Arria II GX Pin Name Arria II GZ Pin Name

Pin Type (1st
and 2nd
Function)

Pin Description Connection Guidelines

CLK[4:15]

NA

Clock, Input Single ended clock input pin. Connect unused pins to GND.

DIFFCLK[0:5]p

NA

Clock, Input

Clock input pin for differential clock input. OCT Rd is not
supported.

Connect unused pins to GND.

DIFFCLK[0:5]n

NA

Clock, Input

Negative clock input for differential clock input. OCT Rd is not
supported

Connect unused pins to GND.

PLL_[1:4]_CLKOUT1p NA I/O, Clock

When not using this pin as a clock output, this pin may be used as a user I/O. When not using these pins,
connect them as defined in Quartus II software. See Note 15.

PLL_[1:4]_CLKOUT1n NA I/O, Clock

When not using this pin as a clock output, this pin may be used as a user I/O. When not using these pins,
connect them as defined in Quartus II Software. See Note 15.

PLL_[1,3]_CLKOUT[2:3]p NA I/O, Clock

When not using this pin as a clock output, this pin may be used as a user I/O. When not using these pins,
connect them as defined in Quartus II software. See Notes 9 and 15.

PLL_[1,3]_CLKOUT[2:3]n NA I/O, Clock

When not using this pin as a clock output, this pin may be used as a user I/O. When not using these pins,
connect them as defined in Quartus II software. See Notes 9 and 15.

NA CLK[1,3,8,10]p Clock, Input

Dedicated high speed clock input pins 1, 3, 8, and 10 that can
also be used for data inputs. OCT Rd is not supported on these

Connect unused pins to GND.

NA CLK[1,3,8,10]n Clock, Input

Dedicated negative clock input pins for differential clock input that
can also be used for data inputs. OCT Rd is not supported on

Connect unused pins to GND.

NA CLK[0,2,9,11]p I/O, Clock

These pins can be used as I/O pins or clock input pins. OCT Rd is
supported on these pins.

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

NA CLK[0,2,9,11]n I/O, Clock

These pins can be used as I/O pins or negative clock input pins
for differential clock inputs. OCT Rd is supported on these pins.

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

NA CLK[4:7,12:15]p I/O, Clock

These pins can be used as I/O pins or clock input pins. OCT Rd is
not supported on these pins.

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

NA CLK[4:7,12:15]n I/O, Clock

These pins can be used as I/O pins or negative clock input pins
for differential clock inputs. OCT Rd is not supported on these
pins.

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

NA PLL_[L1,L4,R1,R4]_CLKp Clock, Input

Dedicated clock input pins to PLL L1, L4, R1, and R4 respectively.
OCT Rd is not supported on these pins.

Connect unused pins to GND.

NA PLL_[L1,L4,R1,R4]_CLKn Clock, Input

Dedicated negative clock input pins for differential clock input to
PLL L1, L4, R1, and R4 respectively. OCT Rd is not supported on
these pins.

Connect unused pins to GND.

NA

PLL_[L1, L2, L3, L4]_CLKOUT0n
PLL_[R1, R2, R3, R4]_CLKOUT0n

I/O, Clock

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

NA

PLL_[L1, L2, L3, L4]_FB_CLKOUT0p
PLL_[R1, R2, R3, R4]_FB_CLKOUT0p

I/O, Clock

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

NA PLL_[T1,T2,B1,B2]_FBp/CLKOUT1 I/O, Clock

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

NA PLL_[T1,T2,B1,B2]_FBn/CLKOUT2 I/O, Clock

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

NA PLL_[T1,T2,B1,B2]_CLKOUT[3,4] I/O, Clock

These pins can be used as I/O pins or two single-ended clock
output pins.

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

NA PLL_[T1,T2,B1,B2]_CLKOUT0p I/O, Clock

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

NA PLL_[T1,T2,B1,B2]_CLKOUT0n I/O, Clock

These pins can be tied to GND or left unconnected. If unconnected, use Quartus II software programmable
options to internally bias these pins. They can be reserved as inputs tristate with weak pull up resistor
enabled, or as outputs driving GND.

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

You should create a Quartus® II design, enter your device I/O assignments and compile the design. The Quartus II software will check your pin connections with respect to I/O assignment and placement rules to ensure proper device
operation. These rules are dependent on device density, package, I/O assignments, voltage assignments and other factors that are not fully described in this document or the device handbook.

Clock and PLL Pins

PLL1 and PLL3 in EP2AGX95, EP2AGX125, EP2AGX190, and
EP2AGX260 support 6 clock I/O pins, configured either as 3
single ended I/Os or 3 differential I/O pairs.

PLL[1:4]_CLKOUT1 (except PLL1 and PLL3 in EP2AGX125 and
EP2AGX260) supports 2 clock I/O pins, configured either as one
single ended I/O or one differential I/O pair. PLL1 and PLL3 in
EP2AGX125 and EP2AGX260 support 6 clock I/O pins,
configured either as 3 single ended I/Os or 3 differential I/O pairs.

Each left and right PLL supports 2 clock I/O pins, configured
either as 2 single ended I/O or one differential I/O pair. When
using both pins as single ended I/Os, PLL_#_CLKOUT0n can be
the clock output while the PLL_#_FB_CLKOUT0p is the external
feedback input pin.

I/O pins that can be used as two single-ended clock output pins or
one differential clock output pair.

Dual purpose I/O pins that can be used as two single-ended
outputs or one differential external feedback input pin.

Configuration/JTAG Pins (See Note 16)

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Pin Connection Guidelines Page 2 of 16

Arria II GX Pin Name Arria II GZ Pin Name

Pin Type (1st
and 2nd
Function)

Pin Description Connection Guidelines

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

You should create a Quartus® II design, enter your device I/O assignments and compile the design. The Quartus II software will check your pin connections with respect to I/O assignment and placement rules to ensure proper device
operation. These rules are dependent on device density, package, I/O assignments, voltage assignments and other factors that are not fully described in this document or the device handbook.

nIO_PULLUP nIO_PULLUP Input

Dedicated input that chooses whether the internal pull-ups on the
user I/O pins and dual-purpose I/O pins (DATA[1:7], CLKUSR,
INIT_DONE, DEV_OE, DEV_CLRn) are on or off before and
during configuration. A logic high (1.5 V, 1.8 V, 2.5 V, 3.0 V, or
(3.3 V, Arria II GX only) turns off the weak pull-up, while a logic
low turns them on.

nIO-PULLUP can be tied directly to (VCCIO3C for Arria II GX only), (VCCPGM for Arria II GZ only) using a
1kΩ pull-up resistor, or tied directly to GND depending on the desired functionality. Refer to the description
column.

MSEL[0:3] MSEL[0:3] Input

Configuration input pins that set the FPGA device configuration
scheme.

These pins are internally connected through a 5-kΩ resistor to GND. Do not leave these pins floating.
When these pins are unused connect them to GND. Depending on the configuration scheme used these
pins should be tied to (VCCPD3C for Arria II GX only), (VCCPGM for Arria II GZ only) or GND. Refer to the
"„Configuration, Design Security, and Remote System Upgrades" chapter in the Arria II GX Handbook. If
only JTAG configuration is used, connect these pins to ground.

nCE nCE Input

Dedicated active-low chip enable. When nCE is low, the device is
enabled. When nCE is high, the device is disabled.

