Dear customer,
Thank you for choosing this quality product from ASKO. We
hope it will meet all of your expectations and fullfill your needs
for many years to come. The Scandinavian design is a combination of clean lines, everyday functionality and high quality.
These are the hallmarks for all of our products and this is why
they are so highly appreciated all over the world.
To get the most out of your new ASKO product, we recommend
that you read the installation and operating instructions before
using the machine.
ASKO D5122
Contents
Before doing your first wash 3
Important safety instructions 4
Child safety 5
Parts of the dishwasher* 6
Technical data 6
Baskets* 7
Control panel 8
Detergent Dispenser 8
Basic Course 9
Load the baskets correctly 9
Dishwashing detergent 9
Switch on the main switch 10
Select program 10
Select Option 10
Press start 11
Standby mode 11
Fragile dishes 16
Cleaning 17
Coarse filter 17
Fine filter 17
Drain pump 18
Spray arms 19
Door 19
Rinse aid 20
Fault indications 21
Troubleshooting 22
The dishes are not clean 22
Stains or a film on the china 22
The china has a whitish-blue sticky film 23
Stains on stainless steel or silver 23
Stains which remain after dishwashing 23
Rattling sound during dishwashing 23
The machine will not start 23
Water remains in the machine 24
Bad odour in the machine 24
Performance information 25
Programs 12
Heavy wash
Normal wash
Quick wash
Rinse & Hold
Program Description 13
Options 14
Temperature selection
Drying
Eco-dishwashing 15
2
Service and guarantee 26
Quick Guide 28
Mini Program Guide
Customer Care Center
1-800-898-1879
www.askousa.com
3
Customer Care Center
1-800-898-1879
www.askousa.com
Before doing your first wash
Read through the directions for use
Read through the directions for use before
starting to use your machine, especially the
Safety, Child Safety, and Basic Course sections.
Take care with certain materials
Read the Fragile Dishes section before
washing china with unglazed decoration
or other household goods made of plastic,
wood, or crystal requiring careful treatment.
Check the door fitting
Check that the door of the dishwasher fits
properly: open the door a little and let it go.
Does it stay exactly where you released
it? If not, you should check the installation
instructions or consult the installer.
Check the water’s hardness
Call your local water utility company to
check the water hardness in your area. This
is important when dispensing dishwasher
detergent and rinse aid.
Note!
Do you need this Use & Care Guide in Spanish? Visit www.askousa.com/customercare
to download.
¿ Necesita esta Instrucciones de uso y cuidado en español? Entre en
www.askousa.com/customercare y descárguesela.
Important safety instructions
This manual does not cover all possible
conditions and situations that may occur.
Common sense and caution should always
be used when installing, operating, and
maintaining any appliance.
• Read all instructions before using the
dishwasher.
• Dishwashers must be electrically grounded.
Read the Installation Instructions for
details.
• Use the dishwasher only for its intended
purpose.
• Do not run the dishwasher while you are
out of the home.
• Use only automatic dishwasher detergents
and rinse agents.
• To reduce the risk of injury, keep detergents
and rinse aids out of the reach of children.
• Do not load sharp items near the door; you
could damage the door seal.
• Place sharp knives in the silverware basket
with the sharp ends down to avoid the risk
of cut-type injuries.
• Do not wash plastic items unless they
are marked “dishwasher safe” or the
equivalent. For items not marked, check
the manufacturer’s recommendations.
Items not dishwasher safe could become
deformed or melt and create a potential fire
hazard.
• Do not touch the heating element during or
imediately after use.
• Do not operate the dishwasher unless all
enclosure panels are properly in place (i.e.,
guard plate, access panel, toe kick, etc.)
• Do not tamper with controls by removing or
changing.
• Do not abuse, sit on, or stand on the
dishwasher door or baskets .
• To reduce the risk of injury, do not allow
children to play in or on a dishwasher.
• Under certain conditions, hydrogen gas
may be produced in a hot water system
that has not been used for two weeks or
more. HYDROGEN GAS IS EXPLOSIVE.
