Page 1
Model type:
LS630EX50-60
Commercial code:
F023506
Page 2
General notes
Technical Documentation guidelines
----------------------------------------------------------------------------------------------------------------------------------
-------------------------------------------------------------
You can find herewith some generic information to simplify cunsulting of technical documentation:
1. Models of same range share the same exploded views, which report the richest set of spare parts:generally, a model does not
necessarly have a related spare part for each particular shown on exploded views.
2. Some spare parts can not be represented directly on the exploded views (instruction booklets, specific kit, etc...). You can find
those codes in the spare parts list with the same reference of particular where spares are installed or with references 099, 999.
Instruction booklets, once managed, appear with 000 reference.
3. On the higher right site of each exploded view there is a serial number which indicates the beginning of the production of
certain range:some models might have more than an exploded view for a given category, each distinguished by a different serial
no.and linked to another spare parts list, In this case, serial no. is required to supply the right spare part code. Exploded view to be
considered is the one with a more recent serial no. but previous than the one of the model that needs assistance.
4.Exploded views might require further updates even after publishing. Addition of new spares will go on following the already
existing numeration references. Revision number of an exploded view is shown into last four digits of serial number into upper
right hand corner.
5.The spare parts list associated to an exploded view shows related codes of spares managed for a certain model; for each spare
part other informations are available:
REF: reference no of spare into a table; SUBSTITUTE: list of spare(s) which can replace a code but that keeps same functional
characteristics
INDUSTRIAL CODE: list of variables of a model (shown into model label) where such spare is used; NOTICE: code of
information(s) to refer to complete technical intervention, track for changes or to find correct spare part code.
6. Some notices, into a same section are generic therefore cannot be directly linked to a spare part. In order to assist a model in
the best way as possible, it is helpful to pay attention to all notices and constantly verify documentation updates
7.Technical documentation cover shows model name and its commercial codes
mod.LS630EX50-60 page 2
Page 3
2170110 Exploded views
mod.LS630EX50-60 page 3
Page 4
2170110 Spare parts list
Ref. Code From To S/N Substitute Description Notice Industrial
000 C00082489 instruction book
001 C00092823
(482000039882)
001 C00092864 edge cover left white
002 C00075715
(482000076415)
003 C00033591
(482000073467)
004 C00057509 worktop white 27
005 C00057504 hook - top cover retention
006 C00078613
(482000038952)
007 C00141317
(482000022949)
008 C00092824
(482000039883)
008 C00092863 edge cover right white
1 x C00092833
(482000039892)
1 x C00085024
(482000077035)
1 x C00092833
(482000039892)
left side panel lh white27
rear cover
rear support - top
catch plate (cabinet)
top and side door seal (1638mm)
(dw)
right side panel white27
009 C00054811
(482000041070)
010 C00040994
(482000026419)
010 C00094191
(482000078041)
011 C00056396
(482000039727)
011 C00108980
(482000079446)
017 C00056438
(482000026962)
019 C00054825
(482000074873)
4 x C00109840
(482000021962)
1 x C00109840
(482000021962)
1 x C00058164
(482000075065)
1 x C00297566
(482000032121)
1 x C00275698
(482000031295)
side support - front rh
upper basket wheel n1045107
upper basket roller evo3 n1045107
upper basket 8/12 'ariston incasso' n1045107
upper basket noclik/clak markii n1045107
flap upper basket 'ariston'
lower basket
mod.LS630EX50-60 page 4
Page 5
019 C00091694
(482000027874)
settore reclinabile cesto inferiore
45cm
022 C00054810
(482000039710)
025 C00076659
(482000038869)
026 C00079023
(482000072285)
