ASRock FM2A75M-DGS R2.0 Motherboard

English

1

Motherboard Layout

151617181920212223

29

28

27

26

25

24

7

8

9

10
11
12

13

14

English

1 ATX 12V Power Connector (ATX12V1) 16 SATA3 Connector (SATA_5)
2 ATX Power Connector (ATXPWR1) 17 SPI Flash Memory (64Mb)
3 CPU Heatsink Retention Module 18 USB 2.0 Header (USB4_5)
4 CPU Socket 19 USB 2.0 Header (USB8_9)
5 CPU Fan Connector (CPU_FAN1) 20 Print Port Header (LPT1)
6 2 x 240-pin DDR3 DIMM Slots 21 USB 3.0 Header (USB3_2_3)
(Dual Channel: DDR3_A1, DDR3_B1) 22 COM Port Header (COM1)
7 Chassis Fan Connector (CHA_FAN1) 23 Front Panel Audio Header (HD_AUDIO1)
8 Southbridge Controller 24 PCI Slot (PCI1)
9 Chassis Speaker Header (SPEAKER1) 25 PCI Express 2.0 x1 Slot (PCIE2)
10 System Panel Header (PANEL1) 26 Clear CMOS Jumper (CLRCMOS1)
11 SATA3 Connector (SATA_1) 27 PCI Express 2.0 x16 Slot (PCIE1)
12 SATA3 Connector (SATA_2) 28 Chassis Intrusion Header (CI1)
13 SATA3 Connector (SATA_4) 29 Power Fan Connector (PWR_FAN1)
14 SATA3 Connector (SATA_3)
15 SATA3 Connector (SATA_6)

2

ASRock FM2A75M-DGS R2.0 Motherboard

I/O Panel

6

4

3

5

7

9

10

1

11

1 PS/2 Mouse Port (Green) 7 USB 3.0 Ports (USB3_01)
* 2 LAN RJ-45 Port *** 8 USB 2.0 Ports (USB01)
3 Line In (Light Blue) 9 DVI-D Port (DVI1)
** 4 Front Speaker (Lime) 10 D-Sub Port (VGA1)
5 Microphone (Pink) 11 PS/2 Keyboard Port (Purple)
*** 6 USB 2.0 Ports (USB23)

* There are two LED next to the LAN port. Please refer to the table below for the LAN port LED
indications.

Activity/Link LED SPEED LED

Status Description Status Description

LAN Port LED Indications

8

2

ACT/LINK
LED

SPEED
LED

Off No Link Off 10Mbps connection
Blinking Data Activity Orange 100Mbps connection
On Link Green 1Gbps connection

** To enable Multi-Streaming function, you need to connect a front panel audio cable to the front
panel audio header. Please refer to below steps for the software setting of Multi-Streaming.
After restarting your computer, please double-click “Realtek HD Audio Manager” on the

system tray. Set “Speaker Conguration” to “Quadraphonic” or “Stereo”. Click “Device

advanced settings”, choose “Make front and rear output devices playbacks two different audio
streams simultaneously”, and click “ok”. Then reboot your system.

LAN Port

*** It is recommended to install the USB Keyboard/Mouse cable to USB 2.0 ports (USB01 or
USB23) instead of USB 3.0 ports.

ASRock FM2A75M-DGS R2.0 Motherboard

English

3

1. Introduction

Thank you for purchasing ASRock FM2A75M-DGS R2.0 motherboard, a reliable
motherboard produced under ASRock’s consistently stringent quality control. It
delivers excellent performance with robust design conforming to ASRock’s commit­ment to quality and endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-

step installation guide. More detailed information of the motherboard can be found
in the user manual presented in the Support CD.

Because the motherboard specications and the BIOS software might

be updated, the content of this manual will be subject to change without
notice. In case any modications of this manual occur, the updated ver­sion will be available on ASRock website without further notice. You may

nd the latest VGA cards and CPU support lists on ASRock website as

well. ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock FM2A75M-DGS R2.0 Motherboard (Micro ATX Form Factor)
ASRock FM2A75M-DGS R2.0 Quick Installation Guide
ASRock FM2A75M-DGS R2.0 Support CD
2 x Serial ATA (SATA) Data Cables (Optional)
1 x I/O Panel Shield

English

ASRock Reminds You...

To get better performance in Windows® 8 / 8 64-bit / 7 / 7 64-bit / VistaTM

/ VistaTM 64 bit, it is recommended to set the BIOS option in Storage
Conguration to AHCI mode.