In multi-device configuration, nCE of the first device is tied low while its nCEO pin drives the nCE of the
next device in the chain. In single device configuration and JTAG programming, nCE should be connected
to GND.

nCONFIG nCONFIG Input

Dedicated configuration control input. Pulling this pin low during
user-mode will cause the FPGA to lose its configuration data,
enter a reset state, and tri-state all I/Opins. Returning this pin toa
logic high level will initiate reconfiguration.

If the configuration scheme uses an enhanced configuration device or EPC2, nCONFIG can be tied directly
to the nINIT_CONF pin of the configuration device. If this pin is not used, it requires a connection directly

or through a 10-kΩ resistor to (VCCIO3C for Arria II GX only), (VCCPGM for Arria II GZ only).

CONF_DONE CONF_DONE

Bidirectional
(open-drain)

This is a dedicated configuration done pin. As a status output, the
CONF_DONE pin drives low before and during configuration.
Once all configuration data is received without error and the
initialization cycle starts, CONF_DONE is released. As a status
input, CONF_DONE goes high after all data is received. Then the
device initializes and enters user mode. It is not available as a
user I/O pin.

Connect this pin to a 10-kΩ pull-up resistor to an acceptable voltage for all devices in the chain which
satisfies the input voltage of the receiving device. If internal pull-up resistors on the enhanced

configuration device are used, external 10-kΩ pull-up resistors should not be used on t his pin.

nCEO nCEO

I/O, Output
(open-drain)

Output that drives low when device configuration is complete.
This pin can be used as regular I/O if not used for device
configuration.

When not using this pin, you can leave it unconnected. During multi-device configuration, this pin feeds
the nCE pin of a subsequent device. In this case, tie the 10-kΩ pull-up resistor to an acceptable voltage
for all devices in the chain which satisfies the input voltage of the receiving device. During single device
configuration, this pin can be used as a regular I/O.

nSTATUS nSTATUS

Bidirectional
(open-drain)

This is a dedicated configuration status pin. The FPGA drives
nSTATUS low immediately after power-up and releases it after
POR time. As a status output, the nSTATUS is pulled low if an
error occurs during configuration. As a status input, the device
enters an error state when nSTATUS is driven low by an external
source during configuration or initialization. It is not available as
an user I/O pin.

Connect this pin to a 10-kΩ pull-up resistor to an acceptable voltage for all devices in the chain which
satisfies the input voltage of the receiving device. The OE and nCE pins of the enhanced configuration
devices and EPC2 devices have optional internal programmable pull-up resistors. If internal pull-up
resistors on the enhanced configuration device are used, external 10-kΩ pull-up should not be used on
these pins. When not using external configuration devices, connect this pin to an external 10-kΩ pull-up
resistor to (VCCIO3C for Arria II GX only), (VCCPGM for Arria II GZ only).

TCK TCK Input Dedicated JTAG test clock input pin. Connect this pin to a 1-kΩ pull-down resis tor to GND.

TMS TMS Input Dedicated JTAG test mode select input pin.

Connect this pin to a 1-kΩ - 10-kΩ pull-up resistor to VCCIO for Arria II GX or VCCPD for Arria II GZ. To

disable the JTAG circuitry connect TMS t o logic high via a 1-kΩ resistor.

TDI TDI Input Dedicated JTAG test data input pin.

Connect this pin to a 1-kΩ - 10-kΩ pull-up resistor to VCCIO for Arria II GX or VCCPD for Arria II GZ. To

disable the JTAG circuitry connect TDI to logic high via a 1-kΩ resistor.

TDO TDO Output Dedicated JTAG test data output pin. The JTAG circuitry can be disabled by leaving TDO unconnected.

NA TRST Input

Dedicated active low JTAG test reset input pin. TRST is used to
asynchronously reset the JTAG boundary-scan circuit.

Utilization of TRST is optional. When using this pin ensure that TMS is held high or TCK is static when

TRST is changed from low to high. If not using TRST, tie this pin to a 1-kΩ to 10-kΩ pull-up resis tor to

VCCPD. To disable the JTAG circuitry, tie this pin to GND.

NA PORSEL Input

Dedicated input which selects between a POR time of 4 -12 ms or
100 - 300 ms. A logic high (1.8V, 2.5V, 3.0V) selects a POR time
of 4 -12 ms and a logic low selects POR time of 100 - 300 ms.

The PORSEL pin should be tied directly to VCCPGM or GND.

nCSO nCSO Output

Dedicated output control signal from the FPGA to the serial
configuration device in AS mode that enables the configuration
device.

When not programming the device in AS mode nCSO is not used. Also, when this pin is not used as an
output then it is recommended to leave the pin unconnected.

ASDO ASDO Output

Control signal from the FPGA to the serial configuration device in
AS mode used to read out configuration data.

When not programming the device in AS mode ASDO is not used. Also, when this pin is not used as an
output then it is recommended to leave the pin unconnected.

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Pin Connection Guidelines Page 3 of 16

Arria II GX Pin Name Arria II GZ Pin Name

Pin Type (1st
and 2nd
Function)

Pin Description Connection Guidelines

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

You should create a Quartus® II design, enter your device I/O assignments and compile the design. The Quartus II software will check your pin connections with respect to I/O assignment and placement rules to ensure proper device
operation. These rules are dependent on device density, package, I/O assignments, voltage assignments and other factors that are not fully described in this document or the device handbook.

DCLK DCLK

I/O (PS, FPP)
Output (AS)

Dedicated configuration clock pin. In PS and FPP configuration,
DCLK is used to clock configuration data from an external source
into the FPGA. In AS mode, DCLK is an output from the FPGA
that provides timing for the configuration interface.

Do not leave this pin floating. Drive this pin either high or low.

CRC_ERROR CRC_ERROR

I/O, Output
(open-drain)

Active high signal that indicates that the error detection circuit has
detected errors in the configuration SRAM bits. This pin is
optional and is used when the CRC error detection circuit is
enabled. This pin can be used as regular I/O if not used for CRC

When using this pin connect it to an external 10-kΩ pull-up resistor to an acceptable voltage for alldevices
in the chain which satisfies the input voltage of the receiving device. When not using this pin, it can be left
floating.

DEV_CLRn DEV_CLRn I/O, Input

Optional pin that allows designers to override all clears on all
device registers. When this pin is driven low, all registers are
cleared; when this pin is driven high, all registers behave as
programmed.

When the dedicated input DEV_CLRn is not used and this pin is not used as an I/O then it is
recommended to tie this pin to ground.

DEV_OE DEV_OE I/O, Input

Optional pin that allows designers to override all tri-states on the
device. When this pin is driven low, all I/O pins are tri-stated;
when this pin is driven high, all I/O pins behave as defined in the

When the dedicated input DEV_OE is not used and this pin is not used as an I/O then it is recommended
to tie this pin to ground.

DATA0 DATA0 Input

DATA[0] is a dedicated pin that is used for both the passive and
active configuration modes

When the dedicated input for DATA[0] is not used on Arria II GX, then it is recommended to tie this pin to
GND. For Arria II GZ, connect this pin as defined in the Quartus II software.

