Page 1
ACX 700
Installation Guide
ACX 700 Installation Guide i
Downloaded from - http://www.guardianalarms.net
Page 2
Version E
Reproduction or distribution forbidden.
Copyright 1997 by Andover Controls.
Subject to change without notice.
Order No. 30-3001-204
Copyright
1997
Andover Controls Corporation
300 Brickstone Square
Andover, Massachusetts 01810
All Rights Reserved.
Published by the Engineering Departm ent at Andover Controls Corporation.
IMPORTANT NOTIC E
This product is subject to change without notice. This document does not
constitute any warranty, express or implied. Andover Controls C orpor ation
reserves the right to alter capabilities, performance, and presentation of this
product at any time.
ACX 700 Installation Guide ii
Page 3
Preface
The Andover Controls ACX 700 Installation Guide presents
instructions for installing the ACX 700 access controller on an Infinet
network. It first presents site preparation information and then step-bystep installation instructions.
ACX 700 Installation Guide iii
Page 4
ACX 700 Installation Guide iv
Page 5
Setting Up the ACX 700 Controller and Infinet
Site/System Setup Requirements..........................................................2
Controller Dimensions and Weight.................................................3
Power Requ ir ements......................... ................. ................ ..............3
Cable Limit a t i o ns.. ................ ................. ....................... ................. ..4
Lightn i ng Protection...... ................. ................ ................. ................4
Building Ground Requirements.......................................................5
Inspecting the Ground......................................................................6
Environmental Requirements..........................................................6
Enclosure Req uirements.......... ......... ................. ......... ......... .......... ..6
Special Wire for Card Reader Inputs.... ....... ..... ....... ....... ....... ....... ...6
Special Wire for Keypad Inputs .............................. ....... ....... ....... ...7
Contents
Output Req u ire m e n t s.......................... ................. ....................... .....7
Input Requ ir e m en ts.................... ................ ................. ................ .....8
Laying Out the Site Setup................................................................9
Installing the ACX 700.................... ................ ................. ...................10
Parts Required................................................................................10
Mounting........................................................................................10
Connecting the AC Power.............................................................15
Selecting the AC Input Voltage.....................................................16
Connecting the UPS Power Supply...............................................17
Connecting the Power Indicating LED ..........................................18
Wiring the Infinet to the ACX 700 .................................................21
Wiring the Infinet to the Inf inity CX 9000 or 9200........................22
Wiring Inputs ......................................................................................24
Supervisory Input Circuits.............................................................26
Wiring Door Switches ...................................................................28
Andover Controls Corporation v
Page 6
Wiring Motion Sensors/Exit Push Buttons....................................30
Wiring Other Two-Wire Inputs .....................................................32
Wiring Card Read er Inputs................. ........................ ................ ...32
Wiring Keypad Inputs....................................................................39
Wiring Outp u ts ................... ................. ....................... ................. .......40
Wiring Door Outputs.....................................................................40
Connecting Modules to the Expansion Port ............ ....... ....... ....... .4 2
Wiring Power Supply for Modules................................................45
Powering Up the ACX 700............ ......... ................. ................ ............47
Reset Button...................................................................................48
Connecting the Battery..................................................................48
Connecting the Andover Controls Service Tool............................49
Appendix A—Underwriters Laboratories Requirements
Appendix B—Setting the Card Type Jumpers
Locating the Card Type Jumpers......................................................B-2
Setting Jumpers for ABA Cards..................................................B-3
Setting Jumpers for Wiegand Cards ............................................B-4
vi ACX 700 Installation Guide
Page 7
Figures
1. Dimensions and Location of Mounting Holes in Cabinet
Provided, in inches (mm)..................................................................11
2. Dimensions and Location of Mounting Holes in Backplate, in
inches (mm ).............. ................ ........................ ................ .................12
3. Dimensions of ACX 700 on Backplate with EMX 190s,
in inches (mm)...................................................................................13
4. Cover Plat e of the ACX 700..............................................................14
5. Metal Plate and Screw for Power Supply Wire ................................16
6. Location of Power Indicating LED on Front Door of Cabinet
Provided ............................................................................................19
7. Power Indicating LED and Its Parts..................................................20
8. Inserting the External LED through Drilled Hole.............................20
9. Infinet Cable Wiring..........................................................................21
10. Attaching the Infinet Cable to Infinity CX 9000 or 9200 ..................22
11. Normally Closed Supervisory Inputs................................................2 6
12. Normally Open Supervisory Inputs..................................................2 7
13. Wiring Ordinary Switch to DoorSwitch Input ......................... ....... .2 8
14. Wiring Switch with Built-in Resistor to DoorSwitch Input .............29
15. Functioning of DoorSwitch Input Wired to Super vis ory Input ........30
16. Functioning of Passive Infrared (PIR) Motion Detector Switch
Wired to Supervisory Input........ ...... . .......................... .... ... ...... . ....... .31
17. Wiring Diagram for Counter or Digital Input...................................32
18. Connections Between Card Reader and Controller..........................33
19. Wiring Wiegand Card Reader (Sensor Engineering) to Controller........34
20. Connections Between Card Reader and Controller..........................35
21. Wiring Proximity Wiegand Card Reader to Controller, with
12 VDC Power Supply ......................................................................36
22. Connections Between Card Reader and Controller..........................37
23. Wiring Dorado ABA Card Reader to Controller..............................38
Andover Controls Corporation vii
Page 8
24. Wiring Diagram for DOOR and AUX Form C Outputs if
Normally Open..................................................................................41
25. Wiring Diagram for DOOR and AUX Form C Outputs if
Normally Closed...............................................................................4 2
26. Wiring External and AC Power to Controller and Modules.............46
B-1. Location of Card Type Jumpers.....................................................B-2
B-2. Jumpers for ABA Cards ................................................................. B-3
B-3. Jumpers for Wiegand Cards ...........................................................B-4
viii ACX 700 Installation Guide
Page 9
Tables
1. Maximum Length Wire for Card Readers............................................7
2. Connecting Jumpers for AC Input Voltages.......................................1 6
Andover Controls Corporation ix
Page 10
x ACX 700 Installation Guide
Page 11
Setting Up the ACX 700
Controller and Infinet
The ACX 700 is a building access controller that can control access to
two doors. You can use it to control access through up to four doors by
attaching two EMX 190 modules to the ACX 700.
You may set up access through either Wiegand or ABA card readers,
which read access cards, or security keypads, which accept access codes.
You may also use both the card reader and the security keypad together,
for extra tight security. This manual covers the following:
• Site/System Setup Requirement s
• Installing the ACX 700
• Powering Up the ACX 700
Warranty Registration
Your warranty is effective for 18 months starting on the date the system
is shipped.
Warning
All wiring and installations must comply with local, state, and national
electrical codes.
ACX 700 Installation Guide 1
Page 12
Hardware Instal lation
Site/System Setup Requirements
Before you proceed to install the system, you should map out where you
plan to install each controller, terminal/workstati on, and modem. When
planning the sites, be aware of any electrical interference that may occur. You also need to be aware of cabinet dimensions, power
requirements, cable limitations, an d environm ental requir e ments .
Note
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions in this manual, may cause harmful interference to radio
communications. Opera tion of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Note
This digital apparatus does not exceed the Class A limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
Avis
Le présent appareil numérique n’émet pas de bruits radioélectriq ues
dépassant les limites applicables aux appareils numériques de la class A
prescrites dans le Règlement sur le brouillage radioélectrique édicté par
le ministère des Communications du Canada.
2 ACX 700 Installation Guide
Page 13
Hardware Installation
Controller Dimensions and Weight
Each ACX 700 is 19 × 15 × 4.56 in. (483 × 381 × 116) and weighs 17
lbs. (7.73 kg).
Power Requirements
Caution
The ACX 700 should receive power from its own independent,
unswitched circuit.
You can choose to connect AC power or a 12 VDC uninterrupted power
supply (UPS), but not both. Instructions for how to connect the 12 VDC
UPS are included later, with the installation instructions.
To maintain the UL listing of your system, you should use a power supply listed by UL under APHV.
If you choose AC power, you can select an AC power supply voltage of
24 V, 115 V, or 230 V. You receive it set to 115 V. Instructions for selecting the power supply you want are included later, with the
installation instructions.
AC voltages you can select are as follows (each uses a 3 A slow blow
fuse):
• 24 VAC 50/60 Hz
• 115 VAC 50/60 Hz
• 230 VAC 50/60 Hz
The ACX 700 consumes 20 VA of power at 115/230 VAC and con-
sumes 50 VA of power at 12 VDC/24 VAC.
