Motherboard LayoutMotherboard Layout
Motherboard Layout
Motherboard LayoutMotherboard Layout
English
EnglishEnglish
EnglishEnglish
22
2
22
1 PS2_USB_PWR1 Jumper 16 BIOS SPI Chip
2 OC 800 / FSB0 / FSB1 / FSB2 Jumper 17 Chassis Fan Connector (CHA_FAN2)
3 775-Pin CPU Socket 18 USB 2.0 Header (USB6_7, Blue)
4 North Bridge Controller 19 USB 2.0 Header (USB4_5, Blue)
5 2 x 240-pin DDR2 DIMM Slots 20 Serial Port Connector (COM2)
(Dual Channel: DDRII_1, DDRII_2; Yellow) 21 Print Port Header (LPT1, Purple)
6 A TX Power Connector (ATXPWR1) 22 Floppy Connector (FLOPPY1)
7 IDE1 Connector (IDE1, Blue) 23 Front Panel Audio Header
8 Clear CMOS Jumper (CLRCMOS1) (HD_AUDIO1, Lime)
9 South Bridge Controller 24 HDMI_SPDIF Header
10 Third SATAII Connector (SA TAII_3; Orange) (HDMI_SPDIF1, Yellow)
11 Fourth SATAII Connector (SATAII_4; Ora nge) 25 Internal Audio Connector: CD1 (Black)
12 Secondary SATAII Connector (SA T AII_2; Red) 26 PCI Slots (PCI1- 5)
13 Primary SATAII Connector (SA T AII_1; Red) 27 PCI Express x16 Slot (PCIE1)
14 Chassis Speaker Header 28 CPU Fan Connector (CPU_FAN1)
(SPEAKER 1, Purple) 29 Power Fan Connector (PWR_FAN1)
15 System Panel Header (P ANEL1, Orange) 30 A TX 12V Connector (A TX12V1)
ASRock G31DE-DVR Motherboard
I/O PI/O P
I/O P
I/O PI/O P
* 3 LAN RJ-45 Port 8 VGA Port
* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED
indications.
anelanel
anel
anelanel
1 PS/2 Mouse Port (Green) 6 Microphone (Pink)
2 USB 2.0 Ports (USB23) 7 USB 2.0 Ports (USB01)
4 Line In (Light Blue) 9 COM Port
5 Line Out (Lime) 10 PS/2 Keyboard Port (Purple)
Activity/Link LED SPEED LED
Status Description Status Description
Off No Activity Off 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
LAN Port LED Indications
Green 1Gbps connection
ACT/LINK
LED
LAN Port
SPEED
LED
* To enable Multi-Streaming function, you need to connect a front panel audio cable to the front
panel audio header. Please refer to below steps for the software setting of Multi-Streaming.
For Windows® XP:
After restarting your computer, you will find “Mixer” tool on your system. Please select “Mixer
ToolBox” , click “Enable playback multi-streaming”, and click “ok”. Choose “2CH” or
“4CH” and then you are allowed to select “Realtek HDA Primary output” to use Rear Speaker
and Front Speaker, or select “Realtek HDA Audio 2nd output” to use front panel audio. Then
reboot your system.
For Windows® VistaTM:
After restarting your computer, please double-click “Realtek HD Audio Manager” on the
system tray. Set “Speaker Configuration” to “Quadraphonic” or “Stereo”. Click “Device
advanced settings”, choose “Make front and rear output devices playbacks two different audio
streams simultaneously”, and click “ok”. Then reboot your system.
