ARD9800
FAST RADIO MODEM
Multi-Mode and Digital Voice Interface
Operating manual
AOR, LTD.
1
Thank you for purchasing the AOR ARD9800 Multimode And Digital Voice Interface.
The ARD9800 is designed to convert your HF radio equipment to a multi mode
and digital voice radio without performing any modifications to your transceiver.
Please read through this instruction manual and familiarize yourself with the
operation of the ARD9800. We suggest you to keep this instruction manual for future
reference.
We believe you will enjoy using the ARD9800 as an enhancement to your enjoyment
of amateur radio.
AOR, LTD.
2
Features:
Digital voice communications using existing analog 2 way radios. The ARD9800
uses the same audio frequencies (300 Hz ~ 2500 Hz) as microphone audio to
modulate the voice signal. This allows you to use an analog radio as a digital voice
transceiver.
Digital voice communications in the Single Side Band (SSB) mode. The automatic
frequency clarifier function adjusts frequency drift automatically in the SSB mode.
(Approximately up to +/- 125 Hz). Utilizes the ODFM (Multi Carrier Modulation)
circuit that is effective against Multi-path or Selective Fading.
Automatic digital receive. Automatic voice signal detector recognizes the received
signal as analog or digital, automatically switching to the appropriate mode.
Digital Slow Scan TV (SSTV). Built-in video capture function (NTSC or PAL
depending on version). Compresses the signal into our original adaptive JPEG. Send
and receive images (similar to analog slow scan TV, but higher resolution) in the
Digital mode. Built-in video output connector (NTSC or PAL depending on version)
allows viewing the picture on an external monitor.
Built-in high grade Vocoder (AMBE). Uses high grade digital voice compression to
deliver quality digital voice communications.
Built-in FEC error correction. A powerful error correction circuit delivers stable and
reliable communications.
Data communications on the HF band Data communication is possible on the HF
(High frequency) bands at no extra cost. (Speed may be limited by regulations in
certain jurisdictions.)
Small and compact unit. Easy to operate. Simply connect the ARD9800 to the
microphone jack. No complicated or risky radio modifications are necessary.
Utilizes a uniquely designed high performance DSP (Digital Signal Processor)
engine.
Battery operation possible for field use.
3
Precautions
To prevent fire, personal injury, or unit damage, please observe the following
precautions:
Do not attempt to adjust this unit unless instructed to do so by this manual.
Do not expose the unit to direct sunlight or place the unit close to heating appliances.
Do not place the unit in excessively dusty, humid or wet areas.
We are not responsible for any damages to the radio equipment due to improper
settings or interface.
We are not responsible for any loss of communications due to an unexpected change
in propagation or the operating environment.
4
Table of Contents
Page
Supplied Accessories ---------------------------------------------------------- 5
Controls and functions -------------------------------------------------------- 6
Front Panel ------------------------------------------------------------------- 6
Rear Panel -------------------------------------------------------------------- 8
Top Panel ----------------------------------------------------------------------- 10
Internal View ------------------------------------------------------------------ 10
Bottom View ------------------------------------------------------------------ 11
Interfacing the ARD9800 ------------------------------------------------------ 12
Connection to a Radio ----------------------------------------------------- 12
Connection to a Microphone -------------------------------------------- 13
Connection to a PC -------------------------------------------------------- 13
Connection to a Power supply ----------------------------------------- 13
Connection to an external speaker ------------------------------------ 14
Presetting ----------- ------- --------- ----------------- ------------------ - -- 15
Output Level to Radio Transceiver -------------------------------------------- 15
Microphone Level ----------------------------------------------------------------- 16
User ID Setting ------------------------------------------------------------------- 17
TX Channel Setting --------------------------------------------------------------- 17
Operation ----------------------------------------------------------------------------- 19
