Alcatel One Touch Pop S7 User Guide

IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 1-2 12/1/2014 10:00:47 AM
Table of Contents
Safety and use ............................................................................ 5
General information ...............................................................12
1 Your mobile .......................................................................14
1.1 Keys and connectors ................................................................................14
1.2 Getting started .......................................................................................... 17
1.3 Home screen ..............................................................................................20
2 Text input ...........................................................................30
2.1 Using the Onscreen Keyboard ............................................................... 30
2.2 Text editing ................................................................................................. 31
3 Phone call, Call log and Contacts ....................................33
3.1 Phone ...........................................................................................................33
3.2 Call log .........................................................................................................40
3.3 People ..........................................................................................................41
4 Messaging, Email ...............................................................49
4.1 Messaging ....................................................................................................49
4.2 Gmail/Email .................................................................................................55
4.3 Google Hangouts ......................................................................................62
5 Calendar & Clock ................................................................66
5.1 Calendar ......................................................................................................66
5.2 Clock ............................................................................................................69
6 Getting connected ............................................................71
6.1 Connecting to the Internet ....................................................................71
6.2 Browser .......................................................................................................74
6.3 Connecting to Bluetooth devices..........................................................82
6.4 Connecting to a computer .....................................................................83
6.5 Sharing your phone's mobile data connection ...................................84
6.6 Connecting to virtual private networks ..............................................86
6.7 Configuring Internet (SIP) calling ...........................................................87
7 Google Play Store .............................................................89
7.1 Locate the item you want to download and install ..........................89
7.2 Download and install ................................................................................90
7.3 Manage your downloads ..........................................................................92
8 Multimedia applications ...................................................94
8.1 Camera ........................................................................................................94
8.2 Gallery ......................................................................................................... 97
8.3 YouTube ....................................................................................................... 99
8.4 Music ..........................................................................................................100
8.5 Video Player ..............................................................................................102
9 Google Maps ....................................................................103
9.1 Get My Location .....................................................................................103
9.2 Search for a location ..............................................................................104
9.3 Star a location ..........................................................................................104
9.4 Get driving, public transportation or walking directions...............106
9.5 Arrangement of Layers ..........................................................................107
1 2
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 1-2 12/1/2014 10:00:47 AM
10 Others ..............................................................................108
10.1 Calculator ..................................................................................................108
10.2 File Manager .............................................................................................109
10.3 Sound Recorder ......................................................................................109
10.4 Radio ..........................................................................................................110
10.5 LED Torch..................................................................................................111
10.6 Setup Wizard ...........................................................................................112
10.7 Help Me ................................................................................................... 112
10.8 Other applications ..................................................................................112
11 Settings ............................................................................113
11.1 Wireless & networks .............................................................................113
11.2 Device ........................................................................................................115
11.3 Personal .....................................................................................................119
11.4 Accounts ...................................................................................................124
11.5 System ........................................................................................................124
12 Making the most of your phone ....................................130
12.1 Smart Suite ...............................................................................................130
12.2 Upgrade .....................................................................................................131
13 Accessories .....................................................................133
14 Telephone warranty ........................................................ 134
15 Troubleshooting ...............................................................136
16 Specifications .................................................................... 142
This product meets applicable national SAR limits of
2.0W/kg. The specific maximum SAR values can be found on page 9 of this user guide.
When carrying the product or using it while worn on your body, either use an approved accessory such
as a holster or otherwise maintain a distance of 10 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.
3 4
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 3-4 12/1/2014 10:00:48 AM
Safety and use ..............................
We recommend that you read this chapter carefully before using your phone. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein.
TRAFFIC SAFETY:
Given that studies show that using a mobile phone while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their mobile when the vehicle is not parked.
When driving, do not use your phone and headphone to listen to music or to the radio. Using a headphone can be dangerous and forbidden in some areas. When switched on, your phone emits electromagnetic waves that can interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure that there is no problem:
- do not place your phone on top of the dashboard or within an airbag deployment area,
- check with your car dealer or the car manufacturer to make sure that the dashboard is adequately shielded from mobile phone RF energy.
