1 Introduction

This manual contains information on the function and use of the various avionics software packages available for multiple California Instruments power sources.

1.1 General Description

California Instruments offers many different software packages to aid in the testing of EUTs to comply with certain military and commercial specifications. The software has been designed to be intuitive, user friendly, and completely customizable to provide maximum flexibility in testing options. The software test parameters are data file driven, so the user can modify any of the tests performed to better suit their needs. This means that if there is a revision change to a specification, the user can make the necessary changes without waiting for an updated version of software to be released.

Each software package has a report generation feature that creates Microsoft Word format reports including test parameters, various pass/fail criteria, current harmonics tables, current harmonics bar graphs, and output waveforms.

This manual is intended to accompany the user manual of the power source being used. Please refer to the appropriate user manual for information on general use and operation of the power source.

1.2 Manual organization and format

All user documentation for California Instruments power sources is provided on CDROM in electronic format. (Adobe Portable Document Format) The required Adobe PDF viewer is supplied on the same CDROM. This manual may be printed for personal use if a hardcopy is desired. To request a hardcopy from California Instruments, contact customer service at support@calinst.com. There will be an additional charge for printed manuals.

All of the avionics test packages are based on the same general software layout and operation. This manual contains sections on how to use the basic functions of all of the avionics options, followed by sections detailing the specific differences for each option. No matter which option was purchased, please read Section 2 first, and then read the subsequent section(s) that pertain to your specific option(s).

Note: Some avionics options are firmware based. For information on these options, please refer to the user manual for your power source.

6 Avionics Software

User Manual - Rev H California Instruments

Rev.

iX Series

Compact iX

MX Series

Lx/Ls Series

Defense Avionics

MIL-STD704

AC Mode

A

-704 (CIGui32/CIGuiSII)

-704 (iXCGui)

-704 (MXGui)

-704F

B

-704 (CIGui32/CIGuiSII)

-704 (iXCGui)

-704 (MXGui)

-704F

C

-704 (CIGui32/CIGuiSII)

-704 (iXCGui)

-704 (MXGui)

-704F

D

-704

-704 or -704F

E

-704

-704 or -704F

F

-704 (CIGui32/CIGuiSII)

-704 (iXCGui)

-704 (MXGui)

-704F

DC Mode

A

-704 (CIGui32/CIGuiSII)

-704 (iXCGui)

-704 (MXGui)

B

-704 (CIGui32/CIGuiSII)

-704 (iXCGui)

-704 (MXGui)

C

-704 (CIGui32/CIGuiSII)

-704 (iXCGui)

-704 (MXGui)

D

-704

E

-704

F

-704 (CIGui32/CIGuiSII)

-704 (iXCGui)

-704 (MXGui)

Commercial Avionics

RTCA-DO160

AC Mode

C

-

- - -160

D

-160

Euro/14D

-160

Chng 2 - - - -160

E

-160 (CIGui32/CIGuiSII)

-160 (iXCGui)

-160 (MXGui)

-160 (LxGui)

F

-

-160 (MXGui)

-

DC Mode C -

- -

D

-160

Euro/14D

-160

Chng 2 - - -

E

-160 (CIGui32/CIGuiSII)

-160 (iXCGui)

-160 (MXGui)

F

-

-160 (MXGui)

Boeing

787B3-0147

AC Mode A -B787 (CIGuiSII)

-B787 (iXCGui)

-B787 (MXGui)

-B787 (LxGui)

1.3 Availability of tests

Table 1-1 below shows a comprehensive list of available avionics test options, their availability on various California Instruments power sources, and the Gui needed to run the option. Note: If no Gui is specified next to an option, the option is implemented by the firmware. For instructions on use of these options, please refer to the user manual for the power source being used.

Avionics Software 7

User Manual – Rev H California Instruments

Rev.

iX Series

Compact iX

MX Series

Lx/Ls Series

B

-B787 (CIGuiSII)

-B787 (iXCGui)

-B787 (MXGui)

-B787 (LxGui)

C

-B787 (CIGuiSII)

-B787 (iXCGui)

-B787 (MXGui)

-B787 (LxGui)

DC Mode A -B787 (CIGuiSII)

-B787 (iXCGui)

-B787 (MXGui)

B

-B787 (CIGuiSII)

-B787 (iXCGui)

-B787 (MXGui)

C

-B787 (CIGuiSII)

-B787 (iXCGui)

-B787 (MXGui)

Airbus

AMD-24

AC Mode C -AMD (CIGuiSII)

-AMD (iXCGui)

-AMD (MXGui)

-AMD (LxGui)

DC Mode C -AMD (CIGuiSII)

-AMD (iXCGui)

-AMD (MXGui)

ABD0100.1.8

AC Mode

D

-ABD (CIGui32/CIGuiSII)

-ABD (iXCGui)

-ABD (MXGui)

-ABD (LxGui)

E

-ABD (CIGuiSII)

-ABD (iXCGui)

-ABD (MXGui)

-ABD (LxGui)

DC Mode

D

-ABD (CIGui32/CIGuiSII)

-ABD (iXCGui)

-ABD (MXGui)

E

-ABD (CIGuiSII)

-ABD (iXCGui)

-ABD (MXGui)

A350 / ABD0100.1.8.1

AC Mode B -A350 (CIGuiSII)

-A350 (iXCGui)

-A350 (MXGui)

-A350 (LxGui)

DC Mode B -A350 (CIGuiSII)

-A350 (iXCGui)

-A350 (MXGui)

Table 1-1: -Avionics Option Test Coverage

8 Avionics Software

User Manual - Rev H California Instruments

2 Basic Operation

This section explains how to use features of the avionics software packages that are common to all of the options. These options can only be used in conjunction with the provided Gui Windows application software due to the amount of selections and data presentation involved. As such, these tests require the use of a PC running Windows XP / 2000 and cannot be operated from the front panel. PC system requirements are the same that are called out to run the gui program, however a 3GHz or higher processor and 512 MB of RAM or more is recommended if generating reports due to the high processing power required. Use of Windows Vista is possible but not recommended.

The avionics software options are completely data file driven to allow a large degree of customization by the end-user if needed so many changes can be supported without the need for software updates.

If purchasing an option after purchasing a unit, the Gui may need to be updated to run the optional software. If the option and the power source are purchased at the same time, no update will be needed to run the software. The Gui program is supplied with all systems free of charge on CD ROM CIC496. It can also be downloaded or updated from the California Instruments web site (www.calinst.com).

2.1 General Test Procedure

Generally, the following steps are needed to perform an avionics test on an EUT.

1. Connect the EUT to the power source.

2. Select the correct mode of operation for the EUT, AC or DC mode, single or three-phase mode (if applicable).

3. Program the relevant nominal voltage and frequency using the Gui main screen.

4. Apply power by closing the output relay. This can be done at a later stage or will be done automatically after prompting the operator when a test is started.

5. Open the avionics option control screen from the Applications menu or click on the appropriate toolbar icon.

6. Select the correct test revision or use the default.

7. Select the correct Power Group Test Category.

8. Select a test from the test table displayed in the bottom part of this screen. You can select a test by clicking on a row. The selected row will be highlighted.

9. Switch to the Test Control tab (middle tab along the top of the screen).

10. Verify that the test sequence and description shown in the table on the Test Control screen is indeed the desired test.

11. Click the Start button to initiate the test.

12. Observe the test progress monitor at the top of the window and observe the EUT.

13. Wait for test completion. You can Abort a test in progress by clicking the Abort button.

14. Select the EUT Performance Measurements tab (Right tab along top of the screen).

15. Click the Update Meas. Button located in the top center of the screen. This will initiate a measurement cycle. Measurements in three-phase mode may take some time to complete.

16. Use the tabs located along the top of the measurement tab (Parameters, Waveforms, Curr Graph and Curr Spectrum) to review the EUT data. Any anomalies can be noted in the observations tab located on the Parameters screen. This information will be included in the test report.

Avionics Software 9

User Manual – Rev H California Instruments

17. Click on the Print button or use File, Print to print a test report for this test.1

18. Return to step 8 as needed.

The following sections provide details on the various screens, menus, displays and controls available to the operator to manage the test process.

1

For test report generation, use of a 3GHz+ Intel or equivalent Windows PC with minimum 512Mb RAM is

recommended. Otherwise reports may take a long time to generate.

10 Avionics Software

User Manual - Rev H California Instruments

Tab

Description

Test Selection

This tab allows the operator to select the library of test files to use (Select Test) and the relevant Power group. It also displays the AC power source settings that are in effect on the right hand side. Available power group selections are shown below the test selection field. The table shown at the bottom of this tab shows the available test sections that can be selected.

Test Control

This tab provides information on the test sequence that is presently selected and also contains the execution controls. It shows the progress of any test that is executing.

EUT Performance Measurements

This tab may be used to display EUT performance data as measured by the

power source‟s advanced data acquisition system. If the source used does not

support advanced measurement function such as waveform capture and FFT, some of the information in this tab may not be displayed.

2.2 Test Control Window

Figure 2-1: 160 Option Test Selection Screen.

To access an avionics option, select the option from the Applications menu of the Gui main screen or click on the appropriate button in the toolbar. The Tables Control window will open selecting the last power group that was selected in a previous instance. It may still be necessary to select the desired power group first however. Also verify that the selected power group on the screen is the correct one for the EUT being tested.

The avionics tests can be operated from the test control screen. This screen contains three main tabs located along the top edge of the window. The following tabs are available. Click on the tab name for additional help on how to use each tab.

In addition to the three tab controls, the left pane of the test control window contains a set of output on/off control buttons and a print button. The on/off buttons may be used to open or close the output

Avionics Software 11

User Manual – Rev H California Instruments

Menu

Sub Menu

Description

File

New

The selected clears all data from the Test Control data grid. This operation is not normally recommended unless a complete new test sequence is to be entered manually.

Open

Opens a specific test sequence file. This menu may be used to directly select a test file without using the Test Selection table tab.

Save

Saves the contents of the test sequence data grid to the selected test file.

Save As…

Saves the contents of the test sequence data grid to a user defined file name. A file dialog box will appear enabling selection of the directory and file name under which to store the contents of the test sequence data grid.

Print

Prints a test report using MS Word format. Only data for the presently selected test sequence is printed. The test reports also include EUT performance measurement data. Note: To print reports, the MS Word report format selection must be made from the Main GUI, Options menu  Report Format menu before opening the test control screen. If not, an error prompt will indicate that no supported report format is selected.

Exit

Closes the test control window.

Edit

Cut

Cuts the selected row from either the Test selection data grid or the Test sequence data grid. The data in the row cut is available for a Paste operation.

Copy

Copies the selected row from either the Test selection data grid or the Test sequence data grid. Copied rows can be pasted to the same grid at a different location.

Paste

Pastes a copied row from to either the Test selection data grid or the Test sequence data grid.

Insert Row

Inserts a new blank row at the selected data grid location.

Delete Row

Deletes the selected row from either the Test selection data grid or the Test sequence data grid. The row contents are permanently discarded.

Run

All

Run selected test

Stop

Abort test in progress

Help

Opens the on-line help file.

relay of the power source at any time. If the output relay is opened during a test run, the test is automatically aborted when the operator clicks on the Off button. The ON button will be shown in red while the output relay is closed. The Off button is shown in green if the output relay is open. The report print function can be invoked by either clicking on the Print button or using the File, Print menu.

If the GUI program is used in demo mode, the “DEMO MODE ONLY!!!” banner will be displayed in this area as well. In Demo mode, all test runs and all measurements are simulated. This mode may be used to develop new test sequences off-line but any run-time errors will not be detected until executed with an actual power source.

2.2.1 Menus

The top of the test control window contains a standard Windows menu bar. Available menus are:

12 Avionics Software

User Manual - Rev H California Instruments

Control / Display

Description

Select Revision.

This drop down control allows the operator to select from one or more libraries of test sequences grouped by revision. The GUI program is supplied with predefined revisions of test sequences.

Power Group Test Table

A library can contain a number of power group test tables. These table names correspond to the Power Groups identified in the specific standard, and are listed in their section of this manual. The operator cannot select a group that is not supported by the present mode of operation of the power source. Thus, if the power source is in AC mode, an error message will be displayed when trying to select a DC group. Operating modes such as AC or DC must be changed from the main GUI screen. The test control screen can remain open while switching back to the main screen. Upon return to the test control screen, the relevant power groups can be selected.

The operator needs to determine what the relevant power group selection is for the unit under test. (EUT). When switching power groups, the table data shown at the bottom of this tab will be updated to reflect the new selection. The first test section of the table will automatically be selected when switching power groups.

Present Power Source Output Settings

This section displays the programmed steady state settings that are in effect. This information is updated each time the test control form regains focus. The mode of operation (AC, DC or AC+DC) is displayed for reference but cannot be changed from this screen. When in DC mode, the frequency setting will show “DC”. Note that changes in steady state settings can only be made from the main GUI screen. The operator can toggle between the main screen and the test control screen for this purpose as needed.

Table Header

The table header is shown against a blue background and contains the table reference designator and a description of the selected power group.

Test Table Display

The data grid at the bottom of the tab displays the selected power group test table. It is also used to select the specific test section and number to be executed. Thus, every test starts by selecting the desired test step from this table. Clicking on the desired ROW does this. The selected row will be highlighted and the associated file shown in the File Ref. Field will be loaded in the Test Control tab. For better readability, the user can adjust the column widths by dragging the dividers between columns. If the window is too small to display all rows and columns, scroll bars will appear at the bottom and/or right of the data grid. The following fields are displayed in the test data tables.

Test

Number of the test from the avionics standard. For sub sections of a test number, this field will be blank.

Section

Test section. Some tests may only have one section in which case this field is blank.

Subject

Description of the type of test.

Test Limits

A summary of the test limits that will be applied by this test.

Comment

Comments concerning this test or its parameters.

File Reference

The test sequence file that is used to implement this test section on the power source.

User Data

The area at the bottom of this tab may be used to enter general information regarding the unit under test, the test location and operator and environmental conditions in effect during the test. This information will be incorporated in the test reports generated by the GUI.

2.3 Test Selection

The Test Selections tab in the test control window contains the following controls and displays.

Avionics Software 13

User Manual – Rev H California Instruments

Control / Display

Description

Execution Controls

The Start and Abort buttons are used to start and stop the selected test step. The execution mode that will be used is determined by the Execution Options setting. The same can be accomplished using the Run menu entries. When operating in Single Step or Loop mode, make sure the desired test step is selected in the test sequence table at the bottom of this tab as this will be the one used by the program.

Execution Options

The execution options determine the mode of operation when the Start button is clicked. Available execution modes and settings are:

Execute all steps

In this mode, all steps in the test sequence will be executed sequentially until the end of the table is reached.

Single Step

Runs only the selected test step. When operating in Single Step mode, make sure the desired test step is selected in the test sequence table at the bottom of this tab before clicking on the Start button.

Loop on Step

In this mode, the same step will be executed repeatedly until the operator clicks on the Abort button. In this mode, the Complete test progress status bar may run past its maximum and will no longer update as the total test time is determined by the operator now and not the program.

2.4 Test Control

Figure 2-2: 160 Option Test Control Screen.

The Test Control tab in the test control window is used to display and execute a selected test. This tab contains the following controls and displays.

14 Avionics Software

User Manual - Rev H California Instruments

Control / Display

Description

Revert to Steady State on Abort

When selected, the output of the power source will be set back to the steady state settings in effect before the start of the test when the operator aborts a test. Normally, the output of the source at the end of a test run is determined by the settings in the test sequence file loaded.

Options

This section contains additional options that can be set by the operator as needed. The following options are available:

Auto Acquire EUT Data after execution

When set, this option causes the GUI program to initiate an EUT performance data measurement sequence automatically at the end of a test (normal mode) or test step (single step mode).

Show Phase B, C data

For three-phase EUTs, data for phases B and C can be displayed as well. In most cases, the settings for all three phases are the same and there is no need to display them all as it takes up screen space. However, this is not the case for voltage imbalance tests. This is a display feature only and has no effect on the actual test. Note however that if the power source is in single-phase mode, settings for phase B and C will be ignored. The phase mode of the power source can only be changed from the main GUI screen.

External Trigger Output

An external trigger signal is provided through the trigger out connection during test execution. There are two modes of operation that can be selected: BOT mode: Beginning of transient. In this mode, a trigger pulse is generated at the first step of each sub list. A sub list may consist of one or more rows as indicated by the value of the link field. Note that most test scripts consist of multiple short sub lists to support single step mode. List Mode: This mode adds a Trig column to the test sequence table. A trigger will be generated for each entry in the trigger column that is set to 1. Any other value including empty will not generate a trigger out. In this mode, the user has to set one or more triggers. Setting a trigger can be done by double clicking on the trigger column with the left mouse button and entering 1.

Test Status

This area of the Test Control tab displays test execution status for each individual test step as well as the complete test. The top section shows the complete test time and what part has been completed so far. The bottom section shows the same information for the present test step.

Test Description

The area at the top of the Test Control tab is used to display additional information about the selected test tab. It is for information purposes only and has no effect on the actual test execution.

Table Header

The table header is shown against a yellow background and shows the table from which this test sequence was selected.

Test Sequence Data Grid

The test sequence data grid displays the specific parameters used to program the power source. This data implements the required tests. The parameters are loaded for the referenced ini file in the test table on the Test Selection tab. It is possible to edit this information if needed which allows variations on any of these tests to be made. Any changes can be saved to a new file. The standard provided test files are write protected however and should not be overwritten. The following columns/data fields are available in this table for each test step (row).

Step number

Sequential number from 1 through end of sequence.

Freq

Test frequency in Hz

FSlew

Frequency slew rate in Hz/sec

Volt A

Test voltage for phase/output A in Vrms or Vdc depending on mode.

Avionics Software 15

User Manual – Rev H California Instruments

Control / Display

Description

VSlew A

Voltage slew rate in V/sec

Func A

Waveform function. Default is SINE for AC mode and DC for DC mode. Arbitrary waveform can be used in AC mode if this capability is supported by the power source.

Volt B

Test voltage for phase/output B in Vrms or Vdc depending on mode.

VSlew B

Voltage slew rate in V/sec

Func B

Waveform function. Default is SINE for AC mode and DC for DC mode. Arbitrary waveform can be used in AC mode if this capability is supported by the power source.

Volt C

Test voltage for phase/output C in Vrms or Vdc depending on mode.

VSlew C

Voltage slew rate in V/sec

Func C

Waveform function. Default is SINE for AC mode and DC for DC mode. Arbitrary waveform can be used in AC mode if this capability is supported by the power source.

Dwell

Dwell time in seconds.

Loop

Repeat count for each step. Default is 1.

Link

Number of subsequent rows that are linked to this step. This function is required to implement complex transients that require multiple steps with zero time skew. When set to a value other

than blank or “0”, subsequent rows are considered part of the

same test step for single step or loop on step execution modes. Rows that are linked will not become highlighted when executed.

PhsB

Phase angle of phase B, only visible if phase angle is changed.

PhsC

Phase angle of phase C, only visible if phase angle is changed.

Comment

A comment about the specific test step.

16 Avionics Software

User Manual - Rev H California Instruments

Sub-Tab

Description

Parameters

This tab displays the parametric measurement data in tabular form. This includes voltage, current, power, power factor, distortion etc. For three-phase EUT‟s data is shown for all three phases. For single phase EUT, data is shown for phase A only as long as the power source is in single-phase mode.

The top half of the Parameters tab displays all parametric measurement data. The following data is available:

Volt RMS (V)

Displays source voltage per phase in Volt RMS or DC depending on power source mode of operation.

Curr RMS (A)

Displays EUT current per phase in amps RMS or DC depending on power source mode of operation.

App. Power (VA)

Displays the apparent power for each phase as well as the total power for all three phases. For three-phase EUT‟s, any imbalance in power between the three phases is calculated by the GUI. The amount of imbalance is displayed in % of total VA to the right of the

2.5 EUT Performance Measurements

Figure 2-3: 160 Option EUT Measurement Data Screen.

The EUT Performance Measurements tab in the test control window provides measurement data taken by the power source‟s data acquisition system. This tab contains four sub-tabs that each present different aspects of the EUT measurement data. Additional user controls for measurement updates and graph scaling are provided right next to the four sub tabs. The following sub tabs are available for selection.

Avionics Software 17

User Manual – Rev H California Instruments

Sub-Tab

Description

power readings.

Inrush Current (A)

Displays peak current detected per phase in Amps since last measurement was taken.

Power Factor

Displays power factor for each phase. If one or more phases is outside the allowable limits, a Fail indication is displayed.

Current Distortion (%)

Displays Total Current Distortion for each phase in percent of fundamental current. Limits are applied when the specification calls them out, otherwise the user can set the limits by modifying the limits text file.

The bottom half of the Parameters tab contains user controls and a text entry field for entering observations regarding the EUT operation.

Test Frequency Dropdown control

The frequency selection drop down control is active only for Variable Frequency tables and can be used to set the frequency at which data from the EUT is to be acquired. For all other modes, it is fixed to either 400 Hz or DC.

Acquire Data at all frequencies

This button causes data to be acquired at all frequencies available in the Test Frequency Dropdown control. For all constant frequency, this button functions like the Update Meas. Button located above the sub tabs.

Abort Meas.

This button aborts measurements in progress. In case of Variable Frequency Tables, acquiring data at all 12 frequency settings can take a long time. This button allows this process to be aborted.

