System Example ............................................. 72
3-EN
Operating Instructions
WARNING
WARNING
This symbol means important instructions.
Failure to heed them can result in serious
injury or death.
INSTALL THE PRODUCT CORRECTLY SO THAT THE
DRIVER CANNOT WATCH TV/VIDEO UNLESS THE VEHICLE
IS STOPPED AND THE EMERGENCY BRAKE IS APPLIED.
It is dangerous for the driver to watch TV/Video while driving a
vehicle. Installing this product incorrectly enables the driver to
watch TV/Video while driving. This may cause a distraction,
preventing the driver from looking ahead, thus causing an
accident. The driver or other people could be severely injured.
DO NOT WATCH VIDEO WHILE DRIVING.
Watching the video may distract the driver from looking ahead of
the vehicle and cause an accident.
DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR
ATTENTION AWAY FROM SAFELY DRIVING YOUR
VEHICLE.
Any function that requires your prolonged attention should only
be performed after coming to a complete stop. Always stop the
vehicle in a safe location before performing these functions.
Failure to do so may result in an accident.
KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL
HEAR OUTSIDE NOISE WHILE DRIVING.
Failure to do so may result in an accident.
USE THE CORRECT AMPERE RATING WHEN REPLACING
FUSES.
Failure to do so may result in fire or electric shock.
DO NOT BLOCK VENTS OR RADIATOR PANELS.
Doing so may cause heat to build up inside and may result in fire.
USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.
Use for other than its designed application may result in fire,
electric shock or other injury.
DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS
IN INSERTION SLOTS OR GAPS.
Doing so may result in personal injury or damage to the product.
CAUTION
This symbol means important instructions.
Failure to heed them can result in injury or
material property damage.
HALT USE IMMEDIATELY IF A PROBLEM APPEARS.
Failure to do so may cause personal injury or damage to the
product. Return it to your authorized Alpine dealer or the nearest
Alpine Service Centre for repairing.
KEEP FINGERS AWAY WHILE THE MOTORIZED FRONT
PANEL OR MOVING MONITOR IS IN MOTION.
Failure to do so may result in personal injury or damage to the
product.
MINIMIZE DISPLAY VIEWING WHILE DRIVING.
Viewing the display may distract the driver from looking ahead of
the vehicle and cause an accident.
DO NOT DISASSEMBLE OR ALTER.
Doing so may result in an accident, fire or electric shock.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so may
result in fire, etc.
KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF THE
REACH OF CHILDREN.
Swallowing them may result in serious injury. If swallowed,
consult a physician immediately.
4-EN
PRECAUTIONS
Product Cleaning
Use a soft dry cloth for periodic cleaning of the product. For
more severe stains, please dampen the cloth with water only.
Anything else has the chance of dissolving the paint or damaging
the plastic.
Temperature
Be sure the temperature inside the vehicle is between +45°C
(+113°F) and 0°C (+32°F) before turning your unit on.
Moisture Condensation
You may notice the disc playback sound wavering due to
condensation. If this happens, remove the disc from the player
and wait about an hour for the moisture to evaporate.
Damaged Disc
Do not attempt to play cracked, warped, or damaged discs.
Playing a bad disc could severely damage the playback
mechanism.
Maintenance
If you have problems, do not attempt to repair the unit yourself.
Return it to your Alpine dealer or the nearest Alpine Service
Station for servicing.
Never Attempt the Following
Do not grip or pull out the disc while it is being pulled back into
the player by the automatic reloading mechanism.
Do not attempt to insert a disc into the unit when the unit power
is off.
New Discs
As a protective measure to prevent the Disc from jamming, the
DVD player will automatically eject discs with irregular surfaces
or inserted incorrectly. When a new disc is inserted into the
player and ejected after initial loading, using your finger, feel
around the inside of the centre hole and outside edge of the disc.
If you feel any small bumps or irregularities, this could inhibit
proper loading of the disc. To remove the bumps, rub the inside
edge of the hole and outside edge of the disc with a ball-point pen
or other such instrument, then insert the disc again.
Centre Hole
Bumps
Centre Hole
New
Disc
Outside
(Bumps)
Installation Location
Make sure the IVA-D300R/IVA-D300RB will not be installed in
a location subjected to:
• Direct sun and heat
• High humidity and water
• Excessive dust
• Excessive vibrations
Correct Handling
Do not drop the disc while handling. Hold the disc so you will
not leave fingerprints on the surface. Do not affix tape, paper, or
gummed labels to the disc. Do not write on the disc.
CORRECT
Inserting Discs
Your player accepts only one disc at a time for playback. Do not
attempt to load more than one disc.
Make sure the label side is facing up when you insert the disc.
Your player will automatically eject any disc that is inserted
incorrectly. If the player continues to eject a correctly inserted
disc, push the RESET switch with a pointed object such as a
ballpoint pen.
Playing a disc while driving on a very bumpy road may result in
skips, but this will not scratch the disc or damage the player.
Irregular Shaped Discs
Be sure to use round shaped discs only for this unit and never use
any special shaped discs.
Use of special shaped discs may cause damage to the mechanism.
INCORRECTCORRECT
Disc Cleaning
Fingerprints, dust, or soil on the surface of the disc could cause
the DVD player to skip. For routine cleaning, wipe the playing
surface with a clean, soft cloth from the centre of the disc to the
outer edge. If the surface is heavily soiled, dampen a clean, soft
cloth in a solution of mild neutral detergent before cleaning the
disc.
Continued
5-EN
Disc Accessories
There are various accessories available on the market for
protecting the disc surface and improving sound quality.
However, most of them will influence the thickness and/or
diameter of the disc. Using such accessories can cause the disc to
be out of standard specifications and may create operational
problems. We recommend not using these accessories on discs
played in Alpine DVD players.
Disc StabilizerTransparent Sheet
Handling the Detachable Front Panel
• Do not expose to rain or water.
• Do not drop or subject to shock.
• After turning the system off, a slight ghost of the image will
remain temporarily. This is an effect peculiar to LCD
technology and is normal.
• In cold temperature conditions, the screen may lose contrast
temporarily. After a short warm-up period, it will return to
normal.
Alpine products equipped with the Ai-NET bus, connected to the
IVA-D300R/IVA-D300RB, can be operated from the IVAD300R/IVA-D300RB. Depending on the products connected, the
functions and displays will vary. For details, consult your Alpine
dealer.
Remove the anti-theft cover when you drive. This prevents the
cover from falling off the unit and interfering with the safe
operation of the vehicle.
Operation of some of the functions of this unit is very complex.
Because of this, it was deemed necessary to place these functions
into a special screen. This will restrict operation of these
functions to times when the vehicle is parked. This ensures the
focus of the driver’s attention will be on the road and not on the
IVA-D300R/IVA-D300RB. This has been done for the safety of
the driver and passengers.
Title Input and Audio Processor Adjustments cannot be made if
the car is moving. The car must be parked and the parking brake
must be engaged for the procedure described in the Owner’s
Manual to be valid. The warning “CAN’T OPERATE WHILE
DRIVING,” will be displayed if any attempts are made to
perform these operations while driving.
Discs Playable on This Unit
Playable discs
The discs listed below can be played on this unit.
Max.
playing time
One-sided
disc
Approx.
4 hours
Two-sided
disc
Approx.
8 hours
One-sided
disc
Approx.
80 Minutes
Two-sided
disc
Approx.
160 Minutes
Approx.
74 Minutes
Approx.
20 Minutes
Approx.
74 Minutes
Approx.
20 Minutes
DVD
Video
Video
CD
Mark (logo)Recorded
DIGITAL VIDEO
content
Audio
Video
(Moving
pictures)
Audio
Video
(Moving
pictures)
Disc size
12 cm*
+
8 cm
12 cm
+
8 cm
VIDEO CD
12 cm
Music
CD
Audio
8 cm
(CD single)
* Two-layer DVD disc compatible
6-EN
Discs that cannot be played
DVD-ROMs, DVD-RAMs, DVD + Rs, DVD + RWs, CD-ROMs
(excluding MP3/WMA files), photo CDs, etc.
DVD region number (playable region number)
This DVD player will play back any disc whose region number is
2 (or All). DVDs with a region number other than those listed
below, cannot be played on this DVD player.
2
ALL
Video CDs
This DVD head unit is compatible with playback control (PBC)
compatible video CDs (version 2.0).
“PBC” is a function by which you can use menu screens recorded
on the disc to find the scene you want to watch and view various
types of information in dialogue style.
Multisession CD-R/RW:
Once a recording has been stopped, this is considered one
session. If the disc is not closed (finalized), additional data may
be added. Once this additional data has been recorded, this
becomes a “multisession” CD. The IVA-D300R/IVA-D300RB
can only read multisession DATA Formatted discs (MP3/WMA
files - Not Audio CD files).
MP3 ID3 Tag/WMA Tag Information:
The IVA-D300R/IVA-D300RB read and displays MP3 ID3v1 tag
or WMA tag information. MP3 files created with ID3v2 tag
information can be played back but the tag info cannot be read or
displayed.
Properly formatted MP3/WMA Discs:
Use ISO9660 formatting to insure proper playback. You may use
standard ISO naming Level 1 (8.3 DOS standard), Level 2 (32
characters) or Joliet (Windows or Macintosh long filenames) file
naming conventions*.
*Please consult the Owner’s manual for additional information.
Using compact discs (CD/CD-R/CD-RW)
If you use unspecified compact discs, correct performance cannot
be guaranteed.
You can play CD-Rs (CD-Recordable)/CD-RWs (CDReWritable) which have been recorded only on audio devices.
You can also play CD-Rs/CD-RWs containing MP3/WMA
formatted audio files.
• Some of the following discs may not play on this unit:
Flawed discs, discs with fingerprints, discs exposed to extreme
temperatures or sunlight (e.g., left in the car or this unit), discs
recorded under unstable conditions, discs on which a recording
failed or a re-recording was attempted, copy-protected CDs
which do not conform to the audio CD industry standard.
• Use discs with MP3/WMA files written in a format compliant
with this unit. For details, see pages 17 and 18.
To customers using CD-R/CD-RW
• If a CD-R/CD-RW cannot be played back, make sure the last
recording session was closed (finalized).
• Finalize the CD-R/CD-RW if necessary, and attempt playback
again.
Tips for making your own CDs
The IVA-D300R/IVA-D300RB plays DVD Video, Video CD,
Audio CD and has a built in MP3/WMA decoder.
The following information is designed to help you create your
own music CDs (either Audio CD or MP3/WMA encoded CD-R/
RW files).
What is the difference between an Audio and MP3/WMA
CD?
An Audio CD is the same format as the commercial CDs you buy
in the store (also known as CD-DA). MP3 (MPEG-1 Audio Layer
3)/WMA (Windows Media Audio) is a data file that uses a
compression scheme to reduce the size of the music file.*
Hybrid Audio CD and Data (MP3/WMA) CD-R/RW discs:
The IVA-D300R/IVA-D300RB can read either sector on the disc.
Choose CD-DA to play the CD audio section or MP3/WMA to
play the MP3/WMA section.*
On handling compact discs (CD/CD-R/CD-RW)
• Do not touch the surface.
• Do not expose the disc to direct sunlight.
• Do not affix stickers or labels.
• Clean the disc when it is dusty.
• Make sure that the disc is smooth and flat.
• Do not use commercially available disc accessories.
Do not leave the disc in the car or the unit for a long time.
Never expose the disc to direct sunlight.
Heat and humidity may damage the disc and you may not be
able to play it again.
Using DVD-Rs/DVD-RWs
• This unit is compatible only with discs recorded in the DVDVideo mode.
Discs recorded in the DVD-VR mode cannot be played back.
• Note that discs not finalized (processed to enable to play on
playback-only DVD players) cannot be played on this DVD
player.
• Some discs may not play back, depending on the recording
device. (This unit has a copy protection function. Discs copied
illegally will not be played back. Some files recorded by a
software using an improper recording system may be
recognized as illegally copied.)
• In the following cases, the disc may not play on this unit:
discs recorded by certain DVD recorders, certain irregular
discs, flawed discs, dirty discs, when the pickup lens of this
DVD player is dirty, or when moisture condensation has
occurred inside the unit.
• Be sure to follow all cautions included with your DVD-Rs/
DVD-RWs discs.
• Do not put stickers, seals, or tape on the label side of DVD-Rs/
DVD-RWs.
• Compared to the regular discs, DVD-Rs/DVD-RWs are more
affected by heat, moisture, and direct sunlight. If left in a car,
etc., damage may occur and it might not play on this unit.
7-EN
Disc terminology
Title
If titles are programmed for the DVD, these are the largest units
of division of the information recorded on the disc.
Chapter
Each Title may also be divided into smaller divisions, called
chapters. These can be specific scenes or musical selections.
• This product incorporates copyright protection technology that is
protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and
other rights owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or
disassembly is prohibited.
• Manufactured under license from Dolby Laboratories. “Dolby,”
• “DTS” and “DTS2.0 + Digital Out” are trademarks of Digital
Theater Systems, inc.
• Windows Media and the Windows logo are trademarks, or
registered trademarks of Microsoft Corporation in the United
States and/or other countries.
8-EN
Getting Started
123456789"#
!
" c button
Ejects a disc.
# OPEN/CLOSE/FLAT button
Raises the monitor.
Press and hold for at least 2 seconds to lower the monitor.
Press to move the open monitor to the flat position.
About the expression of buttons in this Owner’s
Manual
• The buttons on this unit are expressed in bold (e.g. SOURCE/
POWER). The touch buttons on the display are expressed in
bold with [ ] (e.g. [SRC]).
• This Owner’s Manual explains mainly the function of touch
buttons, when a touch button and a unit button have the same
function.
Compatibility with Factory Steering Wheel Radio
Controls
If your vehicle has steering wheel controls for the radio,
an optional steering wheel control interface may be
available to connect to your Alpine radio. For details,
contact your Alpine dealer.
Location of Controls
1 Rotary encoder
Adjust the volume by turning to the left or right.
If pressed, the audio adjusting screen is displayed.
If pressed for at least 2 seconds, MUTE is switched to ON
or OFF.
2 Access Indicator
Blinks when an operation is performed (except when the
volume is adjusted).
3 Remote Sensor
Point the optional remote control transmitter toward the
remote sensor within a range of 2 m.
4 SOURCE/POWER button
Turns the power on. Press and hold for at least 2 seconds
to turn the power off.
Recalls the source selection screen.
5 BAND/TEL. button
Radio mode: Changes the band.
Visual source (except navigation screen): Changes the
display mode.
Press and hold for at least 2 seconds to change to the
TEL. mode, and to be able to place or cut a call. (When
MobileHub (CXA-B200NK) is connected.)
6 V.SEL/OFF button
The visual selecting screen is displayed.
Press and hold for at least 2 seconds to cancel the
Simultaneous function.
7 V.SEL Indicator
Lights when the simultaneous function is activated. (See
“Switching the Visual Source Only (Simultaneous
Function)” on page 25.
8 RESET Switch
Be sure to press the RESET switch when using the unit for
the first time, after changing the car battery, or when an
operation cannot be performed.
9 T.INFO/RDS button
Turns the T.INFO mode ON or OFF.
Press and hold for at least 2 seconds to display the RDS
screen.
! DISC-IN Indicator
This indicator is lit when a disc is inserted.
Using Face Cover
An anti-theft face cover is provided with the
IVA-D300R/IVA-D300RB.
Put the face cover onto the IVA-D300R/IVA-D300RB
when you leave the vehicle.
Be sure to remove the anti-theft face cover when you
drive.
Initial System Start-Up
Immediately after installing or applying power to the
unit, it should be initialized. Press the RESET switch
with a ballpoint pen or any other pointed object.
• If the monitor was open before resetting, it will close automatically
after a reset is performed. None of the buttons will function while it
is closing.
9-EN
Tu rning Power On or Off
Some of this unit’s functions cannot be performed while the vehicle is
in motion. Be sure to stop your vehicle in a safe location and apply
the parking brake, before attempting these operations.
Press SOURCE/POWER to turn on the unit.
1
• The unit can be turned on by pressing any button on the unit except
OPEN and c (Eject).
Press and hold SOURCE/POWER for at least 2
2
seconds to turn off the unit.
• The IVA-D300R/IVA-D300RB draws minimal current even when its
power switch is turned off. If the switched power (ignition) lead of
the IVA-D300R/IVA-D300RB is connected directly to the positive
(+) post of the vehicle’s battery, the battery may be discharged. If
this lead is unswitched, it must be disconnected from the battery
post should the vehicle be left unused for an extended period of
time.
An SPST (Single-Pole, Single-Throw) switch (sold separately) can
be added to simplify this procedure. Then, you can simply place it
in the OFF position when you leave the vehicle. Turn the SPST
switch back ON before using the IVA-D300R/IVA-D300RB. For
connecting the SPST switch, refer to the “Connection Diagram of
SPST switch” (page 69).
• Some operation of the unit cannot be performed while the vehicle is
in motion. In this case, be sure to first stop your vehicle and apply
the parking brake, then perform the operation.
Opening/Closing the Monitor
Press OPEN.
1
The unit beeps 3 times and opens the monitor
automatically.
Press and hold OPEN (CLOSE) for at least 2
2
seconds.
The unit beeps 3 times and closes the monitor
automatically.
• Opening/closing the monitor should never be performed manually.
It may cause a malfunction.
• The monitor’s angle is set to 90 degrees at the factory. Depending
on the car, the monitor may hit the dashboard when opened. The
monitor’s angle can be adjusted and stored in memory so that the
monitor will not hit the dashboard when opening. For adjusting the
monitor, refer to “Adjusting the monitor Angle” on page 26.
Even when the vehicle’s battery power is removed, the adjusted
monitor angle remains stored in memory.
• The IVA-D300R/IVA-D300RB is a precision device. With gentle
handling, its unique capabilities can be enjoyed for a long time.
• If the monitor touches anything while it is being opened (or
closed), the monitor will stop opening (or closing) immediately.
Should this occur, remove the obstacle and press and hold OPEN
for at least 2 seconds again to lower the monitor.
• When the movable monitor is opened, do not place any object on
the monitor and be careful not to bump or apply any pressure to the
monitor while it is open. This can cause damage to the mechanism.
• In low ambient temperature conditions, the display may be dark for
a short period of time immediately after the power is turned on.
Once the LCD has warmed up, the display returns to normal.
•For your safety, some operation of the unit cannot be performed
while the vehicle is in motion. In this case, first stop the vehicle and
engage the parking brake, then perform the operation.
Moving the Monitor to be Flat
When you want to operate some function on the car (air conditioner,
etc.) which is hidden by the raised monitor, use this function.
Press OPEN (FLAT).
1
The monitor moves to the flat position.
Press OPEN (FLAT) again.
2
The monitor returns to the previous angle.
• The monitor returns to the previous angle 10 seconds after being
moved to the flat position.
• If an excessive force is added to the monitor when the monitor is
flat, putting an object on the back of the monitor for example, it
may cause a malfunction.
Adjusting the Volume
Adjust the volume by turning the Rotary encoder.
Volume: 0 - 35
Lowering Volume Quickly
Activating this function will instantly lower the volume level by 20
dB.
Press and hold the Rotary encoder (MUTE) for at
least 2 seconds.
The audio level decreases by about 20 dB.
Pressing and holding the Rotary encoder (MUTE) for at least 2
seconds again brings the audio back to its previous level.
How to view the Display
Touch button operation
The display unit is equipped with tactile feedback (PULSE TOUCH).
What is the tactile feedback (PULSE TOUCH) ?
When you touch a button graphic in the display, you will
feel a mild vibration and click on the display panel surface.
This feedback enables you to easily identify action areas in
the display.
• Be sure to touch the button lightly with the pad of your finger on
the display to protect the display.
• If you touch a button and there is no reaction, remove your finger
from the display once, and try again.
About the expression of touch buttons in this Owner’s
Manual
• Display buttons in this manual are shown in bold with
[ ] (e.g. [SRC]).
• This Owner’s Manual explains mainly the function of
touch buttons, when a touch button and a unit button
have the same function.
10-EN
Recalling the Source
Here is an example explanation for the Radio mode display on how to
recall a source.
Touch [SRC] on the main screen.
1
The source selection screen is displayed.
Display example for source selection screen
1
2
1 Changes to main source screen
2 Displays source modes that can be selected
(The kind of source modes that are displayed varies
depending on connection and setting)
Touch [RADIO].
2
The screen changes to the Radio mode main display.
Main screen example for Radio mode
3
&
%
$
#
"
!
3 Displays the source name, such as radio band, etc.,
that is selected
4 Changes to Telephone mode*
Number of bars decreases depending on reception
level ( is no reception)
5 Changes to VISUAL selection screen
6 Changes to SYSTEM selection screen
7 Displays time
8 Displays shortcut menu screen (pages 11-12)
9 Function Guide:
The function guide display varies depending on each
source.
The contents of the function guide changes by
touching [P1/2]*
many other operations can be performed.
! Icon for new incoming mail*
" Missed incoming mail icon*
# Displays volume level
$ Working state indicator
% Displays the title input screen (see page 23)
& Changes to the source selection screen (to Step 1
screen)
*1Display may vary depending on the connected devices.
*2Displayed when MobileHub (CXA-B200NK) is connected.
1
or [P1/3]*1 on the function guide, and
2
(see page 55)
2
2
4
5
6
7
8
9
• When an optional DVD player or DVD changer is connected,
AUX 1 appears as “EXT.DVD” or “DVD CHG” on the display.
• When both the optional DVD player and DVD changer are
connected, AUX 1 appears as “EXT.DVD” and AUX 2 as “DVD
CHG” on the display. (When an optional expansion Box VPE-S431
is connected)
• When i-Personalize and SETUP are selected, these operations may
only be carried out after the car is parked.
The screen changes to another source by touching
3
[SRC] on the main source screen.
• The screen can be changed to the VISUAL selection screen by
touching [V.SEL].
• The screen can be changed to the SYSTEM selection screen by
touching [SYS.].
• After 5 seconds of each operation in the visual mode, the screen
changes to the visual screen only.
To display the source selection screen, touch the display panel,
then touch [MAIN CONT.] on the screen. The source selection
screen appears by touching [SRC] on the changed main source
screen.
Shortcut Screen
In the main source display, shortcuts for set up of Media Xpander,
Bass MAX EQ, Visual EQ, and DOLBY PLII can be shown and their
settings can be made directly.
Touch [] on the far right of the main source
1
screen.
The shortcut menu screen is displayed. (Displayed when
DEFEAT is set to OFF.)
Touch a desired setup menu.
2
MX (Media Xpander):
Selects the MX mode of the currently displayed audio source.
Bass Max EQ:
Allows choosing any desired mode. (This function cannot be
set when an external audio processor is connected. The
setting can be carried out on the audio processor.)
Visual EQ:
Selectable when the visual source mode is turned on.
DOLBY PLII:
Displayed when an external audio processor is connected.
Continued
11-EN
Display example for shortcut menu screen
Displaying the Numeric Keypad Input Screen
The numeric keypad input screen is displayed when the DVD mode is
selected for searching a title or chapter, and also for entering a
country code or password for the DVD setup item.
Touch [10KEY] on the main source screen.
1
Touch the desired numeric key.
2
The setup screen is
displayed by touching
one of these modes.
Display example for setup screen
1
2
3
1 Close the Shortcut menu screen by touching [].
2 The screen changes to the setup screen mode by
touching another mode.
3 Your desired setting can be made by using operation
buttons.
Display example for numeric keypad
1
2
3
4
5
8
1 Operation buttons of this area can be used while
displaying the numeric keypad input screen.
2 Input screen area
3 All input numbers will be deleted
4 Previous number will be deleted
5 Input number is confirmed
6 Closes numeric keypad input screen
7 Numeric keypad
8 Operation buttons of this area cannot be used while
displaying the numeric keypad input screen.
Touch [ENT] to confirm your entry.
3
6
7
Dual-Screen Display
The connected AMP Link-compatible external amplifier can be
displayed in dual-screen on the main source screen.
12-EN
Touch [V.SEL] on the main source screen.
1
The VISUAL selection screen appears.
Touch [DUAL SCREEN].
2
The main source screen is restored showing the dualscreen display.
Display example for the dual-screen
Changes the AMP display
for the connected amplifier.
Touch [V.SEL] to cancel the dual-screen display.
3
The VISUAL selection screen appears.
Touch [NORMAL].
4
The normal screen will be restored.
Radio
Display example for Radio main screen
3
A
1
2
B
1 [SRC] button: Refer to page 11
2 [TITLE] button: Refer to page 23
3 [] button: Refer to pages 55-57
4 [V.SEL] button: Displays the VISUAL selection screen
5 [SYS.] button: Displays the SYSTEM selection screen
6 [
] button: Refer to page 11
A Displays the input radio station title.
B Displays the preset number/frequency.
Listening to the Radio
Touch [SRC] on the main source screen.
1
The source selection screen is displayed.
Touch [RADIO].
2
The radio mode is activated and the display changes to
the Radio Mode screen.
Touch [BAND] to select the desired radio band.
3
Each press changes the bands as follows:
FM-1 → FM-2 → FM-3 → MW → LW → FM-1
Touch [TUNE] to choose the tuning mode.
4
Each touch changes the tuning mode display.
Distance → Local → Manual → Distance
g f g f g f g f
• There are two modes you can select for auto tuning, DX and
Local:
- DX (Distance) mode (with DX SEEK indicator ON);
Both strong and weak stations will be tuned in.
- Local mode (with SEEK indicator ON);
Only strong stations will be tuned in.
The initial setting is DX.
Touch [g] or [f] to change the radio
5
frequency up or down respectively.
When the button is touched and held, the frequency
changes continuously until the button is released.
• When a stereo FM station is tuned in, the STEREO indicator
appears in the display.
4
5
6
Manual Storing of Station Presets
Tune in a desired radio station you wish to store in
1
the preset memory by manual or automatic seek
tuning.
Touch [P1/2] to change the function guide.
2
Touch [MEMORY].
3
Touch any one of the preset buttons [P.SET 1]
4
through [P.SET 6] within 5 seconds.
The selected station is stored.
Repeat the procedure to store up to 5 other
5
stations onto the same band.
To use this procedure for other bands, simply select the
band desired and repeat the procedure.