CONDITIONS OF USE:
You are advised to switch off the telephone from time to time to optimise its performance. Switch the phone off before boarding an aircraft. Switch the phone off when you are in health care facilities, except in designated areas. As with many other types of equipment now in regular use, mobile telephones can interfere with other electrical or electronic devices, or equipment using radio frequency. Switch the phone off when you are near gas or flammable liquids. Strictly obey all signs and instructions posted in a fuel depot, petrol station, or chemical plant, or in any potentially explosive atmosphere. When the phone is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid or insulin pump, etc. In particular when using the phone, you should hold it against the ear on the opposite side to the device, if any. To avoid hearing impairment, pick up the call before holding your phone to your ear. Also move the handset away from your ear while using the "hands-free" mode because the amplified volume might cause hearing damage. Do not let children use the phone and/or play with the telephone and accessories without supervision.
When replacing the cover please note that your phone may contain substances that could create an allergic reaction. Always handle your phone with care and keep it in a clean and dust-free place. Do not allow your phone to be exposed to adverse weather or environmental conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc). The manufacturer’s recommended operating temperature range is -10°C to +55°C. At over 55°C the legibility of the phone’s display may be impaired, though this is temporary and not serious. Emergency call numbers may not be reachable on all cellular networks. You should never rely only on your phone for emergency calls. Do not open, dismantle or attempt to repair your mobile phone yourself. Do not drop, throw or bend your mobile phone. Do not use the phone if the glass made screen is damaged, cracked or broken to avoid any injury. Do not paint it. Use only batteries, battery chargers, and accessories which are recommended by TCT Mobile Limited and its affiliates and are compatible with your phone model. TCT Mobile Limited and its affiliates disclaim any liability for damage caused by the use of other chargers or batteries. Remember to make back-up copies or keep a written record of all important information stored in your phone. Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing-lights feature on your phone. Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. To limit the likelihood of such symptoms, please take the following safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15 minutes break hourly.
- Play in a room in which all lights are on.
- Play at the farthest distance possible from the screen.
- If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours before playing again.
5 6
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 5-6 12/1/2014 10:00:48 AM
- If you continue to have sore hands, wrists, or arms during or after playing, stop the game and see a doctor.
When you play games on your phone, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow the instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.
PRIVACY:
Please note that you must respect the laws and regulations in force in your jurisdiction or other jurisdiction(s) where you will use your mobile phone regarding taking photographs and recording sounds with your mobile telephone. Pursuant to such laws and regulations, it may be strictly forbidden to take photographs and/or to record the voices of other people or any of their personal attributes, and duplicate or distribute them, as this may be considered to be an invasion of privacy. It is the user's sole responsibility to ensure that prior authorisation be obtained, if necessary, in order to record private or confidential conversations or take a photograph of another person; the manufacturer, the seller or vendor of your mobile phone (including the operator) disclaim any liability which may result from the improper use
of the mobile phone.
BATTERY:
Observe the following precautions for battery use:
- Do not attempt to open the back cover,
- Do not attempt to eject, replace and open battery,
- Do not punctuate the back cover of your phone,
- Do not burn or dispose of your phone in household rubbish or store it at temperature above 60°C.
Batteries must be disposed of in accordance with locally applicable environmental regulations. Only use the battery for the purpose for which it was designed. Never use damaged batteries or those not recommended by TCT Mobile Limited and/or its affiliates.
This symbol on your telephone, the battery and the accessories means that these products must be taken to collection points at the end of their life:
- Municipal waste disposal centres with specific bins for these items of equipment
- Collection bins at points of sale. They will then be recycled, preventing substances being disposed of in the environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with this sign must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not to be thrown into ordinary bins if your jurisdiction or your region has suitable recycling and collection facilities; instead they are to be taken to collection points for them to be recycled. CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
CHARGERS
Mains powered chargers will operate within the temperature range of: 0°C to 40°C. The chargers designed for your mobile phone meet with the standard for safety of information technology equipment and office equipment use. They are also compliant to the ecodesign directive 2009/125/EC. Due to different applicable electrical specifications, a charger you purchased in one jurisdiction may not work in another jurisdiction. They should be used for this purpose only.