Voice Communication ----------------------------------------------------- 19
Digital Voi ce Communication -------- ----------- -------------- --- 19
Analog Voic e Communi c atio n -- --- ---- - ---- ---- ---- - ---- --- - --- 19
Data Communication ------------------------------------------------------- 19
Receive --------------------------------------------------------------- 19
Transmit ------------------------------------------------------------------ 19
Digital Image Communication ------------------------------------------ 20
Receive ------------------------------------------------------------------ 20
Transmit ----------------------------------------------------------------- 20
Specifications ------------------------------------------------------------------------ 21
Control Commands ------------------------------------------------------------- 22
Command List -------------------------------------------------------------------------- 24
5
Supplied Accessories
The following items are provided in the box:
Accessory Quantity
Microphone 1
PC interface cable 1
Speaker Cable 1
DC Power cable 1
8P metal plug (for radio cable) 1
Instruction manual 1
6
Controls and Functions
Front Panel
MMF EDOOIDARTSA
DRA
0089
｜
○
PPPPOOOOWWWWEEEERRRR
a
BBBBUUUUSSSS
c d
b
a. Power on/off switch
b. TX switch
Press this switch to capture image and send. When the Video Through
Function is activated (AVT command is ON), pressing this switch will
enable output of the video signal connected to the Video Input to be
bypassed to the video output so that you can monitor the video image. Press
this switch again to capture the image and then transmit it through the radio
equipment.
When the Video Through Function is de-activated (AVT command is OFF),
pressing this switch will automatically capture the video image and then
transmit it through the radio equipment.
Refer to : Operation -- Digital Image Communication at page 20 for details.
c. 2 color LED
Illuminated red The unit is in the transmit mode
Blinking red In the digital communication mode, it blinks while
Illuminated Green The unit is in the receive mode
Unlit The unit is in the receive standby mode or in the
d. Status LED (STA LED)
It is lit when unsent data remains in the memory.
It is lit with orange color when Video Through Faction is activated in digital
video communication mode.
It is not lit when Video Through Function is deactivated by the dedicated
command (AVT_OFF) though PC. Because, TX switch activates a sequential
faction of capturing and transmission.
It is also lit with orange color when unsent data is remained in the memory in
the data transmission mode.
SSSSPPPP CCCCHHHHAAAANNNNTTTTXXXX SSSSTTTTAAAA MMMMOOOODDDDEEEE
e
the header information is being sent. (approximately
one (1) second)
analog voice receive mode.
7
6
5
MaxMin
4
3
2
f
11110000111100001111
9
A
B
C
D
E
F
0
1
OOOOVVVVEEEERRRR
h
g
MMMMIIIICCCC
i
j
7
e. Speaker volume adjustment
Adjustment for internal speaker output level. When an external speaker is
connected, external speaker level is also adjusted.
f. Operation Mode LED (3 colors)
Indicates the current operation mode:
Green color Digital Voice mode
Red Color Analog Voice mode
Orange Color Data Communication mode
Not lit Digital Image Communication mode
g. Transmitting channel (Rotary Switch)
It consists of 16 channels. Each channel can be programmed with a
Transmitting ID for distant station, NetMask, etc. Freely programmable
depending on the communications scheme.
h. Overload indicator
Lit when the microphone input is overloaded.
A proper microphone input level will light the LED from time to time when
speaking into the microphone at a normal voice level. The microphone level
can be changed by adjusting the microphone level controller.
Refer to Level Adjustment - Output Level to Radio Transceiver at page16
for details.
i. Mode switch
Select the Digital voice mode (10101) or the Analog voice mode (~) When
the Analog voice mode (~) is selected, ordinary analog voice communications
will be made. In the receive mode, however, the ARD9800 will automatically
detect the mode of the incoming signal and decode signals accordingly. The
LED indicates the appropriate operation mode.
j. Microphone connector
Connect the supplied microphone to this connector. Below are the pin
assignments of the connector.
1. Speaker output (SP-OUT)
Monitor output signal is present at this pin.
2. BIAS
Power source for an electric condenser type of microphone. 5V DC
through 2.2KΩ resistor.