027 C00054830
(488000054830)
028 C00054838
(482000074875)
029 C00061989
(482000039756)
029 C00092554
(482000038466)
030 C00057507 plinth panel swell white
031 C00054833
(482000074874)
032 C00056010
(482000026943)
1 x C00091600
(482000077654)
1 x C00143383
(482000029761)
1 x C00094297
(482000022776)
1 x C00054874
(482000041065)
1 x C00118842
(482000080822)
rear support - middle
radio interference suppressor
cutlery basket
drain hose fastener
base moulding cover plate rhs
white27
tray kit n1045062
tray on bottom of tub 60cm
top for front support
foot support x
033 C00104611
(482000028393)
034 C00065836
(482000038457)
034 C00092555
(482000027942)
035 C00054837
(482000038637)
036 C00040288
(482000038794)
036 C00066632
(482000075488)
1 x C00143584
(482000082015)
1 x C00142905
(482000081903)
1 x C00037135
(482000026331)
adjustable foot - all plastic
adjustable front foot + screw nut n1045062
foot 155mm N1045072
base moulding cover plate lhs
white27
lock nut m4
fixing nut
mod.LS630EX50-60 page 5
Page 6
2170110 Spare parts list
Ref. Code From To S/N Substitute Description Notice Industrial
040 C00054812
(482000040472)
side support - front lh
041 C00066629
(482000027246)
043 C00054836
(482000026905)
044 C00079013
(482000027460)
046 C00104638
(482000028395)
047 C00056347
(482000022648)
048 C00040996
(482000022616)
049 C00077001
(482000076513)
051 C00091599
(482000038470)
1 x C00119016
(482000080852)
post piece
kit runner support - upper n1045107
door spring adjuster
basket roller axis n1045107
lower basket wheel
runner stop - upper basket n1045107
basket runner - upper n1045107
front support lower 60cm
mod.LS630EX50-60 page 6
Page 7
2170210 Exploded views
mod.LS630EX50-60 page 7
Page 8
2170210 Spare parts list
Ref. Code From To S/N Substitute Description Notice Industrial
001 C00056001
(482000026942)
upper wash arm feed pipe
002 C00054925
(482000022645)
003 C00054862
(482000038898)
004 C00075686
(482000076409)
005 C00054871
(482000039717)
006 C00056342
(482000026955)
007 C00054926
(482000038916)
008 C00075746
(482000022687)
009 C00041092
(482000026430)
012 C00076658
(482000039788)
1 x C00144315
(482000022981)
1 x C00285074
(482000023233)
1 x C00094134
(482000038917)
1 x C00110526
(482000028476)
1 x C00110527
(482000028477)
1 x C00083706
(482000039822)
upper was basket guide casing
ring-nut fasten.external hose top
water supply distribution assembly n1045084
steel pin fixing upper wash arm
upper wash arm curved set
radio interference suppressor
sprayar
jet gasket
n1045084
feed pipe
upper wash arm feed pipe n1045084
supply cable
015 C00054927
(482000038899)
017 C00063788
(482000038795)
018 C00063790
(482000075256)
019 C00063792
(482000027131)
020 C00063791
(482000027130)
021 C00041086
(482000022617)
022 C00054854
(482000026907)
1 x C00144335
(482000082153)
1 x C00097871
(482000078490)
ring-nut for air-flow body
lock nut m8 inox
washer d.8 mm inox
seal o-ring
temperature sensor
thermostat safety 78ønc (dw)
sump fixing ferrule
mod.LS630EX50-60 page 8
Page 9
023 C00054828
(482000026903)
gasket - sump fixing ring
024 C00076660
(482000039789)
025 C00089827
(482000038814)
026 C00054917
(482000022644)
027 C00054870
(482000038970)
028 C00054869
(482000022642)
029 C00081162
(482000027494)
030 C00037205
(482000038862)
031 C00058843
(482000027055)
032 C00063239
(482000070127)
032 C00066677
(482000075491)
1 x C00091601
(482000077655)
1 x C00090536
(482000027823)
1 x C00084421
(482000027620)
1 x C00143107
(482000029720)
1 x C00041086
(482000022617)
lower rear support hot or cold
'lvs2000'
drain pump 220v 50/60hz
seal 'o'ring (23,81x2,62)
set sump
drain hose
container - overflow unit
microswitch
float - overflow unit
thermostat safety 78ønc
set thermostat 50-58øc
033 C00066470
(482000040486)
034 C00076622
(482000076475)
035 C00044543
(482000039675)
036 C00054841
(482000039714)
037 C00041088
(482000026429)
038 C00073917
(482000027267)
1 x C00041484
(482000026456)
1 x C00063834
(482000027133)
tube 620mm - pressure switch
wheelpressure switch hose
softener + ev
pressure switch 1 level
salt cap
clamp for pump cover
mod.LS630EX50-60 page 9