RADIO WAVES:
Proof of compliance with international standards (ICNIRP) or with European Directive 1999/5/EC (R&TTE) is required of all mobile phone models before they can be put on the market. The protection of the health and safety for the user and any other person is an essential requirement of these standards or this directive. THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES. Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves (radio frequency electromagnetic fields) recommended by international guidelines. The guidelines were developed by an independent scientific organization (ICNIRP) and include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg. Tests for SAR are conducted using standard operating positions with the device transmitting at its highest certified power level in all tested frequency bands. The highest SAR values under the ICNIRP guidelines for this device model are:
7 8
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 7-8 12/1/2014 10:00:49 AM
Maximum SAR for this model and conditions under which it was
recorded.
Head SAR Wi-Fi 802.11b + Bluetooth 0.350 W/kg
Body-worn SAR LTE Band 7 + Bluetooth + Wi-Fi 0.587 W/kg
During use, the actual SAR values for this device are usually well below the values stated above. This is because, for purposes of system efficiency and to minimize interference on the network, the operating power of your mobile device is automatically decreased when full power is not needed for the call. The lower the power output of the device, the lower its SAR value. Body-worn SAR testing has been carried out at a separation distance of 10 mm. To meet RF exposure guidelines during body-worn operation, the device should be positioned at least this distance away from the body. If you are not using an approved accessory ensure that whatever product is used is free of any metal and that it positions the phone the indicated distance away from the body. Organizations such as the World Health Organization and the US Food and Drug Administration have statesd that if people are concerned and want to reduce their exposure they could use a hands-free device to keep the phone away from the head and body during phone calls, or reduce the amount of time spent on the phone. For more information you can go to www.alcatelonetouch.com Additional information about electromagnetic fields and public health are available on the following site: http://www.who.int/peh-emf. Your telephone is equipped with a built-in antenna. For optimal operation, you should avoid touching it or degrading it. As mobile devices offer a range of functions, they can be used in positions other than against your ear. In such circumstances the device will be compliant with the guidelines when used with headset or usb data cable. If you are using another accessory ensure that whatever product is used is free of any metal and that it positions the phone at least 10 mm away from the body.
Regulatory information
The following approvals and notices apply in specific regions as noted.
9 10
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 9-10 12/1/2014 10:00:50 AM
LICENCES
(1)
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TCT Mobile Limited and its affiliates is under license. Other trademarks and trade names are those of their respective owners.
ALCATEL ONETOUCH POP S7 7045Y Bluetooth Declaration ID D022955
The Wi-Fi Logo is a certification mark of the Wi-Fi Alliance. 5 GHz Wi-Fi operation is for indoor use only.
Google, the Google logo, Android, the Android logo, Google SearchTM, Google MapsTM, GmailTM, YouTube, Google Play Store, Google Latitude TM and HangoutsTM are trademarks of Google Inc.
The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative Commons 3.0 Attribution License (the text will show when you touch and hold Google legal in Settings\About phone\Legal information)
You have purchased a product which uses the open source (http://opensource.org/) programs mtd, msdosfs, netfilter/iptables and initrd in object code and other open source programs licensed under the GNU General Public License and Apache License.
We will provide you with a complete copy of the corresponding source codes upon request within a period of three years from the distribution of the product by TCT.
You may download the source codes from http://sourceforge.net/projects/alcatel/ files/. The provision of the source code is free of charge from the Internet.
(1)
.
General information ...................
•Internet address: www.alcatelonetouch.com
• Hot Line Number : see "TCT Mobile Services" leaflet or go to our website.
Address: Room 1910-12A, Tower 3, China HK City, 33 Canton Road, Tsimshatsui,
Kowloon, Hong Kong
On our website, you will find our FAQ (Frequently Asked Questions) section. You can also contact us by e-mail to ask any questions you may have. An electronic version of this user guide is available in English and other languages according to availability on our server: www.alcatelonetouch.com Your telephone is a transceiver that operates on GSM in quad-band with 850/900/1800/1900 MHz, UMTS in dual-band with 900/2100 MHz or LTE in penta­band with B1/B3/B7/B8/B20.
This equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The entire copy of the Declaration of Conformity for your telephone can be obtained through our website: www.alcatelonetouch.com.
Protection against theft
Your telephone is identified by an IMEI (phone serial number) shown on the packaging label and in the phone’s memory. We recommend that you note the number the first time you use your telephone by entering * # 0 6 # and keep it in a safe place. It may be requested by the police or your operator if your telephone is stolen. This number allows your mobile telephone to be blocked preventing a third person from using it, even with a different SIM card.
(1)
(1)
It may not be available according to the countries.
(1)
Contact your network operator to check service availability.
11 12
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 11-12 12/1/2014 10:00:51 AM
Disclaimer
There may be certain differences between the user manual description and the phone’s operation, depending on the software release of your telephone or specific operator services. TCT Mobile shall not be held legally responsible for such differences, if any, nor for their potential consequences, which responsibility shall be borne by the operator exclusively.This handset may contain materials, including applications and software in executable or source code form, which is submitted by third parties for inclusion in this handset (“Third Party Materials”). All third party materials in this handset are provided “as is”, without warranty of any kind, whether express or implied, including the implied warranties of merchantability, fitness for a particular purpose or use/ third party application, interoperability with other materials or applications of the purchaser and non-infringement of copyright. The purchaser undertakes that TCT Mobile has complied with all quality obligations incumbent upon it as a manufacturer of mobile devices and handsets in complying with Intellectual Property rights. TCT Mobile will at no stage be responsible for the inability or failure of the Third Party Materials to operate on this handset or in interaction with any other devices of the purchaser. To the maximum extent permitted by law, TCT Mobile disclaims all liability for any claims, demands, suits or actions, and more specifically – but not limited to – tort law actions, under any theory of liability, arising out of the use, by whatever means, or attempts to use, such Third Party Materials. Moreover, the present Third Party Materials, which are provided free of charge by TCT Mobile, may be subject to paid updates and upgrades in the future; TCT Mobile waives any responsibility regarding such additional costs, which shall be borne exclusively by the purchaser. The availability of the applications may vary depending on the countries and the operators where the handset is used; in no event shall the list of possible applications and software provided with the handsets be considered as an undertaking from TCT Mobile; it shall remain merely as information for the purchaser. Therefore, TCT Mobile shall not be held responsible for the lack of availability of one or more applications wished for by the purchaser, as its availability depends on the country and the operator of the purchaser. TCT mobile reserves the right at any time to add or remove Third Party Materials from its handsets without prior notice; in no event shall TCT Mobile be held responsible by the purchaser for any consequences that such removal may have on the purchaser regarding the use or attempt to use such applications and Third Party Materials.
Your mobile ...........................
1
1.1 Keys and connectors
Headset connector
Back key
Home key
micro-USB connector
Front camera
Power key
Touch screen
Menu key
13 14
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 13-14 12/1/2014 10:00:52 AM
Camera
Flashlight
Volume up
Volume down
Power key
Back key
•Touch to go back to the previous screen, or to close a dialog
box, options menu, the notification panel, etc.
•These keys are visible when the screen lights up.
Home key
•While on any application or screen, touch to return to the
Home screen.
Menu key
•Touch to access Settings options.
•Touch and hold: Touch and hold to open a list of thumbnail
images of applications you've worked with recently.
Camera flash/
Power key
•Press: Lock the screen/Light up the screen
•Press and hold: Power on or generate a pop up menu providing
more options, such as Restart, Airplane mode, etc.
•Press and hold Powe r key and Volume down key to capture
a screenshot.
•Press to mute the ringtone when there’s an incoming call.
Volume keys
•In call mode, adjust the earpiece or headset volume.
•In Music/Video mode, adjust the media volume.
•Mute the ringtone of an incoming call.
•Press to light up the screen when it dims during a call.
15 16
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 15-16 12/1/2014 10:00:54 AM
1.2 Getting started
1.2.1 Set-up
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls.