If the hot water system has not been
used for two weeks, before using the
dishwasher turn on all hot water faucets
and let the water flow from each for several
minutes. This will release any accumulated
hydrogen gas. As the gas is flammable, do
not smoke or use an open flame during this
time.
4
• When removing an old dishwasher from
service or discarding it, remove the door
to the washing compartment.
• Do not store or use combustible materials,
gasoline, or other flammable vapors and
liquids in the vicinity of this or any other
appliance.
• Disconnect the electrical power to the
dishwasher before servicing.
• Repairs should be done by a qualified
technician.
Customer Care Center
1-800-898-1879
www.askousa.com
5
Customer Care Center
1-800-898-1879
www.askousa.com
Child safety
Child safety tips
Dishwasher detergents and rinse aids are
corrosive, so always keep them out of reach
of children.
• Should a child swallow dishwasher detergent or rinse aid, give plenty to drink immediately, i.e., one or two glasses of milk or
water. Do not try to induce vomiting. Seek
medical advice immediately: Call the National Capital Poison Center at 1-800-222-1222
• Always close the door and start the dishwasher as soon as you put in the detergent.
• Always keep small children away from
the machine when it is open. There may
be some detergent residue left inside the
machine.
• If dishwasher detergent gets in someone’s
eyes, rinse them with plenty of water for at
least 15 minutes.
• Do not allow children to use or play in or
on the dishwasher.
• Load all long and sharp items in the knife/
utensil basket. If this is not possible, load
sharp objects with the pointed end facing
the back of the dishwasher. Sharp items
loaded in the silverware basket should be
loaded with pointed ends down.
• Engage the child safety lock.
Engaging the Child Safety Lock
This model has a child safety lock on the left of
the door handle. To activate the lock, press in
the door handle and use a screwdriver to turn
the screw slot to a vertical position. Reset it by
turning the slot to its horizontal position.
To open the door when the safety lock is
engaged, press the white plastic tab located
to the left of the door handle toward the left
and hold it as you lift the door handle. (See
illustration at below.)
Parts of the dishwasher*
1. Upper basket
2. Spray arms
3. Cutlery basket
4. Lower basket
5. Dishwasher detergent compartment
6. Main power switch
7. Rinse Aid Compartment
8. Filter
9. Serial tag and rating plate
*Details may differ depending on the model
and market!
1
2
3
3
4
5
9
6
7
8
Technical data
Height 34-3/8” - 36-1/2” 874-927mm
Width 24” (610)mm
Depth 24” (610mm)
Weight 105.8 lbs (48 kg)
Water pressure
0.03 - 1.0 MPa
0.3-10 Bar
Connection Single phase, 120 V, 60 Hz, 10 A
Max output 1300 W
4.2 - 140 psi
Customer Care Center
6
1-800-898-1879
www.askousa.com
7
Customer Care Center
1-800-898-1879
www.askousa.com
Baskets*
Upper basket
1
Lower basket
1. Wine glass shelf
2
2. Cup rack
3. Knife stop
4. Cutlery basket with door and folding
handle
3
Cutlery basket
*Details may differ depending on the
model and market!
4
Control panel
3
1
2
PROGRAMPROGRAM
6
1. Program selector
2. Heavy wash
3. Normal wash
4. Quick wash
4
8
5
STARTSTART
STOPSTOP
7
5. Rinse & Hold
6. Normal temperature
7. Normal dry
8. Start/stop
Detergent Dispenser
13
2
4
5
1. Compartment for main wash dishwasher
detergent
2. Compartment for pre-wash detergent
3. Refill indicator rinse aid
4. Rinse aid cover
5. Detergent compartment cover
Customer Care Center
8
1-800-898-1879
www.askousa.com
9
Customer Care Center
1-800-898-1879
www.askousa.com
Basic Course
Below are step-by-step instructions to help you
achieve the best possible dishwashing results.
Load the baskets correctly!
