AOC Q2577FQ, Q2577PQU, U3477PQU User Manual

LCD Monitor User Manual

Q2577FQ

Q2577PQU/U3477PQU

LED backlight

www.aoc.com

Safety ........................................................................................................................................................................

National Conventions .........................................................................................................................................

Power ................................................................................................................................................................

Installation ..........................................................................................................................................................

Cleaning ............................................................................................................................................................

Other ..................................................................................................................................................................

Setup ........................................................................................................................................................................

Contents in Box .................................................................................................................................................

Setup Base ......................................................................................................................................................

Wall Mounting ..................................................................................................................................................

Adjusting Viewing Angle ..................................................................................................................................

Using "MHL(Mobile High-Definition Link)".......................................................................................................

Connecting the Monitor ...................................................................................................................................

Adjusting ................................................................................................................................................................

Setting Optimal Resolution .............................................................................................................................

Windows 8 ...............................................................................................................................................

Windows 7 ...............................................................................................................................................

Windows Vista .........................................................................................................................................

Windows XP... .........................................................................................................................................

Windows ME/2000 ....................................................................................................................................

Hotkeys ...........................................................................................................................................................

OSD Setting ....................................................................................................................................................

Luminance ...............................................................................................................................................

Image Setup ............................................................................................................................................

Color Setup ..............................................................................................................................................

Picture Boost ...........................................................................................................................................

OSD Setup ..............................................................................................................................................

PIP Setting ...............................................................................................................................................

Extra ........................................................................................................................................................

Exit ..........................................................................................................................................................

LED Indicator ..................................................................................................................................................

Driver .....................................................................................................................................................................

Monitor Driver .................................................................................................................................................

Windows 8 ...............................................................................................................................................

Windows 7 ...............................................................................................................................................

Windows Vista .........................................................................................................................................

Windows XP... .........................................................................................................................................

Windows 2000 .........................................................................................................................................

Windows ME .............................................................................................................................................

i-Menu ..............................................................................................................................................................

e-Saver ............................................................................................................................................................

Screen+ ...........................................................................................................................................................

Troubleshoot ...........................................................................................................................................................

Specification ............................................................................................................................................................

General Specification .......................................................................................................................................

Preset Display Modes ......................................................................................................................................

Pin Assignments ..............................................................................................................................................

61 61

4 4 5 6 7 8 9 9 10 12 13 14 15 19 19 19 21

27 29 30 31 32 33 34 35 36 37 38 39 39 39 43 47

55 56 57 58 59

63 66

Plug and Play ...................................................................................................................................................

Regulation ...............................................................................................................................................................

FCC Notice ......................................................................................................................................................

WEEE Declaration ...........................................................................................................................................

WEEE Declaration for India .............................................................................................................................

EPA Energy Star ..............................................................................................................................................

EPEAT Declaration ..........................................................................................................................................

Service ....................................................................................................................................................................

Warranty Statement for Europe ........................................................................................................................

Warranty Statement for Middle East and Africa (MEA) ....................................................................................

AOC International (Europe) B.V. ......................................................................................................................

Warranty Statement for North & South America (excluding Brazil) ...........................................................

EASE PROGRAME .........................................................................................................................................

TCO DOCUMENT ...........................................................................................................................................

69 70 70 70 71

68 69

72 72 74 76 77 79

Safety

National Conventions

The following subsections describe notational conventions used in this document.

Notes, Cautions, and Warnings

Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows:

NOTE: A NOTE indicates important information that helps you make better use of your computer system.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the

problem.

WARNING: A WARNING indicates the potential for bodily harm and tells you how to avoid the problem. Some warnings may appear in alternate formats and may be unaccompanied by an icon. In such cases, the specific presentation of the warning is mandated by regulatory authority.

Power

The monitor should be operated only from the type of power source indicated on the label. If you are not sure

of the type of power supplied to your home, consult your dealer or local power company.

The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of the grounded plug.

Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the monitor from damage due to power surges.

Do not overload power strips and extension cords. Overloading can result in fire or electric shock.

The wall socket shall be installed near the equipment and shall be easily accessible.

Factory:

Q2577PQU  SHENZHENHONORELECTRONICCO.,LTD. Model：ADS‐110DL‐19‐1190090G



Q2577FQ TPVELECTRONICS(FUJIAN)CO.,LTDModel：ADPC1965

SHENZHENHONORELECTRONICCO.,LTD.Model:ADS‐65LSI‐19‐119065G



Installation

Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and use mounting accessories recommended by the manufacturer. A product and cart combination should be moved with care.