ACX 700 Installation Guide 3
Page 14
Cabl e Limitations
The maximum cable length for all buses is 4,000 ft. (1,200 m) at 19,200
baud (up to 32 Infinet controllers). You can extend buses beyond
4,000 ft. or put more than 32 Infinet controllers on less than 4,000 ft. by
using the InfiLink 200 amplification module.
Note
You mu s t use s hie ld ed ca bl es f o r Infinet to ensure compliance with the
Class A FCC limits and to provide reliable communications.
Cables that form Infinet are 24-gauge (0.25 mm), sing le-twisted-pair,
tinned, shielded copper wire. Use the following cables1 or the ir
equivalents:
Hardware Instal lation
• Brand Rex # H 9002 (single-pair)
• Anixter # 9J2401021 (single-pair plenum cable)
The cable should have a nominal impedance of 100 Ohms and a nomi-
nal velocity of propagation of 78%.
Capacitance of Infinet cable should be nominal, below 12.5 pF/ft
(41 pF/m) between conductors and below 22 pF/ft (72 pF/m) between
the conductor connected to ground and the next conductor.
Lightning Protection
Lightning Arrestors are required at each point where an Infinet or other
wiring (such as for a card reader) enters or exits a building. Use the
following arrestor: Two pair combination gas tube/silicon avalanche arrestor, Andover Controls # 01-210 0-299.
1. You can also use any cables you may already have in place for ACNET or LBUS.
4 ACX 700 Installation Guide
Page 15
Hardware Installation
Building Ground Requirements
Warning
Be sure that all Infi nity products from Ando ver Controls Corporation
are grounded to true earth ground. This kind of ground protects the
equipment from transients and other power surges in the area.
We cannot guarantee that the controller system will operate as
documented unless you properly grou nd all control lers .
Warning
Grounding should be in accordance with article 240 of the National
Electrical Code. Be sure to have your grounds inspected before you
begin the installation proc ess to be sure your municipality follows the
National Electrical Code. Many municipaliti es do not a nd often have
substandard electrical grounds.
An example of a substandard ground is a galvanized steel cold water
pipe. As the pipe corrodes, it does not act as a true ground. The corrosion acts as an insulator, raising the potential of the pipe with respect to
the ground.
When lightning strikes in the area of the ins talla tion, it drastically
changes the potential of the earth. Since properly grounded Andover
Controls units respond to changes in potential more rapidly than poorly
grounded electrical systems, a poorly grounded buildi ng tries to reach
ground through the Andover Controls system. The surge of current can
destroy electronic components on the controller board.
Surges of much lower potential than lightning also impact the reliability
of Andover Controls equipment.
ACX 700 Installation Guide 5
Page 16
Inspecting the Ground
You can check your ground as follows:
1. Check yo ur ground by firs t inspecti ng the buildi ng power distributi on
panel for ea rth ground ter mination. If the ground t ermination is any of
the following, it is not adequate and must be corrected:
• Does not exist.
• Is connected to a corroded or galvanized pipe.
• Is connected using a small gauge wire thinner than 14 AWG (16
or 18 AWG, for example, or less than 2.5 mm2).
2. Be sure your Andover Controls cabinet is connected to the ground
with a copper conductor that terminates at the distribution panel.
Hardware Instal lation
Environmental Requirements
The ACX 700 operates in rooms with temperatures ranging from 32 to
120°F (0° to 49°C) and with humidity between 10 and 95%, noncondensing.
Enclosure Requirements
If you did not purchase the Andover Controls cabinet, you purchased
the open class controller. The open class controller must be in an Underwriters Laboratories listed enclosure that is a minimum of 12.75 ×
30 × 2.75 in. (324 × 762 × 70 mm).
Special Wire for Card Reader Inputs
We recommend a five-conductor, 22-gauge ( 0. 35 mm2) shielded wire for
wiring card reader inputs.
Table 1 shows the various card brands and the maximum length for #18
gauge wire (1.0 mm2), then for #22 gauge (0.35 mm2) wire.
6 ACX 700 Installation Guide
Page 17
Hardware Installation
Table 1. Maximum Length Wire for Card Readers
Card Reader Type
Sensor Engineering
Proximity (12V at ACX 700) 250 ft (76 m) 100 ft (30 m)
Proximity (12V at Reader) 500 ft (152 m) 350 ft (106 m)
Dorado ABA Card Reader 500 ft (152 m) 200 ft (76 m)
* Model number 30387 for UL listed systems.
*
#18 Gauge
(1.0 mm2)
500 ft (152 m) 200 ft (60 m)
Special Wiring for Keypad Inputs
We recommend eight-conductor, 18-gauge shielded wire for wiring keypad inputs except for the Essex unit, which requires two extra wires
bringing its total to ten conductors.
8-conductor, shielded
10-conductor, shielded for E ssex Touch Pads
#22 Gauge
(0.35 mm2)
You can extend the length of this cable up to 500 ft.
Output Requirements
Two of the outputs are door outputs that control a door through a card
reader or keypad access. Each output is a Form C relay rated at 24 VAC,
5 A. You wire these outputs just as you would a digital/pulsed output.
Resolution of the output is 0.1 sec. You may choose to manually override
the output by setting the OVER RIDE switch to ON or OFF. Or you can
set it to AUTO to have the card reader control access through the door.
The OVERRIDE LED indicates at least one of the door outputs is on
manual control; the DOOR OPEN LED indicates the door is open.
The third output is an auxilia ry output, also a Form C relay rate d a t
24 VAC, 5 A. You may want to use this output for a bell or other audio
alarm indicator.
ACX 700 Installation Guide 7
Page 18
Input Requirements
Caution
Andover Controls inputs are designed to be used with the specified card
readers, two-wire door switches, two-wire motion sensors, and other
two-wire input devices; they do not provide sufficient power to operate
sensors requiring an external power supply of 12 or 24 VAC/DC .
Each ACX 700 contro lle r has the following inputs :
• Two card reader inputs that receive either the Wiegand fo rmat or the
standard ABA format. You set the switch next to each reader to
indicate Wiegand or ABA.
Hardware Instal lation
You may also have additional card readers by attaching one or two
EMX 190 modules to the ACX 700. The card reader may have an
LED, but does not have to. (UL listed systems must use model
30387 Sensor Engineering card readers. )
Maximum data rate for the card reader—1 ms between bits with a 50
µs bit width.
Maximum power available to each card reader is 35 mA at 5 VDC.
If the card reader requires 12 or 24 VCD, it requires an
external power supply.
• Eight supervisory inputs (1 through 8) that you can use for any of the
following types of inputs:
— Door switch that indicates the status of the door—open or closed.
Must have a 10 KΩ res istor in ser ies if normall y closed or in
parallel if normally open. The resistor allows the input to detect
tampering. Refer to the Infinity CX Programmer’s Guide for
2± 2±
details. Required.
— An exit reque st input, usu ally a motion s ensor tha t determines
someone is a pproaching the door or a push button that you mus t
press to leave the area. Must have a 10 KΩ resistor in series if
8 ACX 700 Installation Guide
Page 19
Hardware Installation
normal ly closed or in parall el if normally open. T he resistor allows
the input to detec t ta mp ering. Refer to the Infini ty CX Program-
mer’s Guide for details. Opt iona l.
— Two keypads , each a sing le inp ut (inputs 9 and 10), that you pl ace
near the door as an alternative to a card reader. The person punches
in an access code that the controller recognizes before allowing the
person access. You may have up to two ke ypads and/or two ca rd
readers. Each keypad has eight connections.
• One built-in tamper switch that indicates when the cabinet door has
been forced open. The switch is actually a button that reacts when
someone opens the cabinet door. You may also wire another switch
to the input if you install the unit in another cabinet. When the switch
is open, the cabinet tamper is ON.
Laying Out the Site Setup
You may want to draw a map of where you plan to put each controller
and store it in a notebook.
Find the tag attached to each controller that gives the number of the controller. Bef ore you remove any tags, be sure the tag has all of the
following information on it:
• Location of the controller.
• Serial number.
• Model name and number.
• Communications port the Infinet connects to on the ACX 700
controller.
Then collect the tags. You will need to know where your controllers are
located when you later assign a name to each controller and each input
and output.