DATA[7:1] DATA[7:1] I/O, Input

Dual-purpose configuration input data pins. The DATA[7:0] pins
can be used for byte-wide configuration. DATA[7:1] pins can also
be used as user I/O pins after configuration, but not DATA0.

When the dedicated inputs for DATA[7:1] are not used and these pins are not used as an I/O thenconnect
them as defined in Quartus. (See Note 15).

INIT_DONE INIT_DONE

I/O, Output
(open-drain)

This is a dual-purpose pin and can be used as an I/O pin when
not enabled as INIT_DONE. When enabled, a transition from low
to high at the pin indicates when the device has entered user
mode. If the INIT_DONE output is enabled, the INIT_DONE pin
cannot be used as a user I/O pin after configuration.

When using this pin connect it to an external 10-kΩ pull-up resistor to an acceptable voltage for alldevices
in the chain which satisfies the input voltage of the receiving device. When not using this pin, it can be left
floating or tied to GND.

CLKUSR CLKUSR I/O, Input

Optional user-supplied clock input. If this pin is not enabled for
use as a user-supplied configuration clock, it can be used as an
user I/O pin.

If the CLKUSR pin is not used as a configuration clock input and the pin is not used as an I/O then it is
recommended to connect this pin to ground.

DIFFIO_RX_[T,B,R][##]p,
DIFFIO_RX_[T,B,R][##]n

DIFFIO_RX_[T,B,L,R][##]p,
DIFFIO_RX_[T,B,L,R][##]n

I/O, RX
channel

Pins with a "p" suffix carry the positive signal for the differential
channel. Pins with an "n" suffix carry the negative signal for the
differential channel. If not used for differential signaling, these
pins are available as user I/O pins.

For Arria II GX, these are true LVDS receiver channels with OCT
Rd support.

For Arria II GZ, only DIFFIO_RX_[L,R]* pins are true LVDS
receiver channels with OCT Rd support.

When these IO pins are not used they can be tied to GND. Connect unused pins as defined in Quartus II
software.

DIFFIO_TX_[T,B,R][##]p,
DIFFIO_TX_[T,B,R][##]n

DIFFIO_TX_[L,R][##]p,
DIFFIO_TX_[L,R][##]n

I/O, TX
channel

These are true LVDS transmitter channels. Pins with a "p" suffix
carry the positive signal for the differential channel. Pins with an
"n" suffix carry the negative signal for the differential channel. If
not used for differential signaling, these pins are available as user
I/O pins.

For Arria II GX if not used as true LVDS transmitter channels,
these pins can be configured as true LVDS receiver channels
without OCT Rd support (DIFFIN_[T,B,R][##][p,n]).

When these IO pins are not used they can be tied to GND. Connect unused pins as defined in Quartus II
software.

DIFFIN_[T,B,R][##]p,
DIFFIN_[T,B,R][##]n

NA

I/O, RX
channel

These are true LVDS receiver channels without OCT Rd support.
Pins with a "p" suffix carry the positive signal for the differential
channel. Pins with an "n" suffix carry the negative signal for the
differential channel. If not used as true LVDS receiver channels
without OCT Rd support, these pins can be configured as true
LVDS transmitter channels (DIFFIO_TX_[T,B,R][##][p,n]). If not
used for differential signaling, these pins are available as user I/O
pin.

When these IO pins are not used they can be tied to GND. Connect unused pins as defined in Quartus II
software.

Differential I/O Pins (See Note 12)

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Pin Connection Guidelines Page 4 of 16

Arria II GX Pin Name Arria II GZ Pin Name

Pin Type (1st
and 2nd
Function)

Pin Description Connection Guidelines

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

You should create a Quartus® II design, enter your device I/O assignments and compile the design. The Quartus II software will check your pin connections with respect to I/O assignment and placement rules to ensure proper device
operation. These rules are dependent on device density, package, I/O assignments, voltage assignments and other factors that are not fully described in this document or the device handbook.

DIFFOUT_[T,B,R][##]p,
DIFFOUT_[T,B,R][##]n

DIFFOUT_[T,B,L,R][##]p,
DIFFOUT_[T,B,L,R][##]n

I/O, TX
channel

These are emulated LVDS output channels. Pins with a "p" suffix
carry the positive signal for the differential channel. Pins with an
"n" suffix carry the negative signal for the differential channel. If
not used for differential signaling, these pins are available as user
I/O pins.

On Arria II GX I/O banks there are true LVDS input buffers but no
true LVDS output buffers. However, all user I/Os, including I/Os
with true LVDS input buffers, (DIFFIO_RX_[T,B,R][##][p,n] ,
DIFFIN_[T,B,R][##][p,n]) can be configured as emulated LVDS
output buffers.

On Arria II GZ column I/O banks thereare true LVDS input buffers
but no true LVDS output buffers. However, all column user I/Os,
including I/Os with true LVDS input buffers, can be configured as
emulated LVDS output buffers.

When these IO pins are not used they can be tied to GND. Connect unused pins as defined in Quartus II
software.

DQS[##][T,B,R] DQS[##][T,B,L,R] I/O, DQS

Optional data strobe signal for use in external memory interfacing.
These pins drive to dedicated DQS phase shift circuitry. The
shifted DQS signal can also drive to internal logic.

When these IO pins are not used they can be tied to GND. Connect unused pins as defined in Quartus II
software.

DQSn[##][T,B,R] DQSn[##][T,B,L,R] I/O, DQSn

Optional complementary data strobe signal for use in external
memory interfacing. These pins drive to dedicated DQS phase
shift circuitry.

When these IO pins are not used they can be tied to GND. Connect unused pins as defined in Quartus II
software. See Note 11.

DQ[##][T,B,R] DQ[##][T,B,L,R] I/O, DQ

Optional data signal for use in external memory interfacing. The
order of the DQ bits within a designated DQ bus is not important;
however, use caution when making pin assignments if you plan
on migrating to a different memory interface that has a different
DQ bus width. Analyze the available DQ pins across all pertinent
DQS columns in the pin list.

When these IO pins are not used they can be tied to GND. Connect unused pins as defined in Quartus II
software.

CQ[##][T,B,R] CQ[##][T,B,L,R] DQS

Optional data strobe signal for use in QDR II SRAM. These are
the pins for echo clocks.

When these IO pins are not used they can be tied to GND. Connect unused pins as defined in Quartus II
software.

CQn[##][T,B,R] CQn[##][T,B,L,R] DQS

Optional complementary data strobe signal for use in QDR II
SRAM. These are the pins for echo clocks.

When these IO pins are not used they can be tied to GND. Connect unused pins as defined in Quartus II
software. See Note 11.

RUP[0:2] RUP[1:8]A I/O, Input

Reference pins for I/O banks. The RUP pins share the same
VCCIO with the I/O bank where they are located. The external
precision resistor RUP must be connected to the designated RUP
pin within the bank. If not required, this pin is a regular I/O pin.

When the device does not use this dedicated input for the external precision resistor or as an I/O it is
recommended that the pin be connected to the VCCIO of the bank in which the RUP pin resides or GND.
When using OCT tie these pins to the required banks VCCIO through either a 25 W or 50 W resistor,
depending on the desired I/O standard. Refer to the Arria II GX handbook for the desired resistor value for
the I/O standard used.