Read Meas. Data from File

This button reads measurement data from disk. Each time measurement data is acquired by the GUI, it is saved to an ASCII text file. A separate file is used for each frequency or DC setting. To recall data taken at a specific frequency setting, select the desired frequency using the Test Frequency Dropdown control before clicking on this button. Note that all measurement data files are saved in the Reports subdirectory of the GUI application directory using file name

convention “MeasData_option_nnn_Hz.txt” where „option‟ is

the avionics option and „nnn‟ is the frequency setting or DC.

Waveforms

This tab displays the voltage and current waveform (time domain) for each phase. The sample rate is automatically set to display about 20 msec of time.

Cur Graph

This tab displays the Current harmonics in a bar graph format. Up to 50 harmonics are displayed.

Cur Spectrum

This tab displays the same current harmonics as the Current Graph tab except in a tabular format. Data is shown in both absolute and relative from (percent of fundamental current). A limit table is applied and a pass or fail indication is shown in the last column. Values that exceed the allowable limits are shown with a red background in the Pass/Fail column.

Note: Usually, the power source measurement bandwidth is less than required to make full compliance current harmonics measurements. This feature is provided for pre-compliance assessment purposes only. A high bandwidth power analyzer with a 100 KHz sampling rate or better is generally required. Harmonics that are outside of

the range of the measurement system are indicated with a “BWL” (bandwidth

limited) label instead of a readout.

No.

Harmonic number, 1 through 40

Freq (Hz)

Frequency of harmonic in Hz.

Curr (A)

Absolute current (rms) in Amps.

% Fund.

Relative current in percent of the fundamental current (I1).

Limit

Allowable current harmonic limits per individual EUT specifications. These limits are located in the file named

“option_Distortion_Limits.ini” where „option‟ is the avionics

option, located in the Gui application directory. They are set to correspond with the limits called out in the applicable standard. If there are no limits called out in the standard, these are set to 0 and no limits will be implemented. All limits

18 Avionics Software

User Manual - Rev H California Instruments

Sub-Tab

Description

are subject to change by the user.

P/F

Pass or Fail indication.

A phase selection is available to the left of the graphs and table, which allows each phase to be displayed, one at a time.

Control / Display

Description

Update Meas.

Triggers a new acquisition cycle and updates measurement data for all tabs. For Variable Frequency tables, data will be acquired at the frequency set by the Test Frequency Dropdown control. This button is always available regardless of what sub tab is selected.

Settings

Brings up a dialog box that allows scaling and color changes for the Waveform or Current harmonics graphs. Note that setting changes will apply to graphs for all phases. For current harmonics graphs, only the absolute bar settings apply. The measurement screen does not display relative current harmonic bar charts but relative data is available in tabular format on the Cur Spectrum tab. This button is available only if either the Waveforms or Cur Graph sub tab is selected

Additional user controls located on the EUT Performance Measurements Tab:

Avionics Software 19

User Manual – Rev H California Instruments

2.6 Test Description Files – Creating Custom Tests

The avionics options use a set of configuration files that contain the relevant test descriptions. These files are contained in the test revision folder in the Gui application directory. For example, the DO160

test folder is titled „DO160_RevE‟.

The contents of these tables are defined by the “option_Structure_Tbl_X.ini” configuration files located

in the test revision directory. “X” references the relevant table and “option” is the avionics option (example: DO160_Structure_Tbl_ACF115.ini).

The test description files used to perform a specific test are listed in the last column labeled “Test

File”. These files must be present in the directory.

The structure files cannot be renamed, since they relate to one of the available power groups. The structure files can be completely edited to include as many or as little subsequent tests as desired. The individual test file names can be renamed as needed as long as they are correctly referenced in the structure configuration files. From there, the individual test files can be modified to perform the new test.

Tests can be customized as needed by editing these table configuration and test sequence files. To access these new tests, create a new subdirectory under the application directory. To access any new sub directory from within the test control window, the directory name must be added to the UserTestLibraries text file located in the Gui application directory. This is a simple text file listing all test description directories available.

Example: “DO160UserTestLibraries.txt” file content: MyNew_DBase Dummy_Dir_Entry These two directories listed will now be available for selection from the Test Revision selection in the

160 Test Setup screen. To facilitate creating new test directories, it is easiest to create a copy of the existing directory first and

rename it as required.

20 Avionics Software

User Manual - Rev H California Instruments

No

Description

Potential cause

2

Current Limit Fault

EUT may require more current than the programmed current limit setting. This is possible on constant power loads during reduced voltage (low line) type test steps. If the power source is set to Constant Voltage (CV) mode, the output will trip off when the current limit is exceeded and a Current Limit fault is generated. In Constant Current (CC) mode, the output voltage will be reduced to reduce the current to the set limit. In this case, no error message will be generated.

113

Undefined Header

Generally caused by a communication problem between the PC and the power source.

If the RS232 interface is used and these problems persist, try using the GPIB interface instead. (Requires National Instruments GPIB controller).

15

Slew exceeds dwell

The power source transient system was programmed to slew to a voltage and/or frequency value that would take longer to accomplish than the slew time set. This error can result in single step mode if the steps are executed out of order or one or more steps are skipped. The voltage/frequency values may no longer line up. Try running the test from the first step.

16

Illegal during transient

A transient step is still in progress. Try using the Abort button to abort any test in progress. If other Gui screens other than the Main GUI screen are open, they may have initiated a transient, which conflicts with the option. Try closing all other Gui windows.

2.7 Avionics Option Related Error Messages

The Gui program will monitor the power source on a regular basis for any run time errors. If an error is reported by the power source, any test step execution will be aborted. Possible errors and error sources are:

Great efforts have been made to check all test sequence files provided as part of the avionics options. However, due to the breadth and complexity of the test databases, an occasional error may occur while using these files. If an error cannot be resolved, turn on the Gui bus monitor window and rerun the test that yields the error and save the bus trace to a text file using the File, Save All menu in the bus monitor window. This file can be emailed to support@calinst.com along with a description of the error.

Furthermore, test files were developed making reasonable assumptions concerning the intent of the avionics test directives. The user is free to modify, edit, revise or otherwise update any of these tests to match his/her own requirements. In this case, we recommend you copy the supplied test revision subdirectory and use this copy to make modifications to. This will preserve the original data provided.

Avionics Software 21

User Manual – Rev H California Instruments

No.

115V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

28 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

16.5.1.1

Voltage and Frequency

  

16.6.1.1

Voltage

  

16.5.1.2

Voltage Modulation

  

16.6.1.2

Ripple Voltage

P P P

16.5.1.3

Frequency Modulation

  

16.6.1.3

Momentary Power Interruptions

  

16.5.1.4

Momentary Power Interruptions

  

16.6.1.4

Normal Surge Voltage

  

16.5.1.5. 1

Normal Surge Voltage

  

16.6.1.5

Engine Starting Under Voltage

N/A



16.5.1.5. 2

Normal Frequency Transients



N/A

16.6.2.1

Abnormal Voltage

  

16.5.1.6

Normal Frequency Variations

N/A



16.6.2.2

Low Voltage Conditions

N/A  N/A

3 Option –160: RTCA/DO-160 Rev E, F Tests

The -160 option supports RTCA/DO-160 rev E and F, Section 16, voltage and frequency immunity tests in either of the AC or DC modes (if available).

The –160 option is based on the RTCA/DO-160 Environmental Conditions and Test Procedures for Airborne Equipment: Section 16 – Power Input dated December 9 2004.

Future revisions of the RTCA/DO-160 directive may be issued over time and updates may be made available to cover any changes in test levels, durations, procedures etc. Furthermore, the –160 option is completely data file driven to allow a large degree of customization by the end-user if needed so many changes can be supported without the need for software updates.

This section of the manual explains the limitations of this test option, the use of special features unique to this option, and gives a complete layout of all tests performed by this option.

This manual is not intended to elaborate on the intent or purpose of the immunity tests and the expected behavior of the EUT as described in the RTCA/DO-160 documents. It is assumed that the end-user is familiar with the content of the RTCA/DO-160 test standard.

3.1 Test Coverage

The comprehensiveness of the tests that can be performed with the –160 option is determined primarily by the capabilities of the power source used. Tests that are outside the hardware capabilities of the power source used will not be enabled and cannot be selected. For these tests, additional equipment may be required as indicated.

3.1.1 MX Series –DO160 Option Limitations

The extent of coverage of the –160 option as implemented on the MX Series platform is shown in the table below. Tests marked with an „x‟ generally require additional hardware to be used. Tests marked „N/A‟ are not applicable to the corresponding table. Tests marked with a „‟ are covered by the –160

option. Tests marked with a „P‟ require arbitrary waveform capability, which is available on Pi models

or base models with the –ADV option only. An –HV indication means the –HV 400Vrms range option is required. Note: The MX15 Series power sources are single phase output only and therefore all

three phase tests are not available on the MX15.

Revision E

22 Avionics Software

User Manual - Rev H California Instruments

No.

115V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

28 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

16.5.1.7

Voltage DC Content

P P P

16.6.2.3

Momentary Under Voltage Operation

  

16.5.1.8

Voltage Distortion

P P P

16.6.2.4

Abnormal Voltage Surge

  

16.5.2.1

Abnormal Voltage and Frequency

  

16.5.2.2

Momentary Under Voltage Operation

  

16.5.2.3. 1

Abnormal Surge Voltage

  

16.5.2.3. 2

Abnormal Frequency Transient



N/A

No.

230V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

14 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

16.5.1.1

Voltage and Frequency

  

16.6.1.1

Voltage

  

16.5.1.2

Voltage Modulation

  

16.6.1.2

Ripple Voltage

P P P

16.5.1.3

Frequency Modulation

  

16.6.1.3

Momentary Power Interruptions

  

16.5.1.4

Momentary Power Interruptions

  

16.6.1.4

Normal Surge Voltage

  

16.5.1.5.1

Normal Surge Voltage (see note)

-HV

16.6.1.5

Engine Starting Under Voltage

N/A



16.5.1.5.2

Normal Frequency Transients



N/A

16.6.2.1

Abnormal Voltage

  

16.5.1.6

Normal Frequency Variations

N/A



16.6.2.2

Low Voltage Conditions

N/A  N/A

16.5.1.7

Voltage DC Content

P P P

16.6.2.3

Momentary Under Voltage Operation

  

16.5.1.8

Voltage Distortion

P P P

16.6.2.4

Abnormal Voltage Surge

  

16.5.2.1

Abnormal Voltage and Frequency

  

16.5.2.2

Momentary Under Voltage Operation

  

16.5.2.3.1

Abnormal Surge Voltage (see note)

-HV

16.5.2.3.2

Abnormal Frequency Transient



N/A

Table 3-1: -160 Option MX Test Coverage, 115VAC and 28VDC, Rev E

Avionics Software 23

Table 3-2: -160 Option MX Test Coverage, 230VAC and 14VDC, Rev E

Note that some AC tests requiring more than 300Vrms output will require the –HV (400 Vrms) optional output range.

User Manual – Rev H California Instruments

No.

115V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

28 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

Table

DDC

16.5.1.1

Voltage and Frequency

  

16.6.1.1

Voltage

  



16.5.1.2

Voltage Modulation

  

16.6.1.2

Ripple Voltage

P P P

X

16.5.1.3

Frequency Modulation

  

16.6.1.3

Momentary Power Interruptions

  



16.5.1.4

Momentary Power Interruptions

  

16.6.1.4

Normal Surge Voltage

  



16.5.1.5. 1

Normal Surge Voltage

  

16.6.1.5

Engine Starting Under Voltage

N/A



N/A

16.5.1.5. 2

Normal Frequency Transients



N/A

16.6.2.1

Abnormal Voltage

  



16.5.1.6

Normal Frequency Variations

N/A



16.6.2.2

Low Voltage Conditions

N/A  N/A

N/A

16.5.1.7

Voltage DC Content

P P P

16.6.2.3

Momentary Under Voltage Operation

  



16.5.1.8

Voltage Distortion

P P P

16.6.2.4

Abnormal Voltage Surge

  



16.5.2.1

Abnormal Voltage and Frequency

  

16.5.2.2

Momentary Under Voltage Operation

  

16.5.2.3. 1

Abnormal Surge Voltage

  

16.5.2.3. 2

Abnormal Frequency Transient



N/A

No.

230V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

14 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

Table

DDC

16.5.1.1

Voltage and Frequency

  

16.6.1.1

Voltage

  



16.5.1.2

Voltage Modulation

  

16.6.1.2

Ripple Voltage

P P P

P

16.5.1.3

Frequency Modulation

  

16.6.1.3

Momentary Power Interruptions

  



16.5.1.4

Momentary Power Interruptions

  

16.6.1.4

Normal Surge Voltage

  



16.5.1.5.1

Normal Surge Voltage (see note)

-HV

16.6.1.5

Engine Starting Under Voltage

N/A



N/A

16.5.1.5.2

Normal Frequency Transients



N/A

16.6.2.1

Abnormal Voltage

  



16.5.1.6

Normal Frequency Variations

N/A



16.6.2.2

Low Voltage Conditions

N/A  N/A

N/A

16.5.1.7

Voltage DC Content

P P P

16.6.2.3

Momentary Under Voltage Operation

  



Revision F

24 Avionics Software

Table 3-3: -160 Option MX Test Coverage, 115VAC, 28VDC and 270VDC, Rev F

User Manual - Rev H California Instruments

No.

230V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

14 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

Table

DDC

16.5.1.8

Voltage Distortion

P P P

16.6.2.4

Abnormal Voltage Surge

  



16.5.2.1

Abnormal Voltage and Frequency

  

16.5.2.2

Momentary Under Voltage Operation

  

16.5.2.3.1

Abnormal Surge Voltage (see note)

-HV

16.5.2.3.2

Abnormal Frequency Transient



N/A

Table 3-4: -160 Option MX Test Coverage, 230VAC, 14VDC and 135VDC, Rev F

Note that some AC tests requiring more than 300Vrms output will require the –HV (400 Vrms) optional output range.

Avionics Software 25

User Manual – Rev H California Instruments

Vnom

Test

Std requirement

Actual setting

Reason

115VAC

A(CF):16.5.1.2

115 +/- .18 Vrms

115 +/- .2 Vrms

Resolution

115VAC

A(NF):16.5.1.2

115 +/- .18 Vrms

115 +/- .2 Vrms

Resolution

115VAC

A(WF):16.5.1.2

115 +/- .18 Vrms

115 +/- .2 Vrms

Resolution

115VAC

A(CF):16.5.1.2

115 +/- 1.24 Vrms

115 +/- 1.2 Vrms

Resolution

115VAC

A(NF):16.5.1.2

115 +/- 1.24 Vrms

115 +/- 1.2 Vrms

Resolution

115VAC

A(WF):16.5.1.2

115 +/- 1.24 Vrms

115 +/- 1.2 Vrms

Resolution

230VAC

A(CF):16.5.1.2

230 +/- .36 Vrms

230 +/- .4 Vrms

Resolution

230VAC

A(CF):16.5.1.2

230 +/- 2.48 Vrms

230 +/- 2.5 Vrms

Resolution

115VAC

A(CF):16.5.1.3

400Hz mod by .75Hz

400Hz mod by .8Hz

Resolution

115VAC

A(NF):16.5.1.3

360Hz mod by .75Hz

360Hz mod by .8Hz

Resolution

115VAC

A(NF):16.5.1.3

650Hz mod by .75Hz

650Hz mod by .8Hz

Resolution

115VAC

A(WF):16.5.1.3

360Hz mod by .75Hz

360Hz mod by .8Hz

Resolution

115VAC

A(WF):16.5.1.3

800Hz mod by .75Hz

800Hz mod by .8Hz

Resolution

230VAC

A(CF):16.5.1.3

400Hz mod by .75Hz

400Hz mod by .8Hz

Resolution

14VDC

ADC:16.6.1.1

15.15 V nom

15.2 V nom

Resolution

14VDC

BDC:16.6.1.1

15.15 V nom

15.2 V nom

Resolution

14VDC

ZDC:16.6.1.1

15.15 V nom

15.2 V nom

Resolution

270VDC

ADC:16.6.1.2

ripple voltage

Not included

Requires additional equipment

28VDC

ADC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

28VDC

BDC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

28VDC

ZDC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

14VDC

ADC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

14VDC

BDC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

14VDC

ZDC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

14VDC

ADC:16.6.2.1

10.25 V nom

10.3 V nom

Resolution

14VDC

BDC:16.6.2.1

10.25 V nom

10.3 V nom

Resolution

14VDC

ZDC:16.6.2.1

10.25 V nom

10.3 V nom

Resolution

14VDC

ADC:16.6.2.4

23.15V in transient

23.2V in transient

Resolution

No.

115V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

28 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

16.5.1.1

Voltage and Frequency

  

16.6.1.1

Voltage

  

16.5.1.2

Voltage Modulation

  

16.6.1.2

Ripple Voltage

I, P

16.5.1.3

Frequency Modulation

  

16.6.1.3

Momentary Power Interruptions

  

3.1.1.1 Specific Test Limitations and Discrepancies

While every effort has been made to provide comprehensive coverage of the RTCA/DO-160 tests, some limitations apply, largely due to hardware limitations of the MX power source such as available programming resolution or rounding. The following table lists specific implementation issues by test number. The deviation from the standard requirement is shown in the “Actual setting” column. The reason for the deviation is shown in the last column.

3.1.2 i/iX Series –DO160 Option Limitations

26 Avionics Software

The extent of coverage of the –160 option as implemented on the iX Series platform is shown in the

table below. Tests marked with an „x‟ generally require additional hardware to be used. Tests marked

„N/A‟ are not applicable to the corresponding table. Tests marked with a „‟ are covered by the –160 option. Tests marked with a „P‟ require arbitrary waveform capability, which is available on iX models

only. Tests marked with an “I” are available on the i/iX products only. Tests marked with a „C‟ are

available on the Compact iX products only.

User Manual - Rev H California Instruments

No.

115V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

28 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

16.5.1.4

Momentary Power Interruptions

  

16.6.1.4

Normal Surge Voltage

  

16.5.1.5.1

Normal Surge Voltage

  

16.6.1.5

Engine Starting Under Voltage

N/A



16.5.1.5.2

Normal Frequency Transients



N/A

16.6.2.1

Abnormal Voltage

  

16.5.1.6

Normal Frequency Variations

N/A



16.6.2.2

Low Voltage Conditions

N/A  N/A

16.5.1.7

Voltage DC Content

P or

C,x

P or

C,x

P or

C,x

16.6.2.3

Momentary Under Voltage Operation

  

16.5.1.8

Voltage Distortion

P P P

16.6.2.4

Abnormal Voltage Surge

  

16.5.2.1

Abnormal Voltage and Frequency

  

16.5.2.2

Momentary Under Voltage Operation

  

16.5.2.3.1

Abnormal Surge Voltage

  

16.5.2.3.2

Abnormal Frequency Transient



N/A

No.

230V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

14 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

16.5.1.1

Voltage and Frequency



C C 16.6.1.1

Voltage

  

16.5.1.2

Voltage Modulation



C C 16.6.1.2

Ripple Voltage

I, P

16.5.1.3

Frequency Modulation



C C 16.6.1.3

Momentary Power Interruptions

  

16.5.1.4

Momentary Power Interruptions



C C 16.6.1.4

Normal Surge Voltage

  

16.5.1.5.1

Normal Surge Voltage

X X X

16.6.1.5

Engine Starting Under Voltage

N/A



16.5.1.5.2

Normal Frequency Transients



N/A

16.6.2.1

Abnormal Voltage

  

16.5.1.6

Normal Frequency Variations

N/A C C

16.6.2.2

Low Voltage Conditions

N/A  N/A

16.5.1.7

Voltage DC Content

P or

C,x

C, x

16.6.2.3

Momentary Under Voltage Operation

  

16.5.1.8

Voltage Distortion

P

C, P

16.6.2.4

Abnormal Voltage Surge

  

16.5.2.1

Abnormal Voltage and Frequency



C C

16.5.2.2

Momentary Under Voltage Operation



C C

16.5.2.3.1

Abnormal Surge Voltage

X X X

16.5.2.3.2

Abnormal



C C

Table 3-5: -160 Option i/iX Test Coverage, 115VAC and 28VDC

Avionics Software 27

User Manual – Rev H California Instruments

No.

