MixWizard WZ
USER GUIDE
Publication AP5332
3
14:4:2
Limited One Year Warranty
This product is warranted to be free from defects in materials or workmanship for
a period of one year from the date of purchase by the original owner.
To ensure a high level of performance and reliability for which this equipment has
been designed and manufactured, read this User Guide before operating. In the
event of a failure, notify and return the defective unit to ALLEN&HEATH Limited
or its authorised agent as soon as possible for repair under warranty subject to
the following conditions
Conditions Of Warranty
1. The equipment has been installed and operated in accordance with the
instructions in this User Guide
2. The equipment has not been subject to misuse either intended or accidental,
neglect, or alteration other than as described in the User Guide or Service
Manual, or approved by ALLEN&HEATH.
3. Any necessary adjustment, alteration or repair has been carried out by
ALLEN&HEATH or its authorised agent.
4. This warranty does not cover fader wear and tear.
5. The defective unit is to be returned carriage prepaid to ALLEN&HEATH or its
authorised agent with proof of purchase.
6. Units returned should be packed to avoid transit damage.
In certain territories the terms may vary. Check with your ALLEN&HEATH agent
for any additional warranty which may apply.
This product complies with the European Electromagnetic
Compatibility directives 89/336/EEC & 92/31/EEC and the
European Low Voltage Directives 73/23/EEC & 93/68/EEC.
This product has been tested to EN55103 Parts 1 & 2 1996 for use in
Environments E1, E2, E3, and E4 to demonstrate compliance with the
protection requirements in the European EMC directive 89/336/EEC.
During some tests the specified performance figures of the product
were affected. This is considered permissible and the product has
been passed as acceptable for its intended use. Allen & Heath has a
strict policy of ensuring all products are tested to the latest safety and
EMC standards. Customers requiring more information about EMC and
safety issues can contact Allen & Heath.
NOTE: Any changes or modifications to the console not approved by
Allen & Heath could void the compliance of the console and therefore
the users authority to operate it.
WZ314:4:2 User Guide AP5332 Issue 3
Copyright © 2005 Allen & Heath Limited. All rights reserved
ALLEN&HEATH Limited
Kernick Industrial Estate, Penryn, Cornwall, TR10 9LU, UK
http://www.allen-heath.com
2 WZ314:4:2 User Guide
Important Safety Instructions
WARNINGS
- Read the following before proceeding :
CAUTION
ATTENTION: RISQUE DE CHOC ELECTRIQUE – NE PAS OUVRIR
Read instructions: Retain these safety and operating instructions for future reference. Adhere
to all warnings printed here and on the console. Follow the operating
instructions printed in this User Guide.
Do not remove cover: Operate the console with its covers correctly fitted. Disconnect mains
power by unplugging the power cord if the cover needs to be removed for
setting internal options. Refer this work to competent technical personnel
only.
Power sources: Connect the console to a mains power unit only of the type described in
this User Guide and marked on the rear panel. Use the power cord with
sealed mains plug appropriate for your local mains supply as provided with
the console. If the provided plug does not fit into your outlet consult your
service agent for assistance.
Power cord routing: Route the power cord so that it is not likely to be walked on, stretched or
pinched by items placed upon or against it.
Grounding: Do not defeat the grounding and polarisation means of the power cord
plug. Do not remove or tamper with the ground connection in the power
cord.
WARNING: This equipment must be earthed.
Water and moisture: To reduce the risk of fire or electric shock do not expose the console to
rain or moisture or use it in damp or wet conditions. Do not place
containers of liquids on it which might spill into any openings.
Ventilation: Do not obstruct the ventilation slots or position the console where the air
flow required for ventilation is impeded. If the console is to be operated in
a rack unit or flightcase ensure that it is constructed to allow adequate
ventilation.
Heat and vibration: Do not locate the console in a place subject to excessive heat or direct
sunlight as this could be a fire hazard. Locate the console away from any
equipment which produces heat or causes excessive vibration.
Servicing: Switch off the equipment and unplug the power cord immediately if it is
exposed to moisture, spilled liquid, objects fallen into the openings, the
power cord or plug become damaged, during lightening storms, or if
smoke, odour or noise is noticed. Refer servicing to qualified technical
personnel only.
