Amped Wireless R10000 User Manual
User’s Guide
High Power Wireless-N 600mW Smart Router
R10000
R10000
USER’S GUIDE
1
CONTENTS
INTRODUCTION ..................................................................... 2
GETTING STARTED ................................................................. 3
Package Contents ..................................................................... 3
LED Indicators .......................................................................... 4
Back Panel Description ............................................................. 5
SETUP GUIDE ......................................................................... 6
Setup Preparations ................................................................... 6
Welcome to the Smart Setup Wizard ..................................... 11
Configure your Internet Connection ...................................... 12
WIRELESS SETTINGS ............................................................. 17
Basic Settings .......................................................................... 17
Basic Settings: Guest Networks .............................................. 19
Security Settings ..................................................................... 20
Advanced Settings .................................................................. 21
Wi-Fi Protected Setup (WPS) .................................................. 23
NETWORK SETTINGS ............................................................ 24
Local Network (LAN) ............................................................... 24
Internet Network (WAN) ........................................................ 26
Advanced Settings .................................................................. 28
SMART FEATURES ................................................................ 30
Wireless Coverage Controls .................................................... 31
Access Schedule ..................................................................... 32
Block Websites ........................................................................ 33
User Access (MAC Address Filtering) ...................................... 34
User Access (IP Address Filtering) ........................................... 35
FIREWALL SETTINGS ............................................................. 36
Port Filtering ........................................................................... 37
Port Forwarding ...................................................................... 38
DMZ (Demilitarized Zone) ....................................................... 39
Virtual LAN .............................................................................. 40
Denial Of Service ..................................................................... 41
QUALITY OF SERVICE ............................................................ 42
MANAGEMENT FEATURES ................................................... 43
System Status .......................................................................... 44
Network Statistics ................................................................... 45
Dynamic DNS Settings ............................................................. 46
System Clock ........................................................................... 47
System Logs ............................................................................ 48
Upgrade Firmware .................................................................. 49
Save and Reload Settings ........................................................ 50
Password Settings ................................................................... 51
TECHNICAL SPECIFICATIONS ................................................. 52
DEFAULT SETTINGS .............................................................. 53
TROUBLESHOOTING AND SUPPORT INFORMATION .............. 54
WARRANTY AND REGULATORY INFORMATION .................... 66
R10000
USER’S GUIDE
2
INTRODUCTION
Thank you for purchasing this Amped Wireless product. At Amped Wireless we strive to provide you with the
highest quality products through innovation and advanced technology. We pride ourselves on delivering
products that outperform the competition and go beyond your expectations. If you have any questions please
feel free to contact us. We’d love to hear from you and thank you for your support!
Email: sales@ampedwireless.com
Call: 888-573-8830
Web: www.ampedwireless.com
R10000
USER’S GUIDE
3
GETTING STARTED
Package Contents
Check to make sure you have all the contents within your package:
High Power Wireless-N 600mW Smart Router
Two Detachable 5dBi High Gain Antennas
Two x RJ-45 Ethernet Cables
Power Supply
Setup Guide
CD: User’s Manual, Installation Video, Setup Guide, Wi-Fi Analytics Android App
Vertical Mounting Base
R10000
USER’S GUIDE
4
LED Indicators
(From top to bottom)
Power: Indicates when the High Power Router is powered on. The LED will stay lit
when the power adapter is plugged into the router.
Wireless Activity: Blinks rapidly when wireless data traffic is transmitted or received
over the wireless network.
Wired Ports 1-4: Indicates when a networking device is connected to a wired port on
the back of the High Power Router. The LED blinks rapidly when wired data traffic is
transmitted or received. Internet Connection: Indicates when the High Power Router
is connected to a broadband modem. The LED will blink when Internet traffic is
transmitted or received.
Internet Connection: Indicates when the High Power Router is connected to a
broadband modem. The LED will blink when Internet traffic is transmitted or
received.
