC surfaces.
Cover Your Notebook PC
Purchase a carrying bag to protect the Notebook PC from dirt, water, shock, and scratches.
Charge Your Batteries
If you intend to use battery power, be sure to fully charge your battery pack and any optional battery packs before going on long trips. Remember that the power adapter charges the battery pack as long as it is plugged into the computer and an AC power source. Be aware that it takes much longer to charge the battery pack when the Notebook PC is in use.
10
Notebook PC User Manual
Airplane Precautions
Contact your airline if you want to use the Notebook PC on the airplane. Most airlines will have restrictions for using electronic devices. Most airlines will allow electronic use only between and not during takeoffs and landings.
CAUTION! There are three main types of airport security devices: X-ray machines (used on items placed on conveyor belts), magnetic detectors (used on people walking through security checks), and magnetic wands (hand-held devices used on people or individual items). You can send your Notebook PC and diskettes through airport X-ray machines. However, it is recommended that you do not send your Notebook PC or diskettes through airport magnetic detectors or expose them to magnetic wands.
Notebook PC User Manual
11

Preparing your Notebook PC

1
2
3
HDMI
1
3
110V-220V
2
These are quick instructions for using your Notebook PC.
Installing the Battery Pack
Connecting the Power Adapter
Opening the LCD display panel
1. Carefully lift up the display panel with your thumb.
2. Slowly tilt the display panel forward or backward to a comfortable viewing angle.
Turning on the Power
1. Push and release the power button located beneath the LCD display panel.
2. Use [Fn]+[F5] or [Fn]+[F6] to adjust the LCD brightness.
12
Notebook PC User Manual
Chapter 2:
Knowing the parts
2
14
Notebook PC User Manual

Top Side

4
5
6
7
3
2
1
9
The keyboard differs for each territory.
14” model
Notebook PC User Manual
15
esc
f1 f2 f3 f4 f5 f6 f7 f8 f9
f10 f11 f12
pause prt sc
sysrq
delete
backspace
home
home
num lk scr lk
pgup
pgup
pgdn
pgdn
enter
enter
shift
shift
ctrlaltctrl fn alt
end
end
insert
delete
insert
break
7 8 9
4 5 6
1 203
tab
caps lock
4
5
6
7
1
3
9
15.6”/16” model
16
Notebook PC User Manual
Camera
1
The built-in camera allows picture taking or video
recording. Can be used with video conferencing and other interactive applications.
Camera Indicator
2
The camera indicator shows when the built-in camera is in
use.
Microphone (Built-in)
3
The built-in mono microphone can be used for video
conferencing, voice narrations, or simple audio recordings.
4
Display Panel
The display panel functions the same as a desktop monitor.
The Notebook PC uses an active matrix TFT LCD, which provides excellent viewing like that of desktop monitors. Unlike desktop monitors, the LCD panel does not produce any radiation or flickering, so it is easier on the eyes. Use a soft cloth without chemical liquids (use plain water if necessary) to clean the display panel.
Power Switch
5
The power switch allows powering ON and OFF the
Notebook PC and recovering from STD. Use the switch once to turn ON and once to turn OFF the Notebook PC. The power switch only works when the display panel is opened.
Notebook PC User Manual
17
Keyboard
6
The keyboard provides full-sized keys with comfortable
travel (depth at which the keys can be depressed) and palm rest for both hands. Two Windows function keys are provided to help ease navigation in the Windows operating system.
7
Touchpad and Buttons
The touchpad with its buttons is a pointing device that
provides the same functions as a desktop mouse. A software-controlled scrolling function is available after setting up the included touchpad utility to allow easy Windows or web navigation.
Status Indicators (top)
8
Status indicators represent various hardware/software
conditions. See indicator details in Chapter 3.
9
Status Indicators (front)
Status indicators represent various hardware/software
conditions. See indicator details in Chapter 3.
18
Notebook PC User Manual

