TABLE OF CONTENTS

WELCOME TO THE TEAM ----------------------------------------------5

IMPORT ANT FEA TURES OF YOUR NEW HEA T PUMP ------------------6

HOW A HEA T PUMP WORKS ------------------------------------------7

SAFETY INFORMATION------------------------------------------------8

QUICK ST ART & STOP-------------------------------------------------10

HEA TER CONTROLS ---------------------------------------------------12

Control Panel Layout -----------------------------------------------12 Buttons, Lights, and Display --------------------------------------12 Operational & Programming Codes--------------------------------13 Owner-Level Programming (complete) ---------------------------14

MAINTENANCE AND GENERAL OPERA TION--------------------------18

General Maintenance-----------------------------------------------18 Safety During Cleaning Operations -------------------------------18 Maintaining Proper Water Flow ------------------------------------19 Controlling W ater Chemistry --------------------------------------19 Controlling Irrigation and Storm Water R un Off ------------------20 Maintaining Clearances Around Heater ---------------------------20

(Continued on Next Page)

TABLE OF CONTENTS

(CONTINUED)

MAINTENANCE AND GENERAL OPERATION...CONTINUED:

Heating Tips--------------------------------------------------------21

- Heating in Cooler W eather--------------------------------------21

Pool/Spa Blankets-----------------------------------------------21

Pool & Spa Combination Heating-------------------------------21

Spa Set-Back Option -------------------------------------------21

Calculating Initial Heating Time-----------------------------------22

Seasonal Use & Shut Down----------------------------------------23

- (Use) During the Swim Season --------------------------------23

- Freeze Protection and Winterizing Requirements--------------23

- Winterizing Procedure ------------------------------------------24

AquaCal Preventive Maintenance Program------------------------25

TROUBLESHOOTING (No Op, No heat, W ater from Unit) ------------26

T roubleshooting Flowcharts----------------------------------------27

DEALER-SPECIFIC INFORMATION (Installation & Set Up) ---------31

Dealer-Specific Table of Contents ---------------------------------32

CONT ACTING THE FACTORY ------------------------------------------58

Welcome

to the

eam

Dear Owner:

ongratulations on your wise decision to make an AquaCal heat pump part of

your home. Since 1981, AquaCal has maintained the worldwide lead in the manufacture of swimming pool & spa heat pumps. Y our new heat pump is not only a great investment, but also the most cost effective method available for heating pools and spas. For example, your heat pump is up to 400% more efficient than gas, and, when compared to electric resistance heat, your heat pump is nearly 600% more effective. You can rest assured your new heat pump is of the highest quality and efficiency , and is designed and built to provide years of trouble-free operation.

“You can rest assured

knowing your new heat

pump is of the highest quality and efficiency,

Moreover, should you decide you would like AquaCal to provide regular inspection and maintenance of your heat pump— which we do recommend—you will find AquaCal’s factory-trained service staff is the largest and most-qualified in the pool & spa heat pump industry .

and is designed and

built to provide years

of trouble-fr ee

operation.”

Import ant Features of Your

New Heat Pump

ThermoLink® Heat Exchanger

The heart of your heat pump is the patented ThermoLink heat exchanger. The primary cause of premature heat pump demise is the failure of the heat exchanger. Ordinary heat exchangers are made from a cupronickel alloy. This cupronickel material is susceptible to attack from the sanitizers used in pools and spas, and from other related water chemistry conditions. Once the heat exchanger fails, the heat pump is ruined. The ThermoLink heat exchanger tube is made from titanium, and is virtually impervious to water chemistry damage.

Scroll Compressor

50% fewer moving parts than standard piston-type compressors. This equates to much improved reliability and improved efficiency. Scroll compressors are also much quieter in operation than piston-type compressors.

Digital Controller

Digitally-based microprocessor, controls water temperature to within 1º Fahrenheit of set point. Controller also permits user to predefine different pool and spa water temperatures, and to prevent tampering by locking out controls via a pass code.