A total of 30 stations can be stored in the preset memory
(6 stations for each band; FM1, FM2, FM3, MW or LW).
• If a preset memory has already been set in the same preset number,
it will be cleared and the new station will be memorized.
Automatic Memory of Station Presets
The tuner can automatically seek and store 6 strong stations in the
selected band in order of signal strength.
After selecting the desired band, touch [A.MEMO].
The tuner automatically seeks and stores 6 strong stations into
[P.SET 1] to [P.SET 6] in order of signal strength.
When the automatic storing has been completed, the tuner
goes to the station stored in [P.SET 1].
• If no stations are stored, the tuner will return to the original station
you were listening to before the automatic storing procedure
began.
Tuning to Preset Stations
You can tune in the preset stations in memory on each band using the
preset number.
After selecting the desired band, touch [P1/2] to
1
change the function guide.
Touch any one of the preset buttons [P.SET 1]
2
through [P.SET 6] that has a station stored to it.
The preset station is received.
Searching from Radio Station Title
If the title of a radio station is entered, a title list is displayed. (See
“Titling Discs/Radio Stations” on page 23)
Touch [] to activate the search mode.
1
The screen changes to the radio title list display.
Touch [:] to select the desired radio title.
2
The screen changes to the radio mode main display, and
the desired radio station is received.
13-EN
RDS Operation
Tu rning AF (Alternative Frequencies) On or
Off
The RDS (Radio Data System) is a radio information system using
the 57 kHz subcarrier of regular FM broadcast. The RDS allows you
to receive a variety of information such as traffic information, station
names, and to automatically re-tune to a stronger transmitter that is
broadcasting the same programme.
Touch [SYS.] on the main source screen.
1
The SYSTEM selection screen is displayed.
Touch [RDS].
2
The display changes to the RDS* mode screen.
* RDS/DAB mode screen when DAB is connected.
Touch [AF] to select the AF (Alternative
3
Frequency) ON or OFF mode.
• When the AF ON mode is selected, the unit automatically tunes to
a strong signal station in the AF list.
• Use the AF OFF mode when automatic re-tuning is not required.
Touch [RETURN] to return to the previous screen.
4
Tips
• When the unit receives the PTY31 (Emergency Broadcast)
signal, the unit will show “ALARM” in the display
• The RDS digital data includes the following:
PIProgramme Identification
PSProgramme Service Name
AFList of Alternative Frequencies
TPTraffic Programme
TATraffic Announcement
PTYProgramme Type
EONEnhanced Other Networks
• Refer to GENERAL Setup section (Pages 31-32) about “PI
SEEK Setting”, “Receiving RDS Regional (Local) Stations”
and “Switching the Display Language of PTY (Programme
Type)”.
Receiving Traffic Information
Press T.INFO/RDS to turn on the Traffic Information
mode.
When the traffic information station is tuned in, the TP indicator
lights up.
Traffic information is heard only when it is being broadcast. If
traffic information is not being broadcast, the unit is set in the
standby mode.
When a traffic information broadcast begins, the unit
automatically receives it and the display shows “Traffic Info.”
When traffic information broadcast is over, the unit will
automatically set in the standby mode.
• If the traffic information broadcast signal falls below a certain
level, the unit remains in the receiving mode for 1 minute. If the
signal remains below a certain level for over 70 seconds, “TP
OFF” is displayed.
• If you do not want to listen to the traffic information being
received, lightly press T.INFO/RDS to skip that traffic information
message. The T. INFO mode will remain in the ON position to
receive the next traffic information message.
• If the volume level is changed while receiving traffic information,
the changed volume level will be memorized. When traffic
information is received next time, the volume level will be
automatically adjusted to the level memorized.
PTY (Programme Type) Tuning
Press and hold T.INFO/RDS for at least 2 seconds
1
in the FM radio mode.
The display changes to the RDS Setting Screen.
Touch [PTY] to activate the PTY mode.
2
The Programme Type of the station being currently
received will be displayed.
Touch [;] or [:] after activating the PTY mode to
3
choose the desired programme type while “PTY”
(programme type) is displayed.
Each press scrolls the programme type by one.
Touch [PTY] after selecting the programme type to
4
start searching for a station of the selected
programme type.
If no station is found, “NO PTY” will be displayed.
• When the DAB Receiver Box is connected, the PTY tuning is used
in the same way.
Receiving Traffic Information While Playing
CD or Radio
The example explained here is how to receive the traffic information
broadcast during CD playback.
In the CD mode, press T.INFO/RDS to turn on the
11
Traffic information mode.
The unit automatically starts to search the receivable
traffic broadcasts.
When the traffic information broadcast is searched out,
the CD mode is switched to the Radio mode and the unit
receives the traffic information broadcast.
• When the traffic information broadcast starts, the unit
automatically mutes the CD.
• When the traffic information broadcast finishes, the unit
automatically returns to the original source you were
playing before the traffic information broadcast began.
• The receiver is equipped with the EON (Enhanced Other
Networks) function so if the station being received does not
broadcast the traffic information, the receiver automatically tunes
in the related station that broadcasts the traffic information.
When the traffic information broadcast has
2
finished, the unit returns to the CD mode.
• When the DAB Receiver Box is connected, another operation can
be carried out. Refer to “Setting the Announcement Select Mode”
(page 55).
14-EN
Priority PTY (Programme Type)
This function allows presetting of a programme type such as music
category, news, etc. You can listen to a programme in the preset
programme type as the unit automatically gives priority to the preset
programme type when it begins broadcasting, and interrupts the
programme you are currently listening. This feature is functional
when your unit is set to a mode other than the LW and MW modes.
CD/MP3/WMA
Display example for MP3/WMA main screen
A
1
2
3
4
Touch [SYS.] on the main source screen.
1
Touch [RDS].
2
The display changes to the RDS mode Screen.
Touch [P.PTY] to activate the PRIORITY PTY
3
mode.
The programme type selected by the P.PTY is displayed.
Touch [;] or [:] to choose a desired programme
4
type. Then touch [P.PTY].
The PRIORITY PTY function will activate.
The “P.PTY” indicator lights up.
• When the P.PTY mode is set to the ON position, the unit
automatically plays the preset programme type whenever the unit
receives the programme type even while the unit is displaying other
source screen than radio.
• If you do not want to listen to the programme being received, touch
[P.PTY] in the RDS mode screen to skip the P.PTY mode. The
P.PTY mode will remain in the P.PTY ON position to receive the
next preset programme type when it occurs.
•To disable the PRIORITY PTY (interrupting) function, touch and
hold [P.PTY] for at least 2 seconds.
• In the PRIORITY PTY function, unlike in the T.INFO function, the
volume does not increase during operation.
Touch [RETURN] to return to the previous screen.
5
Displaying Radio Text
Text messages from a radio station can be displayed.
Tune in a radio station that transmits text
1
messages.
Touch [INFO.] in the FM radio mode to activate the
2
Radio Text mode.
The display shows “WAIT” for a few seconds.
5
B
6
1 [SRC] button: Refer to page 11
2 [
3 [V.SEL] button: Displays the VISUAL selection screen
4 [SYS.] button: Displays the SYSTEM selection screen
5 [
6 [
A CD:
B CD:
*1Displayed when CD text is available.
*2Displayed when a CD changer is connected.
*3Displayed when an MP3 compatible CD changer is connected.
] button: Refer to pages 55-57
] button: Refer to page 11
] button: Refer to page 24
Displays track text*
Displays input title in the lower line.
Disc text*
display.
MP3/WMA:
After displaying the file name in the upper line, the
track name is displayed if there is ID3 tag information.
After displaying the folder name, the artist name/
album name are displayed if there is ID3 tag
information.
Displays the track number/disc number*
time.
MP3/WMA:
Displays the folder number/file number/disc number*3/
elapsed playback time
1
is displayed if there are no titles in the
1
in the upper line.
2
/elapsed
To deactivate the Radio Text mode, touch [INFO.].
3
• If there is no receivable text message or the unit cannot receive a
text message properly, the display shows “NO TEXT.”
15-EN
Playback
Repeat Play
Touch [SRC] on the main source screen.
1
The source selection screen is displayed.
Touch [DVD PLAYER].
2
The display shows the DVD player mode screen.
When a CD/MP3/WMA is inserted into the DISC SLOT of
the IVA-D300R/IVA-D300RB, with the label side facing up,
the unit starts to play the CD/MP3/WMA.
• When an optional Alpine CD player is connected,
inserting a CD into the optional CD player starts
playback automatically.
Touch [g] or [f] to select the desired track
3
(file).
Returning to the beginning of the current track (file):
Touch [g].
Fast backward :
Touch and hold [g].
Advancing to the beginning of the next track (file) :
Touch [f].
Fast forward :
Touch and hold [f].
To pause playback
Touch [-/J].
Touching [-/J] again will resume playback.
To eject the disc
Press c.
• The IVA-D300R/IVA-D300RB models include a built-in MP3/WMA
unit. You can play CD-ROMs, CD-Rs, and CD-RWs containing
MP3/WMA files on this unit. Use the format compliant with this
unit.
For further information about playing or storing MP3/WMA files,
refer to pages 17 and 18 before using the unit.
•A WMA format file that is protected by DRM (Digital Rights
Management) cannot be played back on this unit.
• The unit can play discs containing both audio data and MP3/WMA
data.
• The MP3/WMA indicator is lit during MP3/WMA playback.
• No sound is played during fast-forwarding/fast-reversing.
• The fast-reversing operation can be performed in the MP3/WMA
mode only when a track (file) is currently being played back.
• The track display for CD audio data playback is the track numbers
recorded on the disc.
• Three-inch (8cm) CD’s can be used.
• Playing MP3/WMA Data is mentioned on page 32 “GENERAL
Setup.”
• When an MP3/WMA disc is played, it sometimes takes a few
moment until it starts.
•Touch [] to activate the search mode. For operations, refer to
“Disc Search Function” on page 24.
Touch [] to play back repeatedly the track currently
being played.
The track (file) will be played repeatedly.
Touch [] again and select OFF to deactivate Repeat play.
CD:RPT → RPT ALL∗1 → (off) → RPT
MP3/WMA:
1Touch [P1/2]∗3 to change the function guide.
2Touch [] and select the desired Repeat play.
RPT → RPT FLDR∗2 → RPT ALL∗1 → (off) → RPT
*1If a CD Changer or an MP3 compatible CD changer is connected
and the RPT ALL mode is selected, the unit repeatedly plays back
all tracks (files) on the disc selected.
*2Only files in a folder are repeatedly played back.
*3Display may vary depending on the connected devices.
M.I.X. (Random Play)
Touch [] during playback.
The tracks (files) on the disc will be played back in a random
sequence.
To cancel M.I.X. play, touch [].
CD:M.I.X. → M.I.X. ALL*1 → (off) → M.I.X.
MP3/WMA:
1Touch [P1/2]*4 to change the function guide.
2Touch [] and select the desired M.I.X. play.
M.I.X. FLDR
*1If a CD Changer equipped with the M.I.X. ALL function is
connected, M.I.X. ALL will also be selectable.
In this mode, the tracks on all the CDs in the current magazine will
be included in the random playback sequence.
*2If an MP3 compatible CD changer is connected, all files in a disc
are played back in random sequence, and playback shifts to the
next disc.
*3Only files in a folder are played back in random sequence in the
M.I.X. FLDR mode.
*4Display may vary depending on the connected devices.
*3
→ M.I.X.
*2
→ (off) → M.I.X. FLDR
Selecting Folders (concerning MP3/WMA)
Touch [F.DN] or [F.UP] to select the folder.
*3
16-EN
About MP3/WMA
CAUTION
Except for private use, duplicating audio data (including MP3/
WMA data) or distributing, transferring, or copying it, whether
for free or for a fee, without permission of the copyright holder is
strictly prohibited by the Copyright Act and by international
treaty.
What is MP3?
MP3, whose official name is “MPEG-1 Audio Layer 3,” is a
compression standard prescribed by the ISO, the International
Standardization Organization and MPEG which is a joint
activity institution of the IEC.
MP3 files contain compressed audio data. MP3 encoding is
capable of compressing audio data at extremely high ratios,
reducing the size of music files to as much as one-tenth their
original size. This is achieved while still maintaining near CD
quality. The MP3 format realizes such high compression ratios
by eliminating the sounds that are either inaudible to the
human ear or masked by other sounds.
What is WMA?
WMA, or “Windows Media™ Audio,” is compressed audio
data.
WMA allows you to create music files and store them at higher
ratios of compression than MP3 audio data (approx. half
original size). This is achieved while still maintaining CD
quality sound.
Method for creating MP3/WMA files
Audio data is compressed by using MP3/WMA specified
software. For details on creating MP3/WMA files, refer to the
user’s manual for that software.
MP3/WMA files that can be played back by this device have
the file extension “mp3” / “wma”. Files with no extension
cannot be played back. (WMA ver. 7.1 and 8 are supported)
Sampling rates: 32 kHz ∼ 48 kHz
Bit rates:32 - 192 kbps
This device may not play back correctly depending on
sampling rates or bit rates.
ID3 tags/WMA tags
This device supports ID3 tag v1, and WMA tag.
If tag data is in an MP3/WMA file, this device can display the
title (track title), artist name, and album name ID3 tag/WMA
tag data.
This device can only display single-byte alphanumeric
characters (up to 30 for ID3 tags and up to 15 for WMA tags)
and the underscore. For non-supported characters, “NO
SUPPORT” is displayed.
The tag information may not be correctly displayed,
depending on the contents.
Producing MP3/WMA discs
MP3/WMA files are prepared, then written to a CD-R or CDRW using CD-R writing software. A disc can hold up to 255
files/255 folders (including Root Folders).
Depending on the structure of the folders or files, it may take
time to read a disc. In this case, it is recommended to
decrease the number of folders or files.
Media supported
The media that this device can play back are CD-ROMs, CDRs and CD-RWs.
Corresponding File Systems
This device supports discs formatted with ISO9660 Level 1 or
Level 2.
Under the ISO9660 standard, there are some restrictions to
remember.
The maximum nested folder depth is 8 (including the root
directory). File/folder names are limited to 31 characters
(including the extension).
Valid characters for folder/file names are letters A-Z (all
caps), numbers 0-9, and ‘_’ (underscore).
This device also can play back discs in Joliet, Romeo, etc.,
and other standards that conform to ISO9660. However,
sometimes the file names, folder names, etc., are not
displayed correctly.
Formats supported
This device supports CD-ROM XA, Mixed Mode CD,
Enhanced CD (CD-Extra) and Multi-Session.
This device cannot correctly play back discs recorded with
Track At Once or packet writing.
Order of files
The unit plays the files in the order that the writing software
writes them. Therefore, the playing order may not be the same
as the order you input. The playback order of the folders and
files is as follows. However, the folder and file playback order
differs from the folder no. and file no. indicated on the display.
1
Root
Folder
2
2
3
4
4
5
6
7
1
FolderMP3/WMA File
Continued
3
5
6
17-EN
Terminology
Bit rate
This is the “sound” compression rate specified for encoding. The
higher the bit rate, the higher the sound quality, but also the larger
the files.
Sampling rate
This value shows how many times per second the data is sampled
(recorded). For example, music CDs use a sampling rate of 44.1
kHz, so the sound is sampled (recorded) 44,100 times per second.
The higher the sampling rate, the higher the sound quality, but also
the larger the volume of data.
Encoding
Converting music CDs, WAVE (AIFF) files, and other sound files
into the specified audio compression format.
Tag
Song information such as track titles, artist names, album names,
etc., written into MP3/WMA files.
MP3: ID3 tag
WMA: WMA tag
Root folder
The root folder is found at the top of the file system. The root folder
contains all folders and files.
DVD/Video CD
Display example for DVD main screen
2
A
1
B
1 [SRC] button: Refer to page 11
2 [
3 [V.SEL] button: Displays the VISUAL selection screen
4 [SYS.] button: Displays the SYSTEM selection screen
5 [
6 [
A Displays the input title only for video CD.
B Displays the title number/chapter number/elapsed
• Some operations cannot be carried out depending on the disc or
playback screen.
• Displays of the function guide [P1/2], etc., may vary depending on
the connected device(s).
] button: Refer to pages 55-57
] button: Refer to page 11
] button: Refer to page 24
playback time for a DVD.
Displays the track number/elapsed playback time for a
video CD.
3
4
5
6
Playing DVD/Video CD
IVA-D300R/IVA-D300RB has a built-in DVD player. When an
optional Alpine DVD/video CD/CD player (or DVD changer) is
connected to the IVA-D300R/IVA-D300RB, you can control it from
the IVA-D300R/IVA-D300RB. (except some operations)
WARNING
It is dangerous for the driver to watch the TV/DVD/
Video while driving the vehicle. The driver may be
distracted from looking ahead and an accident
could occur.
Install the IVA-D300R/IVA-D300RB correctly so that
the driver cannot watch TV/DVD/Video unless the
vehicle is stopped and the emergency brake is
applied.
If the IVA-D300R/IVA-D300RB is not installed
correctly, the driver will be able to watch the TV/
DVD/Video while driving the vehicle and may be
distracted from looking ahead causing an accident.
The driver or other people could be severely
injured.
18-EN
To display the DVD mode screen
• If you try to activate the auxiliary device while driving, the display
will show the warning-PICTURE OFF FOR YOUR SAFETY.
If a menu screen appears
On DVDs and Video CDs with playback control (PBC), menu
screens may appear automatically. If this happens, perform
the operation described below to start playback.
Caution
• Not all functions will operate for every DVD. See
the individual DVD’s instructions for details on
the features supported.
• Fingerprints on a disc may adversely affect
playback. If a problem occurs, remove the disc
and check for fingerprints on the playback side.
Clean the disc if necessary.
• If you switch the power or Ignition Key OFF or
change sources during playback, playback will
continue where you left off when you resume
playback.
• If you try to perform an invalid operation (based
on the type of disc being played), the following
mark is displayed on the monitor screen:
• Play Position Memory Function
Even if you turn power off or switch the Ignition
Key to OFF during playback or change the
source, playback will continue from the point
where playback stopped when the power is
turned ON again.
Touch [SRC] on the main source screen.
1
The source selection screen is displayed.
Touch [DVD PLAYER].
2
The display shows the DVD player mode screen.
Insert a disc with the label side facing up. The unit starts
to play the disc.
When an optional Alpine DVD player is connected:
Insert a disc into the DVD/video CD/CD player, the player
starts playing.
• The operation screen changes to the visual screen in the DVD or
video CD mode for 5 seconds after an operation has been
performed. Touch the display panel to display the operation screen
again.
• The display mode can be changed by touching [WIDE].
For operation, see “Switching Display Modes” on page 25.
Direct Menu Operations (DVD only)
1Touch the DVD menu directly.
• Some operations cannot be performed depending on the
disc.
Menu Operations (DVD only)
1Touch [KEY].
The menu operation mode will be displayed.
2 Select a desired menu item by touching [8], [9], [;] or
[:].
3Touch [ENTER] to confirm the selected item.
Continued
To eject the disc
Press c.
• The reverse side of a double-sided DVD will not be played
automatically.
Remove the disc, turn it over, and reinsert it.
• DO NOT insert discs containing maps for the navigation system.
Doing so could result in damage.
• Refer also to “DVD Setup” (pages 27 to 30).
• If : (playback symbol) is displayed when a video CD with PBC
(Playback Control) is inserted, playback is enabled by touching
and holding [:/J] for at least 2 seconds.
• Be sure the remote input lead is connected to the remote output
lead of this unit when a DVD changer or DVD player is connected.
If not correctly connected, touch operation cannot be performed.
•To return to the previous screen during video CD playback, touch
[;] after touching [P1/2] of the function guide. However, the
function may vary depending on the disc.
19-EN
Numeric Keypad Input Operations (DVD)
1Touch [KEY].
The menu operation mode appears.
2Touch [KEY] again.
The numeric keypad input mode screen appears.
Touch [RTN] to close the numeric
keypad input screen.
3Touch a desired number.
4Touch [ENT] on the numeric keypad mode screen to
confirm your selection.
Displaying the Menu Operation Mode Screen
(DVD only)
Touch [P1/2] on the DVD mode main screen.
1
The function guide changes.
Touch [MENU CONT].
2
The menu operation mode screen appears.
•For further operation, see “If a menu screen appears” on pages 19
and 20.
Tu rning the PBC Function ON or OFF
(Video CD only)
The following describes how to turn a video CD equipped PBC
(playback control) on or off.
Touch [PBC] on the video CD mode main screen.
Touching [PBC] sequentially turns the PBC on and off.
Stopping Playback (PRE STOP)
Press the stop button during playback to stop playback. That position
is stored in the memory.
Touch [L] once during playback.
1
“PRE STOP” is displayed.
Numeric Keypad Input Operations (Video CD)
When PBC is turned OFF, the menu screen is not displayed. Turn it
ON to display the screen (see “Turning the PBC Function ON or
OFF” on this page).
1Touch [P1/2] in the video CD mode to change to the
function guide.
2Touch [10KEY].
The numeric keypad is displayed.
3Touch and input a desired number.
4Touch [ENT] to confirm.
Displaying the Top Menu Screen (DVD only)
When a DVD contains two or more titles, the top menu screen
appears.
Touch [TOP MENU] on the DVD mode main screen.
The top menu screen appears.
•To perform necessary operations, see “If a menu screen appears”
on pages 19 and 20.
Displaying the Menu Screen (DVD only)
With a DVD having two or more menus, a menu screen will appear
for the programs available, in addition to the main programs.
Touch [MENU] on the DVD mode main screen.
The menu screen appears.
•To perform necessary operations, see “If a menu screen appears”
on pages 19 and 20.
Touch [:/J] in the PRE STOP mode.
2
Playback starts from the position at which it was stopped.
•For some discs, the position at which playback was stopped may
not be accurate.
Stopping Playback
Touch [L] twice or touch and hold [L] for at least 2
seconds during playback.
“STOP” is displayed, and playback stops.
• Playback starts from the beginning when [:/J] is touched while
playback is stopped.
Fast-forwarding/Fast-reversing
During playback, touch [g] (Fast-reverse) or
1
[f] (fast-forward).
When touched and held for more than 1 second, the disc
is forwarded/reversed at double speed. When held for 5
more seconds or longer, the disc is forwarded/reversed at
8 times the normal speed.
Stop touching [g] or [f] to return to normal
2
playback.
• No sound is played during fast-forwarding/fast-reversing.
• No subtitles are shown during fast-forwarding/fast-reversing.
However, subtitles may be displayed depending on the disc.
•For DVDs and video CDs with playback control (PBC), the menu
screen may reappear during fast-forwarding/fast-reversing.
20-EN
Finding the Beginnings of Chapters or Tracks
During playback, touch [g] or [f].
The chapter/track switches each time the button is touched,
and playback of the selected chapter/track starts.
f : Touch this to start playback from the beginning of
the following chapter or track.
g : Touch this to start playback from the beginning of
the current chapter or track.
• Some DVDs do not have chapters.
Supplementary explanation
“Chapters” are divisions of movies or musical selections
on DVDs.
“Tracks” are divisions of movies or musical selections on
video and music CDs.
Playing Still Frames (Pausing)
During playback, touch [:/J].
1
Touch [:/J] to resume playback.
2
• No sound is played during the still frame mode.
• The image or sound may stop temporarily when playback starts
from the pause mode. This is not a malfunction.
Frame-by-frame Playback
In the pause mode, touch [f].
1
The picture advances by one frame each time the button
is touched.
Touch [:/J] to return to normal mode.
2
• No sound is played during frame-by-frame playback.
9
REPEATThe chapter is played repeatedly.
9
REPEAT TITLEThe title is played repeatedly.
9
REPEAT OFFThe playback returns to normal mode.
• Display may vary depending on the connected devices.
Video CD
During playback, touch [P1/2].
1
During playback, touch [] on the main unit.
2
The repeat mode switches every time the button is
touched.
9
REPEATThe track is played repeatedly.
9
REPEAT ALLThe disc is played repeatedly.
9
REPEAT OFFThe playback returns to normal mode.
• Display may vary depending on the connected devices.
• The track/disc repeat modes cannot be used on video CDs with
playback control (PBC). These modes can be carried out after
turning PBC off. See “Turning the PBC Function ON or OFF” on
page 20.
•For some discs it is not possible to switch the repeat mode.
• Step 1 is not necessary when a DVD changer or DVD player is
connected.
Searching by Title Number (DVD only)
Use this function to easily find positions on the DVD using the
DVD’s titles.
Slow Motion Playback
When [f] is touched and held while in the pause
1
mode, the 1/8th speed slow motion playback mode
is set.
When held in for 5 more seconds, the slow motion
speed switches to 1/2 the normal speed.
Stop touching [f] to pause, and touch [:/J] to
2
playback.
• No sound is played during slow motion playback.
•Reverse slow motion playback is not available.
• 1/2, 1/8 are approximate speeds. The actual speed differs from disc
to disc.
Chapter/Track/Title Repeat Playback
Use this function to play the disc’s titles, chapters or tracks
repeatedly.
DVD
During playback, touch [P1/2].
1
Touch [] on the main unit.
2
The repeat mode switches every time the button is
touched.
Touch [P1/2] while playback is stopped.
1
The function guide appears.
Touch [10KEY].
2
The numeric keypad input mode screen appears.
Enter a desired title by touching its title number.
3
See page 20 for operation of the numeric keypad.
Confirm your selection by touching [ENT].
4
Playback will start from the title number selected.
• This function cannot be used on discs on which no title numbers
are recorded.
• Playback starts from the beginning of the chapter/track number in
the state of PRE STOP.
• Some disc may not accept any operation.
21-EN
Searching Directly by Chapter or Track
Number
Use this function to easily move to the beginnings of the chapters or
tracks on the disc.
Touch [P1/2] in any mode other than stop mode.
1
The function guide will appear.
Touch [10KEY].
2
The numeric keypad input mode screen will appear.
Touch and enter the chapter or track number you
3
want to play.
See page 20 for operation of the numeric keypad.
Touch [ENT] to confirm your selection.
4
Playback will start from the selected chapter or track.
• This function is not available for a disc on which chapters or
tracks are not stored.
• Direct search of a track number is not available for a video CD
with the PBC (playback control) function as long as its PBC is
turned on. Be sure to turn PBC off before starting the search (see
“Turning the PBC function ON or OFF” on page 20).
