CentreCOM
AT-MR840TF
8-Port Hub
Installation Guide
PN 613-10662-00 Rev. A
Page 2
Copyright 1997 Allied Telesyn International Corp.
All rights reserved. No part of this publication may be reproduced without prior written
permission from Allied Telesyn International Corp.
Allied Telesyn International Corp. reserves the right to make changes in specifications and
other information contained in this document without prior written notice. The information
provided herein is subject to change without notice. In no event shall Allied Telesyn
International Corp. be liable for any incidental, special, indirect, or consequential damages
whatsoever, including but not limited to lost profits, arising out of or related to this manual
or the information contained herein, even if Allied Telesyn International Corp. has been
advised of, known, or should have known, the possibility of such damages.
Trademarks: Ethernet is a registered trademark of Xerox Corporation.
All company names, logos, and product designations that are trademarks or registered
trademarks are the property of their owners.
Page 3
Electrical Safety and Installation Requirements
STANDARDS
RADIATED ENERGY
Note: This equipment has been tested and found to comply with the limits for a
Class A digital device pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Note: Modifications or changes not expressly approved by the manufacturer or the
FCC can void your right to operate this equipment.
This Class A digital apparatus meets all requirements of the Canadian InterferenceCausing Equipment Regulations.
Cet appariel numérique de la classe A respecte toutes les exigences du Règlement
sur le matériel brouilleur du Canada.
RFI Emission EN55022 Class A
: This product meets the following standards.
U.S. Federal Communications Commission
Canadian Department of Communications
WARNING
which case the user may be required to take adequate measures.
Immunity EN50082-1
Electrical Safety EN60950, UL1950, CSA 950
Laser EN60825
: In a domestic environment this product may cause radio interference in
iii
Page 4
Electrical Safety and Installation Requirements
SAFETY
ELECTRICAL NOTICES
WARNING:
To prevent ELECTRIC shock , do not remove cover. No user-serviceable parts inside.
This unit contains HAZARDOUS VOLTAGES and should only be opened by a trained
and qualified technician. To avoid the possibility of ELECTRIC SHOCK disconnect
electric power to the product before connecting or disconnecting the LAN cables.
This is a “CLASS 1 LED PRODUCT”
INSTALLATION
LIGHTNING DANGER
DANGER
ACTIVITY.
CAUTION
EQUIPMENT disconnect the power cord.
ELECTRIC SHOCK HAZARD
: DO NOT WORK on equipment or CABLES during periods of LIGHTNING
: POWER CORD IS USED AS A DISCONNECTION DEVICE. TO DE-ENERGISE
ELECTRICAL—AUTO VOLTAGE ADJUSTMENT
This product will automatically adjust to any voltage between the ranges shown on the
label.
ELECTRICAL—TYPE CLASS 1 EQUIPMENT
THIS EQUIPMENT MUST BE EARTHED. Power plug must be connected to a properly
wired earth ground socket outlet. An improperly wired socket outlet could place
hazardous voltages on accessible metal parts.
ELECTRICAL—CORD NOTICE
Use power cord, maximum 4.5 meters long, rated 6 amp minimum, 250V, made of
HAR cordage molded IEC 320 connector on one end and on the other end a plug
approved by the country of end use.
MOUNTING INSTRUCTIONS
CAUTION
: These models are designed for operation in the HORIZONTAL position.
VERTICAL MOUNTING must NOT BE DONE without the use of an Allied Telesyn
vertical mount chassis designed for this purpose.
CAUTION
: Air vents must not be blocked and must have free access to the room
ambient air for cooling.
OPERATING TEMPERATURE
This product is designed for a maximum ambient temperature of 50 degrees C.
ALL COUNTRIES
Codes.
: Install product in accordance with local and National Electrical
iv
Page 5
AT-MR840TF Installation Guide
NORMEN
: Dieses Produkt erfüllt die Anforderungen der nachfolgenden Normen.
Hochfrequenzstörung EN55022 Klasse A
WARNUNG
hervorrufen. In diesem Fall müßte der Anwender angemessene Gegenmaßnahmen
ergreifen.
Störsicherheit EN50082-1
Elektrische Sicherheit EN60950, UL1950, CSA 950
Laser EN60825
SICHERHEIT
ACHTUNG:
Das Gehäuse nicht öffnen. Das Gerät enthält keine vom Benutzer wartbaren Teile. Das
Gerät steht unter Hochspannung und darf nur von qualifiziertem technischem
Personal geöffnet werden. Vor Anschluß der LAN-Kabel, Gerät vom Netz trennen.
Das ist ein “LED Produkt der Klasse 1”
INSTALLATION
GEFAHR DURCH BLITZSCHLAG
GEFAHR
ausführen.
VORSICHT
ZUR TRENNUNG VOM NETZ, KABEL AUS DER STECKDOSE ZIEHEN.
AUTOMATISCHE SPANNUNGSEINSTELLUNG
Dieses Gerät stellt sich automatisch auf die auf dem Etikett aufgeführten
Spannungswerte ein.
: Bei Verwendung zu Hause kann dieses Produkt Funkstörungen
GEFÄHRLICHE SPANNUNG
: Keine Arbeiten am Gerät oder an den Kabeln während eines Gewitters
: DAS NETZKABEL DIENT ZUM TRENNEN DER STROMVERSORGUNG.
GERÄTE DER KLASSE 1
DIESE GERÄTE MÜSSEN GEERDET SEIN. Der Netzstecker darf nur mit einer
vorschriftsmäßig geerdeten Steckdose verbunden werden. Ein unvorschriftsmäßiger
Anschluß kann die Metallteile des Gehauses unter gefährliche elektrische Spannungen
setzen.
NETZKABEL
Das Netzkabel sollte eine maximale Länge von 4,5 Metern, einen Nennwert von
mindestens 6 A und 250 V haben, aus HAR-Material hergestellt und mit einer
gepreßten, IEC 320 entsprechenden, Anschlußverbindung an einem Ende, und am
anderen Ende mit einem im Land des Endverbrauchers geprüften Stecker ausgestattet
sein.
MONTAGEANWEISUNGEN
VORSICHT
Das Gerät darf NICHT OHNE Gebrauch eines dafür entworfenen Allied TelesynVertikalmontagegestells in VERTIKALER POSITION montiert werden.
: Diese Modelle sind für Betrieb in horizontaler Position entworfen worden.
v
Page 6
Electrical Safety and Installation Requirements
VORSICHT
Die Entlüftungsöffnungen dürfen nicht versperrt sein und müssen zum Kühlen freien
Zugang zur Raumluft haben.
BETRIEBSTEMPERATUR
Dieses Produkt wurde für den Betrieb in einer Umgebungstemperatur von nicht mehr
als 50° C entworfen.
ALLE LÄNDER
entsprechen.
STANDARDER
STRÅLINGSENERGI
Dette kommercielle produkt opfylder de krav, der i USA stilles til udstyr af Klasse A.
Radiofrekvens forstyrrelsesemission EN55022 Klasse A
ADVARSEL
Bliver det tilfældet, påkræves brugeren muligvis at tage tilstrækkelige foranstaltninger.
Immunitet EN50082-1
Elektrisk sikkerhed. EN60950, UL1950, CSA 950.
Laser EN60825
SIKKERHED
ELEKTRISKE FORHOLDSREGLER
ADVARSEL:
For at forebygge ELEKTRISK stød, undlad at åbne apparatet. Der er ingen indre dele,
der kan repareres af brugeren. Denne enhed indeholder LIVSFARLIGE
STRØMSPÆNDINGER og bør kun åbnes af en uddannet og kvalificeret tekniker. For
at undgå risiko for ELEKTRISK STØD, afbrydes den elektriske strøm til produktet, før
LAN-kablerne monteres eller afmonteres.
Dette er et “PRODUKT UNDER KLASSE 1 LED”
: Installation muß örtlichen und nationalen elektrischen Vorschriften
: Dette produkt tilfredsstiller de følgende standarder.
: I et hjemligt miljø kunne dette produkt forårsage radio forstyrrelse.
RISIKO FOR ELEKTRISK STØD
INSTALLATION
FARE UNDER UVEJR
FARE:
UNDLAD at arbejde på udstyr eller KABLER i perioder med LYNAKTIVITET.
