User Guide
English ( 3 – 4 )
Guía del usuario
Español ( 5 – 6 )
Guide d'utilisation
Français ( 7 – 8 )
Guida per l'uso
Italiano ( 9 – 10 )
Benutzerhandbuch
Deutsch ( 11 – 12 )
Appendix
English ( 14 )
User Guide (English)
Introduction
Box Contents
V61 |
Visit alesis.com/v61 and click |
V Editor Software (download) |
Docs & Downloads to download |
Software Download Cards |
the V Editor Software. |
USB Cable |
|
User Guide |
|
Safety & Warranty Manual |
|
Support
For the latest information about this product (system requirements, compatibility information, etc.) and product registration, visit alesis.com/v61.
For additional product support, visit alesis.com/support.
Quick Start / Connection Diagram
Remember to select V61 as the controller in your digital audio workstation (DAW).
Items not listed under the Box Contents are sold separately.
Computer
Sustain Pedal
3 |
Features |
|
|
|
|
8 |
9 |
|
6 |
6 |
6 |
6 |
|
|
5 |
5 |
2 |
3 |
5 |
5 |
4 |
4 |
||
|
|
|
1 |
|
|
7 |
|
1.Keyboard: This 61-note keyboard is velocity-sensitive and, in conjunction with the Octave Down/Up buttons, can access the full range of 127 available MIDI notes.
2.Pitch-Bend Wheel: Moving this wheel sends MIDI Pitch Bend information.
3.Modulation Wheel: Moving this wheel sends continuous controller data—MIDI CC #01 (modulation), by default.
You can also use the V Editor software to set this wheel to send a different MIDI CC message to your software. See the V Editor's User Guide to learn how to do this.
4.Octave Down/Up: Use these buttons to shift the keyboard's range up or down. The display will indicate the current octave. Press both buttons simultaneously to reset the octave shift to "zero."
5.Assignable Buttons: Use these buttons to send MIDI CC messages to your software. They can function as momentary or toggle (latching) buttons.
You can also use the V Editor software to set each button to send Program Change messages to your software. See the V Editor's User Guide to learn how to do this.
6.Assignable Knobs: Use these 270º knobs to send MIDI CC messages to your software.
You can also use the V Editor software to set each knob to send aftertouch messages to your software. See the V Editor's User Guide to learn how to do this.
7.Pads: Use these pads to trigger drum hits or other samples in your software. The pads are velocity-sensitive, which makes them very responsive and intuitive to play.
You can also use the V Editor software to set each pad to send MIDI CC messages or Program Change messages to your software. See the V Editor's User Guide to learn how to do this.
8.USB Port: Use a standard USB cable to connect this USB port to your computer. The computer's USB port provides ample power to V61. This connection is also used to send and receive MIDI data to and from your computer.
9.Sustain Input: Connect an optional 1/4" TS sustain pedal to this input.
You can also use the V Editor software to set the sustain pedal to send other MIDI CC messages to your software. See the V Editor's User Guide to learn how to do this.
4
Guía del usuario (Español)
Introducción
Contenido de la caja
V61 |
Visite alesis.com/v61 y haga clic |
|
V Editor (descargar) |
Docs & Downloads para descargar |
|
Cable USB |
el software V Editor. |
|
|
|
|
Tarjetas de descarga de software |
|
|
Guía del usuario |
|
|
Manual sobre la seguridad y garantía |
|
|
|
|
|
Soporte |
|
|
Para obtener la información más completa acerca de este product (los requisitos del sistema, compatibilidad, etc) y registro del producto, visite alesis.com/v61.
Para soporte adicional del producto, visite alesis.com/support.
Diagrama de instalación y conexión rápida
Recuerde seleccionar V61 como controlador en su estación de trabajo de audio digital (DAW).
Los elementos que no se enumeran en
Contenido de la caja se venden por separado.
Ordenador
Pedal de
sostenido |
5 |