Heat & Cool Capability*

Puts you in full control, year round ...Warms your pool or spa with the reliability and efficiency of our other heat pumps, but, with the flip of a switch, can also cool your pool or spa to refreshing temperatures during the hot summer months. For cooler climates,

Icebreaker

read more below...

heat pumps offer unique advantages over passive defrost models. Please

Hot Gas Defrost*

Your Icebreaker® heat pump is uniquely equipped for active defrost. Active defrost involves directing hot refrigerant gas to the heat collector, melting accumulated ice away in a matter of a few minutes—then right back to heating. Standard heat pumps may remain “off in defrost” for extended periods during very cold weather. Because of its ability to continue to operate even during freezing weather, your Icebreaker extends the swimming season longer than any other heat pump.

Corrosion-Proof Cabinet

The cabinet, being made from resilient, UV-Protected ABS material, can never rust, fade or corrode. You can expect the cabinet to retain a like-new appearance with only an occasional wash down and—if so desired—a quick waxing.

*Icebreaker

Models Only

PLEASE READ FURTHER TO BECOME FAMILIAR WITH ALL THE FEATURES, THE

SAFE OPERATION, AND THE CARE OF YOUR NEW HEAT PUMP.

HOW A HEA T PUMP WORKS

THE FOLLOWING EXPLANATION IS PROVIDED TO HELP YOU IN UNDERSTANDING

WHA T

TO EXPECT FROM YOUR HEAT PUMP…

A Heat Pump Does Not Make Heat…

Heat pumps are so extraordinarily efficient because they do not need to produce heat in order to warm pool or spa water. Rather, heat pumps simply transfer heat from the outside air into the water.

If one considers absolute “0”–the point where all heat is absent–occurs at 459º F ahrenheit below zero, it becomes evident outside air–even at the relative cool temperature of 55º Fahrenheit –still contains large amounts of heat energy . It is that abundant heat energy a heat pump captures and places into your pool or spa.

...

EAT

EMOVED

OOL

FROM

EA T

ADEN

NTERS

ARMED

ATER

OOL

ATER

SAFETY INFORMA TION

Used and maintained properly, your heat pump will provide year-upon-year of safe and economical service. However, as with any mechanical or electrical device, to get the most from your heat pump–while insuring personal safety for you and others–certain operational and maintenance factors must be observed.

Likewise, excepting a few minor owner-capable maintenance items (explained later in this manual), repair and service of your heat pump must be performed only by experienced service personnel. Should you, the owner, suspect your heat pump is not performing properly, by referring to the section in this manual entitled: "Troubleshooting", you will be able to determine if a call for service is required. Your installer can be one source of service, or AquaCal Customer Support personnel stand ready to assist you at: (800) 786-7751. For questions concerning installation, modifications, operation, service and upkeep, please contact your installer or AquaCal Customer Support. W arr anties ma y be voided if the heater has been used, maintained, or repaired improperly.

In addition to possible voiding of warranties: unapproved installation methods, nonstandard modifications, poor or incorrect maintenance, service by unqualified personnel, or improper use of this unit, may result in personal injury and/or property damage. For personal safety and to avoid damage to equipment, it is important that safety instructions displayed on the heat pump, and within this manual, are read, understood, and followed.

Throughout this manual the following two safety signals are placed where particular care is required. Please note "WARNING" relates to personal safety , while "CA UTION" signals promote avoiding damage to equipment.

Failure to heed the following may result in perma-

W ARNING !

“Warning” signal appears in this manual where special attention is required for personal safety. (Specific instructions will appear in this box.)

CAUTION !

“Caution” signal appears in this manual where special care is required to avoid equipment damage. (Specific instructions will appear in this box.)

nent injury or death.

Failure to heed the following may result in equipment damage.

Notice: Heater NOT Repairable by Owner

Failure to heed the following may result in permanent

W ARNING !

Heat pumps contain no owner-repairable components. Repairs must not be attempted by untrained and/or unqualified individuals. If service is deemed necessary, contact installing dealer or AquaCal Customer Support at (800) 786-7751.

injury or death.

Refrigerant Circuit Service Only by

Qualified, EPA Certified Technician

Failure to heed the following may result in permanent

W ARNING !

Heater contains refrigerant under pressure. Repairs to the refrigerant circuit must not be attempted by untrained and/or unqualified individuals. Service must be performed only by qualified HV AC technicians. Recover refrigerant to relieve pressure before opening system.

injury or death.

Water Temperature Safety

Failure to heed the following may result in permanent

W ARNING !