Switching the Angle (DVD only)
On DVDs in which scenes have been filmed from multiple angles, the
angle can be switched during playback.
During playback, touch [P1/2].
1
The function guide changes.
Touch [ANGLE].
2
The angle switches between the angles recorded on the
disc every time the button is touched.
• Some time may be required for the angle to change.
• Depending on the disc, the angle may switch in one of two ways.
- Seamless: The angle switches smoothly.
- Non-seamless: When the angle is switched, a still picture is
displayed first, after which the angle switches.
Switching the Audio Tracks
DVDs can have up to 8 different audio tracks. These alternate tracks
can be switched during playback.
During playback, touch [P1/2].
1
Touch [AUDIO].
2
The sound switches between the alternate audio tracks
recorded on the disc every time the button is touched.
• The alternate track selected becomes the default setting every time
the power is turned on or the disc is replaced. If the disc does not
include that track, the disc’s default language is selected instead.
• Not all discs will allow changing the alternate audio tracks during
playback. In these cases, select audio tracks from the DVDs menu.
• There may be a delay before the selected alternate track begins to
play.
Video CDs with multiplex audio
During playback, touch [P1/2].
1
The function guide changes.
Touch [AUDIO].
2
The left and right channels will be output as shown in the
figure below, each time the button is pressed.
AUDIO L/L → AUDIO R/R → AUDIO L/R → AUDIO L/L
Switching the Subtitles (Subtitle Language)
(DVD only)
With DVDs on which multiple subtitle languages are recorded, the
subtitle language can be switched during playback; moreover,
subtitles can be hidden.
During playback, touch [P1/2].
1
The function guide changes.
Touch [SUBT.].
2
Touching this button repeatedly selects sequentially the
subtitle languages recorded on the disc, and then turns
the subtitles OFF.
• There may be a delay before the selected subtitle appears.
• Not all discs will allow changing the subtitles during playback. In
these cases, select subtitles from the DVDs menu.
• The subtitle language selected becomes the default setting every
time the power is turned on or the disc is replaced. If the disc does
not include that language, the disc’s default language is selected
instead.
•For some discs, the subtitles will be displayed even when this is set
to off.
Switching from the disc menu
For some discs, the audio language, angle and subtitles can be
switched from the disc menu.
Touch [MENU] or [TOP MENU] to display the
1
menu.
Select an item to confirm it.
2
See “If a menu screen appears” on pages 19 and 20.
Displaying the Disc Status for DVD/Video CD
Use the procedure described below to display the status (title number,
chapter number, etc.) of the currently playing DVD or of the currently
playing video CD (track number, etc.) on the monitor.
During playback, touch the display panel.
1
The operation menu screen is displayed.
Touch [MAIN CONT.] within 5 seconds.
2
The display status is displayed for 5 seconds.
22-EN
Other Useful Features
Adjusting the Audio
Press the Rotary encoder on the unit.
The display changes to the Audio Adjustment screen.
Display Example for Audio Adjustment Screen
Adjusting the BASS Level
Touch [;] or [:] of BASS to adjust the low frequency
bass level.
Setting range: 0 to 11
• This adjustment becomes available when AMP Link compatible
external amplifiers (MRD-M301 and MRD-M501) are connected.
Adjusting the Balance/Fader Directly
Touch and move [\] to a desired setting.
Or touch a desired setting range, and [\] will move to that location.
Touch [L] or [R] of Balance and [F] or [R] of Fader for fine-tuning.
3
2
1
4
1 Adjust the volume of the front and rear speakers by
touching [F] or [R].
2 Adjust the volume of the left and right speakers by
touching [L] or [R].
3 Determine your desired setting value by touching and
moving [\].
4 Touches [;] or [:] to adjust to your preference.
•Touch [AUDIO MODE] on the SYSTEM selection screen to change
to the Audio Adjustment screen.
Adjusting the Balance
Touch [L] or [R] to adjust the sound volume of the left
and right speakers.
Setting range: L15 to R15
Adjusting the Fader
Touch [F] or [R] to adjust the volume of the front and
rear speakers.
Setting range: F15 to R15
Adjusting the Subwoofer Level
Touch [;] or [:] of SUBW. to adjust the subwoofer output.
Setting range: 0 to 15
• The level adjustment becomes available when 0° or 180° is set in
“Subwoofer On and Off” (page 40).
Adjusting NAV. LEVEL
Touch [;] or [:] of NAV. to adjust the volume of
navigation interruption.
Setting range: 0 to 15
• This adjustment becomes available when NAV.MIX is turned on in
“Setting the Navigation Interruption” (page 33).
Turning defeat ON or OFF
Touch [;] or [:] of DEFEAT to turn it ON or OFF.
If you set the defeat to ON, MX is turned OFF and EQ is
returned to the initial setting.
Titling Discs/Radio Stations
The Parking Brake must be engaged to access the Title Input
mode screen. Attempting to access this screen while driving
will display the warning-CAN’T OPERATE WHILE DRIVING.
You can title discs (CD, Video CD) and radio stations. This manual
describes how to title Radio stations (In the RDS mode, you can only
input a title when PI is not being received). You cannot title DVD and
MP3/WMA discs.
Activate the Radio mode.
1
Touch [TITLE] on the radio main screen.
2
The title input screen appears.
Touch a desired character symbol to input. Up to
3
16 digits can be input.
Each time [A/a/1/+] is touched, alphabet upper case,
lower case, numerical and then symbols are selected.
Display example for title input screen
2
1
9
1 Moves the cursor to the left in the input area
2 Input area
3 Moves the cursor to the right in the input area
4 Changes between character and symbol
5 All you have input is deleted
6 Deletes a previous character
7 Confirms and stores a title you have input
8 Returns to a previous screen
9 Character/Symbol Pallet
Touch [ENT] to confirm the input title.
4
The display changes to the radio mode.
•You can enter up to 100 titles of radio stations, CD and video CD.
•You cannot enter file name, folder name and tag information on
MP3/WMA files on this unit.
• When the memory is full, “Full Data” is displayed for 2 seconds.
At this point, touch [ENT] to delete the oldest title you have input
first, and then you can input a new one.
• Immediately after inputting titles or c hanging the settings of Setup
mode or Display mode (while the system is inputting the titles or data
automatically) do not turn the ignition key (engine key) to OFF.
Otherwise, the title may not be written, or the settings may not be changed.
3
4
5
6
7
8
23-EN
Disc Search Function
Touch [] on the function guide while in the disc
1
mode.
The disc search mode is turned on, and the disc search
list screen is displayed.
Select a desired disc title.
Touch [:] for direct playback.
When a hierarchical list is prepared for the disc, [] or
[] will be displayed. Touch [] to display the
respective hierarchy list screens (to respective modes
described in Step 2).
Display Example for Disc Search Screen
2
4
3
1 [] is displayed if there is a hierarchical list.
2 Select directly by touching [:], and its disc (or folder/
file) is played back.
3 Go through the list pages by touching [ ] or [ ].
4 Touch [
* This screen displays a list of the disc currently playing, or of each
disc of a connected external CD player or changer.
• When a disc title is not given to a CD or video CD, “NO TITLE” is
displayed.
] to return to the previous list screen*.
1
Rear Entertainment Function
The rear entertainment function independently routes different
sources to the front and the rear inside a car. For example, while
listening to the radio or other audio source in the front, DVD can be
enjoyed in the rear with the optional rear monitor and headphones.
Touch [SYS.] on the main source screen.
1
The SYSTEM selection screen is displayed.
Touch [REAR SELECT].
2
Rear Select display appears.
• This function cannot be used when MONITOR OUT 1 or 2 is
set to OFF in the SYSTEM SETUP.
Touch your desired source (the auxiliary input or
3
built-in DVD) to select.
REAR.1:
External monitor which is connected to AUX OUT of the
tuner box on this unit. (If the optional expansion box (VPES431) is not connected), or an external monitor is connected
to AUX OUT1 of the optional expansion box (VPE-S431).
REAR.2*:
External monitor which is connected to AUX OUT 2 the
optional expansion box (VPE-S431)
* REAR.2 is not displayed if only an external monitor is connected.
The setting screen is displayed for REAR.2 if the external monitor
is connected to the optional expansion box (VPE-S431).
•Touch [OFF] to cancel the rear entertainment function.
• When the “Setting the AUX Mode” (page 33) is set to OFF, the
auxiliary source is not displayed.
• When TV is selected in AUX IN 1, 2 MODE, TV is displayed.
Switching the function of the remote sensor
For optional remote control operation, the remote sensor of the
external device (monitor, etc.) can be switched, as you prefer.
Touch [] of the selected disc title.
2
Another hierarchical list appears.
Refer to the following mode procedure.
Internal CD player mode
1 The track title list* or the track list screen appears.
Select a desired folder and then touch [].
([] appears only when a file is present in the
selected folder.)
The file list screen is displayed.
•Touch [:] to play back the folder directly.
2Touch [:] of a desired file name.
The selected file will be played back.
Touch [FRONT], [REAR 1] or [REAR 2].
4
The monitor which has a priority to the remote control
operation is changed.
FRONT: The remote sensor of this unit is effective.
REAR1: The remote sensor of the external monitor
REAR2: The remote sensor of the external monitor
• When you watch the built-in DVD in IVA-D300R/IVA-D300RB
(front monitor) and in the rear monitor, the On Screen display of
the rear monitor (PLAY, PAUSE, FAST FWD, etc.) is not displayed.
• The sensor of the touch panel rear monitor has priority over the
sensor of the remote control, if the rear monitor (connected to the
Alpine touch panel rear monitor via the Monitor control lead) is
touched, regardless of the remote control sensor switch setting.
Note, however, that the sensor of the remote control that has been
set takes priority if it has been 5 seconds since last touching the
panel.
• When an optional DVD changer or DVD player is connected, and
the remote control sensor is set to REAR1 or REAR2, some touch
button operations ( [L] STOP, etc.) cannot be performed.
In this case, set the remote control sensor to FRONT.
connected to AUX OUT of the tuner box of this
unit, or the optional expansion box (VPE-S431)
is effective, and the remote control can operate
only the source selected for the terminals.
connected to AUX OUT of the optional
expansion box (VPE-S431) is effective, and the
remote control can operate only the source
selected for the terminals.
24-EN
Switching Display Modes
While your vehicle is parked, touch [WIDE] on the
visual source screen.
Switching the Visual Source Only
(Simultaneous Function)
You can watch the video portion of another source while listening to
the current source.
Touch [V.SEL] on the audio source screen.
1
The VISUAL selection screen appears.
MODE1
In Mode 1 (Wide), the monitor displays a normal picture wider
to fit in a wide-screen monitor by evenly stretching out the
picture horizontally.
MODE2
In the Mode 2 (Zoom), the monitor displays a normal picture
wider to fit in the wide-screen monitor by unevenly stretching
out. The centre portion of the picture is stretched out only
slightly in order to make the important centre portion of the
picture look natural.
MODE3
In Mode 3 (Cinema), the monitor displays a normal picture by
stretching out the picture horizontally and vertically. This mode
is good for displaying a cinema type picture at the 16 : 9 ratio.
MODE4
In Mode 4 (Normal), the monitor displays a normal picture at
the centre of the screen with a vertical black band at each
side.
Touch a desired visual source.
2
The visual source is switched to the selected one.
• If a DVD player is connected, you can receive the DVD picture/
sound.
DVD player (DVA-5205P) or DVD changer (DHA-S680P) is
connected:
Press and hold V.OUT on the remote control supplied with the
DVD player or DVD changer for more than 2 seconds. The picture
and sound of the DVD will be output.
The DVA-5210 is connected:
Press V.OUT on the remote control (included with the DVA-5210)
to output DVD picture/sound.
• The simultaneous function cannot be used when the Audio source
is in the navigation mode.
• By pressing V.SEL for more than 2 seconds, the simultaneous
function is cancelled.
Blackout Mode On and Off
When Blackout mode is turned on, the display will turn off to reduce
power consumption.
This additional power enhances the sound quality.
Touch [V.SEL] on the main source screen.
1
The VISUAL selection screen is displayed.
Touch [OFF].
2
The backlit-display portion goes out.
Touch [OFF] again to cancel the display backlight.
3
• If any button on the unit is pressed during Blackout mode, the
function will be displayed for 5 seconds to show the operation
before returning to Blackout mode.
25-EN
Setting VISUALIZER
This setting is available when the expansion box (VPE-S431) is
connected.
Touch [V.SEL] on the main source screen.
1
The VISUAL selection screen is displayed.
Touch [VISUALIZER].
2
The Visualizer setting screen is displayed. If you do not
touch any button for 5 seconds, the operating display
buttons, [MAIN CONT.] etc., will disappear.
Touch the screen (visual screen only) after the
3
operating display has disappeared.
The VISUALIZER setup mode is displayed.
Monitor Setting
Monitor Setting Operation
Following Steps 1 to 4 describe the common procedures for
operating the MONITOR setting function. For details of the
setting function items, refer to descriptions of respective items.
Touch [SYS.] on the main source screen.
1
The SYSTEM selection screen is displayed.
Touch [MONITOR].
2
The MONITOR screen appears.
Select a desired mode by touching [;] or [:] of
4
VISUALIZER within 5 seconds.
MODE1 to MODE6 / OFF:
Recalls the maker’s setting mode on the expansion
box (VPE-S431).
SCAN: Displays the pattern of MODE1 to MODE6 repeatedly.
Cancelling the Visualizer Function:
Touch [NORMAL] on the VISUAL selection screen.
• This setting is enabled when OFF is selected for “Setting the
Visual Effect” (this page) and ON is selected for “Connecting and
Setting the External Expansion Box”, “Setting the VISUALIZER
Mode Display” (page 33).
Setting the Visual Effect
This setting becomes available when the expansion box (VPE-S431)
is connected.
Touch [V.SEL] on the visual main source screen.
1
The VISUAL selection screen is displayed.
Touch [VISUALIZER].
2
The Visualizer setting screen is displayed. If you do not
touch any button for 5 seconds, the operating display
buttons, [MAIN CONT.] etc., will disappear.
Touch the screen (visual screen only) after the
3
operation display has disappeared.
The VISUALIZER setup screen appears.
Select “ON” by touching [;] or [:] of V.EFFECT
4
within 5 seconds.
ON: Tur ns on the function for enhancing visual effects when
connected to two or more external monitors.
Set to OFF to cancel.
•V.EFFECT is not displayed when the audio main source is
selected.
• When the visual effect is set to ON, the rear monitor source cannot
be changed from the unit.
• This setting may not be performed while driving.
Touch [;] or [:] of the desired item to change its
3
setting.
Setting items:
TILT / SLIDE / MONITOR O/C (OPEN/CLOSE)
Touch [RETURN] to return to the previous screen.
4
Touch [MAIN CONT.] to return to the main source screen
that was displayed before the setup operation was
started.
Adjusting the Monitor Angle
Adjust the monitor’s angle (between 40 and 105 degrees) for optimum
visibility.
Setting item: TILT
Setting range: 1 to 10
• If the monitor touches an obstacle, remove the obstacle.
• The screen colour will vary when viewed at certain angles. Adjust
the screen angle for the best viewing position.
• If the voltage of the vehicle’s battery power is low, the screen may
blink when the screen angle is changed. This is not a malfunction.
Selecting the Monitor Position
The monitor can be set in 2 positions.
Setting item: SLIDE
Setting content: BACK / FRONT
BACK: Slides the display backwards.
FRONT: Slides the display forwards
• If the monitor is forcibly pushed or pulled, you may not be able to
set the monitor angle or position. In this case, press OPEN for
more than 2 seconds to close the monitor once, and then open the
monitor again.
Setting Automatic Opening/Closing of the Monitor
Setting item: MONITOR O/C (OPEN / CLOSE)
Setting content: MANUAL / FULL / CLOSE
MANUAL: The monitor is manually opened or closed by
FULL:The monitor automatically opens or closes when
CLOSE:The monitor automatically closes when the ignition
pressing OPEN.
the ignition key is turned to the “ACC” or “ON”
position.
key is turned OFF.
26-EN
Setup
DVD Setup
DVD Setup Operation
The Parking Brake must be engaged to access the DVD
mode screen. Attempting to access this screen while driving
will display the warning-CAN’T OPERATE WHILE DRIVING.
The DVD Setup operation can be carried out after removing
the disc from the unit.
The following steps 1 to 5 are common operations to each
“Setting item” of DVD Setup. Refer to each section for
details.
Touch [SYS.] on the main source screen.
1
The SYSTEM selection screen is displayed.
Touch [SETUP].
2
The SETUP screen appears.
Touch [] of DVD SETUP.
3
The DVD setup screen appears.
Touch [;] or [:] of the desired item to change its
4
setting.
Setting items:
MENU LANGUAGE / AUDIO LANGUAGE / SUBT. LANGUAGE
/ COUNTRY CODE / PARENTAL / DIGITAL OUT MODE /
OPTICAL OUT / TV SCREEN
Display example for DVD setup screen
Touch [;] or [:] to set a desired language.
Touch [RETURN] to return to the previous screen.
5
Touch [MAIN CONT.] to return to the main source screen
that was displayed before the setup operation was
started.
•
Immediately after inputting titles or changing the settings of DVD
mode (while the system is inputting the titles or data automatically)
do not turn the ignition key (engine key) to OFF.
Otherwise, a title may not be written, or the settings may not be
changed.
Changing the language setting
The audio language, subtitle language and menu language can be set
according to your preferences.
Once set, this becomes the default language. This function is
convenient when you always want to listen in English. (The language
setting is not effective on some discs. If not, the default language is
set from the factory.)
• When the settings are changed, the old settings are overwritten. Make
a note of the current settings before making changes. The settings are
not cleared even when the vehicle’s battery is disconnected.
•To temporarily change the language of the current disc, either do
so from the DVD menu or by using the operation described in the
section “Switching the Audio Tracks” (page 22).
• If the disc does not include the selected language, the disc’s default
language is set.
Setting of the Menu Language
Set the language used for the menus (title menu, etc.).
Setting item: MENU LANGUAGE
Setting contents: AUTO / ENGLISH / GERMAN / FRENCH /
JAPANESE / CODE
• When “AUTO” is selected, the primary menu language among the
recorded ones is played.
Setting of the Audio Language
Set the audio language produced from the speakers.
Setting item: AUDIO LANGUAGE
Setting contents: AUTO / ENGLISH / GERMAN / FRENCH /
JAPANESE / CODE
• When “AUTO” is selected, the primary audio language among the
recorded ones is played.
Touch [CODE] to display the numeric keypad screen.
Touch [ ] or [ ] to turn pages of setting items.
Numeric keypad input screen
The numeric keypad is used if you
want to play back in a language other
than that displayed, or to input your
parental lock password, etc.
Setting of the Subtitle Language
Set the language of the subtitles displayed on the screen.
Setting item: SUBT. LANGUAGE
Setting contents: AUTO / ENGLISH / GERMAN / FRENCH /
JAPANESE / CODE
• When “AUTO” is selected, the primary subtitle language among
the recorded ones is played.
To play in a language other than those displayed
1Touch [CODE].
The numeric keypad screen is displayed.
2Touch the 4-digit numeral of the language number.
As for the language number, refer to “List of Language
codes” (page 59).
3Touch [ENT] to memorize the number.
Continued
27-EN
Changing the Country Code Setting
Set the country code when setting the rating level (Parental lock).
Setting item: COUNTRY CODE
Setting content: CODE
• When the settings are changed, the old settings are overwritten.
Make a note of the current settings before making changes. The
settings are not cleared even when the vehicle’s battery is
disconnected.
1Touch [CODE].
2Touch [ALL DEL] or [BS].
Delete the displayed country number.
3Touch the 4-digit country code.
As for the country number, refer to “List of Country
Codes” (pages 60, 61).
4Touch [ENT] to memorize the code.
Setting the Rating Level (Parental Lock)
This function can help restrict the viewing of movies to children of
appropriate age levels only.
Setting item: PARENTAL
Setting content: INPUT
• When the settings are changed, the old settings are overwritten.
Make a note of the current settings before making changes. Then
settings are not cleared even when the vehicle’s battery is
disconnected.
• On unrated DVDs, playback will not be restricted even if the rating
level is set.
• Once set, this rating level remains in memory until changed. To
enable playback of discs of higher rating levels or to cancel the
parental lock, the setting must be changed.
• Not all DVDs provide a Parental Lock feature. If you are unsure
about a DVD, play it first to confirm. Do not leave DVDs
accessible to young children for whom you deem them
inappropriate.
1Touch [INPUT].
The numeric keypad screen is displayed.
2Touch the numeric keypad to input a 4-digit password.
The initial number is 1111.
Input number are displayed as “∗”.
3Touch [ENT] to memorize the number.
The PARENTAL screen appears.
Set the rating level of PARENTAL
4Touch [;] or [:] of PARENTAL to turn on.
5Touch [;] or [:] of PARENTAL LEVEL to select the
rating level (1 to 8).
Select “OFF” to cancel the parental lock or if you do not
want to set a rating level. The smaller the number, the
higher the rating level.
6Touch [RETURN] to return to the previous screen.
Changing the password
4Touch [INPUT] of PASSWORD CHANGE.
The numeric keypad screen is displayed.
5Touch the input screen to enter a new 4-digit password
•Keep a note of the number somewhere safe in case you should
forget it.
6Touch [ENT] to memorize the number.
7Touch [RETURN] to return to the previous screen.
Changing the rating level temporarily
Some discs may request that you change the rating level set
in the default settings during playback. In this case, the
message appears on the monitor screen “PARENTAL LEVEL
CHANGE OK? [YES] / [NO].”
If this screen appears, change the level as follows:
• To change parental level and play, touch [YES].
• To play without changing the parental level, touch [NO].
(When [NO] is touched, playback will be at the parental
level set in “Setting the Rating Level (Parental Lock).”)
Changing the Digital Output Setting
Use the following procedure to set the digital audio signal output from
the IVA-D300R/IVA-D300RB.
Setting item: DIGITAL OUT MODE
Setting contents: AUTO / LPCM
AUTO: The digital output is switched automatically according
to the type of audio signals being played.
Be sure to select “AUTO” when you want to connect a
digital audio processor and play Dolby Digital audio.
“AUTO” is the factory setting.
LPCM: The audio signals recorded on the disc are converted
to 48 kHz/16 bit (for DVDs) or 44.1 kHz (for video CDs
and CDs) linear PCM audio signals for output.
28-EN
Audio output/Optical digital audio output
DiscAudio recording
DVD
format
Dolby Digital
Linear
PCM
MPEG2
Video CD
CD
MP3
WMA
MPEG
Audio
Layer3
Bit Rate:
32kbps
320kbps
Windows
Media™
Audio
Bit Rate:
32kbps
320kbps
MPEG1
Linear PCM
~
~
DTS
DTS
48kHz/16bit
48kHz/20bit
48kHz/24bit
96kHz/16bit
96kHz/20bit
96kHz/24bit
32kHz/16bit
44.1kHz/16bit
48kHz/16bit
32kHz/16bit
44.1kHz/16bit
48kHz/16bit
Digital output
setting
AUTO
LPCM
AUTO
LPCM
AUTO
or
LPCM
AUTO
or
LPCM
AUTO
or
LPCM
AUTO
or
LPCM
AUTO
or
LPCM
AUTO
or
LPCM
AUTO or LPCM
AUTO or LPCM
AUTO or LPCM
AUTO
LPCM
AUTO or LPCM
AUTO or LPCM
AUTO or LPCM
AUTO or LPCM
AUTO or LPCM
AUTO or LPCM
Optical digital audio output
(when a digital audio
processor is connected)
DTS Elementary Stream
LPCM Encode
2ch Down mix
(48kHz/16bit)
Dolby Digital
LPCM (48kHz/16bit)
LPCM (48kHz/16bit)
LPCM (48kHz/16bit)
LPCM (48kHz/16bit)
LPCM (48kHz/16bit)
LPCM (48kHz/16bit)
LPCM (48kHz/16bit)
LPCM (48kHz/16bit)
LPCM (44.1kHz)
LPCM (44.1kHz)
DTS Elementary Stream
LPCM Encode
2ch Down mix
(44.1kHz/16bit)
LPCM Encode
2ch
(32kHz/16bit)
LPCM Encode
2ch
(44.1kHz/16bit)
LPCM Encode
2ch
(48kHz/16bit)
LPCM Encode
2ch
(32kHz/16bit)
LPCM Encode
2ch
(44.1kHz/16bit)
LPCM Encode
2ch
(48kHz/16bit)
Analog audio
output (Ai-NET,
RCA output)
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
29-EN
Setting the Digital Output
To connect an audio processor using the optical digital output, set to
“ON” by the following procedure.
Setting item: OPTICAL OUT
Setting contents: OFF / ON
• Afterwards, set ACC to OFF once, then turn it ON again. The
setting of Digital Output is decided.
Setting the TV Screen Setting
Use the procedure described below to modify the output screen
according to the type of TV monitor (rear monitor) being used.
This setting can also be applied for the IVA-D300R/IVA-D300RB.
If the rear monitor is not connected, the screen setting is 16:9.
•For some discs, the picture may not be set to the selected screen
size. (For details, refer to the explanation on the disc’s jacket.)
4:3 LETTER BOX:
Select this when connected to a conventional 4:3 size (normal
TV aspect ratio) monitor. There may be black stripes visible at
the top and bottom of the screen (when playing a 16 : 9 size
movie). The width of these stripes will depend upon the
original aspect ratio of the theatrical release of the movie.
4:3 PAN-SCAN:
Select this when connected to a conventional 4:3 size monitor.
The picture will fill the entire TV screen. However, due to the
mismatch in aspect ratio, parts of the movie at the extreme left
and right sides will not be visible (when playing a 16 : 9 size
movie).
GENERAL Setup
General Setup Operation
The Parking Brake must be engaged to access the DVD
mode screen. Attempting to access this screen while driving
will display the warning-CAN’T OPERATE WHILE DRIVING.
The following steps 1 to 5 are common operations to each
“Setting item” of GENERAL Setup. Refer to each section for
details.
Touch [SYS.] on the main source screen.
1
The SYSTEM selection screen is displayed.
Touch [SETUP].
