AOC L22DK99U, L26DK99U, L32DK99U User Manual

1
This manual provides as an operational guide to user. All statements, technical information, and recommendations in this manual and in any guides or related documents are believed reliable, but the accuracy and completeness thereof are not guaranteed or warranted, and they are not intended to be, nor should they be understood to be, representations or warranties concerning the products described.
1
Table of Content
IMPORTANT INFORMATION .................................................................................................................... 3
WARNING ................................................................................................................................................ 3
CAUTION ................................................................................................................................................. 3
IMPORTANT SAFETY INFORMATION ..................................................................................................... 3
USAGE INSTRUCTIONS .......................................................................................................................... 4
Installation ................................................................................................................................................ 4
AC Power Cable ...................................................................................................................................... 4
LCD Screen ............................................................................................................................................. 5
Wiring ....................................................................................................................................................... 5
Electric Shock .......................................................................................................................................... 5
Lightning Storms ...................................................................................................................................... 6
When Not in Use ...................................................................................................................................... 6
Overloading ............................................................................................................................................. 6
Optional Equipment ................................................................................................................................. 6
Small Accessories.................................................................................................................................... 6
Antennas .................................................................................................................................................. 6
Batteries ................................................................................................................................................... 6
Cleaning ................................................................................................................................................... 7
Magnetic Influence .................................................................................................................................. 7
Sound ....................................................................................................................................................... 7
Carrying the TV ........................................................................................................................................ 7
Ventilation ................................................................................................................................................ 7
Moisture ................................................................................................................................................... 8
Volume Adjustment .................................................................................................................................. 8
Servicing .................................................................................................................................................. 8
CONTENTS IN THE BOX .......................................................................................................................... 9
CONTROLS & CONNECTIONS: ............................................................................................................ 11
Remote control ...................................................................................................................................... 12
OPTION MENU DESCRIPTION .............................................................................................................. 14
CONNECTING TV .................................................................................................................................... 15
Cable System or Antenna System ......................................................................................................... 15
High Definition Interface ........................................................................................................................ 15
HDMI Connection .................................................................................................................................. 15
Component Signal Connection .............................................................................................................. 16
PC Connection ....................................................................................................................................... 16
Composite Signal Connection ............................................................................................................... 17
USING AOC TV........................................................................................................................................ 18
Out Of Box Setting ................................................................................................................................. 19
Input Source selection ........................................................................................................................... 20
Picture Setting ....................................................................................................................................... 21
Audio Setting ......................................................................................................................................... 23
Features Setting .................................................................................................................................... 24
Installation Setting ................................................................................................................................. 26
Manual Search Description ................................................................................................................... 27
Multimedia (USB) Setting ...................................................................................................................... 28
PRODUCT INFORMATION ..................................................................................................................... 31
PRODUCT SPECIFICATION ................................................................................................................... 32
TROUBLE SHOOTING ............................................................................................................................ 37
2
Important Information
WARNING
This symbol is intended to alert the user to the presence of insinuated “dangerous voltage” within the TV’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the TV.
To reduce the risk of fire or electric shock, do not expose this TV to rain or moisture, and no objects filled with liquids, such as vases, shall be placed on the TV.
CAUTION
To prevent electric shock, do not use this polarized AC plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure.
Use the Wall-Mount bracket or TV stand which was recommended by AOC, and please consult your dealer for detailed information.
Use with other Wall-Mount Bracket or TV stand may cause instability and possibly result in injury.
Disposal of your old product Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.
Important Safety Information
1 Read and keep these instructions. 2 Heed all warnings. 3 Follow all safety instructions. 4 Operate the TV only on suitable power input.
5 Do not install the TV in a hot or humid place, or in a place subject to excessive dust or mechanical
vibration.
6 Do not block any ventilation openings to prevent internal heat buildup. Install in accordance with the
manufacturer’s instructions.
7
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
3
Usage Instructions
Installation
Placement
It is recommended to watch the TV at a distance of 3 -7 times which of the screen height, and in moderate brightness. Watching the TV for too long or in a dark room may cause eye fatigue. To obtain a clear picture, do not expose the screen to direct illumination or direct sunlight. It is recommended to use spot lighting directed down from the ceiling or to cover the windows that face the screen with opaque drapery. It is desirable to install the TV in a room where the floor and walls are not of a reflective material.
To prevent the TV from toppling over and causing injury, take measurement to secure the TV to a wall or stand.
The TV should be installed near an easily accessible AC power outlet.
Observe the following in placing the TV. Otherwise the TV may fall from the stand or Wall-Mount, causing damage or serious injury.
Place the TV on a stable, level surface. Do not hang anything on the TV. Do not allow children
to climb on the TV.
Do not install the TV in places subject to extreme
temperatures, such as in direct sunlight, near a radiator, or near a heating vent or exposed to direct air conditioning.
Never place the TV in hot, oily, humidor excessively
dusty places.
Do not install the TV where insects may enter. Do not install the TV where it may be exposed to
mechanical vibration.
Do not install the TV in a location where it may
protrude, such as on or behind a pillar, or where you might bump your head on it. Otherwise, it may result in injury.
Outdoor Use
Do not install this TV outdoors. If the TV is exposed to rain, it may result in a fire or an electric shock. Do not expose the TV to direct sunlight, it may heat up and become damaged.
Vehicle, Ships and Other Vessels
Do not install this TV in a vehicle. Bumping of the vehicle may cause the TV to fall down
and cause injury.