Installing the microSD card
Place the microSD card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the microSD card, press and slide it out.
Charging the battery
Place the SIM card with the chip facing downwards and slide it into its housing. Make sure that it is correctly inserted. To remove the SIM card, press and slide it out.
Your phone only supports micro-SIM card. Do not at tempt to insert other SIM types like mini and nano cards, otherwise you may damage your phone.
17 18
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 17-18 12/1/2014 10:00:56 AM
To charge the battery, connect the charger to your phone and mains socket. You can also charge your phone via a USB cable.
To reduce energy wastage, disconnect your charger from the plug
when the battery is fully charged.
To reduce your phone’s power consumption, switch off Wi-Fi, GPS, Bluetooth or apps running in the background when not needed. In Settings you can also lower the brightness of the screen, and shorten the length of time before the screen goes to sleep.
1.2.2 Power on your phone
Hold down the Power key until the phone powers on, unlock your phone (Slide, PIN, Password, Pattern, Face unlock or Voice unlock) if necessary and confirm. The Home screen will then be displayed.
If you do not know your PIN code or if you have forgotten it, contact your network operator. Do not leave your PIN code with your phone. Store this information in a safe place when not in use.
Set up your phone for the first time
Once you have powered on your phone for the first time, you should set the following options:
• Touch Get started..., then select the phone's language.
•Select your input keyboard, then touch Next.
• Set your date and timezone, you can also choose Automatic time zone,
then touch Next.
Setup your Google account: Touch Set up now. If you have a Google
Account, touch Ye s , then enter your user name and password. If you forget your password, you can go to http://www.google.com/ to retrieve it. Touch Next to skip to the next step.
•Touch Next ,then the Setup complete screen displays, touch Finish to
confirm.
When the phone is powered on, you can connect to a Wi-Fi network, without a SIM card inserted (refer to section "6.1.2 Wi-Fi"), to sign into your Google account and use some features.
1.2.3 Power off your phone
Hold down the Power key until the pop-up menu appears, select Power off to confirm.
1.3 Home screen
You can bring all the items (applications, shortcuts, folders and widgets) you love or use most frequently to your Home screen for quick access. Touch the Home key to switch to Home screen. Drag the screen upwards to access the application list.
Status bar
• Status/Notification indicators
Favourite applications tray
• Touch to enter the application.
• Touch and hold to move or change applications.
Touch to enter application list.
Home screen is provided in an extended format to allow more space for adding applications, shortcuts etc. Slide the Home screen horizontally left and right to get a complete view of the Home screen. The white short line at the lower part of the screen indicates which screen you are viewing.
1.3.1 Using the touchscreen
Touch
To access an application, touch it with your finger.
19 20
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 19-20 12/1/2014 10:00:57 AM
Touch and Hold
Touch and hold the home screen to access Widgets and Downloaded screen.
Status icons
For dual SIM models, status icons referring to either SIM1 or SIM2 will be identified by a colour which you have defined.
GPRS connected GPS is on
Drag
Place your finger on any item to drag it to another location.
Slide/Swipe
Slide the screen to scroll up and down the widget screen, photo screen, web pages… at your convenience.
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place the fingers of one hand on the screen surface and draw them apart or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to landscape by turning the phone sideways to have a better view.
1.3.2 Status bar
From the status bar, you can view both phone status (to the right side) and notification information (to the left side).
21 22
GPRS in use Roaming
EDGE connected
No SIM card inserted
EDGE in use Vibrate mode
3G connected Ringer is silenced
3G in use Battery is very low
HSPA (3G+) connected Battery is low
HSPA (3G+) in use Battery is partially drained
Connected to a Wi-Fi network
Battery is full
Bluetooth is on Battery is charging
Connected to a Bluetooth device
Headset connected
Airplane mode No signal (gray)
Alarm is set Signal strength (blue)
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 21-22 12/1/2014 10:01:00 AM
Notification icons
New text or multimedia message
Problem with SMS or MMS delivery
New Hangouts message Downloading data
New voicemail Download finished
Upcoming event Select input method
Call forwarding is on
Uploading data
Touch and drag down the Status bar to open the Quick setting panel or Notification panel. Touch and drag up to close it. When there are notifications, you may touch and drag the Status bar with two fingers to access Quick setting panel directly.