230V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

14 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

Frequency Transient

Vnom

Test

Std requirement

Actual setting

Reason

230VAC

A(NF)

No Tests Performed

Max. output voltage limitation

230VAC

A(WF)

No Tests Performed

Max. output voltage limitation

115VAC

A(CF):16.5.1.2

115 +/- .18 Vrms

115 +/- .2 Vrms

Resolution

115VAC

A(NF):16.5.1.2

115 +/- .18 Vrms

115 +/- .2 Vrms

Resolution

115VAC

A(WF):16.5.1.2

115 +/- .18 Vrms

115 +/- .2 Vrms

Resolution

115VAC

A(CF):16.5.1.2

115 +/- 1.24 Vrms

115 +/- 1.2 Vrms

Resolution

115VAC

A(NF):16.5.1.2

115 +/- 1.24 Vrms

115 +/- 1.2 Vrms

Resolution

115VAC

A(WF):16.5.1.2

115 +/- 1.24 Vrms

115 +/- 1.2 Vrms

Resolution

230VAC

A(CF):16.5.1.2

230 +/- .36 Vrms

230 +/- .4 Vrms

Resolution

230VAC

A(CF):16.5.1.2

230 +/- 2.48 Vrms

230 +/- 2.5 Vrms

Resolution

115VAC

A(CF):16.5.1.3

400Hz mod by .75Hz

400Hz mod by .8Hz

Resolution

115VAC

A(NF):16.5.1.3

360Hz mod by .75Hz

360Hz mod by .8Hz

Resolution

115VAC

A(NF):16.5.1.3

650Hz mod by .75Hz

650Hz mod by .8Hz

Resolution

115VAC

A(WF):16.5.1.3

360Hz mod by .75Hz

360Hz mod by .8Hz

Resolution

115VAC

A(WF):16.5.1.3

800Hz mod by .75Hz

800Hz mod by .8Hz

Resolution

230VAC

A(CF):16.5.1.3

400Hz mod by .75Hz

400Hz mod by .8Hz

Resolution

230VAC

A(CF):16.5.1.5.1

320V Transient

Test skipped

Requires additional equipment

230VAC

A(CF):16.5.2.3.1

360V Transient

Test skipped

Requires additional equipment

14VDC

ADC:16.6.1.1

15.15 V nom

15.2 V nom

Resolution

14VDC

BDC:16.6.1.1

15.15 V nom

15.2 V nom

Resolution

14VDC

ZDC:16.6.1.1

15.15 V nom

15.2 V nom

Resolution

28VDC

ADC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

28VDC

BDC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

28VDC

ZDC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

14VDC

ADC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

14VDC

BDC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

14VDC

ZDC:16.6.1.2

> 5 kHz ripple voltage

Test skipped

Requires additional equipment

14VDC

ADC:16.6.2.1

10.25 V nom

10.3 V nom

Resolution

14VDC

BDC:16.6.2.1

10.25 V nom

10.3 V nom

Resolution

14VDC

ZDC:16.6.2.1

10.25 V nom

10.3 V nom

Resolution

14VDC

ADC:16.6.2.4

23.15V in transient

23.2V in transient

Resolution

Table 3-6: -160 Option i/iX Test Coverage, 230VAC and 14VDC

Note that the iX Series does not support 800 Hz testing at more than 150Vrms. Consequently, all 230V nominal tests for A(NF) and A(WF) categories are not supported. Some A(CF) tests requiring more than 300V output are also unavailable due to hardware limitations of the iX Series power source.

3.1.2.1 Specific Test Limitations and Discrepancies

While every effort has been made to provide comprehensive coverage of the RTCA/DO-160 tests, some limitations apply, largely due to hardware limitations of the iX power source such as available programming resolution or rounding. The following table lists specific implementation issues by test

number. The deviation from the standard requirement is shown in the “Actual setting” column. The

reason for the deviation is shown in the last column.

28 Avionics Software

User Manual - Rev H California Instruments

No.

115V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

28 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

16.5.1.1

Voltage and Frequency

  

16.6.1.1

Voltage X X

X

16.5.1.2

Voltage Modulation

  

16.6.1.2

Ripple Voltage

X X X

16.5.1.3

Frequency Modulation

  

16.6.1.3

Momentary Power Interruptions

X X X

16.5.1.4

Momentary Power Interruptions

  

16.6.1.4

Normal Surge Voltage

X X X

16.5.1.5.1

Normal Surge Voltage

  

16.6.1.5

Engine Starting Under Voltage

X X X

16.5.1.5.2

Normal Frequency Transients



N/A

16.6.2.1

Abnormal Voltage

X X X

16.5.1.6

Normal Frequency Variations

N/A



16.6.2.2

Low Voltage Conditions

X X X

16.5.1.7

Voltage DC Content

X X X

16.6.2.3

Momentary Under Voltage Operation

X X X

16.5.1.8

Voltage Distortion

P P P

16.6.2.4

Abnormal Voltage Surge

X X X

16.5.2.1

Abnormal Voltage and Frequency

  

16.5.2.2

Momentary Under Voltage Operation

  

16.5.2.3.1

Abnormal Surge Voltage

  

16.5.2.3.2

Abnormal Frequency Transient



N/A

3.1.3 Lx/Ls Series –DO160 Option Limitations

The extent of coverage of the –160 option as implemented on the Lx/Ls Series platform is shown in

the table below. Tests marked with an „x‟ generally require additional hardware to be used. Tests marked „N/A‟ are not applicable to the corresponding table. Tests marked with a „‟ are covered by

the –160 option. Tests marked with a „P‟ require arbitrary waveform capability, which is available on Lx models and Ls models with the –ADV option only. Note that some voltage surge tests may require optional output voltage ranges on the Lx/Ls and may not be supported on the standard voltage range.

DC tests are NOT supported by the Lx/Ls Series

Table 3-7: -160 Option Ls/Lx Test Coverage, 115VAC and 28VDC

Avionics Software 29

User Manual – Rev H California Instruments

No.

230V Tests Description

Table A(CF)

Table A(NF)

Table

A(WF)

No.

14 VDC Tests Description

Table

ADC

Table

BDC

Table

ZDC

16.5.1.1

Voltage and Frequency

  

16.6.1.1

Voltage X X

X

16.5.1.2

Voltage Modulation

  

16.6.1.2

Ripple Voltage

X X X

16.5.1.3

Frequency Modulation

  

16.6.1.3

Momentary Power Interruptions

X X X

16.5.1.4

Momentary Power Interruptions

  

16.6.1.4

Normal Surge Voltage

X X X

16.5.1.5.1

Normal Surge Voltage1

  

16.6.1.5

Engine Starting Under Voltage

X X X

16.5.1.5.2

Normal Frequency Transients



N/A

16.6.2.1

Abnormal Voltage

X X X

16.5.1.6

Normal Frequency Variations

N/A



16.6.2.2

Low Voltage Conditions

X X X

16.5.1.7

Voltage DC Content

X X X

16.6.2.3

Momentary Under Voltage Operation

X X X

16.5.1.8

Voltage Distortion

P P P

16.6.2.4

Abnormal Voltage Surge

X X X

16.5.2.1

Abnormal Voltage and Frequency

  

16.5.2.2

Momentary Under Voltage Operation

  

16.5.2.3.1

Abnormal Surge Voltage2

  

16.5.2.3.2

Abnormal Frequency Transient



N/A

Table 3-8: -160 Option Ls/Lx Test Coverage, 230VAC and 14VDC

1

Requires –HV voltage range option.

2

Requires –HV voltage range option.

30 Avionics Software

User Manual - Rev H California Instruments

Vnom

Test

Std requirement

Actual setting

Reason

115VAC

A(CF):16.5.1.2

115 +/- .18 Vrms

115 +/- .2 Vrms

Resolution

115VAC

A(NF):16.5.1.2

115 +/- .18 Vrms

115 +/- .2 Vrms

Resolution

115VAC

A(WF):16.5.1.2

115 +/- .18 Vrms

115 +/- .2 Vrms

Resolution

115VAC

A(CF):16.5.1.2

115 +/- 1.24 Vrms

115 +/- 1.2 Vrms

Resolution

115VAC

A(NF):16.5.1.2

115 +/- 1.24 Vrms

115 +/- 1.2 Vrms

Resolution

115VAC

A(WF):16.5.1.2

115 +/- 1.24 Vrms

115 +/- 1.2 Vrms

Resolution

230VAC

A(CF):16.5.1.2

230 +/- .36 Vrms

230 +/- .4 Vrms

Resolution

230VAC

A(CF):16.5.1.2

230 +/- 2.48 Vrms

230 +/- 2.5 Vrms

Resolution

115VAC

A(CF):16.5.1.3

400Hz mod by .75Hz

400Hz mod by .8Hz

Resolution

115VAC

A(NF):16.5.1.3

360Hz mod by .75Hz

360Hz mod by .8Hz

Resolution

115VAC

A(NF):16.5.1.3

650Hz mod by .75Hz

650Hz mod by .8Hz

Resolution

115VAC

A(WF):16.5.1.3

360Hz mod by .75Hz

360Hz mod by .8Hz

Resolution

115VAC

A(WF):16.5.1.3

800Hz mod by .75Hz

800Hz mod by .8Hz

Resolution

230VAC

A(CF):16.5.1.3

400Hz mod by .75Hz

400Hz mod by .8Hz

Resolution

230VAC

A(CF):16.5.1.5.1

320V Transient

No deviation but –HV option required to run.

Max voltage 320Vrms requires 400V range.

230VAC

A(CF):16.5.2.3.1

360V Transient

No deviation but –HV option required to run.

Max voltage 360Vrms requires 400V range.

3.1.3.1 Specific Test Limitations and Discrepancies

While every effort has been made to provide comprehensive coverage of the RTCA/DO-160 tests, some limitations apply, largely due to hardware limitations of the Lx power source such as available programming resolution or rounding. The following table lists specific implementation issues by test number. The deviation from the standard requirement is shown in the “Actual setting” column. The reason for the deviation is shown in the last column.

DC tests are NOT supported by the Lx/Ls Series

Avionics Software 31

User Manual – Rev H California Instruments

3.2 –160 Power Groups

The following twelve power groups are covered in the RTCA/DO-160 directive: Category reference:

- For ac equipment: A(CF), A(NF), and A(WF)

- For dc equipment: A, B, Z

- AC tests can be performed at 115V nominal or 230V nominal, except A(NF) and A(CF),

which can only be done at 115V nominal. All AC line voltages shown are L-N.

- DC tests can be performed at 28V nominal or 14V nominal Definitions: A(CF): designates ac equipment intended for use on aircraft electrical systems where the primary

power is from constant frequency (400 Hz) ac system. A(NF): designates ac equipment intended for use on aircraft electrical systems where the primary

power is from narrow variable frequency (360 to 650 Hz) ac system. A(WF): designates ac equipment intended for use on aircraft electrical systems where the primary

power is from wide variable frequency (360 to 800 Hz) ac system. A: designates dc equipment intended for use on aircraft electrical systems where the dc is generated

from primary power supplied from either a constant or variable frequency ac system. B: designates dc equipment intended for use on aircraft electrical systems supplied by engine-driven

alternator/rectifiers, or dc generators where a battery of significant capacity is floating on the dc bus at all times.

Z: designates dc equipment that may be used on all other types of aircraft electrical systems applicable to these standards. Category Z shall be acceptable for use in lieu of Category A or Category B.

D: designates dc equipment that may be used on all other types of aircraft electrical systems applicable to these standards. Category Z shall be acceptable for use in lieu of Category A or Category B.

The required steady state output settings for each power group must be selected based on the type of EUT to be tested. These settings can be made from the front panel of the power source or from the main Gui control screen.

32 Avionics Software

User Manual - Rev H California Instruments

3.3 –160 Option Special Features

DC ripple tests for 28VDC or 14VDC EUT‟s are provided through a separate control screen. This is

required to extend the range of the ripple frequency to 5000 Hz. The actual requirement for DO160 Rev E is testing up to 150 KHz ripple. This is out of the available range of the power source. To test to the full 150 KHz range, an external audio generator and coupling transformer as outlined in RTCA/DO160, Section 18, Figure 18-1 is required.

The DO160 DC Ripple test screen is available from the main screen, Applications, RTCA/DO160, DC Ripple Test menu. Once selected, the DC ripple test control screen is modal and must be closed before any other tests can be run. Opening this screen requires several seconds as the power source is being set up to perform the DC ripple tests. This screen also places the power source in AC+DC mode.

Available test settings are 14VDC or 28VDC nominal, category A, Z or category B and phase/output selection. For single-phase systems, only phase A can be selected. The test pattern is fixed per section 18.3.1 with a ripple frequency range from 16 Hz to 5000 Hz per Figure 18-2 (Cat A,Z) or 18-3 (Cat B). The frequency slew rate is 30 minutes for each decade covered or one hour and 15 minutes total. Tests can be aborted sooner if needed.

3.4 Test Tables

The tables shown on the next few pages list the test sections covered by the –160 option. Where relevant, the numbering used matches that of the RTCA/DO-160 document. Test tables are listed by power group

.

Figure 3-1: DO160E DC Ripple Test Window.

Avionics Software 33

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.5.1

Normal Operating Conditions (ac)

16.5.1.1b(1)

1 Phs Voltage and Frequency (ac)

100V to 122V, 390Hz to 410Hz

Apply for 30 mins each test

EACF115_VFNORM1P

16.5.1.1c(1)

3 Phs Voltage and Frequency (ac)

100V to 122V, 390Hz to 410Hz

Apply for 30 mins each test

EACF115_VFNORM3P

16.5.1

Emergency Operating Conditions (ac)

16.5.1.1b(2)

1 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 440Hz

Apply for 30 mins each test

EACF115_VFEMER1P

16.5.1.1c(2)

3 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 440Hz

Apply for 30 mins each test

EACF115_VFEMER3P

16.5.1

Normal Operating Conditions (ac)

16.5.1.2

Voltage Modulation (ac)

Vamp = 0.18V to 1.24V, Mrate = 1Hz to 200Hz

Figure 16-1

EACF115_VMOD

16.5.1.3

Frequency Modulation (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

EACF115_FMOD

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1

Equipment with Digital Circuits

EACF115_PINTB

16.5.1.4c

Momentary Power Interruptions (ac)

Other Equipment

EACF115_PINTC

16.5.1.5

Normal Transients (ac)

16.5.1.5.1 - Normal Voltage Surge (ac)

160V to 70V, 400 Hz

EACF115_NVSUR

16.5.1.5.2 - Normal Frequency Surge (ac)

115V, 350Hz to 400Hz

EACF115_NFSUR

16.5.1.7

Voltage DC Content (ac)

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.1VDC

Apply for 30 mins each test

EACF115_DCOFS1P

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.1VDC

Apply for 30 mins each test

EACF115_DCOFS3P

16.5.1.8

Voltage Distortion (ac)

8% +2%/-0% VTHD - Clipped Sine, 400Hz

Apply for 30 mins each test

EACF115_VTHD

16.5.2

Abnormal Operating Conditions (ac)

16.5.2.1b

1 Phs Voltage (ac)

97V to 134V, 400Hz

Apply for 5 mins each test

EACF115_VABN1P

16.5.2.1c

3 Phs Voltage (ac)

97V to 134V, 400Hz

Apply for 5 mins each test

EACF115_VABN3P

16.5.2.1d

1 Phs Voltage and Frequency (ac)

100V to 122V, 370Hz to 430Hz

Apply for 5 mins each test

EACF115_VFABN1P

16.5.2.1e

3 Phs Voltage and Frequency (ac)

100V to 122V, 370Hz to 430Hz

Apply for 5 mins each test

EACF115_VFABN3P

16.5.2.2

Momentary Undervoltage (ac)

10V and 60V, 400Hz

Apply for 7 seconds each test

EACF115_VUND

16.5.2.3

Abnormal Transients (ac)

16.5.2.3.1 - Abnormal Voltage surge

148V to 180V, 400Hz

Figure 16.5 - apply at 10 sec intervals

EACF115_AVSUR

16.5.2.3.1 - Abnormal Frequency transients

0V to 115V, 320Hz to 480Hz

Figure 16.5 - apply at 10 sec intervals

EACF115_AFSUR

3.4.1 DO160 Section 16, Rev E:

3.4.1.1 Table A(CF)115:

34 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.5.1

Normal Operating Conditions (ac)

16.5.1.1b(1)

1 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 650Hz

Apply for 30 mins each test

EANF115_VFNORM1P

16.5.1.1c(1)

3 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 650Hz

Apply for 30 mins each test

EANF115_VFNORM3P

16.5.1

Emergency Operating Conditions (ac)

16.5.1.1c(2)

3 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 650Hz

Apply for 30 mins each test

EANF115_VFEMER3P

16.5.1

Normal Operating Conditions (ac)

16.5.1.2

Voltage Modulation 360Hz (ac)

Vamp = 0.18V to 1.24V, Mrate = 1Hz to 200Hz

Figure 16-1

EANF115_VMOD360

16.5.1.2

Voltage Modulation 650Hz (ac)

Vamp = 0.18V to 1.24V, Mrate = 1Hz to 200Hz

Figure 16-1

EANF115_VMOD650

16.5.1.3

Frequency Modulation 360Hz (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

EANF115_FMOD360

16.5.1.3

Frequency Modulation 650Hz (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

EANF115_FMOD650

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1 360Hz nom

Equipment with Digital Circuits

EANF115_PINTB360

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1 650Hz nom

Equipment with Digital Circuits

EANF115_PINTB650

16.5.1.4c

Momentary Power Interruptions (ac)

360Hz nom

Other Equipment

EANF115_PINTC360

16.5.1.4c

Momentary Power Interruptions (ac)

650Hz nom

Other Equipment

EANF115_PINTC650

16.5.1.4d

Momentary Power Interruptions (ac)

Table 16-2

Additional Requirement (Var Freq)

EANF115_PINTD

16.5.1.5

Normal Transients (ac)

16.5.1.5.1 - Normal Voltage Surge (ac)

160V to 70V, 360 Hz

EANF115_NVSUR360

16.5.1.5.1 - Normal Voltage Surge (ac)

160V to 70V, 650 Hz

EANF115_NVSUR650

16.5.1.6

Normal Frequency Surge (ac)

115V, 360Hz to 650Hz

EANF115_NFSUR

16.5.1.7

Voltage DC Content (ac)

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.1VDC (360Hz nom)

Apply for 30 mins each test

EANF115_DCOFS1P360

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.1VDC (650Hz nom)

Apply for 30 mins each test

EANF115_DCOFS1P650

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.1VDC (360Hz nom)

Apply for 30 mins each test

EANF115_DCOFS3P360

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.1VDC (650Hz nom)

Apply for 30 mins each test

EANF115_DCOFS3P650

16.5.1.8

Voltage Distortion (ac)

8% +2%/-0% VTHD - Clipped Sine, 360Hz

Apply for 30 mins each test

EANF115_VTHD360

16.5.1.8

Voltage Distortion (ac)

8% +2%/-0% VTHD - Clipped Sine, 650Hz

Apply for 30 mins each test

EANF115_VTHD650

16.5.2

Abnormal Operating Conditions (ac)

16.5.2.1b

1 Phs Voltage (ac)

97V to 134V, 360Hz

Apply for 5 mins each test

EANF115_VABN1P360

16.5.2.1b

1 Phs Voltage (ac)

97V to 134V, 650Hz

Apply for 5 mins each test

EANF115_VABN1P650

16.5.2.1c

3 Phs Voltage (ac)

97V to 134V, 360Hz

Apply for 5 mins each test

EANF115_VABN3P360

16.5.2.1c

3 Phs Voltage (ac)

97V to 134V, 650Hz

Apply for 5 mins each test

EANF115_VABN3P650

16.5.2.2

Momentary Undervoltage (ac)

10V and 60V, 360Hz

Apply for 7 seconds each test

EANF115_VUND360

16.5.2.2

Momentary Undervoltage (ac)

10V and 60V, 650Hz

Apply for 7 seconds each test

EANF115_VUND650

16.5.2.3

Abnormal Transients (ac)

3.4.1.2 Table A(NF)115:

Avionics Software 35

User Manual – Rev H California Instruments

16.5.2.3.1 - Abnormal Voltage surge

148V to 180V, 360Hz

Figure 16.5 - apply at 10 sec intervals

EANF115_AVSUR360

16.5.2.3.1 - Abnormal Voltage surge

148V to 180V, 650Hz

Figure 16.5 - apply at 10 sec intervals

EANF115_AVSUR650

36 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.5.1

Normal Operating Conditions (ac)

16.5.1.1b(1)

1 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 800Hz

Apply for 30 mins each test

EAWF115_VFNORM1P

16.5.1.1c.2(1)

3 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 800Hz

Apply for 30 mins each test

EAWF115_VFNORM3P

16.5.1

Emergency Operating Conditions (ac)

16.5.1.1c.2(2)

3 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 800Hz

Apply for 30 mins each test

EAWF115_VFEMER3P

16.5.1

Normal Operating Conditions (ac)

16.5.1.2

Voltage Modulation 360Hz (ac)

Vamp = 0.18V to 1.24V, Mrate = 1Hz to 200Hz

Figure 16-1

EAWF115_VMOD360

16.5.1.2

Voltage Modulation 800Hz (ac)

Vamp = 0.18V to 1.24V, Mrate = 1Hz to 200Hz

Figure 16-1

EAWF115_VMOD800

16.5.1.3

Frequency Modulation 360Hz (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

EAWF115_FMOD360

16.5.1.3

Frequency Modulation 800Hz (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

EAWF115_FMOD800

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1 360Hz nom

Equipment with Digital Circuits

EAWF115_PINTB360

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1 800Hz nom

Equipment with Digital Circuits

EAWF115_PINTB800

16.5.1.4c

Momentary Power Interruptions (ac)

360Hz nom

Other Equipment

EAWF115_PINTC360

16.5.1.4c

Momentary Power Interruptions (ac)

800Hz nom

Other Equipment

EAWF115_PINTC800

16.5.1.4d

Momentary Power Interruptions (ac)

Table 16-2

Additional Requirement (Var Freq)

EAWF115_PINTD

16.5.1.5

Normal Transients (ac)

16.5.1.5.1 - Normal Voltage Surge (ac)

160V to 70V, 360 Hz

EAWF115_NVSUR360

16.5.1.5.1 - Normal Voltage Surge (ac)

160V to 70V, 800 Hz

EAWF115_NVSUR800

16.5.1.6

Normal Frequency Surge (ac)