Page 10
2170210 Spare parts list
Ref. Code From To S/N Substitute Description Notice Industrial
039 C00079016
(482000027461)
pipe rubber sump-pump
041 C00005819
(482000022028)
042 C00041090
(482000038892)
043 C00103610
(482000028363)
044 C00043737
(482000074143)
045 C00033618
(482000026254)
046 C00054868
(482000074878)
048 C00092578
(482000027944)
050 C00042134
(482000039664)
051 C00018315
(482000070785)
053 C00054985
(482000074890)
1 x C00144235
(482000029868)
1 x C00009415
(482000070317)
1 x C00005781
(482000025917)
salt funnel
retaining ring - softener
seal - softener/wash chamber
switch - salt light (eledro)
electrovalve (water softener)
tube - softener/sump l.(480mm)
electrovalve 1e 1u
mains inlet hose h/c-10bar 90ø
sealing washer+filter - mains inlet
hose
solenoid valve half-load n4514k00
053 C00087279
(482000077233)
054 C00077140
(482000027411)
056 C00105360
(482000079120)
057 C00076628
(482000027383)
058 C00079385
(482000076652)
059 C00080518
(482000027467)
060 C00075695
(482000076410)
octagonal seal 'o'ring
wash motor/pump assy 220v-75w
1/2-held
capacitor 5mf
tub spring
overflow hose
container connection overflow
connection gasket overflow
mod.LS630EX50-60 page 10
Page 11
061 C00075726
(482000027359)
bodytop overflow
062 C00075057
(482000039782)
063 C00066643
(482000027247)
064 C00066642
(482000039777)
065 C00075108
(482000022677)
067 C00076233
(482000027370)
068 C00103689
(482000039229)
069 C00054866
(482000026909)
074 C00046319
(482000038811)
075 C00054872
(482000074879)
076 C00074714
(482000076340)
1 x C00075111
(482000027318)
1 x C00075111
(482000027318)
1 x C00075111
(482000027318)
1 x C00084600
(482000027626)
1 x C00066598
(482000038389)
cap corner for support washing
blade hub
support - lower wash arm bush
ring-nut for fastening bottom
spacer ring
lower wash arm inox 60cm
pump junction pipe
jet gasket
water inlet air break
heating element 2000w/230v
support bracket - heating element
terminal protection - heating
element
078 C00054863
(482000039375)
079 C00054851
(482000038923)
080 C00081164
(482000039374)
081 C00061929
(482000027109)
085 C00075879
(482000076424)
086 C00054979
(482000074887)
1 x C00142344
(482000029630)
1 x C00145075
(482000029987)
1 x C00142344
(482000029630)
central filter
outlet filter stainless lvs2000
filter cylindrical
outer fine rotating polyester filter
clamp
pump cover
mod.LS630EX50-60 page 11
Page 12
2170210 Spare parts list
Ref. Code From To S/N Substitute Description Notice Industrial
087 C00054850
(482000038972)
1 x C00093752
(482000027980)
ring-nut for fastening bottom
spacer ring
n1045063
087 C00093752
(482000027980)
088 C00054915
(482000074881)
099 C00040562
(482000038799)
099 C00075678
(482000022033)
099 C00076515
(482000039787)
102 C00098769
(482000022804)
1 x C00084479
(482000022034)
1 x C00074713
(482000076339)
suction assembly moulded
seal 'o'ring (32,99x2,62) n1045063
hose clamp
clamp for electrovalve evo3
heat trasmiter paste
upper wash arm seal
mod.LS630EX50-60 page 12
Page 13
2170350 Exploded views
mod.LS630EX50-60 page 13
Page 14
2170350 Spare parts list
Ref. Code From To S/N Substitute Description Notice Industrial
002 C00051754
(482000039704)
1 x C00051755
(482000022636)
plug
003 C00075468
(482000038919)
004 C00078609
(482000027442)
006 C00057514
(482000075017)
007 C00041790
(482000090693)
008 C00042126
(482000074018)
009 C00057635
(482000075032)
010 C00074513
(482000038812)
011 C00082493 wiring harness - copreci td 010069
012 C00082491 white 27 dashboard n1045052
012 C00083080 dashboard ls630ex
1 x C00143574
(482000029794)
1 x C00090761
(482000027843)
detergent+rinseaid
electrodispenser
locking assembly
plinth cover lid handle
push button switch nc
pushbutton switch nc+no+change
over
red pilot lamp 230v ariston
timer - copreci td 010069
013 C00034319
(482000070798)
018 C00064667
(482000075326)
019 C00057510
(482000026997)
020 C00057501 white door shell bowed l=588 n1045052
020 C00083322 white door shell bowed l=582
021 C00065127
(482000039770)
022 C00054818
(482000038453)
1 x C00104581
(482000028391)
1 x C00054815
(482000026899)