Prolonged immersion in water warmer than normal body temperature may cause a condition known as HYPERTHERMIA. The symptoms of hyperthermia include: unawareness of impending hazard, failure to perceive heat, failure to recognize the need to exit the spa, and unconsciousness. The use of alcohol, drugs, or medication can greatly increase the risk of fatal hyperthermia. In addition, persons having an adverse medical history , or pregnant women, should consult a physician before using a hot tub or spa. Children and the extreme elderly should be supervised by a responsible adult.

injury or death.

W ater Chemistry Safety

Failure to heed the following may result in permanent

W ARNING !

Improper water chemistry can present a serious health hazard. T o avoid possible hazards, maintain Pool/Sp a water per standards detailed later in this manual..

CAUTION !

injury or death.

Failure to heed the following can result in damage to equipment.

While your heat pump’s titanium-based heat exchanger provides nearly impervious protection against poor water chemistry , improper water chemistry may cause expensive damage to pump, filter , pool shell, etc. To avoid equipment damage, maintain Pool/S pa water per standards detailed later in this manual.

Getting Started

HEATING- QUICK ST ART & STOP

This brief information is provided as an aide to installers, service personnel, and owners. The intent of this section is to provide rapid access to (only) very basic operational information. Individuals who will be routinely using, installing, maintaining, and servicing this heat pump, are strongly encouraged to read this entire manual. Herein, the terms: Heat Pump, Heater, and Unit are used synonymously.

These instructions are intended for local control of a heat pump, independent of an external controller. Owners: if your installation includes an external controller, contact your installing dealer for operational instructions.

These are instructions to quick-start in the HEATING mode...Owners of Heat-Cool units, in order to utilize all features of their heater, will cert ainly want to also refer to: ning on page-14 of this manual.

1. Verify Electrical Power is Present at Heater:

A . Ensure that the unit has electrical power connected; the heater controller display should

be illuminated;

B. If the display is blank, be certain the electrical breaker, and heater disconnect, are

switched to “ON”;

C. For now, leave the water circulation pump OFF.

Owner Level Programming, begin-

2. Set the Heater Controls (Refer to Control Panel Layout, Pg-12): OWNER- If heater is connected to a Call-Flex controller, also see Call-Flex programming

located in INST ALLER- Is heater connected to an external controller? See:

beginning on page-31 this manual. A. The owner settings can be set without water flowing. Once the heater has electrical power

connected, with water not flowing, the display should read FLO;

B. Press the MODE button until the HEAT (HEA) indication displays. This action will enable

the remaining programming keys;

C. Using the POOL / SPA selector key, select the POOL mode. The chosen mode will be

verified by an illuminated indicator light, located on the left side of the display , showing that the POOL control has been selected (If heating just a spa, using the DOWN arrow

key, lower the POOL temperature until OFF is displayed; then proceed to Step-E. ). D. Use the UP / DOWN arrow keys to set the desired water temperature for the POOL water; E. If the heat pump will be used to heat a spa, use the POOL/SPA selector key to select

SPA, then use the UP / DOWN arrow keys to set the desired water temperature for the

SPA (If heating just a POOL, using the DOWN arrow key, lower the SPA temperature until

OFF is displayed.); F. The heat pump controls are now set to maintain the desired water temperature for the

POOL and/or SPA.

Owner Level Programming, beginning on page-14 of this manual.

Dealer-Specific Instructions,

(Quick-Start & Stop Continued Next Page)

HEATING-QUICK START & STOP (continued):

3. To Begin Heating:

A . Verify MODE is set to: HEAT ; then, depending on which body of water is to be heated, use the

POOL / SPA selector key to select POOL or SPA ;

B. Position external water valves appropriately to flow water to & from the body of water and

through the heater;

C. Start the water pump...Within 4-minutes, depending on the status of the controller’s internal

time delay , the heater will st art. The selected body of water will be brought to temperature and maintained per the setting determined previously in: “Set the Heater Controls”;

D. In operation, whenever the actual (displayed) water temperature falls below the desired set

point, after an initial time delay of 4-minutes, the unit will begin heating .

NOTE: THE HEAT CONTROLLER INCORPORATES AN ANTI-SHORT CYCLE TIME DELAY. SHOULD OPERATION BE

INTERRUPTED

4. Program Filter Pump Run Time:

Most pool/spa systems utilize a timer or multifunction controller to manage filter pump run times.” If your system incorporates such a device, follow the instructions below:

A . It will be necessary to allow the filter pump to run continuously until the water has reached the

desired temperature. If a timer controls the pool filter pump, it will be necessary to override the timer to allow 24-hr. operation.