4

ASRock FM2A75M-DGS R2.0 Motherboard

1.2 Specications

Platform - Micro ATX Form Factor

- Solid Capacitor for CPU power
CPU - Support for Socket FM2 100W processors

- Supports AMD’s Cool ‘n’ QuietTM Technology

- UMI-Link GEN2

Chipset - AMD A75 FCH (Hudson-D3)
Memory - Dual Channel DDR3 Memory Technology

- 2 x DDR3 DIMM slots

- Support DDR3 1866/1600/1333/1066 non-ECC, un-buffered
memory (see CAUTION 1)

- Max. capacity of system memory: 32GB (see CAUTION 2)

- Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2

- Supports AMD Memory Prole (AMP)

Expansion Slot - 1 x PCI Express 2.0 x16 slot (PCIE1 @ x16 mode)

- 1 x PCI Express 2.0 x1 slot

- 1 x PCI slot

- Supports AMD Dual Graphics (see CAUTION 3)
Graphics - AMD Radeon HD 7000 graphics

- DirectX 11, Pixel Shader 5.0

- Max. shared memory 2GB

- Dual VGA Output: support DVI and D-Sub ports by

independent display controllers

- Supports Dual-link DVI with max. resolution up to

2560x1600 @ 75Hz

- Supports D-Sub with max. resolution up to 1920x1600 @
60Hz

- Supports AMD Steady Video

processing capability for automatic jutter reduction on home/
online video

- Supports HDCP function with DVI port

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback
with DVI port

Audio - 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efcient Ethernet 802.3az

- Supports PXE

TM

2.0: New video post

English

ASRock FM2A75M-DGS R2.0 Motherboard

5

English

Rear Panel I/O I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x D-Sub Port

- 1 x DVI-D Port

- 4 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)

- HD Audio Jack: Line in / Front Speaker / Microphone
SATA 3 - 6 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

RAID 1 and RAID 10), NCQ, AHCI and “Hot Plug” functions

USB 3.0 - 2 x Rear USB 3.0 ports, support USB 1.1/2.0/3.0 up to
5Gb/s

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports),
supports USB 1.1/2.0/3.0 up to 5Gb/s
Connector - 6 x SATA3 6.0Gb/s connectors

- 1 x Print port header

- 1 x COM port header

- 1 x Chassis Intrusion header

- 1 x CPU Fan connector (4-pin)

- 1 x Chassis Fan connector (4-pin)

- 1 x Power Fan connector (3-pin)

- 24 pin ATX power connector

- 4 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)
BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- DRAM, VDDP, VDDR, SB Voltage Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),
CyberLink MediaEspresso 6.5 Trial, Google Chrome
Browser and Toolbar
Hardware - CPU Temperature Sensing
Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan

- CPU/Chassis Fan Multi-Speed Control

6

ASRock FM2A75M-DGS R2.0 Motherboard

- CASE OPEN detection

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore

OS - Microsoft® Windows® 8 / 8 64-bit / 7 / 7 64-bit / Vista

VistaTM 64-bit compliant
Certications - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking,
including adjusting the setting in the BIOS, applying Untied Overclocking
Technology, or using third-party overclocking tools. Overclocking may
affect your system’s stability, or even cause damage to the components
and devices of your system. It should be done at your own risk and
expense. We are not responsible for possible damage caused by
overclocking.

TM

/

CAUTION!

1. Whether 1866/1600MHz memory speed is supported depends
on the CPU you adopt. If you want to adopt DDR3 1866/1600
memory module on this motherboard, please refer to the mem­ory support list on our website for the compatible memory mod­ules.

ASRock website http://www.asrock.com

2. Due to the operating system limitation, the actual memory size
may be less than 4GB for the reservation for system usage un­der Windows® 8 / 7 / VistaTM. For Windows® 64-bit OS with 64­bit CPU, there is no such limitation. You can use ASRock XFast
RAM to utilize the memory that Windows® cannot use.

3. For the discrete GPUs which support Dual Graphics technology,
please refer to http://www.amd.com/us/products/technologies/
dual-graphics/Pages/dual-graphics.aspx#3 for details.