115V, 360Hz to 800Hz

EAWF115_NFSUR

16.5.1.7

Voltage DC Content (ac)

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.1VDC (360Hz nom)

Apply for 30 mins each test

EAWF115_DCOFS1P360

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.1VDC (800Hz nom)

Apply for 30 mins each test

EAWF115_DCOFS1P800

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.1VDC (360Hz nom)

Apply for 30 mins each test

EAWF115_DCOFS3P360

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.1VDC (800Hz nom)

Apply for 30 mins each test

EAWF115_DCOFS3P800

16.5.1.8

Voltage Distortion (ac)

10% +2%/-0% VTHD - Clipped Sine, 360Hz

Apply for 30 mins each test

EAWF115_VTHD360

16.5.1.8

Voltage Distortion (ac)

10% +2%/-0% VTHD - Clipped Sine, 800Hz

Apply for 30 mins each test

EAWF115_VTHD800

16.5.2

Abnormal Operating Conditions (ac)

16.5.2.1b

1 Phs Voltage (ac)

97V to 134V, 360Hz

Apply for 5 mins each test

EAWF115_VABN1P360

16.5.2.1b

1 Phs Voltage (ac)

97V to 134V, 800Hz

Apply for 5 mins each test

EAWF115_VABN1P800

16.5.2.1c

3 Phs Voltage (ac)

97V to 134V, 360Hz

Apply for 5 mins each test

EAWF115_VABN3P360

3.4.1.3 Table A(WF)115:

Avionics Software 37

User Manual – Rev H California Instruments

16.5.2.1c

3 Phs Voltage (ac)

97V to 134V, 800Hz

Apply for 5 mins each test

EAWF115_VABN3P800

16.5.2.2

Momentary Undervoltage (ac)

10V and 60V, 360Hz

Apply for 7 seconds each test

EAWF115_VUND360

16.5.2.2

Momentary Undervoltage (ac)

10V and 60V, 800Hz

Apply for 7 seconds each test

EAWF115_VUND800

16.5.2.3

Abnormal Transients (ac)

16.5.2.3.1 - Abnormal Voltage surge

148V to 180V, 360Hz

Figure 16.5 - apply at 10 sec intervals

EAWF115_AVSUR360

16.5.2.3.1 - Abnormal Voltage surge

148V to 180V, 800Hz

Figure 16.5 - apply at 10 sec intervals

EAWF115_AVSUR800

38 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

22.0V to 30.3V

Apply for 30 mins each test

EADC28_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

18.0V

Apply for 30 mins each test

EADC28_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = 0.6V to 1.6V, Freq = 10Hz to 200Hz

Figure 18-2

EADC28_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

EADC28_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

EADC28_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

47V to 17V

EADC28_NVSUR

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

20.5V to 32.2V

Apply for 5 mins each test

EADC28_VABN

16.6.2.3

Momentary Undervoltage (dc)

12V

Apply for 7 seconds each test

EADC28_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4c - Abnormal Voltage Surge

46.3V

Figure 16-4 - apply at 10 sec intervals

EADC28_AVSUR

3.4.1.4 Table ADC28:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

Avionics Software 39

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

22.0V to 30.3V

Apply for 30 mins each test

EBDC28_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

18.0V

Apply for 30 mins each test

EBDC28_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = 1.6V, Freq = 200Hz

Figure 18-2

EBDC28_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

EBDC28_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

EBDC28_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

47V to 17V

EBDC28_NVSUR

16.6.1.5

Engine Starting Under Voltage Operation (dc)

10V min

Slew for 35 sec

EBDC28_VENG

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

20.5V to 32.2V

Apply for 5 mins each test

EBDC28_VABN

16.6.2.2

Low Voltage Conditions (dc)

0V over 10 minutes

EBDC28_LVABN

16.6.2.3

Momentary Undervoltage (dc)

12V

Apply for 7 seconds each test

EBDC28_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4d - Abnormal Voltage Surge

60VDC

Figure 16-4 - apply at 10 sec intervals

EBDC28_AVSUR

3.4.1.5 Table BDC28:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

40 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

22.0V to 30.3V

Apply for 30 mins each test

EZDC28_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

18.0V

Apply for 30 mins each test

EZDC28_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = 0.6V to 1.6V, Freq = 10Hz to 200Hz

Figure 18-2

EZDC28_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

EZDC28_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

EZDC28_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

50V to 12V

EZDC28_NVSUR

16.6.1.5

Engine Starting Under Voltage Operation (dc)

10V min

Slew for 35 sec

EZDC28_VENG

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

20.5V to 32.2V

Apply for 5 mins each test

EZDC28_VABN

16.6.2.3

Momentary Undervoltage (dc)

12V

Apply for 7 seconds each test

EZDC28_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4b - Abnormal Voltage Surge

80VDC

Figure 16-4 - apply at 10 sec intervals

EZDC28_AVSUR

3.4.1.6 Table ZDC28:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

Avionics Software 41

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.5.1

Normal Operating Conditions (ac)

16.5.1.1b(1)

1 Phs Voltage and Frequency (ac)

200V to 244V, 390Hz to 410Hz

Apply for 30 mins each test

EACF230_VFNORM1P

16.5.1.1c(1)

3 Phs Voltage and Frequency (ac)

200V to 244V, 390Hz to 410Hz

Apply for 30 mins each test

EACF230_VFNORM3P

16.5.1

Emergency Operating Conditions (ac)

16.5.1.1b(2)

1 Phs Voltage and Frequency (ac)

200V to 244V, 360Hz to 440Hz

Apply for 30 mins each test

EACF230_VFEMER1P

16.5.1.1c(2)

3 Phs Voltage and Frequency (ac)

200V to 244V, 360Hz to 440Hz

Apply for 30 mins each test

EACF230_VFEMER3P

16.5.1

Normal Operating Conditions (ac)

16.5.1.2

Voltage Modulation (ac)

Vamp = 0.36V to 2.48V, Mrate = 1Hz to 200Hz

Figure 16-1

EACF230_VMOD

16.5.1.3

Frequency Modulation (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

EACF230_FMOD

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1

Equipment with Digital Circuits

EACF230_PINTB

16.5.1.4c

Momentary Power Interruptions (ac)

Other Equipment

EACF230_PINTC

16.5.1.5

Normal Transients (ac)

16.5.1.5.1 - Normal Voltage Surge (ac)

320V to 140V, 400 Hz

EACF230_NVSUR

16.5.1.5.2 - Normal Frequency Surge (ac)

230V, 350Hz to 400Hz

EACF230_NFSUR

16.5.1.7

Voltage DC Content (ac)

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.2VDC

Apply for 30 mins each test

EACF230_DCOFS1P

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.2VDC

Apply for 30 mins each test

EACF230_DCOFS3P

16.5.1.8

Voltage Distortion (ac)

8% +2%/-0% VTHD - Clipped Sine, 400Hz

Apply for 30 mins each test

EACF230_VTHD

16.5.2

Abnormal Operating Conditions (ac)

16.5.2.1b

1 Phs Voltage (ac)

194V to 268V, 400Hz

Apply for 5 mins each test

EACF230_VABN1P

16.5.2.1c

3 Phs Voltage (ac)

194V to 268V, 400Hz

Apply for 5 mins each test

EACF230_VABN3P

16.5.2.1d

1 Phs Voltage and Frequency (ac)

200V to 244V, 370Hz to 430Hz

Apply for 5 mins each test

EACF230_VFABN1P

16.5.2.1e

3 Phs Voltage and Frequency (ac)

200V to 244V, 370Hz to 430Hz

Apply for 5 mins each test

EACF230_VFABN3P

16.5.2.2

Momentary Undervoltage (ac)

20V and 120V, 400Hz

Apply for 7 seconds each test

EACF230_VUND

16.5.2.3

Abnormal Transients (ac)

16.5.2.3.1 - Abnormal Voltage surge

296V to 360V, 400Hz

Figure 16.5 - apply at 10 sec intervals

EACF230_AVSUR

16.5.2.3.1 - Abnormal Frequency transients

0V to 230V, 320Hz to 480Hz

Figure 16.5 - apply at 10 sec intervals

EACF230_AFSUR

3.4.1.7 Table A(CF)230:

42 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

11.0V to 15.2V

Apply for 30 mins each test

EADC14_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

9.0V

Apply for 30 mins each test

EADC14_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = 0.3V to .8V, Freq = 10Hz to 200Hz

Figure 18-2

EADC14_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

EADC14_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

EADC14_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

23.5V to 8.5V

EADC14_NVSUR

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

10.3V to 16.1V

Apply for 5 mins each test

EADC14_VABN

16.6.2.3

Momentary Undervoltage (dc)

6V

Apply for 7 seconds each test

EADC14_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4c - Abnormal Voltage Surge

23.2V

Figure 16-4 - apply at 10 sec intervals

EADC14_AVSUR

3.4.1.8 Table ADC14:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

Avionics Software 43

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

11.0V to 15.2V

Apply for 30 mins each test

EBDC14_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

9.0V

Apply for 30 mins each test

EBDC14_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = .8V, Freq = 200Hz

Figure 18-2

EBDC14_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

EBDC14_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

EBDC14_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

23.5V to 8.5V

EBDC14_NVSUR

16.6.1.5

Engine Starting Under Voltage Operation (dc)

5V min

Slew for 35 sec

EBDC14_VENG

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

10.3V to 16.1V

Apply for 5 mins each test

EBDC14_VABN

16.6.2.2

Low Voltage Conditions (dc)

0V over 10 minutes

EBDC14_LVABN

16.6.2.3

Momentary Undervoltage (dc)

6V

Apply for 7 seconds each test

EBDC14_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4d - Abnormal Voltage Surge

30VDC

Figure 16-4 - apply at 10 sec intervals

EBDC14_AVSUR

3.4.1.9 Table BDC14:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

44 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

11.0V to 15.2V

Apply for 30 mins each test

EZDC14_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

9.0V

Apply for 30 mins each test

EZDC14_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = 0.3V to .8V, Freq = 10Hz to 200Hz

Figure 18-2

EZDC14_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

EZDC14_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

EZDC14_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

25V to 6V

EZDC14_NVSUR

16.6.1.5

Engine Starting Under Voltage Operation (dc)

5V min

Slew for 35 sec

EZDC14_VENG

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

10.3V to 16.1V

Apply for 5 mins each test

EZDC14_VABN

16.6.2.3

Momentary Undervoltage (dc)

6V

Apply for 7 seconds each test

EZDC14_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4b - Abnormal Voltage Surge

40VDC

Figure 16-4 - apply at 10 sec intervals

EZDC14_AVSUR

3.4.1.10 Table ZDC14:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

Avionics Software 45

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.5.1

Normal Operating Conditions (ac)

16.5.1.1b(1)

1 Phs Voltage and Frequency (ac)

100V to 122V, 390Hz to 410Hz

Apply for 30 mins each test

FACF115_VFNORM1P

16.5.1.1c(1)

3 Phs Voltage and Frequency (ac)

100V to 122V, 390Hz to 410Hz

Apply for 30 mins each test

FACF115_VFNORM3P

16.5.1

Emergency Operating Conditions (ac)

16.5.1.1b(2)

1 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 440Hz

Apply for 30 mins each test

FACF115_VFEMER1P

16.5.1.1c(2)

3 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 440Hz

Apply for 30 mins each test

FACF115_VFEMER3P

16.5.1

Normal Operating Conditions (ac)

16.5.1.2

Voltage Modulation (ac)

Vamp = 0.18V to 1.24V, Mrate = 1Hz to 200Hz

Figure 16-1

FACF115_VMOD

16.5.1.3

Frequency Modulation (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

FACF115_FMOD

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1

Equipment with Digital Circuits

FACF115_PINTB

16.5.1.4c

Momentary Power Interruptions (ac)

Other Equipment

FACF115_PINTC

16.5.1.5

Normal Transients (ac)

16.5.1.5.1 - Normal Voltage Surge (ac)

160V to 70V, 400 Hz

FACF115_NVSUR

16.5.1.5.2 - Normal Frequency Surge (ac)

115V, 350Hz to 400Hz

FACF115_NFSUR

16.5.1.7

Voltage DC Content (ac)

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.1VDC

Apply for 30 mins each test

FACF115_DCOFS1P

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.1VDC

Apply for 30 mins each test

FACF115_DCOFS3P

16.5.1.8

Voltage Distortion (ac)

8% +2%/-0% VTHD - Clipped Sine, 400Hz

Apply for 30 mins each test

FACF115_VTHD

16.5.2

Abnormal Operating Conditions (ac)

16.5.2.1b

1 Phs Voltage (ac)

97V to 134V, 400Hz

Apply for 5 mins each test

FACF115_VABN1P

16.5.2.1c

3 Phs Voltage (ac)

97V to 134V, 400Hz

Apply for 5 mins each test

FACF115_VABN3P

16.5.2.1d

1 Phs Voltage and Frequency (ac)

100V to 122V, 370Hz to 430Hz

Apply for 5 mins each test

FACF115_VFABN1P

16.5.2.1e

3 Phs Voltage and Frequency (ac)

100V to 122V, 370Hz to 430Hz

Apply for 5 mins each test

FACF115_VFABN3P

16.5.2.2

Momentary Undervoltage (ac)

10V and 60V, 400Hz

Apply for 7 seconds each test

FACF115_VUND

16.5.2.3

Abnormal Transients (ac)

16.5.2.3.1 - Abnormal Voltage surge

148V to 180V, 400Hz

Figure 16.5 - apply at 10 sec intervals

FACF115_AVSUR

16.5.2.3.1 - Abnormal Frequency transients

0V to 115V, 320Hz to 480Hz

Figure 16.5 - apply at 10 sec intervals

FACF115_AFSUR

3.4.2 DO160 Section 16, Rev F:

3.4.2.1 Table A(CF)115:

46 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.5.1

Normal Operating Conditions (ac)

16.5.1.1b(1)

1 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 650Hz

Apply for 30 mins each test

FANF115_VFNORM1P

16.5.1.1c(1)

3 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 650Hz

Apply for 30 mins each test

FANF115_VFNORM3P

16.5.1

Emergency Operating Conditions (ac)

16.5.1.1c(2)

3 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 650Hz

Apply for 30 mins each test

FANF115_VFEMER3P

16.5.1

Normal Operating Conditions (ac)

16.5.1.2

Voltage Modulation 360Hz (ac)

Vamp = 0.18V to 1.24V, Mrate = 1Hz to 200Hz

Figure 16-1

FANF115_VMOD360

16.5.1.2

Voltage Modulation 650Hz (ac)

Vamp = 0.18V to 1.24V, Mrate = 1Hz to 200Hz

Figure 16-1

FANF115_VMOD650

16.5.1.3

Frequency Modulation 360Hz (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

FANF115_FMOD360

16.5.1.3

Frequency Modulation 650Hz (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

FANF115_FMOD650

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1 360Hz nom

Equipment with Digital Circuits

FANF115_PINTB360

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1 650Hz nom

Equipment with Digital Circuits

FANF115_PINTB650

16.5.1.4c

Momentary Power Interruptions (ac)

360Hz nom

Other Equipment

FANF115_PINTC360

16.5.1.4c

Momentary Power Interruptions (ac)

650Hz nom

Other Equipment

FANF115_PINTC650

16.5.1.4d

Momentary Power Interruptions (ac)

Table 16-2

Additional Requirement (Var Freq)

FANF115_PINTD

16.5.1.5

Normal Transients (ac)

16.5.1.5.1 - Normal Voltage Surge (ac)

160V to 70V, 360 Hz

FANF115_NVSUR360

16.5.1.5.1 - Normal Voltage Surge (ac)

160V to 70V, 650 Hz

FANF115_NVSUR650

16.5.1.6

Normal Frequency Surge (ac)

115V, 360Hz to 650Hz

FANF115_NFSUR

16.5.1.7

Voltage DC Content (ac)

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.1VDC (360Hz nom)

Apply for 30 mins each test

FANF115_DCOFS1P360

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.1VDC (650Hz nom)

Apply for 30 mins each test

FANF115_DCOFS1P650

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.1VDC (360Hz nom)

Apply for 30 mins each test

FANF115_DCOFS3P360

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.1VDC (650Hz nom)

Apply for 30 mins each test

FANF115_DCOFS3P650

16.5.1.8

Voltage Distortion (ac)

8% +2%/-0% VTHD - Clipped Sine, 360Hz

Apply for 30 mins each test

FANF115_VTHD360

16.5.1.8

Voltage Distortion (ac)

8% +2%/-0% VTHD - Clipped Sine, 650Hz

Apply for 30 mins each test

FANF115_VTHD650

16.5.2

Abnormal Operating Conditions (ac)

16.5.2.1b

1 Phs Voltage (ac)

97V to 134V, 360Hz

Apply for 5 mins each test

FANF115_VABN1P360

16.5.2.1b

1 Phs Voltage (ac)

97V to 134V, 650Hz

Apply for 5 mins each test

FANF115_VABN1P650

16.5.2.1c

3 Phs Voltage (ac)

97V to 134V, 360Hz

Apply for 5 mins each test

FANF115_VABN3P360

16.5.2.1c

3 Phs Voltage (ac)

97V to 134V, 650Hz

Apply for 5 mins each test

FANF115_VABN3P650

16.5.2.2

Momentary Undervoltage (ac)

10V and 60V, 360Hz

Apply for 7 seconds each test

FANF115_VUND360

16.5.2.2

Momentary Undervoltage (ac)

10V and 60V, 650Hz

Apply for 7 seconds each test

FANF115_VUND650

16.5.2.3

Abnormal Transients (ac)

3.4.2.2 Table A(CF)115:

Avionics Software 47

User Manual – Rev H California Instruments

16.5.2.3.1 - Abnormal Voltage surge

148V to 180V, 360Hz

Figure 16.5 - apply at 10 sec intervals

FANF115_AVSUR360

16.5.2.3.1 - Abnormal Voltage surge

148V to 180V, 650Hz

Figure 16.5 - apply at 10 sec intervals

FANF115_AVSUR650

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.5.1

Normal Operating Conditions (ac)

16.5.1.1b(1)

1 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 800Hz

Apply for 30 mins each test

FAWF115_VFNORM1P

16.5.1.1c.2(1)

3 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 800Hz

Apply for 30 mins each test

FAWF115_VFNORM3P

16.5.1

Emergency Operating Conditions (ac)

16.5.1.1c.2(2)

3 Phs Voltage and Frequency (ac)

100V to 122V, 360Hz to 800Hz

Apply for 30 mins each test

FAWF115_VFEMER3P

16.5.1

Normal Operating Conditions (ac)

16.5.1.2

Voltage Modulation 360Hz (ac)

Vamp = 0.18V to 1.24V, Mrate = 1Hz to 200Hz

Figure 16-1

FAWF115_VMOD360

16.5.1.2

Voltage Modulation 800Hz (ac)

Vamp = 0.18V to 1.24V, Mrate = 1Hz to 200Hz

Figure 16-1

FAWF115_VMOD800

16.5.1.3

Frequency Modulation 360Hz (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

FAWF115_FMOD360

16.5.1.3

Frequency Modulation 800Hz (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

FAWF115_FMOD800

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1 360Hz nom

Equipment with Digital Circuits

FAWF115_PINTB360

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1 800Hz nom

Equipment with Digital Circuits

FAWF115_PINTB800

16.5.1.4c

Momentary Power Interruptions (ac)

360Hz nom

Other Equipment

FAWF115_PINTC360

16.5.1.4c

Momentary Power Interruptions (ac)

800Hz nom

Other Equipment

FAWF115_PINTC800

16.5.1.4d

Momentary Power Interruptions (ac)

Table 16-2

Additional Requirement (Var Freq)

FAWF115_PINTD

16.5.1.5

Normal Transients (ac)

16.5.1.5.1 - Normal Voltage Surge (ac)

160V to 70V, 360 Hz

FAWF115_NVSUR360

16.5.1.5.1 - Normal Voltage Surge (ac)

160V to 70V, 800 Hz

FAWF115_NVSUR800

16.5.1.6

Normal Frequency Surge (ac)

115V, 360Hz to 800Hz

FAWF115_NFSUR

16.5.1.7

Voltage DC Content (ac)

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.1VDC (360Hz nom)

Apply for 30 mins each test

FAWF115_DCOFS1P360

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.1VDC (800Hz nom)

Apply for 30 mins each test

FAWF115_DCOFS1P800

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.1VDC (360Hz nom)

Apply for 30 mins each test

FAWF115_DCOFS3P360

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.1VDC (800Hz nom)

Apply for 30 mins each test

FAWF115_DCOFS3P800

16.5.1.8

Voltage Distortion (ac)

10% +2%/-0% VTHD - Clipped Sine, 360Hz

Apply for 30 mins each test

FAWF115_VTHD360

16.5.1.8

Voltage Distortion (ac)

10% +2%/-0% VTHD - Clipped Sine, 800Hz

Apply for 30 mins each test

FAWF115_VTHD800

16.5.2

Abnormal Operating Conditions (ac)

3.4.2.3 Table A(CF)115:

48 Avionics Software

User Manual - Rev H California Instruments

16.5.2.1b

1 Phs Voltage (ac)

97V to 134V, 360Hz

Apply for 5 mins each test

FAWF115_VABN1P360

16.5.2.1b

1 Phs Voltage (ac)

97V to 134V, 800Hz

Apply for 5 mins each test

FAWF115_VABN1P800

16.5.2.1c

3 Phs Voltage (ac)

97V to 134V, 360Hz

Apply for 5 mins each test

FAWF115_VABN3P360

16.5.2.1c

3 Phs Voltage (ac)

97V to 134V, 800Hz

Apply for 5 mins each test

FAWF115_VABN3P800

16.5.2.2

Momentary Undervoltage (ac)