Thanks to Self Cleaning System, you
do not need to rinse the dishes under
running water. Simply remove large food
particles and debris. Convenient and environmentally-friendly!
Place glasses, cups, bowls, side plates, and
saucers in the upper basket. Wine glasses
should be hung from or leaned against the
wine glass shelf and knives placed in the knife
stand if present.
Note!
Ensure that all soiled surfaces face inwards
or downwards!
The cutlery basket has a folding flap in the
middle for small items or narrow shafts,
such as electric whisks.
Place long cutlery and carving knives in the
special knife box (if present) or in the upper
basket.
Check that the spray arms are able to
move freely.
See the section entitled Fragile Dishes if you
want to wash objects that may be fragile.
Place dinner plates, side plates, serving
dishes, saucepans, and cutlery (in the cutlery basket) in the lower basket. The removable plate insert, which comes with certain
models, can be easily removed to provide
room for large plates, saucepans, and pots, or
placed in three alternative positions.
Stand the cutlery with handles downward
and as spread out as possible. Ensure that
spoons are not resting inside each other.
Do not put cutlery made of different materials - such as silver and stainless steel - in
the same compartment (risk of stains).
Dishwashing detergent
We recommend that you use
only unscented, granular automatic dishwashing detergent. Using the wrong detergent could cause flooding and/or damage
your dishwasher. Do not use detergent that
has been wet and is clumped. Also, check
the expiration date on the container.
The amount of detergent needed can vary
due to differences in water hardness. To
determine the water hardness in your area,
contact your local water utility or area water
softening company. The harder the water,
the more detergent you may need. Refer to
the chart below for the recommended detergent amounts based on water hardness.
Remember, you should adjust the amount
of detergent you use by small amounts
until you find the correct amount.
Twelve grains and higher is extremely hard
water and detergent alone may not be
enough. You may need to use a water softener to maximize the performance of your
dishwasher. Also, in areas with hard water
(9+) you may need to wash at lower temperatures to prevent hard water deposits from
forming in tank and wash system.
In hard water areas, both the dishes and
the machine can develop a white or gray
film after a while. This can be removed by
replacing the prewash detergent with two
tablespoons of citric acid. If the water is very
hard, use a rinse aid that contains citric acid.
Different brands of dishwasher detergent
have different amounts of phosphorous for
softening water. If you have hard water and
use a detergent with less than 8.7% phosphorous content, you may need to use more
detergent or use a detergent with more than
8.7% phosphorous content.
NOTE:
We recommend that you do not add prewash detergent for the Quick wash programs.
NOTE:
If you use a dishwashing detergent with
a rinse aid additive, you should not fill the
rinse aid dispenser. This could cause a film
on your dishes.
Dishwasher tablets
Halve the tablet if it is difficult to close the
dispenser cover. There is a risk that the
dishwasher detergent will not break down
properly to give the correct dosage if the
cover is tight and cannot be opened correctly.
3-in-1/ Multi-purpose detergent
Note!
Read the directions for use for such products
carefully. If anything is unclear, contact the
detergent manufacturer.
Switch on the main switch
Select program
For select program see Part Programs.
Select Option
If you wish to use additional options,
continue Part Options. Otherwise you
can now start the machine, see point 6.
10
Recommended detergent amounts based on water hardness
Water hardness Detergent amounts
Soft
(0-3 grains per gallon)
Medium
(4-8 grains per gallon)
hard
(9+ grains*)
Prewash 1 teaspoon
Main wash 1 to 1-1/2 tablespoons
Prewash 1 teaspoon
Main wash 1 to 2 tablespoons
Prewash 1 teaspoon
Main wash 2 to 3 tablespoons
* 12 grains and higher is extremely hard water.
Customer Care Center
1-800-898-1879
www.askousa.com
11
Customer Care Center
1-800-898-1879
www.askousa.com
Press start
The dishwasher will now start. It manages the entire wash automatically. Ensure
that the door is properly closed or the machine will not start.