1 x C00096996
(482000028184)
knob plate
timer knob white
push-button knob on/off white
hinge item, right
hinge assembly
mod.LS630EX50-60 page 14
Page 15
023 C00058776
(482000022656)
washer d = 6 mm
024 C00048504
(482000022630)
025 C00065128
(482000039771)
026 C00075689
(482000027355)
028 C00075693
(482000027356)
029 C00082394 front panel soundproofing
030 C00066649
(482000040635)
031 C00075690
(482000039783)
032 C00054931
(482000038939)
032 C00083324
(482000039819)
033 C00054827
(482000026902)
1 x C00054817
(482000026900)
1 x C00091543
(482000077646)
1 x C00091958
(482000039373)
1 x C00092501
(482000039032)
inner door panel stainless l=588 n1045052
inner door panel stainless l=582
hinge pin
hinge item, left
door spring
gaffel x door spring
door spacer assy
cabinet gasket
side strip for door l=435
036 C00057637
(482000075033)
099 C00040005
(482000039656)
099 C00065862
(482000027216)
099 C00076108
(482000038796)
099 C00077438
(482000038797)
099 C00082166
(482000076799)
1 x C00033026
(482000073442)
1 x C00012687
(482000072661)
1 x C00012687
(482000072661)
push-button knob wh
grease amblig ta 1 gr.
screw stainless 3,5x8 door liner
dishwash
screw canoe klip
self-tapping galvanized screw sw
3.5x14tm
rivet
mod.LS630EX50-60 page 15
Page 16
Notices
N1045072: Introduction of fixed rear foot H=31mm on free-standing models.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
From serial no. 40218.0001, free-standing dishwashers affected by this modification have been equipped with new fixed rear feet
(H=31mm).
The new foot replaces the adjustable one (H=155mm) Service code 092555; on the EVO3 range with TurboDry the new foot
replaces the adjustable foot (H=95mm) Service code 094605.
The Spare Part Warehouse will continue to manage only 155mm and 95mm adjustable feet as they are interchangeable with the
fixed 31mm foot.
The three feet are shown in illustration N1045072FIG1.
mod.LS630EX50-60 page 16
Page 17
n1045017: New pressure switches and pipes.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Beginning with serial no. 00116.0001, instead of the pressure switch part no. 054841 and the pressure switch pipe part no.
054829, the part no. 063834 already employed on 45 cm appliances and part no. 066470 are used respectively on 60 cm Washing
machines manufactured at the None factory.
With the only exception of models LSI61 and LSI61A, fitted with a hide-away electro-mechanical timer, where the pressure
switch part no. 056476 must absolutely be fitted (mod. Elbi 120mm).
Should the float come into operation during functioning on pre-modification appliances, then both the pressure switch and the
pressure switch pipe should be replaced, using the new parts.
In order to avoid any errors in the use of the part no. 054841, it was eliminated from documentation, whereas a kit is handled with
part no. 063834, that is composed of both the pressure switch and the pipe.
n1045018: New meliorative heating elements.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
New meliorative heating elements have been created for 60 and 45 cm dishwashers, with the following spare part numbers:
066598, with green surface colour, for 60 cm models.
066602, for 45 cm models.
The new heating elements replace part numbers 046319 and 061014(Rohs 144251).
n1045033: Kit of adjustable feet for dishwashers LVS2000, 140 mm high.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
In order to cope with the increasingly frequent demand from furniture manufacturers, new 14 cm height-adjustable feet are being
used on dishwashers LVS2000.
Moreover, a kit of adjustable feet has been made available which allows the worktop to be adjusted to a height of up to nine
centimetres.
Spare part number of the Kit:
066655 KIT OF ADJUSTABLE FEET H.140
Spare part numbers for each individual foot:
066653 ADJUSTABLE FOOT WITH NUT H.140 MM
074435 ADJUSTABLE FOOT H=140 MM.
n1045034: New top condenser.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
As of the last week in July 2000, the new "Wind drying system" was inserted on some appliances from the new MarckII Range.