ADVARSEL
SKAL STRØMMEN TIL APPARATET AFBRYDES, tages ledningen ud af stikket.
ELEKTRISK—AUTOMATISK SPÆNDINGSREGULERING
Dette apparat vil automatisk tilpasse sig enhver spænding indenfor de værdier, der er
angivet på etiketten.
vi
: DEN STRØMFØRENDE LEDNING BRUGES TIL AT AFBRYDE STRØMMEN.
Page 7
AT-MR840TF Installation Guide
ELEKTRISK—KLASSE 1-UDSTYR
DETTE UDSTYR KRÆVER JORDFORBINDELSE. Stikket skal være forbundet med en
korrekt installeret jordforbunden stikkontakt. En ukorrekt installeret stikkontakt kan
sætte livsfarlig spænding til tilgængelige metaldele.
ELEKTRISK -- LEDNING
Anvend ledning af maksimum 4,5 meters længde, med en kapacitet på minimum 6
amp., 250 v, bestående af en IEC 320 connector med indstøbt HAR ledning i den ene
ende og et stik i den anden ende, der er godkendt af myndighederne i brugerlandet.
INSTRUKTIONER FOR OPSTILLING
ADVARSEL
(vandret).VERTIKAL OPSTILLING (lodret) må IKKE FORETAGES uden brug af et Allied
Telesyn vertikalt monteringsstel konstrueret til dette formål.
: Disse modeller er konstrueret til at betjenes i HORISONTAL position
ADVARSEL
omgivende luft i rummet for afkøling.
BETJENINGSTEMPERATUR
Dette apparat er konstrueret til en omgivende temperatur på maksimum 50 grader C.
ALLE LANDE
national lovgivning for elektriske installationer.
EISEN
STRALINGSENERGIE
Dit handelsprodukt werd getest en voldoet aan de Amerikaanse vereisten voor een
klasse A toestel.
RFI Emissie EN55022 Klasse A
WAARSCHUWING
geval de gebruiker verplicht kan worden om gepaste maatregelen te nemen.
Immuniteit EN50082-1
Electrische Veiligheid EN60950, UL1950, CSA 950
Laser EN60825
VEILIGHEID
WAARSCHUWINGEN MET BETREKKING TOT ELEKTRICITEIT
WAARSCHUWING:
Verwijder het deksel niet, teneinde ELEKTRISCHE schokken te voorkomen. Binnenin
bevinden zich geen onderdelen die door de gebruiker onderhouden kunnen worden.
Dit toestel staat onder GEVAARLIJKE SPANNING en mag alleen worden geopend
door een daartoe opgeleide en bevoegde technicus. Om het gevaar op ELEKTRISCHE
SCHOKKEN te vermijden, moet u het toestel van de stroombron ontkoppelen alvorens
de LAN-kabels te koppelen of ontkoppelen.
: Ventilationsåbninger må ikke blokeres og skal have fri adgang til den
: Installation af produktet skal ske i overensstemmelse med lokal og
: Dit product voldoet aan de volgende eisen.
: Binnenshuis kan dit product radiostoring veroorzaken, in welk
GEVAAR VOOR ELEKTRISCHE SCHOKKEN
Dit is een “KLASSE 1 LED-PRODUKT”
vii
Page 8
Electrical Safety and Installation Requirements
INSTALLATIE
GEVAAR VOOR BLIKSEMINSLAG
GEVAAR:
NIET aan toestellen of KABELS WERKEN bij BLIKSEM.
WAARSCHUWING:
STROOMKABEL TE ONTKOPPELEN.OM HET TOESTEL STROOMLOOS TE MAKEN: de
stroomkabel ontkoppelen.
ELEKTRISCH
Dit toestel past zich automatisch aan elke spanning aan, tussen de op het label
vermelde waarden.
ELEKTRISCHE TOESTELLEN VAN KLASSE 1
DIT TOESTEL MOET GEAARD WORDEN. De stekker moet aangesloten zijn op een juist
geaarde contactdoos. Een onjuist geaarde contactdoos kan de metalen onderdelen
waarmee de gebruiker eventueel in aanraking komt onder gevaarlijke spanning
stellen.
ELEKTRISCHE SNOEREN
Gebruik een elektrisch snoer, maximum 4,5 meter lang, berekend voor ten minste 6
ampåçère, 250 V, uit HAR vervaardigd, met aan het ene uiteinde een gevormd IEC 320
aansluitstuk en aan het andere uiteinde een stekker die goedgekeurd is door het land
waar het toestel gebruikt zal worden.
MONTAGE-INSTRUCTIES
OPGELET
: Deze modellen zijn ontworpen om te werken in HORIZONTALE stand.
VERTICALE MONTAGE mag NIET UITGEVOERD WORDEN, tenzij een daartoe speciaal
ontworpen Allied Telesyn chassis voor verticale montage wordt gebruikt.
OPGELET
: De ventilatiegaten mogen niet worden gesperd en moeten de
omgevingslucht ongehinderd toelaten voor afkoeling.
BEDRIJFSTEMPERATUUR
De omgevingstemperatuur voor dit produkt mag niet meer bedragen dan 50 graden
Celsius.
HET TOESTEL WORDT UITGESCHAKELD DOOR DE
: AUTOMATISCHE AANPASSING VAN DE SPANNING
viii
ALLE LANDEN
elektrische voorschriften.
NORMES
ÉNERGIE IRRADIÉE
Ce matériel a été testé et certifié conforme par la réglementation américaine aux
normes définies pour les appareils de Classe A.
Emission d’interférences radioélectriques EN55022 Classe A
MISE EN GARDE
interférences radioélectriques. Auquel cas, l’utilisateur devra prendre les mesures
adéquates.
Immunité EN50082 - 1
: het toestel installeren overeenkomstig de lokale en nationale
: ce produit est conforme aux normes de suivantes :
: dans un environnement domestique, ce produit peut provoquer des
Page 9
AT-MR840TF Installation Guide
Sécurité électrique EN60950, UL1950, CSA 950
Laser EN60825
SÉCURITÉ
INFORMATION SUR LES RISQUES ÉLECTRIQUES
AVERTISSEMENT :
Pour éviter toute ÉLECTROCUTION, ne pas ôter le revêtement protecteur du matériel.
Ce matériel ne contient aucun élément réparable par l’utilisateur. Il comprend des
TENSIONS DANGEREUSES et ne doit être ouvert que par un technicien dûment
qualifié. Pour éviter tout risque d’ÉLECTROCUTION, débrancher le matériel avant de
connecter ou de déconnecter les câbles LAN.
Ce matériel est un “PRODUIT À DIODE ÉLECTROLUMINESCENTE DE CLASSE 1”
INSTALLATION
DANGER DE FOUDRE
DANGER
: NE PAS MANIER le matériel ou les CÂBLES lors d’activité orageuse.
DANGER D’ÉLECTROCUTION
ATTENTION
COUPER L’ALIMENTATION DU MATÉRIEL, débrancher le cordon.
RÉGLAGE DE TENSION AUTOMATIQUE ÉLECTRIQUE
Ce matériel peut s’ajuster automatiquement sur n’importe quelle tension comprise
dans la plage indiquée sur l’étiquette.
ÉQUIPEMENT DE CLASSE 1 ÉLECTRIQUE
CE MATÉRIEL DOIT ÊTRE MIS A LA TERRE. La prise de courant doit être branchée
dans une prise femelle correctement mise à la terre car des tensions dangereuses
risqueraient d’atteindre les pièces métalliques accessibles à l’utilisateur.
INFORMATION SUR LE CORDON ÉLECTRIQUE
Utiliser un cordon secteur de 4.5 mètres de long maximum, calibré à 6 ampères
minimum, 250V, fabriqué en câblage HAR avec connecteur IEC 32C moulé à une
extrémité, et à l'autre extrémité, une prise de courant mâle répondant aux normes du
pays d'utilisation.
INSTRUCTIONS DE MONTAGE
ATTENTION
matériel NE DOIT PAS être utilisé en MONTAGE VERTICAL, à moins d’utiliser un
châssis de montage vertical Allied Telesyn conçu à cet effet.
ATTENTION
circuler librement pour le refroidissement.