WPS: Wi-Fi Protected Setup activity. When the WPS mode is activated the WPS LED
blinks as it awaits a connection.
R10000
USER’S GUIDE
5
Back Panel Description
Antenna Connectors (1-2): RJ-SMA antenna connectors. Connectors are compatible with all antennas with RPSMA connectors and upgradable to high gain antennas for more range.
Reset: Push down once to reboot the High Power Router. Hold down for 5-10 seconds to reset the router
back to factory settings.
WPS: Hold down for 3 seconds to enable WPS push button configuration.
Wired Devices: RJ-45 ports for connecting to wired computers or network devices.
Modem: RJ-45 port for connecting to your Broadband Modem.
Power: Power adapter port. DC 12V 1A.
R10000
USER’S GUIDE
6
SETUP GUIDE
Setup Preparations
Disconnect and Power Off your Existing Router
Disconnect your existing router from your computer, your broadband
modem and its power outlet. If you do not have an existing router
please continue to the next step.
Power Off your Modem
Power off the Modem by disconnecting the Modem’s power adapter
from the power outlet. If your Modem has a backup battery, remove
the backup battery from your Modem. Do NOT power on the Modem
until prompted at a later step.
R10000
USER’S GUIDE
7
Connect the High Power Router to your Modem
Do NOT connect the power adapter to the High Power Router at this time
a) Use the included Ethernet cable and connect one end of the cable to your Modem
b) Connect the other end of the cable to the blue “Modem” port on the High Power Router
R10000
USER’S GUIDE
8
Power on your Modem
Plug in your Modem’s power adapter and backup battery (if available):
R10000
USER’S GUIDE
9
Power On the High Power Router and Connect it to your Computer
a) Attach the antennas of the High Power Router to the antenna ports labeled 1 and 2
b) Connect the included grey network cable to an available port on your computer
c) Attach the power adapter to the High Power Router’s PWR port and a power outlet
R10000
USER’S GUIDE
10
Open your Web Browser to Access the Setup Wizard
a. Open your web browser.
b. Type in: http://setup.ampedwireless.com into
the web address bar.
c. If the web menu fails to open, type in the
following IP address into your web address
bar:http://192.168.1.240
d. When prompted, enter the login and password
R10000
USER’S GUIDE
11
Welcome to the Smart Setup Wizard
When the web menu appears, click Start to proceed
with the Smart Setup Wizard.
The Smart Setup Wizard will guide you through the
following settings:
1) Internet Connection
2) System Clock
3) Wireless Connection
R10000
USER’S GUIDE
12
Configure your Internet Connection
Configure your Internet settings using the automatic configuration settings. The wizard will check the
connection to your modem and attempt to automatically configure your Internet connection settings. If there
is a problem with the connection the wizard will provide you with information regarding the problem.
More advanced users may choose to configure their connections manually by selecting Manual Configuration.
DSL users may require additional login information. Select the appropriate connection type and enter the
required information.
Click Next to continue.
R10000
USER’S GUIDE
13
If there was a problem with the Automatic
Configuration, the wizard will notify you of the issue. If
you continue to have problems, contact our support
department at 888-573-8820.
If the Automatic configuration was successful, you will
be directed to a Configuration Successful page.
Click Next to continue.
R10000
USER’S GUIDE
14
Set the System Clock
The System Clock is used for system logs and setting
schedules for Internet access. Click Sync to
synchronize the System Clock with the time on your
computer.
Click Next to continue.
R10000
USER’S GUIDE
15
Configure your Wireless Settings
The default SSID of the High Power Router is “Amped_Network”
To change it, enter a new name in the SSID field. Users connecting
wirelessly to the High Power Router will use this ID to identify your
wireless network.
The default Security Key (WPA/WPA2) for your wireless network is
“wireless”.
To change it, enter a new key in the Security Key field. The key must
be 8-characters minimum.
Click Next to apply your settings. The High Power Router will reboot.