3. GND
Chassis ground
4. TX
Grounding this pin will enable the transmit mode.
(Same operation as the TX switch on the front panel.)
8
5. D/A
Grounding this pin will force the unit to the digital voice
communication mode. When this pin is left open, the operation mode
will be set by the mode switch on the front panel.
6. MIC PTT
PTT (Push To Talk) input.
7. MIC GND
Microphone ground signal
8. MIC IN
Microphone signal input
Rear Panel
AOR,LTD.
VIDEO
IN OUT
RADIO
OUT
SP
IN
+-
DC IN
k
l
m n
o
p q r
k. Communication Connector (mini DIN 8 pin)
A communication connector for PC (RS-232C)
Pin Number Signal Signal Direction
1 TX ARD9800----->PC
2 DTR ARD9800----->PC
3 DSR ARD9800<-----PC
4 GND GND
5 RX ARD9800<-----PC
6 RTS ARD9800----->PC
7 CTS ARD9800<-----PC
8 NC No Connection
Shell FG Frame ground
Baud Rate: 9600bps
Data Length: 8
Start bit: 1
Stop bit: 1
Parity: None
Synchronization: Asynchronous
Flow control: Hardware
9
l. VIDEO - IN connector (75ΩΩΩΩ)
Connect a video signal source such as a digital camera.
m. VIDEO – OUT connector (75ΩΩΩΩ)
Connect a video monitor to this connector to monitor the received image or a
picture to be sent.
n. RADIO Connector
Using the supplied 8 pin connector, connect the ARD9800 to your radio
equipment. You will need to wire a cable according to the microphone
connector specifications of your radio (refer to your radio’s manual).
Below are the pin assignments of the ARD9800 connector.
Pin number Signal Details
1 MIC GND Microphone ground
2 MIC OUT Microphone Output
3 PTT (H) PTT (Push To Talk) output (High level)
4 PTT (L) PTT (Push To Talk) output (Low level)
5 NC No connection
6 NC No connection
7 GND Ground
8 NC No connection
Note: MIC GND and GND must not be connected together in the ARD9800
connector, or RF feedback will result.
o. SP IN Connector (3.5 mm mono jack)
Connect to the radio equipment’s speaker jack. (Input level: 0.5 V – 5 V p-p)
Note: Output signal from the accessory connector of the radio may not be
high enough to use for this purpose.
p. SP OUT Connector (3.5 mm mono jack)
Connect an external speaker to this jack to disable internal speaker.
q. DC IN Connector (EIAJ Type 4)
Connect to a regulated power supply. (10.7 ~ 16.0 V DC, Center pin – positive)
10
For lower voltage battery operation, set the internal jumper terminal for battery
operation, and then connect external batteries.
Warning: If you have changed the internal jumper for low-voltage battery
operation, battery voltage must be within the range of 5.6 ~ 6.5 VDC. DO
NOT apply 12.0 V or severe damage will result, and the warranty will be void!
Note: There is no low battery voltage detector built-into the ARD9800.
r. FG Screw
Frame ground
Top Panel
s. Internal Speaker
Internal View
(PCB design subject
to changes.)
t. Factory setting jumper
Must be set between 2-3. (Do not change this setting at any time.)
s
11
v. Battery operation selector
Place the jumper between 1 – 2 (NOR) for normal operation. Change it
between 2-3 (BATT) for battery operation.
Warning: If you have changed the internal jumper for low-voltage battery
operation, battery voltage must be within the range of 5.6 ~ 6.5 VDC. DO NOT
apply 12.0V or severe damage will result, and the warranty will be void!
Note: There is no low battery voltage detector built-into the ARD9800.
w. Internal speaker setting
Jumper setting
1 – 2 Activates internal speaker (default)
2 -- 3 Disable internal speaker
Speaker output is available from the pin #1 of the microphone
Connector.
Note: The SP OUT (external speaker output) has priority regardless of the
above jumper setting.
x. Output level setting
Jumper setting
1 – 2 Normal level (default) (LOW)
2 – 3 High level (HIGH)
In case the microphone output level is too low to drive your radio
equipment, place the jumper to the 2-3 position.
