Altera MasterBlaster User Manual

MasterBlaster Serial/USB

Communications Cable User Guide

101 Innovation Drive San Jose, CA 95134 www.altera.com

Software Version: 80 Document Version: 1.1 Document Date: © July 2008

Copyright © 2008 Altera Corporation. All rights reserved. Altera, The Programmable Solutions Company, the stylized Altera logo, specific device designations, and all other words and logos that are identified as trademarks and/or service marks are, unless noted otherwise, the trademarks and service marks of Altera Corporation in the U.S. and other countries. All other product or service names are the property of their respective holders. Altera products are protected under numerous U.S. and foreign patents and pending applications, maskwork rights, and copyrights. Altera warrants performance of its semiconductor products to current specifications in accordance with Altera's standard warranty, but reserves the right to make changes to any products and services at any time without notice. Altera assumes no responsibility or liability arising out of the application or use of any information, product, or service described herein except as expressly agreed to in writing by Altera Corporation. Altera customers are advised to obtain the latest version of device specifications before relying on any published information and before placing orders for products or services

UG-MB81204-1.1 P25-10322-00

Chapter 1. Installing the MasterBlaster Serial/USB Communications Cable

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–1

Installation on a Windows PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–2

Installation on a Linux or UNIX Workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–3

Selecting the MasterBlaster Cable for the SignalTap

Chapter 2. MasterBlaster Serial/USB Communications Cable Data Sheet

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1

Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–1

Download Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

SignalTap II Logic Analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–2

MasterBlaster Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–3

Header & Plug Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–3

Powering the MasterBlaster Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–4

Circuit Board Header Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5

LED Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5

Operating Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5

References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–7

II Logic Analyzer . . . . . . . . . . . . . . . . . . . . . . . . 1–4

Chapter Info. Additional Information

Referenced Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Info–1

Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Info–1

How to Contact Altera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Info–1

Typographic Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Info–2

MasterBlaster Serial/USB Communications Cable User Guide © July 2008 Altera Corporation

List of Figures v

List of Figures

Figure 1–1: MasterBlaster Serial/USB Communications Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Figure 1–2: The Hardware Setup Dialog Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Figure 2–1: MasterBlaster Serial/USB Communications Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2

Figure 2–2: MasterBlaster 10-Pin Female Plug Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Figure 2–1: 10-Pin Male Header Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

vi List of Figures

MasterBlaster Serial/USB Communications Cable User Guide © July 2008 Altera Corporation

List of Tables vii

List of Tables

Table 2–1: MasterBlaster 9-Pin Serial D-Type Connector Pin-Outs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3

Table 2–2: MasterBlaster Female Plug’s Pin Names & Download Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4

Table 2–1: LED Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5

Table 2–2: MasterBlaster Cable Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Table 2–3: MasterBlaster Cable Recommended Operating Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

Table 2–4: MasterBlaster Cable DC Operating Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6

viii List of Tables

MasterBlaster Serial/USB Communications Cable User Guide © July 2008 Altera Corporation

Introduction

1. Installing the MasterBlaster

Serial/USB Communications Cable

The MasterBlasterTM serial/USB communications cable is a download cable that allows PC and workstation users to program and configure devices in-system. The MasterBlaster cable provides multi-device JTAG chain configuration and programming support for SRAM-based devices, such as APEX devices, EEPROM-based devices, such as MAX

3000 and MAX 7000 devices, and configuration devices, such as the EPC2 and EPC16. You can also use the MasterBlaster cable to run SignalTap

II logic analysis. The MasterBlaster cable also provides multi-device passive serial (PS) chain configuration support for SRAM-based devices, such as APEX 20K and Mercury devices. This cable can be used in 2.5-, 3.3-, and 5.0-V systems.

Altera® offers a variety of hardware to program and configure Altera devices. For conventional device programming, in-system programming, and in-circuit reconfiguration, designers can choose from a wide range of programming hardware options.

This user guide provides the following information about the MasterBlaster serial/USB communications cable.