This process may take up to 1 minute. The page will automatically
reload after the countdown. If it does not, you may need to refresh
the page manually or check your connection to the router.
R10000
USER’S GUIDE
16
Setup Summary
Once the High Power Router has rebooted, it will load
the Setup Summary page and provide you with the
details of your setup.
Open a new web browser window and check that you
have access to the Internet.
At this time, you may disconnect from the High Power
Router and start a wireless connection.
If you have any wired devices that you would like to
attach to the High Power Router you may do so now as
well.
Enjoy your Amped Wireless network.
R10000
USER’S GUIDE
17
WIRELESS SETTINGS
Wireless Settings: Basic Settings
The Basic Settings page allows you to adjust settings for your
local wireless network.
Disable All Wireless Connections: Disabling Wireless will turn off
all Wi-Fi activity. Users will no longer be able to connect
wirelessly to your network.
Band: Select the compatible Wi-Fi standard and speed for your
wireless network
Broadcast SSID: Selecting Disable Broadcast SSID will hide the
visibility of the router’s SSID. Users must manually enter the
SSID to connect.
Data Rate: Sets the maximum wireless data rate that your
network will operate on.
Wireless Network ID (SSID): The name of your wireless network.
Channel Number: Wi-Fi networks operate on specific wireless
channels. Some network channels may have more interference than others. If your performance is unstable,
try a different channel number. If you are using a repeater with this network, it is recommended you set a
static channel, instead of using "Auto."
R10000
USER’S GUIDE
18
WMM: Prioritizes multimedia data over the wireless network.
Associated Clients: Shows the active users connected wirelessly to your network.
R10000
USER’S GUIDE
19
Wireless Settings: Basic Settings: Guest Networks
Guest Networks: You may add additional names (SSID) to your Wireless Network with different characteristics
for each SSID.
Each additional Network or SSID can have its own
security, band and data rate settings. You may
restrict users to specific SSIDs or provide access
only to some users with lower bandwidth by
changing the band (i.e. only allow 802.11b access
to specific users).
Guest Networks may also be set with restrictions
so that guests can only access the Internet and not the local network.
Associated Clients: View all computers and network devices that are connected to your network wirelessly.
R10000
USER’S GUIDE
20
Wireless Settings: Security Settings
The Security page allows you to change the type of wireless
security settings for your wireless network.
Using the drop down menu, you can select which network
you wish to configure and may adjust the security settings
below.
If you are using the Guest Network feature, you will be able
to adjust the security settings for your additional SSIDs as well.
Encryption Types:
WEP is rated as a low level encryption and is compatible with all wireless devices and operating systems.
Using WEP may slow down your wireless performance.
WPA is a medium level encryption and is supported by most wireless devices and operating systems.
WPA2 is a high level encryption and is supported by most wireless devices and operating systems.
WPA Mixed Mode allows the use of both WPA and WPA2 at the same time.
If you are not sure which encryption type to use, we recommend you choose WPA/WPA2 Mixed Mode.
R10000
USER’S GUIDE
21
Wireless Settings: Advanced Settings
Advanced Wireless Settings should only be
adjusted by technically advanced users. It is not
recommended that novice users adjust these
settings to avoid degrading wireless performance.
Fragment Threshold: The default and
recommended setting is at 2346, meaning the High
Power Router will never fragment any frames that
it sends to wireless users.
RTS Threshold: Adjusts the size of RTS data
packets. Lower values reduce throughput, but
allow the system to recover quicker from
interference/collisions. Higher values provide the
fastest throughput.
Beacon Interval: Indicates the frequency interval of the beacon. A beacon is a packet broadcast by the router
to synch the wireless network.
R10000
USER’S GUIDE
22
Preamble Type: Defines the length of the Cyclic Redundancy Check for communication between the router and
roaming wireless users.
IAPP: Inter-Access Point Protocol
STBC: Space Time Block Coding improves reception by coding the data stream in blocks.
Loading...