The display shows ‘Program started’. If the
door is open or not properly closed, ‘Close
door’ appears in the display.
Changing program
If you wish to change the program after
having started the machine, press the Start/
Stop button for three seconds. Then select a
new program and press the Start/Stop button again.
Do you want to load more dishes?
Carefully open the door; the machine will
stops automatically, put in the dishes, close
the door and the dishwasher will continue
from where it left off.
Standby mode
7
Once the machine has finished, it is drawing
a very small amount of power. Disconnect
the power by switch off at the main switch.
Turn off the water tap if the machine is not to
be used for an extended period, e.g. during
holidays.
The indicators around the Start/Stop
field gradually light up as the programme
progresses.
When the programme finishes, all the indicators are lit, turning off 2 hours later.
If the machine is switched off at the
main switch
(or in the event of a power cut) before the
washing program has been completed, the
interrupted program will continue when the
power comes back on.
NB!
If the power is switched off, or if the door
is open during drying, the program is interrupted.
Programs
Select a program by pressing the program
selector one or more times until the required
program symbol lights up. See the Program
guide below.
Heavy wash
The Heavy Wash program should be used
for heavily soiled dishes, e.g. saucepans,
pots and gratin dishes. If there is still space
in the machine after loading such items, you
can add plates etc.
Normal wash
Used for washing normally soiled dishes
such as plates, serving dishes, cups and
glasses, etc.
Note!
For washing normally soiled mixed loads
use the Normal wash program
normal temperature
drying
.
and normal
with
To save more water and energy use
economy temperature and economy drying.
Quick wash
Select Quick Wash if the dishes are very
lightly soiled. This program is used for very
lightly soiled glass and china, e.g. coffee
cups.
Rinse & Hold
For rinsing the dishes while waiting for the
machine to be filled.
12
Customer Care Center
1-800-898-1879
www.askousa.com
13
Customer Care Center
1-800-898-1879
www.askousa.com
Program Description
Programview
Programs Heavy
Normal
Quick Rinse &
Hold
Program
info
Options
Prewashes
with SCS*
Mainwash *** 160°F 150°F 140°F --
Number of
rinses
For heavily
soiled loads,
such as pots,
pans, casseroles, etc.
2 prewashes 2 prewashes -- --
3, last
rinse 160°F
For normally soiled
loads such
as plates,
glasses,
bowls, and
lightly soiled
pans.
2, last
rinse 160°F
For lightly
soiled loads
that are
washed
immediately after
use. This
program
can also
be used
for delicate
items.
2, last
rinse 140°F
Consumption values
1. Wash time
hot water /
min. **
Energy approx. kWh
2.Wash time
cold water /
min.**
Energy approx.
kWh
Water consumption
(gallon)
205 150 60 4
1.1 0.9 0.7 0.01
240 190 80 4
1.8 1.7 1.1 0.01
5.0 5.5 2.5 0.8
To rinse
dishes that
you plan to
wash later
that day.
--
1 rinse
SCS = Self Cleaning System.
** All quoted times are approximate. Cycle time fluctuations may occur due
to water temperature, water pressure, variations in voltage etc.
1. Hot water connection approx. 50°C (120°F).
2. Cold water connection approx. 10°C (50°F).
*** The listed temperatures are set as the default from the factory. You can
alter the program temperature by choosing the temperature options in the
chart on page 14.
Options
Select options
To select an option, press one of the option
buttons.
Temperature selection **
With the temperature option button you can select the wash temperature
yourself. You can vary the temperatures as
follows:
Normal Economy
Heavy: 160°F (70°C) 130°F (55°C)
Normal: 150°F (65°C) 130°F (55°C)
Quick: 140°F (60°C) 85°F (30°C)
The field next to the button lights up if you
have selected the normal temperature. The
selection remains until a change is made.
Drying *
If you require a better drying result,
you can press the Normal drying button.
The field next to the button lights up. Should
you require a programme with Economy drying – press again and the light will go out.