10V and 60V, 360Hz

Apply for 7 seconds each test

FAWF115_VUND360

16.5.2.2

Momentary Undervoltage (ac)

10V and 60V, 800Hz

Apply for 7 seconds each test

FAWF115_VUND800

16.5.2.3

Abnormal Transients (ac)

16.5.2.3.1 - Abnormal Voltage surge

148V to 180V, 360Hz

Figure 16.5 - apply at 10 sec intervals

FAWF115_AVSUR360

16.5.2.3.1 - Abnormal Voltage surge

148V to 180V, 800Hz

Figure 16.5 - apply at 10 sec intervals

FAWF115_AVSUR800

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

22.0V to 30.3V

Apply for 30 mins each test

FADC28_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

18.0V

Apply for 30 mins each test

FADC28_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = 0.6V to 1.6V, Freq = 10Hz to 200Hz

Figure 18-2

FADC28_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

FADC28_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

FADC28_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

47V to 17V

FADC28_NVSUR

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

20.5V to 32.2V

Apply for 5 mins each test

FADC28_VABN

16.6.2.3

Momentary Undervoltage (dc)

12V

Apply for 7 seconds each test

FADC28_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4c - Abnormal Voltage Surge

46.3V

Figure 16-4 - apply at 10 sec intervals

FADC28_AVSUR

3.4.2.4 Table A(CF)115:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

Avionics Software 49

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

22.0V to 30.3V

Apply for 30 mins each test

FBDC28_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

18.0V

Apply for 30 mins each test

FBDC28_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = 1.6V, Freq = 200Hz

Figure 18-2

FBDC28_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

FBDC28_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

FBDC28_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

47V to 17V

FBDC28_NVSUR

16.6.1.5

Engine Starting Under Voltage Operation (dc)

10V min

Slew for 35 sec

FBDC28_VENG

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

20.5V to 32.2V

Apply for 5 mins each test

FBDC28_VABN

16.6.2.2

Low Voltage Conditions (dc)

0V over 10 minutes

FBDC28_LVABN

16.6.2.3

Momentary Undervoltage (dc)

12V

Apply for 7 seconds each test

FBDC28_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4d - Abnormal Voltage Surge

60VDC

Figure 16-4 - apply at 10 sec intervals

FBDC28_AVSUR

3.4.2.5 Table A(CF)115:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

50 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

22.0V to 30.3V

Apply for 30 mins each test

FZDC28_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

18.0V

Apply for 30 mins each test

FZDC28_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = 0.6V to 1.6V, Freq = 10Hz to 200Hz

Figure 18-2

FZDC28_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

FZDC28_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

FZDC28_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

50V to 12V

FZDC28_NVSUR

16.6.1.5

Engine Starting Under Voltage Operation (dc)

10V min

Slew for 35 sec

FZDC28_VENG

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

20.5V to 32.2V

Apply for 5 mins each test

FZDC28_VABN

16.6.2.3

Momentary Undervoltage (dc)

12V

Apply for 7 seconds each test

FZDC28_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4b - Abnormal Voltage Surge

80VDC

Figure 16-4 - apply at 10 sec intervals

FZDC28_AVSUR

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.5.1

Normal Operating Conditions (ac)

16.5.1.1b(1)

1 Phs Voltage and Frequency (ac)

200V to 244V, 390Hz to 410Hz

Apply for 30 mins each test

FACF230_VFNORM1P

16.5.1.1c(1)

3 Phs Voltage and Frequency (ac)

200V to 244V, 390Hz to 410Hz

Apply for 30 mins each test

FACF230_VFNORM3P

16.5.1

Emergency Operating Conditions (ac)

16.5.1.1b(2)

1 Phs Voltage and Frequency (ac)

200V to 244V, 360Hz to 440Hz

Apply for 30 mins each test

FACF230_VFEMER1P

16.5.1.1c(2)

3 Phs Voltage and Frequency (ac)

200V to 244V, 360Hz to 440Hz

Apply for 30 mins each test

FACF230_VFEMER3P

16.5.1

Normal Operating Conditions (ac)

16.5.1.2

Voltage Modulation (ac)

Vamp = 0.36V to 2.48V, Mrate = 1Hz to 200Hz

Figure 16-1

FACF230_VMOD

16.5.1.3

Frequency Modulation (ac)

Famp = 4.9 Hz to 0.2Hz, Mrate = 0.014Hz to 100Hz

Figure 16-2

FACF230_FMOD

16.5.1.4b

Momentary Power Interruptions (ac)

Table 16-1

Equipment with Digital Circuits

FACF230_PINTB

16.5.1.4c

Momentary Power Interruptions (ac)

Other Equipment

FACF230_PINTC

16.5.1.5

Normal Transients (ac)

3.4.2.6 Table A(CF)115:

3.4.2.7 Table A(CF)115:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

Avionics Software 51

User Manual – Rev H California Instruments

16.5.1.5.1 - Normal Voltage Surge (ac)

320V to 140V, 400 Hz

FACF230_NVSUR

16.5.1.5.2 - Normal Frequency Surge (ac)

230V, 350Hz to 400Hz

FACF230_NFSUR

16.5.1.7

Voltage DC Content (ac)

16.5.1.7 - 1 Phs Voltage DC Content (ac)

± 0.2VDC

Apply for 30 mins each test

FACF230_DCOFS1P

16.5.1.7 - 3 Phs Voltage DC Content (ac)

± 0.2VDC

Apply for 30 mins each test

FACF230_DCOFS3P

16.5.1.8

Voltage Distortion (ac)

8% +2%/-0% VTHD - Clipped Sine, 400Hz

Apply for 30 mins each test

FACF230_VTHD

16.5.2

Abnormal Operating Conditions (ac)

16.5.2.1b

1 Phs Voltage (ac)

194V to 268V, 400Hz

Apply for 5 mins each test

FACF230_VABN1P

16.5.2.1c

3 Phs Voltage (ac)

194V to 268V, 400Hz

Apply for 5 mins each test

FACF230_VABN3P

16.5.2.1d

1 Phs Voltage and Frequency (ac)

200V to 244V, 370Hz to 430Hz

Apply for 5 mins each test

FACF230_VFABN1P

16.5.2.1e

3 Phs Voltage and Frequency (ac)

200V to 244V, 370Hz to 430Hz

Apply for 5 mins each test

FACF230_VFABN3P

16.5.2.2

Momentary Undervoltage (ac)

20V and 120V, 400Hz

Apply for 7 seconds each test

FACF230_VUND

16.5.2.3

Abnormal Transients (ac)

16.5.2.3.1 - Abnormal Voltage surge

296V to 360V, 400Hz

Figure 16.5 - apply at 10 sec intervals

FACF230_AVSUR

16.5.2.3.1 - Abnormal Frequency transients

0V to 230V, 320Hz to 480Hz

Figure 16.5 - apply at 10 sec intervals

FACF230_AFSUR

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

11.0V to 15.2V

Apply for 30 mins each test

FADC14_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

9.0V

Apply for 30 mins each test

FADC14_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = 0.3V to .8V, Freq = 10Hz to 200Hz

Figure 18-2

FADC14_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

FADC14_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

FADC14_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

23.5V to 8.5V

FADC14_NVSUR

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

10.3V to 16.1V

Apply for 5 mins each test

FADC14_VABN

16.6.2.3

Momentary Undervoltage (dc)

6V

Apply for 7 seconds each test

FADC14_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4c - Abnormal Voltage Surge

23.2V

Figure 16-4 - apply at 10 sec intervals

FADC14_AVSUR

3.4.2.8 Table A(CF)115:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

52 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

11.0V to 15.2V

Apply for 30 mins each test

FBDC14_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

9.0V

Apply for 30 mins each test

FBDC14_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = .8V, Freq = 200Hz

Figure 18-2

FBDC14_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

FBDC14_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

FBDC14_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

23.5V to 8.5V

FBDC14_NVSUR

16.6.1.5

Engine Starting Under Voltage Operation (dc)

5V min

Slew for 35 sec

FBDC14_VENG

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

10.3V to 16.1V

Apply for 5 mins each test

FBDC14_VABN

16.6.2.2

Low Voltage Conditions (dc)

0V over 10 minutes

FBDC14_LVABN

16.6.2.3

Momentary Undervoltage (dc)

6V

Apply for 7 seconds each test

FBDC14_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4d - Abnormal Voltage Surge

30VDC

Figure 16-4 - apply at 10 sec intervals

FBDC14_AVSUR

3.4.2.9 Table A(CF)115:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

Avionics Software 53

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

16.6.1

Normal Operating Conditions (dc)

16.6.1.1b

Voltage (Average Value dc)

11.0V to 15.2V

Apply for 30 mins each test

FZDC14_VAVG

16.6.1

Emergency Operating Conditions (dc)

16.6.1.1b(3)

Voltage (Average Value dc)

9.0V

Apply for 30 mins each test

FZDC14_VAVGEMER

16.6.1

Normal Operating Conditions (dc)

16.6.1.21

Ripple Voltage (dc)

Vp-p = 0.3V to .8V, Freq = 10Hz to 200Hz

Figure 18-2

FZDC14_VRIP

16.6.1.3b

Momentary Power Interruptions (dc)

Table 16-3

Equipment with Digital Circuits

FZDC14_PINTB

16.6.1.3c

Momentary Power Interruptions (dc)

Other Equipment

FZDC14_PINTC

16.6.1.4

Normal Transients (dc)

16.6.1.4b - Normal Voltage Surge (dc)

25V to 6V

FZDC14_NVSUR

16.6.1.5

Engine Starting Under Voltage Operation (dc)

5V min

Slew for 35 sec

FZDC14_VENG

16.6.2

Abnormal Operating Conditions (dc)

16.6.2.1

Voltage Steady State (dc)

10.3V to 16.1V

Apply for 5 mins each test

FZDC14_VABN

16.6.2.3

Momentary Undervoltage (dc)

6V

Apply for 7 seconds each test

FZDC14_VUND

16.6.2.4

Abnormal Transients (ac)

16.6.2.4b - Abnormal Voltage Surge

40VDC

Figure 16-4 - apply at 10 sec intervals

FZDC14_AVSUR

3.4.2.10 Table A(CF)115:

1

For more comprehensive DC Ripple tests, refer to section 3.3.

54 Avionics Software

User Manual - Rev H California Instruments

No.

Description

115

VAC

235

VAC

No.

28 VDC Tests Description

Type

I DC

Type II DC

Type

III DC

Type

IV DC

Type V DC

Type

VI DC

1.1

Individual Phase Voltage



5.1-4

DC Voltage

  



1.2

Average of Three Phase Voltages



5.5.2

Voltage Ripple

P P P

P

1.3

Phase Displacement



6.1

Voltage Transients

  



1.4

Phase Voltage Unbalance



6.2

Voltage Spikes

X X X

X

1.5

Voltage Modulation



6.3

Multiple Stroke Power Interruptions

  



1.6.1

Total Harmonic Content

P P 7.1-4

Abnormal DC Voltage

  



1.6.2

Individual Harmonic Content

X X 8.1

Abnormal Voltage Transients

  



1.6.3

DC Content

P P Supp

Supplementary

  



4 Option –B787: Boeing 787B3-0147 Rev A, B, and C Tests

The -B787 option supports Boeing 787B3-0147 revs A, B, and C, Section 3.3, voltage and frequency immunity tests in either of the AC or DC modes (if available).

The –B787 option rev C (currently the most recent revision) is based on the Boeing 787 Electrical Power Quality and Design Requirements Document: Section 3.3 – Electrical Power Characteristics dated October 6 2006.

Future revisions of the Boeing 787B3-0147 directive may be issued over time and updates may be made available to cover any changes in test levels, durations, procedures etc. Furthermore, the –787 option is completely data file driven to allow a large degree of customization by the end-user if needed so many changes can be supported without the need for software updates.

This section of the manual explains the limitations of this test option, the use of special features unique to this option, and gives a complete layout of all tests performed by this option.

This manual is not intended to elaborate on the intent or purpose of the immunity tests and the expected behavior of the EUT as described in the Boeing 787B3-0147 documents. It is assumed that the end-user is familiar with the content of the Boeing 787B3-0147 test standard.

4.1 Test Coverage

The comprehensiveness of the tests that can be performed with the –787 option is determined primarily by the capabilities of the power source used. Tests that are outside the hardware capabilities of the power source used will not be enabled and cannot be selected. For these tests, additional equipment may be required as indicated.

4.1.1 MX Series –B787 Option Limitations

The extent of coverage of the –787 option as implemented on the MX Series platform is shown in the table below. Tests marked with an „x‟ generally require additional hardware to be used. Tests marked

„N/A‟ are not applicable to the corresponding table. Tests marked with a „‟ are covered by the –787 option. Tests marked with a „P‟ require arbitrary waveform capability, which is available on Pi models

or base models with the –ADV option only. Note: The MX15 Series power sources are single phase output only and therefore all three phase tests are not available on the MX15.

Avionics Software 55

User Manual – Rev H California Instruments

No.

Description

115

VAC

235

VAC

No.

28 VDC Tests Description

Type

I DC

Type II DC

Type

III DC

Type

IV DC

Type V DC

Type

VI DC

Transient Tests

1.8

Frequency Modulation



9.1.1

13.1

Steady State Voltage



2.1

Voltage Transients



9.1.2

Steady State Voltage

 N/A

2.2

Voltage Spikes

X X 9.2.1

Differential Mode Voltage Ripple

TBD

N/A

2.3.1

Maximum Ramp Rate



9.2.2

13.3

Differential Mode Ripple Components

X X 2.3.2

Frequency Transients



9.3.1

13.2

Common Mode Voltage

TBD



2.4

Multiple Stroke Power Interruptions



9.3.2

Common Mode Frequency

X

N/A

3.1

Abnormal Individual Phase Voltage



10.1

14.1

Voltage Transients



3.2

Abnormal Average of Three Phase Voltages



11.1

15.1

Abnormal Steady State Voltage



4.1

Abnormal Voltage Transients



11.2.1

Abnormal Differential Mode Ripple

X

N/A

4.2.1

Abnormal Maximum Ramp Rate



12.1

16.1

Abnormal Voltage Transients



4.2.2

Abnormal Frequency Transients



4.3

Abnormal DC Content

P P

Supp

Supplementary Transient Tests



Table 4-1: -B787 Option MX Test Coverage

Note that some AC tests requiring more than 300Vrms output will require the –HV (400 Vrms) optional output range.

56 Avionics Software

User Manual - Rev H California Instruments

Vnom

Test

Std requirement

Actual setting

Reason

115VAC

1.5.1

115 +/- .26 V mod

115 +/- .3 V mod

Resolution

115VAC

1.5.1

115 +/- 1.77 V mod

115 +/- 1.8 V mod

Resolution

115VAC

1.6.2

Audio Frequencies

Test Skipped

Requires Audio Generator

115VAC

2.2

Voltage Spike

Test Skipped

Requires additional equipment

115VAC

2.4

450us dropouts

1ms dropouts

Resolution

115VAC

4.2.2

885 Hz

885Hz

Requires HF option

235VAC

1.5.1

230 +/- .52 V mod

230 +/- .6 V mod

Resolution

235VAC

1.5.1

230 +/- 3.54 V mod

230 +/- 3.6 V mod

Resolution

235VAC

1.6.2

Audio Frequencies

Test Skipped

Requires Audio Generator

235VAC

2.2

Voltage Spike

Test Skipped

Requires additional equipment

235VAC

2.4

450us dropouts

1ms dropouts

Resolution

235VAC

4.1

315 V

Requires HV option

235VAC

4.2.2

885 Hz

885Hz

Requires HF option

28VDC

5.5.2

Voltage Ripple

Tests up to 5kHz only

Hardware Limit

28VDC

6.1

350us dropout

1ms dropout

Resolution

28VDC

6.2

Voltage Spikes

Test Skipped

Requires additional equipment

28VDC

6.3

450us dropouts

1ms dropout

Resolution

No.

Description

115

VAC

235

VAC

No.

28 VDC Tests Description

Type

I DC

Type II DC

Type

III DC

Type

IV DC

Type V DC

Type

VI DC

1.1

Individual Phase Voltage



C

5.1-4

DC Voltage

  



1.2

Average of Three Phase Voltages



C

5.5.2

Voltage Ripple

I, P

1.3

Phase Displacement



C

6.1

Voltage Transients

  



1.4

Phase Voltage Unbalance



C

6.2

Voltage Spikes

X X X

X

1.5

Voltage Modulation



C

6.3

Multiple Stroke Power Interruptions

  



1.6.1

Total Harmonic Content

P

C, P

7.1-4

Abnormal DC Voltage

  



1.6.2

Individual Harmonic Content

X X 8.1

Abnormal Voltage Transients

  



1.6.3

DC Content

P

C, P

Supp

Supplementary Transient Tests

  



4.1.1.1 Specific Test Limitations and Discrepancies

While every effort has been made to provide comprehensive coverage of the Boeing 787B3-0147 tests, some limitations apply, largely due to hardware limitations of the MX power source such as available programming resolution or rounding. The following table lists specific implementation issues

by test number. The deviation from the standard requirement is shown in the “Actual setting” column.

The reason for the deviation is shown in the last column.

4.1.2 i/iX Series –B787 Option Limitations

The extent of coverage of the –787 option as implemented on the iX Series platform is shown in the

table below. Tests marked with an „x‟ generally require additional hardware to be used. Tests marked

„N/A‟ are not applicable to the corresponding table. Tests marked with a „‟ are covered by the –787

option. Tests marked with a „P‟ require arbitrary waveform capability, which is available on iX models

only. Tests marked with a „C‟ are available on the Compact iX products only. Tests marked with an “I” are available on the i/iX products only.

Avionics Software 57

User Manual – Rev H California Instruments

No.

Description

115

VAC

235

VAC

No.

28 VDC Tests Description

Type

I DC

Type II DC

Type

III DC

Type

IV DC

Type V DC

Type

VI DC

1.8

Frequency Modulation



C

9.1.1

13.1

Steady State Voltage



2.1

Voltage Transients



C

9.1.2

Steady State Voltage

 N/A

2.2

Voltage Spikes

X X 9.2.1

Differential Mode Voltage Ripple

TBD

N/A

2.3.1

Maximum Ramp Rate



C

9.2.2

13.3

Differential Mode Ripple Components

X X 2.3.2

Frequency Transients



C

9.3.1

13.2

Common Mode Voltage

TBD



2.4

Multiple Stroke Power Interruptions



C

9.3.2

Common Mode Frequency

X

N/A

3.1

Abnormal Individual Phase Voltage



C

10.1

14.1

Voltage Transients



3.2

Abnormal Average of Three Phase Voltages



C

11.1

15.1

Abnormal Steady State Voltage



4.1

Abnormal Voltage Transients



C

11.2.1

Abnormal Differential Mode Ripple

X

N/A

4.2.1

Abnormal Maximum Ramp Rate



C

12.1

16.1

Abnormal Voltage Transients



4.2.2

Abnormal Frequency Transients

C C

4.3

Abnormal DC Content

P

C, P

Supp

Supplementary Transient Tests



C

Table 4-2: -B787 Option i/iX Test Coverage

Note that the iX Series does not support 800 Hz testing at more than 150Vrms. Consequently, all 230V nominal tests for A(NF) and A(WF) categories are not supported. Some A(CF) tests requiring more than 300V output are also unavailable due to hardware limitations of the iX Series power source.

58 Avionics Software

User Manual - Rev H California Instruments

Vnom

Test

Std requirement

Actual setting

Reason

115VAC

1.5.1

115 +/- .26 V mod

115 +/- .3 V mod

Resolution

115VAC

1.5.1

115 +/- 1.77 V mod

115 +/- 1.8 V mod

Resolution

115VAC

1.6.2

Audio Frequencies

Test Skipped

Requires Audio Generator

115VAC

2.2

Voltage Spike

Test Skipped

Requires additional equipment

115VAC

2.4

450us dropouts

1ms dropouts

Resolution

235VAC

1.5.1

230 +/- .52 V mod

230 +/- .6 V mod

Resolution

235VAC

1.5.1

230 +/- 3.54 V mod

230 +/- 3.6 V mod

Resolution

235VAC

1.6.2

Audio Frequencies

Test Skipped

Requires Audio Generator

235VAC

2.2

Voltage Spike

Test Skipped

Requires additional equipment

235VAC

2.4

450us dropouts

1ms dropouts

Resolution

235VAC

4.1

315 V

300 V

Voltage limit

28VDC

5.5.2

Voltage Ripple

Test Skipped

Requires additional equipment

28VDC

6.1

350us dropout

1ms dropout

Resolution

28VDC

6.2

Voltage Spikes

Test Skipped

Requires additional equipment

28VDC

6.3

450us dropout

1ms dropout

Resolution

+/- 270VDC

All

Requires +/-300VDC+

+/- 300VDC+

Requires Series II controller (iX only)

4.1.2.1 Specific Test Limitations and Discrepancies

While every effort has been made to provide comprehensive coverage of the Boeing 787B3-0147 tests, some limitations apply, largely due to hardware limitations of the iX power source such as available programming resolution or rounding. The following table lists specific implementation issues by test number. The deviation from the standard requirement is shown in the “Actual setting” column. The reason for the deviation is shown in the last column.