ACX 700 Installation Guide 9
Page 20
Installing the ACX 700
Parts Required
To install a single controller you start with the following parts:
• ACX 700 Controller (with or without cabinet)
• AC Power Cable or 12 VDC UPS Power Supply and Cable
• Input and Output Wires
• Up to Two Card Readers and/or Two Keypads
• Up to Two Door Switches
• Up to Two Motion Sensors or Two Exit Buttons (or One of Each)
• LED with Wires Attached and Screws/Washers Included (if you
purchased the open class controller, without the Andover Controls
Hardware Instal lation
cabinet) (optional)
• One Cabinet Door Tamper Switch (optional)
• Infinet Cable (twisted pair)
• InfiLink 200s as Hubs, Repeaters, or Cable Switching Boxes as
required
• Up to two EMX 190 M odules (optional)
Mounting
Caution
You must keep the ACX 700 in the UL listed enclosure provided or
insert it in a UL listed enclosure.
1. Before you begin, if you have the enclosed unit, open the front door
of the ACX 700 cabinet.
Figure 1 shows the dimensions of the UL listed cabinet provided by
Andover Controls and the location of the mounting screw holes.
Figure 2 shows the dimensions of the open class UL listed unit and
the dimensions of the backplate for mounting.
10 ACX 700 Installation Guide
Page 21
Hardware Installation
Figur e 1. Di mensi ons an d Loca tion o f Moun ting Holes in Ca bine t
Provided, in inch es (m m )
15.00 (381)
1.33
(34)
12.35 (314)
1.00 (25)
GND
NEU
HOT
+12VDC
-INPUT
IN1
RET1
IN2
RET2
IN3
RET3
IN4
RET4
IN5
RET5
IN6
RET6
IN7
RET7
IN8
RET8
EXT
TAMPER
SWITCH
+5V
LED
I/DATA
O/CLK
GND
+5V
LED
I/DATA
O/CLK
GND
+
–
SHLD
AC
INPUT
AC INPUT VOLTAGE SELECTION
24V
FROM
E6
E4 E3
P1
PWR
ON
SUPERVISORY
INPUTS
TAMPER
SWITCH 9
ABA
WIEGAND
READER 1
READER 2
ABA
WIEGAND
INFIN ET
SERVICE
PORT
USE COPPER
COND UC T OR S
ONLY
115V
TO
FROME2TOP1FROM
E7
E6
E5
E4 E4 E5
E1
P1
E1 E2
F1
3A,250V
SLOW BLOW
RESET
230V
TO
----
+
B1
3.6V
1.8AHr
LITHIUM
-
CPU
TD
RD
+24VDC CLASS 11
160mA
EXPANSION
PORT
ACX700
KEYPAD 1
KEYPAD 2
OVERRIDE
AUTO/OFF/ON
AUTO/OFF/ON
AUTO/OFF/ON
C1
C2
C3
R1
R2
R3
R4
RET
C1
C2
C3
R1
R2
R3
R4
RET
DOOR 1
OUTPUT
DOOR
OUTPUT
OUTPUT 3
OVERRIDE
19.00
(483)
17.00
(432)
Caution
Never drill holes in the ACX 700 cover or boards. A metal shaving could
easily short circuit the electronics.
ACX 700 Installation Guide 11
Page 22
Hardware Instal lation
2. Position two standard No. 8 screws for the pre-cut eyelets in the
cabinet or backplate, and hang the cabinet or backplate on the
screws.
Figure 2. Dimensions and Location of Mounting Holes in
Backplate, in inches (mm)
12.54 (318)
R .117
(3)
.45 (11)
R .195
(5)
GND
NEU
HOT
+12VDC
-INPUT
IN1
RET1
IN2
RET2
IN3
RET3
IN4
RET4
IN5
RET5
IN6
RET6
IN7
RET7
IN8
RET8
EXT
TAMPER
SWITCH
+5V
LED
I/DATA
O/CLK
GND
+5V
LED
I/DATA
O/CLK
GND
+
–
SHLD
AC
INPUT
AC INPUT VOLTAGE SELECTION
24V
FROM
E6
E4 E3
P1
PWR
ON
SUPERVISORY
INPUTS
TAMPER
SWITCH 9
ABA
WIEGAND
READER 1
READER 2
ABA
WIEGAND
INFINET
SERVICE
PORT
TO
E7 E5
E1 E1 E2
RESET
11.72 (298)
USE COPPER
CONDUCTORS
ONLY
230V
115V
FROME2TOP1FROM
E6
E4 E4 E5
P1
F1
3A,250V
SLOW BLOW
CPU
TD
RD
+24VDC CLASS 11
160mA
TO
----
+
-
EXPANSION
PORT
B1
3.6V
1.8AHr
LITHIUM
ACX700
KEYPAD 1
KEYPAD 2
OVERRIDE
AUTO/OFF/ON
AUTO/OFF/ON
AUTO/OFF/ON
C1
C2
C3
R1
R2
R3
R4
RET
C1
C2
C3
R1
R2
R3
R4
RET
DOOR 1
OUTPUT
DOOR
OUTPUT
OUTPUT 3
OVERRIDE
11.50
(292)
1.45 (37)
14.25
(362)
Figure 3 shows the dimensions of the ACX 700 with an EMX 190. When
you attach modules, they must be enclosed in the same UL listed
enclosure as the controller. For additional modules, you require a larger
cabinet. You can find the exact dimensions of each module in the
installation instructions included with that modu le.
12 ACX 700 Installation Guide
Page 23
Hardware Installation
Figure 3. Dimensions of ACX 700 on Backplate with EMX 190s,
in inches (mm)
12.54 (318)
R .117 (3)
.45 (11)
R .195 (5)
GND
NEU
HOT
+12VDC
-INPUT
IN1
RET1
IN2
RET2
IN3
RET3
IN4
RET4
IN5
RET5
IN6
RET6
IN7
RET7
IN8
RET8
TAMPER
SWITCH 9
EXT
TAMPER
SWITCH
+5V
LED
I/DATA
O/CLK
GND
+5V
LED
I/DATA
O/CLK
GND
+
–
SHLD
AC
INPUT
INFINET
SERVICE
PORT
SUPERVISORY
11.72 (298)
USE COPPER
CONDUCTORS
ONLY
AC INPUT VOLTAGE SEL
FROM
E6
E4 E3 E4 E4 E5
P1
INPUTS
ABA
WIEGAND
READER 1
READER 2
ABA
WIEGAND
24V
115V
TO
FROME2TOP1FROM
E7
E5
E6
E1 E1 E2
P1
F1
3A,250V
SLOW BLOW
PWR
ON
RESET
230V
CPU
TD
RD
+24VDC CLASS 11
160mA
TO
----
+
B1
3.6V
1.8AHr
LITHIUM
-
EXPANSION
PORT
ACX700
KEYPAD 1
KEYPAD 2
OVERRIDE
AUTO/OFF/ON
AUTO/OFF/ON
AUTO/OFF/ON
C1
C2
C3
R1
R2
R3
R4
RET
C1
C2
C3
R1
R2
R3
R4
RET
DOOR 1
OUTPUT
DOOR
OUTPUT
OUTPUT 3
OVERRIDE
14.25 (362)
11.50
(292)
1.45 (37)
6.72
(171)
6.72
(171)
4.95
(126)
4.95
(126)
BOARD
1
2
OVERRIDE
OFF
ON
WIEGAND
CARD READER
BOARD
1
2
OVERRIDE
OFF
ON
WIEGAND
CARD READER
EMX190
DOOR SWITCH
EXIT REQUEST
CARD
READER
INPUT
DOOR
OUTPUT
AUTO
ABA
OVERRIDE
RTN
RTN
RTN
0-CLK
1/DATA
LED
+5V
NC
NO
24VDC
CLASS
EMX190
DOOR SWITCH
EXIT REQUEST
CARD
READER
INPUT
DOOR
OUTPUT
AUTO
ABA
OVERRIDE
RTN
RTN
RTN
0-CLK
1/DATA
LED
+5V
NC
NO
24VDC
CLASS
C
II
C
II
5.38 (137)
6.13 (156)
ACX 700 Installation Guide 13
Page 24
Figure 4. Cover Plate of the ACX 700
Hardware Instal lation
INPUT
GND
NEU
HOT
+12VDC
-INPUT
–
POWER
+
LED
IN1
RET1
IN2
RET2
IN3
RET3
IN4
RET4
IN5
RET5
IN6
RET6
IN7
RET7
IN8
RET8
TAMPER
SWITCH 9
EXT
TAMPER
SWITCH
+5V
LED
I/DATA
O/CLK
GND
AC
USE CO PPER
CONDUCTORS
AC INPUT VOLTAGE SELECTION
24V
FROM
TO
E6
E7 E5
E4 E3 E4 E4 E5
P1
E1 E1 E2
PWR
ON
SUPERVISORY
INPUTS
RESET
ABA
WIEGAND
READER 1
ONLY
115V
FROME2TOP1FROM
E6
P1
F1
3A,250V
SLOW BLOW
CPU
230V
TO
----
+
LITHIUM
-
B1
3.6V
1.8AHr
ACX700
KEYPAD 1
KEYPAD 2
OVERRIDE
AUTO/OFF/ON
C1
C2
C3
R1
R2
R3
R4
RET
C1
C2
C3
R1
R2
R3
R4
RET
DOOR 1
OUTPUT
+5V
LED
I/DATA
O/CLK
GND
+
–
SHLD
INFINET
SERVICE
PORT
READER 2
ABA
WIEGAND
TD
RD
+24VDC CLASS 11
A
160
m
EXPANSION
PORT
AUTO/OFF/ON
AUTO/OFF/ON
DOOR 2
OUTPUT
OUTPUT 3
OVERRIDE
14 ACX 700 Installation Guide
Page 25
Hardware Installation
Figure 4 shows the loca tion of various parts ins ide the ACX 70 0, labe led
on the cov er plate . Note th e par ts of the co ntroll er labe led here. You may
want to refe r to this figure to locate parts during the installation p rocess.