Cannot be used in the Rinse & Hold pro-
*
gramme.
14
Customer Care Center
1-800-898-1879
www.askousa.com
15
Customer Care Center
1-800-898-1879
www.askousa.com
Eco-dishwashing
Only wash full loads
Waiting to run the wash until the machine is
full saves energy.
Wash at a lower temperature
If the dishes are only lightly soiled you can
run a Quick wash program and reduce the
temperature to 86°F (30°C).
Select a program with Economy dry
To save energy, select Economy dry. You will
get a better drying result if you leave the door
slightly open after the end of the program.
Do not rinse before dishwashing
Thanks to the dishwasher’s Self Cleaning
System you do not need to rinse the dishes
under running water before loading them
into the machine.
Choose environmentally-friendly
dishwasher detergent
Read environmental declarations on the
package!
Reduce Energy Use
You can use a cold water fill which can save
additional energy. The dishwasher heats
water which is used for the main wash and
final rinse.
Fragile dishes
A number of household goods are not suitable for machine washing. This can be due
to a variety of reasons. Certain materials
cannot withstand intense heat; others can
be damaged by the dishwasher detergent.
Fragile decoration
China with decoration on top of the glaze
(the goods have a rough feel) should not be
machine washed.
Crystal/ glass
Place the goods so that they do not knock
together during the wash. Use the lowest
possible wash temperature and the shortest
possible program. Do not heat dry! Antique
and very fragile items should not be machine washed.
Glass which is machine washed at high
temperatures can in time develop a grey film
which cannot be removed. Wash fine glass
at the lowest temperature and with a low
dosage of dishwasher detergent.
Plastic
Certain types of plastic cannot withstand
the high temperature generated in machine
dishwashing.
Protect plastic goods
Select a program with a low temperature.
Silver
Silver and stainless steel items should not
come into contact with each other as the
silver can discolor.
Cutlery with glued handles
Certain types of adhesive cannot withstand
machine washing. In such cases the handles can come loose.
Wood
Wooden items should only be machine
washed if they are labeled as dishwasher
safe.
Aluminum
Aluminum can be dulled by machine washing. However, good quality aluminum saucepans can be machine washed, although a
reduction in luster should be expected.
16
Customer Care Center
1-800-898-1879
www.askousa.com
Cleaning
The dishwasher’s inner container is made of
stainless steel and is kept clean through normal use. However, if you have calciferous
(hard) water, lime deposits can form in the
dishwasher. In this case, run a normal wash
program with two tablespoons of citric acid
in the dishwasher detergent compartment.
Coarse filter
The coarse filter collects large food particles which cannot get past the outflow
pump. Empty the coarse filter if necessary.
1. Lift the coarse filter by the handle.
2. Empty the coarse filter.
Remember to replace the filter!
Spray arm
Coarse filter
Fine filter
Tubular
strainer
Fine filter
Debris that collects on the fine filter is
automatically rinsed away during each
programme. However, the fine filter and its
pipe section should be cleaned once or
twice a year.
1. Turn the handle once anticlockwise.
Customer Care Center
1-800-898-1879
www.askousa.com
1x
17
2. Lift the coarse filter and the pipe section
straight up by the handle.
3. Remove the fine filter.
4. Clean the fine filter and the pipe section
with a washing-up brush.
Replace in reverse order. Make sure the
edges seal properly when replacing the fine
filter.
Drain pump
The pump can be accessed from inside the
machine.
VARNING!
Always unplug the dishwasher or turn the
power to the unit off at the circuit breaker
before cleaning the pump.
1.Loosen the coarse filter by turning it anti
clockwise once and remove the fine filter.
2. Remove the pump access plug to the left
in the bottom drain.
3. By inserting a finger into the hole you can
rotate the pump blade and remove any
blockages.
4. Replace the Pump access plug and
filters.
5. Insert the electrical plug back into the
outlet.
18
Customer Care Center
1-800-898-1879
www.askousa.com
19
Customer Care Center
1-800-898-1879
www.askousa.com
If you still cannot start the machine and a
humming noise can be heard, then the overfilling protection has been activated.
