Chapter 1 Introduction

Thank you for purchasing ASRock 775i48 motherboard, a reliable motherboard pro­duced under ASRock’s consistently stringent quality control. It delivers excellent
performance with robust design conforming to ASRock’s commitment to quality and
endurance.
In this manual, chapter 1 and 2 contain introduction of the motherboard and step-by­step guide to the hardware installation. Chapter 3 and 4 contain the configuration
guide to BIOS setup and information of the Support CD.

Because the motherboard specifications and the BIOS software might be
updated, the content of this manual will be subject to change without
notice. In case any modifications of this manual occur, the updated
version will be available on ASRock website without further notice. You
may find the latest memory and CPU support lists on ASRock website as
well. ASRock website

1.1 Package Contents

ASRock 775i48 Motherboard

(ATX Form Factor: 12.0-in x 7.2-in, 30.5 cm x 18.3 cm)
ASRock 775i48 Quick Installation Guide
ASRock 775i48 Support CD (including LGA 775 CPU Installation Live Demo)
One 80-conductor Ultra ATA 66/100 IDE Ribbon Cable
One Ribbon Cable for a 3.5-in Floppy Drive
One Serial ATA (SATA) Data Cable
One Serial ATA (SATA) HDD Power Cable (Optional)
One ASRock I/O PlusTM Shield

http://www.asrock.com

5

1.2 Specifications

Platform: ATX Form Factor: 12.0-in x 7.2-in, 30.5 cm x 18.3 cm

CPU: 775-Pin Socket

supporting Intel® Pentium® 4 / Celeron® processor (in 775-land
LGA package)

Chipsets: North Bridge:

Intel® 848P chipset, FSB @ 800 / 533 MHz,
Max. 1066 MHz at overclocking mode (see CAUTION 1),
supports Hyper-Threading Technology (see CAUTION 2)

South Bridge:

Intel® ICH5, supports SATA 1.5Gb/s

Memory: 2 DDR DIMM slots: DDR1 and DDR2

supports PC3200 (DDR400) / PC2700 (DDR333) /
PC2100 (DDR266), Max. 2GB (see CAUTION 3)

IDE: IDE1: ATA 100 / Ultra DMA Mode 5

IDE2: ATA 100 / Ultra DMA Mode 5
Supports up to 4 IDE devices

Serial ATA: Supports up to 2 SATA devices at 1.5Gb/s data transfer rate

(Not Support “RAID” and “Hot Plug” functions)

Floppy Port: Supports up to 2 floppy disk drives

Audio: 5.1 channels AC’97 Audio

PCI LAN: Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN

Hardware Monitor: CPU temperature sensing,

Chassis temperature sensing,
CPU overheat shutdown to protect CPU life
(ASRock U-COP)(see CAUTION 4),
CPU fan tachometer,
Chassis fan tachometer,
Voltage monitoring: +12V, +5V, +3.3V, Vcore

PCI slots: 5 PCI slots with PCI Specification 2.3

AGP slot: 1 AGP slot, supports 1.5V, 8X/4X AGP card (see CAUTION 5)

USB 2.0: 8 USB 2.0 ports:

includes 6 default USB 2.0 ports on the rear panel,
plus one header to support 2 additional USB 2.0 ports
(see CAUTION 6)

ASRock I/O PlusTM: 1 PS/2 mouse port,

1 PS/2 keyboard port,
1 serial port: COM1,
1 parallel port: ECP/EPP support,
6 default USB 2.0 ports,
1 RJ 45 port,
Audio Jack: Line In / Line Out / Microphone

6

BIOS: AMI legal BIOS,

Supports “Plug and Play”,
ACPI 1.1 compliance wake up events,
Supports jumperfree,
SMBIOS 2.3.1 support,
CPU frequency stepless control
(only for advanced users’ reference, see CAUTION 7)

OS: Microsoft® Windows® 98 SE / ME / 2000 / XP compliant

CAUTION!

1. To support FSB1066, please use DDR400 DIMMs (Double Data Rate 400
MHz). Before installing FSB1066 CPU, please make sure that you have
adjusted the jumpers correctly. The default setting of FSB1 is shorting
pin1 and pin2. However, if you want to support FSB1066 CPU, please
adjust your FSB1 jumper setting, and short pin2 and pin3 (see page 16).

2. About the setting of “Hyper Threading Technology”, please check page 24.

3. Please check the table below for the memory support frequency and its
corresponding CPU FSB frequency.

CPU FSB Frequency Memory Support Frequency

800 DDR266, DDR320
533 DDR266, DDR333

* When you use an FSB800-CPU on this motherboard, it will run at

DDR320 if you adopt a DDR333 memory module.

4. While CPU overheat is detected, the system will automatically shutdown.
Before you resume the system, please check if the CPU fan on the
motherboard functions properly and unplug the power cord, then plug it
back again. To improve heat dissipation, remember to spray thermal
grease between the CPU a nd the heatsink when you in stall the PC syste m.

5. Do NOT use a 3.3V AGP card on the AGP slot of this motherboard!
It may cause permanent damage!

6. Power Management for USB 2.0 works fine under Microsoft
SP1 / 2000 SP4. It may not work properly under Microsoft
ME.

7. Although this motherboard offers stepless control, it is not recommended
to perform over-clocking. Frequencies other than the recommended CPU
bus frequencies may cause the instability of the system or damage the
CPU.