RDN[0:2] RDN[1:8]A I/O, Input

Reference pins for I/O banks. The RDN pins share the same GND
with the I/O bank where they are located. The external precision
resistor RDN must be connected to the designated RDN pin within
the bank. If not required, this pin is a regular I/O pin.

When the device does not use this dedicated input for the external precision resistor or as an I/O it is
recommended that the pin be connected to GND. When using OCT tie these pins to GND through either a
25 W or 50 W resistor depending on the desired I/O standard. Refer to the Arria II GX handbook for the
desired resistor value for the I/O standard used.

DNU DNU Do Not Use Do Not Use (DNU). Do not connect to power, ground or any other signal. These pins must be left floating.

NC NC No Connect Do not drive signals into these pins.

When designing for device migration these pins may be connected to power, ground, or a signal trace
depending on the pin assignment of the devices selected for migration. However, if device migration is not
a concern leave these pins floating.

VCC VCC Power VCC supplies power to the core and periphery.

All VCC pins require a 0.9 V supply. Use the Arria II GX or Arria II GZ Early Power Estimator to determine
the current requirements for VCC and other power supplies. To successfully power-up and exit POR, fully
power VCC before VCCAUX begins to ramp. Decoupling for these pins depends on the design decoupling
requirements of the specific board. See Notes 3, 6 and 17.

For Arria II GX, with a proper isolation filter VCCD_PLL may be sourced from the same regulator as VCC.
To support the startup current as reported by the Early Power Estimator (EPE) for Arria II GX devices, fully
power VCC before VCCCB begins to ramp.

For Arria II GZ, these pins may be tied to the same 0.9V plane as VCCHIP_L. With a proper isolation filter
VCCD_PLL may be sourced from the same regulator as VCC.

Reference Pins

Supply Pins (See Note 8 and 17)

External Memory Interface Pins (See Note 12)

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Pin Connection Guidelines Page 5 of 16

Arria II GX Pin Name Arria II GZ Pin Name

Pin Type (1st
and 2nd
Function)

Pin Description Connection Guidelines

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

You should create a Quartus® II design, enter your device I/O assignments and compile the design. The Quartus II software will check your pin connections with respect to I/O assignment and placement rules to ensure proper device
operation. These rules are dependent on device density, package, I/O assignments, voltage assignments and other factors that are not fully described in this document or the device handbook.

VCCD_PLL_[1:6]

VCCD_PLL_[L,R][1:4],
VCCD_PLL_[T,B][1:2]

Power Digital power for PLL[1:6] and PLL[L[1:4],R[1:4],T[1:2],B[1:2]].

You are required to connect these pins to 0.9 V, even if the PLL is not used. Decoupling for these pins
depends on the design decoupling requirements of the specific board. See Notes 3 and 6.

For Arria II GX, with a proper isolation filter these pins may be sourced from the same regulator as VCC.

For Arria II GZ, with a proper isolation filter these pins may be sourced from the same regulator as VCC
and/or VCCHIP_L.

VCCCB VCCCB Power Configuration RAM bits power supply.

Connect VCCCB to a 1.5 V power supply. These pins may be sourced from the same regulator as
VCCH_GXB with a proper isolation filter. Decoupling for these pins depends on the design decoupling
requirements of the specific board. See Notes 3, 6, and 7.

For Arria II GX, use a linear regulator or switching power supply with ±5 mV maximum voltage ripple (See
note 14). To support the startup current as reported by the Early Power Estimator (EPE) for Arria II GX
devices, fully power VCC before VCCCB begins to ramp.

For Arria II GZ, use a linear or low noise switching regulator.

VCCA_PLL_[1:6]

VCCA_PLL_[L,R][1:4],
VCCA_PLL_[T,B][1:2]

Power Analog power for PLL [1:6] and PLL [L[1:4],R[1:4],T[1:2],B[1:2]].

You are required to connect these pins to 2.5 V, even if the PLL is not used. It is advised to keep this pin
isolated from other VCC for better jitter performance. Decoupling for these pins depends on the design
decoupling requirements of the specific board. See Notes 3, 6, and 7.

For Arria II GX, use an isolated linear regulator or switching power supply with ±5 mV maximum voltage
ripple. These pins may share the same linear regulator as VCCA with a proper isolation filter. (See note

14)

For Arria II GZ, use a linear or low noise switching regulator. With a proper isolation filter, these pins may
be tied to the same regulator as VCCIO, VCCPD, VCCPGM and VCC_CLKIN, but only if each of these
supplies require 2.5V sources. With a proper isolation filter these pins may be sourced from the same
regulator as VCCAUX and VCCA_[L,R], but only if each of these rails requires 2.5V.

NA VCCAUX Power Auxiliary supply for configuration.

VCCAUX can be connected to an isolated 2.5V linear or low noise switching power supply. With a proper
isolation filter these pins may be sourced from the same regulator as VCCA_PLL and VCCA_[L,R], but
only if each of these rails requires 2.5V. Also, with a proper isolation filter, these pins may be tied to the
same regulator as VCCIO, VCCPD, VCCPGM, and VCC_CLKIN, but only if each of these supplies require

2.5V sources. To successfully power-up and exit POR, fully power VCC before VCCAUX begins to ramp.
Decoupling for these pins depends on the design decoupling requirements of the specific board. See
Notes 3, 6, 7 and 19.

NA VCCPGM Power

Configuration pins power supply. Can be connected to1.8V, 2.5V
or 3.0V depending on the particular design.

Connect this pin to either a 1.8V, 2.5V or 3.0V power supply. VCCPGM must ramp-up from 0V to
VCCPGM within 100 ms when PORSEL is low or 4 ms when PORSEL is high to ensure successful
configuration. When these pins require 2.5V they may be tied to the same regulator as VCC_CLKIN,
VCCIO and VCCPD, but only if each of these supplies require 2.5V sources. VCC_CLKIN has a set
voltage of 2.5V, so excluding VCC_CLKIN you may tie these pins to the same regulator as VCCPD and/or
VCCIO as long as they all require the same voltage. Also, when these pins use 2.5V they may be sourced
from the same regulator as VCCAUX and VCCA_PLL with a proper isolation filter. Decoupling for these
pins depends on the design decoupling requirements of the specific board. See Notes 3 and 6.

VCCIO[3:8][A,B] VCCIO[1:8][A,C],

VCCIO[3,4,7,8]B

Power

These are I/O supply voltage pins for banks 1 through 8. Each
bank can support a different voltage level. VCCIO supplies power
to the output buffers for all LVDS, LVCMOS(1.2 V, 1.5 V, 1.8 V,

2.5 V, 3.0 V, (3.3 V, Arria II GX only)), HSTL(12, 15, 18),
SSTL(15, 18, 2), 3.0 V PCI/PCI-X I/O as well as LVTTL (1.8 V, 2.5
V, 3.0 V, (3.3 V, Arria II GX only)) I/O standards. VCCIO also
supplies power to the input buffers used for LVCMOS(1.2 V,

1.5 V, 1.8 V, 2.5 V, 3.0 V, (3.3 V, Arria II GX only)), 3.0 V PCI/PCI­X, and LVTTL (1.8 V, 2.5 V, 3.0 V, (3.3 V, Arria II GX only)) I/O
standards.