Quick setting panel
Touch and drag down the Status bar to open Quick setting panel, where you can enable or disable functions or change modes by touching the icons.
Touch to access Settings, where you can set more items
Touch to switch to the notification panel
Song is playing
USB tethering is on
Portable Wi-Fi hotspot is on
Screenshot captured System update available
Carrier data use threshold approaching or exceeded
An open Wi-Fi network is available
Phone is connected via USB cable
Radio is on
Connected to VPN
Notification panel
When there are notifications, touch and drag down the Status bar to open the Notification panel and read the detailed information.
Missed call
23 24
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 23-24 12/1/2014 10:01:03 AM
Touch to clear all event–based notifications (other ongoing notifications will remain)
Touch to switch to the Quick setting panel
1.3.3 Search bar
The phone provides a Search function which can be used to locate information within applications, the phone or the web.
Search by text
• Touch Search bar from the Home screen.
•Enter the text/phrase you want to search for.
•Touch on the keyboard if you want to search on the web.
Search by voice
•Touch from the Search bar to display a dialog screen.
•Speak the word/phrase you want to search for. A list of search results will
display for you to select from.
1.3.4 Lock/Unlock your screen
To protect your phone and privacy, you can lock the phone screen by choosing slide or creating a variety of patterns, PIN or password, etc.
To create a screen unlock pattern (refer to section "Screen lock"for detailed settings)
•Drag down the notification panel and touch and then the settings
icon to enter Settings, then touch Lock settings\Select screen lock\Pattern.
•Draw your own pattern.
25 26
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 25-26 12/1/2014 10:01:04 AM
Draw your unlock pattern
Touch to confirm by drawing pattern again
To create a screen unlock PIN/Password
•Touch Settings\Lock settings\Select screen lock\PIN or Password.
•Set your PIN or password.
To set up voice unlock
•Touch Settings\Lock settings\Select screen lock\Voice unlock.
•Touch Record and speak out your voice command (a command with 2-8
syllables, then repeat 3-6 times).
To set up Face unlock
•Touch Settings\Lock settings\Select screen lock\Face unlock.
•Hold the phone at eye level and show your face until the phone captures
the face.
To lock phone screen
Press the Powe r key once to lock the screen.
To unlock phone screen
Press the power key once to light up the screen, draw the unlock pattern you have created or enter your PIN or password, etc. to unlock the screen.
If you have chosen Slide as the screen lock, touch and drag the screen to the right.
1.3.5 Personalize your Home screen
Add
You can touch and hold a folder, an application or a widget to activate the Move mode, and drag the item to any Home screen as you prefer.
Reposition
Touch and hold the item to be repositioned to activate Move mode, drag the item to the desired position and then release. You can move items both on the Home screen and the Favourite tray. Hold the icon on the left or right edge of the screen to drag the item to another Home screen.
27 28
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 27-28 12/1/2014 10:01:04 AM
Create folders
To improve the organization of items (shortcuts or applications) on the Home screen, you can add them to a folder by stacking one item on top of another.
Wallpaper customization
Touch Menu key then touch Wallpaper to customize wallpaper.
1.3.6 Volume adjustment
Using volume key
Press Volume key to adjust the volume. To activate the vibrate mode, press the Volume down key until the phone vibrates. Press the Volume
down key once more to activate the silent mode.
Using Settings menu
Drag down the notification panel and touch and then the settings icon
to enter Settings, then touch Sound, you can set the volume of calls,
notification, system and etc. to your preference.
Text input ..............................
2
2.1 Using the Onscreen Keyboard
Onscreen Keyboard settings
From the main menu screen, select Settings\Language&input, touch the Settings icon on the right of Android keyboard, and then series of settings are available for your selection.
Adjust the Onscreen Keyboard orientation
Turn the phone sideways or upright to adjust the Onscreen Keyboard orientation. You can also adjust it by changing the settings (Touch Settings\ Display\Auto-rotation).