English

ASRock FM2A75M-DGS R2.0 Motherboard

7

1.3 Pin Header Easy Installation Guide

IntA_P_D+

1

ID

IntA_P_SSRX-

ASRock motherboard is equipped with pin headers with obvious colors which indi­cate you to recognize the crucial headers more easily. Please refer to below illustra-

tions for the pin denition of onboard headers. If you want to have more information

about the usage of these headers, please refer to “Jumpers Setup“ and “Onboard
Headers and Connectors“ for details.

Front Panel Audio Header

English

8

ntA_P_SSRX+

I

Vbus

Vbus

I

ntA_P_SSRX-

IntA_P_SSRX+

USB 3.0 Header

IntA_P_D+

IntA_P_D-

GND

IntA_P_SSTX+

IntA_P_SSTX-

GND

USB 2.0 Header

GND

IntA_P_SSTX-

IntA_P_SSTX+

GND

IntA_P_D-

ASRock FM2A75M-DGS R2.0 Motherboard

Chassis Speaker Header

System Panel Header

1.4 Jumpers Setup

The illustration shows how jumpers are
setup. When the jumper cap is placed on
pins, the jumper is “Short”. If no jumper cap
is placed on pins, the jumper is “Open”. The
illustration shows a 3-pin jumper whose
pin1 and pin2 are “Short” when jumper cap
is placed on these 2 pins.

Jumper Setting Description

Clear CMOS Jumper

(CLRCMOS1)
(see p.2, No. 26)

Note: CLRCMOS1 allows you to clear the data in CMOS. To clear and reset the
system parameters to default setup, please turn off the computer and unplug

the power cord from the power supply. After waiting for 15 seconds, use a
jumper cap to short pin2 and pin3 on CLRCMOS1 for 5 seconds. However,
please do not clear the CMOS right after you update the BIOS. If you need

to clear the CMOS when you just nish updating the BIOS, you must boot
up the system rst, and then shut it down before you do the clear-CMOS ac­tion. Please be noted that the password, date, time, user default prole, 1394

GUID and MAC address will be cleared only if the CMOS battery is removed.

Clear CMOSDefault

If you clear the CMOS, the case open may be detected. Please adjust
the BIOS option “Clear Status” to clear the record of previous chassis
intrusion status.

ASRock FM2A75M-DGS R2.0 Motherboard

English

9

1.5 Onboard Headers and Connectors

Onboard headers and connectors are NOT jumpers. Do NOT place
jumper caps over these headers and connectors. Placing jumper caps
over the headers and connectors will cause permanent damage of the
motherboard!

Serial ATA3 Connectors These six Serial ATA3

(SATA_1: see p. 2, No. 11)

(SATA_2: see p. 2, No. 12)

(SATA_3: see p. 2, No. 14)

(SATA_4: see p. 2, No. 13)

(SATA_5: see p. 2, No. 16)

(SATA_6: see p. 2, No. 15)

Serial ATA (SATA) Either end of the SATA data
Data Cable cable can be connected to the

(Optional)

SATA3 hard disk or the SATA3

connector on this motherboard.

USB 2.0 Headers Besides four default USB 2.0

(9-pin USB4_5)

(see p. 2, No. 18)

ports on the I/O panel, there

this motherboard. Each USB 2.0
header can support two USB

2.0 ports.

(9-pin USB8_9)
(see p. 2, No. 19)

(SATA3) connectors support

SATA data cables for internal

SATA_1

SATA_2

SATA_3

SATA_4

storage devices. The current
SATA3 interface allows up to

SATA_5 SATA_6

6.0 Gb/s data transfer rate.

are two USB 2.0 headers on

English

10

ASRock FM2A75M-DGS R2.0 Motherboard

USB 3.0 Header Besides two default USB 3.0

(19-pin USB3_2_3)

(see p. 2, No. 21)

ports on the I/O panel, there is

one USB 3.0 header on this
motherboard. This USB 3.0
header can support two USB 3.0
ports.

Front Panel Audio Header This is an interface for the front

(9-pin HD_AUDIO1)

(see p. 2, No. 23)

panel audio cable that allows

convenient connection and
control of audio devices.

1. High Denition Audio supports Jack Sensing, but the panel wire on

the chassis must support HDA to function correctly. Please follow the
instruction in our manual and chassis manual to install your system.

2. If you use AC’97 audio panel, please install it to the front panel audio
header as below:

A. Connect Mic_IN (MIC) to MIC2_L.
B. Connect Audio_R (RIN) to OUT2_R and Audio_L (LIN) to OUT2_L.
C. Connect Ground (GND) to Ground (GND).
D. MIC_RET and OUT_RET are for HD audio panel only. You don’t

need to connect them for AC’97 audio panel.