B. Once the desired temperature has been obtained (2-4 days), reset the pump control device.

Colder months require longer running times–generally eight to twelve hours/day .

C. A heat pump can only operate when the filter pump is running. Therefore, it may be

necessary–during cooler weather–to extend the water pump’s hours of daily operation. The increased run time is necessary in order to keep up with increased, weather-related heat losses.

, RESTART WILL BE DELAYED BY APPROXIMATELY 4-MINUTES.

5. Continuous Usage and Water Around Heater:

Condensation... After the heat pump has been operating for some time, water may be observed surrounding the heater. The moisture seen is condensation produced as a by-product of transferring heat from the air into the pool or spa water. Quantities of 6-8 gallons of water produced per hour are common if the air humidity is high. Conversely , a low humidity condition may result in no condensation being produced. (To troubleshoot, see page-26, “W ater Coming from the Heat Pump.”)

6. To Stop the Heat Pump:

A. Select: OFF via the MODE selector. This method of shut down preserves the controller

settings;

B. An interruption of water flow–such as when a pump timer is in control–will, also, cease heat

pump operation.

(End...Quick-Start & Stop)

HEATER CONTROLS

Control Panel Layout

(APPEARANCE VARIES BY MODEL)

Control Buttons, Indicator Lights, & Display

(AS INDICATED BY CIRCLED NUMBERS)

1) POOL / SPA SELECTOR – Selects either pool or spa thermostat.

2) COOLING INDICATOR LIGHT – Indicates unit is cooling. (Note: This light and

associated text will not be present on heat only models)

3) UP ARROW – Increases temperature setting. (Maximum setting is 104

4) DOWN ARROW – Decreases temperature setting. (Minimum setting is 45

5) HEATING INDICATOR LIGHT – Indicates unit is heating.

6) MODE SELECTOR – Used to select between the Heating, Cooling, Auto-

Changeover, and Off for Heat & Cool models. Used to select between Heating and Off for heat-only models.

7) SPA INDICATOR LIGHT – Indicates heater is referencing spa thermostat.

8) POOL INDICATOR LIGHT – Indicates heater is referencing pool thermostat.

9) LED DISPLAY – Displays water temperature when no keys are being pressed.

Displays desired temperature when UP ARROW or DOWN ARROW is pressed. Also displays operational, programming, and fault codes as applicable.

10) DESIRED TEMPERATURE LIGHT – Indicates temperature set point is being displayed. Indicates temperature set point is being changed due to the UP ARROW or DOWN ARROW being pressed.

11) WATER TEMPERATURE LIGHT – Indicates current water temperature is being displayed.

HEATER CONTROLS...continued

Operational & Programming Codes

HE FOLLOWING CODES WILL BE DISPLAYED AS PART

OF THE NORMAL OPERATION OF THE HEATER:

FLO.....No Water Flow Detected. This code appears whenever the circulating

pump is off, or when the heater is not receiving correct water flow.

OFF..... System is Off. This code appears whenever heater has been turned off

via the mode selector button, or when the temperature set point has been lowered below 45

CFI...... Celsius/Fahrenheit Selection. This is a programming entry point to select

in which format the water temperature will be displayed.

ULC.....User Lock Code. This is a programming entry point; when activated,

steps to the next menu level: ELC.

ELC.....Enter Lock Code. This a programming entry point; permits end user to

select a secret code, thereby limiting access to the owner settings.

CFO.....Call Flex Options. This is a programming entry point; when used in

conjunction with a AquaCal Call/Flex add on kit, permits the use of CALL or FLEX options.

FS....... Heater in Defrost Mode. This code appears as a normal display during

periods of lower air temperatures. Two possibilities follow: Heat-Only Units: Fan continues to run and compressor is off. Compressor

will restart when air coil temperature rises to approximately 38°F. Heat-Cooling (reversing) Units (Applicable in Heat Mode Only): if a

defrost cycle is necessary, the unit’s reversing valve will be activated. While the reversing valve is activated, the fan operation will be suspended to permit maximum heating of the air-coil. The reverse-cycle will continue until the air-coil reaches a set temperature, or until 4-Minutes has elapsed. Upon completion of the defrost cycle, the reversing valve will be deactivated; normal fan and heating operation will resume. During hot-gas defrost cycles, the compressor will not deactivate; rather, it will continue in operation throughout the sequence.