TEMPÉRATURE DE FONCTIONNEMENT
Ce matériel est capable de tolérer une température ambiante maximum de 50 degrés
Celsius.
POUR TOUS PAYS
nationales et locales.
: LE CORDON D’ALIMENTATION SERT DE MISE HORS CIRCUIT. POUR
: Ces modèles sont destinés à fonctionner en position HORIZONTALE. Le
: Ne pas bloquer les fentes d’aération, ceci empêcherait l’air ambiant de
: Installer le matériel conformément aux normes électriques
ix
Page 10
Electrical Safety and Installation Requirements
STANDARDIT
SÄTEILYENERGIA
Tämä kaupallinen tuote on testattu ja noudattaa Yhdysvaltojen vaatimuksia luokan A
laitteelle.
Radioaaltojen häirintä EN55022 Luokka A
VAROITUS
tapauksessa laitteen käyttäjän on mahdollisesti ryhdyttävä tarpeellisiin
toimenpiteisiin.
Kestävyys EN50082-1
Sähköturvallisuus EN60950, UL1950, CSA 950
Laser EN60825
TURVALLISUUS
SÄHKÖÖN LIITTYVIÄ HUOMAUTUKSIA
VAROITUS:
Estääksesi SÄHKÖISKUN älä poista kantta. Sisällä ei ole käyttäjän huollettavissa olevia
osia. Tämä laite sisältää VAARALLISIA JÄNNITTEITÄ ja sen voi avata vain koulutettu
ja pätevä teknikko. Välttääksesi SÄHKÖISKUN mahdollisuuden katkaise sähkövirta
tuotteeseen ennen kuin liität tai irrotat paikallisverkon (LAN) kaapelit.
Tämä on “ENSIMMÄISEN LUOKAN VALODIODITUOTE”
ASENNUS
SALAMANISKUVAARA
HENGENVAARA:
SALAMOINNIN AIKANA.
: Tämä tuote on seuraavien standardien mukainen.
: Kotiolosuhteissa tämä laite voi aiheuttaa radioaaltojen häiröitä, missä
SÄHKÖISKUVAARA
ÄLÄ TYÖSKENTELE laitteiden tai KAAPELEIDEN KANSSA
HUOMAUTUS
KATKAISTAAN irrottamalla virtajohto.
SÄHKÖ—AUTOMAATTINEN JÄNNITTEENSÄÄTÖ
Tämä tuote säätää automaattisesti mihin tahansa jännitteeseen ohjetarrassa
annettujen arvojen välillä.
SÄHKÖ—TYYPPILUOKAN 1 LAITTEET
TÄMÄ LAITE TÄYTYY MAADOITTAA. Pistoke täytyy liittää kunnollisesti maadoitettuun
pistorasiaan. Virheellisesti johdotettu pistorasia voi altistaa metalliosat vaarallisille
jännitteille.
SÄHKÖ —JOHTOON LIITTYVÄ HUOMAUTUS
Käytä seuraavanlaista virtajohtoa: maksimipituus 4,5 metriä, minimiteho 6 ampeeria,
250 V, valmistettu HAR-johdostosta, muovattu IEC 320 -liitin toisessa päässä ja
käyttömaassa hyväksytty pistoke toisessa päässä.
x
: VIRTAJOHTOA KÄYTETÄÄN VIRRANKATKAISULAITTEENA. VIRTA
Page 11
AT-MR840TF Installation Guide
ASENNUSSOHJEET
HUOMAUTUS
PYSTYASENNUSTA EI SAA TEHDÄ ilman Allied Telesyn -pystykiinnitysalustaa, joka
on suunniteltu tähän tarkoitukseen.
: Nämä mallit on suunniteltu käytettäviksi VAAKA-asennossa.
HUOMAUTUS
ympäröivään huoneilmaan, jotta ilmanvaihto tapahtuisi.
KÄYTTÖLÄMPÖTILA
Tämä tuote on suunniteltu ympäröivän ilman maksimilämpötilalle 50°C.
KAIKKI MAAT
mukaisesti.
STANDARD
ENERGIA IRRADIATA
Questo prodotto commerciale è stato collaudato e risponde ai requisiti U.S.A. per i
dispositivi di classe A.
Emissione RFI (interferenza di radiofrequenza) EN55022 Classe A
AVVERTENZA
interferenza. In questo caso potrebbe richiedersi all’utente di prendere gli adeguati
provvedimenti.
Immunità EN50082-1
Sicurezza elettrica EN60950, UL1950, CSA 950
Laser EN60825
NORME DI SICUREZZA
AVVERTENZE ELETTRICHE
ATTENZIONE:
Per evitare SCOSSE ELETTRICHE non asportare il coperchio. Le componenti interne
non sono riparabili dall’utente. Questa unità ha TENSIONI PERICOLOSE e va aperta
solamente da un tecnico specializzato e qualificato. Per evitare ogni possibilità di
SCOSSE ELETTRICHE, interrompere l’alimentazione del dispositivo prima di collegare
o staccare i cavi LAN.
: Ilmavaihtoreikiä ei pidä tukkia ja niillä täytyy olla vapaa yhteys
: Asenna tuote paikallisten ja kansallisten sähköturvallisuusmääräysten
: Questo prodotto è conforme ai seguenti standard.
: in ambiente domestico questo prodotto potrebbe causare radio
PERICOLO DI SCOSSE ELETTRICHE
Questo è un “PRODOTTO CON LED DI CLASSE 1”
INSTALLAZIONE
PERICOLO DI FULMINI
PERICOLO
TEMPORALESCHE.
ATTENZIONE
DISATTIVAZIONE. PER TOGLIERE LA CORRENTE AL DISPOSITIVO staccare il cavo di
alimentazione.
: NON LAVORARE sul dispositivo o sui CAVI durante PRECIPITAZIONI
: IL CAVO DI ALIMENTAZIONE È USATO COME DISPOSITIVO DI
xi
Page 12
Electrical Safety and Installation Requirements
ELETTRICITÀ—REGOLAZIONE AUTOMATICA DELLA TENSIONE
Questo prodotto regolerà automaticamente la tensione ad un valore compreso nella
gamma indicata sull’etichetta.
ELETTRICITÀ—DISPOSITIVI DI CLASSE 1
QUESTO DISPOSITIVO DEVE AVERE LA MESSA A TERRA. La spina deve essere
inserita in una presa di corrente specificamente dotata di messa a terra. Una presa
non cablata in maniera corretta rischia di scaricare una tensione pericolosa su parti
metalliche accessibili.
ELETTRICITÀ—AVVERTENZA SUL CAVO
Usare un cavo della lunghezza massima di metri 4,5, con capacità minima di 6 A, 250
V, di filo HAR, dotato di connettore stampato IEC 320 ad un'estremità e di spina
approvata dal paese di destinazione all'altra.
ISTRUZIONI PER IL MONTAGGIO
ATTENZIONE
ORIZZONTALE. NON È POSSIBILE EFFETTUARE IL MONTAGGIO VERTICALE senza
utilizzare l’apposito telaio per il montaggio verticale Allied Telesyn.
: questi modelli sono concepiti per il funzionamento in posizione
ATTENZIONE
dell’aria ambiente per il raffreddamento.
TEMPERATURA DI FUNZIONAMENTO
Questo prodotto è concepito per una temperatura ambientale massima di 50 gradi
centigradi.
TUTTI I PAESI
nazionali.
SIKKERHETSNORMER
UTSTRÅLT ENERGI
Dette kommersielle produktet er blitt testet og funnet å være i samsvar med
amerikanske krav for et klasse A-apparat.
RFI stråling EN55022 Klasse A
ADVARSEL
radioforstyrrelse. Hvis dette skjer, må brukeren ta de nødvendige forholdsregler.
Immunitet EN50082-1
Elektrisk sikkerhet EN60950, UL1950, CSA 950
Laser EN60825
SIKKERHET
ELEKTRISITET
ADVARSEL:
For å unngå ELEKTRISK sjokk, må dekslet ikke tas av. Det finnes ingen deler som
: le prese d’aria non vanno ostruite e devono consentire il libero ricircolo
: installare il prodotto in conformità delle vigenti normative elettriche
: Dette produktet tilfredsstiller følgende sikkerhetsnormer.
