Smart-UPS: legendary uninterruptible power
apc.com/smartups
Intelligent, reliable protection for servers and networks
A legacy of
apc.com/smartups
reliability
Smart-UPS
models
Smart-UPS
Smart-UPS
management
accessories
solutions
Maintain critical operations
apc.com/smartups
with certainty
Energy reliability has a name.
From home oces to business enterprises, Smart-UPS
units support the uninterruptible power needs of your
IT and equipment. This time-tested benchmark from
™
APC
and connections from power risks by supplying clean,
reliable, network-grade power.
by Schneider Electric™ protects critical data
™
The Smart-UPS family
apc.com/smartups
Choose yours today
A variety of models for a variety of needs.
There is a Smart-UPS model for nearly
every application and budget. Home
oces, small businesses, managed
service providers, and IT professionals
can choose from a range of form factors.
From entry-level to scalable runtime,
Smart-UPS solutions are ideal for servers,
point-of-sale equipment, routers, switches,
hubs, and more.
apc.com/smartups
Smart-UPS
models
SMC: entry-level UPS models
FEATURES
TECH
SPECS
apc.com/smartups
IDEAL FOR:
• Small business
routers
• Entry-level
servers
• Point-of-sale
equipment
SMC1500C
SMC1000C
SMC1500-2UC
SMC1000-2UC
SMC: entry-level UPS models
TECH
SPECS
FEATURES
SMC features:
IDEAL FOR:
• Small business
routers
• Entry-level
servers
• Point-of-sale
equipment
• Network-grade power conditioning
Filters noise, provides automatic voltage regulation
(AVR), and includes surge protection
• Sine-wave output on battery
Compatibility with a broad range of IT power
supplies whether online or on battery
• LCD display
Intuitive interface provides key status at a glance
• Battery disconnect
Convenient way to disconnect battery for transport
(tower models)
• PowerChute
UPS monitoring and control, safe operating system
shutdown, and innovative energy-management
capabilities via USB (optional serial cable available)
™
Business Edition software
• Intelligent battery management
Extends battery life, optimizes performance,
and maximizes reliability through precise
temperature-compensated charging and
automatic self tests
• High-eciency green mode
Optimal eciency that saves utility and
cooling costs
• Rack-mount hardware*
Brackets provided to install in both 2- and
4-post racks — additional rails optional
*Rack-mount models only
SMC: entry-level UPS models
TECH
SPECS
FEATURES
OUTPUT
IDEAL FOR:
• Small business
routers
• Entry-level
servers
• Point-of-sale
equipment
Power capacity 600 W / 1,000 VA 900 W / 1,500 VA 600 W / 1,000 VA 900 W / 1,500 VA
Output connections (NEMA
INPUT
Input voltage range for main operations
(max adjustable range)
Input connection 5 -15P 5-15P
RUNTIME ESTIMATES
200 W :26 :36 :26 :48
300 W :16 :23 :16 :31
500 W :08 :12 :08 :16
700 W – :07 – :10
Full load :06 :05 :06 :07
COMMUNICATIONS AND MANAGEMENT
Interface ports USB and serial (RJ45) USB and serial (RJ45)
APC SmartConnect feature Yes (Ethernet) Yes (Ethernet)
Control panel and audible alarms
PHYSICAL
Height (inches) 8.5 8.5 3.5 3.5
Width (inches) 6.7 6.7 17 17
Depth (inches) 17. 3 17. 3 16 18
Weight (pounds) 38 45 45 62
SMC1000C SMC1500C SMC1000C-2UC SMC1500C-2UC
®
) (8) 5 -15R (6) 5 -15R
93 – 130 V (85 – 136 V) 93 – 130 V (85 – 136 V)
Etched glass LCD display with LED status indicators:
alarm on battery, distinctive “low battery” alarm
Etched glass LCD display with LED status indicators:
alarm on battery, distinctive “low battery” alarm
SMT: standard-level UPS models
FEATURES
TECH
SPECS
apc.com/smartups
IDEAL FOR:
• Various types
of tower servers
(from entry-level
to mid-range)
• Storage
• Point-of-sale
equipment and
network devices
SMT1000C
SMT1000RM2UC
SMT1500C SMT1500RM2UC
SMT: standard-level UPS models
TECH
SPECS
FEATURES
SMT features (in addition to entry-level SMC features):
IDEAL FOR:
• Various types
of tower servers
(from entry-level
to mid-range)
• Storage
• Point-of-sale
equipment and
network devices
• Congurable, multi-lingual LCD display
Provides UPS status and key measures at a
glance. Clear and accurate, menu-driven display
for easy set-up and customization with or without
software installation
• Extended-range automatic voltage regulation
Provides enhanced brownout protection,
boosting incoming voltage up to 30% without
using battery power
• Switched outlet group
Controlled separately from the UPS for discrete
reboot of hung devices, sequenced ON / O F F,
and non-critical load shedding
• Advanced battery management
Innovative, dynamic recommended battery
replacement date indicator
™
• SmartSlot
Accepts a wide array of accessory cards
for advanced management and
environmental monitoring
• Rack-mount rails
All hardware provided to securely install in
your IT rack
interface:
*
*
Rack-mount models only