2
The SETUP screen appears.
Touch [] of GENERAL SETUP.
3
The GENERAL setup screen appears.
Touch [;] or [:] of the desired item to change its
4
setting.
Setting items:
CLOCK / CLOCK ADJUST / DAYLIGHT SAVING TIME /
DEMONSTRATION / BEEP / AUTO SCROLL / RDS CLOCK
DISP / FM LEVEL / FM CONDITION / PI SEEK / RDS
REGIONAL / DRC*1 / DAB REGIONAL*1 / AUTO SW DAB
TO RDS*1 / PTY LANGUAGE / PHONE RECEIVE*2 / PLAY
MODE
*1Displayed when the DAB Receiver Box is connected. The
DAB operation is stated in pages 53 to 55.
*2Displayed only when MobileHub (CXA-B200NK) is
connected.
Touch [RETURN] to return to the previous screen.
5
Touch [MAIN CONT.] to return to the main source screen
that was displayed before the setup operation was
started.
• Immediately after inputting titles or changing the settings of
General Mode (While the system is inputting the titles or data
automatically) do not turn the ignition key (engine key) to OFF.
Otherwise, the title may not be written, or the settings may not be
changed.
16:9 WIDE:
Select this when connected to a wide screen TV. This is the
factory setting.
30-EN
Displaying the Time
The clock display is turned off or on respectively.
Setting item: CLOCK
Setting content: OFF / ON
Setting the Time
Setting item : CLOCK ADJUST
Further setting items : HOUR / MINUTE / TIME ADJUST
Setting content:
HOUR:Adjust the hour.
MINUTE: Adjust the minute.
RESET: If the clock shows less than 30 minutes past, the
0-23 / 0-59 / RESET
minute will be “: 00”; more than 30, the hour
advances.
• The clock-adjusting mode is cancelled when the power is turned
off, when [RETURN] or [MAIN CONT.] is touched.
Setting Daylight Saving Time
Setting item: DAYLIGHT SAVING TIME
Setting content: OFF / ON
ON: Place the Summer Time mode ON. The time advances
by one hour.
OFF: Return to the ordinary time.
Demonstration Function
This unit is equipped with a demonstration function capable of
showing basic operations of respective sources on the display.
Setting item: DEMONSTRATION
Setting content: OFF / ON
ON: Tu rns on the demonstration mode to show the basic
operations.
OFF: Tu rns off the demonstration mode.
• The demonstration operation is automatically repeated until the
function is turned off.
Sound (Beep) Guide Function
Setting item: BEEP
Setting content: OFF / ON
ON: Activate the Sound Guide mode.
OFF: Deactivate the Sound Guide mode. The sound guide
beep will not be produced when a button on the unit is
pressed.
Setting the Scroll
Scroll display is available if titles are entered in the disc. Scroll
display of CD text, folder names, file names and tag information is
also enabled.
Setting item: AUTO SCROLL
Setting content: OFF / ON
ON: Tu rns on the AUTO scroll mode. Scroll display is
repeated as long as the mode is turned on.
OFF: Tu rns off the AUTO scroll mode.
Scroll display is done once as a track is changed.
RDS Time Display
When ON is selected, the clock is adjusted automatically based on the
time data sent from the RDS broadcast.
Setting item: RDS CLOCK DISP
Setting content: OFF / ON
ON: Adjust the clock automatically based on the time data. In
this case, the clock cannot be adjusted manually.
To adjust it manually, select OFF.
Adjusting Source Signal Levels
If the difference in volume level between the CD and FM radio is too
great, adjust the FM signal level as follows.
Setting item: FM LEVEL
Setting content: LOW / HIGH
Setting the Sound Quality of the Tuner
The IVA-D300R/IVA-D300RB incorporates the MAX TUNE Pro for
the highest quality tuner audio. Moreover, you can choose between 3
settings to suit your own personal sound preferences and usage.
Setting item: FM CONDITION
Setting content: NORMAL / HI-FI / STABLE
When OFF is selected, the unit automatically keeps receiving the
related local RDS station.
Setting item: RDS REGIONAL
Setting content: OFF / ON
Setting ON/OFF for DRC (Dynamic Range Control)
If you set this ON when receiving the sound of a wide Dynamic
Range, the DRC (Dynamic Range Control) gain increases when the
source sound is small, and the DRC (Dynamic Range Control) gain
decreases when the source sound is large, making the Dynamic Range
narrower to give you better and more comfortable sound even in the
vehicle that produces a large noise.
Setting item: DRC
Setting content: OFF / ON
• When a radio programme is set to ON, sound other than what you
previously set may be produced depending on the broadcast. In this
case, turn the programme OFF.
• Use this function when the DAB Receiver Box is connected.
31-EN
Receiving Announcement Information of DAB Local Stations
Setting item: DAB REGIONAL
Setting content: OFF / ON
ON: You can automatically receive the announcement
interrupt of the regional you are currently in.
OFF: Announcement interrupt is valid for all religions.
• Use this function when the DAB Receiver Box is connected.
SYSTEM Setup
System Setup Operation
The Parking Brake must be engaged to access the System
mode screen. Attempting to access this screen while driving
will display the warning-CAN’T OPERATE WHILE DRIVING.
Setting for Automatic Change from DAB to RDS
When the DAB reception is poor, you can set this selection ON to
automatically change to the RDS station (a station that can be
received) within the same broadcasting station until good reception is
achieved. You can switch this for voice only (except Service label/
Dynamic label display). The display and operation remain as for
DAB.
Setting item: AUTO SW FROM DAB TO RDS
Setting content: OFF / ON
• Use this function when the DAB Receiver Box is connected.
Switching the Display Language of PTY (Programme Type)
You can select one of the patterns of the display languages. When the
optional DAB Receiver Box is connected, the setting is mutually
affected for both equipment.
Setting item: PTY LANGUAGE
Setting content: GB / NL / F / D / I / E
Switching the incoming calls of the telephone
This operation can be carried out only when a cellular phone and
MobileHub (CXA-B200NK) is connected.
Setting item: PHONE RECEIVE
Setting content: AUTO / MANUAL
• The incoming call can be switched to Automatic Calling or Manual
Calling.
Playing MP3/WMA Data
When using discs containing both audio data and MP3/WMA data.
Setting item: PLAY MODE
Setting content: CD / MP3
CD: Plays only the audio data on discs containing both audio
data and MP3/WMA data.
MP3: Plays only the MP3/WMA files on discs containing both
audio data and MP3/WMA data.
• Remove the disc from this unit before setting.
• When an MP3-compatible CD changer is used, this setting cannot
be applied.
The following steps 1 to 5 are common operations to each
“Setting item” of SYSTEM Setup. Refer to each section for
details.
Touch [SYS.] on the main source screen.
1
The SYSTEM selection screen is displayed.
Touch [SETUP].
2
The SETUP screen appears.
Touch [] of SYSTEM SETUP.
3
The SYSTEM setup screen appears.
Touch [;] or [:] of the desired item to change its
4
setting.
Setting items:
IN INT. MUTE / IN INT. ICON / NAV. IN / NAV. MIX /
EXPANSION BOX*
AUX IN-2*
2
2*
/ CAMERA IN / V.SEL KEY / ILLUMINATION COLOR (IVA-
D300R only) / A. PROC TYPE
*1The setting is effective when the external expansion box (VPE-
S431) is connected.
*2Displayed when the expansion box is set to ON.
Touch [RETURN] to return to the previous screen.
5
Touch [MAIN CONT.] to return to the main source screen
that was displayed before the setup operation was
started.
• Immediately after inputting titles or changing the settings of
System Mode (While the system is inputting the titles or data
automatically) do not turn the ignition key (engine key) to OFF.
Otherwise, a title may not be written, or the settings may not be
changed.
1
/ VISUALIZER*2 / AUX IN-1 /
2
/ AUX IN-3*2 / MONITOR OUT-1 / MONITOR OUT-
Setting the External Device Interrupt Mode
If an Alpine Ai-NET Interrupt Box (NVE-K200) is connected to the
IVA-D300R/IVA-D300RB, an Auxiliary Source will be allowed to
interrupt the current audio source. For example, you can listen to the
voice guidance of your navigation system when it occurs even while
you are playing a CD or DVD. The CD/DVD player will be
automatically muted during voice guidance. For further details, please
refer to the manual for NVE-K200.
Setting item: IN INT. MUTE
Setting content: OFF / ON
OFF: The volume level can be adjusted in Interrupt mode.
ON: Sound will not be output. The icon that is set in “Setting
the Interrupt Icon Display” is displayed.
• The auxiliary device being connected must have an Interrupt wire
with a negative trigger for this function to operate automatically.
Otherwise, a separate switch needs to be added to switch it
manually.
32-EN
Setting the Interrupt Icon Display
The unit can display the icon of an external device, such as a
telephone, whenever a phone call comes in to tell you there is a phone
call.
Setting item: IN INT. ICON
Setting content: INT / TEL
INT: The INT icon appears on the display.
TEL: When the external device (telephone) sends the
interrupt signal, the telephone icon appears on the
display.
• TEL icon on this setting is not related to TEL Link Operation
(pages 55 to 57).
Setting the Navigation Mode
When you connect an optional navigation equipment, set it to ON.
Setting item: NAV. IN
Setting contents: OFF / ON
ON: Navigation source is displayed.
OFF: Navigation source is not displayed. The settings related
to the navigation can not be changed from this unit.
Setting the Navigation Interruption
With an Alpine navigation system connected to the IVA-D300R/IVAD300RB, the voice guidance of the navigation system will be mixed
with the radio or CD play.
Setting item: NAV.MIX
Setting content: OFF / ON
OFF: The navigation interruption mode is turned off.
ON: The navigation interruption mode is on.
To adjust the navigation interruption volume level, the
adjustment for NAV. LEVEL can be performed in “Adjusting the
Audio” on page 23 after setting to ON.
• The audio volume during the navigation guide can be set by
adjusting the audio volume while the navigation guide continues.
When the navigation guide finishes, the previous audio volume and
the previous screen are restored. For exception, if the navigation
cuts in when the audio volume is lower than the setting level, the
audio volume during the navigation guide is reset the current
listening volume. (When the navigation guide cuts in, the audio
volume does not increase.)
• This setting is effective when NAV.IN of SYSTEM list screen is ON.
• When PXA-H510 or PXA-H900 is connected, NAV.MIX value set in
this unit does not affect PXA-H510 or PXA-H900.
Setting the VISUALIZER Mode Display
Select this display when displaying the source names of
VISUALIZER on the VISUAL selection screen.
Note that this setting is enabled only when the optional expansion
box (VPE-S431) is connected.
Setting item: VISUALIZER
Setting contents: OFF / ON
OFF: “VISUALIZER” and source names are not displayed on
the VISUAL selection screen.
ON: “VISUALIZER” and source names are displayed on the
VISUAL selection screen.
Setting the AUX Mode
Setting item: AUX IN-1, 2, 3
Setting content: OFF / ON
OFF: AUX source is not displayed.
ON: AUX source is displayed.
• OFF is not displayed when the optional DVD player or DVD
changer is connected.
• When OFF is selected, the settings related to AUX cannot be
changed from this unit.
• When either DVD player or DVD changer is connected to AUX IN
1, EXT. DVD is displayed on the screen. When both of them are
connected, EXT.DVD is displayed for AUX IN 1 and DVD CHG is
displayed for AUX IN 2.
•AUX IN 2,3 is displayed when the external expansion box (VPES431) is connected.
Naming External Devices
When more than one external device is connected, you can name each
(up to 3) as you like. After setting to ON in “Setting the AUX mode,”
touch any one of the [] buttons of AUX IN 1 through 3, then this
setting may be carried out.
Setting items: NAME
Setting contents: AUX / VCR / GAME-1,2 / TV / NAV.
• The selected source name is displayed instead of AUX source
name. When a source is selected, the Function Guide of AUX mode
appears.
• Only AUX IN-3 MODE can be named “NAV.” When AUX mode is
selected, “NAV.” is displayed as the source name.
This setting is recomended if you view the navigation screen on the
rear monitor. However, it is available only when the Alpine
navigation system (except RGB navigation) is connected.
• Only when an Alpine TV tuner is connected, can you operate the
displayed function guide from this unit.
Connecting and Setting the External Expansion Box
This setting becomes necessary when the optional expansion box
(VPE-S431) is connected.
Setting item: EXPANSION BOX
Setting content: OFF / ON
OFF: Select when the expansion box (VPE-S431) is not
connected.
ON: Select when the expansion box (VPE-S431) is
connected.
Adjusting the External Input Audio Level
After setting to ON in “Setting the AUX mode,” touch any one of the
[] buttons of AUX IN 1 through 3, then this setting may be carried
out.
Setting item: LEVEL
Setting content: LOW / HIGH
LOW: Decreases the external input audio level
HIGH: Increases the external input audio level
33-EN
Switching the Visual Input Signal
After setting to ON in “Setting the AUX mode,” touch any one of the
[] buttons of AUX IN 1 through 3, then this setting may be carried
out.
Setting item: SIGNAL
Setting content: NTSC / PAL
• The video input type can be changed.
Setting of the External Monitor Output
Set it to ON when you use the rear entertainment function (page 24).
Setting items: MONITOR OUT-1, 2
Setting contents: OFF / ON
ON: By setting the connected external monitor to ON, the
remote control will be usable.
OFF: When either MONITOR OUT 1 or 2 is set to OFF, only
one monitor can be set by the rear enter function.
When both MONITOR OUT 1 and 2 are set to OFF,
REAR SELECT, which is displayed on the SYSTEM
selection screen, cannot be used.
• “MONITOR OUT-2” is displayed when “ON” is set in
“Connecting and Setting the External Expansion Box” on page 33.
Optical Digital Input Selection for an External Audio
Processor
Make sure “OPTICAL OUT” is ON in “Setting the Digital Output”
(page 30) before switching this setting.
Setting item: A.PROC TYPE
Setting contents: PXA-H510 / OTHER
OTHER:
When connecting any audio processor via an optical
digital cable except the PXA-H510.
Connect the optical digital input connector with the
connector for the Head unit.
PXA-H510:
When connecting PXA-H510.
Connect the optical digital input connector with the
connector for the DVD.
• After input selection is completed, turn ignition OFF and back ON
again. Your setting of the optical digital input switch is completed.
DISPLAY Setup
Display Setup Operation
Setting of the Rear Camera
When the rear camera is connected, rear pictures are output on the
screen.
Setting item: CAMERA IN
Setting contents: OFF / NTSC/PAL
NTSC/PAL: Even if the shift lever is not set to reverse (R), the
rear pictures are output by pressing V.SEL and
selecting the CAMERA source.
OFF: The rear pictures are not output.
• By shifting to reverse (R), the rear pictures are output.
This function is effective when the reverse wire is properly
connected.
Setting Visual Mode
This setting changes the function of the V.SEL button on the unit.
Setting item: V.SEL KEY
Setting content: V.SEL / NAV.
NAV.: Pressing V.SEL directly switches to the navigation
screen. (Only when an Alpine optional RGB Navigation
is connected.)
V.SEL: Press V.SEL to recall the VISUAL Select screen.
Changing the Lighting Colour of Buttons
(IVA-D300R only)
Setting item: ILLUMINATION COLOR
Setting content: GREEN / RED
GREEN: Lighting colour is green.
RED:Lighting colour is red.
The Parking Brake must be engaged to access the Display
mode screen. Attempting to access this screen while driving
will display the warning-CAN’T OPERATE WHILE DRIVING.
The following steps 1 to 5 are common operations to each
“Setting item” of DISPLAY Setup. Refer to each section for
details.
Touch [SYS.] on the main source screen.
1
The SYSTEM selection screen is displayed.
Touch [SETUP].
2
The SETUP screen appears.
Touch [] of DISPLAY SETUP.
3
The DISPLAY setup screen appears.
Touch [;] or [:] of the desired item to change its
4
setting.
Setting items:
DIMMER / DIMMER LOW LEVEL / BACKGROUND / AUTO
BACKGROUND / FONT TYPE / FONT COLOR / TOUCH
PANEL / SCREEN ALIGNMENT
Touch [RETURN] to return to the previous screen.
5
Touch [MAIN CONT.] to return to the main source screen
that was displayed before the setup operation was
started.
• Immediately after inputting titles or changing the settings of
Display Mode (While the system is inputting the titles or data
automatically) do not turn the ignition key (engine key) to OFF.
Otherwise, a title may not be written, or the settings may not be
changed.
34-EN
Illumination Control
Backlighting is provided by a fluorescent light built into the liquid
crystal panel. The illumination control adjusts the brightness of the
backlighting based on the car ambient lighting for easier viewing.
Setting item: DIMMER
Setting content: OFF / ON / AUTO
OFF:Deactivate Auto Dimmer mode to keep the
background illumination of the monitor bright.
ON:Keep the background illumination of the monitor dark.
AUTO: Adjust the brightness of the background illumination
of the monitor automatically to the brightness of the
car interior.
However, when set to AUTO with the monitor closed,
the button lighting will become active when the
headlights are turned on. (This is not functional if the
illumination lead of the unit is not connected).
Adjusting the Minimum Level of Backlight
You can adjust the brightness of the backlight (LOW). This function
could be used, for instance, to change the screen brightness while
travelling at night.
Setting item: DIMMER LOW LEVEL
Setting content: -15 to +15
You can adjust the level between MIN (-15) and MAX (+15).
When it reaches the minimum or maximum point, the display
shows “MIN” or “MAX” respectively.
Switching Background Textures
You have a choice of 5 different background textures preset at the
factory.
Setting item: BACKGROUND
Setting content: MODE1 to 5
• When you select a source other than the built-in disc on this unit,
and the built-in disc is selected on the rear monitor connected to
the unit, background textures cannot be displayed on the unit.
• When an error message is displayed (ERROR, HI-TEMP, etc.),
background textures selected by this setting cannot be displayed on
the unit.
Switching the Font Back Display Colour
You can choose from 5 different display colours for the font back
(source title, shortcut display, etc.).
Setting item: FONT COLOR
Setting contents: MODE 1 to MODE 5
Turning the Touch Panel Vibration ON or OFF
You can turn the touch panel’s vibration ON or OFF during operation.
Setting item: TOUCH PANEL
Setting content: NORMAL / FORCE
NORMAL: Tu rns off vibration during operation.
FORCE: Tu rns on vibration during operation.
Adjusting the Touch Panel
Adjustment becomes necessary when the display position on the LCD
and the touch position on the touch panel do not match.
Setting item: SCREEN ALIGNMENT
Setting content:
1Touch [] of SCREEN ALIGNMENT.
The adjustment screen appears.
2 Accurately touch the mark provided in the lower left
corner of the screen.
The screen changes to the adjustment screen.
3 Accurately touch the mark provided in the upper
right corner of the screen.
This completes adjustment, and returns to the DISPLAY
setup mode screen.
• If you have touched a location other than the mark, touch
[RESET] to restore the adjustment screen to the initial setting.
• If you touch [RETURN] on the adjustment screen, no adjustment is
done and the DISPLAY setup screen is restored.
/ RESET
Setting Automatic Background Textures
Turn on the Automatic Background Texture Scroll to automatically
change background texture. The background texture will change each
time the ignition key is turned off and turned back on again (5
textures).
Setting item: AUTO BACKGROUND
Setting content: OFF / ON
ON: Tu rn on the Auto Background Texture Scroll mode.
The background textures will scroll when the ignition key
is turned off once and turned back on again as follows:
MODE1 → MODE2 → MODE3 → MODE4 →
MODE5 → MODE1
OFF: Tu rn off the Auto Background Texture Scroll mode.
Setting the Font Type
You can choose a character (text and tag information, etc.) font type
for the main display.
Setting item: FONT TYPE
Setting content: FONT 1 / FONT 2
The Parking Brake must be engaged to access the
i-Personalize mode screen. Attempting to access this screen
while driving will display the warning-CAN’T OPERATE WHILE
DRIVING.
MX (Media Xpander) makes vocals or instruments sound distinct
regardless of the music source. The radio, CD, and MP3, will be able
to reproduce the music clearly even in cars with a lot of road noise.
Touch [SYS.] on the source main screen.
1
The SYSTEM selection screen is displayed.
Touch [i-Personalize].
2
The screen changes to the i-Personalize.
Touch [;] or [:] of MEDIA XPANDER to turn MX
3
ON or OFF.
OFF: MX mode is cancelled for all music sources.
ON: The selected MX mode is turned on.
After setting to ON, touch [].
4
The screen changes to the Media Xpander setting screen.
6 Touch [RETURN] to return to the previous screen.
• When OFF is selected, MX effect of each MX mode will be off.
• Each music source, such as radio, CD and MP3 can have its own
MX setting.
•AUX is displayed when ON is selected in “Setting the AUX Mode”
(page 33).
• MX mode does not function for MW, LW radio when MX is ON.
• MX COMPRESS MEDIA is applied for MP3/WMA, MMD.
• If the unit is connected to an audio processor with the MX function,
such as PXA-H700, etc., the MX processing can be applied to the
audio processor. In this case the audio processor needs to be
adjusted. For details, refer to the Owner’s Manual of the audio
processor.
• This function is inoperable when Defeat is set to ON.
Bass Engine Function
Setting the Bass Engine
The following steps 1 to 6 are common operations to each
“Setting item” of bass engine Setup. Refer to each section for
details.
1 Touch [SYS.] on the source main screen.
The SYSTEM selection screen is displayed.
Touch [i-Personalize].
2
The i-Personalize screen appears.
Touch [;] or [:] of the desired MX mode.
5
The level of the audio source can be adjusted.
MX CD (OFF, CD1 to 3)
The large quantity of uncompressed CD data is
processed to reproduce the sound with more clarity.
MX COMPRESS MEDIA (OFF, CMPM1 to 3) / MX DAB
(OFF, DAB 1 to 3)
This corrects information that was omitted at the time of
compression. This reproduces a well-balanced sound
close to the original.
MX FM (OFF, FM1 to 3)
The medium to high frequencies become more clear, and
produces well balanced sound in all the bands.
MX DVD (OFF, MOVIE 1 to 2)
The dialogue portion of the video is reproduced more
clearly.
(DVD MUSIC)
This disk contains a large quantity of data such as a
music clip. MX uses this data to reproduce the sound
accurately.
MX AUX 1 to 3 (OFF, MP3, MOVIE, MUSIC)
Choose the MX mode (MP3, MUSIC, or MOVIE) that
corresponds to the media connected.
Touch [] of BASS ENGINE.
3
The screen changes to the Bass Engine setting screen.
5 Touch [;] or [:] of the selected setting item, and
change the setting.
• When setting is complete, storing in memory is recommended.
Touch [RETURN].
6
The screen returns to the previous one.
Selecting Bass EQ mode (Maker’s setting)
10 typical equalizer settings are preset at the factory for a variety of
musical source material.
Setting item: BASS MAX EQ
Setting contents: FLAT / ROCK / POPS / JAZZ / ELECTRIC /
* Contents that are adjusted in parametric EQ.
HIPHOP / EASY / COUNTRY / CLASSIC /
NEWS / CUSTOM
*
36-EN
5.1ms
∗
Adjusting and Storing/Recalling the Parametric EQ
The frequency bands of the graphic equalizer are fixed. This makes it
very difficult to correct for undesired peaks and dips at specific
frequencies. The parametric equalizer’s centre frequency can be tuned
to these specific frequencies. Then, the bandwidth (Q) and level are
fine-tuned, independently, to make the necessary corrections. The
parametric equalizer function is an advanced tool for serious
audiophiles.
Setting item: P-EQ
Further setting items: HIGH / MID-HIGH / MID-LOW / LOW
Setting contents: FREQ / LEVEL / Q
1Touch [] of P-EQ.
The screen changes to the P-EQ setup screen.
2Touch a desired item for adjustment.
FREQ : Adjusts the centre frequency.
LEVEL : Adjusts the level.
Q:Adjusts the bandwidth (Q).
3 After the necessary selection is done in Step 2 above,
adjust a desired band by touching [;] or [:]
corresponding to that band.
cannot be adjusted in HIGH).
MID-HIGH : 1.0, 2.0, 3.0
MID-LOW : 1.0, 1.5, 2.0
LOW: 1.0, 2.0, 3.0
• If you set the parametric EQ, BASS EQ setting content is set to
“CUSTOM.”
4 When adjusting another band, repeat Steps 2 and 3
above.
5Touch [RETURN] to return to the previous screen.
Storing Adjusted Contents
The following operation is performed after Step 5 above.
6Touch [MEMORY].
7Within 5 seconds, touch any one of preset buttons
[P.SET 1] through [P.SET 6] on the BASS ENGINE
screen.
The adjusted contents are stored on the P.SET number
you touch.
• The stored contents on the P.SET number remain undeleted despite
a following reset operation or disconnection of the battery power
cord.
• Adjusted/set contents of each setting item in Bass Engine can be
stored in the preset buttons (1 through 6).
Recalling the Adjusted and Stored Contents
The following operation is performed after Step 5 above.
6Touch any one of [P.SET 1] to [P.SET 6] on the BASS
ENGINE screen.
The adjusted and stored contents are recalled.
• The frequencies of adjacent bands cannot be adjusted within 4
steps.
• This function is inoperable when Defeat is set to ON.
About the Time Correction
The distance between the listener and the speakers in a car vary
widely due to the special conditions of the mobile environment. This
difference in the distances from the speakers to the listener creates a
shift in the sounds image and frequency characteristics. This is caused
by the time delay between the sound reaching the listener’s right
versus left ear.
To correct this, the IVA-D300R/IVA-D300RB is able to delay the
audio signal to the speakers closest to the listener. This effectively
creates a perception of increased distance for those speakers. The
listener can be placed at an equal distance between the left and right
speakers for optimum staging.
The adjustment will be made for each speaker in a step of 0.1 ms.
Example 1. Listening Position: Front Left Seat
Adjust the time correction level of the front left speaker to a
high value and the rear right to zero or a low value.
0.5m
2.25m
∗
Tips
*
Subwoofer speaker
You cannot change the time correction value for the
subwoofer, but you can set the subwoofer’s apparent position
to the front by adjusting the time correction value of the front
and rear speakers.
For details, refer to the “Tips” on page 39.
Here we calculate the time correction value for the front left
speaker in the diagram above.
