ASKO CC4525S User Manual
Instructions for use
Cooker hood
CC4525S / 4000
EN Manual EN 3 - EN 13
Pictograms used :
Important information
Tip
CONTENT
Your canopy hood
Description 4
Introduction 4
Use
Controls 5
Maintenance
Cleaning 7
Removing the grease filters 8
Replacing the carbon filter 8
Changing the light bulbs 8
Installation
General 9
Electrical connection 10
Mounting the canopy hood 11
Technical specifications
12
Appendice
Disposal of appliance and packaging 13
EN 3
YOUR CANOPY HOOD
Description
L Switch lighting on/off
T1 Switch on/off + fan speed 1
T2 Switch on fan speed 2/switch on carbon filter indicator
T3 Switch on fan speed 3/reset grease filter indicator
T4 Switch on intensive setting
S1 Filter indicator
Introduction
This user manual gives you a quick overview of all the possibilities
offered by the appliance. You will find information on safety measures
and maintaining the appliance.
EN 4
Please retain this user manual and the installation guide.
They may be of use to future users of the appliance.
Declaration of conformity
We declare that our products meet the applicable European Directives,
Decisions and Regulations and the requirements listed in the standards
referenced.
Read the separate safety instructions before
using the device!
USE
Controls
Switching the fan on and off
• Use the On/Off button (T1) to switch on the fan and select the
extractor setting desired with the ‘T2’, ‘T3’ or ‘T4’ buttons.
The LED indication on the buttons shows which setting has been
selected.
• Use the ‘T4’ button to switch on the intensive setting.
• The intensive setting switches off automatically after 6 minutes.
After these 6 minutes the speed is reduced to the
setting previously selected.
Switch the lighting on and off
• Use the ‘L’ button to switch the lighting on and off.
Grease filter indication
• The ‘S1’ indicator light switches on when the grease filter needs to
be cleaned.
• The indicator light switches on after the extractor hood has been in
use for 100 hours. This is to indicate that the grease filter needs to
be cleaned.
• Press and hold the ‘T3” button for 3 seconds to reset the indication.
The ‘S1’ indicator light flashes 3 times to confirm that the
setting has been reset.
EN 5