E. To activate the front mic.
For Windows® 8 / 8 64-bit / 7 / 7 64-bit / VistaTM / VistaTM 64-bit OS:
Go to the "FrontMic" Tab in the Realtek Control panel. Adjust

“Recording Volume”.

Chassis Intrusion Header This motherboard supports

(2-pin CI1)

CASE OPEN detection feature

(see p.2, No. 28)

that detects if the chassis cover
has been removed. This feature
requires a chassis with chassis
intrusion detection design.

ASRock FM2A75M-DGS R2.0 Motherboard

English

11

System Panel Header This header accommodates

(9-pin PANEL1)

(see p.2 No. 10)

several system front panel

functions.

Connect the power switch, reset switch and system status indicator
on the chassis to this header according to the pin assignments below.
Note the positive and negative pins before connecting the cables.

PWRBTN (Power Switch):

Connect to the power switch on the chassis front panel. You may con-

gure the way to turn off your system using the power switch.

RESET (Reset Switch):

Connect to the reset switch on the chassis front panel. Press the reset
switch to restart the computer if the computer freezes and fails to per­form a normal restart.

PLED (System Power LED):

Connect to the power status indicator on the chassis front panel. The
LED is on when the system is operating. The LED keeps blinking
when the sys-tem is in S1 sleep state. The LED is off when the system
is in S3/S4 sleep state or powered off (S5).

HDLED (Hard Drive Activity LED):

Connect to the hard drive activity LED on the chassis front panel. The
LED is on when the hard drive is reading or writing data.

The front panel design may differ by chassis. A front panel module
mainly consists of power switch, reset switch, power LED, hard drive
activity LED, speaker and etc. When connecting your chassis front
panel module to this header, make sure the wire assignments and the
pin assign-ments are matched correctly.

English

Chassis Speaker Header Please connect the chassis

(4-pin SPEAKER 1)

(see p.2 No. 9)

speaker to this header.

Print Port Header This is an interface for print

(25-pin LPT1)

(see p.2 No. 20)

port cable that allows

convenient connection of printer

devices.

12

ASRock FM2A75M-DGS R2.0 Motherboard

Chassis and Power Fan Connectors Please connect the fan cables

(4-pin CHA_FAN1)

(see p.2 No. 7)

to the fan connectors and

match the black wire to the

ground pin. CHA_FAN1 fan

(3-pin PWR_FAN1)

(see p.2 No. 29)

speed can be controlled through
UEFI or AXTU.

CPU Fan Connectors Please connect the CPU fan

(4-pin CPU_FAN1)

(see p.2 No. 5)

ground pin.

Though this motherboard provides 4-Pin CPU fan (Quiet Fan) support, the 3-Pin

cable to the connector and

match the black wire to the

1 2 3 4

CPU fan still can work successfully even without the fan speed control function.
If you plan to connect the 3-Pin CPU fan to the CPU fan connector on this
motherboard, please connect it to Pin 1-3.

Pin 1-3 Connected

3-Pin Fan Installation

ATX Power Connector Please connect an ATX power

(24-pin ATXPWR1)

(see p.2 No. 2)

supply to this connector.

12 1

1324

Though this motherboard provides 24-pin ATX power connector,
it can still work if you adopt a traditional 20-pin ATX power supply.
To use the 20-pin ATX power supply, please plug your power
supply along with Pin 1 and Pin 13.

20-Pin ATX Power Supply Installation

24

12

13

1

ATX 12V Power Connector Please connect an ATX 12V

(4-pin ATX12V1)

(see p.2, No. 1)

power supply to this connector.

Serial port Header This COM1 header supports a

(9-pin COM1)

(see p.2 No.22)

serial port module.

ASRock FM2A75M-DGS R2.0 Motherboard

English

13

2. BIOS Information

The Flash Memory on the motherboard stores BIOS Setup Utility. When you start up
the computer, please press <F2> or <Del> during the Power-On-Self-Test (POST)
to enter BIOS Setup utility; otherwise, POST continues with its test routines. If you
wish to enter BIOS Setup after POST, please restart the system by pressing <Ctl>

+ <Alt> + <Delete>, or pressing the reset button on the system chassis. The BIOS

Setup program is designed to be user-friendly. It is a menu-driven program, which
allows you to scroll through its various sub-menus and to select among the prede­termined choices. For the detailed information about BIOS Setup, please refer to the

User Manual (PDF le) contained in the Support CD.