Do not install this TV in a ship or vessel. If the TV is
exposed to seawater, it may cause a fire or damage the TV.
Medical institutions
Do not place this TV in a place where medical
equipment is in use.
The interference may cause a malfunction of both TV
and the medical equipment.
Attachments
Do not use attachments not recommended by the manufacturer, as they may cause hazards.
Wall-Mount
Wall-Mount installation requires the use of a Wall-Mount Bracket. When installing or removing the TV, using a Wall-Mount Bracket, be sure to use qualified contractors. If not properly secured during installation or removal from the Wall-Mount Bracket, the TV may fall and cause serious injury. Observe the following when installing the TV using a Wall-Mount bracket.
Be sure to follow the operating instructions supplied
with the Wall-Mount bracket when installing the TV.
Be sure to attach the brackets supplied with the Wall-
Mount bracket.
Don’t hang the TV from the ceiling. It may fall and
cause serious injury.
AC Power Cable
Use the AC power cord specified by AOC and suitable
for the voltage where you use it.
The plug is designed, for safety purposes, to fit into the
wall outlet only one way. If you are unable to insert the plug fully into the outlet, contact your dealer.
If you will not be using the TV for several days,
disconnect the power by pulling the plug itself. Never pull on the cord.
When disconnecting AC power cord, the power cord
should be easily accessible for disconnection.
TV should be installed near an easily accessible power outlet. Do not use a poor fitting outlet. Insert the plug fully into the outlet. If it is loose, it may cause arcing and result in a fire. Contact your electrician to have the outlet changed.
Observe the followings to prevent the AC power cord from being damaged. If the AC power cord is damaged, it may result in a fire or an electric shock. Stop using it and ask your dealer or AOC service center to exchange it.
4
Do not place the TV where the power cord is subject to
wear or abuse.
Do not pinch, bend, or twist the cord excessively. The
core lines may be bared and cut, causing a short­circuit, and resulting in a fire or an electric shock.
Broken Pieces
Do not throw anything at the TV. The screen glass may break by the impact and cause serious injury. If the surface of the TV cracks, do not touch it until you have unplugged the AC power cord. Otherwise electric shock may result.
Do not convert or damage the power cord. Do not allow anything to rest on or roll over the power
cord.
Do not move the TV with the power cord plugged in. Keep the power cord away from heat sources. To unplug power cord, disconnect it from the wall
outlet first.
Be sure to grasp the plug when disconnecting the
power cord.
Do not pull the power cord. Do not use the supplied AC power cord on any other
equipment.
Use only an original AOC AC power cord, not other
brands.
LCD Screen
Although the LCD screen is made with high-precision
technology and has effective pixels of 99.99% or more, black dots or bright points of light (red, blue, or green) may appear constantly on the LCD screen. This is a structural property of the LCD panel and is not a malfunction.
The LCD screen is made with high-precision
technology and to achieve a high level of performance and picture quality, this TV’s backlight setting is set to maximize the brightness of the TV. However, uneven brightness may be observed when the LCD TV is viewed in a dark ambient without an input source or a blank screen. This condition is normal and not a malfunction of the TV. Changing the Picture mode, Backlight setting, enabling the Light Sensor, or turning on the Power management will improve this condition.
Do not expose the LCD screen surface to direct
sunlight. Doing so may damage the LCD panel.
Do not push or scratch the LCD screen, or place
objects on top of the TV. The image may be uneven or the LCD panel may be damaged.
If the TV is used in a cold place, a smear may occur in
the picture or the picture may become dark. This does not indicate a failure. These phenomena improve as the temperature rises.
Ghosting may occur when still pictures are displayed
continuously. It should disappear after a few moments.
The screen and cabinet get warm when the TV is in
use. This is not a malfunction.
Avoid spraying insect repellent with volatile material on
the screen.
Avoid prolonged contact with rubber or plastic material.
Handling of broken glass and liquid crystal leakage
If the LCD panel gets damaged, crystalline liquid leakage may occur, or scattered broken glass may result. Do not touch broken glass or crystalline liquid which is toxic, with bare hands as cuts, poisoning or skin irritation may occur. Also, do not let glass fragments or leaked crystalline liquid get into your eyes or mouth. Should either contact your eyes or mouth, rinse the contacted area thoroughly with water and consult your doctor.
Wiring
When connecting cables, be sure to unplug the AC power cord for your safety. Take care not to catch your feet on the cables. It may damage the TV set.
Electric Shock
Do not touch the AC power cord or the TV with a wet hand. If you plug/unplug the AC power cord from the TV with a wet hand, it may cause electric shock.
5
Lightning Storms
For added protection for this TV during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the TV due to lightning and power line surges.
When Not in Use
If you will not be using the TV set for several days, the TV set should be disconnected from the AC power outlet for environmental and safety reasons. The TV set is not disconnected from the AC power source when the TV set is switched off. To disconnect the TV set completely, pull the plug from the AC power outlet.
equipment emitting electromagnetic radiation.
Small Accessories
Keep small accessories out of children’s reach.
Antennas
Overloading
This TV set is designed to operate on a 100 - 240 V AC supply only. Take care not to connect too many appliances to the same AC power outlet as this could result in a fire or an electric shock.