Never push any object into the slot on the monitor cabinet. It could damage circuit parts causing a fire or electric shock. Never spill liquids on the monitor.

Do not place the front of the product on the floor.

If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit instructions.

Leave some space around the monitor as shown below. Otherwise, air-circulation may be inadequate hence overheating may cause a fire or damage to the monitor.

See below the recommended ventilation areas around the monitor when the monitor is installed on the wall or with the stand: Installed on the wall

Installed with stand

Cleaning

Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet.

When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface.

Please disconnect the power cord before cleaning the product.

Other

If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center.

Make sure that the ventilating openings are not blocked by a table or curtain.

Do not engage the LCD monitor in severe vibration or high impact conditions during operation.

Do not knock or drop the monitor during operation or transportation.

For display with glossy bezel the user should consider the placement of the display as the bezel may cause

disturbing reflections from surrounding light and bright surfaces.

Setup

Contents in Box

Monitor

CD Manual Base Power Cable

Audio Dual link DVI Analog Cable DP HDMI USB MHL

Not all signal cables (Audio, Dual link DVI, Analog, DP, HDMI, MHL and USB cables) will be provided for all

countries and regions. Please check with the local dealer or AOC branch office for confirmation.

Setup Stand & Base

Please setup or remove the base following the steps as below. Please place the monitor on a soft and flat surface to prevent the scratch. Q2577PQU/U3477PQU Setup:

Remove:

Setup Stand

Please setup or remove the Stand following the steps as below.

Q2577FQ

Setup

Remove:

Wall Mounting

Preparing to install an optional wall mount arm. Q2577PQU/U3477PQU

Q2577FQ

This monitor can be attached to a wall mounting arm you purchase separately. Disconnect power before this procedure. Follow these steps:

1. Remove the base.

2. Follow the manufacturer's instructions to assemble the wall mounting arm.

3. Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the holes in the back of the monitor.

4. Insert the 4 screws into the holes and tighten.

5. Reconnect the cables. Refer to the user's manual that came with the optional wall mounting arm for instructions on attaching it to the wall.

Noted: VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC.

Adjusting Viewing Angle

For optimal viewing, it is recommended to look at the full face of the monitor, and then adjust the monitor's angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor's angle.

Q2577PQU/U3477PQU

You are able to adjust the monitor's angle from -5° to 24 °.

Q2577FQ

You are able to adjust the monitor's angle from -3° to 24 °.

NOTE:

Do not adjust the viewing angle over 24 degrees in order to avoid damage.

Using "MHL(Mobile High-Definition Link)"

1."MHL" (Mobile High-Definition Link)

This feature allows you to enjoy videos and photos (imported from a connected mobile device that supports MHL) on the screenof the product. z To use the MHL function, you need an MHL-certified mobile device. You can check if your mobile device is

MHL certified on the device manufacturer's website. To find a list of MHL-certified devices, visit the official MHL website (http://www.mhlconsortium.org).

z To use the MHL function, the latest version of software must be installed on the mobile device. z On some mobile devices, the MHL function may not be available depending on the device's performance or

functionality.

z Since the display size of the product is larger than those of mobile devices, the picture quality may degrade. z This product is officially MHL-certified. If you encounter any problem when using the MHL function, please

contact the manufacturer of the mobile device.

z The picture quality may degrade when content (imported from the mobile device) with a low Resolution is

played on the product.

Using "MHL"

1. Connect the micro USB port on the mobile device to the [HDMI / MHL] port on the product using the MHL cable.

z When the MHL cable is used, [HDMI / MHL] is the only port on this monitor that supports the MHL function. z Mobile device must be purchased separately.

2. Connect the AC power cord to the product and a power outlet.

3. Press the source button

4. After about 3 seconds, the MHL screen will be displayed if MHL mode is active. Remark: The indicated time "3 sec later" may vary depending on the mobile device.

When the mobile device is not connected or does not support MHL

z If MHL mode is not activated even though the mobile device supports MHL, check if mobile device MHL port is

MHL standard port otherwise an additional MHL-enabled adapter is required.

and switch to HDMI /MHL to activate MHL mode.

Connecting the Monitor

Q2577PQU

Cable Connections In Back of Monitor and Computer:

DVI

MHL-HDMI

Display port

Analog (D-Sub 15-Pin VGA cable)

Earphone out

AUDIO IN

USB 3.0+ fast charging

USB 3.0

USB input

9 10

Power

To protect equipment, always turn off the PC and LCD monitor before connecting. 1 Connect the power cable to the AC port on the back of the monitor. 2 Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the

computer's D-Sub port.