Conditions:
Farthest Speaker – listening position:2.25 m (88-9/16")
Front left speaker – listening position: 0.5 m (19-11/16")
Calculation: L = 2.25 m – 0.5 m = 1.75 m (68-7/8")
Time correction = 1.75 ÷ 343
**
Speed of sound: 343 m/s (765 mph) at 20˚C
The sound is not balanced because the distance between the
listening position and the various speakers is different.
The difference in distance between the front left speaker and
the rear right speaker is 1.75 m (68-7/8").
Time correction eliminates the differences in the time required
for the sound to reach the listening position.
The time of the front left speaker is corrected by 5.1 ms so that
its sound reaches the listening position at the same time as the
sound of other speakers.
In other words, giving the front left speaker a time correction
value of 5.1 ms makes it seem as if the distance to the front left
speaker is the same as the distance to the farthest speaker.
**
× 1000 = 5.1 (ms)
Continued
37-EN
Example 2. Listening Position: All Seats
Adjust the time correction level of each speaker to almost the
same level.
1 Sit in the listening position (driver’s seat, etc.) and
measure the distance (in meters) between your head
and the various speakers.
2 Calculate the difference between the distance to the
farthest speaker and the other speakers.
L = (distance to farthest speaker) – (distance to other
speakers)
3 Divide the distances calculated for the speakers by the
speed of sound (343 m/s (765 mph) at 20˚C).
These values are the time correction values for the
different speakers.
Adjusting and Storing/Recalling the Bass Focus
The time difference between the front-rear/left-right speakers, can be
adjusted at the same time. With an initial delay of 0.1 ms for each of
the 0 to 99 steps, audible time correction can be done.
Setting item: BASS FOCUS
Setting contents: 0-99
1Touch [] of BASS FOCUS.
The screen changes to the BASS FOCUS setup screen.
2 Set the number of steps in the front and rear as well as
on the right and left by touching either button [;] or [:]
of the front, rear, right and left speakers.
3 Repeat the Step 2 above to set another channel
(speaker).
4Touch [RETURN] to return to the previous screen.
• Any manual time correction adjustments will also affect
corrections made for bass focus.
Storing Adjusted Contents
The following operation is performed after Step 4 above.
5Touch [MEMORY].
6Within 5 seconds, touch any one of preset buttons
[P.SET 1] through [P.SET 6] on the BASS ENGINE
screen.
The adjusted contents are stored on the P.SET number
you touch.
• The stored contents on the P.SET number remain undeleted despite
a following reset operation or disconnection of the battery power
cord.
• Adjusted/set contents of each setting item in Bass Engine can be
stored in the preset buttons (1 through 6).
Recalling the Adjusted and Stored Contents
Following operation is performed after Step 4 above.
5Touch any one of [P.SET 1] to [P.SET 6] on the BASS
ENGINE screen.
Recall the adjusted and stored contents.
Time Difference Table
Number of
Steps
Time
Difference
(ms)
0.0
0
0.1
1
0.2
2
0.3
3
0.4
4
0.5
5
0.6
6
0.7
7
0.8
8
0.9
9
1.0
10
1.1
11
1.2
12
1.3
13
1.4
14
1.5
15
1.6
16
1.7
17
1.8
18
1.9
19
2.0
20
2.1
21
2.2
22
2.3
23
2.4
24
2.5
25
2.6
26
2.7
27
2.8
28
2.9
29
3.0
30
3.1
31
3.2
32
3.3
33
3.4
34
3.5
35
3.6
36
3.7
37
3.8
38
3.9
39
4.0
40
4.1
41
4.2
42
4.3
43
4.4
44
4.5
45
4.6
46
4.7
47
4.8
48
4.9
49
5.0
50
Distance
cm (inch)
0.0
3.4 (1-3/8")
6.9 (2-3/4")
10.3 (4-1/16")
13.7 (5-3/8")
17.2 (6-13/16")
20.6 (8-1/8")
24.0 (9-7/16")
27.4 (10-13/16")
30.9 (12-3/16")
34.3 (13-1/2")
37.7 (14-13/16")
41.2 (16-1/4")
44.6 (17-9/16")
48.0 (18-7/8")
51.5 (20-1/4")
54.9 (21-5/8")
58.3 (22-15/16")
61.7 (24-1/4")
65.2 (25-5/8")
68.6 (27")
72.0 (28-3/8")
75.5 (29-11/16")
78.9 (31-1/16")
82.3 (32-3/8")
85.8 (33-3/4")
89.2 (35-1/8")
92.6 (36-7/16")
96.0 (37-3/4")
99.5 (39-13/16")
102.9 (40-1/2")
106.3 (41-7/8")
109.8 (43-1/4")
113.2 (44-9/16")
116.6 (45-7/8")
120.1 (47-5/16")
123.5 (48-5/8")
126.9 (49-15/16")
130.3 (51-5/16")
133.8 (52-11/16")
137.2 (54")
140.6 (55-3/8")
144.1 (56-3/4")
147.5 (58-1/16")
150.9 (59-3/8")
154.4 (60-3/4")
157.8 (62-1/8")
161.2 (63-7/16")
164.6 (64-3/4")
168.1 (66-3/16")
171.5 (67-1/2")
Number of
Steps
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
Time
Difference
(ms)
5.1
5.2
5.3
5.4
5.5
5.6
5.7
5.8
5.9
6.0
6.1
6.2
6.3
6.4
6.5
6.6
6.7
6.8
6.9
7.0
7.1
7.2
7.3
7.4
7.5
7.6
7.7
7.8
7.9
8.0
8.1
8.2
8.3
8.4
8.5
8.6
8.7
8.8
8.9
9.0
9.1
9.2
9.3
9.4
9.5
9.6
9.7
9.8
9.9
Distance
cm (inch)
174.9 (68-7/8")
178.4 (70-1/4")
181.8 (71-9/16")
185.2 (72-7/8")
188.7 (74-1/4")
192.1 (75-5/8")
195.5 (77")
198.9 (78-5/16")
202.4 (79-11/16")
205.8 (81")
209.2 (82-3/8")
212.7 (83-3/4")
216.1 (85-1/16")
219.5 (86-3/8")
223.0 (87-3/4")
226.4 (89-1/8")
229.8 (90-1/2")
233.2 (91-13/16")
236.7 (93-3/16")
240.1 (94-1/2")
243.5 (95-7/8")
247.0 (97-1/4")
250.4 (98-9/16")
253.8 (99-7/8")
257.3 (101-1/4")
260.7 (102-5/8")
264.1 (104")
267.5 (105-5/16")
271.0 (106-11/16")
274.4 (108-1/16")
277.8 (109-3/8")
281.3 (110-3/4")
284.7 (112-1/16")
288.1 (113-1/16")
291.6 (114-3/4")
295.0 (116-1/8")
298.4 (117-1/2")
301.8 (118-13/16")
305.3 (120-3/16")
308.7 (121-1/2")
312.1 (122-7/8")
315.6 (124-1/4")
319.0 (125-9/16")
322.4 (126-7/8")
325.9 (128-5/16")
329.3 (129-5/8")
332.7 (131")
336.1 (132-5/16")
339.6 (133-11/16")
38-EN
Example of Bass Focus Setting
1 After entering corrections for the front (left and right)
speakers in STEP 15, the time difference is 1.5 ms for
both front-left and front-right speakers.
1.5ms
∗
1.5ms
2 After entering corrections for the left (front and rear)
speakers in STEP 15, the time difference becomes 3.0
ms** for the front left speaker and 1.5 ms for the left
rear speaker.
**
Because the time difference was already set to 1.5 ms for the
front left speaker in Step 1, the additional correction in STEP
15 makes the time difference of the front left speaker 3.0 ms.
3.0ms
1.5ms
1.5ms
1.5ms
∗
Tips
*
Subwoofer speaker
Delay (turn the rotary encoder) the audio signal to the front
(left and right) speakers to make the apparent position of the
subwoofer to be at the front. In doing this, the apparent
position between the front (left and right) speakers and
subwoofer will appear equal to the driver. After performing
above, you can change the positions of left and right speakers
by delaying the time.
1.5ms
Storing the Adjusted Contents
The storing/recalling of time correction operation is performed after
Step 4 above.
5Touch [MEMORY].
6Within 5 seconds, touch any one of preset buttons
[P.SET 1] through [P.SET 6] on the BASS ENGINE
screen.
The adjusted contents will be stored on the preset
number you touch.
• The stored contents on the P.SET number remain undeleted despite
a reset operation or disconnection of the battery power cord.
• Adjusted/set contents of each setting item in Bass Engine can be
stored in the preset buttons (1 through 6).
Recalling the Stored Time Correction Setting
The storing/recalling of time correction operation is performed after
Step 4 above.
5Touch any one of [P.SET 1] to [P.SET 6] on the BASS
ENGINE screen.
The stored adjusting contents will be recalled.
Adjustment and Storing/Recalling of the Built-in
Crossover
The High and Low Pass Filters on this unit can be adjusted to suit
your personal taste.
Setting item: X-OVER
Setting contents: LPF / HPF
1Touch [] of X-OVER.
The screen changes to the X-OVER setup screen.
2 Adjust LPF/HPF by touching [;] or [:] of LPF or HPF.
LPF: Outputs all frequencies lower than that selected
according to your preference.
(Only available when using the subwoofer output from
this unit.)
HPF: Outputs all frequencies higher than that selected
according to your preference.
3Touch [RETURN] to return to the previous screen.
• When the subwoofer output of this unit is turned OFF, LPF and
phase are deactivated.
• Except when the HPF and LPF is turned OFF, the subwoofer is in
monaural mode.
Adjustment and Storing/Recalling of Time
Correction
Before performing the following procedures, refer to “About the
Time Correction” (page 37).
* The setting is available in the visual source mode. (except
navigation screen)
Change the setting on the selected item by
5
touching its [;] or [:].
Touch [RETURN] to return to the previous screen.
6
Touch [MAIN CONT.] to return to the main source screen
that was displayed before the setup operation was
started.
Selecting the VISUAL EQ Mode (Maker’s setting)
You can select a mode suitable for the subject image.
Setting item: VISUAL EQ
Setting contents: OFF (FLAT) / NIGHT M. / SOFT / SHARP /
CONTRAST / P-1 / P-2
OFF (FLAT): Initial Setting
NIGHT M.: Suitable for movies in which dark scenes
SOFT:Suitable for CGs and animated films.
SHARP:Suitable for old movies where images are not
CONTRAST: Suitable for recent movies.
P-1:Recalls the VISUAL EQ mode being stored on
P-2:Recalls the VISUAL EQ mode being saved on
•To return to the initial setting, after selecting any one of the setting
contents (NIGHT M. to CONTRAST) and adjusting a desired
brightness, picture tint, etc., set this function to OFF.
• If your desired brightness, picture tint, etc., are adjusted after
selecting any one of the setting contents (NIGHT M. to
CONTRAST), “CUSTOM” is displayed.
Adjusting Brightness
Setting item: BRIGHT
Setting content: -15 ~ +15
You can adjust the brightness between MIN (–15) and MAX (+15).
When it reaches the minimum or maximum point, the display shows
“MIN” or “MAX” respectively.
frequently appear.
clearly shown.
preset No.P-1 from “Storing VISUAL EQ” (page
41).
preset No.P-2 from “Storing VISUAL EQ” (page
41).
40-EN
Adjusting Colour of Picture
Setting item: COLOR
Setting content: -15 ~ +15
You can adjust the colour between MIN (–15) and MAX (+15).
When it reaches the minimum or maximum point, the display
shows “MIN” or “MAX” respectively.
• Colour adjustment can be made only in the navigation, DVD,
AUX1 and AUX2 modes.
• Colour adjustment cannot be made if a Navigation system with the
RGB feature is connected.
Adjusting Tint of Picture
Setting item: TINT
Setting content: G15 ~ R15
Adjust the colour from G15 to R15. “G MAX” or “R MAX” is
displayed at the maximum of each colour.
•Tint adjustment can be made only in the navigation, DVD, AUX1
and AUX2 modes.
•Tint adjustment cannot be made if a Navigation system with the
RGB feature is connected.
• When setting PAL, you cannot adjust the TINT.
Adjusting Image Contrast
Setting item: CONTRAST
Setting content: -15 to +15
Adjustment of contrast is done in the range of -15 to +15.
“HIGH” and “LOW” appear as the maximum and minimum
values specified.
Adjusting Picture Quality
Setting item: SHARP
Setting content: -15 to +15
Adjustment of picture quality is done in the range of -15 to
+15. “HARD” and “SOFT” appear as the maximum and
minimum values specified.
• Picture Quality adjustment can be made only in the navigation,
DVD, AUX1 and AUX2 modes.
• Picture Quality adjustment cannot be made if a Navigation system
with the RGB feature is connected.
Data Download
About SOUND SETUP Download
You can download data (from Alpine’s website) to a CD-R/CD-RW or
HDD, and download and store the data to the IVA-D300R/IVAD300RB.
To start SOUND SETUP download, access the URL below and follow
the on-screen instructions.
http://www.alpine.com or http://www.alpine-europe.com
or http://www.alpine.com.au
Downloadable data
Parametric
equalizer
Time correction
Crossover
The file name of download data shall be
“A_U*****.MP3.”
A_U∗∗∗∗∗.MP3
You can create a file name via the website. Do not change a
file name once it has been created. Malfunction may result.
•For details about procedures of download, see ALPINE’s web site.
• If a external audio processor is connected, data that is downloaded
cannot be used.
Data is memorized in Preset 6 of the
Parametric EQ Mode.
Data is memorized in Preset 6 of the
Time Correction Mode.
Data is memorized in Preset 6 of the
crossover mode.
Extender (fixed)
Identifier (alphabet or number 5
letters maximum)
Header (fixed)
Storing VISUAL EQ
You can store the settings made for “Adjusting Image Brightness,
Tint, Depth, Picture Quality and Contrast.”
Setting item: USER MEMORY
Setting content: P-1 / P-2
1 After completing “Adjusting Image Brightness, Tint,
Depth, Picture Quality, and Contrast” (this page), touch
[;] or [:] of USER MEMORY and then select preset
number “P-1” or “P-2” to which the settings are to be
stored.
2 After selecting a preset No., touch [WRITE].
The adjusted VISUAL EQ mode is stored by the above
operations.
•You can recall the VISUAL EQ mode stored here from P-1 or P-2
of “Selecting the VISUAL EQ Mode” (page 40).
41-EN
Data Downloading
Insert the CD-R/CD-RW disc containing the data.
1
• If the optional HDA-5460 is connected, steps 2 to 7 can be
performed after the data has downloaded removable hard disc. The
MM DRIVER main source screen can then be selected on this unit.
• If audio data is contained in a CD-R/CD-RW, set to “MP3” in
“Playing MP3/WMA Data” (page 32).
Touch [SYS.].
2
The SYSTEM selection screen appears.
Touch [i-Personalize].
3
The i-Personalize screen appears.
Touch [] of DATA DOWNLOAD.
4
Touch [] of SOUND SETUP.
5
The unit starts searching the disc for data. When the data
search has completed, the Data Download file selection
screen is displayed.
• If a file is not found by the data search, “NO FILE” is indicated.
Touch [] of file which is to be downloaded.
6
Data downloading starts.
When data has been successfully downloaded, the
confirmation screen is displayed for 5 seconds, and the
screen returns to the file selection screen.
PARAMETRIC EQ data
The data is memorized in Preset 6 of Parametric EQ mode.
The memorized data settings in Preset 6 (Parametric EQ
mode) are automatically applied.
X-OVER (Crossover) data
The data is memorized in Preset 6 of X-OVER mode. The
memorized data settings in Preset 6 (X-OVER mode) are
automatically applied.
TIME CORRECTION data
The data is memorized in Preset 6 of the Time correction
mode. The memorized data settings in Preset 6 (Time
Correction mode) are automatically applied.
Touch [RETURN] to return to the previous screen.
7
Touch [MAIN CONT.] to return to the main source screen
which was previously set.
• When you download the data again, the data is overwritten in
Preset 6.
Setting AMP Link (Optional)
Adjusting and Storing/Recalling the External
Amplifier (Optional)
When an external amplifier (MRD-M301 or MRD-M501) is
connected, you can set it from this unit. Up to eight amplifiers can be
set.
• If amplifier settings are made on the unit, do not then change the
setting with the amplifier buttons, as the amplifier display may not
match the operation of the unit.
Touch [SYS.] on the main source screen.
1
The SYSTEM selection screen appears.
Touch [i-Personalize].
2
The i-Personalize screen appears.
Touch [] of AMPLIFIER LINK.
3
The AMPLIFIER LINK list screen* appears.
* Connected external amplifiers are listed, and their temperature
(Celsius °C), voltage, and electric current are displayed.
•For details of the adjustment mode, refer to the Owner’s Manual of
the external amplifier.
To adjust another amplifier, touch [RETURN] and
6
then repeat Steps 4 and 5 above.
Touch [RETURN] to return to the previous screen.
7
Touching [MAIN CONT.] restores the main source screen
that was displayed before amplifier adjustment was
started.
Storing Contents of the Amplifier Adjustment
1 After adjusting the amplifier, select P-1 or P-2 by
touching [;] or [:] of MEMORY WRITE from the
adjustment mode list.
2Touch [WRITE].
The contents of the adjustment will be stored on the
preset number you have touched.
• The stored information remains undeleted even if a reset operation
is performed, or if the battery cord is disconnected.
42-EN
Recalling the Stored Contents of Amplifier
Adjustment
1 Select P-1 or P-2 by touching [;] or [:] of MEMORY
READ from the adjustment mode list.
2Touch [READ].
Stored adjustment data will be recalled.
Titling the Amplifier
From the AMPLIFIER LINK list screen, touch []
1
of an amplifier to which a title is to be given.
The adjustment mode list screen appears.
Touch [] of NAME.
2
The title input screen appears.
Touch the desired character symbols.
3
You can use up to 8 characters.
After the input, touch [ENT] to confirm your entry.
4
As the entry is confirmed, the screen immediately before
the current one will be restored, and the title that has been
entered from the AMPLIFIER LINK list screen is shown.
Displaying Status of External Amplifier
You can display the status of the connected external amplifier (MRDM301 or MRD-M501) for AMP Link.
External Audio Processor
(Optional)
When an external audio processor is connected to this unit, you can
operate it from this unit. Some audio processors may not be operated.
When PXA-H510 or PXA-H900 is connected, some of the operations
may not be performed from this unit. In this case, operate them in the
connected product. Explanations below is the case when PXA-H700
or PXA-H701 is connected for example.
Refer also to the operating instructions of the connected audio
processor.
• The adjustments or settings performed on the connected audio
processor cannot be operated properly from this unit.
The Parking Brake must be engaged to access the Audio
Processor mode screen. Attempting to access this screen
while driving will display the warning-CAN’T OPERATE WHILE
DRIVING.
Continued
Touch [V.SEL] on the main source screen.
1
The VISUAL selection screen appears.
Touch [AMP STATUS].
2
The AMP status screen appears.
Display Example for AMP status screen
2
1 Amplifier Name
2 Turns pages
3 Temperature (°C)
4 Voltage (V)
5 Electric Currency
To cancel the AMP status screen, touch [V.SEL].
3
The VISUAL selection screen is displayed.
Touch [NORMAL].
4
The screen returns to the normal screen.
1
2
3
4
5
43-EN
Adjustment Procedure for Dolby Surround
Make the adjustments described below in order to reproduce Dolby
Digital and DTS sound with greater accuracy.
Adjustment procedure
Speaker Setup (page 48)
1
(Turning the speakers to be used on and off and
setting their response)
B
Adjusting the speaker levels (page 49)
2
(Adjusting the signal output level to the various
speakers)
B
Mixing bass sound to the rear channel (page
48)
3
(Achieving smooth sound in the rear seat by mixing
the front audio signals with the rear speaker signals)
B
Adjusting the acoustic image (page 48)
(Adjusting the acoustic image to achieve a sound as
4
if the centre speaker were directly in front of the
listener)
• Settings above can be carried out even when the speaker is set to
OFF in “Speaker Setup” (page 48).
•To use the subwoofer in MONO with PXA-H700 or PXA-H701
connected, connect the subwoofer to the subwoofer output terminal
of PXA-H700 or PXA-H701.
B
Achieving powerful high volume sound (page
49)
5
(Achieving energetic sound with even greater power,
like the sound in a movie theater)
B
Adjusting the DVD Level (page 49)
6
(Adjust the volume (signal level) in the Dolby Digital,
Pro Logic II, DTS and PCM modes.)
B
Storing settings in the Memory (page 49)
(Storing all the settings and adjustments made on the
7
IVA-D300R/IVA-D300RB (not only the above settings/
adjusts) in the memory)
In case of combining the Automatic adjustments etc.
We recommend to make the Automatic adjustments before the Dolby
Surround adjustments.
Set MX Mode of the External Audio
Processor
Before performing the operations below, set MX (Media Xpander) mode of
the PXA-H700 to “AUTO” when the PXA-H700 is connected.
Check that Defeat mode is off.
1
Touch [SYS.] on the main source screen.
2
The SYSTEM selection screen appears.
Touch [i-Personalize].
3
The i-Personalize screen will appear.
Select ON or OFF of MX by touching [;] or [:] of
4
MEDIA XPANDER.
OFF: Tu rns off the MX effect of every music source.
ON: Tu rns on the specified MX mode.
Touch [] after setting to ON.
5
The Media Xpander setup screen appears.
44-EN
Touch [;] or [:] of the desired MX mode.
6
• Music source (such as radio broadcasts and CDs, excluding MW,
LW radio) level can be set.
MX CD (OFF, CD 1 to 3)
CD mode processes a large quantity of data. This data is
used to reproduce the sound cleanly by making use of the
data quantity.
MX COMPRESS MEDIA (OFF, CMPM 1 to 3) / MX DAB (OFF,
DAB 1 to 3)
This corrects information that was omitted at the time of
compression. This reproduces a well-balanced sound close to
the original.
MX FM (OFF, FM 1 to 3)
The medium to high frequencies become more clear, and
produces well balanced sound in all the bands.
MX DVD (OFF, MOVIE 1 to 2)
The dialogue portion of the video is reproduced more clearly.
(DVD MUSIC)
This disk contains a large quantity of data such as music clip.
MX uses this data to reproduce the sound accurately.
MX AUX 1 to 3 (OFF, MP3, MOVIE, MUSIC)
Choose the MX mode (MP3, MUSIC, or MOVIE) that
corresponds to the media connected.
Touch [RETURN] to return to the previous screen.
7
• The contents of MX set here is reflected to PXA-H700 or PXAH701.
• When OFF is selected, MX effect of each MX mode will be OFF.
• Each music source, such as radio, CD, and MP3 can have its own
MX setting.
• MX mode does not function when MX is ON for MW, LW radio.
• MX COMPRESS MEDIA is applied for MP3/WMA, MMD.
X-OVER Adjustment
Touch [;] or [:] of the speaker to adjust its
8
channel.
When adjusting another channel, repeat steps 7
9
and 8 above.
Touch [RETURN] to return to the previous screen.
10
• When the speaker is set to the “OFF” mode, the X-OVER for that
speaker cannot be set. Refer to “Setting the speakers” (page 44).
• Check the playback frequencies of the connected speakers before
adjusting.
• In order to protect the speakers, there is no OFF setting for the
subwoofer low pass filter (the slope remains the same).
• Even if Tweeter is selected for FRONT 1, the filter OFF (slope
OFF) of the H.P.F. can be set. If the slope is set to OFF, speakers
may be damaged. Take care with this setting.
Performing Time Correction Manually (TCR)
Because of the particular conditions inside the vehicle, there can be
major differences in the distances between the various speakers and
the listening position. It is possible to calculate the optimum
correction values and eliminate the time error at the listening position
yourself using this function.
Check that Defeat mode is off.
1
Sit in the listening position (the driver’s seat, for
2
example) and measure the distance (in meters)
between your head and the various speakers.
Calculate the difference in distance between the
3
farthest speaker and the other speakers.
L = (distance of farthest speaker)
– (distance of other speakers)
Check that Defeat mode is off.
1
Touch [SYS.] on the main source screen.
2
The SYSTEM selection screen appears.
Touch [i-Personalize].
3
The i-Personalize screen will appear.
Touch [] of A.PROCESSOR.
4
The A.PROC list screen appears.
Touch [;] or [:] of X-OVER to select L/R or L+R.
5
L/R: Different adjustment values can be set for the left
and right channels.
L+R: Sets the same adjustment values for the left and
right channels.
Touch [] of X-OVER.
6
The X-OVER adjustment screen appears.
Touch a desired adjustment mode.
7
FREQ: Adjust the H.P.F. or L.P.F. cutoff frequency.
The adjustable bands differ according to the
SLOPE: Adjust the H.P.F. or L.P.F. slope.
LEVEL: Adjust the H.P.F. or L.P.F. level.
channel (speaker).
Divide the distances calculated for the different
4
speakers by the speed of sound (343 m/s
temperature 20°C).
This value is the time correction value for the various
speakers.
Concrete examples
Calculating the time correction value for the front left speaker
on the diagram below.
Conditions:
Distance between farthest speaker and listening position:
2.25 m (88-3/4")
Distance between front left speaker and listening position:
0.5 m (20")
Calculation:
L = 2.25 m (88-3/4") – 0.5 m (20")= 1.75 m (68-3/4")
Compensation time = 1.75 ÷ 343 x 1000 = 5.1 (ms)
In other words, setting the time correction value for the front
left speaker to 5.1 (ms) sets a virtual distance matching the
distance to the farthest speaker.
Continued
45-EN
5.1ms
0.5m
2.25m
The sound is uneven
because the distance
between the listening
position and the different
speakers is different.
The difference in the
distance between the front
left and rear right speakers
is 1.75 meters (68-3/4").
Touch [SYS.] on the main source screen.
5
The SYSTEM selection screen appears.
Touch [i-Personalize].
6
The i-Personalize screen appears.
Touch [] of A.PROCESSOR.
7
The A.PROC list screen is displayed.
Touch [;] or [:] of T.CORR.
8
Select L/R or L+R.
L/R: Different adjustment values can be set for the left
and right channels.
L+R: Sets the same adjustment values for the left and right
channels.
Touch [] of T.CORR.