Optional Equipment
Do not install optional equipment too close to the TV set. Keep optional equipment at least 11.875 inches (30 cm) away from the TV set. If a VCR is installed in front of the TV set or beside the TV set, the picture may become distorted. Picture distortion and/or noisy sound may occur if the TV set is positioned in close proximity to any
Outdoor antenna grounding
If an outdoor antenna is installed, follow the precautions below. An outdoor antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can come in contact with such power lines or circuits. When installing an outdoor antenna system,extreme care should be taken to keep from contacting such power lines or circuits as contact with them is almost invariably fatal Be sure the antenna system is grounded so as to provide some protection against voltage surges and built-up static charges.
Antenna lead-in wire
Battery
Do not dispose of batteries in a fire. Do not short circuit, disassemble or overheat the
batteries.
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
6
Disposal of used battery
To preserve our environment, dispose of used battery according to your local laws or regulations.
Cleaning
Cleaning the AC power plug
Unplug the AC power plug and clean it regularly. If the plug is covered with dust and it picks up moisture, its insulation may deteriorate and result in a fire.
Cleaning the screen surface/ cabinet of the TV set
Unplug the AC power cord to avoid electric shock
when cleaning.
Clean the cabinet of the TV with a dry soft cloth. To
remove dust from the screen, wipe it gently with a soft cloth. Stubborn stains may be removed with a cloth slightly dampened with a solution of mild soap and warm water. Never use strong solvents such as thinner or benzene for cleaning.
If using a chemically pretreated cloth, please follow the
instruction provided on the package.
The ventilation holes can accumulate dust over time.
To ensure proper ventilation, we recommend removing the dust periodically (once a month) using a vacuum cleaner.
Carry the TV
Carry the TV in the specified manner
To avoid dropping the TV and causing serious injury, be sure to follow these guidelines:
Before carrying the TV, disconnect all cables. Carrying the large size TV requires two or more
people.
When you carry the TV, place your hand as illustrated
and hold it securely. Do not put stress on the LCD panel.
When lifting or moving the TV, hold it firmly from the
bottom. Place your palm directly under the panel.
Magnetic Influence
This TV contains a strong magnet in the speaker unit that generates a magnetic field. Keep any items susceptible to magnetic fields away from the speaker.
Sound
If a snapping or popping sound from the TV is continuous or frequent while the TV is operating, unplug the TV and consult your dealer or service technician. It is normal for some TV’s to make occasional snapping or popping sounds, particularly when being turned on or off.
7
When carrying, do not subject the TV to shocks or
vibration, or excessive force.
Ventilation
The slots and openings in the TV are provided for necessary ventilation. To ensure reliable operation of the TV and to protect it from overheating, these slots and openings must never be blocked or covered.
Unless proper ventilation is provided, the gather dust and get dirty. For proper ventilation, observe the following:
Do not install the TV face up, down or sideways. Do not install the TV turned over or upside down. Never cover the slots and openings with a cloth or
other materials.
Never block the slots and openings by placing the TV
on a bed, sofa, rug or other similar surface.
TV may
Never place the TV in a confined space, such as a
bookcase or built-in cabinet, unless proper ventilation is provided.
Leave some space around the TV set as shown below. Otherwise, air-circulation may be inadequate and will cause overheating, which may cause a fire or damage to the TV set.
Volume Adjustment
Adjust the volume so as not to trouble your neighbors. Sound carries very easily at night. Therefore, closing the windows or using headphones is suggested. When using headphones, adjust the volume so as to avoid excessive levels, as hearing damage may result.
Service
Do not attempt to service the TV by yourself since opening the cabinet may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Never install the TV set where Air circulation is blocked.
Objects and ventilation holes
Never push objects of any kind into the TV through the cabinet slots as they may touch dangerous voltage points or short out parts that could result in a fire or an electric shock. Do not place any objects on the TV.
Moisture
Moisture and flammable objects
The TV must not be exposed to dripping or splashing.
Do not place objects filled with liquids, such as vases, on the TV.
Do not use power-line operated TV sets near water—
for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. It may result in a fire or an electric shock.
Do not let this TV get wet. Never spill liquid of any kind
on the TV. If any liquid or solid object does fall through, do not operate the TV. It may result in electric shock or damage to the TV. Have it checked immediately by qualified personnel.
To prevent fire, keep flammable objects or open flame
(e.g. candles) away from the TV.
Replacement Parts
When replacement parts are required, be sure the service technician certifies in writing that he/she has used replacement parts specified by the manufacturer that have the same characteristics as the original parts. Unauthorized substitutions may result in a fire, an electric shock or other hazards.
Safety Check
Upon completion of any service or repairs to the TV, ask the service technician to perform routine safety checks (as specified by the manufacturer) to determine that the TV is in safe operating condition, and to so certify. Ask a qualified service technician to dispose of the TV.
Thank you for purchasing this AOC high-definition television. The quality of the image you see on your AOC TV is only as good as the quality of the signal it receives. To experience the stunning detail of your new AOC TV, you need access to HD programming. Your AOC TV can receive and display HD programming from:
Over-the-air broadcasting via HD-quality antenna HD cable subscription HD satellite subscription Blu-ray Disc™ player or other external equipment
Contact your cable or satellite provider for information on upgrading to HD programming.
8
Contents in the Box
After unpack the TV box, Please check the TV and all accessories are well presented and undamaged.
9
Installation
Please refer to the “Usage Instructions” as above.
1. Attaching Table-Top Stand
Before attaching stand, unplug the AC cord from the AC INPUT terminal.
Caution
(1) Before performing work make sure to turn off the TV. (2) Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged. (3) Fasten the screws used to secure the stand in place.