: Hvis dette produktet benyttes til privat bruk, kan produktet forårsake
FARE FOR ELEKTRISK SJOKK
xii
Page 13
AT-MR840TF Installation Guide
brukeren kan reparere på innsiden. Denne enheten inneholder FARLIGE
SPENNINGER, og må kun åpnes av en faglig kvalifisert tekniker. For å unngå
ELEKTRISK SJOKK må den elektriske strømmen til produktet være avslått før LANkablene til- eller frakobles.
Dette er et “KLASSE 1 LED PRODUKT”
INSTALLASJON
FARE FOR LYNNEDSLAG
FARE
: ARBEID IKKE på utstyr eller KABLER i TORDENVÆR.
FORSIKTIG
DEAKTIVISERE UTSTYRET, må strømforsyningen kobles fra.
ELEKTRISK—AUTO SPENNINGSTILPASNING
Dette produktet vil automatisk bli tilpasset hvilken som helst strømspenning i de
områdene som vises på etiketten.
ELEKTRISK—TYPE 1- KLASSE UTSTYR
DETTE UTSTYRET MÅ JORDES. Strømkontakten må være tilkoplet en korrekt jordet
kontakt. En kontakt som ikke er korrekt jordet kan føre til farlig spenninger i lett t
ilgjengelige metalldeler.
ELEKTRISK — MEDDELELSE OM LEDNINGER
Bruk en strømledning av maksimalt 4.5 m. i lengde, godkjent for minst av 6 amp,
250V, fremstilt av HAR ledning IEC 320 koplingsstykke i den ene enden, og i den andre
enden en plugg som er blitt godkjent i brukerlandet.
BRUKSANVISNING FOR MONTERING
FORSIKTIG
MONTERING må IKKE UTFØRES uten bruk av et Allied Telesyn vertikal
monteringschassis som er spesiallaget til dette formål.
FORSIKTIG
romtemperatur for avkjøling.
DRIFTSTEMPERATUR
Dette produktet er konstruert for bruk i maksimum romtemperatur på 50 grader
celsius.
ALLE LAND:
koder.
: STRØMLEDNINGEN BRUKES TIL Å FRAKOBLE UTSTYRET. FOR Å
: Disse modellene er beregnet til bruk i HORISONTAL stilling. l VERTIKAL
: Lufteventilene må ikke blokkeres, og må ha fri tilgang til luft med
Produktet må installeres i samsvar med de lokale og nasjonale elektriske
xiii
Page 14
Electrical Safety and Installation Requirements
PADRÕES
ENERGIA IRRADIADA
Este produto foi testado e atende aos requisitos para dispositivos comerciais de
Classe A dos E.U.A.
Emissão de interferência de radiofrequência EN55022 Classe A
AVISO
radiorrecepção e, neste caso, pode ser necessário que o utente tome as medidas
adequadas.
Imunidade EN50082-1
Segurança Eléctrica EN60950, UL1950, CSA 950
Laser EN60825
SEGURANÇA
AVISOS SOBRE CARACTERÍSTICAS ELÉTRICAS
ATENÇÃO:
Para evitar CHOQUE ELÉTRICO, não retire a tampa. Não contém peças que possam
ser consertadas pelo usuário. Este aparelho contém VOLTAGENS PERIGOSAS e só
deve ser aberto por um técnico qualificado e treinado. Para evitar a possibilidade de
CHOQUE ELÉTRICO, desconecte o aparelho da fonte de energia elétrica antes de
conectar e desconectar os cabos da LAN.
Este é um “PRODUTO CLASSE 1 LED”
INSTALAÇÃO
PERIGO DE CHOQUE CAUSADO POR RAIO
PERIGO
suscetíveis a QUEDAS DE RAIO.
: Este produto atende aos seguintes padrões.
: Num ambiente doméstico este produto pode causar interferência na
PERIGO DE CHOQUE ELÉTRICO
: NÃO TRABALHE no equipamento ou nos CABOS durante períodos
xiv
CUIDADO
DESCONEXÃO. PARA DESELETRIFICAR O EQUIPAMENTO, desconecte o cabo de
ALIMENTAÇÃO.
ELÉTRICO—AJUSTE AUTOMÁTICO DE VOLTAGEM
Este produto ajustar-se-á automaticamente a qualquer voltagem que esteja dentro
dos limites indicados no rótulo.
ELÉTRICO—EQUIPAMENTOS DO TIPO CLASSE 1
DEVE SER FEITA LIGAÇÃO DE FIO TERRA PARA ESTE EQUIPAMENTO. O plugue de
alimentação deve ser conectado a uma tomada com adequada ligação de fio terra.
Tomadas sem adequada ligação de fio terra podem transmitir voltagens perigosas a
peças metálicas expostas.
ELÉTRICO—AVISO SOBRE O CABO DE ALIMENTAÇÃO
Use cabo de alimentação com comprimento máximo de 4,5 metros, com uma
capacidade indicada mínima de 6 amp e 250 V, fabricado de material para cabo HAR
com conector moldado IEC 320 em uma extremidade e, na outra extremidade, um
plugue aprovado para uso no país em questão.
: O CABO DE ALIMENTAÇÃO É UTILIZADO COMO UM DISPOSITIVO DE
Page 15
AT-MR840TF Installation Guide
INSTRUÇÕES DE INSTALAÇÃO
CUIDADO
NÃO DEVE SER EFETUADA INSTALAÇÃO VERTICAL sem o uso de um chassis de
montagem vertical Allied Telesyn projetado para este fim específico.
: Estes modelos foram projetados para funcionar na posição HORIZONTAL.
CUIDADO
livre ao ar ambiente para arrefecimento adequado do aparelho.
TEMPERATURA DE FUNCIONAMENTO
Este produto foi projetado para uma temperatura ambiente máxima de 50 graus
centígrados.
TODOS OS PAÍSES
para instalações elétricas.
ESTÁNDARES
ENERGIA RADIADA
Este producto comercial ha sido probado y cumple con las normas requeridas en los
EE. UU. para un dispositivo de Clase A.
Emisión RFI EN55022 Clase A
ADVERTENCIA
radiointerferencias, en cuyo caso, puede requerirse del usuario que tome las medidas
que sean convenientes al respecto.
Inmunidad EN50082-1
Seguridad eléctrica EN60950, UL1950, CSA 950
Laser EN60825
SEGURIDAD
AVISOS ELECTRICOS
ADVERTENCIA:
Para evitar un ELECTROCHOQUE, no quite la tapa. No hay ningún componente en el
interior al cual puede prestar servicio el usuario. Esta unidad contiene VOLTAJES
PELIGROSOS y sólo deberá abrirla un técnico entrenado y calificado. Para evitar la
posibilidad de ELECTROCHOQUE desconecte la corriente eléctrica que llega al
producto antes de conectar o desconectar los cables LAN.
: As aberturas de ventilação não devem ser bloqueadas e devem ter acesso
: Instale o produto de acordo com as normas nacionais e locais
: Este producto cumple con los siguientes estándares.
: en un entorno doméstico, este producto puede causar
PELIGRO DE ELECTROCHOQUE
Este es un “PRODUCTO DE DIODO LUMINISCENTE (LED) CLASE 1”
INSTALACION
PELIGRO DE RAYOS
PELIGRO
: NO REALICE NINGUN TIPO DE TRABAJO O CONEXION en los equipos o en
LOS CABLES durante TORMENTAS ELECTRICAS.
ATENCION
DESCONEXION. PARA DESACTIVAR EL EQUIPO, desconecte el cable de
alimentación.
: EL CABLE DE ALIMENTACION SE USA COMO UN DISPOSITIVO DE
xv
Page 16
Electrical Safety and Installation Requirements
ELECTRICO—AUTO-AJUSTE DE TENSION
Este producto se ajustará automáticamente a cualquier tensión entre los valores
máximos y mínimos indicados en la etiqueta.
ELECTRICO—EQUIPO DEL TIPO CLASE 1
ESTE EQUIPO TIENE QUE TENER CONEXION A TIERRA. El cable tiene que conectarse
a un enchufe a tierra debidamente instalado. Un enchufe que no está correctamente
instalado podría ocasionar tensiones peligrosas en las partes metálicas que están
expuestas.