This new system foresees the elimination of the lateral air-flow body and the insertion of a new system with top condenser.
The spare part numbers eliminated are as follows:
054927(Rohs 144335) - RING NUT FOR AIR-FLOW BODY
mod.LS630EX50-60 page 17
Page 18
054928 - AIR-FLOW BODY
103689 - NOZZLE GASKET
057874 - TOP SOUNDPROOFING LAYER
Whereas the new spare part numbers are:
076238 - WIND DRYNG SYSTEM CONDENSER
076239 - CONDENSER RING NUT
076240 - TOP CONDENSER GASKET
076241 - TOP CONDENSER PIPE
The new part numbers are not interchangeable with the old ones, as they are completely different. See technical drawing attached
to notice NT002500.
n1045036: New power supply cables and terminal boards on down-market dishwashers.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
On the down-market dishwashers, the power supply cable has been modified and the new component parts are not
interchangeable with the old ones.
Therefore, in the event of intervention by the Technical Assistance service, the power supply cables, the front and back cross
pieces and the old wiring cannot be replaced using the new ones.
n1045052: Width reduction from 588 to 582 mm(3)
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
The introduction of new, narrower external doors has involved the introduction of new panel codes with narrower guide slots and
new, narrower inner doors.
The new replacements for the external doors, inner doors and panels are 582mm wide, whereas the premodification items are
588mm wide.
In not being interchangeable, the new system must be managed with the new and the old with the old.
Given below is a list of the models (with commercial code in brackets) with modification introduction serial numbers and
relevant replacements:
LSE615SP (25723)
Serial no. 10607.0001
mod.LS630EX50-60 page 18
Page 19
Panel: old 082572 - new 083097
Inner door: old 078589 - new 087854
External door: old 057501 - new 83322
LSE620TANEU (24948)
Serial no. 10607.0001
Panel: old 082610 - new 083096
Inner door: old 078589 - new 087854
External door: old 077317 - new 087834
LSE610EU (23438)
Serial no. 10706.0001
Panel: old 082430 - new 083095
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
L73NDUO (24559)
Serial no. 10704.0001
Panel: old 079111 - new 083094
Inner door: old 078589 - new 087854
External door: old 077317 - new 087834
LSE620FR (23445)
Serial no. 10608.0001
Panel: old 079082 - new 083092
Inner door: old 078589 - new 087854
External door: old 057501 - new 083322
LSE610FR (25443)
Serial no. 10607.0001
Panel: old 082019 - new 083093
Inner door: old 078589 - new 087854
External door: old 057501 - new 083322
L73WDUO (23450)
Serial no. 10616.0001
Panel: old 079062 - new 083087
Panel: old 078589 - new 087854
External door: old 057501 - new 083322
LSE730TEU (23525)
Serial no. 10604.0001
Panel: old 082432 - new 083090
Inner door: old 078589 - new 087854
External door: old 057501 - new 083322
LSE730FR (23534)
Serial no. 10606.0001
Panel: old 078581 - new 083086
Inner door: old 078589 - new 087854
External door: old 057501 - new 83322
LSE732FR (23535)
Serial no. 10625.0001
Panel: old 079107 - new 083088
Inner door: old 078589 - new 087854
External door: old 057501 - new 083322
mod.LS630EX50-60 page 19
Page 20
LSE620AEU (23440)
Serial no. 10703.0001
Panel: old 082040 - new 083083
Inner door: old 078589 - new 087854
External door: old 057501 - new 083322
LSE620TEU (23447)
Serial no. 10607.0001
Panel: old 082548 - new 083084
Inner door: old 078589 - new 087854
External door: old 057501 - new 083322
L62WE (23449)
Serial no. 10607.0001
Panel: old 079384 - new 083081
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
LSE620TK (23495)
Serial no. 10607.0001
Panel: old 082020 - new 083082
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
LS2040UK (16884)
Serial no. 10915.0001
Panel: old 058590 - new 083065
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
LS2020A (16812)
Serial no. 10604.0001
Panel: old 058670 - new 083068
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
LS2020UK (16880)
Serial no. 10607.0001
Panel: old 058670 - new 083068
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
LS2020AAUS/1 (18672)
Serial no. 10604.0001
Panel: old 058670 - new 083068
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
AF250 (25087)
Serial no. 10616.0001
Panel: old 080711 - new 083070
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
LS600TK (23493)
Serial no. 10711.0001
mod.LS630EX50-60 page 20
Page 21
Panel: old 080733 - new 083074
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
L52IT (23444)
Serial no. 10629.0001
Panel: old 080407 - new 083075
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
LS62AG (23516)
Serial no. 10611.0001
Panel: old 082577 - new 083076
Inner door: old 054931 - new 083324
External door: old 057501-new 083322
LS620TK (23494)
Serial no. 10606.0001
Panel: old 080730 - new 083077
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
LS63050-60EX (23506)
Serial no. 10723.0001
Panel: old 082491 - new 083080
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
LS630115-60EX (23504)
Serial no. 10604.0001
Panel: old 082491 - new 083080
Inner door: old 054931 - new 083324
External door: old 057501 - new 083322
LSE830TEU (23529)
Serial no. 10627.0001
Panel: old 082563 - new 083060
Inner door: old 082553 - new 086782
External door: old 057501 - new 083322
L83WDUO (23532)
Serial no. 10630.0001
Panel: old 079257 - new 083059
Inner door: old 082553 - new 086782
External door: old 057501 - new 083322
See figure NT 006900.