Connect these pin to 1.2 V, 1.5 V, 1.8 V, 2.5 V, 3.0 V, or (3.3 V, Arria II GX only) supplies, depending on
the I/O standard connected to the specified bank. Decoupling for these pins depends on the design
decoupling requirements of the specific board. See Notes 3 and 6.

For Arria II GX, these pins may be tied to the same regulator as VCCPD, but only if each of these supplies
require the same voltage level.

For Arria II GZ, when these pins require 2.5V they may be tied to the same regulator as VCC_CLKIN,
VCCPGM and VCCPD, but only if each of these supplies require 2.5V sources. VCC_CLKIN has a set
voltage of 2.5V, so excluding VCC_CLKIN you may tie these pins to the same regulator as VCCPGM
and/or VCCPD as long as they all require the same voltage. Also, when these pins use 2.5V they may be
sourced from the same regulator as VCCAUX and VCCA_PLL with a proper isolation filter.

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Pin Connection Guidelines Page 6 of 16

Arria II GX Pin Name Arria II GZ Pin Name

Pin Type (1st
and 2nd
Function)

Pin Description Connection Guidelines

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

You should create a Quartus® II design, enter your device I/O assignments and compile the design. The Quartus II software will check your pin connections with respect to I/O assignment and placement rules to ensure proper device
operation. These rules are dependent on device density, package, I/O assignments, voltage assignments and other factors that are not fully described in this document or the device handbook.

VCCIO[3,8]C NA Power

These are configuration and JTAG supply voltage pins for banks
3C and 8C. Each bank can support a different voltage level. For
AS/PS/FPP configuration schemes, VCCIO8C supports 1.8 V, 2.5
V, 3.0 V or 3.3 V. JTAG can support 1.5 V, 1.8 V, 2.5 V, 3.0 V or

3.3 V.

Connect these pin to 1.5 V, 1.8 V, 2.5 V, 3.0 V, or 3.3 V supplies, depending on the I/O standard
connected to the specified bank. When using configuration schemes that require external configuration
devices, the voltage level of these pins must match that of the configuration device. These pins may be
tied to the same regulator as VCCPD, but only if each of these supplies require the same voltage level.
Decoupling for these pins depends on the design decoupling requirements of the specific board. See
Notes 3 and 6.

VCCPD[3:8][A,B],
VCCPD[3,8]C

VCCPD[1:8][A,C],
VCCPD[3,4,7,8]B

Power

Dedicated power pins. This supply is used to power the I/O pre­drivers and the input buffers for HSTL/SSTL input buffers. This
can be connected to (3.3 V Arria II GX only), 3.0 V or 2.5 V. For

3.3 V I/O standard connect VCCPD to 3.3 V, for 3.0 V I/O
standard connect VCCPD to 3.0 V and for 2.5 V/1.8 V/1.5 V/1.2 V
I/O standards connect VCCPD to 2.5 V.

The VCCPD pins require 2.5 V, 3.0 V,or (3.3 V, Arria II GX only) and must ramp-up from 0 V to 2.5 V, 3.0
V, or (3.3 V, Arria II GX only) within 100 ms to ensure successful configuration. When these pins require

2.5 V, 3.0 V, or (3.3 V, Arria II GX only) they may be tied to the same regulator as VCCIO, but only if each
of these supplies require the same voltage level. Decoupling for these pins depends on the design
decoupling requirements of the specific board. See Notes 3 and 6.

For Arria II GZ VCCPD must ramp-up from 0V to VCCPD within 100 ms when PORSEL is low or 4 ms
when PORSEL is high to ensure successful configuration. When these pins require 2.5V they may be tied
to the same regulator as VCC_CLKIN, VCCPGM and VCCIO, but only if each of these supplies require

2.5V sources. VCC_CLKIN has a set voltage of 2.5V, so excluding VCC_CLKIN you may tie these pins to
the same regulator as VCCPGM and/or VCCIO as long as they all require the same voltage. Also, when
these pins use 2.5V they may be sourced from the same regulator as VCCAUX and VCCA_PLL with a
proper isolation filter.

NA VCC_CLKIN[3,4,7,8]C Power

Differential clock input power supply for top and bottom I/O banks.
Connect to 2.5V.

Connect these pins to 2.5V power source. These pins may be tied to the same regulator as VCCIO,
VCCPGM and VCCPD, but only if each of these supplies require 2.5V sources. Decoupling for these pins
depends on the design decoupling requirements of the specific board. See Note 3.

For Arria II GZ, with a proper isolation filter these pins may be sourced from the same regulator as
VCCAUX and VCCA_PLL.

VCCBAT VCCBAT Power

Battery back-up power supply for design security volatile key
register.

Connect this pin to a Non-volatile battery power source in the range of (1.2 V - 3.3 V, for Arria IIGX) or 1.2
V - 3.0 V, for Arria II GZ) when using design security volatile key. 3.0 V is the typical power selected for
this supply. When not using the volatile key, tie this to a 3.0 V supply or GND. Do not share this source
with other FPGA power supplies.

GND GND Ground Device ground pins. All GND pins should be connected to the board ground plane.

VREF[3:8][A,B]N0 VREF[1:8][A,C],

VREF[3,4,7,8]B

Power

Input reference voltage for each I/O bank. If a bank uses a voltage­referenced I/O standard, then these pins are used as the voltage­reference pins for the bank. These pins cannot be used as regular

If VREF pins are not used, designers should connect them to either the VCCIO in the bank in which the
pin resides or GND. Decoupling depends on the design decoupling requirements of the specific board.
See Note 3.

NA VCCHIP_L Power

PCIe Hard IP digital power supply, specific to the left (L) side of
the device.

All VCCHIP_L pins require a 0.9V supply. When not using HIP these pins may be connected to GND.
These pins may be tied to the same 0.9V plane as VCC. With a proper isolation filter these pins may be
sourced from the same regulator as VCCD_PLL. Decoupling for these pins depends on the design
decoupling requirements of the specific board. See Notes 3 and 6.

NA VCCR_[L,R] Power

Analog power, receiver, specific to the left (L) side or right (R)
side of the device.

VCCR_[L,R] can be connected to a 1.1V linear or low noise switching regulator. These pins may be tied to
the same 1.1V plane as VCCL_GXB[L,R] and/or VCCT_[L,R]. However, for better jitter performance at
high data rates this plane should be isolated from all other power supplies. Decoupling for these pins
depends on the design decoupling requirements of the specific board design. See Notes 3, 6, 17, 18 and

19.

NA VCCT_[L,R] Power

Analog power, transmitter, specific to the left (L) side or right (R)
side of the device.

VCCT_[L,R] can be connected to a 1.1V linear or low noise switching regulator. These pins may be tied to
the same 1.1V plane as VCCL_GXB[L,R], and/or VCCR_[L,R]. However, for better jitter performance at
high data rates this plane should be isolated from all other power supplies. Decoupling for these pins
depends on the design decoupling requirements of the specific board design. See Notes 3, 6, 17, 18 and

19.

VCCL_GXB VCCL_GXB[L,R][0:2] Power

Supplies power to the transceiver PMA TX, PMA RX and clocking.