*, DDR400

®

Windows® XP

®

Windows® 98/

7

1.3 Motherboard Layout

1

2

1

PS2_USB_PWR1

PS2

Mouse

PARALLEL PORT

ATX12V1

Ps2

Keyboard

COM1

18.3cm (7.2in)

4

3

5

18

CMOS

Battery

FSB800

DDR400

Intel
ICH5

1

USB67

1

IR1

17

CLRCMOS0

DDR1(64/72 bit, 184-pinmodule)

1

SPEAKER1

16

DDR2(64/72 bit, 184-pinmodule)

SATA

IDE2

IDE1

SATA1

CHA_FAN1

PLEDPWRBTN

1

HDLED RESET

PANEL1

15

SATA2

6

30.5cm (12.0in)

7

8

9

10

11

12
13
14

29

28

27

26

25

24

23

USB2.0
T: US B2
B:USB3

USB2.0
T: US B0
B:USB1

MicIn

USB2.0
T: US B4
B:USB5

Bottom:

LineOut

Center:

1

22

Top:
RJ-45

1

USB4_5

Top:

LineIn

2Mb
BIOS

Super

CPU_FAN1

I/O

ATXPWR1

1

FSB1

Intel

848P

Chipset

AGP 8X

1.5V_AGP1

PCI 1

775i48

GAME1

5.1 CH

19

PCI 2

PCI 3

PCI 4

PCI 5

USB2.0

FLOPPY1

LAN
PHY

Audio

CODEC

JR1

JL1

AUDIO1

AUX1

CD1

20

21

1 PS2_USB_PWR1 Jumper 16 External Speaker Connector (SPEAKER1)
2 A TX 12V Connector (A TX12V1) 17 Infrared Module Connector (IR1)
3 775-Pin CPU Socket 18 Floppy Connector (FLOPPY1)
4 North Bridge Controller 19 Game Connector (GAME1)
5 184-pin DDR DIMM Slots (DDR DIMM1- 2) 20 Internal Audio Connector: CD1 (Black)
6 Secondary IDE Connector (IDE2, Black) 21 Internal Audio Connector: AUX1 (White)
7 Primary IDE Connector (IDE1, Blue) 22 Front Panel Audio Connector (AUDIO1)
8 AGP Slot (1.5V_AGP1) 23 JR1 / JL1 Jumpers
9 South Bridge Controller 24 PCI Slots (PCI1- 5)
10 Primary Serial A T A Conne ctor (SA T A1 ) 25 Flash Memory
11 Secondary Serial A T A Connector (SAT A2) 26 FSB Select Jumper (FSB1)
12 Clear CMOS Jumper (CLRCMOS0) 27 CPU Fan Connector (CPU_FAN1)
13 Chassis Fan Connector (CHA_FAN1) 28 Shared USB 2.0 Header (USB4_5, Blue)
14 USB 2.0 Header (USB67, Black) 29 A TX Power Connector (ATXPWR1)
15 System Panel Connector (P ANEL1)

8

1.4 ASRock I/O Plus

TM

1

11

1 Parallel Port 7 USB 2.0 Ports (USB01)
2 RJ-45 Port 8 USB 2.0 Ports (USB23)
3 Line In (Light Blue) 9 Serial Port: COM1
4 Line Out (Lime) 10 PS/2 Keyboard Port (Purple)
5 Microphone (Pink) 11 PS/2 Mouse Port (Green)
6 Shared USB 2.0 Ports (USB45)

2

8910

7

6

3

4

5

9

Chapter 2 Installation

775i48 is an ATX form factor (12.0" x 7.2", 30.5 x 18.3 cm) motherboard. Before you
install the motherboard, study the configuration of your chassis to
ensure that the motherboard fits into it.

Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so may cause physical injuries to you and
damages to motherboard components.

2.1 Screw Holes

Place screws into the holes indicated by circles to secure the motherboard to the
chassis.

Do not over-tighten the screws! Doing so may damage the motherboard.

2.2 Pre-installation Precautions

Take note of the following precautions before you install motherboard components
or change any motherboard settings.

1. Unplug the power cord from the wall socket before touching any component.

2. T o avoid damaging the motherboard components due to static electricity, NEVER
place your motherboard directly on the carpet or the like. Also remember to use
a grounded wrist strap or touch a safety grounded object before you handle
components.

3. Hold components by the edges and do not touch the ICs.

4. Whenever you uninstall any component, place it on a grounded antistatic pad or
in the bag that comes with the component.

10

Before you install or remove any component, ensure that the power is
switched off or the power cord is detached from the power supply.
Failure to do so may cause severe damage to the motherboard, peripherals,
and/or components.

2.3 775-LAND CPU Installation

For the installation of Intel 775-LAND CPU,
please follow the steps below.

Before you insert the 775-LAND CPU into the socket, please check if
the CPU surface is unclean or if there is any bent pin on the socket.
Do not force to insert the CPU into the socket if above situation is
found. Otherwise, the CPU will be seriously damaged.

Step 1. Open the socket:

Step 1-1. Disengaging the lever by depressing

down and out on the hook to clear
retention tab.

Step 1-2. Rotate the load lever to fully open po-

sition at approximately 135 degrees.

Step 1-3. Rotate the load plate to fully open po-

sition at approximately 100 degrees.

775-Pin Socket Overview

Step 2. Insert the 775-LAND CPU:

Step 2-1. Hold the CPU by the edges where are

marked with black lines.

Step 2-2. Orient the CPU with IHS (Integrated

Heat Sink) up. Locate Pin1 and the two
orientation key notches.

Pin1

orientation

key notch

775-LAND CPU

orientation

key notch

Pin1

alignment key

black line

775-Pin Socket

black line

alignment key

11
