Asus MyLogo2 Application Manual

ASUS MyLogo2™

The ASUS MyLogo2™ utility lets you customize the boot logo. The boot logo is the
image that appears on screen during the Power‑On Self‑Tests (POST). The ASUS
MyLogo2™ is automatically installed when you install the ASUS Update utility from
the Support CD. See section “Utilities menu” for details.

• Before using the ASUS MyLogo2™, use the AFUDOS utility to make a copy
of your original BIOS le, or obtain the latest BIOS version from the ASUS

website. See section AFUDOS utility in manual.

• Make sure that the BIOS item Full Screen Logo is set to [Enabled] if you

wish to use ASUS MyLogo2. See section Boot Settings Conguration in
manual.

• You can create your own boot logo image in GIF le format.

To launch the ASUS MyLogo2™:

1. Launch the ASUS Update utility. Refer to section “ASUS Update utility” in
manual for details.

2. Select

3. Check the option

4. Select

5. When prompted, locate the new

6. From the left window pane, select the

Options from the drop down menu, then click Next.

Launch MyLogo to replace system boot logo before

ashing BIOS, then click Next.

Update BIOS from a le from the drop down menu, then click Next.

BIOS le, then click Next. The ASUS
MyLogo window appears.

folder that contains the image you
intend to use as your boot logo.

7. When the logo images appear on the
right window pane, select an image to
enlarge by clicking on it.

8. Adjust the boot image to your desired

size by selecting a value on the Ratio

box.

9. When the screen returns to the ASUS Update utility, ash the original BIOS to

load the new boot logo.

10. After ashing the BIOS, restart the computer to display the new boot logo

during POST.