LOC.....This is a Service Entry Point (not intended for use by the owner). The

[LOC] code permits service personal to enter a factory code for access to adjustable calibration and site-dependant setup parameters. Service adjustments are available to authorized installation and service personnel, only.

Failure to heed the following may result in equipment damage

CAUTION !

and voiding of manufacturer’s warranty.

Heat pumps contain no owner-serviceable components. Owner-initiated adjustments, beyond the controller “LOC” code, must not be attempted. If adjustments are deemed necessary, the owner should contact installing dealer or AquaCal Customer Support at (800) 786-7751.

HEATER CONTROLS...continued

Start Up & Setting Operating Controls

Owner-Level Programming Instructions (Complete)

Covered within this section are features and settings typically accessed first by the installer, and then remaining accessible by the end user (owner). These features reside at the Level-1 access point within the microprocessor.

1. Applying Power to The Controller:

A . When power is first applied, the controller performs a lamp test and the display will read

[888]. Following [888] the software version will display briefly;

B. The control will then display the actual water temperature, provided the circulating pump is

operating, and adequate water is flowing through the heater;

C. If the pool-circulating pump is off, the control will display: [FLO]. This code message

indicates no (or insufficient) water is being circulated through the heat pump.

2. Starting the Heat Pump:

A. Once electrical power is supplied to the heat pump, sufficient water is circulating, and the

heater controller has successfully completed its self-test, the heater is ready to operate;

B. The heat pump is shipped with the controller [MODE] function set to “OFF”. There are two

ways to switch the heat pump OFF: button is “OFF”. below the minimum temperature setting (45 “OFF”. To switch the unit ON, first use the mode button to select the HEAT mode— for Heat Only models—or, if the heat pump is a Heat and Cool model, use the mode button to select one of the following modes: HEA T, COOL, or ACH (Auto-changer over). In the [OFF] mode, the actual water temperature will be displayed as long as the circulating pump is operational and correct water flow is present. In the event water is not circulating through the heat pump (or flow is insufficient), the controller will display the [FLO] (No Water Flow) code message.

C. Using the UP ARROW key, increase the desired temperature until it exceeds the value of the

actual temperature displayed. (Note: See # “8,” later in this section, if “000” is displayed upon pressing either the up or down arrow keys.) Once the desired temperature has been entered, the display will read the actual temperature and the heat pump will start to operate. Both the compressor and the fan must be operating before the “Heating” LED will illuminate.

(Note: When MODE function is OFF, the current water temperature will be displayed; no functions, values, or programming will be available for adjustment.)

3. Turning The Heat Pump Off:

Method 1: using the [MODE] key, depress the key until the display reads “OFF” The heater will shut off and remain off until the [MODE] key is used the select an operational mode. This is the preferred method for shutting off the heat pump.

Second Method- The thermostat set point can be lowered to a position

First Method- One of the functions of the [MODE]

F); this action will cause the display to read

B. Method 2: using the DOWN key, depress the key until the desired water temperature

reaches 45 display to read “OFF”. This method is typically used in conjunction with 2-wire external controllers; these controllers are equipped with their own thermostats.

F (minimum setting); then, depress the DOWN key one more time, causing the

(Continued on Next Page)

HEATER CONTROLS...continued

Start Up & Setting Operating Controls

Owner-Level Programming Instructions...continued:

4. Selecting Pool/Spa Thermostat Settings:

A . Depress the [POOL/SPA] key to toggle between the pool and the spa temperature set

points.

B. The pool/spa LED indicator lights, located to the left of the temperature display, will confirm

the selected set point.

5. Changing The Pool Temperature Set Point:

A . Using the [POOL/SPA] key, select the POOL temperature set point. The pool set point

indicator light will confirm the selection.

B. The pool temperature set point is adjustable from a minimum of 45

104oF. Depressing the [UP ARROW] key will raise the set point 1-degree for every push of the button. Depressing the [DOWN ARROW] key will lower the set point 1-degree for every push of the button.

6. Changing The Spa Temperature Set Point:

F to a maximum of

A . Using the [POOL/SPA] key , select the SPA temperature set point. The sp a set point indicator

light will confirm the selection.