2. Setting the TV on the Wall
This TV can be installed on a wall by using a Wall-Mount Bracket. Before mounting the TV on a wall, the Table-Top Stand must be removed from the TV.
Caution
(1) Installing the TV requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. AOC bears no responsibility for improper mounting or mounting that result in accident or injury. (2) Carefully read the instructions that come with the bracket before beginning work. (3) For product protection and safety reasons, AOC strongly recommends that you use the Wall-Mount Bracket model designed for your TV and the Wall-Mounting of your TV should be performed by AOC dealer or licensed contractor.
10
Controls & Connections:
Item
Description
MENU
Controls
1. VOL Press to increase or decrease the sound volume level.
2. CH Press to select the next higher or lower program number.
3.
4. INPUT Press to select the input source.
5. (Power)
Connections
Item Description
Headphone Jack
AV(Audio/Video) Input
AV Output
S-VIDEO Input
HDMI Input Connect a HDMI signal to HDMI port. VGA IN
(RGB/AUDIO)
Component input
RF Input Connects RF antenna or cable to this jack. USB Connect USB storage device to this jack.
SPDIF
Service For technician service only
Press to open or exit the OSD menu.
Switches the product on/standby or off. The product is not powered off completely unless it is physically unplugged.
Connect to your headphones. While headphones are connected, the TV speakers are muted.
Connect audio/video output from an external device to these jacks.
Connect second TV or monitor to the AV OUT socket on the TV. Only TV, AV and S-Video source can support this function. Connect S-VIDEO output from an external device to this jacks. The audio input connector was shared with AV IN. The S-VIDEO provides better picture quality than composite video.
Connect the output from a PC.
Connect a component video/audio device to these jacks. Component provides better picture quality than the S-VIDEO or the composite video connections.
SPDIF is highly recommended for high quality digital sound output. Carrying digital audio signals over either optical or electrical cable.
11
Remote control
All the functions can be controlled with the remote control handset. Some functions can also be adjusted with the buttons at the side of the TV set.
Remote control handset Before you use the control handset, Please install the batteries.
Battery installation
Remove the cover of the battery compartment. Insert the 2 batteries supplied
(Type AAA 1.5V).
12
Remote control button function description
Button Description
(Standby-
On)
Switch the TV to standby if it is on. Switch on the TV if it is in standby.
INFO Press to display the current signal information.
I/II
Select audio languages if dual sound broadcast is available. Select mono or stereo if stereo broadcast is available. Press repeatedly to cycle through the available sleep timer from
Sleep
0~180 minutes. The sleep timer can be set in steps of five minutes. If sleep timer set to 0, the sleep timer is switched off.
ZOOM Change the picture aspect ratio.
0~9 Press to select a TV channel directly.
EPG
Press EPG and then input 3 numeric button when channel number is more than 99.
Back Press to display the previous TV channel.
VOL -/+ Press to adjust the volume.
Source Press to display the input source menu.
Mute Mutes or restores volume. CH-/+ Press to select the TV channel. Audio Press repeatedly to cycle through the available sound modes.
Picture Press repeatedly to cycle through the available picture modes.
Press to select/adjust the various function items on the menu.
Confirm an entry or selection and display a option menu
OK
when watching TV. Please see next page for detail description
Exit Press to close menu.
MENU
Press to display/close OSD menu or return to previous OSD menu. To use the four colored buttons, can access Teletext in the corresponding item or page color instructions.
To turn On / off Teletext.
Press this button to activate Teletext with TV.
Press this button to change the font size.
Display the sub page (when available).
Press this button to return to page 100 or the index page.
Non-functional.
Press this button to stop the scrolling of pages. The text decoder stops receiving data.
Reveal hidden information.
13
Option menu description
OK,
OK
1. Press the OK directly to display above menu when watching TV.
2. Press the / button to select the desired item.
3. The items which you can choose are shown as below table.
Items Description
Press the button to enter. Press the / button to select desired favourite list. Press the OK to enter . Press the / button to select desired channel .
Show favorite ch.
Mark as favourite (Unmark as fav.)
Rename channel
Lock/Unlock channel
TV Time
Press the OK to confirm . Tips:1.The favourite channel group [favourite1, 2, 3, 4] is empty until
Press the button to enter. Press the / button to select desired favourite list to add current channel to this favourite list. (Or press the OK button to remove current channel from one of favourite list.) Press the OK , the channel is added to the favourite list Tips: All favourite channels are marked by an asterisk in the favourite list. Press the Press the / / button to select characters. Press the OK to confirm each character Select [Done], then press the OK to finish renaming channels. Tips:1.Press [Aa] to change an uppercase letter to a lowercase letter.
Press the OK and then press numeric buttons to input password .
effect.
Press the Tips:1. If TV Time had been enabled, the information is TV clock.
mark as favourite be done.
2. You can exit a favourite list and view all installed channels when you select [All].
3. When you use one of favourite list, you can only select those channels in this favourite list.
A virtual keyboard will appear.
2.The channel name can be up to six characters .
Tips: 1. Switch the TV off and on again for the channel lock to take
2. Default password:8888
3. If you access the locked channel by pressing CH+/- on the remote control, you are prompted enter your password.
to display the time.
2. If TV Time not be active, the information is TV worked time from this power on time.
3. TV Time setup is in the Feature section of TV main menu.
14
Connecting TV
Cable System or Antenna System
It is strongly recommended that you connect the antenna/cable input using a 75-ohm coaxial cable to receive optimum picture quality.