VCCL_GXB[L,R] can be connected to a 1.1V linear or low noise switching regulator. These pins may be
tied to the same 1.1V plane as VCCT_[L,R] and/or VCCR_[L,R]. However, for better jitter performance at
high data rates this plane should be isolated from all other power supplies. For the best jitter performance,
provide each quad its own power source. Decoupling for these pins depends on the design decoupling
requirements of the specific board design. See Notes 3, 6, 7 and 18.

Transceiver Pins (See Note 8)

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Pin Connection Guidelines Page 7 of 16

Arria II GX Pin Name Arria II GZ Pin Name

Pin Type (1st
and 2nd
Function)

Pin Description Connection Guidelines

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

You should create a Quartus® II design, enter your device I/O assignments and compile the design. The Quartus II software will check your pin connections with respect to I/O assignment and placement rules to ensure proper device
operation. These rules are dependent on device density, package, I/O assignments, voltage assignments and other factors that are not fully described in this document or the device handbook.

VCCH_GXB VCCH_GXB[L,R][0:2] Power Supplies power to the transceiver PMA output (TX) buffer.

Connect VCCH_GXB to a 1.5V power supply. These pins may be sourced from the same regulator as
VCCCB with a proper isolation filter. Decoupling for these pins depends on the design decoupling
requirements of the specific board design. See Notes 3, 6, 7 and 18.

For Arria II GX, use a linear regulator or switching power supplywith ±5 mV maximum voltage ripple. (See
Note 14)

For Arria II GZ, use a linear or low noise switching regulator.

VCCA VCCA_[L,R] Power Supplies power to the transceiver PMA regulator.

Decoupling depends on the design decoupling requirements of the specific board design. See Notes 3, 6,
7 and 18.

For Arria II GX, connect VCCA to a 2.5V linear regulator or switching power supply with ±5 mV
maximum voltage ripple. (See note 14) These pins may be sourced from the same linear regulator as
VCCA_PLL with a proper isolation filter.

For Arria II GZ, VCCA_[L,R] can be connected to a 2.5V or 3.0V linear or low noise switching regulator.
Connect these pins to 3.0V if the TX PLL and/or RX CDR are configured at a base data rate > 4.25Gbps.
Connect these pins to 2.5V or 3.0V if the TX PLL and/or RX CDR are configured at a base data rate ≤

4.25Gbps. For data rates ≤ 4.25Gbps, if VCCA_[L,R] is 2.5V these pins may be sourced from the same
linear regulator as VCCAUX and/or VCCA_PLL with a proper isolation filter.

GXB_RX[0:15]p GXB_RX_[L,R][0:11]p Input High speed positive differential receiver channels.

These pins may be AC-coupled or DC-coupled when used. (Note 4) Connect all unused GXB_RXp pins
either individually to GND through a 10-kΩ resistor or tie all unused pins together through a single 10-kΩ
resistor. Ensure that the trace from the pins to the resistor(s) are as short as possible. See Note 2.

GXB_RX[0:15]n GXB_RX_[L,R][0:11]n Input High speed negative differential receiver channels.

These pins may be AC-coupled or DC-coupled when used. (Note 4) Connect all unused GXB_RXn pins
either individually to GND through a 10-kΩ resistor or tie all unused pins together through a single 10-kΩ
resistor. Ensure that the trace from the pins to the resistor(s) are as short as possible. See Note 2.

GXB_TX[0:15]p GXB_TX_[L,R][0:11]p Output High speed positive differential transmitter channels. Leave all unused GXB_TXp pins floating. See Note 2.

GXB_TX[0:15]n GXB_TX_[L,R][0:11]n Output High speed negative differential transmitter channels. Leave all unused GXB_TXn pins floating. See Note 2.

REFCLK[0:7]p

REFCLK_[L,R][0:5]p,
GXB_CMURX_[L,R][0:5]p

Input High speed differential reference clock positive.

These pins should be AC-coupled when used (see Note 5). Connect all unused pins either individually to
GND through a 10-kΩ resistor or tie all unused pins together through a single 10-kΩ resistor. Ensure that
the trace from the pins to the resistor(s) are as short as possible.

REFCLK[0:7]n

REFCLK_[L,R][0:5]n,
GXB_CMURX_[L,R][0:5]n

Input High speed differential reference clock complement.

These pins should be AC-coupled when used (see Note 5). Connect all unused pins either individually to
GND through a 10-kΩ resistor or tie all unused pins together through a single 10-kΩ resistor. Ensure that
the trace from the pins to the resistor(s) are as short as possible.

RREF[0:1] RREF_[L,R][0:1] Input Reference resistor for transceiver.

If any REFCLK pin or transceiver channel on one side (left or right) of the device is used, you must
connect each RREF pin on that side of the device to its own individual 2.00-kΩ +/- 1% resistor to GND.
Otherwise, you may connect each RREF pin on that side of the device directly to GND. In the PCB layout,
the trace from this pin to the resistor needs to be routed so that it avoids any aggressor signals.

3) Capacitance values for the power supply should be selected after consideration of the amount of power they need to supply over the frequency of operation of the particular circuit being decoupled. A target impedance for the power
plane should be calculated based on current draw and voltage droop requirements of the device/supply. The power plane should then be decoupled using the appropriate number of capacitors. On-board capacitors do not decouple
higher than 100 MHz dueto “Equivalent Series Inductance” of the mounting of the packages. Proper board design techniques such as interplane capacitance with low inductance should be considered for higher frequency decoupling. To
assist in decoupling analysis Altera's Power Distribution Network (PDN) design tool serves as an excellent decoupling analysis tool.

2) Transceiver signals GXB_RX[0:15] and GXB_TX[0:15] are device specific.

1) This pin connection guideline is created based on the Arria II GX and Arria II GZ devices. Shaded cells indicate pin name differences between the Arria II GX and Arria II GZ.

8) Refer to Example 1 and Figure 1 on the "Power Regs" tab below for the minimum power supply regulator recommendations.

6) Use the Arria II GX or Arria II GZ Early Power Estimator to determine the current requirements for VCC and other power supplies.

9) PLL[1,3]_CLKOUT[2:3]p/n are only available in PLL1 and PLL3 in EP2AGX95, EP2AGX125, EP2AGX190, and EP2AGX260.

Notes:

Power Distribution Network Design Tool

Altera provides these guidelines only as recommendations. It is the responsibility of the designer to apply simulation results to the design to verify proper device functionality.

4) For AC-coupled links, the AC-coupling capacitor can be placed anywhere along the channel. PCI Express protocol requires the AC-coupling capacitor to be placed on the transmitter side of the
interface that permits adapters to be plugged and unplugged.

5) In PCI Express configuration, DC-coupling is allowed on REFCLK if the selected REFCLK I/O standard is HCSL (High-Speed Current Steering Logic).

7) These supplies may share power planes across multiple Arria II GX or Arria II GZ devices.

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Pin Connection Guidelines Page 8 of 16

Arria II GX Pin Name Arria II GZ Pin Name

Pin Type (1st
and 2nd
Function)

Pin Description Connection Guidelines

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

You should create a Quartus® II design, enter your device I/O assignments and compile the design. The Quartus II software will check your pin connections with respect to I/O assignment and placement rules to ensure proper device
operation. These rules are dependent on device density, package, I/O assignments, voltage assignments and other factors that are not fully described in this document or the device handbook.