20K and MercuryTM

™

Installation

1 The Quartus II software version 8.1 and later will no longer support MasterBlaster

■ How to install the cable and its driver software

■ How to use the cable after installation

■ A complete list of the cable’s features

■ A functional description of the cable

The MasterBlaster communications cable connects a circuit board to the USB (Windows 2000, Windows XP x32 edition, and Windows Vista x32 edition only) or RS232 serial port (called a COM port on a PC) on a PC, UNIX, or Linux workstation. The 10-pin female plug for the cable connects to a 10-pin male header on the circuit board that contains the target device(s), as shown in Figure 1–1. Programming or configuration data can be downloaded from the serial or USB port, using the Quartus II Programmer, through the MasterBlaster cable to the circuit board through these connections.

communication cable.

The MasterBlaster communications cable receives power from any one of the following sources:

■ 5.0- or 3.3-V circuit boards

■ 5.0 V from the USB cable (Windows 2000, Windows XP x32 edition, and Windows

Vista x32 edition only)

1–2 Chapter 1: Installing the MasterBlaster Serial/USB Communications Cable

■ DC power supply, which is supplied with the MasterBlaster communications cable

The MasterBlaster cable connects to a computer through a serial or USB port, and connects to the circuit board through a standard 10-pin female connector.

Installation on a Windows PC

To install and set up the MasterBlaster cable for device configuration or programming on a Windows PC, follow these steps:

1. Connect one end of a standard RS-232 cable or a standard USB cable, to the

MasterBlaster cable and connect the other end to the appropriate port on the computer.

1 If you are using the MasterBlaster communications cable with the USB port, the

Windows 2000, Windows XP, or Windows Vista operating system prompts you to locate the MasterBlaster USB driver mblaster.inf file. The MasterBlaster driver is located in your \<Quartus II system directory>\drivers directory.

2. Connect the 16-pin female header end of the cable to the 16-pin male MasterBlaster

port, and the 10-pin female end of the cable to the 10-pin male header on the target printed circuit board. Figure 1–1 shows the MasterBlaster serial/USB communications cable.

Figure 1–1. MasterBlaster Serial/USB Communications Cable

3. Open the Quartus II Programmer. Choose Programmer (Tools menu) or choose

New (File menu). Click the Other Files tab, select Chain Description File, and

click OK.

4. In the Programmer window, click Hardware Setup. The Hardware Settings tab of

the Hardware Setup dialog box is displayed.

5. Click Add Hardware. The Add Hardware dialog box is displayed.

6. In the Hardware type list, select either MasterBlaster (COM) or MasterBlaster

(USB).

MasterBlaster Serial/USB Communications Cable User Guide © July 2008 Altera Corporation

Chapter 1: Installing the MasterBlaster Serial/USB Communications Cable 1–3

Installation

1 The USB option is available only for Windows 2000, Windows XP x32 edition and

Windows Vista x32 edition systems.

1 The COM option is available only for Windows 2000, Windows XP x32 edition,

Windows XP x64 edition and Windows Vista x32 edition systems.

7. In the Port list, select the appropriate port.

8. If you are using a serial port, in the Baud rate list, select a baud rate appropriate

for your computer.

9. Click OK to close the Add Hardware dialog box. You will see MasterBlaster in the

Available hardware items section of the Hardware Setup dialog box.

10. Click on MasterBlaster to highlight it, then click on the Select Hardware button to

the right of the Available hardware items section. You w il l no w se e MasterBlaster and your selected port in the Currently selected hardware section of the window, as shown in Figure 1–2.

11. Click Close to close the Hardware Setup dialog box.

Figure 1–2. The Hardware Setup Dialog Box

12. Close the Programmer window.

Installation on a Linux or UNIX Workstation

To install and set up the MasterBlaster cable for device configuration or programming on a Linux or UNIX Workstation, follow these steps:

1. With a standard RS-232 cable, connect one end of the cable to the MasterBlaster

cable, and connect the other end of the cable to the appropriate port on the computer.

2. Connect the 16-pin female header end of the cable to the 16-pin male MasterBlaster

port, and the 10-pin female end of the cable to the 10-pin male header on the target printed circuit board, as shown in Figure 1–1.

1–4 Chapter 1: Installing the MasterBlaster Serial/USB Communications Cable

3. Open the Quartus II Programmer. Choose Programmer (Tools menu) or choose

New (File menu). Click the Other Files tab, select Chain Description File, and

click OK.