9
The T.CORR adjustment screen appears.
Adjust the time correction value (0.0 - 20.0ms) of a
10
desired speaker by touching the respective [;] or
[:] button (1 step = 0.1ms).
Touch [RETURN] to return to the previous screen.
11
• When the speaker is set to the “OFF” mode, the TCR for that
speaker cannot be set. Refer to “Setting the Speakers” (page 44).
• The adjustment value for FRONT 2 (speakers) which is adjusted in
time correction, is also applied to the front speakers in “Setting
Bass Focus” (page 47).
• The adjustment (AUTO TCR) cannot be automatically set on this
unit.
Time correction eliminates
the difference between the
time required for the sound
from the different speakers
to reach the listening
position.
Setting the time correction of
the front left speaker to 5.1
ms makes it possible to
coordinate the distance from
the listening position to the
speaker.
Phase Switching
Make sure that the defeat is turned off (page 23).
1
Touch [SYS.] on the main source screen.
2
The SYSTEM selection screen is displayed.
Touch [i-Personalize].
3
The i-Personalize screen appears.
Touch [] of A.PROCESSOR.
4
The A.PROC list screen is displayed.
Touch [] of PHASE.
5
The PHASE adjustment screen appears.
Switch the phase (0° or 180°) by touching [;] or
6
[:] of the desired speaker.
Touch [RETURN] to return to the previous screen.
7
Graphic Equalizer Adjustments
The graphic equalizer allows you to modify the sound using 31 bands
each for the front (left and right), rear (left and right) and centre
speakers. An additional 10 bands are available for the subwoofer. This
allows you to customize the sound to suit your taste.
Check that the Defeat mode is off.
1
Touch [SYS.] on the main source screen.
2
The SYSTEM selection screen appears.
Touch [i-Personalize].
3
The i-Personalize screen will appear.
Touch [] of A.PROCESSOR.
4
The A.PROC list screen appears.
Select L/R or L+R by touching [;] or [:] of G-EQ.
5
L/R: Different adjustment values can be set for the left
and right channels.
L+R: Sets the same adjustment values for the left and
right channels.
When parametric EQ is adjusted, this setting will be
turned off.
Touch [] of G-EQ.
6
The G-EQ list screen appears.
Touch [] of the desired speaker (channel).
7
The G-EQ adjustment screen appears.
Adjust the level by touching [;] or [:] of the
8
desired frequency.
When adjusting another frequency, repeat steps 7
9
and 8 above.
46-EN
Touch [RETURN] to return to the previous screen.
10
• When the speaker is set to the “OFF” mode, the graphic equalizer
for that speaker cannot be set. Refer to “Setting the Speakers”
(page 44).
• Check the playable frequency ranges of the connected speakers
before making the equalizer adjustments. If the speaker’s playable
frequency range is 55 Hz to 30 kHz, for example, adjusting the 40
Hz or 20 Hz band has no effect. Additionally, you may overload
and damage the speakers.
• When graphic EQ is adjusted, the adjustment for parametric EQ
becomes ineffective.
• When the speaker is set to the “OFF” mode, the parametric
equalizer for that speaker cannot be set. Refer to “Setting the
Speakers” (page 44).
• It is not possible to adjust the frequencies of adjacent bands within
7 steps.
• Check the playable frequency ranges of the connected speakers
before making the equalizer adjustments. If the speaker’s playable
frequency range is 55 Hz to 30 kHz, for example, adjusting the 40
Hz or 20 Hz band has no effect. Additionally, you may overload
and damage the speakers.
• When the parametric EQ is adjusted, the adjustment for graphic
EQ becomes ineffective.
Parametric Equalizer Adjustments
The frequency bands of the graphic equalizer are fixed. This makes it
very difficult to correct for undesired peaks and dips at specific
frequencies. The parametric equalizer’s centre frequency can be tuned
to these specific frequencies. Then, the bandwidth (Q) and level are
fine-tuned, independently, to make the necessary corrections. The
parametric equalizer function is an advanced tool for serious
audiophiles.
Check that Defeat mode is off.
1
Touch [SYS.] on the main source screen.
2
The SYSTEM selection screen appears.
Touch [i-Personalize].
3
The i-Personalize screen will appear.
Touch [] of A.PROCESSOR.
4
The A.PROC list screen appears.
Select L/R or L+R by touching [;] or [:] of P-EQ.
5
L/R: Different adjustment values can be set for the left
and right channels.
L+R: Sets the same adjustment values for the left and
right channels.
When graphic EQ is adjusted, this setting will be turned
off.
Touch [] of P-EQ.
6
The P-EQ list screen appears.
Touch [] of the desired speaker (channel).
7
The P-EQ adjustment screen appears.
Touch the desired adjustment mode.
8
FREQ : Selects the frequency.
LEVEL : Adjusts the level.
Q:Adjust the band width.
Adjust the desired band by touching [;] or [:] of
9
that band.
Setting Bass Sound Control
Make sure that the defeat is turned off.
1
Touch [SYS.] on the main source screen.
2
The SYSTEM selection screen is displayed.
Touch [i-Personalize].
3
The i-Personalize screen appears.
Touch [] of A.PROCESSOR.
4
The A.PROC list is displayed.
Touch [] of BASS SOUND CONT.
5
The Bass Sound Cont. screen appears.
Setting Bass Compressor
You can adjust the sound of low frequencies as desired.
Touch [;] or [:] of BASS COMP. to select the
6
desired mode.
Bass sound is emphasized more as the mode is
sequentially switched as MODE1 → 2 → 3, offering you
vivid low frequencies.
Select OFF when the setting is not necessary.
Touch [RETURN] to return to the previous screen.
Setting Bass Focus
Using the previously specified delay number (time difference) allows
you to set a time difference between the front-rear/left-right speakers.
Namely, it enables a time correction based on your preference. With
an initial delay of 0.10 ms for each of the 0 to 200 steps, audible time
correction can be achieved.
Set the delay number in the front and rear, and on
6
the right and left of the desired speaker by
touching the respective [;] or [:] button.
• Any setting in Bass Focus is applied in time correction, too.
•Touch [RETURN] to return to the previous screen.
When adjusting another band, repeat steps 7 to 9
10
above.
Touch [RETURN] to return to the previous screen.
11
47-EN
Speaker Setup
The PXA-H700 or PXA-H701 can be set according to the playable
frequency range of your speakers.
Check the playable frequency range of the speakers (not including the
subwoofer) before performing this operation to verify whether the
speakers can play low frequencies (of about 80 Hz or less).
•Avoid stopping, pausing, switching the disc, cueing, fastforwarding or switching the audio channel of this unit while
making this adjustment. The setting is cancelled if Decode mode is
switched.
Check that Defeat mode is off (page 23).
1
Touch [SYS.] on the main source screen.
2
The SYSTEM selection screen appears.
Touch [i-Personalize].
3
The i-Personalize screen will appear.
Touch [] of A.PROCESSOR.
4
The A.PROC list screen appears.
Touch [] of SPEAKER SETUP.
5
The adjusting screen of SPEAKER SETUP appears.
Select the speaker characteristic by touching [;]
6
or [:] of the desired speaker setting.
OFF∗1:When no speaker is connected.
SMALL: When a speaker that cannot play low
LARGE∗2: When a speaker that can play low frequencies
∗1 It is not possible to set the front speakers to “OFF”.
∗2 If the front speakers are set to “SMALL”, the rear and
• If the centre speaker is turned “OFF,” the centre channel’s audio
signals are added to the audio signals output from the front
speakers.
• If you set the speaker response to “OFF,” also set the speaker
setting to “OFF.” (page 44)
•Perform the setup for all the speakers (“Front,” “Center,” “Rear”
and “Subwoofer”). If not, the sound may not be balanced.
• When centre is set to “OFF”, the setting is ineffective even if
centre is set with this function.
• Through changing the settings on each speaker, a change in the
output of the other speakers may occur due to the setting
requirements.
• When using the PRO LOGIC II, if the rear speaker is set to
“LARGE”, then there will be no output from the subwoofer.
frequencies (80 Hz or less) is connected.
(80 Hz or less) is connected.
centre speakers cannot be set to “LARGE”.
Setting of Dolby 5.1ch
Check that Defeat mode is off.
1
Touch [SYS.] on the main source screen.
2
The SYSTEM selection screen appears.
Touch [i-Personalize].
3
The i-Personalize screen will appear.
Touch [] of A.PROCESSOR.
4
The A.PROC list screen appears.
Touch [] of DOLBY 5.1 CH SETUP.
5
The DOLBY 5.1CH SETUP display appears.
Set the items below as you desire.
Adjusting the acoustic image
In most installations, the centre speaker must be placed directly
between the front passenger and driver. Using this function, the centre
channel information is distributed to the left and right speakers. This
creates an acoustic image simulating a centre speaker directly in front
of each listener. Adjusting the centre width in PL II MUSIC (see
“Using the Pro Logic II mode,” page 50), makes this function
ineffective.
•Avoid stopping, pausing, switching the disc, cueing, fastforwarding or switching the audio channel of this unit while
making this adjustment. The setting is cancelled if the Decode
mode is switched.
Touch [;] or [:] of BI-PHANTOM to adjust the level.
The level can be adjusted within the range of -5 to +5. The
higher the level, the more the position of the centre speaker is
shifted to the sides.
The BI-PHANTOM function is turned off by touching [OFF].
• This adjustment is effective when the setting of the centre speaker
to SMALL or LARGE in the speaker setup settings.
• This adjustment is ineffective when the speaker is set to CENTER
OFF in “Setting the Speakers” (page 44).
Mixing bass sound to the rear channel
This function mixes the front channel audio signals to the audio
signals output from the rear speakers, improving the sound in the
vehicle’s rear seat.
•Avoid stopping, pausing, switching the disc, cueing, fastforwarding or switching the audio channel of this unit while
making this adjustment. The setting is cancelled if the Decode
mode is switched.
Touch [;] or [:] of REAR MIX to adjust the level.
The level can adjusted in five steps: –6, –3, 0, +3 and +6. The
higher the level, the more bass is output from the rear
speakers. (The effect differs according to the software (DVD,
etc.).)
The REAR MIX function is turned off by touching [OFF].
• This adjustment is ineffective when the rear speaker setup setting is
set to “OFF.”
•For linear PCM signals, the voice is output from the rear speaker
regardless of the REAR FILL and REAR MIX setting.
48-EN
Achieving powerful high volume sound
With Dolby Digital, the dynamic range is compressed so that
powerful sound can be achieved at regular volume levels. This
compression can be cancelled to achieve an energetic sound with even
greater power, like the sound in a movie theater.
This function works only in the Dolby Digital mode.
Touch [;] or [:] of LISTENING MODE to select STD or MAX.
STD: For powerful sound at regular volume levels
MAX: For powerful sound at high volumes
•Keep the volume to a level at which sounds outside the vehicle can
still be heard.
Adjusting the speaker levels
The test tones help to make the volume adjustments of the different
speakers. When levels are equal, a strong sense of presence can be
heard from the different speakers at the listening position.
•Avoid stopping, pausing, switching the disc, cueing, fastforwarding or switching the audio channel of this unit while
making this adjustment. The setting is cancelled if the decode mode
is switched.
1Touch [ON] of OUTPUT LEVEL.
Test tone output is repeated for each of the different
speaker channels. They will be repeated in the order
shown below.
If no operation is performed for 2 seconds, the channel
switches to the next channel.
Left → Center → Right → Right Surround →
Left surround → Left
2 While the test tone is being produced from the
speakers, touch [;] or [:] of OUTPUT LEVEL balance
the output from all the speakers.
• The adjustment range for the different speakers is
–10 dB - +10 dB.
• Adjust based on the front speakers.
• If a speaker is set to off mode, that speaker’s level adjustment
cannot be made.
Refer to “Speaker Setup” (page 48).
Adjusting the DVD Level
The volume (signal level) for Dolby Digital, Dolby PL II, DTS and
PCM modes can be set.
•Avoid stopping, pausing, switching the disc, cueing, fastforwarding or switching the audio channel of this unit while
making this adjustment. The setting is cancelled if the Decode
mode is switched.
Check that Defeat mode is off.
1
Touch [SYS.] on the main source screen.
2
The SYSTEM selection screen appears.
Touch [i-Personalize].
3
The i-Personalize screen will appear.
Touch [] of A.PROCESSOR.
4
The A.PROC list screen appears.
Touch [] of DVD LEVEL.
5
The DVD LEVEL list screen appears.
Adjust the level by touching [;] or [:] of the
6
desired adjusting mode.
The level can be adjusted in the range of –5 to +5.
Storing Settings in the Memory
Adjustment or setting contents can be stored.
Contents that can be stored vary depends on the audio processor used.
Check that Defeat mode is off.
1
Touch [MEMORY] on the A.PROC list display.
2
Within 5 seconds, touch any one of the preset
3
buttons [P.SET 1] through [P.SET 6] on the
A.PROC list screen.
The setting contents are stored.
• The stored contents will not be deleted even when the battery
power cord is detached.
Getting out the Preset Memory
Check that Defeat mode is off.
1
Touch any one of the preset buttons [P.SET 1]
2
through [P.SET 6] on the A.PROC list display to
select the preset memory.
• It takes a few moment to get out the preset memory.
49-EN
Using the Pro Logic II Mode
Pro Logic processing can be conducted on the music signals recorded
on two channels to achieve Dolby Pro Logic II surround sound. For
two-channel Dolby Digital and DTS signals, there is also a “REAR
FILL” function for outputting the signals of the front channel to the
rear channel.
Check that Defeat mode is off (page 23).
1
Touch [SYS.] on the main source screen.
2
The SYSTEM selection screen appears.
Touch [i-Personalize].
3
The i-Personalize screen will appear.
Touch [] of A.PROCESSOR.
4
The A.PROC list screen appears.
Touch [] of DOLBY PLII.
5
The DOLBY PLII adjusting screen appears.
Touch [;] or [:] of DOLBY PLII to select the
6
desired mode.
PL II MOVIE:
Suits the stereo TV shows and all programs
encoded in Dolby Surround. It improves the sound
field directivity to near that of discrete 5.1-channel
sound.
PL II MUSIC:
Can be used for all stereo music recordings, and
provides a wide, deep sound field.
REAR FILL:
Depending on the input signals, the sound may only
be output from the front speakers. In this case, the
“REAR FILL” function can be used to output signals
from the rear speakers as well.
OFF: Tur ns DOLBY PL II function to OFF.
If PL II MUSIC is selected, the center width can be adjusted
with following operations.
This function offers the optimum vocal position by adjusting
the center channel position between the center speaker and
the L/R speaker. (The adjustments established in “Adjusting
the acoustic image” (page 48) are ineffective while this
function is activated.)
Touch [;] or [:] of CENTER WIDTH CONT to adjust the
level.
The level can be adjusted between 0 to 7. When the
level increases, the center channel position moves from
the center speaker position to both sides.
Touch [OFF] of CENTER WIDTH CONT to turn off the
center width control.
• This adjustment is effective when the setting of the center speaker
is SMALL or LARGE in the speaker setup settings.
•Avoid stopping, pausing, switching the disc, cueing, fastforwarding or switching the audio channel of this unit while
making this adjustment. The setting is cancelled if the Decode
mode is switched.
• This adjustment is ineffective when the speaker is set to CENTER
OFF in “Setting the Speakers” (page 44).
• This function only works with two-channel signals. This operation
is ineffective when 5.1-channel DTS or Dolby Digital signals are
input.
• If the setting of REAR FILL is made when REAR MIX is ON, sound
is unchanged in the rear fill setting because REAR MIX is given
priority during 2 channel decoder other than linear PCM.
•For linear PCM signals, the voice is output from the rear speaker
regardless of the REAR FILL and REAR MIX setting.
Linear PCM Setting
The output when playing discs recorded in linear PCM can be set to 2
or 3 channels.
• This adjustment is ineffective when the speaker is set to CENTER
OFF in “Setting the Speakers” (page 44).
50-EN
Navigation System (Optional)
Auxiliary Device (Optional)
Switching the Navigation Screen (Optional)
If an optional Alpine Navigation System is connected to the IVAD300R/IVA-D300RB, the Navigation screen can be displayed on this
unit.
Touch [SRC] on the main source screen.
1
The source screen appears on the display.
Touch [NAV].
2
The Navigation screen is displayed.
The operation is possible with the supplied navigation
remote control.
For navigation operation, refer to the Owner’s Manual of
the navigator.
• When V. SEL is pressed while the Navigation selection mode is
being selected in “Setting Visual Mode” (page 34), the navigation
mode will be directly activated.
• If the Navigation mode menu is not displayed on the main menu
screen, set NAV. IN to on by following “Setting the navigation
mode” (page 33).
• When the Navigation System is on, the audio and visual navigation
cuts in.
Operating Auxiliary Devices (Optional)
To operate your devices connected to the AUX terminals on the rear
panel of IVA-D300R/IVA-D300RB, follow the procedure described
below.
WARNING
It is dangerous for the driver to watch the TV/Video while
driving the vehicle. The driver may be distracted from
looking ahead and an accident could occur.
Install the IVA-D300R/IVA-D300RB correctly so that the
driver cannot watch TV/Video unless the vehicle is
stopped and the emergency brake is applied.
If the IVA-D300R/IVA-D300RB is not installed correctly, the
driver will be able to watch the TV/Video while driving the
vehicle and may be distracted from looking ahead and
cause an accident. The driver or other people could be
severely injured.
• If you try to activate the auxiliary device while driving, the display
will show the warning-PICTURE OFF FOR YOUR SAFETY.
Touch [SRC] on the main source screen.
1
The source screen appears on the display.
Touch [AUX]*.
2
The external input screen is displayed.
Touch [NTSC/PAL] to change the video input.
3
*AUX-1 to AUX-3 are displayed if the external input devices
(maximal 3) are connected, or the name which is given as the
source name in “Naming External Devices” on page 33 is
displayed.
• If the AUX mode is not displayed on the main menu, set AUX IN to
ON by following “Setting the AUX mode” (page 33).
• The setting of switching NTSC/PAL, which you have set in this
section, can be used in same way in “Switching the Visual Input
Signal” on page 34.
• The display mode changes by touching [WIDE].
For operation, refer to “Switching Display Modes” on page 25.
51-EN
Changer (Optional)
Controlling CD Changer (Optional)
An optional 6-disc or 12-disc CD Changer may be connected to the
IVA-D300R/IVA-D300RB if it is Ai-NET compatible. With a CD
Changer connected to the Ai-NET input of the IVA-D300R/IVAD300RB, the CD Changer will be controllable from the IVA-D300R/
IVA-D300RB.
If you connect a changer compatible with MP3, you can play CDROMs, CD-Rs, and CD-RWs containing MP3 files on the IVAD300R/IVA-D300RB.
Using the KCA-400C (the Multi-Changer Switching device) multiple
changers can be controlled by the IVA-D300R/IVA-D300RB.
See the Multi-Changer Selection section for selecting the CD
Changers (explained on this page).
Touch [SRC] on the main source screen.
1
Touch [CD CHG].
2
The display changes to the CD changer mode screen.
When a 6 Disc CD Changer is connected;
1Touch [P1/2]*.
The Function Guide display appears.
* When an MP3 compatible CD changer or DVD changer is
connected, touch repeatedly until the disc number is displayed.
2Touch any one of the select buttons [DISC 1] through
[DISC 6].
DISC 1 through DISC 6 select the discs from the first
disc to 6th disc.
When an MP3 compatible CD changer is connected;
1Touch [P1/3] twice to change the Function Guide
display.
2Touch any one of the select buttons [DISC 1] through
[DISC 6].
DISC 1 through DISC 6 select the discs from the first
disc to 6th disc.
When a 12-Disc CD Changer is connected;
You can select the disc numbers 1 to 6 in the same manner as
for 6-disc Changer.
Touch [P1/3] twice to select disc numbers 7 to 12.
The function guide display changes so that DISC 7
through DISC 12 represent disc numbers 7 to 12.
• After selecting the desired disc, you can operate in the same way
as for the CD player. For details, see the CD/MP3/WMA section
• When an MP3 compatible CD changer is connected, the unit can
play discs containing both audio data and MP3 data.
• The DVD changer (optional) is controllable from the IVA-D300R /
IVA-D300RB as well as the CD changer.
Multi-Changer Selection (Optional)
Alpine’s Ai-NET system will support up to 6 CD Changers. When
operating two or more changers, the KCA-400C (Multi-Changer
Switching device) must be used. If you use 1 Switching device, you
can connect up to 4 CD Changers. If you use 2 Switching devices,
you can connect up to 6 CD Changers. When using KCA-410C
(Versatile Link Terminal), you can connect two changers only.
In changer mode, touch [CHG SEL] or press
1
BAND on the unit to select the next changer
(connected changers only) .
To operate the selected changer, see “CD/MP3/
2
WMA” section.
•To operate the selected changer, see “CD/MP3/WMA” (pages 16
and 17).
52-EN
HDD Player Operation
DAB Operation
(Optional)
Listening to Music of HDD
This device is controllable from the unit when Alpine HDD player is
connected.
Touch [SRC] on the main source screen.
1
The source selection screen appears.
Touch [MM DRIVER].
2
The MM DRIVER mode main screen appears.
Select the desired music by touching [g] or
3
[f].
Searching: Touch [g] or [f].
Fast-forward/reverse: Touch and hold [g] or [f].
Touch [:/J] to temporarily stop the music
4
currently playing.
Touch [:/J] again to resume the play.
(Optional)
Using DAB Receiver for the Ensemble Seek
Tuning (Optional)
DAB (Digital Audio Broadcasting) offers excellent sound quality even
in a moving vehicle, enabling you to receive various types of
information, including weather and traffic information, and it also
displays information sent from the broadcasting stations. You can
also let urgent broadcasts or announcements interrupt a current
broadcast.
• If you connect the DAB Receiver Box TUA-T100DAB (separately
sold), you can control DAB for the reception of broadcast.
• CD quality sound can be obtained from DAB broadcasts, although
quality may differ on some services.
• Some broadcasting stations may perform test broadcasts.
• When DAB reception is poor, metallic noise may occur. This is not
a malfunction.
Touch [SYS.] on the source main screen.
1
The SYSTEM selection screen is displayed.
Touch [DAB].
2
The screen changes to the DAB* main screen display.
* When receiving RDS, the DAB/RDS screen appears.
Touch [BAND] to select DAB1, DAB2, or DAB3.
3
If you touch and hold [g] or [f] while
4
receiving DAB1, 2, or 3, ensemble is automatically
searched.
“ENS. SEEK” indicator lights up.
The ensemble label is displayed during the ensemble
seek.
• “Receiving Announcement Information of DAB Local Stations”,
“Setting ON/OFF for DRC”, and “Setting for Automatic change
from DAB to RDS” are stated in “GENERAL Setup” section on
pages 31 to 32.
Tip
When you use DAB, you can select a desired ensemble which
may contain one or more services, any of which can be
received. Furthermore, each service contains a Service
Component, which itself can contain any number of Primary or
Secondary services, depending on the Service Component.
Several different kinds of service can therefore be selected.
53-EN
Changing the Service
Services are received within the ensemble that you are currently
receiving.
Touch [SRV/ENS] to switch to the Service.
1
“SERV.” indicator lights up.
While receiving the ensemble, momentarily touch
2
[g] or [f] to select your desired service.
The selected service label is displayed for 2 seconds, and
then you return to the display that you select with the
steps described under the section “Changing the Display
Mode” (see page 55).
Memorizing the Ensemble Automatically
After selecting a desired band, touch [A.MEMO].
The ensemble is searched for, and six ensembles are
automatically received and memorized with the preset No.
(P.SET 1 through P.SET 6).
When memorization has completed, the Ensemble that was
memorized last is received.
The mode selected in “Changing the Display Mode (page 55)”
is displayed.
• If no ensemble is received, the one that has been received before
you perform this automatic memorization is received.
Changing the Service Component
You can change Audio Services of the Service Component between
the Primary and Secondary, when listening to an Audio Service that
has a Secondary Service Component.
Touch [P/S] to change the Service Component
between the Primary and Secondary broadcast.
Every time you touch the button the selection toggles.
The Component label is displayed for 2 seconds, and then you
return to the display that you selected with the steps described
under the section “Changing the Display Mode” (see page 55).
• If When the Primary service component is tuned while the
Secondary service component exists, “P” indicator is displayed.
• When the Secondary service component is tuned, “S” indicator is
displayed.
• When the Secondary service component does not exist, there is no
indicator in the display.
Memorizing the Service
Select the service that you want to memorize.
1
Touch [P1/2].
2
The function guide is switched.
Touch [MEMORY].
3
Touch any one of the preset buttons [P.SET 1]
4
through [P.SET 6] within 5 seconds.
The selected service is memorized.
•You can memorize up to 18 stations (6 stations for each band;
DAB1, DAB2, DAB3).
• If you select a preset No. that has already memorized a service, the
new selection takes it over.
• When you are not receiving DAB, the service is not memorized.
(Memorize the service when the DAB reception is good.)
PTY (Programme Type) Tuning
Press and hold T.INFO/RDS for at least 2 seconds
1
in the DAB mode.
The display changes to the DAB setting screen.
In Radio (DAB receiving) mode, touch [PTY] to go
2
to the PTY Select mode.
Touch [;] or [:] to select your desired programme
3
type.
After selecting a programme type, touch [PTY] to
4
go to the PTY Search mode.
The selected programme type is searched for.
•To cancel the PTY Search mode, touch [PTY].
When the station is received, the received
5
programme type is displayed for 5 seconds. If no
station is found, “NO PTY” is displayed for 5
seconds.
• Above functions can be performed only for services within an
ensemble.
Tu rning ON/OFF Traffic News Announcement
When you set to ON, you can automatically receive the Traffic News.
Press T.INFO/RDS to set ON/OFF for the Traffic News.
•You can also set the RDS stations at the same time.
• This operation can also be performed by turning the Traffic News
ON/OFF in the “Setting the Announcement Select Mode” section
page 55.
Receiving the Memorized Service
After selecting a desired band, touch [P1/2].
1
The function guide is switched.
Touch any one of the preset buttons [P.SET 1]
2
through [P.SET 6].
The selected service is received.
The mode selected in “Changing the Display Mode (page
55)” is displayed.