B. The spa temperature set point is adjustable from a minimum of 45

F to a maximum of 104oF. Depressing the [UP ARROW] key will raise the set point 1-degree for every push of the button. Depressing the [DOWN ARROW] key will lower the set point 1-degree for every push of the button.

7. Selecting Between

F and oC:

A. Simultaneously depress and hold both the [UP ARROW] and [DOWN ARROW] keys until

[CF1] (Celsius / Fahrenheit) code appears.

B. With the [CF1] code displayed, pressing the [UP ARROW] or [DOWN ARROW] keys will

change the selection code to either “0” or “1”. Select “1” for Fahrenheit temperature display , or “0” for Celsius temperature display. Once the desired temperature display mode has been selected,

not pressing any buttons for 15-seconds will allow the controller to save the selection and return to the normal operating mode. Pressing the {POOL/SPA] key will also save the selection and step to the next menu parameter: [ULC] (User Lock Code).

8. User Lock Code Option [ULC]:

This Option Explained: Heat pumps are shipped from the factory with the [ULC] option disabled. Enabling the [ULC]

function permits the heat pump owner to restrict access to the unit’s controls. With the [ULC] function enabled, unless the correct ULC code number is entered, changes to Level-1 programming are not possible. (I.e.: Altering temperature set point s, Pool/Spa selection, C/F display changes, etc., will not be possible). The [ULC] option can be thought of as an electronic lockable cover for the controls.

(Continued on Next Page)

HEATER CONTROLS...continued

Start Up & Setting Operating Controls

Owner-Level Programming Instructions...continued:

8. User Lock Code Option [ULC]...continued:

A. Selecting UCL Option:

1) Depress either the UP or DOWN ARROW keys; if “LOC” is momentarily displayed flowed by “0”, the ULC feature is enabled. If “0” displays proceed to “6)” of this section; otherwise, see number “2” below.

2) Simultaneously depress and hold both the [UP ARROW] and [DOWN ARROW] keys until [CF1] (Celsius / Fahrenheit) code appears.

3) Depress the [POOL/SPA] key once to display [ULC].

4) With [ULC] displayed, pressing either the Up or Down Arrow key will display either “1” or “0”. Selecting “0” will allow the keypad to remain unlocked. Selecting “1” will enable the User Lock Code option. Then to enter a lock code number, press the [POOL/SPA] key once to display [ELC] (Enter Lock Code).

5) With [ELC] displayed, use the Up or Down arrow keys to select a lock code. The code can be any number from “00” to “99”. The factory set lock code is “0”. Not pressing any buttons for 15-seconds will allow the controller to save the selection and return to the normal operating mode. Pressing the {POOL/SPA] key will also save the selection, and will step the controller to the next menu parameter: [CFO] (Call Flex Options).

6) Once the ULC option has been enabled, depressing any key will momentarily display “LOC” followed by “0” (prompting the entry of the correct lock code number). To gain access to the controller:

a. Using the [UP ARROW] key, scroll to the correct lock code number, then; b. Press the [POOL/SPA] key…Current water temperature will be displayed…Control

setting can now be viewed or changed as desired.

c. After a period of approximately four (4) minutes, during which time no buttons have

been pressed, the controller will automatically return to the locked mode. Provided

ULC selection is set to “1,” the controller will always fail-safe in the locked mode.

d. Without knowledge of the correct lock code, and with the ULC enabled, control

adjustments will place. The lock code may be changed any number of times by following the instructions detailed in this section.

B. De-Activating the User Lock Code [ULC] function:

1) Following the instructions detailed previously at: “8, 6)”, press any key and enter the user lock code number; then press the [POOL/SPA] key.

2) Immediately following the entry of the user lock code, simultaneously depress and hold the [UP ARROW] and [DOWN ARROW] keys until the code [CF1] appears on the display.

not be possible. Be certain to record your lock code in a safe

3) Then, use the [POOL/SPA] key to scroll to the [ULC] message; press the [DOWN ARROW] key to change the display to “0”. This will disable the User lock function.