Refer to Presetting - Microphone Level at page 16 for details.
Bottom View
y. Output Level Adjustment
Refer to Presetting - Output level to Radio Transceiver at page 15 for
details
y
12
Interfacing the ARD9800
Connection to a Radio
Before using your ARD9800, you will first need to wire the cable between your radio
equipment and the ARD9800.
For your convenience, an 8-pin of a microphone connector for the ARD9800 is included.
You will need to prepare, however, your own microphone connector for your radio
equipment.
Below are the pin assignments of the 8-pin RADIO connector on the rear panel of the
ARD9800.
Pin number Signal Details
1 MIC GND Microphone ground
2 MIC OUT Microphone Output
3 PTT (H) PTT (Push To Talk) Output (H level)
4 PTT (L) PTT (Push To Talk) Output (Low level)
5 NC No connection
6 NC No connection
7 GND Ground
8 NC No connection
Note: MIC GND and GND must not be connected together in the
ARD9800 connector, or RF feedback will result.
Both a microphone plug and a cable for your radio transceiver are required to be
prepared at the user side.
13
Connection to a Microphone
A speaker microphone is included with your ARD9800. However, if you wish to use
your own microphone with the ARD9800, you may do so by wiring your microphone
to the ARD9800. Below are the pin assignments of the microphone connector of the
ARD9800.
1. SP-OUT (Speaker output)
Monitor output signal is present at this pin.
2. BIAS
Power source for an electric condenser type microphone.
5V DC through 2.2KΩ resistor
3. GND
Chassis ground
4. TX
Grounding this pin will allow to transmit .
(Same operation of the TX switch on the front panel.)
5. D/A
Grounding this pin will force the ARD9800 to the Digital
voice communication mode. When this pin is left open, the
operation mode will be set by the mode switch on the front
panel.
6. MIC PTT
PTT (Push To Talk) input.
7. MIC GND
Microphone ground signal
8. MIC IN
Microphone signal input
Connection to a PC
A PC interface cable is included with the ARD9800. Parameter settings can be made
by using terminal software.
Refer to Control Commands at page 22 for details
Connection to a Power Supply
To operate your ARD9800, use a regulated power supply. The operating voltage must
be within the range of 10.7 ~ 16.0 V DC (approximately 200mA).
A DC power cable is also included with the ARD9800.
Color Polarity
RED Positive (+)
BLACK Negative ( - )
14
Refer to Internal View: Battery operation at page 11 for details
Warning: If you have changed the internal jumper for low-voltage battery operation,
supplied voltage must be within the range of 5.6 ~ 6.5 VDC. DO NOT apply 12.0 V or
severe damage will result, and the warranty will be void!
Note: There is no low battery voltage detector built-into the ARD9800.
.
Connection to an External Speaker
If an external speaker is desired, connect it to the SP OUT jack. This will also disable
the internal speaker.
15
Presetting
Output Level to Radio Transceiver
This level has to be supplied properly to the radio transceiver for operation.
1. Connect the supplied hand microphone to the ARD9800 first. Then connect
your radio to the RADIO terminal on the ARD9800 by using your prepared
connection cable certainly. Turn ON the ARD9800.
2. Make sure that the output level adjusting volume (y) is set to minimum.
3. Select the mode switch (i) to [10101] position as digital.
4. Press PTT switch on the supplied hand microphone.
5. Adjust microphone gain control on the radio transceiver to suitable level.
Particularly, it is recommended to adjust the level that activates ALC function.
If the ALC function activates too much, it might create audio distortion. As a
result, the communication with a distant station might be compromised.
6. Adjust the output level located on the bottom side of the ARD9800 when the
microphone gain control on the radio transceiver does not adjust for sufficient
level.
7. If the microphone gain is still not enough even though you proceeded as per
step (6.), turn OFF the ARD9800 first and go to step (8).