• When you receive the Secondary Service Component, you
memorize the service, but when you call out this memorized
service, the Primary Service Component will be called out.
54-EN
Setting the Announcement Select Mode
Press and hold T.INFO/RDS for at least 2 seconds.
1
The display changes to the RDS/DAB* mode screen.
* RDS mode screen when DAB is not connected.
Touch [ANNC].
2
Touch [;] or [:] to select the desired
3
Announcement.
All Select → Traffic News → Travel news → Warning → News
→ Weather → Event → Special Event → Radio Info → SportsNews → Financial → All Select
Touch [ON] or [OFF] to set ON/OFF for the
4
selected Announcement.
Repeat Steps 3 and 4 to set more.
• When one of the selections between “All Select” and “Financial”
is set to ON, no announcement interruptions are made if you set to
OFF by touching [ANNC ENT].
• If you set ON/OFF with the “All Select” selection, you can set
ON/OFF for the selections from “Traffic News” to “Financial.”
Tips
• When an urgent broadcast is received, the mode
automatically changes to the DAB mode to receive the
Alarm Announcement. If you adjust the volume level at this
time, that volume level is memorized, and that volume level
is applied the next time you receive an urgent broadcast.
• If the announcement that you select in Step 3 interrupts, the
selected announcement label is displayed. If you adjust
the volume level at this time, that volume level is
memorized, and that volume level is applied the next time
announcement interrupts.
Touch [RETURN] to return to the DAB setting
5
screen.
Changing the Display Mode
You can display information that is sent from broad-casting stations,
such as the channel number or the service name that you are receiving
or listening.
While receiving DAB, touch [INFO.] to change the
display mode.
*1You can display this only when the broadcasting station supplies
the Service Component Label. Otherwise, “No Component” is
displayed.
*2“NO TEXT” is displayed when broadcasting stations which
contain no Dynamic Label are received.
• Dynamic Label is not displayed in the dual screen.
1
→ Dynamic Label (Radio Text)
MobileHub™ Link
(Optional)
About MobileHub™ Link (Optional)
Connect a separately sold junction box and a portable telephone
(available from Nokia) to control the incoming and outgoing calls of
the portable telephone.
CAUTION
• Even with hands-free operation, a driver can be distracted
during telephone operation or receiving a call. For the
sake of safety, drivers are requested to refrain from
operating the telephone while driving.
• For the sake of safety, operations other than incoming
calls and Speed-Dial outgoing calls cannot be used.
• If a portable telephone is connected, its address book, incoming
and outgoing history, short message history and standardized
sentences are downloaded to the junction box.
Please refer to the instruction manual of the junction box.
• When a portable telephone is not connected, “NO PHONE” is
displayed for at least 5 seconds, then the mode returns to the
original source mode.
• When the portable telephone is taken off the junction box during an
incoming or outgoing call, or during a hands-free call, the call will
be treated as an ordinary one by the portable telephone.
• When there is an incoming call while the power of the IVA-D300R/
IVA-D300RB is OFF, the power of the IVA-D300R/IVA-D300RB
turns ON automatically, hands-free call is cut, and the portable
telephone call is enabled.
• Even if the power of the portable telephone is OFF, when IVAD300R/IVA-D300RB is set to the telephone mode, the power of the
portable telephone will be turned ON.
• If the ACC power of the vehicle is turned OFF (the engine is
stopped) during a hands-free call, the hands-free call cuts, and the
normal portable telephone call is enabled.
• If there is an incoming call during operation (except an outgoing
call or talking), operation mode will end and switch to the
incoming or talking mode.
• An outgoing call from a portable telephone is also possible.
However, you cannot perform different operations at the same time
from a portable telephone and IVA-D300R/IVA-D300RB as
malfunction can result.
•With a junction box connected outgoing, incoming, and sending
history will also be recorded in the portable telephone.
• While telephoning, Time Correction is set to normal (0.0ms) and
DEFEAT is also set to ON. When the call has finished, the unit
returns to the setting which you previously set.
• The telephone volume can be adjusted from the IVA-D300R/IVAD300RB. The volume you set during the call is memorized, and is
automatically applied again on the next call.
55-EN
Telephone Reception
When this unit receives a call, the screen is
1
switched to RINGING display of Telephone mode.
When AUTO call (setting of AUTO/MANUAL call
2
page 32) is selected, CONNECT display appears
and this unit enters AUTO call mode in 3 seconds
after receiving.
To cut the call, touch []. Or the call is
3
automatically cut in 5 seconds after finishing.
The screen returns to the previous source mode.
To input any number or symbol during call:
1Touch [10 KEY] in the CONNECT display.
The numeric keypad screen is displayed.
2Touch and input a desired number or symbol.
3Touch [RTN] to return to the previous screen.
Calling
Calling by using the Speed Dial
You can place a call by retrieving one of the telephone numbers
registered in No. 1 to 9 of the address book.
Touch [] on the main source screen.
1
The Speed Dial and the numeric keypad displays appear.
Touch any one of the buttons [1] through [9] in
2
which the telephone numbers are recorded.
• A call is sent directly by touching and holding any one of the
recorded buttons [1] to [9] for at least 2 seconds.
Touch [] to start call.
3
To cut the call, touch []. Or the call is
4
automatically cut in 5 seconds after finishing.
• If no telephone number is registered in the selected function button,
“NO PRESET” is displayed for 5 seconds.
Touch [RETURN] to return to the Telephone menu.
• When [SPEED DIAL] is touched in the Telephone menu display,
the Speed Dial display appears.
Dial call
Input the telephone number using the dial.
Touch [] on the main source screen.
1
The Speed Dial display appears.
Touch [RTN] on the numeric keypad input screen
2
to close the numeric keypad screen.
The Telephone menu display appears.
Touch [DIRECT CALL].
3
The Direct Call and numeric keypad displays appear.
Touch and input the telephone number.
4
Touch [ENT].
5
Touch [] to start call.
6
• The call is cut in 5 seconds after “NO NETWORK COVERAGE” is
displayed.
To listen to the answer-phone or to input numbers:
1 In the CONNECT display, touch [10 KEY].
The Dial Sending and numeric keypad displays appear.
2Touch and input a desired number or symbol.
3Touch [RTN] to return to the previous screen.
To cut the call, touch []. Or the call is
7
automatically cut in 5 seconds after finishing.
The screen returns to the previous source mode.
• If [RETURN] is touched within 5 seconds of cutting the call, the
Telephone menu display appears.
• When the call is cut, touching [] dials the number again.
Calling by the address book
From your vehicle, call from the address book registered in the
portable telephone.
The operation may be carried out only when vehicle is parked.
Touch [] on the main source screen.
1
The Speed Dial display appears.
Touch [RTN] on the numeric keypad input screen
2
to close the numeric keypad screen.
The Telephone menu display appears.
Touch [PHONE BOOK].
3
The Phone Book list appears.
Touch [CALL] of a desired addressee on the list.
4
• By touching [ ] or [ ], the names are listed in alphabetical
order.
• If no data is in the PHONE BOOK, “NO MEMORY” is
displayed.
Touch [RETURN] to return to the Telephone menu display.
Touch [] to place the call.
5
To cut the call, touch []. Or the call is
6
automatically cut in 5 seconds after finishing.
Calling by the outgoing / incoming /
absent incoming history
You can place a call to one of the last 999 calls by the outgoing/
incoming/absent incoming history.
Touch [] on the main source screen.
1
The Speed Dial display appears.
Touch [RTN] on the numeric keypad input screen
2
to close the numeric keypad screen.
The Telephone menu display appears.
Touch any one of the buttons [DIALED CALL],
3
[MISSED CALL] or [RECEIVED CALL].
DIALED CALL:Outgoing history list display
MISSED CALL:Absent incoming history list display
RECEIVED CALL: Incoming history list display
• If no history is registered to any of the lists, “NO MEMORY” is
displayed.
To return to Telephone menu display, touch [RETURN].
56-EN
Touch [CALL] of a desired addressee on the list.
4
Touch [] to start call.
5
To cut the call, touch []. Or the call is
6
automatically cut in 5 seconds after finishing.
SMS (Short Message Service) Operation
You can receive messages, show the contents of messages, and send
standardized sentences.
When a message is received, an icon is indicated on the display.
Information
About DVDs
Music CDs and DVDs have grooves (tracks) in which the
digital data is recorded. The data is represented as
microscopic pits recorded into the track – these pits are read
by a laser beam to play the disc. On DVDs, the density of the
tracks and pits is twice that of CDs, so DVDs can contain more
data in less space.
Receiving a Short message
Touch [] on the main source screen.
1
The Speed Dial display appears.
Touch [RTN] on the numeric keypad input screen
2
to close the numeric keypad screen.
The Telephone menu display appears.
Touch [SMS READ].
3
The SMS Read display appears.
Touch [READ] of the received short message.
4
The SMS Inbox display appears.
The contents of the received message is displayed up to
140 letters.
Touch [RETURN] to return to the SMS Read display.
• When the unit receives a message, the new reception icon appears.
CDs
Minimum pit
length -
0.9 µm
DVDs
Minimum pit
length -
0.9 µm
A 12 cm disc can contain one movie or about four hours of
music.
In addition, DVDs provide sharp picture quality with vivid colours
thanks to a horizontal resolution of over 500 lines (compared to less
than 300 for VHS tape). With the addition of an optional, digital audio
processor (PXA-H900/PXA-H510/PXA-H700, etc.), you can recreate
the power and presence of a movie theater with Dolby Digital 5.1channel Surround.
In addition, DVDs offer a variety of functions.
• Multiple audio* (page 22)
Movies can be recorded in up to eight languages. The
desired language can be selected from the remote control
unit.
• Subtitles function* (page 22)
Movies can include subtitles in up to 32 languages. The
desired subtitle language can be selected from the remote
control unit.
• Multi angle function* (page 22)
When the DVD contains a movie shot from multiple angles,
the desired angle can be selected from the remote control
unit.
• Multi story function*
With this function, a single movie includes various story
lines. You can select different story lines to view various
versions of the same movie.
Operation differs from disc to disc. Story line selection
screens including instructions appear during the movie.
Just follow the instructions.
* The functions audio languages, subtitle languages, angles, etc.,
differ from disc to disc. For details, refer to the disc’s instructions.
1.2 mm
0.6 mm
0.6 mm
Track pitch -
1.6 µm
Track pitch -
0.74 µm
57-EN
Te rminology
Dolby Digital
Dolby Digital is a digital audio compression technology
developed by Dolby Laboratories that allows large quantities
of audio data to be efficiently recorded on discs. It is
compatible with audio signals from mono (1 channel) all the
way up to 5.1-channel surround sound. The signals for the
different channels are completely independent, and since the
sound is high quality digital there is no loss of sound quality.
* The separately sold digital audio processor (PXA-H510/PXA-
H900/PXA-H700, etc.) is required to enjoy full 5.1-channel
surround sound.
The IVA-D300R/IVA-D300RB performs Dolby Digital decoding
when it outputs analog audio signals, it just happens to be 2channel audio not 5.1-channel.
Center
speaker
Front
speakers
Rear
speakers
Dolby Pro Logic
Dolby Pro Logic is the technology used to decode programs
encoded in Dolby Surround. Pro logic decoding will provide
you with four channels of sound (front left/right, center and
monaural rear surround) from a 2-channel (stereo) source.
* The separately sold digital audio processor (PXA-H510/PXA-
H900) is required to enjoy Dolby Pro Logic surround sound.
Dolby Pro Logic II
Dolby Pro Logic II plays 2-channel sources in 5 channels over
the entire frequency range.
This is done with an advance, high sound quality matrix
surround decoder which draws out the spatial properties of the
original recording without adding any sounds to or changing
the sound of the source.
* The separately sold digital audio processor (PXA-H700, etc.) is
required to enjoy Dolby Pro Logic II surround sound.
Linear PCM audio (LPCM)
LPCM is a signal recording format used for music CDs.
Whereas music CDs are recorded at 44.1 kHz/16 bits, DVDs
are recorded at 48 kHz/16 bits to 96 kHz/24 bits, thereby
achieving higher sound quality than music CDs.
Rating levels (parental lock)
This is a function of the DVD for restricting the viewing age as
stipulated by laws in different countries. The way in which
viewing is restricted differs from DVD to DVD. Sometimes the
DVD cannot be played at all, other times certain scenes are
skipped, and other times certain scenes are replaced with
other scenes.
Subwoofer
Speaker layout for enjoying
Dolby Digital sound/dts sound
DTS
This is a home-use digital sound format of the DTS Sound
System. This is a high quality sound system, developed by
Digital Theater Systems Corp for use in movie theatres.
DTS has six independent sound tracks. The theatre
presentation is fully realized in the home and other settings.
DTS is the abbreviation for Digital Theatre System.
*To enjoy DTS surround sound you need the separately sold DTS
digital audio processor (PXA-H900/PXA-H700, etc.). The DVD
video software must also have a DTS sound track.
The IVA-D300R/IVA-D300RB has a built-in DTS 2-channel
audio decoder. Analog audio outputs are available.
Afar
Abkhazian
Afrikaans
Amharic
Arabic
Assamese
Aymara
Azerbaijani
Bashkir
Byelorussian
Bulgarian
Bihari
Bislama
Bengali, Bangla
Tibetan
Breton
Catalan
Corsican
Czech
Welsh
Danish
German
Bhutani
Greek
English
Esperanto
Spanish
Estonian
Basque
Persian
Finnish
Fiji
Faroese
French
Frisian
Irish
Scots Gaelic
Galician
Guarani
Gujarati
Hausa
Hindi
Croatian
Hungarian
Armenian
Interlingua
Interlingue
Inupiak
Indonesian
Icelandic
Italian
Hebrew
Japanese
Yiddish
Javanese
Georgian
Kazakh
Greenlandic
Cambodian
Kannada
Korean
Kashmiri
Kurdish
Kirghiz
Latin
Lingala
Laothian
Lithuanian
Latvian, Lettish
Malagasy
Maori
Macedonian
Malayalam
Mongolian
Moldavian
Marathi
Malay
Maltese
Burmese
Nauru
Nepali
Dutch
Norwegian
Occitan
(Afan) Oromo
Oriya
Punjabi
Polish
Pashto, Pushto
Portuguese
Quechua
Rhaeto-Romance
Dominica
Dominican Republic
Algeria
Ecuador
Estonia
Egypt
Western Sahara
Eritrea
Spain
Ethiopia
Finland
Fiji
Falkland Islands
Micronesia, Federated States of
Faroe Islands
France
Gabon
United Kingdom
Grenada
Georgia
French Guiana
Ghana
Gibraltar
Greenland
Gambia
Guinea
Guadeloupe
Equatorial Guinea
Greece
South Georgia and the
South Sandwich Islands
Guatemala
Guam
Guinea-Bissau
Guyana
Hong Kong
Heard Island and
McDonald Islands
Honduras
Croatia
Haiti
Hungary
Indonesia
Ireland
Israel
India
British Indian Ocean Territory
Iraq
Iran, Islamic Republic of
Iceland
Italy
Jamaica
Jordan
Japan
Kenya
Kyrgyzstan
Cambodia
KI
KM
KN
KP
KR
KW
KY
KZ
LA
LB
LC
LI
LK
LR
LS
LT
LU
LV
LY
MA
MC
MD
MG
MH
MK
ML
MM
MN
MO
MP
MQ
MR
MS
MT
MU
MV
MW
MX
MY
MZ
NA
NC
NE
NF
NG
NI
NL
NO
NP
NR
NU
NZ
OM
PA
7573
Kiribati
7577
Comoros
7578
Saint Kitts and Nevis
7580
Korea, Democratic
People’s Republic of
7582
Korea, Republic of
7587
Kuwait
7589
Cayman Islands
7590
Kazakstan
7665
Lao People’s
Democratic Republic
7666
Lebanon
7667
Saint Lucia
7673
Liechtenstein
7675
Sri Lanka
7682
Liberia
7683
Lesotho
7684
Lithuania
7685
Luxembourg
7686
Latvia
7689
Libyan Arab Jamahiriya
7765
Morocco
7767
Monaco
7768
Moldova, Republic of
7771
Madagascar
7772
Marshall Islands
7775
Macedonia, The former
Yugoslav Republic of
7776
Mali
7777
Myanmar
7778
Mongolia
7779
Macau
7780
Northern Mariana Islands
7781
Martinique
7782
Mauritania
7783
Montserrat
7784
Malta
7785
Mauritius
7786
Maldives
7787
Malawi
7788
Mexico
7789
Malaysia
7790
Mozambique
7865
Namibia
7867
New Caledonia
7869
Niger
7870
Norfolk Island
7871
Nigeria
7873
Nicaragua
7876
Netherlands
7879
Norway
7880
Nepal
7882
Nauru
7885
Niue
7890
New Zealand
7977
Oman
8065
Panama
60-EN
Abbreviation
PE
PF
PG
PH
PK
PL
PM
PN
PR
PT
PW
PY
QA
RE
RO
RU
RW
SA
SB
SC
SD
SE
SG
SH
Taiwan, Province of China
Tanzania, United Republic of
Ukraine
Uganda
United States Minor
Outlying Islands
United States
Uruguay
Uzbekistan
Holy See (Vatican City State)
Saint Vincent and the
Grenadines
Venezuela
Virgin Island, British
Virgin Islands, U.S
Viet Nam
Vanuatu
Wallis and Futuna
Samoa
Yemen
Mayotte
Yugoslavia
South Africa
Zambia
Zimbabwe
61-EN
In Case of Difficulty
If you encounter a problem, please turn the power off, then on
again. If the unit is still not functioning normally, please review
the items in the following checklist. This guide will help you
isolate the problem if the unit is at fault. Otherwise, make sure the
rest of your system is properly connected, or then consult your
authorized Alpine dealer.
Basic
No function or display.
• Vehicle’s ignition is off.
- If connected according to the instructions, the unit will not
operate with the vehicle’s ignition off.
• Improper power lead connections.
- Check power lead connections.
• Blown fuse.
- Check the fuse on the battery lead of the unit; replace
with the proper value if necessary.
• Internal micro-computer malfunctioned due to interference
noise, etc.
- Press the RESET switch with a ballpoint pen or other
pointed article.
• Blackout mode is activated.
- Cancel Blackout mode.
No sound or unnatural sound.
• Incorrect setting of volume/balance/fader controls.
- Readjust the controls.
• Connections are not properly or securely made.
- Check the connections and firmly connect.
Screen not displayed.
• Brightness control is set at the minimum position.
- Adjust the Brightness control.
• Temperature in the vehicle is too low.
- Increase the vehicle’s interior temperature to operation
temperature range.
• Connections to the DVD, CD player, navigation system are not
securely made.
- Check the connections and firmly connect.
Movement of displayed picture is abnormal.
• Temperature in the vehicle is too high.
- Allow the vehicle’s interior temperature to cool.
Unclear or noisy display.
• Fluorescent plate is worn out.
- Replace the fluorescent plate.
Navigation system inoperative.
• Connections to the navigation system are incorrect.
- Check the connections with the navigation system and
connect the cables correctly and firmly.
Unclear picture display.
• Fluorescent tube is exhausted.
- Replace the fluorescent tube*.
* The fluorescent tube replacement is not free of charge even within
the warranty period, for the tube is an article of consumption.
Radio
Unable to receive stations.
• No antenna, or open connection in the antenna cable.
- Make sure the antenna is properly connected;
replace the antenna or cable if necessary.
Unable to tune stations in the seek mode.
• You are in a weak signal area.
- Make sure the tuner is in DX mode.
• If the area you are in is a primary signal area, the antenna may
not be grounded and connected properly.
- Check your antenna connections; make sure the antenna is
properly grounded at its mounting location.
• The antenna may not be the proper length.
- Make sure the antenna is fully extended; if broken, replace
the antenna with a new one.
Broadcast is noisy.
• The antenna is not the proper length.
- Extend the antenna fully; replace it if it is broken.
• The antenna is poorly grounded.
- Make sure the antenna is grounded properly at its mounting
location.
• The station signal is weak and noisy.
- If above solution does not work, tune in another station.
CD/MP3/WMA/DVD/Video CD
Disc playback sound is wavering.
• Moisture condensation in the disc Module.
- Allow enough time for the condensation to evaporate
(about 1 hour).
Disc insertion not possible.
• A disc is already in the DVD player.
- Eject the disc and remove it.
• The disc is being improperly inserted.
- Make sure the disc is being inserted following the
instructions in the CD (MP3/WMA/DVD/Video CD) Player
Operation section.
Unable to fast forward or backward the disc.
• The disc has been damaged.
- Eject the disc and discard it; using a damaged disc in
your unit can cause damage to the mechanism.
Disc playback sound skips due to vibration.
• Improper mounting of the unit.
- Securely re-mount the unit.
• Disc is very dirty.
- Clean the disc.
• Disc has scratches.
- Change the disc.
• The pick-up lens is dirty.
- Do not use a commercial available lens cleaner disc.
Consult your nearest ALPINE dealer.
Disc playback sound skips without vibration.
• Dirty or scratched disc.
- Clean the disc; damaged disc should be replaced.
CD-R/CD-RW playback not possible.
• Close session (finalization) has not been performed.
- Perform finalization and attempt playback again.
62-EN
Error displays
• Mechanical error
- Press c. After the error indication disappears, insert the disc
again. If the above-mentioned solution does not solve the
problem, consult your nearest ALPINE dealer.
MP3/WMA is not played back.
• Writing error occurred. The CD format is not compatible.
- Make sure the CD has been written in a supported format.
Refer to “About MP3/WMA” (pages 17 and 18), then rewrite
in the format supported by this device.
Unit does not operate.
• Monitor’s power is not turned on.
-Turn on the monitor’s power.
• Condensation.
-Wait a while (about 1 hour) for the condensation to dry.
No picture is produced.
• Monitor’s mode is not switched to the mode you want to see.
- Switch to the mode you want to see.
• Monitor’s parking brake lead is not connected.
- Connect the monitor’s parking brake lead and set the parking
brake.
(For details, refer to the monitor’s instructions.)
• Monitor’s parking brake is not set.
- Connect the monitor’s parking brake lead and set the parking
brake.
(For details, refer to the monitor’s instructions.)
Playback does not start.
• Disc is loaded upside-down.
- Check the disc and load it with the labelled side facing
upward.
• Disc is dirty.
- Clean the disc.
• A disc not able to playback with this unit is loaded.
- Check if the disc is able to be played back.
• Parental lock is set.
- Cancel the parental lock or change the rating level.
Picture is unclear or noisy.
• Disc is being fast-forwarded or fast-reversed.
- The picture may be slightly disturbed, but this is normal.
• Vehicle’s battery power is weak.
- Check the battery power and wiring.
(The unit may malfunction if the battery power is under 11
volts with a load applied.)
• Monitor’s fluorescent tube is worn.
- Replace the monitor’s fluorescent tube.
Image stops sometimes.
• Disc is scratched.
- Replaced with a non-scratched disc.
Indication for CD/MP3/WMA
HI-TEMP
• Protective circuit is activated due to high temperature.
- The indicator will disappear when the temperature returns to
within operation range.
-Leave the power OFF until the temperature decreases and
then turn the power ON again.
NO DISC
• No disc is inserted.
- Insert a disc.
• Although a disc is inserted, “NO DISC” is displayed and the
unit does not start to play or eject the disc.
- Remove the disc by following these steps:
Press c for at least 3 seconds.
LOADING ERROR
EJECT ERROR
• Mechanism error.
1) Press c and eject the disc.
If not ejecting, consult your Alpine dealer.
2) When the error indication remains after ejecting, press c
again.
If the error indication still does not turn off after pressing
c for a few times, consult your Alpine dealer.
DISC ERROR
• Scratched disc, contaminated disc/poor recording/disc
incompatible with this unit
- Press c.
- Change the disc.
63-EN
Indication for DVD/Video CD
Indication for CD changer
NO DISC
• No disc is inserted.
- Insert a disc.
• Although a disc is inserted, “NO DISC” is displayed and the
unit does not start to play or eject the disc.
- Remove the disc by following these steps:
Press c for at least 3 seconds.
• Remote control operation is not possible.
-For some discs or playing modes, certain operations are not
possible. This is not a malfunction.
HI-TEMP
• Protective circuit is activated to high temperature.
- The indicator will disappear when the temperature returns to
within operation range.
-Leave the power OFF until the temperature decreases and
then turn the power ON again.
LOADING ERROR
EJECT ERROR
• Mechanism error.
1) Press c and eject the disc.
If not ejecting, consult your Alpine dealer.
2) When the error indication remains after ejecting, press c
again.
If the error indication still does not turn off after pressing
c for a few times, consult your Alpine dealer.
HI-TEMP
• Protective circuit is activated due to high temperature.
- The indicator will disappear when the temperature returns to
within operation range.
ERROR01
• Malfunction in the CD Changer.
- Consult your Alpine dealer. Press the magazine eject
button and pull out the magazine.
Check the indication. Insert the magazine again.
If the magazine cannot be pulled out, consult your Alpine
dealer.
• Magazine ejection not possible.
- Press the magazine eject button. If the magazine does
not eject, consult your Alpine dealer.
ERROR02
•A disc is left inside the CD Changer.
- Press the Eject button to activate the eject function. When the
CD Changer finishes the eject function, insert an empty CD
magazine into the CD Changer to receive the disc left inside
the CD Changer.
NO MAGAZINE
• No magazine is loaded into the CD Changer.
- Insert a magazine.
NO DISC
DISC ERROR
• Scratched disc, contaminated disc/poor recording/disc
incompatible with this unit
- Press c.
- Change the disc.
• No indicated disc.
- Choose another disc.