High Definition Interface
You can enjoy high-definition programming by subscribing to a high-definition cable service or a high-definition satellite service. For the best possible picture, make sure you connect this equipment to your TV via the HDMI or component video (with audio) input on the back of your TV.
HDMI Connection
If the equipment has a DVI jack and not an HDMI jack, connect the DVI jack to the HDMI IN (with DVI-to-HDMI cable or adapter) jack and connect the audio jack to the PC AUDIO IN jacks.
15
Component Signal Connection
PC Connection
Use the TV as a monitor for your PC shown below with the HD15 to HD15 connection. This TV can also be connected to a PC with DVI or HDMI output.
Connect the PC IN jack to the PC using the HD15- HD15 cable and audio cable.
If the PC is connected to the TV and no signal has been input from the PC for more than 30 seconds, the TV enters the standby mode automatically.
16
Composite Signal Connection
17
USING AOC TV
Turn the TV On
Power indicator status Green: Power on Red: Standby
To Switch on
•If the indicator is off, Press (Power) at the side of the TV
• If the indicator is red, Press (Standby-On) on the remote control or Press CH button at the side of the TV.
To Switch to standby
• Press (Standby-On) on the remote control, The indicator switches to red.
To Switch off
• Press (Power) at the side of the TV, The indicator switches off.
Tips
•Though your TV consumes very little power when in standby, energy continues to be consumed. When not in use for an extended period of time, disconnect the TV power cable from the power outlet.
18
Out Of Box Setting
The first time you setup your TV, you are prompted to select a menu language and to install TV.
1.Press the / button to select your desired language and Press the OK .
2. Press the / button to select your desired location and Press the OK .
3. Press the OK to start automatic channel installation. Press the MENU button to close the menu.
19
Source
Input Source selection
1 Source Press the
Press the / button to select desired input source.
2
3
Input source contains: TV, COMP, VGA, HDMI 1, HDMI 2,AV IN 1, AV IN 2/SV, Multimedia.
Press the OK.
button to display source menu
20
Picture Setting
MENU
MENU
Items
Description
Contrast
Brightness
Color
Sharpness
No
ise
Color
1
MENU Press the
2
Press the / button to select icon , and press OK.
button to display main menu
3
4 5
Follow sub-menu operated, the detail description please see below table.
MENU Press the
Personal The user can set their favorite setting. Vivid For Enhances picture contrast and sharpness. Standard For standard picture settings. Recommended for home
Auto picture
Movie
Game For game and entertainment content. Energy saving Decrease backlight level to save the power To sharpen the picture quality. To brighten the dark parts of the picture. To add or reduce colour. To improve detail. To filter out and reduces the image noise and improve picture quality.
reduction
temp.
Select the effect degrees from Off, Minimum, Medium, Maximum.
To choose between Cool, Normal, Warm.
Dynamic contrast
Advanced Pic
Dynamic backlight Colour enhancement To select the available display format from Auto format, Super zoom,4:3,
format
Subtitle zoom, Movie expand 14:9, Movie expand 16:9, Wide screen.
Press the / button to select the desired item and then press the OK
button return to previous menu.
entertainment. For viewing film-based content. Most suitable for viewing in a theater-like environment.
Automatically enhance the image contrast when set up On
To choose between Best Power, Best picture, Off.
Make colors more vivid, bright colors in the details section to improve the resolution when set up On.
21
Picture Setting ( For PC source only )
MENU
MENU
Items
Description
Contrast
Brightness
Color temp.
Horizontal
Vertical
shift
1
MENU Press the
button to display main menu
2
3
4 5
format
shift
Follow sub-menu operated,the detail description please see below table.
MENU Press the
Press the / button to select icon , and press the OK. Press the / button to select the desired item and then press the OK.
button return to main menu.
To sharpen the picture quality. To brighten the dark parts of the picture. To choose between Cool, Normal, Warm.
To select the display format between 4:3 and Wide screen.
Adjusts the picture horizontally for PC-VGA input.
Adjusts the picture vertically for PC-VGA input.
22
Audio Setting
MENU
MENU
Items
Description
Audio
Bass
Treble
Volume
Balance
Headphone
1 MENU Press the
button to display main menu.
2
3
4 5 MENU Press the
Auto sound
Surround Sets Virtual surround on and off
Follow sub-menu operated, the detail description please see below table.
Press the / button to select icon, and then press the OK .
Press the / button to select the desired item and then press OK.
button return to main menu.
Standard: Suitable for spoken dialog. News: For viewing news content Movie: For viewing movie content Personal: Adjust sound mode as personal favorite. Sound Mode can also be accessed by pressing the remote control. Increases or decreases lower-pitched sounds. Increases or decreases higher-pitched sounds. Increases or decreases the volume Emphasizes left or right speaker balance.
button on the
Volume
Auto volume
Delta volume
23
Adjust headphone volume.
Automatically reduces sudden volume changes, for example, when switching channels. Levels out volume differences between channels or connected devices. Switch to the connected device before you change the delta volume.
Features Setting
MENU
MENU
Items
Description
1
2
3
4 5
MENU Press the
Follow sub-menu operated, the detail description please see below table.
MENU Press the
button to display main menu.
Press the / button to select icon and then press the OK .
Press the / button to select the desired item and then press OK.
button return to previous menu.