n1045062: Introduction of a new DW EVO structure
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
From serial number 30101.0001, all dishwasher models affected by this modification have been produced with EVO structure.
mod.LS630EX50-60 page 21
Page 22
These models have been equipped with NEW TRAYS AND NEW FEET (see N1045062TAB1).
The structure for SCANDINAVIA models is indicated below:
COMMERCIAL CODE 28490-26043-23520-28088:
PREMODIFICATION:
Tray: 083625 (for commercial code 28490) 078809 (for commercial codes 26043-23520-28088);
Tray rear feet: 078396-078397-078385;
Tray front feet: 073972;
Front feet supports: 065836(Rohs 143584);
Feet supplied with plinth accessories assembly: 034261;
EVO STRUCTURE:
Tray: 092558 (for commercial code 28490) 092554 (for commercial code 26043-23520-28088);
Tray rear feet: 092820-092821-092822;
Tray front feet: 092555;
Front feet supports: 065836;
Feet supplied with plinth accessories assembly: 034261.
COMMERCIAL CODE 25117:
PREMODIFICATION:
Tray: 061991;
Tray feet: 073972;
Feet supplied with plinth accessories assembly: 034261;
EVO STRUCTURE:
Tray: 092554;
Tray feet: 092555;
Feet supplied with plinth accessories assembly: 034261.
mod.LS630EX50-60 page 22
Page 23
Photo N1045062FIG1 illustrates the bottom of the dishwasher with EVO structure.
Regulation assembly DX/SX Sat codes 078397 and 078396 will be managed up to stock end, after that they will be replaced by
new Sat codes 092821 and092820. The same is for rear foot Sat code 078385 which will be replaced by Sat code 092822.
mod.LS630EX50-60 page 23
Page 24
mod.LS630EX50-60 page 24
Page 25
n1045063: Introduction of coupling+ring nut Sat code 093752
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
From serial number 30224.0001, all dishwashers affected by this modification have been equipped with the new coupling+ring
nut assembly Sat code 093752, in place of coupling Sat code 079016, ring nut Sat code 054850 and gasket Sat code 054915.
mod.LS630EX50-60 page 25
Page 26
Ring nut Sat code 054850 will continue to be available from the spare parts warehouse while stocks last, and coupling Sat code
079016 will continue to be stocked because it is still used for the tank-volute connection.
Picture N1045063 illustrates the premodification structure in FIG1 and the new structure in FIG2.
n1045107: Modification of upper rack.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
From serial no. 50314.0001, the following modifications have been made to dishwasher model LS630EX50-60 (commercial code
23506):
mod.LS630EX50-60 page 26
Page 27
INTRODUCED ITEMS:
108980 upper rack
094191 upper rack wheel
094189 upper rack wheel pin
094112 upper rack plate/runner assembly
094116 upper rack guide
094117 rack guide rear stop
094118 rack guide front stop
ELIMINATED PARTS:
056396 upper rack
040994 upper rack wheel
104638 upper rack wheel pin
054836 runner support kit
077001 upper rack guide
040996 rack guide stop
Illustration N1045097FIG1 shows the new and premodification items.