Connecting the AC Power
Warning
Be sure the AC power cable is not connected to an electrical power
source while you are wiring the controller, or you could receive an
electrical shock that is life-threatening.
If you choose to use a 12 VDC UPS power supply, skip these instructions and go to the section called Connecting the UPS Power Supply.
The AC power connection is in the upper left corner of the controller.
You must wire the AC cable to the three scre ws on the far le ft .
Caution
Be sure to connect all three wires, HOT, NEUTRAL, and GROUND.
Otherwise, the controller could malfunction.
The three screws are labeled GND, NEU, HOT.
1. Place the ground wire under the metal plate behind the screw labeled
GND.
2. Tighten the screw with a flathead screw driver.
Figure 5 shows the position of the plate, where to place the wire, and
how the screw fits on the plate. You can see how the screw holds the
plate in place once you tighten it.
ACX 700 Installation Guide 15
Page 26
Hardware Instal lation
Figure 5. Metal Plate and Screw for Power Supply Wire
Metal Plate
Insert Wire Here
3. Place the neutral wire under the metal plate behind the screw labeled
NEU.
4. Tighten the screw with a flathead screw driver.
5. Place the hot wire under the metal plate behind the screw labeled
HOT.
6. Tighten the screw with a flathead screw driver.
Selecting the AC Input Voltage
The voltage is set to 115 V when shipped. To change the voltage, you
must reset the jumpers to the right of the AC power cord c onnec tion.
Table 2 shows jumper settings for the three voltages.
Table 2. Connecting Jumpers for AC Input Voltages
24V Jumpers 115V Jumpers 230V Jumpers
From To
E6 E7
E4 E3
P1 E1
From To
E6 E5
E4 E2
P1 E1
From To
— —
E4 E5
P1 E2
To change the voltage from 115 V to 24 V, proceed as follows:
1. Disconnect the jumper end from E5 and move it to E7 so it jumpers
E6 to E7 .
16 ACX 700 Installation Guide
Page 27
Hardware Installation
2. Disconnect the jumper end from E2 and move it to E3 so it jumpers
E4 to E3 .
3. Leave the other jumper as it is.
To change the voltage from 115 V to 230 V, proceed as follows:
1. Disconnect the jumper from E6 to E5 and remove it.
2. Disconnect the jumper from E5 and connect it to E2, so it jumpers
E4 to E2 .
3. Disconnect the jumper from E1 and connect it to E2, so it jumpers
P1 to E2.
Connecting the UPS Power Supply
If you choose to connect the controller to a UPS power supply, you may
not also connect it to AC power.
Note
Be sure to size the power supply to provide 1.6 A for each ACX 700
controller. If the supply also provides power to motion sensors, card
readers, or other auxiliary devices, be sure to size the power supply
accordingly.
Wire the UPS power supply to the terminal block connector below the
AC input labeled +12VDC INPUT. The connector is immediately to the
left of the power indicator light labeled PWR ON.
You wire the power supply as follows:
1. Slip the hot wire under the screw labeled + and tighten the screw
down on the wire.
2. Slip the ground wire under the screw labeled – and tighten the screw
down on the wire.
Once the power supply is connected, the PWR ON light should light up.
ACX 700 Installation Guide 17
Page 28
Connecting the Power Indicating LED
Caution
If you purchased the ACX 700 enclosed in the Andover Controls
cabinet, skip this section and proceed with the next section, Wiring the
Infinet to the ACX 700.
If you purchased the ACX 700 without the cabinet (open class), included with it is an LED that you can wire to the printed circuit board and
mount on the front of the UL listed enclosure. This LED lights up to indicate that the unit is receiving power.
Mounti ng the LED
Hardware Instal lation
If you had the cabinet provided by Andover Controls, you would see the
1
LED on the front door of the cabinet, approximately -in. (6 mm) to the
-- 4
left of and below the logo/product name.
Figure 6 shows where the LED would be located. You should position
the LED in an approximately equivalent location.
18 ACX 700 Installation Guide
Page 29
Hardware Installation
Figure 6. Location of Power Indicat ing LED on
Front Door of Cabinet Provided
Location of
Power Indicating
LED on Front
Door of Cabinet
Provided
To mount the LED on the front of the UL enclosure for the open class
controller, proceed as follows:
3
1. If you have an open class controlle r, drill a -in. (9.5 mm) hole in
-- 8
the front of the enclosure for it. Drill the hole approximately in front
of where the controller is labeled EXTERNAL LED on the cover
plate.
2. Find the LED included with the controller. It should have two wires
on the back end.
Figure 7 shows the LED with the three nuts and one washer on it.
ACX 700 Installation Guide 19
Page 30
Figure 7. Power In dicating LED and Its Parts
LED
Red Wire (+)
Hardware Instal lation
Black W ire (–)
3/16-in.
(4.7 mm)
Front Nut
1/16-in.
(1.5 mm)
Front Nut
HexagonalWasher
Nut
3. Remove the two front nuts from the LED assembly.
4. Insert the LED through the drilled hole.
Figure 8 shows how to insert the LED through the drilled hole.
Figure 8. Inserting the External LED through Drilled Hole
Outside Cabinet
or Enclosure
Cabinet Do or
Inside Cabinet
or Enclosure
1
5. Screw the -in. (1.5 mm) front nut approximately in. (6 mm) onto
----- 16
1
-- 4
the threaded area.
3
6. Screw the -in. (4.7 mm) front nut on as far as you can.
7. Unscrew the -in. (1.5 mm) nut until it is tight against the -in.
----- 16
----- 16
1
----- 16
3
(4.7 mm) frontmost nut and secures it.
8. Tighten the hexagonal nut from the rear until it is tight against the
inside of the enclosure.
20 ACX 700 Installation Guide
Page 31
Hardware Installation
Now, you are ready to wire the LED to the controlle r.
Wirin g the Power Indicating LED
You wire the LED to the screws labeled +/ – POWE R LED
as follows:
1. Slip the red wire for the sensor under the screw labeled + next to
POWER LED and tighten the screw down on it.
2. Slip the black wire under the screw labeled – next to POWER LED
and tighten the screw down on it.
Wiring the Infinet to the ACX 700
Note
You mu s t use s hie ld ed ca bl es f o r Infinet to ensure compliance with the
Class A FCC limits and to ensure reliable communications.
Figure 9 illustrates how to w ire the Infinet cable to the remov a ble
terminal block connector in the lower left corner of the ACX 700.
Figure 9. Infinet Cable Wiring
Infinet Connection
+
–
SHLD
1. Trim back the shield over the wires.
2. Take the first wire for the incoming Infinet and the first wire for the
outgoing Infinet and slip both in the hole beneath the screw labeled
with a plus sign.
3. Tighten the screw down on them until the scr ew holds the wir es in
place.
ACX 700 Installation Guide 21
Page 32
Hardware Instal lation
4. Slip the second (usually black) wire from each Infinet cable under
the screw labeled with a minus sign and tighten the screw down on
them.
5. Slip the shields from the incoming and outgoing Infinet cables under
the screw labeled SHLD and tighten the screw down on them.