4. In the Programmer window, click Hardware Setup. The Hardware Settings tab of

the Hardware Setup dialog box is displayed.

5. Click Add Hardware. The Add Hardware dialog box is displayed.

6. In the Hardware type list, select MasterBlaster.

7. In the Port box, select the name of the appropriate serial port. Also, make sure you

have read and write permission for the serial port.

8. In the Baud rate list, select a baud rate that is appropriate for your computer.

9. Click OK.

10. In the Hardware Setup dialog box, click Close.

Selecting the MasterBlaster Cable for the SignalTap II Logic Analyzer

To select the MasterBlaster communications cable for the SignalTap II Logic Analyzer, follow these steps.

1. Choose SignalTap II Logic Analyzer (Tools menu). The SignalTap window will

open.

2. Under JTAG Chain Configuration, select MasterBlaster in the Hardware

pull-down list.

If the MasterBlaster cable does not appear in the Hardware list, continue as follows:

1. Under JTAG Chain Configuration, click Setup.

2. Click Add Hardware in the Hardware Setup dialog box to add a hardware setup

for the MasterBlaster cable.

3. Click Add Hardware in the Hardware Setup dialog box to add a hardware setup

for the communications cable.

f For more information about SignalTap II logic analysis with the MasterBlaster cable,

refer to Selecting the Communications Cable for the SignalTap II Logic Analyzer in the Quartus II Help.

MasterBlaster Serial/USB Communications Cable User Guide © July 2008 Altera Corporation

Features

2. MasterBlaster Serial/USB

Communications Cable Data Sheet

■ Supports SignalTap

■ Allows PC, Linux, and UNIX users to perform the following functions:

■ Configure Stratix

Cyclone

10K, FLEX 3000A, FLEX 6000, FLEX 8000 devices, and ExcaliburTM embedded processor solutions

■ Program MAX

EPC4, EPC8, and EPC16 devices in-system

■ Supports operation with VCC at 5.0 V, 3.3 V, or 2.5 V

■ Provides a fast, low-cost method for in-system programming

■ Downloads data from the Quartus II development software and the MAX+PLUS

II software versions 9.3 and higher

II logic analysis in the Altera® Quartus® II software

IV, Stratix III, Stratix II, Stratix II GX, Stratix, Stratix GX,

III, Cyclone II, Cyclone, MercuryTM, APEXTM II, APEX 20K, FLEX®

II, MAX 9000, MAX 7000S, MAX 7000B, MAX 7000A, EPC2,

■ Interfaces with an RS-232 serial or universal serial bus (USB) port

■ Uses a 10-pin circuit board connector

Functional Description

The MasterBlasterTM serial/USB communications cable (ordering code: PL-MASTERBLASTER) is a standard PC serial or USB port hardware interface (see

Figure 2–1). This cable downloads configuration data to Stratix IV, Stratix III, Stratix

II, Stratix II GX, Stratix, Stratix GX, Cyclone III, Cyclone II, Cyclone, Mercury, APEX II, APEX 20K (including APEX 20K, APEX 20KE, and APEX 20KC), FLEX 10K (including FLEX 10KA and FLEX 10KE), FLEX 8000, and FLEX 6000 devices, as well as programming data to MAX II, MAX 9000, MAX 7000S, and MAX 7000A (including MAX 7000AE) devices. Because design changes are downloaded directly to the device, prototyping is easy and multiple design iterations can be accomplished in quick succession. The MasterBlaster cable also supports in-circuit debugging with the SignalTap II embedded logic analyzer in Stratix, APEX II, and APEX 20K devices.

2–2 Chapter 2: MasterBlaster Serial/USB Communications Cable Data Sheet

Figure 2–1. MasterBlaster Serial/USB Communications Cable

Functional Description

Download Modes

The MasterBlaster cable provides two download modes:

■ Passive serial mode (PS)—In this mode the Quartus II Programmer can configure

all Altera devices supported by the Quartus II software except MAX 3000 and MAX 7000 devices.