3. Software Support CD information

®

This motherboard supports various Microsoft

8 64-bit / 7 / 7 64-bit / VistaTM / Vista

motherboard contains necessary drivers and useful utilities that will enhance moth­erboard features. To begin using the Support CD, insert the CD into your CD-ROM
drive. It will display the Main Menu automatically if “AUTORUN” is enabled in your
computer. If the Main Menu does not appear automatically, locate and double-click

on the le “ASSETUP.EXE” from the BIN folder in the Support CD to display the

menus.

TM

Windows® operating systems: 8 /

64-bit. The Support CD that came with the

English

14

ASRock FM2A75M-DGS R2.0 Motherboard

Spezikationen

Plattform - Micro ATX-Formfaktor

- Festkondensator für CPU-Leistung
CPU - Unterstützt Sockel-FM2-100-W-Prozessoren

- Unterstützt Cool ‘n’ QuietTM-Technologie von AMD

- UMI-Link-GEN2

Chipsatz - AMD A75 FCH (Hudson-D3)
Speicher - Unterstützung von Dual-Kanal-Speichertechnologie

- 2 x Steckplätze für DDR3

- Unterstützt DDR3 1866/1600/1333/1066 non-ECC, unge
pufferter Speicher

- Max. Kapazität des Systemspeichers: 32GB

- Unterstützt Intel® Extreme Memory Prole (XMP)1.3/1.2

- Unterstützt AMD Memory Prole (AMP)

Erweiterungs- - 1 x PCI-Express-2.0-x16-Steckplätze (PCIE1: x16-Modus)
steckplätze - 1 x PCI Express 2.0 x1-Steckplätze

- 1 x PCI -Steckplätze

- Unterstützt AMD duale Grakkarten
Onboard-VGA - AMD Radeon HD 7000-Grak

- DirectX 11, Pixel Shader 5.0

- Maximal gemeinsam genutzter Speicher 2GB

- Doppel-VGA Ausgabe: unterstützt DVI und D-Sub Ports

durch unabhängige Bildschirmanzeige Kontrolleure

- Unterstützt Dual-link DVI mit einer maximalen Auösung von

2560 x 1600 bei 75 Hz

- Unterstützt D-Sub mit einer maximalen Auösung von

1920 x 1600 bei 60 Hz

- Unterstützt AMD Steady Video
Videonachbearbeitung für automatische Reduzierung von
Bildschwankungen bei Heim-/Online-Videos

- Unterstützt HDCP-Funktion mit DVI-Port

- Unterstutzt 1080p Blu-ray (BD) / HD-DVD-Wiedergabe
mit DVI-Port

Audio - 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Unterstützt Wake-On-LAN

- Unterstützt LAN-Kabelerkennung

- Unterstützt energieefzientes Ethernet 802.3az

- Unterstützt PXE

TM

2.0: Neuartige Funktion der

Deutsch

ASRock FM2A75M-DGS R2.0 Motherboard

15

Deutsch

E/A-Anschlüsse I/O Panel
an der Rückseite - 1 x PS/2-Mausanschluss

- 1 x PS/2-Tastaturanschluss

- 1 x D-Sub port

- 1 x DVI-D port

- 4 x Standard-USB 2.0-Anschlüsse

- 2 x Standard-USB 3.0-Anschlüsse

- 1 x RJ-45 LAN Port mit LED (ACT/LINK LED und SPEED
LED)

- HD Audiobuchse: Audioeingang / Lautsprecher vorne /
Mikrofon
SATA3 - 6 x SATA 3-Anschluss mit 6,0 Gb/s, unterstützt RAID-

(RAID 0, RAID 1 und RAID 10), NCQ-, AHCI- und „Hot

Plugging“-Funktionen
USB3.0 - 2 x USB 3.0-Ports an der Rückseite, unterstützt USB

1.1/2.0/3.0 mit bis zu 5 Gb/s

- 1 x USB 3.0-Header (unterstützt zwei USB 3.0-Ports) an der

Vorderseite, unterstützt USB 1.1/2.0/3.0 mit bis zu 5 Gb/s

Anschlüsse - 6 x SATA3 6,0 GB/s-Anschlüsse

- 1 x Druckerport-Anschlussleiste

- 1 x COM-Anschluss-Header

- 1 x Verteiler für Gehäuseeindringversuche

- 1 x CPUlüfter-Anschluss (4-pin)

