ASKO CC4727S, CC4927S User Manual

Instructions for use

Built-in unit

CC4727S / 4000

CC4927S / 4000

CC41227S / 4000

EN Manual EN 3 - EN 13

Pictograms used:

Important information

Tip

CONTENT

Built-in unit

Description 4

Introduction 4

Use

Controls 5

Maintenance

Cleaning 7

Removing the grease filters 8

Replacing the carbon filter 8

Changing the light bulbs 8

Installation

General 9

Electrical connection 10

Mounting the built-in unit 11

Technical specification

12

Appendix

Disposal of appliance and packaging 13

EN 3

YOUR BUILT-IN UNIT

Description

A Switch fan on/off

B Reduce extractor capacity

C Increase extractor capacity

D Engage intensive mode

E Clean air function/filter indication

F Timer function

G Switch lighting on/off

H Dim lighting

I Display

Introduction

This user manual gives you a quick overview of all the possibilities

offered by the appliance. You will find information on safety measures

and maintaining the appliance.

I

EN 4

Please retain this user manual and the installation guide.

They may be of use to future users of the appliance.

Declaration of conformity

We declare that our products meet the applicable European Directives,

Decisions and Regulations and the requirements listed in the standards

referenced.

Read the separate safety instructions before
using the device!

USE

Controls

I

Switching the fan on and off

• Switch the fan on with the on/off button (A) and select the desired

extractor setting with buttons ‘B’ and ‘C’.

The ‘I’ display indicates which setting has been selected.

• Use button ‘D’ to switch on the intensive setting.

“HI” appears in the ‘I’ display.

After 6 minutes the intensive mode is automatically reduced to the

setting previously selected.

Switching the lighting on and off

• Use the ‘G’ button to switch the lighting on and off.

Dimming the lighting

• Dim the lighting with button ‘H’.

The strength of the lighting varies between maximum and minimum,

and vice-versa.

Clean Air function:

With the Clean Air function you can refresh the air in the kitchen

over maximum 24 hours.

• Make sure the built-in unit has been switched off.

• Press on the Clean Air button ‘E’.

Every hour, the extractor hood will switch on for 10 minutes

automatically, at the lowest extraction setting. The display reads

“24” and an indicator flashes at the bottom right.

EN 5