29 30
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 29-30 12/1/2014 10:01:05 AM
2.1.1 Android keyboard
Touch to switch
between "abc/Abc"
mode; touch & hold
to switch between
"abc/ABC" mode
Touch to switch
between symbol and
numeric keyboard
Touch & hold to
show input options;
when Wi-Fi or data
connection is on,
touch to enter voice
input
Touch & hold, then select to enter symbols/emoticons
2.2 Text editing
You can edit the text you have entered.
•Touch and hold or double-tap within the text you would like to edit.
•Drag the tabs to change the highlighted selection.
•The following options will appear: Select all , Cut , Copy
and Paste .
•Touch the icon to confirm.
You can also insert new text
•Touch where you want to type, or touch and hold a blank space, the
cursor will blink and the tabs will show. Drag the tab to move the cursor.
•If you have selected any text, touch the tab to show PASTE icon which
allows you to paste any text you have previously copied.
31 32
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 31-32 12/1/2014 10:01:06 AM
Phone call, Call log
3
and Contacts .........................
International call
To dial an international call, touch and hold to enter "+", then enter the international country prefix followed by the full phone number and finally touch Call.
3.1 Phone ...........................................................
3.1.1 Placing a call
Touch on the home screen to access Phone application.
Dial screen
Touch to add contact
Touch and hold to
access voicemail
Touch to enter
call log
Enter the desired number from the keyboard directly or select a contact from People or Call log by sliding or touching tabs, then touch to
place the call.
The number you entered can be saved to People by touching and Add to contacts.
To hang up a call, touch End.
Touch to delete digits
Touch to pop up menu
Emergency call
If your phone has network coverage, dial the emergency number and touch Call to make an emergency call. This works even without a SIM card and without typing the PIN code.
When making a call with two SIM cards installed, a dialog box will pop up for you to choose the preferred SIM card.
33 34
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 33-34 12/1/2014 10:01:07 AM
3.1.2 Answering or rejecting a call
When you receive a call, drag the icon rightward to answer the call, leftward to reject the call, upward to reject the call by sending a preset message.
To mute incoming calls, press the Volume up/down key or turn the phone face down if Turn over to mute is activated. To activate, touch
Settings\Gestures\Turn over to mute.
3.1.3 Calling your voicemail
Your voicemail is provided by your network to avoid missing calls. It works like an answering machine that you can consult at any time.
To access your voicemail, touch and hold on the Phone tab.
To set your voicemail number, touch the Menu key and select Settings\
Voice call\Voicemail.
If you receive a voicemail, a voicemail icon appears on the Status bar. Open the Notification panel and touch New Voicemail to hear it.
3.1.4 During a call
To adjust the volume during a call, press the Volume up/down ke y.
Touch to hold the current call. Touch this icon again to retrieve the call.
Touch to display Dialpad.
Touch to add a call.
Touch to mute the current call. Touch this icon again to unmute the call.
Touch to activate the speaker during the current call. Touch this icon again to deactivate the speaker.
To avoid accidental touchscreen operations during a call, the screen will be locked automatically when you put the cellphone close to your ear; it will be unlocked when the cellphone is taken away from your ear.
35 36
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 35-36 12/1/2014 10:01:08 AM
3.1.5 Managing multiple calls
With this phone you can handle multiple calls at the same time.
Swap calls
When you accept two calls, touch the icon , you can now switch between two lines. The current call is put on hold and you can join the other call.
Conference calls
To set up a conference call:
•Place a call to the first participant of the conference call.
•Touch the icon.
• Enter the phone number of the person you want to add to the conference
and touch icon Call. You can also add participants from People or Call log.
•Touch the icon to start a conference call.
•During a conference call, touch to drop a participant or to talk
privately to one of the participants. Touch End to drop the participant from the conference, touch to talk privately to the participant and hold the other participants.
•Touch End to end the conference call and disconnect all callers.
(1)
3.1.6 Call settings
Touch and touch Settings from the Dial screen. The following options are available:
Voice call
Voicemail
Voicemail service Open a dialog box where you can select your
carrier’s voicemail service or another service.