ELECTRICO—ADVERTENCIA SOBRE EL CABLE
Use un cable eléctrico con un máximo de 4,5 metros de largo, con una capacidad
mínima de 6 amperios, 250 V, hecho de cable HAR, con el conector moldeado IEC
320 en un extremo y con un enchufe que está aprobado por el país de uso final en el
otro.
INSTRUCCIONES DE MONTAJE
ATENCION: Estos modelos están diseñados para operar en posición HORIZONTAL.
NO SE DEBEN MONTAR VERTICALMENTE sin el uso de un chasis de montaje vertical
de Allied Telesyn que se ha diseñado para este fin.
ATENCION: Las aberturas para ventilación no deberán bloquearse y deberán tener
acceso libre al aire ambiental de la sala para su enfriamiento.
TEMPERATURA REQUERIDA PARA LA OPERACIÓN
Este producto está diseñado para una temperatura ambiental máxima de 50 grados C.
PARA TODOS LOS PAÍSES: Monte el producto de acuerdo con los Códigos Eléctricos
locales y nacionales.
xvi
STANDARDER: Denna produkt uppfyller följande standarder.
ENERGIUTSTRÅLNING
Denna handelsprodukt har testats och befunnits vara i enlighet med USA:s krav för
klass A utrustning.
Radiostörning EN55022 Klass A
VARNING: Denna produkt kan ge upphov till radiostörningar i hemmet, vilket kan
tvinga användaren till att vidtaga erforderliga åtgärder.
Immunitet EN50082-1
Elsäkerhet EN60950, UL1950, CSA 950
Laser EN60825
SÄKERHET
TILLKÄNNAGIVANDEN BETRÄFFANDE ELEKTRICITETSRISK:
RISK FÖR ELEKTRISK STÖTFör att undvika ELEKTRISK stöt, ta ej av locket. Det finns
inga delar inuti som behöver underhållas. Denna apparat är under HÖGSPÄNNING
och får endast öppnas av en utbildad kvalificerad tekniker. För att undvika
ELEKTRISK STÖT, koppla ifrån produktens strömanslutning innan LAN-kablarna
ansluts eller kopplas ur.
Page 17
AT-MR840TF Installation Guide
Detta är en “KLASS 1 LYSDIODPRODUKT”
INSTALLATION
FARA FÖR BLIXTNEDSLAG
FARA: ARBETA EJ på utrustningen eller kablarna vid ÅSKVÄDER.
VARNING: NÄTKABELN ANVÄNDS SOM STRÖMBRYTARE FÖR ATT KOPPLA FRÅN
STRÖMMEN, dra ur nätkabeln.
ELEKTRISKT—AUTOMATISK SPÄNNINGSJUSTERING
Denna produkt justeras automatiskt till alla spänningar inom omfånget som indikeras
på produktens märkning.
ELEKTRISKT—TYP KLASS 1 UTRUSTNING
DENNA UTRUSTNING MÅSTE VARA JORDAD. Nätkabeln måste vara ansluten till ett
ordentligt jordat uttag. Ett felaktigt uttag kan göra att närliggande metalldelar utsätts
för högspänning. Apparaten skall anslutas till jordat uttag, när den ansluts till ett
nätverk.
ELEKTRISKT—ANMÄRKNING BETRÄFFANDE KABELN
Använd en kabel med maximum längd 4,5 meter och minimum 6 amp nominal, 250V,
av HAR kabelfabrikat med ett specialutformat IEC 320-kontaktdon i ena änden och i
den andra en plugg som godkänts i landet där produkten används.
MONTERINGSINSTRUKTIONER
VARNING: Dessa modeller är konstruerade för användning i HORISONTALLÄGE.
VERTIKALMONTERING får EJ UTFÖRAS utan att ett Allied Telesyn specialkonstruerat
vertikalt monteringschassi används.
VARNING: Luftventilerna får ej blockeras och måste ha fri tillgång till omgivande
rumsluft för avsvalning.
DRIFTSTEMPERATUR
Denna produkt är konstruerad för rumstemperatur ej överstigande 50 grader Celsius.
ALLA LÄNDER: Installera produkten i enlighet med lokala och statliga bestämmelser
för elektrisk utrustning.
xvii
Page 18
Page 19
Table of Contents
Electrical Safety and Installation Requirements ..................................iii
Chapter 1
Product Description .......................................................................................1
Overview..............................................................................................................1
Major Features ....................................................................................................2
Functional Description........................................................................................3
Packet Regeneration....................................................................................3
Link Integrity...............................................................................................3
Autopartitioning...........................................................................................3
Jabber Lock-up Protection...........................................................................4
Fragment Extension.....................................................................................4
Jam Signal....................................................................................................4
Functional Block Diagram...........................................................................4
Physical Description............................................................................................5
LEDs .............................................................................................................5
UTP, Cascade, and Uplink Ports.................................................................8
MDI/MDI-X Switch ......................................................................................9
Power Requirements for Model Types ......................................................10
Chapter 2
Installation .....................................................................................................11
Before You Begin...............................................................................................11
Power Requirements.........................................................................................11
Installing the Hub.............................................................................................11
Making UTP Port Connections..................................................................11
Making 10Base-FL Uplink Port Connections...........................................12
Making Cascading Connections ................................................................12
Verifying Installation.................................................................................13
Verifying Collision LED.............................................................................14
xix
Page 20
Table of Contents
Chapter 3
Configurations .............................................................................................. 15
Standalone Configuration................................................................................ 15
Fiber Optic Backbone Network Configuration................................................ 16
Cascade Configuration ..................................................................................... 17
The Four-Repeater Rule............................................................................ 18
Appendix A
Technical Specifications ............................................................................ 19
The AT-MR840TF Specifications.....................................................................19
Physical...................................................................................................... 19
Electrical Rating........................................................................................ 19
Environmental...........................................................................................19
Certification............................................................................................... 20
Connector Pinouts for UTP and Uplink Port...........................................20
Straight-through Cable Wiring........................................................................ 21
Crossover Cable Wiring.................................................................................... 21
10Base-T/10Base-FL Network Specifications................................................. 22
Appendix B
Technical Support Fax Order ................................................................... 23
Appendix C
AT-MR840TF Installation Guide Feedback ............................................25
Appendix D
Where To Find Us ......................................................................................... 27
xx
Page 21
Chapter 1
Product Description
Overview
The AT-MR840TF is a 10Base-T /10Base-FL standalone, unmanaged hub that
has eight UTP (RJ45) ports and one fiber optics port. There are two types of
fiber optic ports that accommodate an uplink connection to the backbone. The
ST version accommodates a fiber ST cable whereas the SC version
accommodates an SC cable. The SC/ST uplink port provides a means for media
conversion and increased distance.
In addition to uplink capabilities, the hubs can be cascaded using one of the
eight RJ45 ports or the fiber ST/SC port to connect to other hubs to increase the
segment size. Up to four hubs can be interconnected per IEEE 802.3 standards.
The AT-MR840TF hubs support full-length cable segments with the maximum
number of supported devices allowed within IEEE 802.3 standards. The hub is
equipped with an internal universal AC power supply and can be desk or wallmounted. For wall-mounting instructions and materials, refer to AT-BRKT17.
