ANPEC APL1431LBBI-TR, APL1431LBBI-TB, APL1431LBBI-PB, APL1431LBBC-TR, APL1431LBBC-TB Datasheet

APL1431L

Low Voltage Adjustable Precision Shunt Regulator

Features General Description

• Precise Reference Voltage to 1.24V

• Guaranteed 0.5% or 1% Reference Voltage

Tolerance

• Sink Current Capability , 60mA to 100mA

• Quick Turn-on

• Adjustable Output Voltage , V

O

= V

REF

to 20V

• Low Operational Cathode Current , 60mA

Typical

• 0.1Ω Typical Output Impedance

• SOT-23-5 Packages

Applications

•

Linear Regulators

• Adjustable Power Supply

• Switching Power Supply

The APL1431L is a 3-terminal low voltage adjust-

able precision reference with specified thermal sta-

bility over applicable commercial temperature ranges

. Output voltage may be set to any value between

V

(1.24 V) and 20 V with two external resistors

REF

(see Figure 2) . When used with an photocoupler ,

the APL1431L is an ideal voltage reference in iso-

lated feedback circuits for 1.24V to 12V switching-

mode power supplies . This device has a typical

output impedance of 0.1Ω . Active output circuitry

provides a very sharp turn-on characteristic , mak-

ing the APL1431L excellent replacements for zener

diodes in many applications , including on-board

regulation and adjustable power supplies .

ANODE REF

45

123

NC NC

CATHODE

Symbol

Functional Diagram

REF

V

REF

Cathode

+

−

Anode

www.anpec.com.tw1

CathodeAnode

REF

ANPEC reserves the right to make changes to improve reliability or manufacturability without notice, and advise
customers to obtain the latest version of relevant information to verify before placing orders.

Copyright  ANPEC Electronics Corp.
Rev. A.4 - May., 2003

APL1431L

Ordering and Marking Information

APL1431L

APL1431L B :

Handling Code

Temp. Range

Package Code

Elec. Grade

1431L

Elec. Grade
A : 0.5% Reference Voltage Tolerance
B : 1% Reference Voltage Tolerance
Package Code
B : SOT- 23 - 5
Temp. Range
C : 0 to 70 C I : -40 to 85 C
Handling Code
PB : Plastic Bag TB : Tape & Box
TR : Tape & Reel

Absolute Maximum Ratings

Symbol Parameter Rating Unit

V

KA

I

K

I

REF

JA

θ

T

J

T

STG

T

SOL

Cathode Voltage 20 V

Continuous Cathode Current 100 mA

Reference Current 3 mA
Thermal Resistance from Junction to Ambient in Free Air

SOT-23-5

357

Operating Junction Temperature Range -40 to 150

Storage Temperature Range -65 to 150

Lead Temperature Range, Ts (Soldering, 10sec) 260

C/W

°

°

°

°

C

C

C

Electrical Characteristics

TA= 25°C ( unless otherwise noted)

Symbol Parameter Test Conditions

VKA=V
T

V

Reference Voltage

REF

A

T

A

, IK=10mA

REF

= 25°C, (Fig. 1)

= full range

(see Note 1), (Fig. 1)

= full range(see Note 1),

T

V

∆

/∆V

I

Copyright  ANPEC Electronics Corp.
Rev. A.4 - May., 2003

V

Temp Deviation

DEF

Ratio of Change in V
to Change in Cathode
Voltage

Reference Input Current

V

REF

DEV

REF

KA

A

V

KA =VREF

REF

I

=10mA, ∆VKA =16V to V

K

=10mA, R1=10kΩ, R2=∞ (Fig. 2)

I

K

, IK =10mA, (Fig. 1)

APL1431L

Min. Typ. Max.

APL1431LA 1.234 1.240 1.246
APL1431LB 1.228 1.240 1.252
APL1431LA 1.222 1.240 1.258
APL1431LB 1.215 1.240 1.265

515mV

(Fig. 2)

REF

-0.2 -1.0 mV/V

0.15 0.5

www.anpec.com.tw2

Unit

V

A

µ

APL1431L

)

Electrical Characteristics T

= 25°C ( unless otherwise noted)

A

Symbol Parameter Test Conditions

T

= full range(see Note 1), R1=10kΩ,

I

REF(DEV

I

K(off)

Z

KA

I

K(MIN)

I

Tem p D ev ia t i o n

REF

Off-state cathode current V

Dynamic Output

Impedance

Minimum Operating

Current

Note : 1. Full temperature range is 0

A

R

=∞ , IK=10mA, (Fig. 2)

2

=0V, (Fig. 3)

REF

V

KA =VREF

, IK=100µA to 100mA ,

f<1kHz , (Fig. 1 )

V

=V

KA

, (Fig. 1) 60 80

REF

°C to 70°C for APL1431LXXC, and –40°C to 85°C for APL1431LXXI.