Avionics Software 59

User Manual – Rev H California Instruments

No.

Description

115

VAC

235

VAC

No.

Description

115 VAC

235 VAC

1.1

Individual Phase Voltage



2.2

Voltage Spikes

X X 1.2

Average of Three Phase Voltages



2.3.1

Frequency Transients



1.3

Phase Displacement



2.4

Multiple Stroke Power Interruptions



1.4

Phase Voltage Unbalance



3.1

Abnormal Individual Phase Voltage



1.5.1

Voltage Modulation



3.2

Abnormal Average of Three Phase Voltages



1.6.1

Total Harmonic Content

P P 4.1

Abnormal Voltage Transients



1.6.2

Individual Harmonic Content

X X 4.2.1

Abnormal Frequency Transients



1.6.3

DC Content

X X 4.2.2

Abnormal Frequency Transients



1.8

Frequency Modulation



4.3

DC Content

X

2.1

Voltage Transients



Supp

Supplementary Transient Tests



4.1.3 Lx/Ls –B787 Option Series Limitations

The extent of coverage of the –787 option as implemented on the Lx/Ls Series platform is shown in the table below. Tests marked with an „x‟ generally require additional hardware to be used. Tests

marked „N/A‟ are not applicable to the corresponding table. Tests marked with a „‟ are covered by

the –787 option. Tests marked with a „P‟ require arbitrary waveform capability, which is available on Lx models or Ls models with the –ADV option only. Note that some voltage surge tests may require optional output voltage ranges on the Lx/Ls and may not be supported on the standard voltage range.

DC tests are NOT supported by the Lx/Ls Series

60 Avionics Software

Table 4-3: -B787 Option Ls/Lx Test Coverage

User Manual - Rev H California Instruments

Vnom

Test

Std requirement

Actual setting

Reason

115VAC

1.5.1

115 +/- .26 V mod

115 +/- .3 V mod

Resolution

115VAC

1.5.1

115 +/- 1.77 V mod

115 +/- 1.8 V mod

Resolution

115VAC

1.6.2

Audio Frequencies

Test Skipped

Requires Audio Generator

115VAC

2.2

Voltage Spike

Test Skipped

Requires additional equipment

115VAC

2.4

450us dropouts

1ms dropouts

Resolution

235VAC

1.5.1

230 +/- .52 V mod

230 +/- .6 V mod

Resolution

235VAC

1.5.1

230 +/- 3.54 V mod

230 +/- 3.6 V mod

Resolution

235VAC

1.6.2

Audio Frequencies

Test Skipped

Requires Audio Generator

235VAC

2.2

Voltage Spike

Test Skipped

Requires additional equipment

235VAC

2.4

450us dropouts

1ms dropouts

Resolution

235VAC

4.1

315 V

Requires EHV option

4.1.3.1 Specific Test Limitations and Discrepancies

While every effort has been made to provide comprehensive coverage of the Boeing 787B3-0147 tests, some limitations apply, largely due to hardware limitations of the Lx power source such as available programming resolution or rounding. The following table lists specific implementation issues by test number. The deviation from the standard requirement is shown in the “Actual setting” column. The reason for the deviation is shown in the last column.

DC tests are NOT supported by the Lx/Ls Series

Avionics Software 61

User Manual – Rev H California Instruments

4.2 –B787 Power Groups

The following twelve power groups are covered in the Boeing 787B3-0147 directive: Category reference:

- For ac equipment: 115V L-N, 235V L-N

- For dc equipment: Type 1 through Type 5, and Type 6 for Rev B and C

Definitions: AC Power Sources: Variable frequency primary AC power will be supplied by either a 230V L-N

(400V L-L) or 115V L-N (200V L-L) nominal, 360-800 Hz nominal, three-phase, four wire, Y (wye) connected system. The neutral of the system is connected to the current return network and the current return network is considered to be the fourth wire. Phase rotation is in the order A, B, C. The current return network is also referred to as the airplane electrical power return and grounding protection path.

Variable frequency single-phase AC power is obtained by connection to any one line and the current return network.

This system includes multiple, engine driven power-generation channels. The output characteristics of these individual electric power channels will remain within the limits specified herein, but will not necessarily be identical.

Ground Handling Equipment: Ground Handling Equipment has a constant frequency and these tests are kept separate from the variable frequency AC tests.

Type I DC Power: Type I DC power will be supplied by a 28 volt (nominal), two-wire, Transformer Rectifier Unit (TRU) powered by the primary AC system, without battery backup. The negative terminal of the TRU is connected to the current return network and the current return network is considered to be the second wire.

Type II DC Power: Type II DC power normally will be supplied by the Type I DC power sources. A 24 volt (nominal) storage battery system will be an alternative backup source of Type II DC power.

Type III DC Power: Type III DC power will be supplied by a 24 volt (nominal) storage battery system with backup by a battery charger.

Type IV DC Power: Type IV DC power will normally be supplied by a 28 volt (nominal) converter regulator (Power Supply Assembly) powered by dedicated Permanent Magnet Generators (PMGs) on one or more engines. Backup sources of power for the converter regulator include: Type I DC power, the standby system main battery and the RAM air turbine generator.

Type IV DC power is provided exclusively for the Fly-By-Wire flight control system and dependent equipment.

Type V High Voltage DC Power: Type V High Voltage DC (HVDC) power will be a +/-270 volt (nominal) system supplied by a two-wire, Auto-Transformer Rectifier Unit (ATRU) system powered by a variable frequency 230V L-N (400V L-L) nominal primary AC system.

The voltage of the two output terminals of this system with respect to ground will be +270 and –270 volts respectively. All +/-270 volt equipment shall be connected between the +270 and –270 volt terminals.

Note: The Type V HVDC system nominal voltage has been initially defined at +/-270V. The nominal voltage may change by as much as +/-20V.

Type VI High Voltage DC Power: Type VI DC power will be a +/-130 volt (nominal) system supplied by a two-wire, Electric Brake Power Supply Unit (EBPSU) system powered by either the Type I DC or Type III DC power system.

62 Avionics Software

User Manual - Rev H California Instruments

The voltage of the two output terminals of this system with respect to the current return network will be +130 and -130 respectively. All +/-130 volt equipment shall be connected between the +130 and -130 volt terminals.

Type VI DC power is provided exclusively for the landing gear electric braking system.

Avionics Software 63

User Manual – Rev H California Instruments

4.3 –B787 Option Special Features

DC ripple tests for 28VDC EUT‟s are provided through a separate control screen. This is required to

extend the range of the ripple frequency to 5000 Hz. The actual requirement for 787 Rev C is testing up to 150 KHz ripple. This is out of the available range of the power source. To test to the full 150 KHz range, an external audio generator and coupling transformer as outlined in 787B3-0147, Figure 18 is required.

The B787 DC Ripple test screen is available from the main screen, Applications, Boeing, DC Ripple Test menu. Once selected, the DC ripple test control screen is modal and must be closed before any other tests can be run. Opening this screen requires several seconds as the power source is being set up to perform the DC ripple tests. This screen also places the power source in AC+DC mode. Note: This feature is not available on the Compact iX or Ls/Lx Series power sources.

Available test settings are phase/output selection. For single-phase systems, only phase A can be selected. The test pattern is fixed per section B.5.5.2 with a ripple frequency range from 16 Hz to 5000 Hz per Figure 7. The frequency slew rate is 30 minutes for each decade covered or one hour and 15 minutes total. Tests can be aborted sooner if needed.

4.4 Test Tables

The tables shown on the next few pages list the test sections covered by the –787 option. Where relevant, the numbering used matches that of the Boeing 787B3-0147 document. Test tables are listed by power group

.

Figure 4-1: B787 DC Ripple Test Window.

64 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

1.0

Normal AC Steady State

1.1

Individual Phase Voltage

100.0 to 122.0 Volts RMS

30 mins, 800Hz and 360Hz

LVAC-11

1.2

Average of Three-Phase Voltages

101.5 to 120.5 Volts RMS

30 mins, 800Hz and 360Hz

LVAC-12

1.3

Phase Displacement

120.0 +/- 4.0°

No specified test

1.4

Phase Voltage Unbalance

Max. 6.0 Volts RMS

Apply each test 30 mins

LVAC-14

1.5

AC Voltage Modulation

1.5.1

Maximum Amplitude

5.0 Volts Peak-to-Valley

Follows specification Figure 1

LVAC-15

1.5.2

Frequency Components

Per Figure 1

Figure only, not a test. (Refer to spec)

1.6

Voltage Waveform

1.6.1

Total Harmonic Content

Max. 10% of Fundamental

30 mins each test

LVAC-16-1

1.6.2

Individual Harmonic Content

Max. 8% of Fundamental

Requires audio generator

1.6.3

DC Content

+/-0.20 Volts (after first cycle)

30 mins each test

LVAC-16-3

1.6.4

Crest Factor

1.41 +/- 0.15

No specified test

1.7

Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.1 and 1.2

1.8

Frequency Modulation

Applies to Ground Handling Equip only

2.0

Normal AC Transients

2.1

Voltage Transients

50ms Dropouts

800Hz and 360Hz

LVAC-21-1

2.1

Voltage Transients

Voltage Surge/Sag

3 times each, 800Hz and 360Hz

LVAC-21-2

2.1

Voltage Transients

Per Table 3.3.2-6

2 times each

LVAC-21-3

2.2

Voltage Spikes

Per Figure 10

Requires additional equipment

2.3.1

Frequency Variations - Max Ramp Rate

100Hz/s up, 200Hz/s down

3 times each, 360Hz nominal

LVAC-23

2.3.2

Frequency Variations - Frequency Transients

Applies to Ground Handling Equip only

2.4

Multiple Stroke Power Interruptions

450us interrupts (actual 1ms)

LVAC-24

3.0

Abnormal AC Steady State

3.1

Individual Phase Voltage

90.0 to 134.0 Volts RMS

Single Phase Unit Test

LVAC-31

3.2

Average of Three-Phase Voltages

91.5 to 132.5 Volts RMS

5 mins each test

LVAC-32-1

3.2

Average of Three-Phase Voltages

90.0 to 134.0 Volts RMS

Three Phase Unit Test

LVAC-32-2

3.3

Abnormal Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.7

4.4.1 Rev C:

4.4.1.1 115VAC:

Avionics Software 65

User Manual – Rev H California Instruments

4.0

Abnormal AC Transients

4.1

Voltage Transients

Per Figure 5A

Apply each transient 3x with 10s interval

LVAC-41

4.2

Frequency Variations

4.2.1

Maximum Ramp Rate

120Hz/s up, 400Hz/s down

3 times each, 360Hz nominal

LVAC-42-1

4.2.2

Frequency Transients

350 to 885 Hz

3 times each, 400Hz nominal

LVAC-42-2

4.3

DC Content

+/- 55VDC offset

800Hz and 360Hz

LVAC-43

SUPP

Supplementary Transient Test Requirements

Tests 1-7, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 8-14, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 15-20, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 21-27, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-4

SUPP

Supplementary Transient Test Requirements

Tests 28-34, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-5

SUPP

Supplementary Transient Test Requirements

Tests 35-40, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-6

SUPP

Supplementary Transient Test Requirements

Tests 41-47, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-7

SUPP

Supplementary Transient Test Requirements

Tests 48-53, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-8

SUPP

Supplementary Transient Test Requirements

Tests 54-62, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-9

SUPP

Supplementary Transient Test Requirements

Tests 63-74, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-10

SUPP

Supplementary Transient Test Requirements

Tests 1-6 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

LSUPP-11

SUPP

Supplementary Transient Test Requirements

Tests 7-12 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

LSUPP-12

SUPP

Supplementary Transient Test Requirements

Tests 13-18 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

LSUPP-13

SUPP

Supplementary Transient Test Requirements

Test 19 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

LSUPP-14

66 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

1.0

Normal AC Steady State

1.1

Individual Phase Voltage

100.0 to 122.0 Volts RMS

30 mins, 441Hz and 360Hz

GHLVAC-11

1.2

Average of Three-Phase Voltages

101.5 to 120.5 Volts RMS

30 mins, 441Hz and 360Hz

GHLVAC-12

1.3

Phase Displacement

120.0 +/- 4.0°

No specified test

1.4

Phase Voltage Unbalance

Max. 6.0 Volts RMS

Apply each test 30 mins

GHLVAC-14

1.5

AC Voltage Modulation

1.5.1

Maximum Amplitude

5.0 Volts Peak-to-Valley

Follows specification Figure 1

GHLVAC-15

1.5.2

Frequency Components

Per Figure 1

Figure only, not a test. (Refer to spec)

1.6

Voltage Waveform

1.6.1

Total Harmonic Content

Max. 10% of Fundamental

30 mins each test

GHLVAC-16-1

1.6.2

Individual Harmonic Content

Max. 8% of Fundamental

Requires audio generator

1.6.3

DC Content

+/-0.20 Volts (after first cycle)

30 mins each test

GHLVAC-16-3

1.6.4

Crest Factor

1.41 +/- 0.15

No specified test

1.7

Steady State Frequency (see Designer Notes)

360 to 441 Hz

Requirement fulfilled in 1.1 and 1.2

1.8

Frequency Modulation

Applies to Ground Handling Equip only

GHLVAC-18

2.0

Normal AC Transients

2.1

Voltage Transients

50ms Dropouts

441Hz and 360Hz

GHLVAC-21-1

2.1

Voltage Transients

Voltage Surge/Sag

3 times each, 441Hz and 360Hz

GHLVAC-21-2

2.1

Voltage Transients

Per Table 3.3.2-6

2 times each

GHLVAC-21-3

2.2

Voltage Spikes

Per Figure 10

Requires additional equipment

2.3.1

Frequency Variations - Max Ramp Rate

100Hz/s up, 200Hz/s down

N/A for GHE

2.3.2

Frequency Variations - Frequency Transients

Applies to Ground Handling Equip only

GHLVAC-23

2.4

Multiple Stroke Power Interruptions

450us interrupts (actual 1ms)

GHLVAC-24

3.0

Abnormal AC Steady State

3.1

Individual Phase Voltage

90.0 to 134.0 Volts RMS

Single Phase Unit Test

GHLVAC-31

3.2

Average of Three-Phase Voltages

91.5 to 132.5 Volts RMS

5 mins each test

GHLVAC-32-1

3.2

Average of Three-Phase Voltages

90.0 to 134.0 Volts RMS

Three Phase Unit Test

GHLVAC-32-2

3.3

Abnormal Steady State Frequency (see Designer Notes)

360 to 441 Hz

Requirement fulfilled in 1.7

4.0

Abnormal AC Transients

4.1

Voltage Transients

Per Figure 5A

Apply each transient 3x with 10s interval

GHLVAC-41

4.2

Frequency Transients

4.4.1.2 115VAC for Ground Handling Equipment:

Avionics Software 67

User Manual – Rev H California Instruments

4.2.1

Maximum Ramp Rate

120Hz/s up, 400Hz/s down

N/A for GHE

4.2.2

Frequency Transients

350 to 480 Hz

3 times each, 400Hz nominal

GHLVAC-42-2

4.3

DC Content

+/- 55VDC offset

441Hz and 360Hz

GHLVAC-43

SUPP

Supplementary Transient Test Requirements

Tests 1-10, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 11-20, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 21-30, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 31-40, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-4

SUPP

Supplementary Transient Test Requirements

Tests 41-50, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-5

SUPP

Supplementary Transient Test Requirements

Tests 51-62, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-6

SUPP

Supplementary Transient Test Requirements

Tests 63-74, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-7

SUPP

Supplementary Transient Test Requirements

Tests 1-11 Table 3.3.2-3B

Tests performed at 360 and 441 Hz

GHLSUPP-8

SUPP

Supplementary Transient Test Requirements

Tests 12-19 Table 3.3.2-3B

Tests performed at 360 and 441 Hz

GHLSUPP-9

68 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

1.0

Normal AC Steady State

1.1

Individual Phase Voltage

190.0 to 244.0 Volts RMS

30 mins, 800Hz and 360Hz

HVAC-11

1.2

Average of Three-Phase Voltages

193.0 to 241.0 Volts RMS

30 mins, 800Hz and 360Hz

HVAC-12

1.3

Phase Displacement

120.0 +/- 4.0°

No specified test

1.4

Phase Voltage Unbalance

Max. 12.0 Volts RMS

Apply each test 30 mins

HVAC-14

1.5

AC Voltage Modulation

1.5.1

Maximum Amplitude

10.0 Volts Peak-to-Valley

Follows specification Figure 1

HVAC-15

1.5.2

Frequency Components

Per Figure 1

Figure only, not a test. (Refer to spec)

1.6

Voltage Waveform

1.6.1

Total Harmonic Content

Max. 10% of Fundamental

30 mins each test

HVAC-16-1

1.6.2

Individual Harmonic Content

Max. 8% of Fundamental

Requires audio generator

1.6.3

DC Content

+/-0.20 Volts (after first cycle)

30 mins each test

HVAC-16-2

1.6.4

Crest Factor

1.41 +/- 0.15

No specified test

1.7

Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.1 and 1.2

1.8

Frequency Modulation

Applies to Ground Handling Equip only

2.0

Normal AC Transients

2.1

Voltage Transients

50ms Dropouts

800Hz and 360Hz

HVAC-21-1

2.1

Voltage Transients

Voltage Surge/Sag

3 times each, 800Hz and 360Hz

HVAC-21-2

2.1

Voltage Transients

Per Table 3.3.2-6

2 times each

HVAC-21-3

2.2

Voltage Spikes

Per Figure 10

Requires additional equipment

2.3.1

Frequency Variations - Max Ramp Rate

100Hz/s up, 200Hz/s down

3 times each, 360Hz nominal

HVAC-23

2.3.2

Frequency Variations - Frequency Transients

Applies to Ground Handling Equip only

3.0

Abnormal AC Steady State

3.1

Individual Phase Voltage

190.0 to 268.0 Volts RMS

Single Phase Unit Test

HVAC-31-1

3.1

Average of Three-Phase Voltages

193.0 to 265.0 Volts RMS

5 mins each test

HVAC-31-2

3.2

Average of Three-Phase Voltages

190.0 to 268.0 Volts RMS

Three Phase Unit Test

HVAC-32

3.3

Abnormal Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.7

4.0

Abnormal AC Transients

4.1

Voltage Transients

Per Figure 5A

Apply each transient 3x with 10s interval

HVAC-41

4.2

Frequency Variations

4.4.1.3 235VAC:

Avionics Software 69

User Manual – Rev H California Instruments

4.2.1

Maximum Ramp Rate

120Hz/s up, 400Hz/s down

3 times each, 360Hz nominal

HVAC-42-1

4.2.2

Frequency Transients

350 to 885 Hz

3 times each, 400Hz nominal

HVAC-42-2

4.3

DC Content

+/- 15VDC offset

800Hz and 360Hz

HVAC-43

SUPP

Supplementary Transient Test Requirements

Tests 1-7, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 8-14, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 15-20, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 21-27, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-4

SUPP

Supplementary Transient Test Requirements

Tests 28-34, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-5

SUPP

Supplementary Transient Test Requirements

Tests 35-40, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-6

SUPP

Supplementary Transient Test Requirements

Tests 41-47, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-7

SUPP

Supplementary Transient Test Requirements

Tests 48-53, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-8

SUPP

Supplementary Transient Test Requirements

Tests 54-62, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-9

SUPP

Supplementary Transient Test Requirements

Tests 63-74, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-10

SUPP

Supplementary Transient Test Requirements

Tests 1-6 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

HSUPP-11

SUPP

Supplementary Transient Test Requirements

Tests 7-12 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

HSUPP-12

SUPP

Supplementary Transient Test Requirements

Tests 13-18 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

HSUPP-13

SUPP

Supplementary Transient Test Requirements

Test 19 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

HSUPP-14

70 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

1.0

Normal AC Steady State

1.1

Individual Phase Voltage

190.0 to 244.0 Volts RMS

30 mins, 441Hz and 360Hz

GHHVAC-11

1.2

Average of Three-Phase Voltages

193.0 to 241.0 Volts RMS

30 mins, 441Hz and 360Hz

GHHVAC-12

1.3

Phase Displacement

120.0 +/- 4.0°

No specified test

1.4

Phase Voltage Unbalance

Max. 12.0 Volts RMS

Apply each test 30 mins

GHHVAC-14

1.5

AC Voltage Modulation

1.5.1

Maximum Amplitude

10.0 Volts Peak-to-Valley

Follows specification Figure 1

GHHVAC-15

1.5.2

Frequency Components

Per Figure 1

Figure only, not a test. (Refer to spec)

1.6

Voltage Waveform

1.6.1

Total Harmonic Content

Max. 10% of Fundamental

30 mins each test

GHHVAC-16-1

1.6.2

Individual Harmonic Content

Max. 8% of Fundamental

Requires audio generator

1.6.3

DC Content

+/-0.20 Volts (after first cycle)

30 mins each test

GHHVAC-16-3

1.6.4

Crest Factor

1.41 +/- 0.15

No specified test

1.7

Steady State Frequency (see Designer Notes)