(ULC Continued on Next Page)

HEATER CONTROLS...continued

Start Up & Setting Operating Controls

Owner-Level Programming Instructions...continued:

C. User Lock Code is Activated, but Pass Number is Not Known (“Back Door Entry”):

Note: Should the ULC option be enabled, and a lock code number other than the factory default (0) be installed but is unknown, the following procedure may be followed to regain controller programming access:

1) Simultaneously depress and hold the [POOL/SPA] and [UP ARROW] keys until the

display shows “888”. This operation will reset the controller to the factory default settings.

2) When reset to the factory default settings the user lock code [ULC] is deactivated and

the user lock code number [ELC] is reset to “0”.

3) In addition, all other settings are returned to the factory defaults. If an external controller

is in use, contact AquaCal Technical Support Group (800-786-7751); ask for assistance with re-configuring the controller for use with an external controller.

9. Selecting Call-Flex Pump Options [CFO]:

General Information:

The Call-Flex option automatically adjusts the run time of the water circulator pump, and heater, based upon changing weather conditions. Without Call-Flex, as weather conditions grow progressively cooler during winter months, or when unusually cold weather occurs, the run duration of the circulator pump may require manual adjustments to permit the heater to maintain or reattain desired water temperature (the water pump must be running in order for the heater to operate). Likewise, without Call-Flex, one must remember to reset the pump run controls following the cold weather event. The Call-Flex option greatly reduces the need for seasonal, manually-made, pump run time adjustments. Call-Flex is a dealer-installed option that does come with every heater; if unsure, check with the installing dealer to determine if a call-flex kit was part of the original installation. If Call-Flex was not part of the installation, and you would like

to have Call-Flex added, your dealer can do so...contact the installing dealer . If the installation is equipped with the Call-Flex option, the following steps are used to control the

Call-Flex features: A. Simultaneously depress and hold the [UP ARROW] and [DOWN ARROW] keys until the

display shows “CF1”. Depress the [POOL/SPA] key three times to scroll the display to [CFO].

B. With the [CFO] (Call-Flex Options) code displayed, use the Up or Down keys to select “0” to

disable the Call Flex Options, “1” to enable the Call Option, or “2” to enable the Flex Option. Not pressing any buttons for 15-seconds will allow the controller to save the selection and return to the normal operating mode. Pressing the {POOL/SPA] key will also save the selection, and will step the controller to the next menu parameter: [LOC] (Service Lock Code).

not

C. For further information, please refer to Call-Flex installation instructions, shipped with the

Call-Flex kit. For additional copies of these instructions, contact the AquaCal Customer Support (800-786-7751).

(End...Owner-Level Programming Instructions)

MAINTENANCE

OPERATIONAL RECOMMENDA TIONS

The information in this section is written primarily for the Home Owner, but may also apply to servicing dealers or HV AC service centers. This section contains information concerning planned maintenance, proper water flow, maint aining proper clearances, as well as other vital information. Please read this section now, and before calling AquaCal Customer Support (800-786-7751).

General Maintenance

Heat pumps should be inspected and maintained on an annual basis by a qualified swimming pool heat pump specialist. Additionally , if the heat pump is located on the beach, or at a sea wall where salt spray and sand can become detrimental factors, more frequent service may be necessary . For service plan information, please see: Customer Support at: 800-786-7751.

Planned Maintenance Program, later in this section, and then contact AquaCal

While annual maintenance is recommended to maintain your warranty , if you choose in the Planned Maintenance Program, rinsing the air coil regularly, and keeping the base of the unit clear of leaves and debris is a necessity.

Should you as the owner desire to perform the coil rinsing and other cosmetic care of the heat pump, please contact AquaCal Customer Support: 1-800-786-7751; request the document titled: “ Care for Air-Source Heat Pump s: Approved Method for Home Owners.”

not to participate

Appearance

Safety During Cleaning Operations

Failure to heed the following may result in permanent

W ARNING !

POSSIBLE ELECTRIC SHOCK HAZARD . . . Should you decide to wash the heat pump via water hose, disconnect all power to the pool equipment pad- including, but not limited to: The heat pump, water pump, and any and all other electrical equipment. Do NOT spray water directly into electrical components. Do NOT restore electrical power until such time as all water has dried completely .

CAUTION !

injury or death.

Failure to heed the following may result in damage to equipment.

Do not use a pressure cleaner to wash heat pump . . . . Damage to evaporator fins, as

well as other components, will result.

+ 42 hidden pages

Aquacal 100 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