3 Optional – (Requires a video card with DVI port) – Connect one end of the DVI cable to the back of the monitor

and connect the other end to the computer’s DVI port.

4 Optional – (Requires a video card with HDMI port) – Connect one end of the HDMI cable to the back of the

monitor and connect the other end to the computer’s HDMI port.

5 Optional – (Requires a video card with DP port) – Connect one end of the DP cable to the back of the monitor

and connect the other end to the computer’s DP port.

6 Turn on your monitor and computer. 7 Video content supporting resolution:

(1) VGA: (2) (3)

(4)

If your monitor displays an image, installation is complete. If it does not display an image, please refer

2560 x 1080/60Hz (Maximum)

DVI Dual-Link: 2560 x 1080/60Hz (Maximum)

HDMI: 2560 x 1080/60Hz (Maximum) DP: 2560 x 1080/60Hz (Maximum)

Troubleshooting.

Connecting the Monitor

Q2577FQ

Cable Connections In Back of Monitor and Computer:

DVI

MHL-HDMI

Display port

Analog (D-Sub 15-Pin VGA cable)

Earphone out

AUDIO IN

6 7

Power

computer's D-Sub port.

3 Optional – (Requires a video card with DVI port) – Connect one end of the DVI cable to the back of the monitor

and connect the other end to the computer’s DVI port.

4 Optional – (Requires a video card with HDMI port) – Connect one end of the HDMI cable to the back of the

monitor and connect the other end to the computer’s HDMI port.

5 Optional – (Requires a video card with DP port) – Connect one end of the DP cable to the back of the monitor

and connect the other end to the computer’s DP port.

6 Turn on your monitor and computer. 7 Video content supporting resolution:

(1) VGA: (2) (3)

(4)

If your monitor displays an image, installation is complete. If it does not display an image, please refer

2560 x 1080/60Hz (Maximum)

DVI Dual-Link: 2560 x 1080/60Hz (Maximum) HDMI: 2560 x 1080/60Hz (Maximum)

DP: 2560 x 1080/60Hz (Maximum)

Troubleshooting.

Connecting the Monitor

U3477PQU

Cable Connections In Back of Monitor and Computer:

2 3

4 5

1 USB 2.0 2 USB 2.0 3 USB 3.0+ fast charging 4 USB 3.0 5 USB input 6 Power 7 DVI 8 MHL-HDMI 9 Display port 10 Analog (D-Sub 15-Pin VGA cable) 11 Earphone out 12 AUDIO IN

RS232

computer's D-Sub port.

3 Optional – (Requires a video card with DVI port) – Connect one end of the DVI cable to the back of the monitor

and connect the other end to the computer’s DVI port.

4 Optional – (Requires a video card with HDMI port) – Connect one end of the HDMI cable to the back of the

monitor and connect the other end to the computer’s HDMI port.

5 Optional – (Requires a video card with DP port) – Connect one end of the DP cable to the back of the monitor

and connect the other end to the computer’s DP port. 6 Turn on your monitor and computer. 7 Video content supporting resolution:

(1) VGA: (Maximum) (2) (3) (4)

2560 x 1080/60Hz

DVI Dual-Link: 3440 x 1440/30Hz (Maximum) HDMI: 3440 x 1440/30Hz (Maximum) DP: 3440 x 1440/60Hz (Maximum)

If your monitor displays an image, installation is complete. If it does not display an image, please refer Troubleshooting.

Adjusting

Setting Optimal Resolution

Windows 8

For Windows 8:

1. Right click and click All apps at the bottom-right of the screen.

2. Set the “View by” to “Category”.

3. Click Appearance and Personalization.

4. Click DISPLAY.

5. SettheresolutionSLIDE-BARtoOptimalpresetresolution

Windows 7

For Windows 7:

1.1.

Click START.

2.2.

Click CONTROL PANEL.

3.3.

Click APPEARANCE.

4.4.

Click DISPLAY.

5. Set the resolution SLIDE-BAR to Optimal preset resolution.

Windows Vista

For Windows Vista:

1 Click START. 2 Click CONTROL PANEL.

3 Click Appearance and Personalization.

4 Click Personalization

5 Click Display Settings.

6 Set the resolution SLIDE-BAR to Optimal preset resolution

+ 56 hidden pages