Test Circuits

V

IN

I

V

O

K

APL1431L

Min. Typ. Max.

0.05 0.3

VK=6V 0.01 0.1

V

=16V 0.01 0.5

K

0.1 0.3

V

IN

I

R

1

I

REF

Unit

A

µ

A

µ

Ω

A

µ

V

O

K

V

REF

Figure 1. Test Circuit for VKA=V

, VO=VKA=V

REF

IN

V

Figure 3. Test Circuit for I

REF

R

2

V

REF

Figure 2. Test Circuit for VKA>V
VO= VKA= V

V

O

I

K(OFF)

K(OFF)

× (1+R1/R2) + I

REF

REF

,

× R

REF

1

Copyright  ANPEC Electronics Corp.
Rev. A.4 - May., 2003

www.anpec.com.tw3

APL1431L

Application Schematic

V

IN

R

B

R

1

V

O

Notes for Application Circuits:

V

REF

R

GND

Precision Voltage Reference

V

IN

R

B

APL431L

0.1µF

Precision Voltage Regulator

0.1µF

APL431L

2

V

O

R

1

V

REF

R

2

1) To improve the stability of output voltage , a 0.1µF capacitor between cathode and anode of APL431L
is strongly recommended.

2) Set VO according to the following equation:

VO= V

(1+R1/ R2)+ I

REF

REF

R1

3) Choose the value for RB as follows:

• The maximum limit for R

operating current (60µA) at V

• The minimum limit for R

should be such that the cathode current( IK) is greater than the minimum

B

should be such that the cathode current (IK) does not exceed 100mA under

B

IN (MIN)

.

all load conditions, and the instantaneous turn-on value for IK does not exceed 150mA . Both of the

following conditions must be met :

R

≥ V

B,MIN

R

≥ V

B,MIN

Copyright  ANPEC Electronics Corp.
Rev. A.4 - May., 2003

/ 150mA ( to limit instantaneous turn-on IK)

IN(MAX)

IN(MAX)

- VO / I

+ 100mA (to limit IK under normal operating conditions)

O (MIN)

www.anpec.com.tw4

APL1431L

Typical Characteristics

300

TA=25°C

200

VKA=V

REF

100

0

-100

Cathode Current (µA)

-200

-300

-1 -0.5 0 0.5 1 1.5

Cathode Voltage (V)

1.248

1.246

1.244

IK=10mA

150

TA=25°C

100

VKA=V

REF

50

0

-50

Cathode Current (mA)

-100

-150

-1.5 -1 -0.5 0 0.5 1 1.5

Cathode Voltage (V)

150

125

IK=10mA

R1=10kΩ

R2=∞

1.242

1.24

1.238

Reference Voltage (V)

1.236

1.234

-40 -20 0 20 40 60 80

Junction Temperature (°C) Junction Temperature (°C)

Copyright  ANPEC Electronics Corp.
Rev. A.4 - May., 2003

100

100

75

Reference Input Current (nA)

50

-40 -20 0 20 40 60 80 100

www.anpec.com.tw5

APL1431L

Typical Characteristics (Cont.)

1.2

1.1

1

0.9

0.8

0.7

0.6

0.5

0.4

0.3

0.2

0.1

0

Ratio of Delta Reference Voltage to Delta

Cathode Voltage (-mV/V)

IK=10mA

∆VKA=16V to V

-40 -20 0 20 40 60 80 100

REF

Junction Temperature (°C)

250

V

=0V

REF

200

VKA=16V

150

100

50

Off State Cathode Current (nA)

0

-40 -20 0 20 40 60 80 100

Junction Temperature (°C)

Copyright  ANPEC Electronics Corp.
Rev. A.4 - May., 2003

www.anpec.com.tw6

APL1431L

Packaging Information

SOT-23-5

e1

45

12

3

E1 E

e

D

Dim

Min. Max. Min. Max.