8. Remove the upper cover of the ARD9800 and locate the jumper pin for Output
level setting. Change the jumper pin (The default is inserted between 1-2) to 23 for high level. Put the cover back into place.
Proceed again with steps 1 to 6.
9. If the microphone gain is still not enough, set the ATT command to OFF with a
terminal software . Then try again steps 1 to 6.
16
Microphone Level
The microphone level has been properly adjusted at the factory with the provided
microphone. Therefore, no further adjustment is needed for normal operation.
If you wish to use your own microphone, you will need to wire your microphone
connector to match the pins of the ARD9800, and then adjust the microphone level as
described in the following steps:
1. Connect your microphone to the Microphone connector on the ARD9800.
(Note: The microphone cable to the radio MUST be unplugged at this time.)
2. Select the mode switch (i) to [10101] position as digital.
3. Select [0=zero] of transmitting channel [CHAN].
4. Turn ON the ARD9800 while pressing the TX switch. It will be blinked Status
LED with orange color. It indicates the ARD9800 is now placed into
microphone level adjusting mode.
5. You can speak into a microphone by pressing PTT button. Rotate the
transmitting channel [CHAN] to clockwise until the [OVER] LED is lit in
some times synchronizing to the speaking level.
6. After you recognize the suitable microphone level at the above stage, press TX
switch while pressing PTT button. The TX LED will be lit in orange color and
it is now memorized this new setting value in digital mode.
7. Release the PTT button and select Mode switch to analog (~) position.
8. The microphone level adjustment in Analog mode is normally not required.
Then press TX switch while pressing PTT button.
However, if audio signal level is weak at the distant station, you can take same
process from 1 to 4 as above even though it is for analog mode. And press TX
switch while pressing PTT button to confirm with the new setting value.
9. Turn the power OFF of the ARD9800 to terminate the microphone level
adjusting mode.
17
User ID Setting
The ARD9800 provides a function of user ID that allows assigning an own identifying
number. In operation with digital mode, you can assign the ID number for the specified
destination’s station along with NETMASK (Group Code) and SQUELCH (DCS)
functions together. This function is only effective in digital mode.
TX Channel Setting
The ARD9800 provides 16 channels (A~F, 0~9). You can assign each channel for ID,
NETMASK and SQUELCH parameters individually. Depending on scene your
communications, you can select the channel number. Take following steps to perform the
channel setting.
1. Connect the supplied PC interface cable between ARD9800 and PC.
2. Set up terminal software on your PC.
3. Select the TX channel [CHAN] where you want to assign the ID, NETMASK
and SQUELCH parameters.
4. In the command prompt of the terminal software, type ACP<CR>.
For example,
cmd>ACP<CR>
CH:A_ID:BBBBB_NM:CCCCC_MD:D
cmd>
<CR> Carriage Return to confirm the command entry.
A Channel number that you selected [CHAN] switch.
_ Space
BBBBB Destination ID. You can only assign the number
of 00000 to 99999.
CCCCC Assign the NETMARK activity. You can only select 0
(=zero) or 1.
1= Activate
0= Deactivate
Note that 1 indicates as F on the terminal software.
D Activate or Deactivate Digital Squelch function.
1= Activate
0= Deactivate
18
Communication pattern
Tx 1 Rx 1
ID:12345 UID:12345
NM:FFF00 MD:1
MD:1
Tx2 Rx 2
ID:12345 UID:12355
NM:FFFF0 MD:1
MD:1
Tx3 Rx3
ID:12345 UID:12348
NM:FFFFF MD:1
MD:1
Tx4 Rx4
ID:12345 UID:13345
NM:FFFFF MD:1
MD:0
Rx5
UID:12345
MD:0
Note: All adjustments must be properly performed before operation.
19
Operation
Voice Communication
Your ARD9800 is capable of Digital Voice Communications and Analog Voice
Communication. In the receive mode, the ARD9800 will automatically recognize
the type of communication, and set the appropriate operation mode.