mod.LS630EX50-60 page 27
Page 28
n4514k00: SOLENOID VALVE HALF LOAD
----------------------------------------------------------------------------------------------------------------------------------
-------------------------------------------------------------
The half load valve is supplied with the wash pump please order the wash pump on the parts list supplied.
mod.LS630EX50-60 page 28
Page 29
Electric schemes and links
Cod. lg027700
mod.LS630EX50-60 page 29
Page 30
Legend
Legend: lg027700
A.. Timer contact LPA Door open
AQS Aquastop electrovalve LPR Prewash LED
B.. Timer contact LRI Rinse LED
C Condensor LS Mains LED -Pilot lampe On/Off
C.. Timer contact LSB Polisher LED
CL Slow cam LSC Cycle ranning lamp
CM Wash pump motor connector LSE Acquastop LED
CN Connector LSS Salt LED
CV Fast cam LV Fan off lamp
D-ED Dispenser - Electric dosing device M Terminal box
D.. Timer contact MB Polisher dip-switch
DB Brightener dispenser ME Acquastop dip-switch
DD Display - Detergent dispenser ML Wash motor
E1 Cold water electrovalve MM Handle dip-switch
E2 Regeneration electrovalve MP Door dip-switch
E3 Hot water electrovalve MR Delay-timer motor - Terminal board
ECO Saving switch MT Timer motor
ED Detergent/Brightener dispenser MTR Fast forward timer motor
EV1 Cold water electrovalve MM- Handle dip-switch MV Motor fan
EV1/2 Half-load electrovalve P Pressure switch
EV2 Regeneration electrovalve P.. Pressure switch contact
EV3 Hot water electrovalve P1 Stage 1 pressure
EVC Hot water electrovalve P2 Stage 2 pressure switch
EVF Cold water electrovalve PAP High pressure switch
EVR Regeneration water electrovalve PO Overflow pressure switch
F Anti-interference filter ML- Wash motor PS Drain pump
FA Radio interferences PULS Push-button panel
I1 On/Off switch - Plus cycle switch -IEC cycle R Heating element
I1/2 Switch half-load R.D. Delay rotary selector
I2 Fast switch -IEC cycle switch (standard) - RA Heating element drying
I2H 2-hour delay switch ROT D Delay rotary selector
I3 Saving switch- Switch for cycle with no pre- ROT. Rotary selector
I4 Switch for cycle fresh dirty S Motor overload cutout
mod.LS630EX50-60 page 30
Page 31
I4H 4-hour delay switch SC Selector cycli
I5-ICR Fast cycle switch SS Salt detector
I6 Soak cycle switch ST START
I6H 6-hour delay switch T.. Delay-tymer contact
IAQS Aquastop switch T1 Power supply earth cable -Thermostat 45?C
ID Switch display T2 Lid earth -Thermostat 55?C
IE Saving switch T3 Timer earth -Thermostat 65?C
IEXD Exstra dray switch T36 36?C N.O. Thermostat
IG Main switch T4 Heating element earth
IMV Off motor fan switch T46 46?C N.O. Thermostat
IP High temperature switch T5 Drain pump earth
IS Cut-off switch T57 57?C N.O. Thermostat
ISB Polisher led switch T6 Wash motor earth
ISS Salt LED switch T8 External lid earth
ITR Heating element switch TE Relay switch
L Mains LED THP Thermoprotector
L1 Cycle 1 lamp TM Timer
L1/2 Lamp cjcle half-load TS Safety thermostat
L2 Cycle 2 lamp TS 40 Thermostat 40 ?C
L3 Cycle 3 lamp TS 50 Thermostat 50 ?C
L4 Cycle 4 lamp TS 62 Thermostat 62 ?C
L5 Cycle 5 lamp TS1 Min. temperature thermostat
L6 Cycle 6 lamp TS2 Max. temperature thermostat
LA Drying LED TT Terminal box support earth
LAQ Aquastop on lamp Tcp nner-door earthing connection
LC Cycle ranning lamp Tfa Radio interference
LD Delay activated lamp Tml Pump wash motor earthing connection
LE Saving cycle Tpg Large door earthing connection
LH2 2-hour delay lamp Tpi Inspection door earthing connection
LH4 4-hour delay lamp Tpr Pressure switch
