Use & Care Instructions PM-10
E N G L I S H
Please read the following instructions before using your new Andis clipper. Give it the care that a fine precision built instrument deserves and it will give you years of service.
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should
always be followed, including the following: Read all instructions before using your Andis clipper.
DANGER: To reduce the risk of electric shock:
1.Do not reach for an appliance that has fallen into water. Unplug immediately.
2.Do not use while bathing or in a shower.
3.Do not place or store appliance where it can fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid.
4.Always unplug this appliance from the electrical outlet immediately after using.
5.Unplug this appliance before cleaning, removing, or assembling parts.
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons:
1.An appliance should never be left unattended when plugged in.
2.Close supervision is necessary when this appliance is used by, on or near children or individuals with certain disabilities.
3.Use this appliance only for its intended use as described in this manual. Do not use attachments not recommended by Andis.
4.Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return the appliance to an Andis authorized service station for examination or repair.
5.Keep the cord away from heated surfaces.
6.Never drop or insert any object into any opening.
7.Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered.
8.Do not use this appliance with a damaged or broken blade or comb, as injury to the skin may occur.
9.To disconnect turn control to OFF then remove plug from outlet.
10.This appliance is not intended for use by children and other persons whose physical, sensory, or mental capabilities or lack of experience and knowledge prevents them from using the appliance safely without supervision or instruction by a responsible person to ensure that they can use the appliance safely. Children should be supervised by the responsible person to ensure that they do not play with the appliance.
SAVE THESE INSTRUCTIONS
THIS PRODUCT INTENDED FOR HOUSEHOLD USE
To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.
OPERATING INSTRUCTIONS
Before starting clipper remove blade guard. Plug cord into electrical outlet, operate at 120 volt, 60 cycle AC electrical current or as noted on the unit. To start clipper move switch button forward, to stop, move switch button back to original position. After using your Andis clipper, rewrap cord and store in a safe place.
CLIPPER BLADE ADJUSTMENT
The blades on your Andis clipper can be adjusted to any one of four settings from shorter to longer. To adjust blades, simply move the adjustment lever with your thumb (Figures A & B).
2 |
3 |
USING THE ATTACHMENT COMBS
(Some models do not have combs and sizes will vary by kit)
You can set the blades for a longer cut by using any of the attachment combs made for your Andis clipper. You can attach a comb to the blade in any one of the four positions. The combs mount easily; simply slip the cutter blade teeth into comb and snap the comb down. To remove, simply snap off (Figures C & D). These attachment combs guide hair into the blades and give you precise control of hair lengths. The length of trim is indicated on the attachment comb. Use the chart to find the approximate lengths of cut. Different blade angles in relation to the skin, as well as thickness and texture of the hair will vary the cutting length.
USER MAINTENANCE
The internal mechanism of your motor clipper has been permanently lubricated by the factory. Other than the recommended maintenance described in this manual, no other maintenance should be performed, except by Andis Company, or an Andis suthorized service station.
BLADE TEMPERATURE
Due to the high speed nature of Andis clippers, please check for blade heat often, especially on close cutting blades. If blades are too hot, dip the blades only into Andis Blade Care Plus or apply Andis Cool Care Plus and then Andis Clipper Oil.
CARE AND SERVICING OF YOUR ANDIS CLIPPER BLADES
The blades should be oiled before, during, and after each use. If your clipper blades leave streaks or slow down, it’s a sure sign the blades need oil. The clipper should be held in the position shown in Figure E to prevent oil from getting into the motor. Place a few drops of Andis Clipper Oil on the front and side of the cutter blades (Figure F). Wipe excess oil off the blades with a soft, dry cloth. Spray lubricants contain insufficient oil for good lubrication, but are an excellent clipper coolant. Always replace broken or nicked blades to prevent injury. You can clean the excess hair from your blades by using a small brush or an old toothbrush. To clean the blades we suggest immersing the blades only into a shallow pan of Andis Clipper Oil while the clipper is running. Any excess hair and dirt that has accumulated between the blades should come out. After cleaning, turn your clipper off, dry the blades with a soft, dry cloth, and start clipping again.
BLADE & CLIPPER/TRIMMER REPAIR SERVICE
When the blades of your Andis clipper become dull after repeated use, it is advised to purchase a new set of blades available through your Andis supplier or through an Andis authorized service station. If you wish your clipper to be serviced as well, it should be carefully packed and mailed either Parcel Post
Insured, or U.P.S. to any Andis authorized service station. To find an Andis authorized service station near you log on to www.andis.com or contact our customer service department: 1-800-558-9441 (U.S.) or 1-800-335-4093
(Canada).
A |
B |
ADJUSTMENT |
ADJUSTMENT |
LEVER |
LEVER |
SET FOR |
SET FOR |
SHORTEST |
LONGEST |
CUTS |
CUTS |
D
E
SNAP!
CLIPPING GUIDE
C
F |
OIL |
|
|
Approx. Length of Cut |
|
Description |
Clipping Direction |
Fine |
Coarse |
|
|
|
|
Standard Andis Blade |
With hair grain |
1/16" (1.6 mm) |
3/16" (4.8 mm) |
|
Against hair grain |
1/32" (0.8 mm) |
1/8" (3.2 mm) |
|
|
|
|
1/16" Attachment Comb |
With hair grain |
3/16" (4.8 mm) |
5/16" (7.9 mm) |
|
Against hair grain |
3/32" (2.4 mm) |
5/32" (4.0 mm) |
|
|
|
|
1/8" Attachment Comb |
With hair grain |
1/4" (6.4 mm) |
3/8" (9.5 mm) |
|
Against hair grain |
1/8" (3.2 mm) |
1/4" (6.4 mm) |
|
|
|
|
1/4" Attachment Comb |
With hair grain |
3/8" (9.5 mm) |
1/2" (12.7 mm) |
|
Against hair grain |
1/4" (6.4 mm) |
3/8" (9.5 mm) |
|
|
|
|
3/8" Attachment Comb |
With hair grain |
1/2" (12.7 mm) |
5/8" (15.9 mm) |
|
Against hair grain |
3/8" (9.5 mm) |
1/2" (12.7 mm) |
|
|
|
|
1/2" Attachment Comb |
With hair grain |
5/8" (15.9 mm) |
7/8" (22.2 mm) |
|
Against hair grain |
1/2" (12.7 mm) |
5/8" (15.9 mm) |
|
|
|
|
3/4" Attachment Comb |
With hair grain |
7/8" (22.2 mm) |
1-1/8" (28.6 mm) |
|
Against hair grain |
3/4" (19.0 mm) |
1" (25.4 mm) |
|
|
|
|
1" Attachment Comb |
With hair grain |
1-1/8" (28.6 mm) |
1-3/8" (34.9 mm) |
|
Against hair grain |
1" (25.4 mm) |
1-1/4" (31.8 mm) |
|
|
|
|