19) Low Noise Switching Regulator - defined as a switching regulator circuit encapsulated in a thin surface mount package containing the switch controller, power FETs, inductor, and other support components. The switching frequency
is usually between 800kHz and 1MHz and has fast transient response.
Line Regulation < 0.4%
Load Regulation < 1.2%

18) If one or more transceivers are used on a particular side of the device (left [L] or right [R]) all of the transceiver power pins on that side of the device must be connected to its required power supply. However, if none of the
transceivers are used on one side then the transceiver power pins on that side may be tied to GND. In this case, all of the GXB_RX pins need to be connected to GND as well.

17) Altera highly recommends using an independent PCB via for each independent power or ground ball on the package. Sharing power or ground pin vias on the PCB could lead to noise coupling into the device and result in reduced
jitter performance.

14) For Arria II GX, VCCA_PLL, VCCCB, VCCA and VCCH_GXB may use a switching regulator with a voltage ripple of ±5 mV maximum.

12) For Arria II GX some of these pins are assigned to a group of 16 I/O pins. These groups are referred to as I/O modules. Refer to the"I/O module" column in the pin tables to determine which pins are grouped together. The following
guideline must be adhered to for each of the I/O modules.

a) A maximum of 12 HSTL/SSTL output or bidirectional pins are allowed per I/O module. When assigning 12 HSTL/SSTL output or bidirectional pins in a module the remaining 4 pins must be input only. Differential assignment is not

available in this case.

b) When 11 or fewer HSTL/SSTLoutput or bidirectional pins are assigned to an I/O module, then differential HSTL/SSTL output or bidirectional assignments are available for the remaining pins. If any pins remain after this assignment,

then upto the first 4 pins must be input only. If there are more than 4 pins, these remaining pins may be input , output or bidirectional.

13) The LVDS bank utilization limits the percentage of pins used based on the current setting and I/O standard. For the best jitter performance, adhere to the following guidelines:

- 100% of the pins in the bank can be used when using 2.5V LVTTL 4 mA, 50 Ω or 25 Ω, SSTL2.5V CI 8 mA and 12 mA

- 90% of the pins in the bank can be used when using 2.5V LVTTL 8 mA

- 60% of the pins in the bank can be used when using 2.5V LVTTL 12 mA

- 50% of the pins in the bank can be used when using 2.5V LVTTL 16 mA

- 60% of the pins in the bank can be used when using SSTL2.5V CII 16 mA

- If the bank contains mixture of 2.5V I/O Standards, the equation to use is

11) When not used as clocks, the CQn and DQSn pins can be used as DQ pins.

Where n = number of different I/O standards, for example: n = 2 if there are SSTL2.5V CII 16 mA and 2.5V LVTTL 16 mA in the bank
a = number of aggressors with that particular I/O standard
b = percentage of aggressor that can be toggle for that specific I/O standard, for example: b = 50% for 2.5V LVTTL 16 mA

c = (total pins in that bank – number of LVDS pins)

16) All dedicated configuration pins reside in banks 3C and 8C. However, dual function (I/O and config) configuration pins may be located in banks 3A, 6A, or 8A.

15) Unused I/O pins need to be tied high, tristated or tied low to match your Quartus II design.

10) Some of the pull-up /pull-down resistors mentioned in the table above may not be required, depending on the exact device configuration scheme. The ability to NC or short them may be valuable during
the debug phase, should you be required to use a different configuration scheme. Refer to the Configuring Arria II GX Devices chapter in the Arria II GX Device Handbook for more information.

%100

1

1

c

b

a

N

n

n



















PCG-01007-1.5
Copyright © 2011 Altera Corp.

Pin Connection Guidelines Page 9 of 16

Power

Pin Name

Regulator

Count

Voltage

Level (V)

Supply

Tolerance

Power

Source

Regulator

Sharing

Notes

VCC (See Note 1)

Share

VCCD_PLL[1:6]

Isolate

VCCL_GXB

2

1.1 ± 5 %

Linear or
Switcher

Share

Depending on the regulator capabilities this supply may be shared with multiple Arria II GX devices. Use the EPE
(Early Power Estimation) tool within Quartus II to assist in determining the power required for your specific
design.

VCCH_GXB

Share

VCCCB (See Note 1)

Isolate

VCCA

VCCA_PLL_[1:6]
VCCIO[3:8][A,B],

VCCIO[3,8]C

Varies

VCCPD[3:8][A,B],
VCCPD[3,8]C

2.5, 3.0,
or 3.3

Note:

1) To support the startup current as reported by the Early Power Estimator (EPE) for Arria II GX devices, fully power VCC before VCCCB begins to ramp.
* When using a switcher to supply these voltages the switcher must be a low noise switcher as defined in note 19 in the Pin Connection Guidelines sheet.

Example Requiring 5 Power Regulators

Share

Share

if 2.5 V, 3.0 V or

3.3 V

4

May be able to share VCCD_PLL with VCC with a proper isolation filter. If not sharing the regulator with VCC the
VCCD_PLL supply should not exceed a tolerance of ± 5%.

3

5

If all of these supplies require 2.5 V, 3.0 V or 3.3 V and the regulator selected satisfies the power specifications
then these supplies may all be tied in common. Use the EPE tool to assist in determining the power required for
your specific design.

May be able to share VCCA_PLL and VCCA with a proper isolation filter. Depending on the regulator capabilities
this supply may be shared with multiple Arria II GX devices. Use the EPE tool to assist in determining the power
required for your specific design.

Linear or

Switcher (*)

May be able to share VCCCB with VCCH_GXB with a proper isolation filter. Depending on the regulator
capabilities this supply may be shared with multiple Arria II GX devices. Use the EPE tool to assist in
determining the power required for your specific design. If not sharing a regulator the VCCH_GXB supply should
not exceed a tolerance of ± 5%.

± 5 %

Switcher

Linear or

Switcher (*)

± 5 %

± 5 %

Each board design requires its own power analysis to determine the required power regulators needed to satisfy the specific board design requirements. An example block diagram is provided in Figure 1.

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

2.5

Switcher

± 30 mV

0.9

1.5

Example 1. Arria II GX Power Supply Sharing Guidelines

1

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Arria II GX Page 10 of 16

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

Figure 1. Example Arria II GX Power Supplies Block Diagram

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Arria II GX Page 11 of 16

Power

Pin Name

Regulator

Count

Voltage

Level (V)

Supply

Tolerance

Power

Source

Regulator

Sharing

Notes

VCC (**)

VCCHIP_L

VCCD_PLL_[L,R][1:4],
VCCD_PLL_[T,B][1:2]

Isolate

May be able to share VCCD_PLL with VCC and VCCHIP
with a proper isolation filter. If not sharing the regulator with VCC and/or VCCHIP the VCCD_PLL supply should
not exceed a tolerance of ± 5%.

VCCIO[1:8][A,C],
VCCIO[3,4,7,8]B

VCCPD[1:8][A,C],
VCCPD[3,4,7,8]B

VCCPGM

VCC_CLKIN[3,4,7,8]C

2.5

VCCR_[L,R]

VCCT_[L,R]
VCCL_GXB[L,R][0:2]

VCCH_GXB[L,R][0:2]

VCCCB

VCCA_PLL_[L,R][1:4],
VCCA_PLL_[T,B][1:2]

VCCAUX (**)

VCCA_[L,R]

** To successfully power-up and exit POR, fully power VCC before VCCAUX begins to ramp.

± 5%

Linear or

Switcher (*)

VCCAUX, VCCA_[L,R] and VCCA_PLL may be able to share a regulator with the proper isolation filter.
Depending on the regulator capabilities this supply may be shared with multiple Arria II GZ devices. Use the EPE
tool to assist in determining the power required for your specific design.