In the transmit mode, the operation mode can be selected by using the front Mode
switch.
Digital Voice Communication
Set the mode switch [10101 - ~] upward to the digital mode position. [10101]
Press and hold the PTT switch of the microphone. The STA (Status) LED will flash
for about 0ne (1) second while sending a data header signal. When the LED stops
flashing, speak into the microphone normally.
Analog Voice Communication
Set the mode switch [10101 - ~ ] downward to the analog mode position. [~]
Press and hold the PTT switch of the microphone, and speak into the microphone
normally.
Data Communication
Run a terminal software program to control the ARD9800, and to enter control
commands.
Refer to Control Commands at page 22 for details
Two different types of data, ASCII data or binary data, can be used.
Both data can be mixed as communication data.
Receive
Enter the command [ACO] to go into the converse mode.
The received valid data will be decoded and displayed on the PC screen.
If received data is missing, (which may occur during poor propagation conditions)
“garbage” data may be displayed on the PC screen.
Transmit
Enter the command [ACO] to go into the converse mode. Type text from the
keyboard, then hit the enter key at the end of the text.
NNNNNNNN [CR]
NNNNNNNN ASCII character
[CR] Carriage Return
Note: The maximum data length is 2046 bytes per packet.
20
To send binary data, add [FE] (hexadecimal) to a header and footer with the data.
FE BBBBBBBBBBBBBBBB FE
BBBBBBBBBBBBBBB Binary data
FE ID as a binary data
Note: If you need to insert the data [FE] in hexadecimal in the middle of the
text, convert it into two (2) bytes of hexadecimal data.
FE FDD8
If you need to insert the data [FD] in hexadecimal in the middle of the text,
convert it into two (2) bytes of hexadecimal data.
FD FDDD
Note: The maximum data length is 2046 bytes per packet.
At the receive side, the data will be automatically decoded and displayed on
the PC screen. If the [ALF] command is set ON, the LF (line feed) code will
be added at the end of received data.
Digital Image Communication
Receive
When valid digital image data is received, it will be decoded and output as a
video image from the VIDEO OUT connector.
If received data is missing during a transmission, that portion will be displayed
as invalid (like noise).
Transmit
Push the TX switch to send the image.
(When pin - 4 of the microphone connector is grounded, the ARD9800 starts
sending the image.)
Note: When the Video Through Function is activated (AVT command is ON=
default), pressing the TX switch will enable output of the video signal connected
to the Video Input to also be sent to the video output, so that you can monitor the
video image. Press the TX switch again to capture the image and then transmit it
through the radio equipment.
When the Video Through Function is de-activated (AVT command is OFF),
pressing the TX switch will automatically capture the video image and then
transmit it through the radio equipment.
The Progress indicator will display on the monitor during image transmission.
21
Specifications
Modulation
Method
OFD Bandwidth: 300 Hz ~ 2.5 KHz, 36 carriers
Symbol Rate 20 mS (50 Baud)
Guard Interval 4 mS
Tone Space 62.5 Hz
Individual Tone
36 carrier: DQPSK(3.6K)
Modulation
Method
Auto
+/- 125 Hz
Frequency
Offset
Error
Correction
Data: Reed Solomon + Vitabi Decoder
Voice: Golay + Hamming
Header 1 second, 3 tone + BPSK training pattern for synchronization
Digital Audio AMBE ® 2020 Coder/Decoder
Mode
Selection
Receive: Automatic selection
Transmit:
Data communication mode: Automatic exchange according to TX
request from PC
Digital voice mode: Manual select by the mode switch
Digital Image mode: Manual select by pressing the TX switch
Analog voice mode: Manual select by the mode switch
Video
AOR original JPEG format
Compression
Video
NTSC or PAL depending on version
Input/output
Power
Requirement
10.7 ~ 16 V DC (Approximately 200 mA @ 12 V DC)
6.0 V DC with battery operation ( 5.6 ~ 6.5 V DC)
Communication RS-232C Asynchronous, 9600 bps (setting / data)
115.2 kbps (image)
I/O Connectors Microphone: 8 – pin metal
Radio: 8 – pin metal
PC interface: Mini 8 – pin DIN
Video In/Out: RCA
Speaker In/Out: 3.5 mm mono jack
Power: EIAJ type 4
Dimension 100 (w) x 32 (h) x 156 (d) (mm)
4 (w) x 1.3 (h) x 6.2 (d) (inch)
Projections not included
Weight: Approximately 600 g (1 lb – 5 oz)
Specifications subject to change without prior notice for product improvement or modification.