■ JTAG mode—Industry-standard IEEE Std. 1149.1 Joint Test Action Group (JTAG)

interface for programming JTAG-capable devices. In JTAG mode, the Quartus II Programmer can program or configure all Altera devices supported by the Quartus II software, except FLEX 6000 devices. FLEX 6000 devices can be in a JTAG chain, but they must be bypassed; they cannot be configured. The Quartus II Programmer can also program EPC2, EPC4, EPC8, and EPC16 configuration devices in this mode. The JTAG chain can contain any number and combination of Altera and non-Altera devices that comply with this IEEE 1149.1 specification.

SignalTap II Logic Analysis

The SignalTap II logic analysis enables captured device data at specified trigger points and stores the data in APEX II and APEX 20K embedded system blocks (ESBs). This data is then sent to the JTAG IEEE Std. 1149.1 port of an APEX II or APEX 20K device, uploaded through the MasterBlaster communications cable, and displayed in the Quartus II Waveform Editor.

f For more information on SignalTap logic analysis, see the Design Debugging using the

SignalTap II Embedded Logic Analyzer chapter in volume 3 of the Quartus II Handbook.

MasterBlaster Serial/USB Communications Cable User Guide © July 2008 Altera Corporation

Chapter 2: MasterBlaster Serial/USB Communications Cable Data Sheet 2–3

Functional Description

MasterBlaster Connections

The MasterBlaster cable connects to a computer through a serial or USB port and connects to the circuit board through a standard 10-pin female connector. Data is downloaded from the serial or USB port through the MasterBlaster cable to the circuit board through the connections discussed in this section.

Header & Plug Connections

The 9-pin male D-type connector connects to an RS-232 port with a standard serial cable. See Table 2–1.

1 The USB connector can be used with any standard USB cable.

Table 2–1. MasterBlaster 9-Pin Serial D-Type Connector Pin-Outs

Pin Signal Name Description

2 rx Receive data

3 tx Transmit data

4 dtr Data terminal ready

5 GND Signal ground

6 dsr Data set ready

7 rts Request to send

8 cts Clear to send

f For more information on 9-pin versus 25-pin serial connectors, search for “9-pin or 25-

pin serial connectors” in the Altera solutions database at www.altera.com.

The 10-pin female plug connects to a 10-pin male header on the circuit board containing the target device(s). Figure 2–2 shows the dimensions of the female plug.

2–4 Chapter 2: MasterBlaster Serial/USB Communications Cable Data Sheet

0.250 Typ.

0.700 Typ.

0.425 Typ.

0.100 Sq.

234

789

0.025 Sq.

Functional Description

Figure 2–2. MasterBlaster 10-Pin Female Plug Dimensions

olor Stri

Dimensions are shown in inches. The spacing between pin centers is 0.1 inches.

Tab le 2 –2 identifies the 10-pin female plug’s pin names for the corresponding

download mode.

Table 2–2. MasterBlaster Female Plug’s Pin Names & Download Modes

Pin PS Mode JTAG Mode

Signal Name Description Signal Name Description

1 dclk Clock signal tck Clock signal

2 gnd Signal ground gnd Signal ground

3 CONF_DONE Configuration control tdo Data from device

4 V

Power supply V

5 nCONFIG Configuration control tms JTAG state machine control

6 V

Reference voltage for

MasterBlaster output driver

7 nstatus Configuration status – No connect

8 – No connect – No connect

9 data0 Data to device tdi Data to device

10 gnd Signal ground gnd Signal ground

Powering the MasterBlaster Cable

The MasterBlaster cable can receive power from the following sources:

Power supply

Reference voltage for MasterBlaster output driver

■ 5.0- or 3.3-V circuit boards

MasterBlaster Serial/USB Communications Cable User Guide © July 2008 Altera Corporation

■ DC power supply

■ 5.0 V from the USB cable

Chapter 2: MasterBlaster Serial/USB Communications Cable Data Sheet 2–5

0.025 Sq.

0.235

0.100

Side View

0.100

Top View

Operating Conditions

When 5.0- or 3.3-V power is not available on the circuit board, the MasterBlaster cable can be powered by either DC power or the USB cable.

1 For the MasterBlaster cable’s output drivers, connect the circuit board’s V

ground to the MasterBlaster cable’s VCC, VIO, and GND pins.