• Shutoff the water
• Remove the plug from the wall socket
• Call Service
CAUTION!
Do not forget to replace the small pump access plug.
Spray arms
The holes and bearings can occasionally
become clogged.
1. Pull the lower spray arm straight up to
release it.
2. Scrape away the debris with a needle or
similar. The spray arms also have holes on
the underside.
To release the upper spray arm, the upper
basket must be removed.
3. Pull out the basket and turn the basket
stop outwards on both rails (see picture).
The basket can now be removed.
4. Remove the upper spray arm in the same
way as the lower arm and clean it.
Door
When cleaning the edge around the door,
use only a slightly damp cloth, possibly with
a little detergent. Do not use a spray bottle
or similar around the door catch. This is to
ensure that water does not penetrate into
the door catch and come into contact with
the electrical components.
CAUTION!
Do not use a spray bottle or similar around
the door catch.
Tip!
In order to prevent bad odours in the dishwasher, clean the strips and corners with a
dish brush and low-lather detergent.
Rinse aid
Adding rinse aid
In some cases, drying can be made more efficient by using rinse aid.
To fill with rinse aid:
1. Turn and lift up the cover of the rinse aid
compartment to the right of the dispenser.
This is where you top up and set the amount
of rinse aid to be dispensed in each wash.
2. Carefully pour in rinse aid up to the dos-
age setting knob.
Alter dosage if required. Do not forget to
close the cover.
Machines with refill indicator
There is a refill indicator in the middle of the
dispenser (see illustration). If the refill indicator is totally black, there is sufficient rinse
aid. However, if the indicator has a more
transparent appearance, you need to fill up
with rinse aid (see above).
Select dosage
The dispenser is usually set at 1= soft water.
However, depending on the water hardness,
you may need to change the dosage.
Open the rinse aid cover. Here you will find
the dispenser’s adjustment dial. Settings 1-6:
the harder the water, the higher the dosage.
When the water hardness exceeds 3 grains,
you should use rinse aid with citric acid (acid
rinse aid).
Too much rinse aid can lead to the buildup of foam. If your water is particularly soft,
you can dilute the rinse aid (1 part rinse aid,
1 part water).
Too much rinse aid can cause streaks on
the dishes, while too little can result in water
stains.
20
Refill indicator
Open
Closed
Cover for rinse aid
Open by turning and lifting the cover!
Customer Care Center
1-800-898-1879
www.askousa.com
21
Customer Care Center
1-800-898-1879
www.askousa.com
Fault indications
Indication Type of fault Action
L2 flashing Too much water in the dishwasher Phone service
L1
L6
L2
PROGRAM
PROGRAM
S1
S1
S3S3 S4S4
L3
L5
L4
L11
L10
L12
STARTSTART
STOPSTOP
S2S2
L7
L8
L9
Troubleshooting
Problems Possible causes Action
The dishes are not clean
Stains or a film on the
china
• The spray arms are not
rotating.
• Old dishwasher detergent.
NB! Detergent is a perishable.
• Incorrect dosage of detergent.
• Insufficiently powerful dishwashing program.
• Incorrect loading of the
dishwasher.
• Glasses and cups have
tipped over during the wash.
• Incorrectly set rinse aid
dispenser.
• Phosphate-free detergent in
combination with hard water.
• Lift off the arms and clean.
• Avoid large packs.
• Dispense according to the
level of water hardness.
• Change to a more intensive program.
• Do not cover china with
large bowls or similar.
• Load the china securely.
• See the chapter on rinse
aid.
• Change detergent.
• Too high a temperature
and/or too much detergent
can cause etching on (crystal) glass. Unfortunately this
cannot be remedied, only
prevented!
• Wash (crystal) glass at a
low temperature and dispense dishwasher detergent
with care. Contact the dishwasher detergent manufacturer.
• Use liquid detergents on
fine china.
