Alinco DJ-G7 User Manual

Specifications and Main Features

  • These Frequency Ranges Include:
  • VHF Band of Frequencies: 144.000~145.995MHz
  • UHF Band of Frequencies: 430.000~439.995MHz
  • SHF Band of Frequencies: 1200~1299.995MHz
  • These Types Include: Triple Band FM Transceiver which is Full Duplex
  • Displays: Large Full-Matrix LCD for ease in usages
  • These Dials Include: Main Sub Band and Independent Dials
  • Telecom EG Versions that Operate AM/SW/FM Broadcasting in the 0.5 to 18300 MHz (T/EG Versions)
  • There is Other Display Type For Usages Like VOX For Hands-Free Operations
  • Devices That Detect Bug WithModes (T Version Only)
  • Available Cloning Function That Enables To Reconfigure The Devices’ Configurations With A Unit Copier
  • Functions Of CTCSS/DCS Reverse Tone Squelch
  • There is Channel Scope Function To Help Monitor Overlapping Signals
  • Extras Included are:
  • EA-163 Flexible Whip Antenna
  • EBP-73 Li-Ion Battery Pack
  • EDC-173 Drop-In Charger
  • EDC-170, EDC-151A, EDC-152A AC Adaptors (for some of the models)
  • EBC-23 Belt Clip
  • Hand Strap
  • There is IPX7 specification hence it is waterproof
  • There are Repeater Operations In The Main Sub Band With A Shift Frequency That Is Adjustable
  • Memory Capacity for Multiple Banks of up to 1000 Channel Memories
  • It has a Dual Band Operation with A Priority Channel

Frequently Asked Questions

Q1: What frequency bands can the DJ-G7 operate on?

A1: The DJ-G7 has the capability of operating on 144MHz, 430MHz and 1200MHz bands.

Q2: Does the DJ-G7 support hands-free operation?

A2: The device does support hands free operation as a VOX function is available on the unit.

Q3: What’s the amount of memory channels the DJ-G7 can hold?

A3: Maximum of up to 1000 memory channels in the various memories it is equipped with.

Q4: Is the DJ-G7 shockproof?

A4: Yes, it has a waterproof protection rating of IPX7 meaning that it can withstand water submersion for a limited time.

Q5: While driving, could I make use of the DJ-G7?

A5: As best practice, it is essential to see and follow applicable local laws concerning the use of radio equipment and devices in vehicles.

Q6: DJ-G7 selection scope, does it exist?

A6: Yes, it is possible to view the transmitting signals being received on the main channel and some adjacent frequencies.

Q7: What are the components which come with the DJ-G7?

A7: For accessories, it has a flexible whip antenna, a lithium ion battery pack, a drop in charger, different AC adapters depending on the version, a belt clip and hand strap.

Q8: Can the configuration from one DJ-G7 to another be copied?

A8: The copying of configurations from one DJ-G7 to another has been made possible due to the cloning function being made available.

Q9: What are the options made available all the time if there does exist a save module for the batteries?

A9: The answer is therefore, yes, the battery save function in the DJ-G7 is one aimed at reducing unnecessary consumption of the batteries within the device.

Q10: What to do if the Battery Pack is no longer able to retain sufficient energy?

A10: In case when the battery pack continues to be charged for a very long time and the operating period offered does become quite short, the survey suggests that the pack needs to be changed.

User Manual

Page 1
Alinco DJ-G7 User Manual
Page 2
Page 3
Page 4
Page 5
Page 6
Page 7
Page 8
Page 9
Page 10
Page 11
Page 12
Page 13
Page 14
Page 15
Page 16
Page 17
Page 18
Page 19
Page 20
Page 21
Page 22
Page 23
Page 24
Page 25
Page 26
Page 27
Page 28
Page 29
Page 30
Page 31
Page 32
Page 33
Page 34
Page 35
Page 36
Page 37
Page 38
Page 39
Page 40
Page 41
Page 42
Page 43
Page 44
Page 45
Page 46
Page 47
Page 48
Page 49
Page 50
Page 51
Page 52
Page 53
Page 54
Page 55
Page 56
Page 57
Page 58