IEEE 802.3 10BASE-T / 10BASE-FL
MULTIPORT MICRO HUB/REPEATER
NETWORK LOAD
124816326484+%
LINK OK
RECEIVE
10BASE-T NETWORK PORTS
Figure 1: AT-MR840TF (ST/SC) Front Panel
87654321
ACTIVITY COLLISION POWER
87654321
HUB STATUS
1
Page 22
Product Description
10BASE-T NETWORK PORTS
8765 4321
MDI MDI-X
1
1
1
1
2
2
2
2
3
3
3
3
6
MDI MDI-X
1
2
3
6
6
1
2
3
6
XXX XXXX
6
6
10BASE-T NETWORK PORTS
8765 4321
1
1
2
2
3
3
XXX XXXX
6
6
10BASE-FL BACKBONE PORT
RX
TXRX
10BASE-FL BACKBONE PORT
RX
TXRX
TX LINK
TX LINK
POWER
POWER
Figure 2: AT-MR840TF (ST/SC) Back Panels
Major Features
The major features of the AT-MR840TF include the following:
❑ 10Base-T/10Base-FL support
❑ Cascading capability via MDI/MDI-X switch
❑ 10Base-FL Uplink via ST/SC connectors for media conversion and
distance
❑ Hub and port status LEDs
❑ Network utilization LEDs
❑ Auto partitioning
❑ Packet regeneration and retiming
❑ Collision detection/correction and reconnection
❑ Jabber lock-up protection
❑ IEEE 802.3 compliant and 10Base-T and Ethernet Version 1.0 and 2.0
compatible
❑ Link integrity test
2
Page 23
AT-MR820TR Hub Installation Guide
Functional Description
The AT-MR840TF hub incorporates the latest technologies, including a custom
Application Specific Integrated Circuit (ASIC) and Surface Mount Technology
(SMT). Employing state-of-the-art technologies results in enhanced
functionality, increased reliability, and improved performance and as detailed
in the following list of features:
Packet Regeneration
Packet regeneration is a high-performance network feature that includes the
regenerating of the packet preamble, retiming of data packets, and the
extension of collision fragments. When transmitting a packet, the hub ensures
that the outgoing packet complies with IEE 802.3 specification in terms of
preamble structure, signal amplitude, and timing characteristics. Data packets
repeated will contain a minimum of 56 preamble bits before start-of-frame
delimiter. In addition, the hub restores signal symmetry to the repeated data
packets, removing jitter and distortion caused by the network cabling.
Link Integrity
The IEEE 802.3 defined link integrity test function continually monitors the
twisted pair cable to ensure link continuity of the receive pair between the user
node and the hub.
Autopartitioning
Also known as segmentation, each segment will be automatically partitioned
whenever 32 consecutive collisions occur on the segment. One valid packet will
reset the segment and return it to the auto reconnecting segment. Any of the
twisted pair ports can be partitioned if the frequency of collisions becomes
excessive. The enabled network port is partitioned if one of the following
conditions occurs on that port:
❑ A collision condition exists continuously for more than 2048 bit times
❑ A collision condition occurs during each of the 32 consecutive attempts
to transmit to that port.
When there is no more collisions in the partitioned port and activity of 512 bit
times or more is detected, the partition is released and the port is reconnected.
3
Page 24
Product Description
Jabber Lock-up Protection
Jabber lock-up protects the hub from being overrun with excessively long data
packets by isolating segments that contain these oversized packets (exceed
maximum packet length). Therefore, jabber lock-up automatically prevents
data which exceeds the allowed duration (usually 5 ms) from reaching the hub,
or if the hub has been continuously transmitting for more than 65,536 bit times.
This protection scheme automatically interrupts transmission for 96 bit times.
Fragment Extension
If the total packet length received is less than 96 bits, including preamble, the
packet length is expanded to 96 bits by appending a jam sequence to the
original fragment.
Jam Signal
If one port detects a carrier, the hub repeats all received data form this port to
another port. If a collision is detected while sending data to a port, the hub
sends the jam signal to all connected ports. If the collision status continues on
only one port even after 96 bits of jam signal have been sent, the jam signal is
sent to ports in the non-collision status.
Functional Block Diagram
Figure 3 shows the relationship between the major components of the
AT-MR840TF hub; Table 1 lists and identifies these components.
(1) (1)
(2) (2)
87
4
(2) (2)
65
4
10Base-T (RJ45)
Figure 3: AT-MR840TF Functional Block Diagram
21
3
(3)
RX
(4)
10Base-FL (ST/SC)
TX
(4)
Page 25
AT-MR820TR Hub Installation Guide
Table 1: AT-MR840TF Major Components
Component # Component Name
1 Ethernet Controller
2 Transceiver/Phy Interface
3 Ethernet MAU
4 Fiber Optic Transceiver
Physical Description
The hub’s major components include the following:
❑ LEDs (port, hub, network)
❑ Eight Unshielded/Shielded Twisted Pair (UTP/STP) RJ45 ports
❑ One fiber uplink port (ST or SC)
❑ MDI/MDI-X switch
❑ AC power connector
LEDs
There are two network port LEDs for each port of the eight 10Base-T (RJ45)
ports: LINK OK and RECEIVE. These LEDs indicate whether the port is
linked, receiving data, or both. In general, port status LEDs show the
functionality of the port.
If the LINK OK LED lights green and the RECEIVE LED is flashing amber, a
signal is being received and the segment attached to the port is functional.
5
Page 26
Product Description
Table 2 lists and defines the ports, hub, and network status LEDs.
Table 2: Port and Hub Status LEDs
LED Color Description
LINK OK (port) green ON indicates that a valid link exists.
No light indicates that the link is not OK. If the
polarity is incorrect, the LINK OK light will be OFF
until polarity is corrected by the multiport hub’s UTP
port.
RECEIVE (port) amber FLASHING indicates that there is activity (packet
transmission) on the port, that the Link is OK, that
the port is not partitioned. Brief flashes indicate low
traffic levels.
LINK (uplink
green ON indicates that a valid link exists.
port)
TX (uplink port) green ON indicates that the port is transmitting packets.
RX (uplink port) green ON indicates that the port is receiving packets.
ACTIVITY (hub) amber FLASHING indicates that the hub is transmitting
packets.
COLLISION
(hub)
amber FLASHING indicates that packet collisions are
occurring on the hub.
POWER (hub) green ON indicates that the hub is receiving power.
NETWORK
LOAD
amber FLASHING indicates the percentage of network
utilization from 1%, 2%, 4%, 8%, 16%, 32%, 64%
to 80+%.
For detailed information concerning the Collision LED, see “Verifying Collision
LED” on page 14.
6
Page 27
AT-MR820TR Hub Installation Guide
321
321
LINK OK
RECEIVE
10BASE-T NE
ACTIVITY COLLISION POWER
HUB STATUS
NETWORK LOAD
124816326484+%
IEEE 802.3 10BASE-T / 10BASE-FL
MULTIPORT MICRO HUB/REPEATER
IEEE 802.3 10BASE-T / 10BASE-FL
MULTIPORT MICRO HUB/REPEATER
NETWORK LOAD
124816326484+%
NETWORK LOAD
124816326484+%
10BASE-T NETWORK PORTS
LINK OK
RECEIVE
10BASE-T NETWORK PORTS
LINK OK
RECEIVE
IEEE 802.3 10BASE-T / 10BASE-FL
MULTIPORT MICRO HUB/REPEATER
87654321
87654321
87654321
87654321
HUB STATUS
ACTIVITY COLLISION POWER
HUB STATUS
ACTIVITY COLLISION POWER
Figure 4: Port, Hub, and Network LEDs
NETWORK LOAD
124816326484+%
10BASE-T NETWORK PORTS
LINK OK
RECEIVE
87654321
87654321
HUB STATUS
ACTIVITY COLLISION POWER
7
Page 28
Product Description
10BASE-FL BACKBONE PORT
RX
TXRX
TX LINK
10BASE-FL BACKBONE PORT
RX
TXRX
TX LINK
UTP, Cascade, and Uplink Ports
While the eight UTP ports can be used to directly connect to workstations in a
standalone configuration, Port 8 is equipped with an MDI/MDI-X switch that
conveniently provides the connection (cascade) to other hubs.
In addition, the 10Base-FL(ST/SC) port provides the uplink connection to a
fiber backbone network. See Figure 5. Also, see Chapter 3 “Configurations” for
standalone, cascade and uplink configurations.
10BASE-T NETWORK PORTS
8765 4321
MDI MDI-X
1
1
1
1
2
2
2
2
3
3
3
3
XXX XXXX
6
6
6
6
10BASE-T NETWORK PORTS
8765 4321
MDI MDI-X
1
1
1
1
2
2
2
2
3
3
3
3
XXX XXXX
6
6
6
6
10BASE-FL BACKBONE PORT
RX
TX LINK
TXRX
10BASE-FL BACKBONE PORT
RX
TXRX
TX LINK
POWER
POWER
Figure 5: ST/SC Fiber Connectors
8
Page 29
AT-MR820TR Hub Installation Guide
1
2
3
6
1
2
3
6
1
2
3
6
1
2
3
6
MDI MDI-X
MDI/MDI-X Switch
The Media Dependent Interface/Media Dependent Interface Crossover (MDI/
MDI-X) switch is a slide switch that allows you to connect to either another hub
or to a workstation by converting Port 8 to an uplinkable port; thereby allowing
one hub to connect to another hub without requiring special crossover cables.