22
Control Commands
Interfacing to a PC
Using the supplied PC interface cable, connect one end to the COM connector at the
rear panel (marked as [10101] ) and the other to the serial port of a PC.
NOTE: Make sure that your PC’s serial port is active. Check for correct hardware
and software settings!
Below are the pin assignments of the COM connector of the ARD9800.
ARD9800 COM connector Serial connector to the PC (D-Sub 9 – pin)
Pin # Pin #
1 -------------------------- 2
2 -------------------------- 6
3 -------------------------- 4
4 -------------------------- 5
5 -------------------------- 3
6 -------------------------- 8
7 -------------------------- 7
8 -------------------------- 1
GND -------------------------- GND
Terminal Settings
Communication Speed: 9600 bps
Data Length: 8 bit
Start Bit: 1
Stop Bit: 1
Parity: None
Flow Control: Hardware
Local Echo: None
Specifications: RS-232C compatible
23
Command Format
Run a terminal software program, and then turn on the power to the
ARD9800. The following message should appear on the PC screen:
cmd>
This indicates the ARD9800 is ready to accept commands from the PC.
Each command consists of three (3) alphabetical characters.
cmd>CCC_NN [CR]
CCC: Command (Must be a capital letter)
_: Space
NN: Parameter
[CR]: Carriage Return
Entering a command without a parameter will display the current parameter
(value) setting.
cmd>CCC[CR]
If an invalid parameter or command is entered, the ARD9800 will respond as
follows:
cmd>
?
cmd>
24
Command List
Comman
Function
d
AAQ Send VIDEO In signal to VIDEO OUT (to a monitor screen)
Capture image into memory of the ARD9800
ACO Enter the Converse mode
ACP TX channel settings
ADC List the current commands
ADS Display current settings
AFC Activate AFC (Automatic Frequency control) function
AHL Set the duration of the synchronization header
ALF Add the LF (Line Feed) code at the end of the CR code
ARA Monitor both digital/analog voice signal or monitor digital voice only
ATT Select output level for the radio equipment
ATX Send digital image
AVT Activate the Video through function when capturing an image
AVR Display the current firmware version
25
Command details
AAQ
Function Send VIDEO In signal to VIDEO OUT port (to the monitor screen)
Capture image into memory of the ARD9800
Default None
Format AAQ {0 / 1} [CR]
Parameter 1: Send VIDEO In signal to a VIDEO OUT (to the monitor screen)
0: Capture image into memory of the ARD9800
Details While AVT command is OFF, [AAQ 0] will be accepted.
Entering AAQ[CR] will respond with the current status.
AAQ ON --- Video signal is passed to the VIDEO OUT port
AAQ OFF ---- Video signal is not passed to VIDEO OUT port
Example AAQ_0 [CR]
ACO
Function Change from the Command mode to the Converse mode
Default None
Format ACO [CR]
Parameter None
Details Change from the Command mode (while cmd> appears on the PC
screen) into the Converse mode.
In the Converse mode, data from the PC keyboard can be sent.
To return to the Command mode, enter [Ctrl – C] (holding the
Control key while entering the C.)
Example ACO [CR]
26
ACP
Function Assign parameters on each TX channel
Default CH:* ID:00000 NM:00000 MD:0
Format ADC_ [00000-99999][CR]
Parameter 00000 – 99999
(No other figures are acceptable.)