64-EN
Specifications
MONITOR SECTION
Screen Size7.0"
LCD TypeTransparent type TN LCD
Operation SystemTFT active matrix
Number of Picture Elements 336,960 pcs. (1,440 × 234)
Effective Number of Picture Elements
80 dB
Signal-to-Noise Ratio80 dB
Stereo Separation45 dB
Capture Ratio2.0 dB
MW TUNER SECTION
Tuning Range531 – 1,602 kHz
Sensitivity (IEC Standard)25.1 µV/28 dB
LW TUNER SECTION
Tuning Range153 – 281 kHz
Sensitivity (IEC Standard)31.6 µV/30 dB
CD/DVD SECTION
Frequency Response5 – 20,000 Hz
Wow & Flutter (% WRMS)Below measurable limits
Total Harmonic Distortion0.008% (at 1 kHz)
Dynamic Range95 dB (at 1 kHz)
Channel Separation85 dB (at 1 kHz)
Signal systemNTSC/PAL
Horizontal resolution500 lines or greater
Video output level1Vp-p (75 ohms)
Video S/N ratioDVD: 60 dB
Audio S/N ratioMore than 105 dB
GENERAL
Power Requirement14.4 V DC
(11–16 V allowable)
Operating temperature+32°F to +113°F
(0°C to + 45°C)
Maximum Power Output50 W × 4
Output Voltage2,000 mV/10k ohms
Weight(Monitor Section) 2.1 kg
Width178 mm (7")
Height50 mm (2")
Depth165 mm (6-1/2")
CHASSIS SIZE (Tuner section)
Width275 mm (10-13/16")
Height40 mm (1-9/16")
Depth170 mm (6-3/4")
• Due to continuous product improvement, specifications and design
are subject to change without notice.
• The LCD panel is manufactured using an extremely high precision
manufacturing technology. Its effective pixel ratio is over 99.99%.
This means that there is a possibility that 0.01% of the pixels could
be either always ON or OFF.
CAUTION
PICKUP
Wave lengthDVD: 665 nm
CD: 800 nm
Laser powerCLASS I
CLASS 1
LASER PRODUCT
(Bottom side of Monitor player)
65-EN
Installation and Connections
Before installing or connecting the unit, please read the
following and pages 4 to 6 of this manual thoroughly
for proper use.
Warning
MAKE THE CORRECT CONNECTIONS
Failure to make the proper connections may result in fire or
product damage.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so may
result in fire, etc.
BEFORE WIRING, DISCONNECT THE CABLE FROM THE
NEGATIVE BATTERY TERMINAL.
Failure to do so may result in electric shock or injury due to
electrical shorts.
DO NOT ALLOW CABLES TO BECOME ENTANGLED IN
SURROUNDING OBJECTS.
Arrange wiring and cables in compliance with the manual to
prevent obstructions when driving. Cables or wiring that obstruct
or hang up on places such as the steering wheel, shift lever, brake
pedals, etc. can be extremely hazardous.
DO NOT SPLICE INTO ELECTRICAL CABLES.
Never cut away cable insulation to supply power to other
equipment. Doing so will exceed the current carrying capacity of
the wire and result in fire or electric shock.
DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING
HOLES.
When drilling holes in the chassis for installation, take
precautions so as not to contact, damage or obstruct pipes, fuel
lines, tanks or electrical wiring. Failure to take such precautions
may result in fire.
DO NOT USE BOLTS OR NUTS IN THE BRAKE OR
STEERING SYSTEMS TO MAKE GROUND CONNECTIONS.
Bolts or nuts used for the brake or steering systems (or any other
safety-related system), or tanks should NEVER be used for
installations or ground connections. Using such parts could
disable control of the vehicle and cause fire etc.
KEEP SMALL OBJECTS SUCH AS BOLTS OR SCREWS OUT
OF THE REACH OF CHILDREN.
Swallowing them may result in serious injury. If swallowed,
consult a physician immediately.
DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER
VEHICLE OPERATION, SUCH AS THE STEERING WHEEL
OR SHIFT LEVER.
Doing so may obstruct forward vision or hamper movement etc.
and results in serious accident.
Caution
HAVE THE WIRING AND INSTALLATION DONE BY
EXPERTS.
The wiring and installation of this unit requires special technical
skill and experience. To ensure safety, always contact the dealer
where you purchased this product to have the work done.
USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM
SECURELY.
Be sure to use only the specified accessory parts. Use of other
than designated parts may damage this unit internally or may not
securely install the unit in place. This may cause parts to become
loose resulting in hazards or product failure.
ARRANGE THE WIRING SO IT IS NOT CRIMPED OR
PINCHED BY A SHARP METAL EDGE.
Route the cables and wiring away from moving parts (like the
seat rails) or sharp or pointed edges. This will prevent crimping
and damage to the wiring. If wiring passes through a hole in
metal, use a rubber grommet to prevent the wire’s insulation from
being cut by the metal edge of the hole.
DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE
OR DUST.
Avoid installing the unit in locations with high incidence of
moisture or dust. Moisture or dust that penetrates into this unit
may result in product failure.
Precautions
• Be sure to disconnect the cable from the (–) battery post before
installing your IVA-D300R/IVA-D300RB. This will reduce any
chance of damage to the unit in case of a short-circuit.
• Be sure to connect the color coded leads according to the
diagram. Incorrect connections may cause the unit to
malfunction or damage to the vehicle’s electrical system.
• When making connections to the vehicle’s electrical system, be
aware of the factory installed components (e.g. on-board
computer). Do not tap into these leads to provide power for this
unit. When connecting the IVA-D300R/IVA-D300RB to the
fuse box, make sure the fuse for the intended circuit of the
IVA-D300R/IVA-D300RB has the appropriate amperage.
Failure to do so may result in damage to the unit and/or the
vehicle. When in doubt, consult your ALPINE dealer.
• The IVA-D300R/IVA-D300RB uses female RCA-type jacks for
connection to other units (e.g. amplifier) having RCA
connectors. You may need an adaptor to connect other units. If
so, please contact your authorized ALPINE dealer for
assistance.
• Be sure to connect the speaker (–) leads to the speaker (–)
terminal. Never connect left and right channel speaker cables to
each other or to the vehicle body.
• The Display must be completely retracted in the casing when
installing. If it is not, problems may occur.
• When installing in automobiles, make sure the Display can
open/close without coming in contact with the gear shift .
IMPORTANT
Please record the serial number of your unit in the space provided
below and keep it as a permanent record. The serial number plate is
located on the bottom of the unit.
66-EN
SERIAL NUMBER:
INSTALLATION DATE:
INSTALLATION TECHNICIAN:
PLACE OF PURCHASE:
Installation
Installing the Monitor
Installation Location
Before deciding on the mounting location, check that opening and
closing the display will not hamper gear shifting in that position.
• Install at an angle of within 30 degrees from the horizontal.
• The monitor’s angle is set to 90 degrees at the factory. Depending
on the car, the monitor may hit the dashboard when opened. The
monitor’s angle can be adjusted and stored in memory so that the
monitor will not hit the dashboard when opening. For adjusting the
monitor, refer to “Adjusting the monitor Angle” on page 26.
Even when the vehicle’s battery power is removed, the adjusted
monitor angle remains stored in memory.
When your vehicle has the Bracket, mount the long hex
bolt onto the rear panel of the IVA-D300R/IVA-D300RB
and put the Rubber Cap on the hex bolt. If your vehicle
does not have the Mounting Support, reinforce the monitor
unit with the metal mounting strap (not supplied). Secure
the ground lead of the unit to a clean metal spot using a
screw (}) already attached to the vehicle’s chassis.
•For the screw marked }}, use an appropriate screw for the
chosen mounting location.
Connect each input lead coming from an amplifier or
equalizer to the corresponding output lead coming from
the left rear of the IVA-D300R/IVA-D300RB. Connect all
other leads of the IVA-D300R/IVA-D300RB according to
details described in the Connections section.
3
1
Bracket
Dashboard
Slide the mounting sleeve into the dashboard. Install the
supplied bracket on the monitor.
• Make sure to use the supplied screw (M4 × 3) to install the
monitor.
If you use another screw to install the monitor, it may cause a
malfunction.
2
Hex Nut (M5)
Metal Mounting
Strap
Mounting Sleeve
(Included)
Rubber Cap
(Included)
Screws (M4 × 3)
(Included)
Mounting Bracket
(Included)
Hex Bolt
(Included)
IVA-D300R/
IVA-D300RB
Screw
Bolt Stud
IVA-D300R/
IVA-D300RB
Lock Pin
Slide the IVA-D300R/IVA-D300RB into the dashboard.
When the unit is in place, make sure the locking pins are
fully seated in the down position. This can be done by
pressing firmly in on the unit while pushing the locking pin
down with a small screwdriver. This ensures that the unit is
properly locked and will not accidentally come out from
the dashboard. Install the supplied Front Frame.
Removal
1. Use a small screwdriver (or similar tool) to push the
locking pins to the “up” position (see Step 3). As each
pin is unlocked, gently pull out on the unit to make sure
it does not re-lock before unlocking the second pin.
2. Pull the unit out, keeping it unlocked as you do so.
< JAPANESE CAR >
To install using the vehicle’s genuine bracket.
Screws (M4 × 6)
Ground Lead
IVA-D300R/
IVA-D300RB
(Included)
Mounting Bracket
Ground
Lead
Chassis
Wider edge should face down.
Front Frame
(Included)
• Make sure to use the supplied screw (M4 × 6) to install the
monitor.
If you use another screw to install the monitor, it may cause a
malfunction.
67-EN
Installing the Tuner Box
Caution
Do not block the unit’s fan or heat sink, thus
preventing air circulation. If blocked, heat will
accumulate inside the unit and may cause a fire.
Air ventilation hole
<Side of the tuner box>
When mounting with Velcro fasteners
When mounting the tuner with the Velcro fasteners, be sure to choose
a flat location.
Do not hang the unit from the bottom of the dashboard or rear deck
with the Velcro fasteners.
Remove the Protective paper and attach two pieces
1
of Velcro fastener to the bottom of the Tuner.
Install the tuner on the floor with the supplied
2
flange-head tapping screws (M4 × 14).
Flange-head tapping screws
(M4 × 14) (Included)
Tuner Box
Installing the DC/DC Converter
Install the DC/DC Converter on the floor with the
supplied flange-head tapping screws (M4 × 14).
Flange-head tapping
screws (M4 × 14)
(Included)
Tuner Box
Protective paper
Velcro Fasteners
Protective paper
Check the position, and then fix the Tuner to the
2
floor carpet.
When mounting with Screws
When mounting the tuner with the screws, be sure to choose a flat
location.
When making holes, be careful not to scratch any pipes or wires.
Connect the bracket to both the flanks of the tuner
1
with the supplied pan screws (M4 × 8).
Tuner Box
(Included)
Bracket (Included)
DC/DC Converter
Pan screws (M4 × 8) (Included)
68-EN
Parking Brake Lead Connection
If necessary, use a pinch connector to connect the parking brake lead, etc.
12
Vehicle Cable
Pinch Connector
Stopper
Pliers
Monitor Cable
Connection Diagram of SPST Switch (Sold Separately)
(If the ACC power supply is not available)
IVA-D300R/IVA-D300RB
(Monitor and Tuner Box)
ACC
(Red)
BATTERY
(Yellow)
SPST SW (Optional)
FUSE (5A)
(Optional)
FUSE (20A)
(Optional)
Battery
• If your vehicle has no ACC power supply, add an SPST (Single-Pole, Single-Throw) switch (sold separately) and fuse (sold separately).
• The diagram and the fuse amperage shown above are in the case when IVA-D300R/IVA-D300RB is used individually.
• If the switched power (ignition) lead of the IVA-D300R/IVA-D300RB is connected directly to the positive (+) post of the vehicle‘s battery, the
IVA-D300R/IVA-D300RB draws some current (several hundred milliamperes) even when its switch is placed in the OFF position and the
battery may be discharged.
To prevent external noise from entering the audio system.
• Locate the unit and route the leads at least 10 cm away from the car harness.
• Keep the battery power leads as far away from other leads as possible.
• Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis.
• If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various
noise suppressors, contact them for further information.
• Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.
69-EN
Connections (IVA-D300R/IVA-D300RB Wiring Diagram)
Antenna
To remote control
interface box
#
)
IVA-D300R/IVA-D300RB
Tuner BOX
"
POWER SUPPLY
REMOTE IN/OUT
NAVIGATION IN
~
DISPLAY OUT
+
,
EQ/DIV
NORM
!
23
IVA-D300R/IVA-D300RB
9
<Monitor>
"
8
SUBW.
REAR
PRE IN/OUT
FRONT
L
R
Ai-NET
EXT.OUT
AV.SELECTOR
CAMERA IN
AUX OUT
VIDEO
L
AUDIO
R
AUX IN
RADIO ANTENNA IN
>
=
<
;
:
/
.
-
(Orange)
BATTERY
(Yellow)
(Black)
|
ILLM
GND
REMOTE
TURN-ON
(Blue/White)
POWER ANT
(Blue)
AUDIO
INTERRUPT IN
(Pink/Black)
PARKING
BRAKE
(Yellow/Blue)
ACC
(Red)
BATTERY
(Yellow)
GND
(Black)
5
6
7
REMOTE OUT
(White/Brown)
REMOTE IN
(White/Brown)
REVERSE
(Orange/White)
(White/Pink)
?
[
\
^
{
6
ILLM
(Orange)
BATTERY
(Yellow)
M.CONT
P.ANT
(Blue)
ACC
(Red)
4
GND
(Black)
$
%
&
(
To the instrument
cluster illumination
lead
To remote
input lead.
To remote
output lead.
To plus side of the
back lamp signal
lead of the car
To monitor
control lead.
@
]
_
1
Note:
Be sure to connect the leads
SPEAKER
LEFT
FRONT
(White)
Black)
SPEAKER
LEFT
REAR
(Green/
Black)
SPEAKER
RIGHT
REAR
(Violet)(Green)(White/
(Violet/
Black)
SPEAKER
RIGHT
FRONT
(Grey/Black) (Grey)
correctly after identifying the
ISO connector terminals for
the Battery and Ignition
(ACC).
5432710V}
F-LchR-LchR-RchF-Rch
• Set the system switch to “NORM” when only a changer is connected (when the Ai-NET compatible equalizer is not used).
70-EN
1 ISO Antenna Plug
2 ISO Antenna Converter Plug (Included)
3 Antenna Extension Cable
4 ISO Connector (Included)
5 Illumination Lead (Orange)
This lead may be connected to the vehicle’s instrument
cluster illumination lead. This will allow the backlighting of
the IVA-D300R/IVA-D300RB to dim whenever the vehicle‘s
lights are turned on.
6 Battery Lead (Yellow)
Connect this lead to the positive (+) post of the vehicle’s
battery.
7 Ground Lead (Black)
Connect this lead to a good chassis ground on the
vehicle. Make sure the connection is made to bare metal
and is securely fastened using the sheet metal screw
provided.
8 Fuse Holder (10A)
9 Digital Output Terminal (Optical)
Use when combining fiber digital input compatible
products.
! Remote Control Interface Connector
Connect to the remote control interface box.
" Power Supply Connector
# DC/DC Converter
• Do not install the converter at a location subjected to water
such as under the floor mat or air conditioner. This may cause
a malfunction.
• Do not bundle the DC/DC converter cable with other audio
cables. Also, do not install the cables directly next to the unit.
Doing so may induce noise into your system.
•Keep the DC/DC converter away from the Antenna cables and
the rear side of the unit, otherwise noise may be generated
when receiving radio broadcast.
$ Remote Control Output Lead (White/Brown)
Connect this lead to the remote control input lead. This
lead outputs the controlling signals from the remote
control.
% Remote Control Input Lead (White/Brown)
Connect the external Alpine product to the remote control
output lead.
& Reverse Lead (Orange/White)
Use only when a back-up camera is connected. Connect
to the plus side of the car’s reverse lamp that lights when
the transmission is shifted into reverse (R).
Switches the video picture to the back-up camera. This is
linked with putting the car into reverse (R).
( Monitor Control Lead (White/Pink)
Connect this to the Monitor Control Lead of the touch
panel-compatible rear monitor.
) Monitor Extension Cable (Included)
~ Remote IN/OUT Terminal
+ Display Output Terminal
, System Switch
When connecting an equalizer or divider using Ai-NET
feature, place this switch in the EQ/DIV position. When no
device is connected, leave the switch in the NORM
position.
• Be sure to turn the power off to the unit before changing the
switch position.
- Antenna Receptacle
. AUX Input Terminals/AUX Output Terminals
If these terminals are connected to the optional expansion
box (VPE-S431), the AUX input and output terminals are
not used on this unit. Connect AUX IN 1, 2 and 3, and the
AUX OUT 1 and 2 terminals of the extension box (VPES431) to the external device(s).
/ AV Select Connector
When this connector is connected to the optional
expansion box (VPE-S431), connect this to the HEAD
UNIT terminal of VPE-S431.
: Ext. Output Connector
If this connector is connected to the optional Amplifier
Link compatible monaural Amplifier, connect this to the
optional Amplifier Link Box, and output the Amplifier Link
control signal.
; Ai-NET Connector
Connect this to the output or input connector of other
product (CD changer, Equalizer, etc.) equipped with AiNET.
< Front input/output Terminal
Use when connecting an amplifier or equalizer.
= Rear input/output Terminal
Use when connecting an amplifier or equalizer.
> Subwoofer output Terminal
Connect the input lead of an amplifier for the subwoofer to
this terminal.
? Remote Turn-On Lead (Blue/White)
Connect this lead to the remote turn-on lead of your
amplifier or signal processor.
@ To amplifier or equalizer
[ Power Antenna Lead (Blue)
Connect this lead to the +B terminal of your power
antenna, if applicable.
\ Audio Interrupt In Lead (Pink/Black)
] To vehicle phone
^ Parking Brake Lead (Yellow/Blue)
Connect this lead to the power supply side of the parking
brake switch to transmit the parking brake status signals
to the IVA-D300R/IVA-D300RB.
_ Connect this lead to the parking brake lead
powered when parking brake is engaged.
{ Switched Power Lead (Ignition) (Red)
Connect this lead to an open terminal on the vehicle’s fuse
box or another unused power source which provides (+)
12V only when the ignition is turned on or in the accessory
position.
| Fuse Holder (10A)
} Right Front (+) Speaker Output Lead (Grey)
V Right Front (–) Speaker Output Lead (Grey/Black)
0 Right Rear (–) Speaker Output Lead (Violet/Black)
1 Right Rear (+) Speaker Output Lead (Violet)
2 Left Rear (+) Speaker Output Lead (Green)
3 Left Rear (–) Speaker Output Lead (Green/Black)
4 Left Front (–) Speaker Output Lead (White/Black)
5 Left Front (+) Speaker Output Lead (White)
71-EN
System Example
Connect the Ai-NET compatible audio processor (Fiber digital compatible), Navigation system, DVD
player and changer.
IVA-D300R/IVA-D300RB Monitor
NVE-N077PS/NVE-N099P
1
Navigation system
(Sold Separately)
IVA-D300R/IVA-D300RB
Tuner BOX
POWER SUPPLY
2
REMOTE IN/OUT
NAVIGATION IN
DISPLAY OUT
3
4
EQ/DIV
NORM
(Yellow)
*Fiber digital Input terminal
Audio Processor (Ai-NET)
(Fiber Digital compatible)
SUBW.
PRE IN/OUT
REAR
FRONT
L
R
Ai-NET
EXT.OUT
AV.SELECTOR
CAMERA IN
AUX OUT
VIDEO
L
AUDIO
R
AUX IN
RADIO ANTENNA IN
7
6
Ai-NET
cable
Fiber digital
Input terminal
(for DVD Player)
!
9
8
Fiber optic cable
Fiber optic
5
cable
(for head unit)
(Sold Separately)
66
#
Ai-NET
cable
!
Fiber digital
Input terminal
(for Changer)
!
**
Fiber
optic cable
%
(White/Brown)
REMOTE OUT
$
(White/Brown)
REMOTE IN
DVD Video Player
(DVA-5210 etc.)
(Sold Separately)
Ai-NET cable
&
"
**
Only connect fiber digital compatible CD Changer
CD Changer (Ai-NET)
(Sold Separately)
• When the fiber digital compatible product is connected, it is necessary to set the mode of this unit. Refer to “Setting the Digital Output” (page
30) and set to ON. Then refer to “Optical Digital Input Selection for an External Audio Processor” (page 34) and switch the setting.
•* When connecting with PXA-H510 :
- Connect the fiber digital input terminal to the DVD.
-IVA-D300R/IVA-D300RB and DVA-5205P or DVA-5210 cannot be connected simultaneously when fiber digital is in use.
• When the NVE-N055PS is connected for the Navigation System, use the RGB conversion cable KCE-030N (Sold separately).
Please observe the following when using Fiber Optic Cable.
• Do not coil the Fiber Optic Cable smaller than a 30 mm radius.
• Do not place anything on top of the Fiber Optic Cable.
72-EN
1 RGB Cable (Included with Navigation)
2 Remote IN/OUT Terminal
3 RGB Input Terminal
Connect this to the RGB output terminal of the Navigation
System.
4 System Switch
When connecting an equalizer or divider using Ai-NET
feature, place this switch in the EQ/DIV position. When no
device is connected, leave the switch in the NORM
position.
• Be sure to turn the power off to the unit before changing the
switch position.
5 Digital Output Terminal
6 Ai-NET Connector
Connect this to the output or input connector of other
product equipped with Ai-NET.
7 AUX Video Input Terminal
Connect the video output lead of a DVD video player or
DVD changer to this terminal.
8 RCA Extension Cable (Included with DVD video
player)
9 Ai-NET Cable (Included with DVD video player)
! Fiber optic Cable (Sold Separately)
" Ai-NET Cable (Included with Audio Processor)
# Ai-NET Cable (Included with CD Changer)
$ Remote Control Output Lead (White/Brown)
Connect this lead to the remote control input lead. This
lead outputs the controlling signals from the remote
control.
% To Ai-NET Connector (Grey)
& To Ai-NET Connector (Black)
73-EN
When Connecting External Equipment
1
EQ/DIV
NORM
*
Connect this to the touch panel-compatible rear monitor.
2
Tuner BOX
POWER SUPPLY
REMOTE IN/OUT
NAVIGATION IN
DISPLAY OUT
(White/Pink)
(White/Brown)
(White/Brown)
(Orange/White)
PRE IN/OUT
4
AUX OUT
(MONO)
AUDIO
AUX IN
M.CONT
REMOTE OUT
REMOTE IN
REVERSE
IVA-D300R/IVA-D300RB
SUBW.
REAR
FRONT
VIDEO
L
R
RADIO ANTENNA IN
AV.SELECTOR
CAMERA IN
To Audio Input terminal
Rear monitor
!
(Sold Separately)
To Video Input terminal
L
R
Ai-NET
EXT.OUT
3
!
To Video Output terminal
Back-up camera
(Sold Separately)
5
!
To Video Output terminal
TV Tuner or VCR
(Sold Separately)
To Audio Output terminal
6
7
8
M.CONT
REMOTE IN
REMOTE OUT
(White/Pink)
(White/Brown)
(White/Brown)
9
Use only when back-up camera is connected.
1 System Switch
When connecting an equalizer or divider using Ai-NET
feature, place this switch in the EQ/DIV position. When no
device is connected, leave the switch in the NORM
position.
• Be sure to turn the power off to the unit before changing the
switch position.
2 Remote IN/OUT Terminal
3 CAMERA Input Terminal
Use when connecting a back-up camera.
4 AUX Video/Audio Output Terminal
Use when connecting an optional monitor etc.
5 AUX Video/Audio Input Terminal
6 Monitor Control Lead (White/Pink)
Connect this to the Monitor Control Lead of the touch
panel-compatible rear monitor.
74-EN
7 Remote Control Output Lead (White/Brown)
Connect this lead to the remote control input lead. This
lead outputs the controlling signals from the remote
control.
8 Remote Control Input Lead (White/Brown)
9 Connect to the plus side of the car’s reverse lamp
which lights when the transmission is shifted into
reverse (R).
Switches the video picture to the back-up camera.
This is linked to putting the car into reverse (R).
! RCA Extension Cable (Sold separately)
Connect an expansion box (VPE-S431), DVD Player, DVD Changer or the Touch Panel-compatible
Monitor.
IVA-D300R/IVA-D300RB
Tuner BOX
8
7
To AUX Input (AUX IN 1)
Terminals
4
To AUX Input (AUX IN 2)
Terminals
4
REMOTE OUT
(White/Brown)
REMOTE OUT
(AUX2)
(AUX1)
7
!
DVD PLAYER
(Sold separately)
"
!
DVD CHANGER
(Sold separately)
REMOTE IN
(White/Brown)
REMOTE IN
(White/Brown)
(AUX1)
(AUX2)
POWER SUPPLY
REMOTE IN/OUT
NAVIGATION IN
DISPLAY OUT
1
EQ/DIV
NORM
SUBW.
PRE IN/OUT
REAR
FRONT
L
R
Ai-NET
EXT.OUT
AV.SELECTOR
CAMERA IN
AUX OUT
VIDEO
L
3
AUDIO
R
AUX IN
RADIO ANTENNA IN
4
To Video Input
Terminals
To Audio Input
Terminals
2
To AUX Input (AUX IN 3)
Terminals
4
5
To AUX Output
Terminals
6
M.CONT
(White/Pink)
TOUCH PANEL COMPATIBLE
REAR MONITOR
(Sold separately)
EXPANSION BOX
(VPE-S431)
(Sold separately)
M.CONT
(White/Pink)
REMOTE
IN
(White/Brown)
REMOTE
OUT
(White/Brown)
9
• If the expansion box (VPE-S431) is connected to either a DVD video player or DVD changer, connect to AUX IN 1. If it is connected to AUX
IN 2, remote control operation will not be possible. If both are to be connected, connect the DVD video player to AUX IN 1, and the DVD
changer to AUX IN 2.
1 System Switch
When connecting an equalizer or divider using Ai-NET
feature, place this switch in the EQ/DIV position. When no
device is connected, leave the switch in the NORM
position.
• Be sure to turn the power off to the unit before changing the
switch position.
2 To AV Selector Terminal
3 AUX Video/Audio Output Terminal
4 RCA Extension Cable (Sold separately)
5 AV Selector Cable (Included with VPE-S431)
6 Monitor Control Lead (White/Pink)
Connect this to the Monitor Control Lead of the touch
panel-compatible rear monitor.
7 Remote Control Output Lead (White/Brown)
Connect this lead to the remote control input lead. This
lead outputs the controlling signals from the remote
control.
8 Ai-NET Cable (Included with DVD video player)
9 Ai-NET Cable (Included with DVD changer)
! To Ai-NET Connector (Black)
" To Ai-NET Connector (Grey)
75-EN
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
