APC SMC15002U, SMC10002U User Manual
Operation Manual
Smart-UPS™ C
Uninterruptible Power Supply
1000/1500/2000/3000 VA Rack-Mount 2U
120/230 Vac
s
u
0
0
8
1
2
a
Product Description
The APC™ by Schneider Electric Smart-UPS™ C is a high performance uninterruptible power supply
(UPS). The UPS provides protection for electronic equipment from AC power blackouts, brownouts,
sags, and surges, small AC power fluctuations and large disturbances. The UPS also provides battery
backup power for connected equipment until AC power returns to safe levels or the batteries are fully
discharged.
This user manual is available on the enclosed Documentation CD and on the APC by Schneider Electric
Web site, www.apc.com.
Safety Messages
Read the instructions carefully to become familiar with the equipment before trying to install, operate,
service or maintain it. The following special messages may appear throughout this manual or on the
equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a
procedure.
CAUTION
UNPROTECTED OUTPUTS
Apply circuit protection to all outputs.
Failure to follow these instructions can result in equipment damage.
Safety and General Information
Inspect the package contents upon receipt. Notify the carrier and dealer if
there is any damage.
Read the Safety Guide supplied with this unit before installing the UPS.
• This UPS is intended for indoor use only.
• Do not operate this UPS in direct sunlight, in contact with fluids, or where there is excessive dust or
humidity.
• Be sure the air vents on the UPS are not blocked. Allow adequate space for proper ventilation.
• The battery typically lasts for two to five years. Environmental factors impact battery life. Elevated
ambient temperatures, poor quality AC power, and frequent short duration discharges will shorten
battery life.
• Connect the UPS power cable directly to a wall outlet. Do not use surge protectors or extension
cords.
WARNING
This is a category C2 UPS product.
In a residential environment, this product may cause radio interference, in which case the
user may be required to take additional measures.
1Smart-UPS C 1000/1500/2000/3000 VA 120/230 Vac Rack-Mount 2U
Specifications
For additional specifications, refer to the APC by Schneider Electric Web site at www.apc.com.
UPS + Battery Battery
Weight
specifications
Temperature
Maximum
Elevation
Humidity
Battery Type
SMC1000-2U / SMC1000I-2U
20.48 kg (45.15 lb)
SMC1500-2U / SMC1500I-2U
27.8 kg (61.20 lb)
SMC2000I-2U
26.2 kg (57.76 lb)
SMC3000RMI2U
41 kg (90.38 lb)
Operating 0° to 40° C (32° to 104° F)
Storage
Operating 3,000 m (10,000 ft)
Storage 15,000 m (50,000 ft)
0% to 95% relative humidity,
non-condensing
Maintenance free, sealed lead acid
Replace used batteries with APC by Schneider Electric approved batteries.
To order a replacement battery go to the APC by Schneider Electric Web site,
www.apc.com.
Always recycle used batteries.
For information on recycling a used battery, refer to the Battery Disposal
Information sheet included with the replacement battery.
APCRBC124
5.6 kg (12.32 lb)
APCRBC132
10 kg (22 lb)
APCRBC133
10 kg (22 lb)
APCRBC151
19 kg (41.80 lb)
-15° to 45° C (5° to 113° F)
charge UPS battery every six months
0° to 40° C (32° to 104° F)
Smart-UPS C 1000/1500/2000/3000 VA 120/230 Vac Rack-Mount 2U2
Product Overview
Front panel features
Display interface
Bezel
Battery
Internal battery connector
1000VA 120/230 Vac
s
u
0
5
6
3
c
3000 VA 230 Vac
1500 VA 120/230 Vac
2000 VA 230 Vac
s
u
0
9
3
6
a
Rear panel features
UPS input
Circuit breaker/Overload protection
Chassis ground screw
Outlets
USB port
Serial data port
1000 VA 120 Vac 1000 VA 230 Vac
s
u
0
6
3
0
c
1500 VA 120 Vac
su0644c
1500 VA 230 Vac
su0644b
su0644d
su0644e
3Smart-UPS C 1000/1500/2000/3000 VA 120/230 Vac Rack-Mount 2U
UPS input
Circuit breaker/Overload protection
Chassis ground screw
Outlets
USB port
Serial data port
2000 VA 230 Vac
3000 VA 230 Vac
Installation
For UPS installation information, refer to the Installation Guide for the Smart-UPS C 1000/1500/2000/
3000 VA Rack-Mount 2U included with the UPS.
The Installation Guide is also available on the Documentation CD included with the UPS and on the
APC by Schneider Electric Web site, www.apc.com.
su0644f
su0644 g
Smart-UPS C 1000/1500/2000/3000 VA 120/230 Vac Rack-Mount 2U4