Bottom Side

1
2
21 3
4
The bottom side may vary in appearance depending on model.
The battery pack size varies depending on model.
14” model
Notebook PC User Manual
19
21 3
4
15.6”/16” model
WARNING! The bottom of the Notebook PC can get very hot. Be careful when handling the Notebook PC while it is in operation or recently been in operation. High temperatures are normal during charging or operation. Do not use on soft surfaces such as beds or sofas which may block the vents. DO NOT PUT THE NOTEBOOK PC ON YOUR LAP OR OTHER PARTS OF THE BODY TO AVOID INJURY FROM THE HEAT.
20
Notebook PC User Manual
1
Battery Lock - Spring
The spring battery lock is used to keep the battery
pack secured. When the battery pack is inserted, it will automatically lock. To remove the battery pack, this spring lock must be held in the unlocked position.
2
Battery Pack
The battery pack is automatically charged when the
Notebook PC is connected to an AC power source and maintains power to the Notebook PC when AC power is not connected. This allows use when moving temporarily between locations. Battery time varies by usage and by the specifications for this Notebook PC. The battery pack cannot be disassembled and must be purchased as a single unit.
Battery Lock - Manual
3
The manual battery lock is used to keep the battery pack
secured. Move the manual lock to the unlocked position to insert or remove the battery pack. Move the manual lock to the locked position after inserting the battery pack.
Hard Disk Drive Compartments
4
The hard disk drive is secured in a compartment. Visit an
authorized service center or retailer for information on hard disk drive upgrades for your Notebook PC. Only purchase hard disk drives from authorized retailers of this Notebook PC to ensure maximum compatibility and reliability.
Notebook PC User Manual
21

Right Side

1
2 3 4
5 6
7
2
3 4
1
5 8 6 7
14” model
15.6”/16” model
Optical Drive
1
The Notebook PC comes in various models with different
optical drives. The Notebook PC’s optical drive may support compact discs (CD) and/or digital video discs (DVD) and may have recordable (R) or re-writable (RW) capabilities. See the marketing specifications for details on each model.
Optical Drive Activity Indicator
2
(location varies by model)
The optical drive activity indicator shows when data is
being transferred by the optical disk drive. This indicator will light in proportion to the data size transferred.
22
Notebook PC User Manual
Optical Drive Electronic Eject
3
The optical drive eject has an electronic eject button for
opening the tray. You can also eject the optical drive tray through any software player or by right clicking the optical drive in Windows “Computer” and selecting Eject.
Optical Drive Emergency Eject
4
(location varies by model)
The emergency eject is used to eject the optical drive tray
in case the electronic eject does not work. Do not use the emergency eject in place of the electronic eject.
5
USB Port (2.0)
The USB (Universal Serial Bus) port is compatible with USB
2.0 or USB 1.1 devices such as keyboards, pointing devices, cameras, hard disk drives, printers, and scanners connected in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). USB allows many devices to run simultaneously on a single computer, with some peripherals acting as additional plug-in sites or hubs. USB supports hot-swapping of devices so that most peripherals can be connected or disconnected without restarting the computer.
LAN Port
6
The RJ-45 LAN port with eight pins is larger than the RJ-11
modem port and supports a standard Ethernet cable for connection to a local network. The built-in connector allows convenient use without additional adapters.
Notebook PC User Manual
23
7
Power (DC) Input
The supplied power adapter converts AC power to DC
power for use with this jack. Power supplied through this jack supplies power to the Notebook PC and charges the internal battery pack. To prevent damage to the Notebook PC and battery pack, always use the supplied power adapter.
The adapter may become warm to hot when in use. Ensure not to cover the adapter and keep it away from your body.
8
Flash Memory Slot
Normally an external memory card reader must be
purchased separately in order to use memory cards from devices such as digital cameras, MP3 players, mobile phones, and PDAs. This Notebook PC has a built-in high-speed memory card reader that can conveniently read from and write to many flash memory cards.
24
Notebook PC User Manual