Sleep Timer
TV Time
On Timer
TV lock
Set code
Press the / button to select a value between 0~ 180 minutes. Tips:
1.If set to 0, the sleep timer is switched off.
2.The TV switches to standby after the specified time.
3.This can also be set using the SLEEP button on the remote control. Press the / / button or numeric buttons to enter time. Select [Done] and press the OK. You can switch on the TV from standby to a specific channel at a specified time. Press the button to enter . Press the / button to select the desired item and then press OK. [Activate]: Selects how often the TV is switched on. [Time]: Sets the time to switch on the TV. [Channel no.]: Selects the channel or the input source. Tips: 1.Select [On timer] >[Activate]> [Off] to disable this feature.
2.Set the TV Time before you use [On timer]. Lock the TV to prevent access to all channels. Enter your password using numeric buttons,The [TV lock] menu appears. Press the / button to select [Lock] or [Unlock]. Press OK. Tips: 1.Switch the TV off and on again for the change to take effect.
2.If you select [Lock], you have to enter your password every time
you turn on your TV. Follow the on-screen instruction to create or change your password using numeric buttons. Tips: If forget your passord, enter ‘8888’ to override any existing codes.
24
MENU
MENU
Items
Description
PIP
PIP Source
PIP Sound
Sleep Timer
TV Time
On Timer
TV lock
Set code
Features Setting (For PC source only)
1
MENU Press the
button to display main menu.
2
Press the / button to select icon and then press the OK .
3
4 5
Follow sub-menu operated, the detail description please see below table.
MENU Press the
Press the / button to select the desired item and then press the OK.
button return to previous menu .
Select PIP function On/Off. Select PIP Source from TV, AV IN 1,AV IN 2/SV source Select PIP Sound from VGA and PIP source. Please refer previous page. Please refer previous page. Please refer previous page. Please refer previous page. Please refer previous page.
25
Installation setting
1
2
3
4
5 MENU/Exit Press the MENU button return to previous menu.
Menu language
Channel Search
MENU Press the MENU button to display main menu.
Press the / button to select icon and then press the OK .
Press the / button to select the desired item and then press the OK.
Follow sub-menu operated, the detail description please see below table.
Items Description
Press the / button to choose language between English, Farsi, Indonesia , Vietnam. Press the OK. Press the / button to choose between [Auto Search], [ Manual search]. Press the OK. [Auto Search]:Press the Tips: To stop searching, Press the OK and follow sub-menu operated.
[Manual search]: the detail description please see next page.
to start auto search.
OK
Location Optimum TV settings for your location - home or shop.
Volume bar
Preferences
E-link
E-label For shop mode only, Sets the location of the e-label.
Factory settings
26
You can restore the default picture and sound settings of your TV. The channel installation settings remain the same.
Displays the volume bar when you adjust the volume when set On. Enables one-touch play and one-touch standby between CEC compliant devices.
Manual Search Description
1.Press the / button to select “Manual Search” item,and then press OK.
2.Press the / button to select desired item,The items you can choose are shown as below.
Items Description
Press the button to enter. Press the / button can select [ AUTO], [PAL], [NTSC-3.58], [NTSC-
Colour system
Sound system
Search
4.43], [SECAM]. Press the OK . Tips:Skip this step if your system setting is correct. Press the button to enter sub-menu. Press the / button can select [AUTO], [M], [B/G], [ I], [D/K], [L], [ L’ ]. Press the OK. Tips:Skip this step if your system setting is correct. Press the button to enter .
Press numeric buttons to manually enter the three-digit frequency to begin search. If a channel is unavailable at the selected frequency, the system searches for the next available channel. Press the
BACK
button when the new channel is found. Press the / button to select [Store new channel] Press the button to enter [Store new channel]. Select [OK],and then press the Tips: press
to continue search new channel.
OK
to store the new channel.
OK
Channel number
Fine-Tune
Skip channel
Press the button to enter. Press the / button to select desired channel number. Press OK. Press the button to enter. Press the / button adjust frequency Press the
OK
. Press the / button to select [Store current channel] to store channel number. Press the button to enter [Store current channel]. Select [OK],and then press the
to store the current channel and return
OK
to previous menu. Press the button to enter. Press the / button to select [Skip]. Press the
to skip current channel.
OK
Repeat the previous steps to skip more channels. Tips:
1. The selected channel is skipped when you press CH +/- on your remote control.
2. Press the Numeric buttons on the remote control to access the skipped channel.
3. To access the skipped channel, please select [No] to restore.
27
Multimedia (USB) setting
Caution:
AOC is not responsible if the USB storage device is not supported, nor is it responsible for damage or loss of data from the device.
1. Connect the USB storage device to the TV, TV can detect USB device automatically.
2. Press the button to select [Category Browse] or press the to select [ File Browse]. Tips: You can also enter Multimedia source by pressing the Source button on the remote control.
Under Category Browse mode:
Press the / button to select the desired item and then press the button to confirm your choice Press the button to select a desired file . Press OK to paly.
Under Pictures mode: Press the / / / button to go to the previous or next picture. Press OK enter to sub-menu select desired item Press OK Item list is as below.
Item Description
Stop Slideshow Starts or stops a slide show. Slideshow transitions Sets the transition from one picture to the next. Slideshow frequency Sets the amount of time that a picture is shown. Rotate image Rotates a picture. Show info Displays the picture information.
Stop music play
Press BACK close sub-menu. Press MENU return to previous menu.