A 0.95 1.45
A1 0.05 0.15
A2 0.90 1.30

D2.83.00

E2.63.00
E1 1.5 1.70

L 0.35 0.55

b

A2

A

A1 L 2

a

L

Millimeters Inches

0.037 0.057

0.002 0.006

0.035 0.051

0.110 0.118

0.102 0.118

0.059 0.067

0.014 0.022

L 1

L1 0.20 BSC 0.008 BSC
L2 0.5 0.7

0.020 0.028

N5 5

α

0

°

10

°

0

°

10

°

Copyright  ANPEC Electronics Corp.
Rev. A.4 - May., 2003

www.anpec.com.tw7

APL1431L

Physical Specifications

Terminal Material Solder-Plated Copper (Solder Material : 90/10 or 63/37 SnPb)
Lead Solderability Meets EIA Specification RSI86-91, ANSI/J-STD-002 Category 3.

Reflow Condition (IR/Convection or VPR Reflow)

Reference JEDEC Standard J-STD-020A APRIL 1999

Peak temperature

temperature

Pre-heat temperature

°

183 C

Time

Classification Reflow Profiles

Convection or IR/

Convection

Average ramp-up rate(183°C to Peak) 3°C/second max. 10 °C /second max.
Preheat temperature 125 ± 25°C)
Temperature maintained above 183°C
Time within 5°C of actual peak temperature
Peak temperature range
Ramp-down rate
Time 25°C to peak temperature

120 seconds max
60 – 150 seconds
10 –20 seconds 60 seconds
220 +5/-0°C or 235 +5/-0°C 215-219°C or 235 +5/-0°C
6 °C /second max. 10 °C /second max.
6 minutes max.

VPR

Package Reflow Conditions

pkg. thickness
and all bgas

Convection 220 +5/-0 °C Convection 235 +5/-0 °C
VPR 215-219 °C VPR 235 +5/-0 °C
IR/Convection 220 +5/-0 °C IR/Convection 235 +5/-0 °C

Copyright  ANPEC Electronics Corp.
Rev. A.4 - May., 2003

2.5mm

≥≥≥≥

pkg. thickness < 2.5mm and
pkg. volume

350 mm³

≥≥≥≥

pkg. thickness < 2.5mm and pkg.
volume < 350mm³

www.anpec.com.tw8

APL1431L

Reliability test program

Test item Method Description

SOLDERABILITY MIL-STD-883D-2003
HOLT MIL-STD-883D-1005.7
PCT JESD-22-B, A102
TST MIL-STD-883D-1011.9
ESD MIL-STD-883D-3015.7 VHBM > 2KV, VMM > 200V
Latch-Up JESD 78 10ms , Itr > 100mA

245°C , 5 SEC
1000 Hrs Bias @ 125 °C
168 Hrs, 100 % RH , 121°C

-65°C ~ 150°C, 200 Cycles

Carrier Tape & Reel Dimensions

E

F

W

Po

A

P

P1

Ao

J

t

D

Bo

D1

T2

C

B

T1

Ko

Application

A B C J T1 T2 W P E

178 ±1 72 ± 1.0 13.0 + 0.2 2.5 ± 0.15 8.4 ± 2 1.5 ± 0.3 8.0 ± 0.3 4 ± 0.1 1.75± 0.1

SOT-23-5

F D D1 Po P1 Ao Bo Ko t

3.5 ± 0.05 1.5± 0.1 1.5± 0.1 4.0 ± 0.1 2.0 ± 0.1 3.15 ± 0.1 3.2± 0.1 1.4± 0.1 0.2±0.033

(mm)

Copyright  ANPEC Electronics Corp.
Rev. A.4 - May., 2003

www.anpec.com.tw9

APL1431L

Cover Tape Dimensions

Application Carrier Width Cover Tape Width Devices Per Reel

SOT- 23-5

Customer Service

Anpec Electronics Corp.

Head Office :

5F, No. 2 Li-Hsin Road, SBIP,
Hsin-Chu, Taiwan, R.O.C.
Tel : [phone]
Fax : [phone]

Taipei Branch :

7F, No. 137, Lane 235, Pac Chiao Rd.,
Hsin Tien City, Taipei Hsien, Taiwan, R. O. C.
Tel : [phone]
Fax : [phone]

8 5.3 3000

Copyright  ANPEC Electronics Corp.
Rev. A.4 - May., 2003