360 to 441 Hz

Requirement fulfilled in 1.1 and 1.2

1.8

Frequency Modulation

Applies to Ground Handling Equip only

2.0

Normal AC Transients

2.1

Voltage Transients

50ms Dropouts

441Hz and 360Hz

GHHVAC-21-1

2.1

Voltage Transients

Voltage Surge/Sag

3 times each, 441Hz and 360Hz

GHHVAC-21-2

2.1

Voltage Transients

Per Table 3.3.2-6

2 times each

GHHVAC-21-3

2.2

Voltage Spikes

Per Figure 10

Requires additional equipment

2.3.1

Frequency Variations - Max Ramp Rate

100Hz/s up, 200Hz/s down

N/A for GHE

2.3.2

Frequency Variations - Frequency Transients

Applies to Ground Handling Equip only

GHHVAC-23

3.0

Abnormal AC Steady State

3.1

Individual Phase Voltage

190.0 to 268.0 Volts RMS

Single Phase Unit Test

GHHVAC-31

3.2

Average of Three-Phase Voltages

193.0 to 265.0 Volts RMS

5 mins each test

GHHVAC-32-1

3.2

Average of Three-Phase Voltages

190.0 to 268.0 Volts RMS

Three Phase Unit Test

GHHVAC-32-2

3.3

Abnormal Steady State Frequency (see Designer Notes)

360 to 441 Hz

Requirement fulfilled in 1.7

4.0

Abnormal AC Transients

4.1

Voltage Transients

Per Figure 5A

Apply each transient 3x with 10s interval

GHHVAC-41

4.2

Frequency Transients

4.2.1

Maximum Ramp Rate

120Hz/s up, 400Hz/s down

N/A for GHE

4.2.2

Transients Outside of Steady State Range

350 to 480 Hz

3 times each, 400Hz nominal

GHHVAC-42-2

4.4.1.4 235VAC for Ground Handling Equipment:

Avionics Software 71

User Manual – Rev H California Instruments

4.3

DC Content

+/- 30VDC offset

441Hz and 360Hz

GHHVAC-43

SUPP

Supplementary Transient Test Requirements

Tests 1-10, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 11-20, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 21-30, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 31-40, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-4

SUPP

Supplementary Transient Test Requirements

Tests 41-50, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-5

SUPP

Supplementary Transient Test Requirements

Tests 51-62, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-6

SUPP

Supplementary Transient Test Requirements

Tests 63-74, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-7

SUPP

Supplementary Transient Test Requirements

Tests 1-11 Table 3.3.2-3B

Tests performed at 360 and 441 Hz

GHHSUPP-8

SUPP

Supplementary Transient Test Requirements

Tests 12-19 Table 3.3.2-3B

Tests performed at 360 and 441 Hz

GHHSUPP-9

72 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.1

Type 1 DC Voltage

22.0 to 32.8 Volts

TYPE1-51

5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Requirement fulfilled in 5.5.2

5.5.2

Ripple Components

Per Figure 7

Use B787 DC ripple window to perform

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE1-61

6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

6.3

Multiple Stroke Power Interrupts

450us dropouts (actual 1ms)

TYPE1-63

7.0

Abnormal DC Steady State

7.1

Type 1 DC Voltage

20.5 to 35.5 Volts

TYPE1-71

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE1-81

SUPP

Supplementary Transient Test Requirements

Tests 1-23, Table 3.3.3-3A

DC1SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 24-46, Table 3.3.3-3A

DC1SUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 47-67, Table 3.3.3-3A

DC1SUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 1-19, Table 3.3.3-3B

DC1SUPP-4

4.4.1.5 Type I DC:

Avionics Software 73

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.2

Type 2 DC Voltage

22.0 to 32.8 Volts

TYPE2-52

5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Requirement fulfilled in 5.5.2

5.5.2

Ripple Components

Per Figure 7

Use B787 DC ripple window to perform

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE2-61

6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

6.3

Multiple Stroke Power Interrupts

450us dropouts (actual 1ms)

TYPE2-63

7.0

Abnormal DC Steady State

7.2

Type 2 DC Voltage

18.0 to 35.5 Volts

TYPE2-72

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE2-81

SUPP

Supplementary Transient Test Requirements

Tests 1-23, Table 3.3.3-3A

DC2SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 24-46, Table 3.3.3-3A

DC2SUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 47-66, Table 3.3.3-3A

DC2SUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 1-19, Table 3.3.3-3B

DC2SUPP-4

4.4.1.6 Type II DC:

74 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.3

Type 3 DC Voltage

22.0 to 32.8 Volts

TYPE3-53

5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Requirement fulfilled in 5.5.2

5.5.2

Ripple Components

Per Figure 7

Use B787 DC ripple window to perform

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE3-61

6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

6.3

Multiple Stroke Power Interrupts

450us dropouts (actual 1ms)

TYPE3-63

7.0

Abnormal DC Steady State

7.3

Type 3 DC Voltage

18.0 to 32.8 Volts

TYPE3-73

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE3-81

SUPP

Supplementary Transient Test Requirements

Tests 1-65, Table 3.3.3-3A

DC3SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 1-19, Table 3.3.3-3B

DC3SUPP-2

4.4.1.7 Type III DC:

Avionics Software 75

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.4

Type 4 DC Voltage

18.0 to 32.8 Volts

TYPE4-54

5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Requirement fulfilled in 5.5.2

5.5.2

Ripple Components

Per Figure 7

Use B787 DC ripple window to perform

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE4-61

6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

6.3

Multiple Stroke Power Interrupts

450us dropouts (actual 1ms)

TYPE4-63

7.0

Abnormal DC Steady State

7.4

Type 4 DC Voltage

18.0 to 35.5 Volts

TYPE4-74

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE4-81

SUPP

Supplementary Transient Test Requirements

Tests 1-79, Table 3.3.3-3A

DC4SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 1-19, Table 3.3.3-3B

DC4SUPP-2

4.4.1.8 Type IV DC:

76 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

9.0

Normal DC Steady State

9.1

Normal Steady-State Voltage

Engine Start with Forward EP Source

+/-230.0 Volts

Apply for 15 min

TYPE5-91-1

All Other Operating Modes

+/-250.0 to +/-320.0 Volts

Apply for 30 min each

TYPE5-91-2

9.2

Voltage Ripple

9.2.1

Differential Mode Ripple Maximum Amplitude

32.0 Volts Peak to Peak

Ripple Frequency Not Specified

9.2.2

Differential Mode Ripple Components

Per Figure 13

Requires Additional Equipment

9.3

Common Mode Voltage

9.3.1

Common Mode Maximum Amplitude

62.0 Volts Peak to Peak

Ripple Frequency Not Specified

9.3.2

Common Mode Frequency Components

Per Figure 14

Requires Additional Equipment

10.0

Normal DC Transients

10.1

Voltage Transients

Per Figures 15A and 15B

TYPE5-101

11.0

Abnormal DC Steady State

Per Figures 9A through 9D

11.1

Steady State Voltage

+/-240.0 to +/-356.0 VDC

TYPE5-111

11.2

Voltage Ripple

11.2.1

Maximum Amplitude

120 Volts Peak to Peak

Ripple Frequency Not Specified

12.0

Abnormal DC Transients

12.1

Voltage Transients

Per Figure 16

TYPE5-121

4.4.1.9 Type V DC:

Avionics Software 77

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

13.0

Normal DC Steady State

13.1

Normal Steady-State Voltage

+/-120.0 to +/-140.0 Volts

Apply for 30 min each

TYPE6-131

13.2

Common Mode Voltage

1.25 Volts

Apply for 30 min

TYPE6-132

13.3

Differential Mode Voltage - Max Amplitude

2.0 Volts Peak to Peak

Requires Additional Equipment

13.4

Differential Mode Voltage - Max Ripple Components

40kHz - 120kHz

Requires Additional Equipment

14.0

Normal DC Transients

14.1

Voltage Transients

Per Figure 30

TYPE6-141

15.0

Abnormal DC Steady-State

15.1

Steady State Voltage

+/-120.0 to +/-140.0 Volts

Requirement fulfilled in 13.1

16.0

Abnormal DC Transients

16.1

Voltage Transients

Per Figure 31

TYPE6-161

4.4.1.10 Type VI DC:

78 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

1.0

Normal AC Steady State

1.1

Individual Phase Voltage

100.0 to 122.0 Volts RMS

30 mins, 800Hz and 360Hz

LVAC-11

1.2

Average of Three-Phase Voltages

101.5 to 120.5 Volts RMS

30 mins, 800Hz and 360Hz

LVAC-12

1.3

Phase Displacement

120.0 +/- 4.0°

No specified test

1.4

Phase Voltage Unbalance

Max. 6.0 Volts RMS

Apply each test 30 mins

LVAC-14

1.5

AC Voltage Modulation

1.5.1

Maximum Amplitude

5.0 Volts Peak-to-Valley

Follows specification Figure 1

LVAC-15

1.5.2

Frequency Components

Per Figure 1

Figure only, not a test. (Refer to spec)

1.6

Voltage Waveform

1.6.1

Total Harmonic Content

Max. 10% of Fundamental

30 mins each test

LVAC-16-1

1.6.2

Individual Harmonic Content

Max. 8% of Fundamental

Requires audio generator

1.6.3

DC Content

+/-0.10 Volts (after first cycle)

30 mins each test

LVAC-16-3

1.6.4

Crest Factor

1.41 +/- 0.15

No specified test

1.7

Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.1 and 1.2

1.8

Frequency Modulation

Applies to Ground Handling Equip only

2.0

Normal AC Transients

2.1

Voltage Transients

50ms Dropouts

800Hz and 360Hz

LVAC-21-1

2.1

Voltage Transients

Voltage Surge/Sag

3 times each, 800Hz and 360Hz

LVAC-21-2

2.1

Voltage Transients

Per Table B.2.1.1.1

2 times each

LVAC-21-3

2.2

Voltage Spikes

Per Figure 10

Requires additional equipment

2.3.1

Frequency Variations - Max Ramp Rate

100Hz/s up, 200Hz/s down

3 times each, 360Hz nominal

LVAC-23

2.3.2

Frequency Variations - Frequency Transients

Applies to Ground Handling Equip only

3.0

Abnormal AC Steady State

3.1

Individual Phase Voltage

90.0 to 134.0 Volts RMS

Single Phase Unit Test

LVAC-31

3.2

Average of Three-Phase Voltages

91.5 to 132.5 Volts RMS

5 mins each test

LVAC-32-1

3.2

Average of Three-Phase Voltages

90.0 to 134.0 Volts RMS

Three Phase Unit Test

LVAC-32-2

3.3

Abnormal Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.7

4.0

Abnormal AC Transients

4.1

Voltage Transients

Per Figure 5A

Apply each transient 3x with 10s interval

LVAC-41

4.4.2 Rev B:

4.4.2.1 115VAC:

Avionics Software 79

User Manual – Rev H California Instruments

4.2

Frequency Transients

4.2.1

Maximum Ramp Rate

120Hz/s up, 400Hz/s down

3 times each, 360Hz nominal

LVAC-42-1

4.2.2

Frequency Transients

350 to 885 Hz

3 times each, 400Hz nominal

LVAC-42-2

4.3

DC Content

+/- 15VDC offset

800Hz and 360Hz

LVAC-43

SUPP

Supplementary Transient Test Requirements

Tests 1-7, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 8-14, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 15-20, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 21-27, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-4

SUPP

Supplementary Transient Test Requirements

Tests 28-34, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-5

SUPP

Supplementary Transient Test Requirements

Tests 35-40, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-6

SUPP

Supplementary Transient Test Requirements

Tests 41-47, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-7

SUPP

Supplementary Transient Test Requirements

Tests 48-53, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-8

SUPP

Supplementary Transient Test Requirements

Tests 54-62, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-9

SUPP

Supplementary Transient Test Requirements

Tests 63-74, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

LSUPP-10

SUPP

Supplementary Transient Test Requirements

Tests 1-6 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

LSUPP-11

SUPP

Supplementary Transient Test Requirements

Tests 7-12 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

LSUPP-12

SUPP

Supplementary Transient Test Requirements

Tests 13-18 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

LSUPP-13

SUPP

Supplementary Transient Test Requirements

Test 19 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

LSUPP-14

80 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

1.0

Normal AC Steady State

1.1

Individual Phase Voltage

100.0 to 122.0 Volts RMS

30 mins, 441Hz and 360Hz

GHLVAC-11

1.2

Average of Three-Phase Voltages

101.5 to 120.5 Volts RMS

30 mins, 441Hz and 360Hz

GHLVAC-12

1.3

Phase Displacement

120.0 +/- 4.0°

No specified test

1.4

Phase Voltage Unbalance

Max. 6.0 Volts RMS

Apply each test 30 mins

GHLVAC-14

1.5

AC Voltage Modulation

1.5.1

Maximum Amplitude

5.0 Volts Peak-to-Valley

Follows specification Figure 1

GHLVAC-15

1.5.2

Frequency Components

Per Figure 1

Figure only, not a test. (Refer to spec)

1.6

Voltage Waveform

1.6.1

Total Harmonic Content

Max. 10% of Fundamental

30 mins each test

GHLVAC-16-1

1.6.2

Individual Harmonic Content

Max. 8% of Fundamental

Requires audio generator

1.6.3

DC Content

+/-0.10 Volts (after first cycle)

30 mins each test

GHLVAC-16-3

1.6.4

Crest Factor

1.41 +/- 0.15

No specified test

1.7

Steady State Frequency (see Designer Notes)

360 to 441 Hz

Requirement fulfilled in 1.1 and 1.2

1.8

Frequency Modulation

Applies to Ground Handling Equip only

GHLVAC-18

2.0

Normal AC Transients

2.1

Voltage Transients

50ms Dropouts

441Hz and 360Hz

GHLVAC-21-1

2.1

Voltage Transients

Voltage Surge/Sag

3 times each, 441Hz and 360Hz

GHLVAC-21-2

2.1

Voltage Transients

Per Table B.2.1.1.1

2 times each

GHLVAC-21-3

2.2

Voltage Spikes

Per Figure 10

Requires additional equipment

2.3.1

Frequency Variations - Max Ramp Rate

100Hz/s up, 200Hz/s down

N/A for GHE

2.3.2

Frequency Variations - Frequency Transients

Applies to Ground Handling Equip only

GHLVAC-23

3.0

Abnormal AC Steady State

3.1

Individual Phase Voltage

90.0 to 134.0 Volts RMS

Single Phase Unit Test

GHLVAC-31

3.2

Average of Three-Phase Voltages

91.5 to 132.5 Volts RMS

5 mins each test

GHLVAC-32-1

3.2

Average of Three-Phase Voltages

90.0 to 134.0 Volts RMS

Three Phase Unit Test

GHLVAC-32-2

3.3

Abnormal Steady State Frequency (see Designer Notes)

360 to 441 Hz

Requirement fulfilled in 1.7

4.0

Abnormal AC Transients

4.1

Voltage Transients

Per Figure 5A

Apply each transient 3x with 10s interval

GHLVAC-41

4.2

Frequency Transients

4.2.1

Maximum Ramp Rate

120Hz/s up, 400Hz/s down

N/A for GHE

4.2.2

Frequency Transients

350 to 480 Hz

3 times each, 400Hz nominal

GHLVAC-42-2

4.4.2.2 115VAC for Ground Handling Equipment:

Avionics Software 81

User Manual – Rev H California Instruments

4.3

DC Content

+/- 15VDC offset

441Hz and 360Hz

GHLVAC-43

SUPP

Supplementary Transient Test Requirements

Tests 1-10, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 11-20, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 21-30, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 31-40, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-4

SUPP

Supplementary Transient Test Requirements

Tests 41-50, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-5

SUPP

Supplementary Transient Test Requirements

Tests 51-62, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-6

SUPP

Supplementary Transient Test Requirements

Tests 63-74, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHLSUPP-7

SUPP

Supplementary Transient Test Requirements

Tests 1-11 Table 3.3.2-3B

Tests performed at 360 and 441 Hz

GHLSUPP-8

SUPP

Supplementary Transient Test Requirements

Tests 12-19 Table 3.3.2-3B

Tests performed at 360 and 441 Hz

GHLSUPP-9

82 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

1.0

Normal AC Steady State

1.1

Individual Phase Voltage

190.0 to 244.0 Volts RMS

30 mins, 800Hz and 360Hz

HVAC-11

1.2

Average of Three-Phase Voltages

193.0 to 241.0 Volts RMS

30 mins, 800Hz and 360Hz

HVAC-12

1.3

Phase Displacement

120.0 +/- 4.0°

No specified test

1.4

Phase Voltage Unbalance

Max. 12.0 Volts RMS

Apply each test 30 mins

HVAC-14

1.5

AC Voltage Modulation

1.5.1

Maximum Amplitude

10.0 Volts Peak-to-Valley

Follows specification Figure 1

HVAC-15

1.5.2

Frequency Components

Per Figure 1

Figure only, not a test. (Refer to spec)

1.6

Voltage Waveform

1.6.1

Total Harmonic Content

Max. 10% of Fundamental

30 mins each test

HVAC-16-1

1.6.2

Individual Harmonic Content

Max. 8% of Fundamental

Requires audio generator

1.6.3

DC Content

+/-0.20 Volts (after first cycle)

30 mins each test

HVAC-16-2

1.6.4

Crest Factor

1.41 +/- 0.15

No specified test

1.7

Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.1 and 1.2

1.8

Frequency Modulation

Applies to Ground Handling Equip only

2.0

Normal AC Transients

2.1

Voltage Transients

50ms Dropouts

800Hz and 360Hz

HVAC-21-1

2.1

Voltage Transients

Voltage Surge/Sag

3 times each, 800Hz and 360Hz

HVAC-21-2

2.1

Voltage Transients

Per Table B.2.1.1.1

2 times each

HVAC-21-3

2.2

Voltage Spikes

Per Figure 10

Requires additional equipment

2.3.1

Frequency Variations - Max Ramp Rate

100Hz/s up, 200Hz/s down

3 times each, 360Hz nominal

HVAC-23

2.3.2

Frequency Variations - Frequency Transients

Applies to Ground Handling Equip only

3.0

Abnormal AC Steady State

3.1

Individual Phase Voltage

190.0 to 268.0 Volts RMS

Single Phase Unit Test

HVAC-31-1

3.1

Average of Three-Phase Voltages

193.0 to 265.0 Volts RMS

5 mins each test

HVAC-31-2

3.2

Average of Three-Phase Voltages

190.0 to 268.0 Volts RMS

Three Phase Unit Test

HVAC-32

3.3

Abnormal Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.7

4.0

Abnormal AC Transients

4.1

Voltage Transients

Per Figure 5A

Apply each transient 3x with 10s interval

HVAC-41

4.2

Frequency Transients

4.2.1

Maximum Ramp Rate

120Hz/s up, 400Hz/s down

3 times each, 360Hz nominal

HVAC-42-1

4.2.2

Transients Outside of Steady State Range

350 to 885 Hz

3 times each, 400Hz nominal

HVAC-42-2

4.4.2.3 235VAC:

Avionics Software 83

User Manual – Rev H California Instruments

4.3

DC Content

+/- 15VDC offset

800Hz and 360Hz

HVAC-43

SUPP

Supplementary Transient Test Requirements

Tests 1-7, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 8-14, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 15-20, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 21-27, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-4

SUPP

Supplementary Transient Test Requirements

Tests 28-34, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-5

SUPP

Supplementary Transient Test Requirements

Tests 35-40, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-6

SUPP

Supplementary Transient Test Requirements

Tests 41-47, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-7

SUPP

Supplementary Transient Test Requirements

Tests 48-53, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-8

SUPP

Supplementary Transient Test Requirements

Tests 54-62, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-9

SUPP

Supplementary Transient Test Requirements

Tests 63-74, Table 3.3.2-3A

Tests performed at 360, 680, and 800 Hz

HSUPP-10

SUPP

Supplementary Transient Test Requirements

Tests 1-6 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

HSUPP-11

SUPP

Supplementary Transient Test Requirements

Tests 7-12 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

HSUPP-12

SUPP

Supplementary Transient Test Requirements

Tests 13-18 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

HSUPP-13

SUPP

Supplementary Transient Test Requirements

Test 19 Table 3.3.2-3B

Tests performed at 360, 680, and 800 Hz

HSUPP-14

84 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

1.0

Normal AC Steady State

1.1

Individual Phase Voltage

190.0 to 244.0 Volts RMS

30 mins, 441Hz and 360Hz

GHHVAC-11

1.2

Average of Three-Phase Voltages

193.0 to 241.0 Volts RMS

30 mins, 441Hz and 360Hz

GHHVAC-12

1.3

Phase Displacement

120.0 +/- 4.0°

No specified test

1.4

Phase Voltage Unbalance

Max. 12.0 Volts RMS

Apply each test 30 mins

GHHVAC-14

1.5

AC Voltage Modulation

1.5.1

Maximum Amplitude

10.0 Volts Peak-to-Valley

Follows specification Figure 1

GHHVAC-15

1.5.2

Frequency Components

Per Figure 1

Figure only, not a test. (Refer to spec)

1.6

Voltage Waveform

1.6.1

Total Harmonic Content

Max. 10% of Fundamental

30 mins each test

GHHVAC-16-1

1.6.2

Individual Harmonic Content

Max. 8% of Fundamental

Requires audio generator

1.6.3

DC Content

+/-0.20 Volts (after first cycle)

30 mins each test

GHHVAC-16-3

1.6.4

Crest Factor

1.41 +/- 0.15

No specified test

1.7

Steady State Frequency (see Designer Notes)