Installation: Install the console in accordance with the instructions printed in this User
Guide. Do not connect the output of power amplifiers directly to the
console. Use audio connectors and plugs only for their intended purpose.
WZ314:4:2 User Guide 3
Important Mains plug wiring instructions.
The console is supplied with a moulded mains plug fitted to the AC
mains power lead. Follow the instructions below if the mains plug has
to be replaced. The wires in the mains lead are coloured in
accordance with the following code:
TERMINAL
L
LIVE BROWN BLACK
N
NEUTRAL BLUE WHITE
E
EARTH GND GREEN & YELLOW GREEN
The wire which is coloured Green and Yellow must be connected to the
terminal in the plug which is marked with the letter E or with the Earth
symbol. This appliance must be earthed.
The wire which is coloured Blue must be connected to the terminal in
the plug which is marked with the letter N.
The wire which is coloured Brown must be connected to the terminal in
the plug which is marked with the letter L.
Ensure that these colour codes are followed carefully in the event of
the plug being changed.
General Precautions
WIRE COLOUR
European USA/Canada
Damage : To prevent damage to the controls and cosmetics avoid placing heavy
objects on the control surface, scratching the surface with sharp objects,
or rough handling and vibration.
Environment : Protect from excessive dirt, dust, heat and vibration when operating and
storing. Avoid tobacco ash, smoke, drinks spillage, and exposure to rain
and moisture. If the console becomes wet, switch off and remove mains
power immediately. Allow to dry out thoroughly before using again.
Cleaning : Avoid the use of chemicals, abrasives or solvents. The control panel is
best cleaned with a soft brush and dry lint-free cloth. The faders, switches
and potentiometers are lubricated for life. The use of electrical lubricants
on these parts is not recommended. The fader and potentiometer knobs
may be removed for cleaning with a warm soapy solution. Rinse and allow
to dry fully before refitting them.
Transporting : The console may be transported as a free-standing unit or mounted in a
rack or flightcase. Protect the controls from damage during transit. Use
adequate packing if you need to ship the unit.
Hearing : To avoid damage to your hearing do not operate any sound system at
excessively high volume. This also applies to any close-to-ear monitoring
such as headphones. Continued exposure to high volume sound can
cause frequency selective or wide range hearing loss.
4 WZ314:4:2 User Guide
Introduction
Welcome to the Allen & Heath WZ
MixWizard series of compact audio mixing consoles. We have tried to keep this user guide
brief and to the point. Please read it fully before starting. Included is information on
installing, connecting and operating the console, panel drawings, system block diagram and
technical specification. For further information on the basic principles of audio system
engineering, please refer to one of the specialist publications and resources available from
bookshops, audio equipment dealers and the Internet.
Whilst we believe the information in this guide to be reliable we do not assume responsibility
for inaccuracies. We also reserve the right to make changes in the interest of further product
development.
We are able to offer further product support through our world-wide network of approved
dealers and service agents. You can also access our Web site on the Internet for
information on our full product range, our company pedigree, assistance with your technical
queries, our contact details or simply to chat about matters audio. To help us provide the
most efficient service please keep a record of your console serial number, and date and
place of purchase to be quoted in any communication regarding this product.
3
14:4:2, one of the latest generation of the popular
www.allen-heath.com
Contents
Warranty ................................................ 2
General Precautions.............................. 4
Introduction to this Guide...................... 5
Front Panel Layout ................................ 6
Introducing the MixWizard .................... 7
Installing the Console............................ 8
Connecting Power................................. 9
Connecting a Backup Supply ...............9
Connection Pinouts and Cables .........10
Audio Connections.............................. 11
Connector Panel Layouts.................... 12
Console Connectors............................ 13
Mono Input Channel ............................15
Stereo Input Channel........................... 17
Group/Aux Masters.............................. 18
Master Section..................................... 19
Talkback, Generator and Matrix ..........20
Specifications ......................................21
System Block Diagram ........................23
User Options........................................24
Cue Sheet ............................................ 27
