ASUS MeMO Pad K00B (ME173X) User Manual

MeMO Pad User Manual

E8254

ASUS is devoted to creating environment-friendly products
and packaging to safeguard consumers’ health while
minimizing the impact on the environment. The reduction
of the number of the manual pages complies with the
reduction of carbon emission.
For the detailed user manual and related information, refer
to the user manual included in the MeMO Pad or visit the
ASUS Support Site at http://support.asus.com/.

E8254_ME173X_User_Manual.indd 1 4/23/13 10:09:53 AM

Charging your batteries

Ensure to fully charge your battery pack before using your
MeMO Pad in battery mode for extended periods. Remember
that the power adapter charges the battery pack as long as it is
plugged into an AC power source. Be aware that it takes much
longer to charge the battery pack when the MeMO Pad is in
use.

IMPORTANT! Do not leave the MeMO Pad connected to the
power supply once it is fully charged. MeMO Pad is not designed
to be left connected to the power supply for extended periods
of time.

Airplane precautions

Contact your airline provider to learn about related inight
services that can be used and restrictions that must be followed
when using your MeMO Pad in-ight.

IMPORTANT! You can send your MeMO Pad through x-ray
machines (used on items placed on conveyor belts), but do not
expose them from magnetic detectors and wands.

Safety precautions

This MeMO Pad should only be used in enviroments with
ambient temperatures between 0°C (32°F) and 35°C (95°F).

Long time exposure to extremely high or low temperature
may quickly deplete and shorten the battery life. To ensure the
battery’s optimal performance, ensure that it is exposed within
the recommended environment temperature.

E8254_ME173X_User_Manual.indd 2 4/23/13 10:09:53 AM

ASUS MeMO Pad

3

Package contents

NOTES:

• If any of the items is damaged or missing, contact your
retailer.

• The bundled power adapter varies with country or region.

ASUS MeMO Pad Power adapter

Micro USB cable Technical documentations and

warranty card

E8254_ME173X_User_Manual.indd 3 4/23/13 10:09:54 AM

ASUS MeMO Pad

4

Your MeMO Pad

Touch screen panel

The touch screen panel allows you to operate your
MeMO Pad using touch gestures or a stylus pen.

Front camera

This built-in 1.2-megapixel camera allows you to take
pictures or record videos using your MeMO Pad.

E8254_ME173X_User_Manual.indd 4 4/23/13 10:09:56 AM

ASUS MeMO Pad

5

Volume button

The volume button allows you to increase or decrease
the volume level of your MeMO Pad.

Power button

Press the power button for about two (2) seconds to
turn your MeMO Pad on.

To turn your MeMO Pad o, press the power button
for about two (2) seconds and when prompted, tap
Power o then tap OK.

To lock your MeMO Pad or put it to standby mode,
press and quickly release the power button.

In the event that your MeMO Pad becomes
unresponsive, press and hold the power button for
about eight (8) seconds to force it to shut down.

IMPORTANT!

• When your MeMO Pad is inactive for fteen (15)

seconds, it will automatically go to standby mode.

• Forcing the system to restart may result to data
loss. We strongly recommend that you back up
your data regularly.

E8254_ME173X_User_Manual.indd 5 4/23/13 10:09:57 AM

ASUS MeMO Pad

6

Speaker/Headset port

This port allows you to connect the MeMO Pad to
amplied speakers or a headset.

IMPORTANT! This port does not support an external
microphone.

Microphone

The built-in microphone can be used for video
conferencing, voice narrations or simple audio
recordings.

Micro USB 2.0 port

Use the micro USB (Universal Serial Bus) 2.0 to charge
the battery pack or supply power to your MeMO Pad.
This port also allows you to transfer data from your
computer to your MeMO Pad and vice versa.

NOTE: When you connect your MeMO Pad to the
USB port on your computer, your MeMO Pad will be
charged only when it is in sleep mode (screen o) or
turned o.

Rear camera

This built-in 5-megapixel camera allows you to take
high-denition pictures or record high-denition
videos using your MeMO Pad.

E8254_ME173X_User_Manual.indd 6 4/23/13 10:09:58 AM

ASUS MeMO Pad

7

MicroSD card slot

The MeMO Pad comes with a built-in memory card
reader slot that supports microSD and microSDHC
card formats.

Audio speaker

The built-in speaker allows you to hear audios straight
from your MeMO Pad. Audio features are software
controlled.

E8254_ME173X_User_Manual.indd 7 4/23/13 10:09:58 AM

ASUS MeMO Pad

8

Charging your MeMO Pad

Connect the micro USB cable to the power adapter.

Plug the micro USB connector into your MeMO Pad.

Plug the power adapter into a grounded power outlet.

To charge your MeMO Pad:

Charge your MeMO Pad for eight (8) hours before
using it in battery mode for the rst time.

E8254_ME173X_User_Manual.indd 8 4/23/13 10:09:59 AM