Wiring the Infinet to the Infinity CX 9000 or 9200
You connect the last piece of Infinet cabling to the Infinity CX 9000 or
9200, as described below (refer to the illustration):
1. Open the front of the Infinity CX 9000 controller cabinet.
Notice that to the left are three ports labeled COMM1, COMM2, and
COMM3. Two RS-485 ports, one above the three comm ports and
one below, are in the same area.
Notice that the end of the Infinet cable has two wires and a shield.
You wire them to the terminal block connector on the RS-485 port.
Figure 10 illustrates how to wire the Infinet cable to the Infinity CX
9000 or 9200.
Figure 10. Attaching the Infinet Cable to Infinity CX 9000 or 9200
+IN
–IN
SHLD
+OUT
–OUT
2. Run the cable through the knockout on the left side of the controller.
3. Select the port to wire the cable to—on a 9000, either the RS-485
port just above the three RS-232 ports (COMM2) or the RS-485 port
just below the three RS-232 ports (COMM1). Once you use either of
22 ACX 700 Installation Guide
Page 33
Hardware Installation
these ports for COMM1 or COMM2, the RS-232 port for COMM1
or COMM2 is disabled. On a 9200, you can also select COMM4.
4. Trim back the shield over the wires.
5. Slip the first wire through the hole under the screw labeled +IN and
jumper it to the screw labeled +OUT.
6. Tighten both screws to hold the wire there.
7. Slip the ground wire through the hole under the screw labeled
–IN and jumper it to the screw labeled –OUT.
8. Tighten both screws to hold the wire there.
9. Slip the shield in under the middle screw labeled SHLD and tighten
the screw to hold it there.
ACX 700 Installation Guide 23
Page 34
Wiring Inputs
Caution
Do not remotely ground any part of the sensor wiring. Remote grounds
connected to the ACX 700 return terminal could make the controller
operate incorrectly or damage the equipment. T he signal return is not tr ue
earth ground. It is a n electronic reference point necessary to interpret the
sensor properly. Do not externally ground sensor or switch terminals that
return to the ACX 700.
Caution
Card readers requi re sh i e l ded wiring .
Hardware Instal lation
Although two-wire inputs us ually funct ion properly with unshielded
sensor wire, you may need shielded wire if you run the wire as follows:
• In the same conduit with other noise-generating conductors such as
60 Hz AC power.
• In long runs close to large power-consuming or power-generating
equipment that can produce 60 Hz noise.
We recommend you run input wiring in a conduit separate from AC
power or output wiring and avoid long wiring runs.
The “supervisory” inputs are on the upper left side of the ACX 700, just
below the 12VDC UPS power connector. Input wires should enter from
the left side. Notice that the inputs are labeled IN1, RET1, IN2, RET2,
IN3, RET3, IN4, RET4, and so on, for up to eight inputs. The first return
terminal goes to the first input, the second to the next input, and so on.
24 ACX 700 Installation Guide
Page 35
Hardware Installation
Caution
Follow the rules below when wiring inputs and outputs:
• Never lay wires across the surface of the printed circuit board. You should
bring input wires in from the left and output wires in from the right.
• Bundle excess wires toward the back of the cabinet to avoid any
contact with circuit boards.
• Wires should never be within 1 in. (25 mm) of any component on the
printed circuit board.
• Keep cabinet free of foreign materials (extra power supplies, relays,
and so on).
• Be careful when stripping wire not to drop small pieces of wire
inside the cabinet.
If you violate any of these rules, the controller could malfunction.
ACX 700 Installation Guide 25
Page 36
Supervisory Input Circuits
All 700/780 controller series inputs are supervisory inputs. The follow-
ing drawings depict the six types of supervisory inputs that exist—three
normally closed and three normally open types. After the drawings,
there is an explanation of which types are recommended for access control installations.
Figure 11 shows the three types of normally closed superviso ry input s.
Figure 11. Normally Closed Supervisory Inputs
NC Series
Door Closed SW Closed 10K
Door Open SW Open Infinite
SW Shorted Zero K
Wire Cut Infinite
Hardware Instal lation
Door Open and Wire Cut conditions both result in an infinite reading
If the door was sensed open without a valid card swipe, a Door Violation
should be triggered.
.
NC Parallel
Door Closed SW Closed Zero K
Door Open SW Open 10K
SW Shorted Zero K
Wire Cut Infinite
Not the best choice, the switch could be shorted and the door forced open,
and the system would still think the door was closed.
NC Series and Parallel
Door Closed SW Closed 5K
Door Open SW Open 10K
SW Shorted Zero K
Wire Cut Infinite
This configuration is the best choice; the parallel and series resistors
provide a redundant security feature.
26 ACX 700 Installation Guide
Page 37
Hardware Installation
Figure 12 shows the three types of normally open supervisory inputs.
Figure 12. Normally Open Supervisory Inputs
NO Series
Door Closed SW Open Infinite
Door Open SW Closed 10K
SW Shorted Zero K
Wire Cut Infinite
This configuration is not the best choice. If the wire is cut and
forced open,
and the system senses that the door is still closed .
the door
NO Parallel
Door Closed SW Open 10K
Door Open SW Closed Zero K
SW Shorted Zero K
Wire Cut Infinite
This configura ti o n is defea ted by shorti n g the switch . The systems senses this
condition as a normal door open situation. However if the wire is cut, that is a
unique resistance that can easily be identified as a tampering situation.
NO Series and Parallel
Door Closed SW Open 10K
Door Open SW Closed 5K
SW Shorted Zero K
Wire Cut Infinite
This configuration provides the most security. There are four unique resistance values
associated with the four possible conditions.
We recommend
NO Parallel
NO Series and Para llel
and
types for
access control instal lations. The next sections explain how to wire these
types of inputs for door switches and motion detectors.
ACX 700 Installation Guide 27
Page 38
Wiring Door Switches
You may wire up to two of the eight supervisory inputs to door switches. The maximum length wire you may use is 500 ft of #18 gauge wire
(152 m of 1.0 mm2) or 200 ft of #22 gauge wire (60 m of 0.35 mm2).
You wire the door switch as follows (switches may be either normally
open or normally closed):
1. Slip the appropriate wire under the IN screw and tighten the screw
down on it.
Figure 13 shows the wiring diagram for the input if the door switch
is an ordinary switch. This swi tch can dete ct e ither the switch
position, or tampering if the switc h has an ope n fault. If the s witc h
is shorted, it appears closed.
Hardware Instal lation
Figure 13. Wiring Ordinary Switch to DoorSwitch Input
RET
Ω
10 K
IN1
28 ACX 700 Installation Guide
Page 39
Hardware Installation
Figure 14 shows the wiring diagram for the input if the door switch
has a built-in series resistor. This switch can detect either the switch
position, or tampering where the switch is shorted or grounded. We
recommend this switch for situations requiring the greatest security.
Figure 14. Wiring Switch with Built-in Resistor to
DoorSwitch Input
RET
IN1
10 K
Ω
Each switch requires a single parallel resistor to provide extra
security should an intruder attempt to break in through the door by
closing the contact.
2. Slip the ground wire under the RET screw that corresponds to the IN
number and tighten the screw down on it.
3. Be sure you wire the 10 KΩ resistor in parallel as shown in each
diagram.
Figure 15 shows the how the door switch works if it is an ordinary
switch (normally open). The switch remains open while the door is in a
normal state (clo sed or not tampered with). If th e switch de te cts the
door is open or has been tampered with, it appears closed.
ACX 700 Installation Guide 29
Page 40
Hardware Instal lation
Figure 15. Functionin g of DoorSwitch Input Wired to
Supervisory Input
Normally Open DoorSwitch
Access
Controller
Ω
10 K
Door Closed
(Normal)
Normally Open DoorSwitch
Access
Controller
Ω
10 K
Detects
Door Open
Wiring Motion Sensors/Exit Push Buttons
You may wire up to two of the first four supervisory inputs to motion
sensors or exit buttons. You wire them the same way you wire DoorSwitch inputs, only the motion sensor requires an external power supply
of 12 VDC or 24 VDC (UL listed under APHV). The maximum
length wire you may use is 500 ft of #18 gauge wire (152 m of 1.0 mm2)
2± 2±
or 200 ft of #22 gauge wire (60 m of 0.35 mm2).
Be sure that when you wire the motion detector, it is correctly set up, as
illustrated in the next figure.
30 ACX 700 Installation Guide
Page 41
Hardware Installation
Figure 16 shows the how the motion detector works if it is an ordinary
Passive Infrar ed (PIR) Motion Detector. The switch (norma ll y o pen )
remains open while it detects no motion or tampering If the switch
detects motion, it appears closed.