- 1 x Gehäuselüfter-Anschluss (4-pin)

- 1 x Stromlüfter-Anschluss (3-pin)

- 24-pin ATX-Netz-Header

- 4-pin anschluss für 12V-ATX-Netzteil

- Anschluss für Audio auf der Gehäusevorderseite

- 2 x USB 2.0-Anschlüsse (Unterstützung 4 zusätzlicher
USB 2.0-Anschlüsse)

- 1 x USB 3.0-Anschlüsse (Unterstützung 2 zusätzlicher
USB 3.0-Anschlüsse)
BIOS - 64Mb AMIs Legal BIOS UEFI mit GUI-Unterstützung

- Unterstützung für “Plug and Play”

- ACPI 1.1-Weckfunktionen

- JumperFree-Modus

- SMBIOS 2.3.1

- DRAM, VDDP, VDDR, SB Stromspannung Multianpassung

Support-CD - Treiber, Dienstprogramme, Antivirussoftware
(Probeversion), CyberLink MediaEspresso 6.5-Testversion,
Google Chrome Browser und Toolbar

16

ASRock FM2A75M-DGS R2.0 Motherboard

Hardware Monitor - CPU-Temperatursensor

- Motherboardtemperaturerkennung

- Drehzahlmessung für CPU/Gehäuse/Stromlüfter

- Geräuscharmer CPU/Gehäuselüfter

- Mehrstuge Geschwindigkeitsteuerung für CPU-/

Gehäuselüfter

- GEHÄUSE OFFEN-Erkennung

- Spannungsüberwachung: +12V, +5V, +3.3V, Vcore

®

Betriebssysteme - Unterstützt Microsoft

VistaTM / Vista

Windows® 8 / 8 64-Bit / 7 / 7 64-Bit /

TM

64-Bit

Zertizierungen - FCC, CE, WHQL

- Gemäß Ökodesign-Richtlinie (ErP/EuP) (Stromversorgung
gemäß Ökodesign-Richtlinie (ErP/EuP) erforderlich)

* Für die ausführliche Produktinformation, besuchen Sie bitte unsere Website:
http://www.asrock.com

ASRock FM2A75M-DGS R2.0 Motherboard

Deutsch

17

Français

Spécications

Format - Facteur de forme Micro ATX

- Condensateur résistant pour alimentation de processeur
CPU - Support des unités centrales Socket FM2 100W

- Supporte la technologie Cool ‘n’ QuietTM d’AMD

- UMI-Link GEN2

Chipsets - AMD A75 FCH (Hudson-D3)
Mémoire - Compatible avec la Technologie de Mémoire à Canal

Double

- 2 x slots DIMM DDR3

- Supporter DDR3 1866/1600/1333/1066 non-ECC, sans
amortissement mémoire

- Capacité maxi de mémoire système: 32GB

- Prend en charge le prol de mémoire extrême Intel® (XMP)

1.3/1.2

- Prend en charge le prol de mémoire AMD (AMP)

Slot d’extension - 1 x slot PCI Express 2.0 x16 (PCIE1 à mode x16)

- 1 x slot PCI Express 2.0 x1

- 1 x slot PCI

- Support de AMD Dual Graphics
VGA sur carte - Graphiques à l’AMD Radeon HD 7000

- DirectX 11, nuanceur de pixels 5.0

- mémoire partagée max 2GB

- Output de VGA Duel: supporter DVI et D-Sub ports par

les controleurs de display independents

- Prend en charge le Dual-link DVI avec une résolution

maximale jusqu’à 2560x1600 @ 75Hz

- Prend en charge le D-Sub avec une résolution maximale
jusqu’à 1920x1600 @ 60Hz

- Supporte AMD Steady Video

de traitement post-vidéo pour réduction automatique des
tremblements dans les clips vidéo en ligne/maison

- Prise en charge de la fonction HDCP avec ports DVI

- Supporter 1080p Blu-ray(BD)/ lecteur de HD-DVD avec
ports DVI

Audio - 5,1 CH HD Audio (Realtek ALC662 Audio Codec)
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supporte du Wake-On-LAN

- Prise en charge de la détection de câble LAN

TM

2.0: Nouvelle fonctionnalité

18

ASRock FM2A75M-DGS R2.0 Motherboard