Voicemail settings If you are using your carrier’s voicemail service, it
opens a dialog box where you can enter the phone number to use for listening to and managing your voicemail. You can enter a comma (,) to insert a pause into the number — for example, to add a password after the phone number.
IP prefix number
Enter prefix number Select to enter a prefix number for IP dialling.
Call forwarding
Touch to configure how your calls are forwarded when you are busy, unanswered or unreachable.
Additional settings
Caller ID Opens a dialog box where you can set whether
your phone number is displayed when making calls.
Call waiting Mark the checkbox to notify you of a new
incoming call.
Call waiting status Check the call waiting status of your phone.
(1)
Depending on your network operator.
37 38
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 37-38 12/1/2014 10:01:08 AM
Video call
(1)
•Local video
replacement
•Outgoing video
call
•Incoming video
call
You can choose a picture from your collection to display when the Camera is unreachable.
Touch to display local video when you place a call.
Touch to display local video when receiving an incoming call.
Dual mic noise reduction
Mark the checkbox to turn on dual mic for noise reduction.
Quick responses
Touch to edit quick responses which will be used when you reject a call with messages.
International dialling assist
Mark the checkbox to activate.
Internet call
For more information of Internet call, please refer to section 6.7 Configuring Internet (SIP) calling.
Other settings
Fixed Dialling Numbers
Fixed Dialling Number (FDN) is a SIM service mode, where outgoing calls are restricted to a set of phone numbers. These numbers are added to the FDN list. The most common practical application of FDN is for parents to restrict the phone numbers which their children can dial.
For security reasons, you’ll be prompted to enable FDN by entering SIM PIN2 which is usually acquired from your service provider or SIM maker.
Minute reminder
Mark the checkbox to enable minute reminder.
Vibrate reminder
Mark the checkbox to enable vibration when the call is connected.
Power key ends call
3.2 Call log
You can access your call memory by touching from the Dial screen. Touch on the right side of the contact/number to place a call directly. There are three kinds of calls in Call log:
Missed calls
Outgoing calls
Incoming calls
Touch icons on top of call logs to change among different kinds.
Touch a contact or number to view information or perform further operations.
You can view detailed information of a call, launch a new call or send messages to a contact or number, or add numbers to People (only available for unsaved phone numbers), etc.
Touch the icon to open the Quick Contact panel.
To clear the entire call memory, touch the Menu key and select Delete.
Mark the checkbox to end a call by pressing the Powe r ke y.
(1)
Depending on your model.
39 40
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 39-40 12/1/2014 10:01:08 AM
3.3 People............................................................
The People enables quick and easy access to the people you want to reach.
You can view and create contacts on your phone and synchronize these with your Gmail contacts or other applications on the web or on your phone.
3.3.1 Consult your contacts
Touch to view your contact groups
Touch the Menu key to display contacts list option menu.
The following actions are enabled:
•Delete contact Select and delete unwanted contacts.
•Contacts to display Choose contacts to display.
•Import/Export Import or export contacts between phone, SIM
•Accounts Manage the synchronization settings for different
•Settings Set contacts' display mode.
•Share visible
contacts
card, and phone storage.
accounts.
Share contacts with others by sending the contact's vCard to them via Bluetooth, Email, SMS,etc.
Touch icon to open
Quick Contact
panel
Touch to search
people
Touch to view the contact’s detailed information
touch to add a new contact
3.3.2 Managing contact groups
The contact group helps you to improve the organization of your contacts. You can add, remove and view groups in the Contact group screen.
Touch the icon to view local groups. To create a new group, touch the icon, enter the new name and touch DONE to confirm. If you have added accounts to your phone, touch the icon to view groups
in accounts.
3.3.3 Adding a contact
Touch the icon in the contact list to create a new contact.
You are required to enter the contact's name and other contact information. By scrolling up and down the screen, you can move from one field to another easily.
41 42
IP4900_Rio-5 GL_UM_Eng_GB_05_141201.indd 41-42 12/1/2014 10:01:09 AM
Loading...
+ 51 hidden pages