Figure 16. Functioning of Passive Infrared (PIR) Motion
Detector Switch Wired to Supervisory Input
Access
Controller
Normally Open PIR Motion Detector
No Motion
Detected
Ω
10 K
Access
Controller
Normally Open PIR Motion Detector
Ω
10 K
Motion
Detected!!!
ACX 700 Installation Guide 31
Page 42
Wiring Other Two-Wire Inputs
Follow these steps to wire two-wir e inputs :
1. Slip the first wire for the sensor under the screw labeled IN5 and
tighten the screw down on it.
2. Slip the ground wire under the RET5 screw and tighten the screw
down on them.
3. Repeat the steps for each pair of inputs.
Figure 17 shows a counter wired to an input point.
Figure 17. Wiring Diagram for Counter or Digital Input
Hardware Instal lation
1 (input point 1)
Wiring Card Reader Inputs
Be sure you wire all card readers with shielded wiring.
The maximum length of wire you may use depends on the card reader
brand name and the type of wiring/cable you use. Refer to the earlier
sections in this manual.
In the case of Proximity card readers, you may connect the required
12 VDC power supply at the ACX 700 or at the card reader.
2±
RET (return)
32 ACX 700 Installation Guide
Page 43
Hardware Installation
Wiring Wiegand Card Reader (Sensor Engineering)
Wire the Sensor Engineering Wiegand card reader to the READER 1
and READER 2 inputs on the lower left side of the ACX 700 as follows:
1. Look at the wire connection on your Wiegand card reader. Notice
that you have five connection points:
•+ 5VDC
• DATA1
• DATA0
•LED
• GND
2. Wire the first end of each wire to the appropriate connection point
on the card reader.
Figure 18 shows where to connect the various wires on the card
reader and the ACX 700.
Figure 18. Connections Between Card Reader and Controller
Card Reader
+5VDC
DATA1
DATA0
LED
GND
ACX 700
+5V
LED
1/DATA
0/CLK
GND
Controller
3. Slip the other end of the +5VDC wire under the +5 V screw on the
controller and tighten the screw down on it.
4. Slip the other end of the DATA1 wire under the 1/DATA screw on
the controller and tighten the screw down on it.
5. Slip the other end of the DATA0 wire under the 0/CLK screw on the
controller and tighten the screw down on it.
ACX 700 Installation Guide 33
Page 44
Hardware Instal lation
6. Slip the other end of the LED wire under the LED screw and tighten
the screw down on it.
Figure 19 illustrates where you connect the various wires.
Figure 19. W iring Wiegand Card Reader (Sensor Engineerin g) to
Controller
Card Reader
+5VDC
DATA1
DATA0
LED
Shield
GND
ACX 700
+5V
LED
1/DATA
0/CLK
GND
7. Slip the GND wire and the shield under the GND screw and tighten
the screw down on it.
8. Tie back the shield at the card reader end and any wires you do not use.
9. Set the switch on the ACX 700 cover plate (to the right of the wiring)
to WIEGAND.
34 ACX 700 Installation Guide
Page 45
Hardware Installation
Wiring Proximity PR-10/PR-12 Card Reader
The Proximity card reader requires a 12 VDC power supply. You
2±
wire the card reader inputs as follows:
1. Look at the wire connections on your Wiegand card reader:
•0
•1
•LED
•+12
• GND
2. Wire the first end of five wires to the appropriate connection point.
Figure 20 shows where to connect the various wires on the card
reader and the ACX 700.
Figure 20. Connections Between Card Reader and Controller
Card Reader
ACX 700
Controller
0
1
LED
+12*
GND
* see next illust r ati on
+5V
LED
1/DATA
0/CLK
GND*
3. Tie back the shield at the card reader end.
4. Slip the other end of the 0 wire under the 0/CLK screw on the
controller and tighten the screw down on it.
5. Slip the other end of the 1 wire under the 1/DATA screw on the
controller and tighten the screw down on it.
6. If the controller has an LED, slip the other end of the LED wire
under the LED screw on the controller and tighten the screw down
on it.
ACX 700 Installation Guide 35
Page 46
Hardware Instal lation
Figure 21 illustrates where you connect the various wires, including
the shield and the 12 V power supply.
2±
Figure 21. Wiring Proximity Wiegand Card Reader to Controller,
with 12 VDC Power Supply
0
1
LED
+12
GND
Card Reader
+12 wire
from reader
+
SHIELD
extensi on wir e
(Two wires and
shield go to GND)
GND
+5V
LED
1/DATA
0/CLK
GND
ACX 700
+12 +/-2 VDC
Power Supply
7. Wire the other end of the +12 wire to the positive terminal of a 12
2±
VDC power supply.
8. Attach an extension wire to the GND terminal of the 12 VDC
2±
power supply.
9. Take the other end of the extension wire from the 12V power supply,
the other end of the cable GND wire, and the end of the shield. Slip
all of them under the GND screw on the module; tighten the screw
down on them.
10. Set the switch on the ACX 700 cover plate (to the right of the wiring)
to WIEGAND.
36 ACX 700 Installation Guide
Page 47
Hardware Installation
Caution
The power supply for the Proximity card reader must have the following specifications:
• Be nonswitching and fully regulated.
• Ripple must be less than 2 mV.
• Size the output for the amperage plus 25%. The PR-10 or PR-12
draws 150 mA, the PR-20 or PR-22 draws 250 mA.
We recommend you use a UL listed power supply.
Wiring the Dorado ABA Card Reader
You wire the Dorado ABA card reader inputs as follows:
1. Look at the wire connections on your ABA card reader:
•+5
•LED
• DATA
•CLK
•COMMON
2. Wire the first end of each wire to the appropriate connection point
on the card reader.
Figure 22 shows where to connect the various wires on the card
reader and the ACX 700.
Figure 22. Connections Between Card Reader and Controller
Card Reader
+5V
ACX 700
+5V
Controller
LED
DATA
CLK
COMMON
ACX 700 Installation Guide 37
LED
1/DATA
0/CLK
GND
Page 48
Hardware Instal lation
3. Slip the other end of the +5 wire under the +5 V screw on the
controller and tighten the screw down on it.
4. Slip the other end of the LED wire under the LED screw and tighten
the screw down on it.
5. Slip the other end of the DATA wire under the 1/DATA screw on
the controller and tighten the screw down on it.
6. Slip the other end of the CLK wire under the 0/CLK screw on the
controller and tighten the screw down on it.
7. Slip the other end of the COMMON wire under the GND screw and
tighten the screw down on it.
Figure 23 illustrates where you connect the various wires.
Figure 23. Wiring Dorado ABA Card Reader to Controller
+5V
LED
DATA
CLK
COMMON
Card Reader
ACX 700
8. Tie back the shield as well as any wires you do not use.
9. Set the switch on the ACX 700 cover plate (to the right of the wiring)
to ABA.
If you would like to connect a different card reader, contact your Andover Controls representative.
+5V
LED
1/DATA
0/CLK
GND
For information on how to assign and program the inputs and outputs,
see the Infinity CX Programmer’s Guide.
38 ACX 700 Installation Guide
Page 49
Hardware Installation
Wiring Keypad Inputs
You wire the keypads to the keypad inputs on the right side of the controller, near the middle. The maximum length of wire to the keypad is
200 ft of #22 gauge wire (152 m of 1.0 mm2) and 500 ft of #18 gauge
wire (60 m of 0.35 mm2).
Wire the keypad inputs to the input terminals marked C1, C2, C3, R1,
R2, R3, R4 and RET as follows:
1. Slip the wire marked COL1 on the keypad under the screw marked
C1 and tighten the screw down on it.
2. Slip the wire marked COL2 on the keypad under the screw marked
C2 and tighten the screw down on it.
3. Repeat the previous step for COL3, connecting them to C3.
4. Slip the wire marked ROW1 on the keypad under the screw marked
R1 and tighten the screw down on it.
5. Slip the wire marked ROW2 on the keypad under the screw marked
R2 and tighten the screw down on it.
6. Repeat the previous step for ROW3 and ROW4, connecting them to
R3 and R4.
7. Slip the shield under the screw marked RET and tighten the screw
down on it.
8. Repeat the entire process for the second keypad.
The remaining two wires for the Essex Keypad are connected as
follows:
1. Connect the wire labeled 5VDC POWER (red) to the appropriate
+5V Reader terminal.
2. Connect the wire labeled LED (white) to the appropriate LED Reader terminal.
ACX 700 Installation Guide 39
Page 50
Wiring Outputs
The outputs are on the lower right side of the ACX 700, labeled
DOOR1, DOOR2, and AUX. All output wires should enter from the
right.