Figure 6 illustrates this switch; Table 3 defines the switch’s function.
10BASE-T NETWORK PORTS
8765 4321
MDI MDI-X
1
1
1
1
2
2
2
2
3
3
3
3
XXX XXXX
6
6
6
6
10BASE-FL BACKBONE PORT
RX
TXRX
TX LINK
POWER
Figure 6: MDI/MDI-X Slide Switch
Table 3: MDI/MDI-X Switch
MDI /MDI-X
Position
Function
MDI When in the MDI position (left), the port can be connected to
another hub using straight through twisted pair cabling. The MDI
position is a hub pinout which automatically swaps the TX and
RX pinouts so that they do not conflict with the TX and RX ports
at the other end of a straight-through cable.
MDI-X When in the MDI-X position (right), the port can be connected to
a workstation, node, or any other DTE (default).
9
Page 30
Product Description
Power Requirements for Model Types
Table 4 lists the power requirements for the AT-MR840TF models.
Table 4: Power Requirements for AT-MR840TF Models
Fiber
Part No. Power Power Cord
AT-MR840TF-13 100V-120V North America ST Unshielded
At-MR840TF-12 100V-120V North America SC Unshielded
AT-MR840TF-23A 200V -240V Not available ST Shielded
AT-MR840TF-22A 200V-240V Not available SC Shielded
Connector
Type
RJ45
10
Page 31
Chapter 2
Installation
Before You Begin
Before proceeding with the installation, please read “Electrical Safety and
Installation Requirements” on page iii through xviii
Note
Installation of this product should only be performed by TRAINED
SERVICE PERSONNEL.
Power Requirements
Be sure that the voltage and frequency is either 100-120 or 200-240 VAC and
50 or 60 Hz. Since there is no external power switch, power is applied when the
power cord is connected.
.
Installing the Hub
Making UTP Port Connections
1. Carefully remove the AT-MR840TF hub from its packaging box. Keep the
packing materials for future use.
2. Position the hub in a location with adequate ventilation and a power
source.
3. Attach an AC cord to the hub and make sure that the POWER LED on the
front panel lights.
4. On the hub side, attach your 10Base-T UTP cables (RJ45 connectors) to the
10Base-T ports.
5. On the workstation side, attach the other end of the UTP cable to the
10Base-T network adapter card on the workstation.
11
Page 32
Installation
Note
If you are not using the UPLINK port (Port 8) for cascading to
another hub, you may connect a standard 10Base-T cable to Port 8.
Set the MDI/MDI-X switch to the MDI-X position.
6. Make sure that the LINK OK LEDs light green. If the LINK OK LEDs do
not light, check that the adapter card on the opposite end of the UTP
segment is operational.
Making 10Base-FL Uplink Port Connections
To make a fiber uplink connection to the network/backbone:
1. Connect the 10Base-FL cables (either SC or ST) to their respective fiber
connectors.
2. Make sure that the LINK LED for the fiber uplink port lights green.
Making Cascading Connections
To cascade (connect from one hub to another):
1. From the first hub, connect Port 8 to any of the available UTP ports on the
second hub. Continue this scheme for any additional hubs, always first
going from Port 8 to an unused UTP port.
2. Make sure the MDI/MDI-X switch for Port 8 is set to the MDI position if
you select Ports 1-7 of the second hub.
3. If you cascade two hubs using Port 8, make sure you set the MDI/MDI-X
switch to the MDI-X position on only one of the hubs.
Note
Any two ports can be used to cascade hubs as long as one side is set to
the MDI position while the other side is set to the MDI-X position
using straight-through cable. However, Allied Telesyn recommends
that you use the dedicated MDI/MDI-X port (Port 8) to connect to
available UTP ports (1-7) when cascading hubs.
12
Page 33
AT-MR840TF Hub Installation Guide
Table 5 lists the MDI/MDI-X switch positions when using straight-through and
crossover cable.
Table 5: MDI/MDI-X Switch Position Rules
Position Required Cable
MDI to MDI-X straight through
MDI-X to MDI straight through
MDI to MDI crossover
MDI-X to MDI-X crossover
Verifying Installation
1. Make sure that the LINK OK LED of the first connected 10Base-T port is
lit. A steady green LED indicates continuity.
2. After a successful connection, disconnect the active 10Base-T connector
and connect it to the next successive port. Continue this process until all
10Base-T ports have been validated with good network connections.
3. Establish a connection from a device connected to Port 1 to a device
connected to Port 2.
4. Once the connection between devices attached to Ports 1 and 2 has been
successfully established, remove the RJ45 connector from Port 2 and
connect it to each of the subsequent hub’s 10Base-T ports, 3 through 8, to
verify their functions.
5. If all ports test successfully, install the rest of the 10Base-T RJ45
connections and make sure that the LINK LED for each port lights.
Remember, the 10Base-T device on the opposite end of the UTP cable must
be operational.
Note
The LINK OK LED validates the receive pair only. The opposite end
of the UTP segment is responsible for validating the transmit pair.
13
Page 34
Installation
If the LINK OK LED does not light, there is no signal continuity.
1. Check that the attached Data Terminal Equipment (DTE) is ON.
2. Check that the Link signal has not been disabled at the other network
device.
If these checks do not identify the problem, it may indicate that the hub or
device connected to the port is faulty.
Verifying Collision LED
The COLLISION LED will blink when an SQE or collision occurs. Occasional
collisions are normal in Ethernet networks. A COLLISION LED that remains
on may indicate that a specific port is experiencing excessive traffic problems.
Continuous blinking of the COLLISION LED may also indicate excessive frame
collisions on a segment. This may be caused by an overloaded segment, a faulty
cable or connection.
14
Page 35
Chapter 3
Configurations
This chapter presents and illustrates the different types of configurations
supported by this hub.
❑ Standalone
❑ Fiber uplink to the backbone
❑ Cascade
Standalone Configuration
Figure 7 shows a standalone hub supporting eight workstations.
100 Meters
TP Cable
wired Pin to Pin
10BASE-T NETWORK PORTS
10BASE-FL BACKBONE PORT
RX
TXRX
TX LINK
Workstations (DTEs)
Figure 7: AT-MR840TF Standalone Configuration
15
Page 36
Configurations
Fiber Optic Backbone Network Configuration
The most straightforward configuration is a hub attached to a fiber optic
(10Base-FL) backbone network. Figure 8 shows a backbone network
configuration using the fiber uplink connector attached to a coaxial Ethernet
cable via a fiber optic transceiver.
Coaxial Ethernet
100 Meters
TP Cable
wired Pin to Pin
10BASE-T NETWORK PORTS
10BASE-FL BACKBONE PORT
RX
TXRX
TX LINK
Fiber optic
Transceiver
Workstations (DTEs)
Figure 8: AT-MR840TF Fiber Backbone Configuration
Overall, in a backbone network configuration, each workgroup has its own local
network and the backbone is used to link the various workgroups through one
or several hubs. The advantages of a backbone network are twofold:
❑ As long as the backbone network is operating correctly, any problem
within a sub-network does not affect other sub-networks.
❑ Since faults are isolated to a single sub-network, they are easier to
locate.
The IEEE 10Base-FL standard extends a fiber segment length to 2 km. This
applies only to configurations in which one 10Base-FL node connects to another
10Base-FL node.
16
Page 37
AT-MR840TF Installation Guide
Cascade Configuration
Port 8, used in conjunction with the MDI/MDI-X switch, is the specified port
that allows you to connect one hub to another (cascade) or to connect to the
backbone using the same medium type. To cascade hubs, you should connect
Port 8 of the first hub to Ports 1-7 of the second hub and continue this scheme
for any additional hubs. The MDI/MDI-X switch for Port 8 of the first hub must
be set to the MDI position.
Figure 9 shows a cascaded topology using four hubs. Its design complies with
the four-repeater rule discussed in the next paragraph.