Under Music mode: Press the / button to go to the previous or next Music. Press the / button to switch to fast forward or fast backward modeX2,X4,X8,X16,X32
is optional. Press OK enter to sub-menu and select desired item Press OK. Item list is as below.
Item Description
Stop playback Starts or stops the music.
Repeat Mode
Show info Displays the file information. Press BACK close sub-menu.
Play once Disables repeat play and plays a song once. Repeat Repeats a song. Shuffle Plays songs randomly.
Stop the music . Tips: We can listen to music or not while browse picture.
28
Press MENU return to previous menu. Under Video mode: Press the / button to go to the previous or next Video. Press the / button to switch to fast forward or fast backward modeX2,X4,X8,X16,X32
is optional. Press OK enter to sub-menu and select desired item Press OK. Item list is as below.
Item Description
Start playback Starts or stops the video.
Repeat Mode
Play once Disables repeat play and plays a video once. Repeat Repeats a video.
Shuffle Plays video randomly. Show info Displays the file information. Press BACK close sub-menu.
Press MENU return to previous menu.
Under File Browse mode:
Press the / button to enter or exit sub folder. Press the / button to select the desired file. Press OK to play.
Under Pictures mode: Press the / / / button to go to the previous or next picture. Press OK enter to sub-menu select desired item Press OK Item list is as below.
Item Description
Stop Slideshow Starts or stops a slide show. Slideshow transitions Sets the transition from one picture to the next. Slideshow frequency Sets the amount of time that a picture is shown. Rotate image Rotates a picture. Show info Displays the picture information.
Stop music play
Stop the music .
Tips: We can listen to music or not while browse picture. Press BACK close sub-menu. Press MENU return to previous menu.
29
Under Music mode: Press the / button to go to the previous or next Music. Press the / button to switch to fast forward or fast backward modeX2,X4,X8,X16,X32
is optional. Press OK enter to sub-menu and select desired item Press OK. Item list is as below.
Item Description
Stop playback Starts or stops the music.
Repeat Mode
Play once Disables repeat play and plays a song once. Repeat Repeats a song.
Shuffle Plays songs randomly. Show info Displays the file information. Press BACK close sub-menu.
Press MENU return to previous menu.
Under Video mode: Press the / button to go to the previous or next Video. Press the / button to switch to fast forward or fast backward modeX2,X4,X8,X16,X32
is optional. Press OK enter to sub-menu and select desired item Press OK. Item list is as below.
Item Description
Start playback Starts or stops the video.
Repeat Mode
Play once Disables repeat play and plays a video once.
Repeat Repeats a video.
Shuffle Plays video randomly. Show info Displays the file information. Press BACK close sub-menu.
Press MENU return to previous menu.
Tips:
1. If can’t detect the connected device, it would be caused by the connected device driver not by TV failure.
2. The reading speed will be variable due to the different connected devices and different storage capacities.
3. Sometimes it can’t detect the device because the connected device can’t meet with the standard USB spec requirement (5V /500 mA).
4. USB port could be also used as software upgrade.
30
Product information
Product information is subject to change without notice.
Supported display resolutions
Computer formats
Item Resolution Refresh rate
VESA 640 x 480 60Hz VESA 800 x 600 60Hz VESA 1024 x 768 60Hz
VESA 1360 x 768 60Hz WXGA+ 1440 x 900 60Hz WSXGA 1680 x 1050 60Hz
Video formats
Item Resolution Refresh rate
SD 720 x 480i 60Hz SD 720 x 480P 60Hz SD 720 x 576i 50Hz
SD 720 x 576P 50Hz HD 1280 x 720P 50Hz HD 1280 x 720P 60Hz HD 1920 x 1080i 50Hz HD 1920 x 1080i 60Hz
FHD 1920 x 1080P 50Hz FHD 1920 x 1080p 60Hz
Supported Multimedia Formats
Note: It can’t support all the below formats due to some source files decoding issues.
It’s not caused by TV failure.
Format Resolution Type Note
High-Definition JPEG
JPEG 5000×5000
Baseline JPEG
Progressive JPEG
Max
1600×1024
Format Sample Rate Date Rate Channel
Audio
8-48 KHz 8-320 Kbps Mono/Stereo
MP3
8-48 KHz 16-576 Kbps Mono/Stereo
Formats File Extension Codec Data Rate
Video
MPEG1 .DAT/.MPG/.VOB MPEG-1 Video Max 10 Mbps MPEG4 .AVI/.VID/.MP4 DIVX3/4/5 /XVID/MPEG-4
Realmedia
31
.RM/.RMVB RealVideo 8/9/10 Max 10 Mbps
Max 8 Mbps
Product specification
Operation
Standby
Set Dimension
Set Dimension
Carton Dimension
Operation Temperatur
e
Storage Temperature
Operation/
Storage
Design and specifications are subject to change without notice.