360 to 441 Hz

Requirement fulfilled in 1.1 and 1.2

1.8

Frequency Modulation

Applies to Ground Handling Equip only

2.0

Normal AC Transients

2.1

Voltage Transients

50ms Dropouts

441Hz and 360Hz

GHHVAC-21-1

2.1

Voltage Transients

Voltage Surge/Sag

3 times each, 441Hz and 360Hz

GHHVAC-21-2

2.1

Voltage Transients

Per Table B.2.1.1.1

2 times each

GHHVAC-21-3

2.2

Voltage Spikes

Per Figure 10

Requires additional equipment

2.3.1

Frequency Variations - Max Ramp Rate

100Hz/s up, 200Hz/s down

N/A for GHE

2.3.2

Frequency Variations - Frequency Transients

Applies to Ground Handling Equip only

GHHVAC-23

3.0

Abnormal AC Steady State

3.1

Individual Phase Voltage

190.0 to 268.0 Volts RMS

Single Phase Unit Test

GHHVAC-31

3.2

Average of Three-Phase Voltages

193.0 to 265.0 Volts RMS

5 mins each test

GHHVAC-32-1

3.2

Average of Three-Phase Voltages

190.0 to 268.0 Volts RMS

Three Phase Unit Test

GHHVAC-32-2

3.3

Abnormal Steady State Frequency (see Designer Notes)

360 to 441 Hz

Requirement fulfilled in 1.7

4.0

Abnormal AC Transients

4.1

Voltage Transients

Per Figure 5A

Apply each transient 3x with 10s interval

GHHVAC-41

4.2

Frequency Transients

4.2.1

Maximum Ramp Rate

120Hz/s up, 400Hz/s down

N/A for GHE

4.2.2

Transients Outside of Steady State Range

350 to 480 Hz

3 times each, 400Hz nominal

GHHVAC-42-2

4.4.2.4 235VAC for Ground Handling Equipment:

Avionics Software 85

User Manual – Rev H California Instruments

4.3

DC Content

+/- 30VDC offset

441Hz and 360Hz

GHHVAC-43

SUPP

Supplementary Transient Test Requirements

Tests 1-10, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 11-20, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 21-30, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 31-40, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-4

SUPP

Supplementary Transient Test Requirements

Tests 41-50, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-5

SUPP

Supplementary Transient Test Requirements

Tests 51-62, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-6

SUPP

Supplementary Transient Test Requirements

Tests 63-74, Table 3.3.2-3A

Tests performed at 360 and 441 Hz

GHHSUPP-7

SUPP

Supplementary Transient Test Requirements

Tests 1-11 Table 3.3.2-3B

Tests performed at 360 and 441 Hz

GHHSUPP-8

SUPP

Supplementary Transient Test Requirements

Tests 12-19 Table 3.3.2-3B

Tests performed at 360 and 441 Hz

GHHSUPP-9

86 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.1

Type 1 DC Voltage

22.0 to 32.8 Volts

TYPE1-51

5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Requirement fulfilled in 5.5.2

5.5.2

Ripple Components

Per Figure 7

Use B787 DC ripple window to perform

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE1-61

6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

7.0

Abnormal DC Steady State

7.1

Type 1 DC Voltage

20.5 to 35.5 Volts

TYPE1-71

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE1-81

SUPP

Supplementary Transient Test Requirements

Tests 1-23, Table 3.3.3-3A

DC1SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 24-46, Table 3.3.3-3A

DC1SUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 47-67, Table 3.3.3-3A

DC1SUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 1-19, Table 3.3.3-3B

DC1SUPP-4

4.4.2.5 Type I DC:

Avionics Software 87

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.2

Type 2 DC Voltage

22.0 to 32.8 Volts

TYPE2-52

5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Requirement fulfilled in 5.5.2

5.5.2

Ripple Components

Per Figure 7

Use B787 DC ripple window to perform

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE2-61

6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

7.0

Abnormal DC Steady State

7.2

Type 2 DC Voltage

18.0 to 35.5 Volts

TYPE2-72

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE2-81

SUPP

Supplementary Transient Test Requirements

Tests 1-23, Table 3.3.3-3A

DC2SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 24-46, Table 3.3.3-3A

DC2SUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 47-66, Table 3.3.3-3A

DC2SUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 1-19, Table 3.3.3-3B

DC2SUPP-4

4.4.2.6 Type II DC:

88 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.3

Type 3 DC Voltage

22.0 to 32.8 Volts

TYPE3-53

5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Requirement fulfilled in 5.5.2

5.5.2

Ripple Components

Per Figure 7

Use B787 DC ripple window to perform

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE3-61

6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

7.0

Abnormal DC Steady State

7.3

Type 3 DC Voltage

18.0 to 32.8 Volts

TYPE3-73

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE3-81

SUPP

Supplementary Transient Test Requirements

Tests 1-65, Table 3.3.3-3A

DC3SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 1-19, Table 3.3.3-3B

DC3SUPP-2

4.4.2.7 Type III DC:

Avionics Software 89

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.4

Type 4 DC Voltage

18.0 to 32.8 Volts

TYPE4-54

5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Requirement fulfilled in 5.5.2

5.5.2

Ripple Components

Per Figure 7

Use B787 DC ripple window to perform

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE4-61

6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

7.0

Abnormal DC Steady State

7.4

Type 4 DC Voltage

18.0 to 35.5 Volts

TYPE4-74

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE4-81

SUPP

Supplementary Transient Test Requirements

Tests 1-79, Table 3.3.3-3A

DC4SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 1-19, Table 3.3.3-3B

DC4SUPP-2

4.4.2.8 Type IV DC:

90 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

9.0

Normal DC Steady State

9.1

Normal Steady-State Voltage

Engine Start with Forward EP Source

+/-230.0 Volts

Apply for 15 min

TYPE5-91-1

All Other Operating Modes

+/-250.0 to +/-320.0 Volts

Apply for 30 min each

TYPE5-91-2

9.2

Voltage Ripple

9.2.1

Differential Mode Ripple Maximum Amplitude

32.0 Volts Peak to Peak

Ripple Frequency Not Specified

9.2.2

Differential Mode Ripple Components

Per Figure 13

Requires Additional Equipment

9.3

Common Mode Voltage

9.3.1

Common Mode Maximum Amplitude

62.0 Volts Peak to Peak

Ripple Frequency Not Specified

9.3.2

Common Mode Frequency Components

Per Figure 14

Requires Additional Equipment

10.0

Normal DC Transients

10.1

Voltage Transients

Per Figures 15A and 15B

TYPE5-101

11.0

Abnormal DC Steady State

Per Figures 9A through 9D

11.1

Steady State Voltage

+/-240.0 to +/-356.0 VDC

TYPE5-111

11.2

Voltage Ripple

11.2.1

Maximum Amplitude

120 Volts Peak to Peak

Ripple Frequency Not Specified

12.0

Abnormal DC Transients

12.1

Voltage Transients

Per Figure 16

TYPE5-121

4.4.2.9 Type V DC:

Avionics Software 91

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

13.0

Normal DC Steady State

13.1

Normal Steady-State Voltage

+/-120.0 to +/-140.0 Volts

Apply for 30 min each

TYPE6-131

13.2

Common Mode Voltage

1.25 Volts

Apply for 30 min

TYPE6-132

13.3

Differential Mode Voltage - Max Amplitude

2.0 Volts Peak to Peak

Requires Additional Equipment

13.4

Differential Mode Voltage - Max Ripple Components

40kHz - 120kHz

Requires Additional Equipment

14.0

Normal DC Transients

14.1

Voltage Transients

Per Figure 30

TYPE6-141

15.0

Abnormal DC Steady-State

15.1

Steady State Voltage

+/-120.0 to +/-140.0 Volts

Requirement fulfilled in 13.1

16.0

Abnormal DC Transients

16.1

Voltage Transients

Per Figure 31

TYPE6-161

4.4.2.10 Type VI DC:

92 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

1.0

Normal AC Steady State

1.1

Individual Phase Voltage

100.0 to 122.0 Volts RMS

30 mins, 800Hz and 360Hz

LVAC-11 1.2

Average of Three-Phase Voltages

101.5 to 120.5 Volts RMS

30 mins, 800Hz and 360Hz

LVAC-12 1.3

Phase Displacement

120.0 +/- 4.0°

Apply from main gui screen manually

1.4

Phase Voltage Unbalance

Max. 6.0 Volts RMS

Apply each test 30 mins

LVAC-14 1.5

AC Voltage Modulation

1.5.1

Maximum Amplitude

5.0 Volts Peak-to-Valley

Follows specification Figure 1

LVAC-15 1.5.2

Frequency Components

Per Figure 1

Figure only, not a test. (Refer to spec)

1.6

Voltage Waveform

1.6.1

Total Harmonic Content

Max. 10% of Fundamental

30 mins each test

LVAC-16-1

1.6.2

Individual Harmonic Content

Max. 8% of Fundamental

Requires audio generator

1.6.3

DC Content

+/-0.10 Volts (after first cycle)

30 mins each test

LVAC-16-2

1.6.4

Crest Factor

1.41 +/- 0.15

1.7

Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.1 and 1.2

1.8

Frequency Modulation

Per Figure 2

2 mins each test (400 Hz nominal)

LVAC-18

2.0

Normal AC Transients

2.1

Voltage Transients

50ms Dropouts

800Hz and 360Hz

LVAC-21-1

2.1

Voltage Transients

Voltage Surge/Sag

3 times each, 800Hz and 360Hz

LVAC-21-2

2.1

Voltage Transients

Per Table B.2.1.1.1

2 times each

LVAC-21-3

2.2

Voltage Spikes

Per Figure 10

Requires additional equipment

2.3

Frequency Transients

2.3.1

Maximum Ramp Rate

100Hz/s up, 200Hz/s down

3 times each, 360Hz nominal

LVAC-23

3.0

Abnormal AC Steady State

3.1

Individual Phase Voltage

90.0 to 134.0 Volts RMS

Single Phase Unit Test

LVAC-31-1

3.1

Individual Phase Voltage

90.0 to 134.0 Volts RMS

Three Phase Unit Test

LVAC-31-2

3.2

Average of Three-Phase Voltages

91.5 to 132.5 Volts RMS

5 mins each test

LVAC-32 3.3

Abnormal Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.7

4.0

Abnormal AC Transients

4.1

Voltage Transients

Per Figure 5A

Apply each transient 3x with 10s interval

LVAC-41

4.4.3 Rev A:

4.4.3.1 115VAC:

Avionics Software 93

User Manual – Rev H California Instruments

4.2

Frequency Transients

4.2.1

Maximum Ramp Rate

100Hz/s up, 200Hz/s down

Test procedure TBD

4.2.2

Transients Outside of Steady State Range

Per Figure 6

Test procedure TBD

4.3

DC Content

Per Figure 11

Test procedure TBD

SUPP

Supplementary Transient Test Requirements

Tests 1-7, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

LSUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 8-14, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

LSUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 15-20, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

LSUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 21-27, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

LSUPP-4

SUPP

Supplementary Transient Test Requirements

Tests 28-34, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

LSUPP-5

SUPP

Supplementary Transient Test Requirements

Tests 35-40, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

LSUPP-6

SUPP

Supplementary Transient Test Requirements

Tests 41-47, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

LSUPP-7

SUPP

Supplementary Transient Test Requirements

Tests 48-53, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

LSUPP-8

SUPP

Supplementary Transient Test Requirements

Tests 54-62, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

LSUPP-9

SUPP

Supplementary Transient Test Requirements

Tests 63-74, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

LSUPP-10

SUPP

Supplementary Transient Test Requirements

Tests 1-6 Table 3.3.2-3B

Tests performed at 360, 530, and 800 Hz

LSUPP-11

SUPP

Supplementary Transient Test Requirements

Tests 7-12 Table 3.3.2-3B

Tests performed at 360, 530, and 800 Hz

LSUPP-12

SUPP

Supplementary Transient Test Requirements

Tests 13-15 Table 3.3.2-3B

Tests performed at 360, 530, and 800 Hz

LSUPP-13

Test No.

Section

Subject

Test Limits

Comment

File Ref.

1.0

Normal AC Steady State

1.1

Individual Phase Voltage

190.0 to 244.0 Volts RMS

30 mins, 800Hz and 360Hz

HVAC-11 1.2

Average of Three-Phase Voltages

193.0 to 241.0 Volts RMS

30 mins, 800Hz and 360Hz

HVAC-12 1.3

Phase Displacement

120.0 +/- 4.0°

Apply from main gui screen manually

1.4

Phase Voltage Unbalance

Max. 12.0 Volts RMS

Apply each test 30 mins

HVAC-14 1.5

AC Voltage Modulation

1.5.1

Maximum Amplitude

10.0 Volts Peak-to-Valley

Follows specification Figure 1

HVAC-15

1.5.2

Frequency Components

Per Figure 1

Figure only, not a test. (Refer to spec)

1.6

Voltage Waveform

1.6.1

Total Harmonic Content

Max. 10% of Fundamental

30 mins each test

HVAC-16-1

1.6.2

Individual Harmonic Content

Max. 8% of Fundamental

Requires audio generator

1.6.3

DC Content

+/-0.20 Volts (after first cycle)

30 mins each test

HVAC-16-2

1.6.4

Crest Factor

1.41 +/- 0.15

4.4.3.2 230VAC:

94 Avionics Software

User Manual - Rev H California Instruments

1.7

Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.1 and 1.2

1.8

Frequency Modulation

Per Figure 2

2 mins each test (360, 800Hz nominal)

HVAC-18

2.0

Normal AC Transients

2.1

Voltage Transients

50ms Dropouts

800Hz and 360Hz

HVAC-21-1

2.1

Voltage Transients

Voltage Surge/Sag

3 times each, 800Hz and 360Hz

HVAC-21-2

2.1

Voltage Transients

Per Table B.2.1.1.1

2 times each

HVAC-21-3

2.2

Voltage Spikes

Per Figure 10

Requires additional equipment

2.3

Frequency Transients

2.3.1

Maximum Ramp Rate

100Hz/s up, 200Hz/s down

3 times each, 360Hz nominal

HVAC-23

3.0

Abnormal AC Steady State

3.1

Individual Phase Voltage

190.0 to 268.0 Volts RMS

Single Phase Unit Test

HVAC-31-1

3.1

Individual Phase Voltage

190.0 to 268.0 Volts RMS

Three Phase Unit Test

HVAC-31-2

3.2

Average of Three-Phase Voltages

193.0 to 265.0 Volts RMS

5 mins each test

HVAC-32 3.3

Abnormal Steady State Frequency (see Designer Notes)

360 to 800 Hz

Requirement fulfilled in 1.7

4.0

Abnormal AC Transients

4.1

Voltage Transients

Per Figure 5A

Apply each transient 3x with 10s interval

HVAC-41 4.2

Frequency Transients

4.2.1

Maximum Ramp Rate

100Hz/s up, 200Hz/s down

Test procedure TBD

4.2.2

Transients Outside of Steady State Range

Per Figure 6

Test procedure TBD

4.3

DC Content

Per Figure 11

Test procedure TBD

SUPP

Supplementary Transient Test Requirements

Tests 1-7, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

HSUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 8-14, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

HSUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 15-20, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

HSUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 21-27, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

HSUPP-4

SUPP

Supplementary Transient Test Requirements

Tests 28-34, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

HSUPP-5

SUPP

Supplementary Transient Test Requirements

Tests 35-40, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

HSUPP-6

SUPP

Supplementary Transient Test Requirements

Tests 41-47, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

HSUPP-7

SUPP

Supplementary Transient Test Requirements

Tests 48-53, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

HSUPP-8

SUPP

Supplementary Transient Test Requirements

Tests 54-62, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

HSUPP-9

SUPP

Supplementary Transient Test Requirements

Tests 63-74, Table 3.3.2-3A

Tests performed at 360, 530, and 800 Hz

HSUPP-10

SUPP

Supplementary Transient Test Requirements

Tests 1-6 Table 3.3.2-3B

Tests performed at 360, 530, and 800 Hz

HSUPP-11

SUPP

Supplementary Transient Test Requirements

Tests 7-12 Table 3.3.2-3B

Tests performed at 360, 530, and 800 Hz

HSUPP-12

SUPP

Supplementary Transient Test Requirements

Tests 13-15 Table 3.3.2-3B

Tests performed at 360, 530, and 800 Hz

HSUPP-13

Avionics Software 95

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.1

Type 1 DC Voltage

22.0 to 29.5 Volts

TYPE1-51 5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Procedure TBD

5.5.2

Ripple Components

Per Figure 7

Requires Additional Equipment

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE1-61 6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

7.0

Abnormal DC Steady State

7.1

Type 1 DC Voltage

20.5 to 32.2 Volts

TYPE1-71

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE1-81

SUPP

Supplementary Transient Test Requirements

Tests 1-27, Table 3.3.3-3A

DC1SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 28-51, Table 3.3.3-3A

DC1SUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 52-79, Table 3.3.3-3A

DC1SUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 1-15, Table 3.3.3-3B

DC1SUPP-4

4.4.3.3 Type I DC:

96 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.2

Type 2 DC Voltage

18.0 to 29.5 Volts

TYPE2-52 5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Procedure TBD

5.5.2

Ripple Components

Per Figure 7

Requires Additional Equipment

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE2-61 6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

7.0

Abnormal DC Steady State

7.2

Type 2 DC Voltage

18.0 to 32.2 Volts

TYPE2-72

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE2-81

SUPP

Supplementary Transient Test Requirements

Tests 1-27, Table 3.3.3-3A

DC2SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 28-51, Table 3.3.3-3A

DC2SUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 52-80, Table 3.3.3-3A

DC2SUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 1-15, Table 3.3.3-3B

DC2SUPP-4

4.4.3.4 Type II DC:

Avionics Software 97

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.3

Type 3 DC Voltage

18.0 to 32.2 Volts

TYPE3-53

5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Procedure TBD

5.5.2

Ripple Components

Per Figure 7

Requires Additional Equipment

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

N/A for Type 3

6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

7.0

Abnormal DC Steady State

7.3

Type 3 DC Voltage

18.0 to 32.2 Volts

TYPE3-73

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

N/A for Type 3

SUPP

Supplementary Transient Test Requirements

Tests 1-80, Table 3.3.3-3A

DC3SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 1-15, Table 3.3.3-3B

DC3SUPP-2

4.4.3.5 Type III DC:

98 Avionics Software

User Manual - Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

5.0

Normal DC Steady State

5.4

Type 4 DC Voltage

18.0 to 29.5 Volts

TYPE4-54

5.5

Voltage Ripple

5.5.1

Maximum Amplitude

4.0 Volts Peak to Peak

Procedure TBD

5.5.2

Ripple Components

Per Figure 7

Requires Additional Equipment

6.0

Normal DC Transients

6.1

Voltage Transients

Per Figures 8A through 8E

TYPE4-61

6.2

Voltage Spikes

Per Figure 10

Requires Additional Equipment

7.0

Abnormal DC Steady State

7.4

Type 4 DC Voltage

18.0 to 32.2 Volts

TYPE4-74

8.0

Abnormal DC Transients

8.1

Voltage Transients

Per Figures 9A through 9D

TYPE4-81

SUPP

Supplementary Transient Test Requirements

Tests 1-79, Table 3.3.3-3A

DC4SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 1-15, Table 3.3.3-3B

DC4SUPP-2

4.4.3.6 Type IV DC:

Avionics Software 99

User Manual – Rev H California Instruments

Test No.

Section

Subject

Test Limits

Comment

File Ref.

9.0

Normal DC Steady State

9.1

Steady State Voltage

+/-250.0 to +/-320.0 Volts

TYPE5-91

9.2

Voltage Ripple

9.2.1

Differential Mode Ripple Maximum Amplitude

32.0 Volts Peak to Peak

Procedure TBD

9.2.2

Differential Mode Ripple Components

Per Figure 13

Requires Additional Equipment

9.3

Common Mode Voltage

9.3.1

Common Mode Maximum Amplitude

62.0 Volts Peak to Peak

Procedure TBD

9.3.2

Common Mode Frequency Components

Per Figure 14

Procedure TBD

10.0

Normal DC Transients

10.1

Voltage Transients

Per Figures 15A and 15B

TYPE5-101

10.2

Voltage Spikes

Figure TBD

Requires Additional Equipment

11.0

Abnormal DC Steady State

Per Figures 9A through 9D

11.1

Steady State Voltage

+/-240.0 to +/-356.0 VDC

TYPE5-111

11.2

Voltage Ripple

11.2.1

Differential Mode Ripple Maximum Amplitude

120 Volts Peak to Peak

Procedure TBD

11.3

Common Mode Voltage

11.3.1

Common Mode Maximum Amplitude

TBD

12.0

Abnormal DC Transients

12.1

Voltage Transients

Per Figure 16

TYPE5-121

SUPP

Supplementary Transient Test Requirements

Tests 1-24, Table 3.3.3-8A

DC5SUPP-1

SUPP

Supplementary Transient Test Requirements

Tests 25-46, Table 3.3.3-8A

DC5SUPP-2

SUPP

Supplementary Transient Test Requirements

Tests 47-69, Table 3.3.3-8A

DC5SUPP-3

SUPP

Supplementary Transient Test Requirements

Tests 1-15, Table 3.3.3-8B

DC5SUPP-4

4.4.3.7 Type V DC:

100 Avionics Software

AMETEK Compact i/iX User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