LH6 6-hour delay lamp Tps Discharge pump earthing connection
LL Wash LED Tr Heating element
LP High temperature LED Tte Delay-timer earthing connection
mod.LS630EX50-60 page 31
Page 32
Electric schemes and links
Cod. se083200
mod.LS630EX50-60 page 32
Page 33
Legend
Legend: se083200
A.. Timer contact LPA Door open
AQS Aquastop electrovalve LPR Prewash LED
B.. Timer contact LRI Rinse LED
C Condensor LS Mains LED -Pilot lampe On/Off
C.. Timer contact LSB Polisher LED
CL Slow cam LSC Cycle ranning lamp
CM Wash pump motor connector LSE Acquastop LED
CN Connector LSS Salt LED
CV Fast cam LV Fan off lamp
D-ED Dispenser - Electric dosing device M Terminal box
D.. Timer contact MB Polisher dip-switch
DB Brightener dispenser ME Acquastop dip-switch
DD Display - Detergent dispenser ML Wash motor
E1 Cold water electrovalve MM Handle dip-switch
E2 Regeneration electrovalve MP Door dip-switch
E3 Hot water electrovalve MR Delay-timer motor - Terminal board
ECO Saving switch MT Timer motor
ED Detergent/Brightener dispenser MTR Fast forward timer motor
EV1 Cold water electrovalve MM- Handle dip-switch MV Motor fan
EV1/2 Half-load electrovalve P Pressure switch
EV2 Regeneration electrovalve P.. Pressure switch contact
EV3 Hot water electrovalve P1 Stage 1 pressure
EVC Hot water electrovalve P2 Stage 2 pressure switch
EVF Cold water electrovalve PAP High pressure switch
EVR Regeneration water electrovalve PO Overflow pressure switch
F Anti-interference filter ML- Wash motor PS Drain pump
FA Radio interferences PULS Push-button panel
I1 On/Off switch - Plus cycle switch -IEC cycle R Heating element
I1/2 Switch half-load R.D. Delay rotary selector
I2 Fast switch -IEC cycle switch (standard) - RA Heating element drying
I2H 2-hour delay switch ROT D Delay rotary selector
I3 Saving switch- Switch for cycle with no pre- ROT. Rotary selector
I4 Switch for cycle fresh dirty S Motor overload cutout
mod.LS630EX50-60 page 33
Page 34
I4H 4-hour delay switch SC Selector cycli
I5-ICR Fast cycle switch SS Salt detector
I6 Soak cycle switch ST START
I6H 6-hour delay switch T.. Delay-tymer contact
IAQS Aquastop switch T1 Power supply earth cable -Thermostat 45?C
ID Switch display T2 Lid earth -Thermostat 55?C
IE Saving switch T3 Timer earth -Thermostat 65?C
IEXD Exstra dray switch T36 36?C N.O. Thermostat
IG Main switch T4 Heating element earth
IMV Off motor fan switch T46 46?C N.O. Thermostat
IP High temperature switch T5 Drain pump earth
IS Cut-off switch T57 57?C N.O. Thermostat
ISB Polisher led switch T6 Wash motor earth
ISS Salt LED switch T8 External lid earth
ITR Heating element switch TE Relay switch
L Mains LED THP Thermoprotector
L1 Cycle 1 lamp TM Timer
L1/2 Lamp cjcle half-load TS Safety thermostat
L2 Cycle 2 lamp TS 40 Thermostat 40 ?C
L3 Cycle 3 lamp TS 50 Thermostat 50 ?C
L4 Cycle 4 lamp TS 62 Thermostat 62 ?C
L5 Cycle 5 lamp TS1 Min. temperature thermostat
L6 Cycle 6 lamp TS2 Max. temperature thermostat
LA Drying LED TT Terminal box support earth
LAQ Aquastop on lamp Tcp nner-door earthing connection
LC Cycle ranning lamp Tfa Radio interference
LD Delay activated lamp Tml Pump wash motor earthing connection
LE Saving cycle Tpg Large door earthing connection
LH2 2-hour delay lamp Tpi Inspection door earthing connection
LH4 4-hour delay lamp Tpr Pressure switch
LH6 6-hour delay lamp Tps Discharge pump earthing connection
LL Wash LED Tr Heating element
LP High temperature LED Tte Delay-timer earthing connection
mod.LS630EX50-60 page 34
Loading...