Wiring Door Outputs
Wire the door and auxiliary outputs as follows:
You wire the door outputs like any other Form C output, as follows:
1. Slip the appropriate wire under the NC screw and tighten the screw
down on it.
2. Slip the appropriate wire under the C screw and tighten the screw
Hardware Instal lation
down on it.
3. Slip the appropriate wire under the NO screw and tighten the screw
down on it.
4. We recommend you install a metal oxide varistor (Andover part #
01-2020-095, purchased separately) across the door strik e or lock
being switched.
40 ACX 700 Installation Guide
Page 51
Hardware Installation
Figure 24 shows the schematic for wiring a DOOR or AUX output if the
circuit is normally open.
Figure 24. Wiring Diagram for DOOR and AUX Form C
Outputs if Normally Open
NC
Oxide Metal
Varistor
(Andover #01-2020-095)
C
NO
C
+ –
Door Strike
(UL listed burglary-
12/24V
resistant electric
locking mechanism
Power Supply
(UL listed power
(CVXY) for
UL listed systems)
supply (APHV) for
UL listed systems)
This configuration shows a normally deenergized lock (when secured)
in a fail secure mode. Always be sure to use “panic” hardware that allows emergency exit from the secured area.
ACX 700 Installation Guide 41
Page 52
Hardware Instal lation
Figure 25 shows the schematic for wiring a DOOR or AUX output if the
circuit is normally closed.
Figure 25. Wiring Diagram for DOOR and AUX Form C
Outputs if Normally Closed
Oxide Metal
Varistor
NC
(Andover #01-2020-095)
C
NO
Electromagnetic
C
Door Lock
(UL listed burglaryresistant electric
locking mechanism
12/24V
(CVXY) for
UL listed systems)
Power Supply
(UL listed power
supply (APHV) for
UL listed systems)
This configuration shows a normally deenergized lock (when secured)
in a fail secure mode. If power loss occurs, the lock circuit opens.
Connecting Modules to the Expansion Port
The expansion port at the bottom center of the controller board allows
you to connect modules to expand the capabilities of the controller.
For details on installing the E M X 190, see the E MX 190 Ins tal lation
Guide provided with the unit.
42 ACX 700 Installation Guide
Page 53
Hardware Installation
Caution
If you are wiring an ACX 700 rather than an ACX 710, disregard the
Modules Configuration Guide included with the unit a nd follow the
guidelines that follow.
You can install multiple expansion modules, along with the EMX 190s,
on the ACX 700, as long as you comply with the following:
• Never attach more than two modules of the same model to the
controller.
• Do not exceed the maximum total number of inputs or outputs
allowed on the controller.
The maximum number of inputs/outputs allowed on the ACX 700 is as
follows:
Outputs
• Maximum Base Outputs (already on control ler) —3
• Maximum Expansion Mo dule Output s— 4
• Maximum Tota l Outputs—7
Inputs
• Maximum Base Supervisory Inputs (already on controller)—8
• Maximum Expansion Mo dule Input s— 21
• Maximum Total Input s— 29
If the modules, however, consume a total greater than 166 mA, you
must add an external power supply (more later).
ACX 700 Installation Guide 43
Page 54
Caution
Do not attach an output module, an input module, then another output
module, as this later causes confusion when assigning input and output
numbers.
Attach Modules in Order
You should first attach all output modules, then all input modul es.
Expansion Outputs Allowed
Of the output modules available, you can have up to 4 expansion outputs on an ACX 700 controller.
Expansion Inputs Allowed
Hardware Instal lation
Before you add any input modules to the ACX 70 0, the first 4 inputs you
define are the supervisory inputs on the EMX 190s. Of the input modules you can attach, you can always have a maximum of two EMX 160s
and one EMX 170s for 17 more expansion inputs; the first 4 plus the 17
is a total of 21 expansion inputs.
EMX 190 Modul es
EMX 190s must always be the first two expansion output modules on
the chai n .
Other Output Modules
After the EMX 190s, you can have one more and only one output module with up to two outputs—and it can be any of the following:
• EMX 150
• EMX 151
• EMX 155
• EMX 140—If you attach an EMX 141 or 143, you must count the one
output as two when numbering the outputs.
44 ACX 700 Installation Guide
Page 55
Hardware Installation
First Input Modules
EMX 160s (or other digital/counter input modules with up to 16 inputs
between them) must always be the first two expansion input modules on
the chai n .
Place EMX 170 at End of Chain
If you have an EMX 170 or expect to add one in the future, the EMX 170
must always be the last module on the entire chain.
Setting Board Switches on Modules
You must always set the first modu le of a partic ula r mod el number to
Board 1. So, we strongly advise that you attach the modules of the same
model number one immedi a tely afte r the othe r .
You must set the first output module on the chain to Board 1, the second
to Board 2, the third to Board 1, the fourth to Board 2, and so on—no
matter which model number modules. When you start the input modules, start at again Board 1 and continue to alternate from 1 to 2.
Wiring Power Supply for Modules
After you have installed the modules, if you require an external power
supply, refer to the Modules Configuration Guide for details regarding
how much external power each module you attach requires.
You must wire the power supply to ensure that the modules receive
power at the same time that the controller does.
ACX 700 Installation Guide 45
Page 56
Hardware Instal lation
Figure 26 shows how to wire the power supply. You must wire it to the
AC power source as shown.
Figure 26. Wiring External and AC
Power to Controller and Modules
120 VAC
700
Modules
24 VDC
+
External
Power
Supply
120 VAC
–
46 ACX 700 Installation Guide
Page 57
Hardware Installation
Powering Up the ACX 700
Warning
Before powering up the controller, be sure the board is jumpered for the
correct input voltage.
Before you proceed, be sure the following are correct:
1. Be sure you have jumpered the proper input voltage.
2. Be sure the battery is conne cte d.
3. Be sure the AC power or UPS 12 VDC power source is wired properly.
For AC power, check to be sure all three wires have been connected.
4. Be sure the controller has a true earth ground.
5. Be sure you have used the proper cables/wires and the correct lengths.
6. Be sure you have properly labeled the tag with the name of the
controller before removing the tag.
7. Be sure the Infinet cable has been properly wired.
8. Be sure the Infinet cable shields are properly connected.
If you have completed all previous sections in this manual, you are now
ready to power up the controller.
Turn on the AC power source (or close the power connection) and the
controller starts automatically. The following occurs (also occurs when
you press RESET):
1. If the controller has been off, relays remain off. If you have pressed
RESET, relays deenergize.
2. The CPU light begins flashing and flashes every.1 sec if all is
normal. If the controller fails a ROM test, the CPU light flashes
every .2 sec. If the controll er fails a RAM test, the C PU light flashes
ACX 700 Installation Guide 47
Page 58
Hardware Instal lation
every .025 sec. If the controller fails any other software test, it
flashes every .05 seconds.
3. The POWER LED on the front of the cabinet turns on and remains
on as long as the unit is receiving power.
4. The TD light may not flash at this time. Once you have set up the
Infinet controller in the software and assigned the controller an ID,
the TD light immediately starts flashing to show data is being
transmitted.
5. The RD light begins flashing only if data is being received from
other controllers on the network. This may not happen immediately.
6. If any of the three outputs is not set to AUTO, the OVERRIDE light
remains steadily on.
7. The E XTERNA L +24V li ght t urns on and rem ains s teadi ly on . Whe n
the EXTE RNAL +24V light goes out, it m ea ns no power i s be ing
supplie d to the e xpans ion port. Y ou may have to re place t he fuse. See
the Andover Controls Infinet Controller Troubleshooting Guide.
Reset Button
The RESET button is the red square button to the left of the vertical center of the board. You press it to restart the controller without erasing
memory. The same events occur as described above.
Connecting the Battery
When you have the controller mounted, find the AA battery. Remove
the plastic tab below the clip on the battery to activate the battery.
The battery is an 1.8 A 3.5 V primary lithium battery that runs the realtime clock and maintains RAM when AC power goes ou t.
48 ACX 700 Installation Guide
Page 59
Hardware Installation
Connecting the Andover Controls Service Tool
The SERVICE PORT on the left side of the bottom of the controller is
to connect the Andover Controls Service Tool to an ACX 700. The service tool accesses all ACX 700s and other Infinet controllers on the same
network. For information on availability of the Andover Controls Service Tool, contact your Andover Controls representative.