Left Side

HDMI
3 4 5
6
21
E-SATA
3 4 5 7 621
14” model
15.6”/16” model
1
Kensington® Lock Port
The Kensington® lock port allows the Notebook PC to
be secured using Kensington® compatible Notebook PC security products. These security products usually include a metal cable and lock that prevent the Notebook PC to be removed from a fixed object. Some may also include a motion detector to sound an alarm when moved.
Air Vents
2
The air vents allow cool air to enter and warm air to exit the
Notebook PC.
Ensure that paper, books, clothing, cables, or other objects do not block any of the air vents or else overheating may occur.
3
Display (Monitor) Output
The 15-pin D-sub monitor port supports a standard
VGA-compatible device such as a monitor or projector to allow viewing on a larger external display.
Notebook PC User Manual
25
HDMI
4
HDMI Port
HDMI (High-Definition Multimedia Interface) is an
uncompressed all-digital audio/video interface between any audio/video source, such as a set-top box, DVD player, and A/V receiver and an audio and/or video monitor, such as a digital television (DTV). Supports standard, enhanced, or high-definition video, plus multi-channel digital audio on a single cable. It transmits all ATSC HDTV standards and supports 8-channel digital audio, with bandwidth to spare to accommodate future enhancements or requirements.
5
6
USB Port (2.0)
Headphone Output & Microphone Input Combo Jack
(on selected models)
This combo jack (1/8 inch) can be used to connect the
Notebook PC’s audio out signal to amplified speakers or headphones, or can be used to connect an external microphone or output signals from audio devices. Select the connecting device type in the dialog box and switches the jack function.
Headphone Output Jack (on selected models)
Microphone Input Jack
7

Rear Side

1
1
1
Battery Pack
The battery pack is automatically charged when the
Notebook PC is connected to an AC power source and maintains power to the Notebook PC when AC power is not connected. This allows use when moving temporarily between locations. Battery time varies by usage and by the specifications for this Notebook PC. The battery pack cannot be disassembled and must be purchased as a single unit.

Front Side

14” model
15.6”/16” model
26
Flash Memory Slot
1
Notebook PC User Manual
Chapter 3:
Getting Started
3
28
Notebook PC User Manual

Power System

HDMI
1
3
110V-220V
2

Using AC Power

The Notebook PC power is comprised of two parts, the power adapter and the battery power system. The power adapter converts AC power from a wall outlet to the DC power required by the Notebook PC. Your Notebook PC comes with a universal AC-DC adapter. That means that you may connect the power cord to any 100V-120V as well as 220V-240V outlets without setting switches or using power converters. Different countries may require that an adapter be used to connect the provided US-standard AC power cord to a different standard. Most hotels will provide universal outlets to support different power cords as well as voltages. It is always best to ask an experienced traveler about AC outlet voltages when bringing power adapters to another country.
You can buy travel kits for the Notebook PC that includes power and modem adapters for almost every country.
WARNING! DO NOT connect the AC power cord to an AC outlet prior to connecting the DC plug to the Notebook PC. Doing so may damage the AC-DC adapter.
Notebook PC User Manual
29
IMPORTANT! Damage may occur if you use a different adapter to power the Notebook PC or use the Notebook PC’s adapter to power other electrical devices. If there is smoke, burning scent, or extreme heat coming from the AC-DC adapter, seek servicing. Seek servicing if you suspect a faulty AC-DC adapter. You may damage both your battery pack(s) and the Notebook PC with a faulty AC-DC adapter.
This Notebook PC may come with either a two or three-prong plug depending on territory. If a three-prong plug is provided, you must use a grounded AC outlet or use a properly grounded adapter to ensure safe operation of the Notebook PC.
WARNING! THE POWER ADAPTER MAY BECOME WARM TO HOT WHEN IN USE. BE SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM YOUR BODY.
Unplug the power adapter or switch off the AC outlet to minimize the power consumption when the Notebook PC is not in use.
30
Notebook PC User Manual

Using Battery Power

1
2
3
The Notebook PC is designed to work with a removable battery pack. The battery pack consists of a set of battery cells housed together. A fully charged pack will provide several hours of battery life, which can be further extended by using power management features through the BIOS setup. Additional battery packs are optional and can be purchased separately through a Notebook PC retailer.
Installing and Removing the Battery Pack
Your Notebook PC may or may not have its battery pack installed. If your Notebook PC does not have its battery pack installed, use the following procedures to install the battery pack.
IMPORTANT! Never attempt to remove the battery pack while the Notebook PC is turned ON, as this may result in the loss of working data.
To install the battery pack:
Loading...
+ 88 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