Model
L22DK99U
L26DK99U
L32DK99U
Color System PAL/ SECAM PAL/ SECAM PAL/ SECAM
Sound System B/G B/G B/G
Speaker Output 5W x 2 7W x 2 10W x 2
Input Voltage 100-240V, 50/60Hz 100-240V, 50/60Hz 100-240V, 50/60Hz
Power consumption
Power consumption
((((W x H x D)))) (with base and stand)
535.4x384.1x170.9
55W 105W 150W
1W 1W 1W
659.5x485.2x232.5 792.6x561.5x232.5
(mm)
((((W x H x D)))) (w/o base and stand)
535.4x352.7x60.5 659.5x448.8x92.4 792.6x519.5x97
(mm)
((((W x H x D))))
593x451x157 736x553x198 875x665x188
(mm) Net Weight (Kg) 5.2 8.7 12.5 Gross Weight(Kg) 6.3 10.9 14.4
Wall mount size
100 x 100mm
M 4x10(Screw)
200 x 100mm
M6x10(Screw)
200 x 200mm
M6x10(Screw)
0ºC~35ºC 0ºC~35ºC 0ºC~35ºC
-20ºC~50ºC -20ºC~50ºC -20ºC~50ºC
Humidity
10~90% 10~90% 10~90%
32
Troubleshooting
Condition
Explanation / Solution
No picture
Poor picture
No picture Check the Power Saving settings.
Make sure the power cord is connected securely. Turn on the power of the Cannot receive any channels
TV is locked to one channel
Cannot receive or select
The TV turns off
No picture from some video
TV.
Check antenna/cable connections. Make sure the Cable setting is correct for
your TV signal source.
Perform Auto Program to add receivable channels that are not present in the
TV’s memory.
Perform Auto Program to add receivable channels that are not present in the
channels TV’s memory.
To receive or select cable channels, make sure that Cable in the Channel
settings is set to On. To receive or select UHF channels over an antenna,
make sure Cable is set to Off.
Check if Sleep Timer is activated, or confirm the Duration setting of Timer
automatically.
Check PC Power Management in General Settings.
Check the connection between the optional video equipment and the TV
Sources.
Press INPUT on the remote control.
Select your desired input from the External Inputs list.
The quality of the images is not as good as what I saw at the store Double images or ghosts Only snow and noise appear on the screen
Dotted lines or stripes
No color/Dark picture/Color is not correct/The picture is too bright
Noisy picture
Can not play photo, music and video or poor quality.
Picture quality depends on the signal content. See Quick Setup Guide
(supplied) to display the best possible picture for that signal.
Check antenna/cable connections.
Check the antenna location and direction.
Check if the antenna is broken or bent; Check if the antenna has reached the
end of its serviceable life. (3-5 years in normal use, 1-2 years at the seaside.)
Keep the TV away from noise sources such as cars, motorcycles, or hair-
dryers.
If using 300 ohm twin lead, move the excess lead away from the TV or try
using 75 ohm coaxial cable instead.
Press PICTURE to select the desired Picture Mode; Adjust the Picture Mode
options in the Picture settings.
Make sure that the antenna is connected using a 75-ohm coaxial cable.
Keep the antenna cable away from other connecting cords.
To avoid TV interference, make sure to use an undamaged antenna cable.
Check source format meet product specifications or not.
33
No sound/Noisy
sound
PC Input
Condition
Explanation / Solution
PC Input
Check the volume control. Press MUTE or VOL + so that disappears
from the screen. Good picture, no sound
Disconnect your headphones.
For HDMI equipment, confirm that the audio output setting of the connected
equipment is set to PCM. This TV's HDMI inputs support PCM 32, 44.1 and
48 kHz, 16, 20 and 24bits.
Make sure that the antenna is connected using a 75-ohm coaxial cable. Audio noise
Keep the antenna cable away from other connecting cords.
To avoid TV interference, make sure to use an undamaged antenna cable.
Confirm the PC is correctly connected to the TV with either the PC IN (with
an HD15 cable) or with the HDMI IN.
No Picture / No Signal
Ensure the output signal from the PC is one of the formats listed on page 18.
Turn the PC off. Confirm the PC connection and restart the PC. Plug and
play will auto-detect the TV and correctly set up PC timing.
Verify PC Power Management is activated. Poor Picture Adjust the resolution. Adjust Pitch and Phase.
The current Wide Mode setting is automatically replaced with the 4:3
Default setting when you change the channel or video input, if 4:3 Default in Wide Mode changes automatically
the Screen settings is set to other than Off. If you want to lock in Wide Mode
selected with WIDE on the remote control, set 4:3 Default to Off in the
Screen settings.
Check the Auto Wide option in the Screen settings.
The picture gets smaller during the commercials, this is due to the method Suddenly the picture gets smaller
the provider broadcasts their contents. When HD content channels switch to
SD definition content (commercials), the picture may be small with a black
border.
You have selected a text option and no text is available. To turn off this “Black box” on screen
feature, set the CC Display option to Off. If you were trying to select closed
captioning, select CC1 instead of Text1-4.
Some wide screen programs are filmed in aspect ratios that are greater than
16:9 (this is especially common with theatrical releases). Your TV will show Black bands appear at the edges of the screen
these programs with black bands at the top and bottom of the screen. For
more details, check the documentation that came with your DVD (or contact
your program provider). Programs in 4:3 aspect ratio will have bands on left
and right sides of the screen.
Certain programs on DVD or other digital sources display a loss of detail, especially during fast-motion or dark scenes
This is due to the digital compression of the source content used by certain
digital broadcasts and DVDs which may cause your TV’s screen to display
less detail than usual, or cause artifacts (small blocks or dots, pixilation) to
appear on your screen. These signal compressions are more visible and are
dependent on the clarity and resolution of the television.
Check the polarity of the batteries or replace the batteries.
Point the remote control at the remote control sensor located at the front of Remote control does not operate
the TV.
Fluorescent lamps can interfere with your remote control operation; try
turning off the fluorescent lamps.
Keep the remote control sensor area clear from obstacles.
34
Loading...