MDI
TP Link Segment
(Port 8 to Port 7)
MDI-X
TP Link Segment
(Port 8 to Port 7)
MDI-X
TP Link Segment
(Port 8 to Port 7)
MDI-X
10BASE-T NETWORK PORTS
10BASE-T NETWORK PORTS
10BASE-T NETWORK PORTS
10BASE-T NETWORK PORTS
10BASE-FL BACKBONE PORT
TX LINK
RX
TXRX
7 workstations (DTEs)
10BASE-FL BACKBONE PORT
TX LINK
RX
TXRX
6 workstations (DTEs)
10BASE-FL BACKBONE PORT
TX LINK
RX
TXRX
6 workstations (DTEs)
10BASE-FL BACKBONE PORT
TX LINK
RX
TXRX
7 workstations (DTEs)
Figure 9: Port 8 Cascading Hubs
17
Page 38
Configurations
The Four-Repeater Rule
The IEEE 802.3 standard provides general rules for 10Base-T cable length and
network connections on single segments of cable or on point-to-point links with
media attenuation and signal propagation delays. The basic rule is that, for any
network, the maximum number of repeaters in the data path between any two
nodes cannot exceed four.
18
Page 39
Appendix A
Technical Specifications
The AT-MR840TF Specifications
Physical
Height 37.6 mm (1.55 in.)
Width 332 mm (13 in.)
Depth 112 mm (4.4 in.)
Installation options desk or wall mount
Electrical Rating
Input voltage 100-120 or 200-240 VAC
Frequency 50 or 60 Hz
Amperage 0.5/0.25 Amp
Environmental
Operating temperature 0˚ C to 50˚ C (32˚ to 94˚ F)
Storage temperature -10˚ C to 70˚ C
Operating altitude up to 10,000 ft.
Relative humidity 5% to 80%, non-condensing
19
Page 40
Technical Specifications
Certification
Safety CE Compliant
UL 1950, CSA 22.2 No. 950, TUV EN60950,
EN 60825
Emission EMI/RFI FCC Class A, EN55022 Class A,
Immunity EN50082-1, IEC 801-2 1984 level 2 EFT/Burst
Immunity IEC 801-41 1988 level 2
Connector Pinouts for UTP and Uplink Port
Table 6 shows the pinouts for straight through cable when connecting a hub to
a NIC. Table 7 shows the pinouts for straight through cable when connecting a
hub to a hub (cascading using Port 8). According to the 10Base-T specification,
pins 1 and 2 on the connector are used for transmitting data; pins 3 and 6 are
used for receiving data. The “+” and “-” signs represent the polarity of the two
wires that make up each wire pair.
Table 6: Hub to NIC Pin Assignments
Hub Side
MDI/MDI-X switch must be
set to MDI-X for UTP
Hub Side
MDI/MDI-X
switch must be
set to MDI for
fiber
Signal
Name
TX+ 1 -----------> RX+ MDI/MDI-X
TX- 2 -----------> RX-
RX+ 3 <----------- TX+
RX- 6 <----------- TX-
Signal
Name
RX+ 1 <----------- TX+
RX- 2 <----------- TX-
TX+ 3 -----------> RX+
TX- 6 -----------> RX-
Table 7: Hub to Hub Pin Assignments
Pin No.
Pin No.
Signal
Direction
Signal
Direction
Signal
Name
Signal
Name
Hub Side
switch must be
set to MDI-X
20
Page 41
AT-MR820TF Hub Installation Guide
Straight-through Cable Wiring
If the twisted-pair link segment is to join two ports on a switch, and only one of
the ports has an internal crossover, the two pairs of wires must be
straight-through, as shown in Table 8.
Table 8: Straight-through Cable RJ45 Pin Assignments
Hub Device
1 (TX+) 1 (TX+)
2 (TX-) 2 (TX-) 3 (RX+) 3 (RX+) 6 (RX-) 6 (RX-)
Crossover Cable Wiring
Two AT-MR840TFs can communicate only if the transmitter on one unit is
connected to the receiver on the other unit. This reversal, or crossover function,
can be implemented either in the wiring or in the device itself (MDI-MDI-X)
switch. When connecting AT-MR840TFs, a crossover must be implemented in
the wiring. Refer to Table 9 for crossover pin assignments.
Table 9: Crossover Cable RJ45 Pin Assignments
AT-MR840TF AT-MR840TF
1 (TX+) 3 (RX+) 2 (TX-) 6 (RX-)
3 (RX+) 1 (TX+)
6 (RX-) 2 (TX-)
21
Page 42
Technical Specifications
10Base-T/10Base-FL Network Specifications
Table 10 provides an overview of the IEEE 802.3 specifications for 10Base-T/
10Base-FL network configurations using twisted-pair wiring or fiber optics.
Table 10: IEEE 802.3 10Base-T/10Base-FL Network Specifications
10Base-T 10Base-FL
Media Twisted Pair Cable ST/SC fiber optic cable Topology Star, Tree Star, Tree External Devices Network Adapter Card Network Adapter Card Maximum Segment
Length Required Category 3, 4, or 5 850 NM Maximum Devices per
Segment
Required gauge and
impedance
Maximum Devices per
Network
100 meters (328 ft.) 2K (1.25 miles)
12 2 MAUs/segment
22 to 26 AWG TP wire with 100 W impedance
1024 1024
Multimode fiber 50/125 or
62.5/125 micron
22
Page 43
Appendix B
Technical Support Fax Order
Name__________________________________________________________________
Company _______________________________________________________________
Address ________________________________________________________________
City ________________________State/Province _______________________________
Zip/Postal Code ___________________ Country _______________________________
Phone _______________________________Fax _______________________________
Incident Summary
Model number of Allied Telesyn product I am using _____________________________
Network software products I am using________________________________________
______________________________________________________________________
Brief summary of problem _________________________________________________
______________________________________________________________________
Conditions (List the steps that led up to the problem.) ___________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
Detailed description (Use separate sheet, if necessary)
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
When completed, fax this sheet to the appropriate ATI office. Refer to Appendix D on
page 27 for fax numbers.
23
Page 44
Page 45
Appendix C
AT-MR840TF Installation Guide Feedback
Please tell us what additional information you would like to see discussed in the guide. If there
are topics you would like information on that were not covered in the guide, please photocopy
this page, answer the questions and fax or mail this form back to Allied Telesyn International
Corp. The mailing address and fax number are at the bottom of the page. Your comments are
valuable when we plan future revisions of the guide.
I found the following the most valuable _______________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
I would like the following more developed _____________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
I would find the guide more useful if _________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
______________________________________________________________________
Please fax or mail your feedback. Fax to 1-206-481-3790. Or mail to:
Allied Telesyn International Technical Communications Department
19015 North Creek Parkway
Bothell, WA 98011 USA
25
Page 46
Page 47
Appendix D
Where To Find Us
For Technical Support or Service
Location Phone Fax
Americas
United States, Canada, Mexico, Central America,
South America
Asia
Singapore, Taiwan, Thailand, Malaysia,
Indonesia, Korea, Philippines, China, India
Australia
Australia, New Zealand
France
France, Belgium, Luxembourg, The Netherlands,
Middle East, Africa
Germany
Germany, Switzerland, Austria, Eastern Europe
Hong Kong (+852) 2-529-4111 (+852) 2 529-7661
Italy
Italy, Spain, Portugal, Greece, Turkey, Israel
Japan (+81) 3-3443-5640 (+81) 3-3443-2443
United Kingdom
United Kingdom, Denmark, Norway, Sweden,
Finland, Iceland
Technical Bulletin Board Service 1 (206) 483-7979
Technical Support E-mail Address TS1@alliedtelesyn.com
CompuServe Go ALLIED
World Wide Web http://www.alliedtelesyn.com
FTP Server Address: gateway.centre.com [lowercase letters]
1 (800) 428-4835 1 (206) 481-3790
(+65) 3815-613 (+65) 3833-830
(612) 416-0619 (612) 416-9764
(+33) 1-60-92-15-32 (+33) 1-69-28-37-49
(+49) 30-435-900-126 (+49) 30-435-70-650
(+39) 2-416047 (+39) 2-419282
(+44) 1-235-442560 (+44) 1-235-442490
Login: anonymous [lowercase letters]
Password: your e-mail address [requested by the server at login]