ACX 700 Installation Guide 49
Page 60
Hardware Instal lation
50 ACX 700 Installation Guide
Page 61
Appendix A
Underwriters Laboratories
Requirements
This appendix explains all requirements for installing the ACX 700 in a
UL listed system.
ACX 700 Installation Guide A-1
Page 62
The ACX 700 is listed by Underwriters Laboratories, Inc. for standard
UL 294, Access Control System Units, as a stand-alone unit. A UL
listed system must be set up in one of the following ways:
• The ACX 700 enclosed class controller board residing in the ACX
700 enclosure.
OR
• The ACX 700 open class controller residing in a listed enclosure,
with or without one or two EMX 190 modules. See the section called
Installing the ACX 700.
You must install the controller and accessories in accordance with the
UL requirements stated in this manual to have a UL listed access control
system. Failure to install the access control system in accordance with
the UL requirements liste d in this manua l is a violation of the lis ting
mark of Underwriters Laboratories.
EMX 190 modules are UL listed for use with the ACX 700 i n access control systems. These modules are designed for use with the open class
ACX 700 for access control. Each ACX 700 is limited to two EMX 190
modules.
UL has examined th e ACX 700 controller with Sensor Engineering card
reader model 30387. For other accessories (door switches, door locks,
etc.) and specific two-wire inputs you should use in UL listed systems,
consult the UL listings. The exit push button and its wiring must be installed inside the secured area.
UL has not examined the operation of the door switch input, lightning
arrestors, keypad input, or the Andover Controls metal oxide varis tor
with the ACX 700. (For varistors you shou ld use in UL listed sys tems,
consult the UL listings.) UL has not examined connection and operation
with the Infinet.
For UL listed systems, all wires connected to the panel should be in dedicated, grounded conduit.
A-2 ACX 700 Installation Guide
Page 63
For a UL listed system, when wiring a fail secure door strike, you
should use listed panic hardware to allow emergency exit from the secured area.
For information on how to program the controller and modules, refer to
the Infinity CX Programmer’s Guide, #30-3001-166 Version 1.4, ©
1993 or the SX 8000 Programmer’s Guide # 30-3001-174 Version 1.4,
© 1993. (Please note that the keypad option is not intended for UL listed
systems.)
ACX 700 Installation Guide A-3
Page 64
A-4 ACX 700 Installation Guide
Page 65
Appendix B
Setting the
Card Type Jumpers
This appendix shows how to switch required jumpers if you change
card types from ABA to Wiegand or from Wiegand to ABA.
ACX 700 Installation Guide B-1
Page 66
Locating the Card Type Jumpers
Located inside the ACX 700 cabinet to the right of the Card Type
Switches are two sets of 0 Ω resistor jumpers. These jumpers are correctly set for ABA or Wiegand card types when shipped. If you choose
to change the card type from ABA to Wiegand or from Wiegand to
ABA you must reset the jumpers.
Figure B-1 shows the location of the card type jumpers.
Figure B-1. Location of Card Type Jumpers
Card Type Switch
for READER 1
Card Type Switch
for READER 2
ABA
WIEGAND
ABA
WIEGAND
J1
J2
J3
J4
CPU
TD
RD
+24VDC CLASS 11
A
160
m
Card Type Jumpers
for READER 1
Card Type Jumpers
for READER 2
J5
J6
J7
J8
B-2 ACX 700 Installation Guide
Page 67
Setting Jumpers for ABA Cards
Figure B-2 illustrates how the jumpers should look when set for ABA
cards.
Figure B-2. Jumpers for ABA Cards
READER 1 READER 2
J1
J2
J3
J4
J5
J6
J7
J8
Set the READER 1 jumpers for ABA cards as foll ows:
1. Find the jumpers labeled J1, J2, J3, and J4 to the right of the Card
Type Switch for READER1on the AC X 700.
2. Leave
J1
jumpered.
3. Do not jumper J2.
4. Using pliers, remove the jumper from J3.
5. Insert the jumper into J4.
Set the READER 2 jumpers for ABA cards as foll ows:
1. Find the jumpers labeled J5, J6, J7, and J8 to the right of the Card
Type Switch for READER2 on the ACX 700.
2. Using pliers, remove the jumper from J6.
3. Insert the jumper into J5.
4. Leave J7 jumpered.
5. Do not jumper J8.
ACX 700 Installation Guide B-3
Page 68
Setting Jumpers for Wiegand Cards
Figure B-3 illustrates how the jump ers should look w hen set for
Wiegand cards.
Figure B-3. Jumpers for Wiegand Cards
READER 1 READER 2
J1
J2
J3
J4
J5
J6
J7
J8
Set the READER 1 for Wiegand cards as follows:
1. Find the jumpers labeled J1, J2, J3, and J4 to the right of the Card
Type Switch for READER 1 on the ACX 700.
2. Leave J1 jumpered.
3. Do not jumper J2.
4. Using pliers, remove the jumper from J4.
5. Insert the jumper into J3.
Set the READER 2 for Wiegand cards as follows:
1. Find the jumpers labeled J5, J6, J7, and J8 to the right of the Card
Type Switch for READER 2 on the ACX 700.
2. Using pliers, remove the jumper from J5.
3. Insert the jumper into J6.
4. Leave
J7
jumpered.
5. Do not jumper J8.
B-4 ACX 700 Installation Guide
Page 69
Index
A
AC power
connecting 15
AC voltage
setting 16
Andover Controls Service Tool
using 49
auxiliary outputs
wiring 40
B
backup power
connecting 48
battery
connecting 48
C
cabinet
dimensions 3
weight 3
cable
for Infinet 4
length 4
card reader
ABA
jumpers B-3
wiring 37
Wiegand
jumpers B-4
wiring 33, 35
card readers
length of wire to 6
Proximity
power supply requirements 37
circuit requirements for power 3
configuration
planning 9
counter inputs
wiring 32
D
dimensions
cabinet 3
dimensions to knockouts 10
door outputs
length of wire to 40
wiring 40
door switch inputs
wiring 28
door switches
length of wire to 28
E
enclosure
Underwriters Laboratories
requirements 6, 10
environments
for operating 6
exit buttons
length of wire to 30
expansion modules
connecting 42
expansion port
purpose 42
G
ground
correcting 6
inspecting 6
requirements 5
I
Infinet
lightning arrester for 4
selecting port for 22
wiring 23
Infinet cable
connecting 21
Infinet cable numbers 4
ACX 780 Installation Guide Index-1
Page 70
inputs
card reader
wiring 33, 35, 37
door switch
wiring 28
keypad
wiring 39
motion sensor
wiring 30
standard two wire
wiring 32
wiring rules 25
J
jumpers
location of card reader jumpers B-2
setting for AC voltage 16
K
keypad inputs
length of wire to 39
wiring 39
knockouts
dimensions 10
L
LED
power indicating
mounting 18
lightning arrester
for Infinet 4
normally open
supervisory inputs 27
O
outputs
wiring auxiliary 40
wiring door 40
wiring rules 25
P
parts
inside the controller 15
port
selecting for Infinet 22
power
battery backup 48
power indicating LED
mounting 18
wiring 21
power requirements
circuit 3
power supply
requirements for Proximity card
reader 37
power surges
preventing 5
powering up
preparations for 47
R
RESET button 48
M
motion sensor inputs
wiring 30
motion sensors
length of wire to 30
mounting controller 10
mounting power indicating LED 18
N
normally closed
supervisory inputs 26
Index-2 ACX 780 Installation Guide
S
screw holes
locations for mounting 10
service port
purpose of 49
shields
for Infinet cable
connecting 22
required for sensor wire 24
supervisory inputs
circuit types 26
Page 71
normally closed 26
normally open 27
recommended types 27
T
temperatures
for operating 6
two-wire inputs
wiring 32
U
Underwriters Laboratories
enclosure requirements 6, 10
V
voltage
selecting for AC power 16
W
weight
cabinet 3
wiring
AC power connection 15
card reader
ABA 37
Wiegand 33, 35
connecting Infinet cable 21
correct wire gauge for ground 6
counter inputs 32
door outputs 40
door switch inputs 28
Infinet 23
inputs 24
keypad inputs 39
length to card readers 6
length to door outputs 40
length to door switches 28
length to exit buttons 30
length to keypad inputs 39
length to motion sensors 30
motion sensor inputs 30
rules for inputs and outputs 25
two-wire inputs 32
ACX 780 Installation Guide Index-3
Page 72
Index-4 ACX 780 Installation Guide
Page 73
30-3001-204 ACX 700 Installation Guide Rev E
Loading...