22
Customer Care Center
1-800-898-1879
www.askousa.com
23
Customer Care Center
1-800-898-1879
www.askousa.com
Problems Possible causes Action
The china has a whitishblue sticky film
Stains on stainless steel
or silver
Stains which remain after
dishwashing
• Too high dosage of rinse
aid.
• Certain food remnants
such as mustard, mayonnaise, lemon, vinager, salt
and dressings can cause
stains on stainless steel if
allowed to remain for any
length of time. All stainless steel can mark silver if
allowed to come into contact during the dishwashing
process. Aluminium can
also cause stains on dishes.
• Lipstick and tea can be difficult to remove.
• Reduce dosage. See the
chapter on rinse aid. If the
water is very soft, you could
try diluting the rinse aid (1
part rinse aid, 1 part water).
• Rinse off food residue of
this type if you do not intend
to start the dishwasher immediately.
• Seperate your cutlery into
various compartments in
the basket. Make sure silver
and stainless steel are not
together.
• Change to a detergent
with bleach.
Rattling sound during dishwashing
The machine will not start
To restart the machine,
press Start/stop for 3 seconds. Now select a new
programme and press
Start/stop.
• The dishes are not properly loaded or the spray arms
are not rotating.
• You have forgotten to
switch on the main switch.
• The door is not properly
closed.
• A fuse has blown.
• The plug is not plugged in.
• The water tap is off.
• Overfilling/leakage
• A droning sound (drainage pump) can be heard
from the machine, this does
not stop when the power is
switched off using the main
power switch.
• Check that the china is
loaded securely. Spin the
spray arms to make sure
that they rotate.
• Check
• Check
• Check
• Check
• Check
1. Close the water tap.
2. Pull out the plug.
3. Call a service engineer
Problems
Possible causes Action
Water remains in the
machine
Bad odour in the machine
• Obstruction in the drain
hose.
• Kinks in the drain hose.
• The filters are clogged.
• Objects in the drain pump.
• Dirt along the strips and in
corners
• Disconnect the drain hose
where it is connected to the
sink’s water trap. Check that
no debris has become stuck.
Is the cone-shaped part of
the pipe cut so that the diameter is at least 16 mm?
• Check that the hose is free
from kinks or sharp bends.
• Clean out the coarse filter,
the fine filter and the filter.
• Clean out the drain pump.
See chapter on cleaning
• Clean with a dish brush
and low-lather detergent.
24
Customer Care Center
1-800-898-1879
www.askousa.com
25
Customer Care Center
1-800-898-1879
www.askousa.com
Performance information
Energy standard
USA: ANSI/AHAM DW-1-2005
Technical data
Height: 34-3/8” - 36-1/2” 874-927mm
Width: 24” (610mm)
Depth: 24” (610mm)
Weight: 105.8 lbs (48 kg)*
Water pressure
0.03 - 1.0 MPa
0.3-10(Bar)
Electrical connection: See serial tag/rating plate
Rated power: See serial tag/rating plate
*The weight can vary due to varying specifications.
4.2 - 140 psi
Loading of performance test
Upper basket with 10 place settings AHAM DW-1
Lower basket with 10 place settings AHAM DW-1
Service and guarantee
Asko Appliances Inc. will not pay
for:
1. Service calls to:
• Correct the installation of the appliance.
• Repair damage due to shipment, delivery, installation, misuse or abuse.
• Instruct how to use the appliance.
• Replace house fuses or correct house
wiring.
• Correct house plumbing, including drainage problems related to improper installation.
• Clean or service air device in drain line.
2. Repair and/or replacement parts for failure of product if appliance is used for other
than home/residential use.
3. Damage resulting from accident, fire,
floods, acts of God, alteration, misuse,
abuse, improper installation, or installation
not in accordance with local electrical or
It is important to register your product warranty by logging onto
www.askousa.com/customercare/registration and filling out all required fields within 90
days from the date of purchase. After doing so, you will be e-mailed a certificate that will
extend the original warranty for one additional year. If you do not have access to the in
ternet, complete the warranty card included with the product and mail it to the address on
the warranty card within 90 days of the date of purchase. Cosmetic damage must be repor
ted to your dealer within five days from the date of purchase. After unpacking the washer,
thoroughly check the unit for cosmetic damage.
plumbing codes.