* When using a switcher to supply these voltages the switcher must be a low noise switcher as defined in note 19 in the Pin Connection Guidelines sheet.

5

Each board design requires its own power analysis to determine the required power regulators needed to satisfy the specific board design requirements. An example block diagram using the Arria II GZ device for
data rates less than or equal to 4.25Gbps is provided in Figure 2.

4

1.5

± 50mV

Linear or

Switcher (*)

Share

May be able to share VCCCB with VCCH_GXB with a proper isolation filter. Depending on the regulator
capabilities this supply may be shared with multiple Arria II GZ devices. Use the EPE tool to assist in determining
the power required for your specific design. If not sharing a regulator the VCCH_GXB supply should not exceed a
tolerance of ± 5%.

Isolate/Share

2.5

3

1.1

± 50mV

Linear or

Switcher (*)

Share

The left [L] and [R] may share the same regulator. Depending on the regulator capabilities this supply may be
shared with multiple Arria II GZ devices. Use the EPE (Early Power Estimation) tool within Quartus II to assist in
determining the power required for your specific design.

2

Varies

± 5%

Switcher

Share

if 2.5V

If all of these supplies require 2.5V and the regulator selected satisfies the power specifications then these
supplies may all be tied in common. However, for any other voltage you will require a 2.5V regulator for
VCC_CLKIN and as many regulators as there are variations of supplies in your specific design. Use the EPE tool
to assist in determining the power required for your specific design.

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

Example 2. Arria II GZ Power Supply Sharing Guidelines for Data Rates <= 4.25 Gpbs

Example Requiring 5 Power Regulators

1

0.9

± 30mV

Switcher

Share

VCC and VCCHIP may share regulators.

If not using HIP, VCCHIP may be tied to GND.
PCG-01007-1.5
Copyright © 2011 Altera Corp.

Arria II GZ Pwr Regs <=4.25Gbps Page 12 of 16

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

Figure 2. Example Arria II GZ Power Supplies Block Diagram for Data Rates <= 4.25 Gpbs

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Arria II GZ Pwr Regs <=4.25Gbps Page 13 of 16

Power

Pin Name

Regulator

Count

Voltage

Level (V)

Supply

Tolerance

Power

Source

Regulator

Sharing

Notes

VCC (**)

VCCHIP_L

VCCD_PLL_[L,R][1:4],

VCCD_PLL_[T,B][1:2]

Isolate

May be able to share VCCD_PLL with VCC and VCCHIP

with a proper isolation filter. If not sharing the regulator with VCC and/or VCCHIP the VCCD_PLL supply should

not exceed a tolerance of ± 5%.

VCCIO[1:8][A,C],

VCCIO[3,4,7,8]B

VCCPD[1:8][A,C],

VCCPD[3,4,7,8]B

VCCPGM

VCC_CLKIN[3,4,7,8]C

VCCAUX (**)

VCCA_PLL_[L,R][1:4],

VCCA_PLL_[T,B][1:2]

VCCR_[L,R]

VCCT_[L,R]

VCCL_GXB[L,R][0:2]

VCCH_GXB[L,R][0:2]

VCCCB

VCCA_[L,R]

5

3.0 ± 5%

Linear or

Switcher (*)

Share

Depending on the regulator capabilities this supply may be shared with multiple Arria II GZ devices. Use the EPE

tool to assist in determining the power required for your specific design.

** To successfully power-up and exit POR, fully power VCC before VCCAUX begins to ramp.

2.5

Share

if 2.5V

Isolate/Share

If all of these supplies require 2.5V and the regulator selected satisfies the power specifications then these

supplies may all be tied in common. However, for any other voltage you will require a 2.5V regulator for

VCC_CLKIN and as many regulators as there are variations of supplies in your specific design. Use the EPE tool

to assist in determining the power required for your specific design.

VCCAUX and VCCA_PLL may be able to share a regulator with the proper isolation filter.

Each board design requires its own power analysis to determine the required power regulators needed to satisfy the specific board design requirements. An example block diagram using the Arria II GZ device for

data rates between 4.25 Gbps and 6.375 Gbps is provided in Figure 3.

May be able to share VCCCB with VCCH_GXB with a proper isolation filter. Depending on the regulator

capabilities this supply may be shared with multiple Arria II GZ devices. Use the EPE tool to assist in determining

the power required for your specific design. If not sharing a regulator the VCCH_GXB supply should not exceed

a tolerance of ± 5%.

3

1.1

* When using a switcher to supply these voltages the switcher must be a low noise switcher as defined in note 19 in the Pin Connection Guidelines sheet.

Linear or

Switcher (*)

Share

4

1.5

± 50mV

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

Example 3. Arria II GZ Power Supply Sharing Guideline for Data Rates Between 4.25 Gbps and 6.375 Gbps

Example Requiring 5 Power Regulators

1

0.9

2

Varies

± 5%

Switcher

Share

VCC and VCCHIP may share regulators.

If not using HIP, VCCHIP may be tied to GND.

± 30mV

Switcher
Linear or

Switcher (*)

Share

± 50mV

The left [L] and [R] may share the same regulator. Depending on the regulator capabilities this supply may be

shared with multiple Arria II GZ devices. Use the EPE (Early Power Estimation) tool within Quartus II to assist in

determining the power required for your specific design.

PCG-01007-1.5
Copyright © 2011 Altera Corp.

AIIGZ Pwr Regs>4.25Gbps<=6.375G Page 14 of 16

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

Figure 3. Example Arria II GZ Power Supplies Block Diagram for data rates between 4.25 Gbps and 6.375 Gbps

PCG-01007-1.5
Copyright © 2011 Altera Corp.

AIIGZ Pwr Regs>4.25Gbps<=6.375G Page 15 of 16

Revision Description of Changes Date

1.0

Initial Release.

2/8/2009

1.1

Added DNU pins and updated NC guidelines, added note 17, updated Power Regs diagram, updated note

references.

5/18/2009

1.2

Removed Note 12a, Note 12b becomes Note 12a, added 1.5 V level to VCCPD

11/2/2009

1.3

Updated Note 13

1/29/2010

1.4

Added Arria II GZ device information. Changed the title of the document. Added table and diagram for Arria II GZ

device.

11/2/2010

1.5

Added VCCAUX to GZ pin name field, updated Note 9, PLL_[1,3]_CLKOUT[2:3]p/n pin description, updated

TMS/TDI/VCC/VCCCB connection guidelines, updated Example 2 and Example 3

VCCR_[L,R]/VCCT_[L,R]/VCCL_GXB[L,R][0:2] supply tolerance. Removed Preliminary.

6/28/2011

Revision History

Arria® II Device Family Pin Connection Guidelines

PCG-01007-1.5

PCG-01007-1.5
Copyright © 2011 Altera Corp.

Rev History Page 16 of 16