Circuit Board Header Connection

The MasterBlaster cable’s 10-pin female plug connects to a 10-pin male header on the circuit board. The 10-pin male header has two rows of five pins, which are connected to the device’s programming or configuration pins. Figure 2–1 shows the dimensions of a typical 10-pin male header.

1 Although a 10-pin surface mount header can be used for the JTAG, AS or PS

download cable, Altera recommends using a through-hole connector due to the repeated insertion and removal force needed.

Figure 2–1. 10-Pin Male Header Dimensions

and

LED Status

The purpose of the LED indicator lights located on the MasterBlaster download cable is to provide information about the status of the MasterBlaster cable. Ta bl e 2 –1 lists the indicator and status of the MasterBlaster cable.

Table 2–1. LED Status Indicator

Color Blink Frequency Description

Green Slow Cable ready

Green Fast Performing a logic analysis

Amber Slow Programming in progress

Operating Conditions

Tab le 2 –2 through 2–6 summarize the absolute maximum ratings, recommended

operating conditions, and DC operating conditions for the MasterBlaster cable.

2–6 Chapter 2: MasterBlaster Serial/USB Communications Cable Data Sheet

Operating Conditions

Table 2–2. MasterBlaster Cable Absolute Maximum Ratings

Symbol Parameter Conditions Min Max Unit

Supply voltage With respect to ground –0.5 7.0 V

DC input voltage With respect to ground –0.5 7.0 V

Table 2–3. MasterBlaster Cable Recommended Operating Conditions (Note 1), (2)

Symbol Parameter Conditions Min Max Unit

Board header supply voltage,

—4.55.5V

5.0-V operation

Board header supply voltage,

—3.03.6V

3.3-V operation

Notes for Tab le 2–3

(1) The DC adapter supply voltage has a minimum value of 3.0 V, a maximum value of 16.0 V, and a power consumption of 1 W (VCC can be at 5.0

V, 3.3 V, or 2.5 V).

(2) The 5.0-V USB cable supply voltage has a minimum value of 4.5 V and a maximum value of 5.5 V (VCC can be at 5.0 V, 3.3 V, or 2.5 V).

Table 2–4. MasterBlaster Cable DC Operating Conditions

Symbol Parameter Conditions Min Max Unit

High-level input voltage VCC = V

Low-level input voltage VCC = V

5.0-V high-level TTL

0.25 ¥ VIO + 0.3 V V

0.25 ¥ V

TTL load. VCC = VIO = 4.5 V, IOH=8mA 3.2 V

output voltage

3.3-V high-level TTL

TTL load. V

= VIO = 3.0 V, IOH=4mA 2.4 V

output voltage

5.0-V high-level CMOS output voltage

3.3-V high-level CMOS output voltage

2.5-V high-level CMOS output voltage

5.0-V low-level TTL output

CMOS load. V

=0.1mA

CMOS load. V

=0.1mA

CMOS load. V

=0.1mA

= VIO = 4.5 V,

= VIO = 3.0 V,

= VIO = 2.3 V,

TTL load. VCC = VIO = 4.5 V, IOL=8mA 0.4 V

4.0 V

2.7 V

2.0 V

voltage

3.3-V low-level TTL output

TTL load. V

= VIO = 3.0 V, IOL=4mA 0.4 V

voltage

5.0-V low-level CMOS output voltage

3.3-V low-level CMOS output voltage

2.5-V low-level CMOS output voltage

CMOS load. V

=0.1mA

CMOS load. V

=0.1mA

CMOS load. V

=0.1mA

= VIO = 4.5 V,

= VIO = 3.0 V,

= VIO = 2.3 V,

0.1 V

P Operating power 1.0 W

Chapter 2: MasterBlaster Serial/USB Communications Cable Data Sheet 2–7

References

For more information on configuration and in-system programmability (ISP), see the following sources:

■

The Altera Configuration Handbook

■

AN 95: In-System Programmability in MAX Devices

■

AN 100: In-System Programmability Guidelines

■

APEX 20K Programmable Logic Device Family Data Sheet

■

FLEX 10K Embedded Programmable Logic Family Data Sheet

■

FLEX 8000 Programmable Logic Device Family Data Sheet

■

FLEX 6000 Programmable Logic Device Family Data Sheet

■

MAX 9000 Programmable Logic Device Family Data Sheet

■

MAX 7000 Programmable Logic Device Family Data Sheet

■

MAX 7000A Programmable Logic Device Family Data Sheet

■ Design Debugging using the SignalTap II Embedded Logic Analyzer chapter in

volume 3 of the Quartus II Handbook

2–8 Chapter 2: MasterBlaster Serial/USB Communications Cable Data Sheet

References

Info. Additional Information

Referenced Documents

■ Refer to the following introduction and overview topics in Quartus

■ Selecting the Communications Cable for the SignalTap II Logic Analyzer

Revision History

The table below displays the revision history for the chapters in this user guide.

Date and

Document

Version Changes Made Summary of Changes

July 2008, v1.1

July 2004, v1.0

■ General Style and Formatting update.

■ Added the “Additional Information” chapter.

■ Added Windows Vista to the supported operating system.

■ Updated the “Features” section.

■ Updated the “Functional Description” section.

■ Updated the “Download Modes” section.

Initial release. —

—

II Help:

How to Contact Altera

For the most up-to-date information about Altera® products, refer to the following table.

Technical support Website www.altera.com/support

Technical training Website www.altera.com/training

Product literature Website www.altera.com/literature

Altera literature services Email literature@altera.com

Non-technical support (General)

(Software Licensing)

Note to table:

(1) You can also contact your local Altera sales office or sales representative.

Contact (1) Contact Method Address

Email custrain@altera.com

Email nacomp@altera.com

Email authorization@altera.com

Info–2 Chapter Info: Additional Information

Typographic Conventions

This document uses the typographic conventions shown below.

Visual Cue Meaning

Bold Type with Initial Capital Letters

bold type External timing parameters, directory names, project names, disk drive names, filenames,

Italic Type with Initial Capital Letters

Italic type Internal timing parameters and variables are shown in italic type.

Initial Capital Letters Keyboard keys and menu names are shown with initial capital letters. Examples: Delete

“Subheading Title” References to sections within a document and titles of on-line help topics are shown in

Courier type Signal and port names are shown in lowercase Courier type. Examples: data1, tdi,

1., 2., 3., and a., b., c., etc.

■●• Bullets are used in a list of items when the sequence of the items is not important.

v The checkmark indicates a procedure that consists of one step only. 1 The hand points to information that requires special attention. c A caution calls attention to a condition or possible situation that can damage or destroy

w A warning calls attention to a condition or possible situation that can cause injury to the

r The angled arrow indicates you should press the Enter key.

f The feet direct you to more information about a particular topic.

Command names, dialog box titles, checkbox options, and dialog box options are shown in bold, initial capital letters. Example: Save As dialog box.

filename extensions, and software utility names are shown in bold type. Examples: f

MAX

\qdesigns directory, d: drive, chiptrip.gdf file.

Document titles are shown in italic type with initial capital letters. Example: AN 75: High-Speed Board Design.

Examples: t

PIA

, n + 1.

Variable names are enclosed in angle brackets (< >) and shown in italic type. Example: <file name>, <project name>.pof file.

key, the Options menu.

quotation marks. Example: “Typographic Conventions.”

input. Active-low signals are denoted by suffix n, for example, resetn.

Anything that must be typed exactly as it displays is shown in Courier type. For example:

c:\qdesigns\tutorial\chiptrip.gdf. Also, sections of an actual file, such as a

Report File, references to parts of files (for example, the AHDL keyword well as logic function names (e.g.,

TRI) are shown in Courier.

SUBDESIGN), as

Numbered steps are used in a list of items when the sequence of the items is important, such as the steps listed in a procedure.

the product or the user’s work.

user.

Altera MasterBlaster User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Introduction

Installation

Installation on a Windows PC

Installation on a Linux or UNIX Workstation

Selecting the MasterBlaster Cable for the SignalTap II Logic Analyzer

Features

Functional Description

Download Modes

SignalTap II Logic Analysis

MasterBlaster Connections

Operating Conditions

LED Status

References

Info. Additional Information

Referenced Documents

Revision History

How to Contact Altera

Typographic Conventions