4. Any shipping costs for parts during the
limited warranty period.
5. Replacement parts or repair labor costs
for units operated outside the continental
United States.
6. Pickup and delivery. ASKO washers are
designed to be repaired in the home.
In no event shall Asko Appliances Inc. be responsible for any
incidental or consequential damages.
Some states will not allow the exclusion
or limitation of incidental or consequential
damages, so this exclusion or limitation
may not apply to you. This warranty gives
you specific legal rights and you may also
have other rights which vary from state to
state.
26
For residential installations only Asko Appliances Inc. will pay for:
Length of warranty Two-Year Full From
date of purchase.
Third year full
Complete your product warranty registration online at www.askousa.com/customercare/registration within 90 days from
the date of purchase to extend the original
warranty one additional year. If you do not
have access to the internet, complete the
warranty card included with the product
and mail it to the address on the warranty
card within 90 days of the date of purchase.
Customer Care Center
1-800-898-1879
www.askousa.com
ASKO replacement parts and/or repair
labor to correct defect in materials or workmanship. Service must be provided by an
authorized ASKO service agent.
ASKO replacement parts and/or repair
labor to correct defect in materials or workmanship. Service must be performed by
an authorized ASKO service agent.
27
Customer Care Center
1-800-898-1879
www.askousa.com
For residential installations only Asko Appliances Inc. will pay for:
Lifetime ASKO replacement parts (labor cost not
included) for the stainless steel tank if it
exhibits a manufacturing defect such as
cracking or rusting through. Service must
be provided by an authorized ASKO service
agent.
For non-residential installations One-year
Full Warranty from date of purchase.
ASKO replacement parts and/or repair labor
to correct defect in materials or workmanship. Service must be provided by an authorized ASKO service agent.
For warranty service, contact our Customer Care Center at the number listed below.
Before calling for service or contacting Asko Appliances Inc. regarding a warranty issue,
make a note of the model, type name, and serial number.
Write to us at:
Asko Appliances Inc.
P. O. Box 851805
Richardson, Texas 75085-1805
www.askousa.com
Or contact our Customer Care Center at
1-800-898-1879
www.askousa.com
Quick Guide
1. Load the baskets correctly!
Thanks to the Self Cleaning System you don’t need to rinse the dishes, simply scrape large
food particles and debris.
2. Dispensing dishwasher detergent
The detergent compartment has a small compartment for pre-wash and one for main wash.
3. Ensure that the spray arms can rotate freely
4. Turn on the main power switch
5. Close the door
6. Select the program and press start
For normally soiled dishes, use the Normal Wash program with Normal temperature
Normal drying
.
To save more water and energy use Economy temperature and Economy dry.
Mini Program Guide
and
Programview
Programs Heavy
Program
info
Options
Prewashes
with SCS*
Mainwash *** 160°F 150°F 140°F --
Number of
rinses
For heavily
soiled loads,
such as pots,
pans, casseroles, etc.
2 prewashes 2 prewashes -- --
3, last
rinse 160°F
Normal
For normally soiled
loads such
as plates,
glasses,
bowls, and
lightly soiled
pans.
2, last
rinse 160°F
Quick Rinse &
For lightly
soiled loads
that are
washed
immediately after
use. This
program
can also
be used
for delicate
items.
2, last
rinse 140°F
Hold
To rinse
dishes that
you plan to
wash later
that day.
--
1 rinse
Item No.: 80 820 07 Rev. 01 We reserve the right to make changes.
Printed on environmentally-friendly paper that meets the demands of Friends of the Earth and the
Swedish Society for Nature Conservation.
Customer Care Center
28
1-800-898-1879
www.askousa.com
Loading...