Place: 1/0
(No other figures are acceptable)
0----- Deactivate
1----- Activate
NM----- NetMask
MD----- Digital Squelch
Details The ARD9800 provides a function of user ID that allows assigning
an own identified number. In operation with digital mode, you can
assign the ID number for the specified destination’s station along
with NETMASK (Group Code) and SQUELCH (DCS) functions
together. This function is only effective in digital mode.
The ARD9800 provides 16 channels (A~F, 0~9). You can assign
each channel for ID, NETMASK and SQUELCH parameters
individually. Depending on your communications scheme, you can
select the channel number.
Example In case of scene as:
Channel: 8
Destination ID :12345
Netmask: 11100
Squelch: 1 (= activate)
ACP_12345_11100_1[CR]
ADC
Function List the current commands
Default None
Format ADC [CR]
Parameter None
Details Lists the current commands
Example ADC [CR]
27
ADS
Function Display current settings
Default Headerlen : 1.00
AFC = ON
Analog : ON
Format ADS [CR]
Parameter None
Details Displays the current parameter settings
Example ADS [CR]
AFC
Function Activate AFC (Automatic Frequency control) function
Default On
Format AFC {ON/OFF} [CR]
Parameter ON: Activates the AFC function
OFF: Deactivates the AFC function
Details Must be set to ON for the SSB mode
Set to OFF for the FM mode
Example AFC_ON [CR]
AHL
Function Set the duration of the synchronization header
Default 100 (1 second)
Format AHL {050 – 198} [CR]
Parameter 050 – 198 (0.02 incremental)
Details Sets the duration of the synchronization header
{100} represents 1.00 second.
Example AFC_146 [CR] Set duration to 1.46 seconds.
ALF
Function Add the LF (Line Feed) code at the end of the CR code
Default ON
Format ALF {ON/OFF} [CR]
Parameter ON : Add the LF code at the end of the CR code
OFF : The LF will not be added to the end of the CR code
Details When this command is set to ON, it facilitates the entry of new data
from the transmit terminal, as a new line is automatically started
(and the previous line is automatically sent).
Example ALF_ON [CR]
28
ARA
Function Monitor both digital/analog voice signals or monitor digital voice
only
Default ON
Format ARA_ {ON/OFF} [CR]
Parameter ON : Monitor digital voice and Analog voice
OFF : Monitor Digital voice only
Details Monitor both digital/analog voice signal or monitor digital voice
only
Example ARA_ON [CR]
ATT
Function Selects the output level to the radio equipment
Default ON
Format ATT_ {ON/OFF} [CR]
Parameter ON : Lower level
OFF : Higher level
Details Selects the output level to the radio equipment
Example ATT_ON [CR]
ATX
Function Send digital image
Default None
Format ATX [CR]
Parameter None
Details An image must be captured and stored into memory before it can be
sent.
Example ATX [CR]
AVT
Function Activate the Video through function when capturing an image
Default ON
Format AVT_ {ON/OFF} [CR]
Parameter ON : Activate the Video through function
OFF : Deactivate the Video through function
Details When the AVT command is ON, pressing the TX switch will enable
output of the video signal connected to the Video Input to be passed
to the video output port so that you can monitor the video image.
Press the TX switch again to capture the image and then transmit it
through the radio equipment.
When the AVT command is OFF, pressing the TX switch will
automatically capture the video image and then transmit it through
the radio equipment.
Example AVT_ON [CR]
29
AVR
Function Display the current firmware version
Default None
Format AVR [CR]
Parameter None
Details Displays the current firmware version
Example AVR [CR]
30
Manufacturer: AOR, LTD.
2-6-4, Misuji, Taito-Ku,
Tokyo, 111-0055, Japan
URL: www.aorja.com
US distributor: AOR USA, INC.
20655 S. Western Ave. Suite 112
Torrance, CA 90501
Phone: 310-787-8615
Fax: 310-787-8619
URL: www.aorusa.com
e-mail: info@aorusa.com
April 17, 2013
Printed in Japan
Loading...
