One Touch Pop S3
User Guide
70 pgs12.22 Mb0
Table of contents
Loading...

Alcatel One Touch Pop S3 User Guide

Table of Contents
Safety and use ����������������������������������������������������������������������������� 4 General information ���������������������������������������������������������������� 12 1 Your mobile ������������������������������������������������������������������������14
1.1 Keys and connectors ................................................................................14
1.2 Getting started ..........................................................................................17
1.3 Home screen .............................................................................................. 21
2 Text input ��������������������������������������������������������������������������� 32
2.1 Using the Onscreen Keyboard ...............................................................32
2.2 Text editing .................................................................................................33
3 Phone call, Call log and Contacts ������������������������������������34
3.1 Phone ........................................................................................................... 34
3.2 Call log .........................................................................................................40
3.3 Contacts ......................................................................................................40
4 Messaging, Gmail/Email, Google Hangouts ��������������������47
4.1 Messaging ....................................................................................................47
4.2 Gmail/Email .................................................................................................54
4.3 Google Hangouts ......................................................................................60
5 Calendar & Alarm clock & Calculator ���������������������������� 63
5.1 Calendar ...................................................................................................... 63
5.2 Time ............................................................................................................ 65
5.3 Calculator ....................................................................................................67
6 Getting connected ������������������������������������������������������������69
6.1 Connecting to the Internet ....................................................................69
6.2 Browser .......................................................................................................72
6.3 Connecting to Bluetooth devices.......................................................... 79
6.4 Connecting to a computer .....................................................................81
6.5 To safely remove the microSD card from your phone ....................81
7 Google Play Store �������������������������������������������������������������85
8 Multimedia applications ���������������������������������������������������90
9 Google Maps ����������������������������������������������������������������������98
10 Others ������������������������������������������������������������������������������102
11 Settings ����������������������������������������������������������������������������107
1 2
11.5 System ........................................................................................................121
12 Making the most of your phone ������������������������������������ 124
12.1 Smart Suite ...............................................................................................124
12.2 Upgrade .....................................................................................................125
13 Telephone warranty ��������������������������������������������������������127 14 Accessories ��������������������������������������������������������������������� 129 15 Troubleshooting ��������������������������������������������������������������130 16 Specifications ������������������������������������������������������������������� 135
This product meets applicable national SAR limits of
2.0 W/kg. The specific maximum SAR values can be found on page 8 of this user guide.
When carrying the product or using it while worn on your body, either use an approved accessory such
www.sar-tick.com
as a holster or otherwise maintain a distance of 1.0 cm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call.
3 4
Safety and use ������������������������������
We recommend that you read this chapter carefully before using your phone. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a mobile phone while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their mobile when the vehicle is not parked.
When driving, do not use your phone and headphone to listen to music or to the radio. Using a headphone can be dangerous and forbidden in some areas.
When switched on, your phone emits electromagnetic waves that can interfere with the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure that there is no problem:
- do not place your phone on top of the dashboard or within an airbag deployment area,
- check with your car dealer or the car manufacturer to make sure that the dashboard is adequately shielded from mobile phone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the telephone from time to time to optimise its performance.
Switch the phone off before boarding an aircraft. Switch the phone off when you are in health care facilities, except in designated
areas. As with many other types of equipment now in regular use, mobile telephones can interfere with other electrical or electronic devices, or equipment using radio frequency.
Switch the phone off when you are near gas or flammable liquids. Strictly obey all signs and instructions posted in a fuel depot, petrol station, or chemical plant, or in any potentially explosive atmosphere.
When the phone is switched on, it should be kept at least 15 cm from any medical device such as a pacemaker, a hearing aid or insulin pump, etc. In particular when using the phone, you should hold it against the ear on the opposite side to the device, if any.
To avoid hearing impairment, pick up the call before holding your phone to your ear. Also move the handset away from your ear while using the “hands-free” mode because the amplified volume might cause hearing damage.
Do not let children use the phone and/or play with the telephone and accessories without supervision.
When replacing the cover please note that your phone may contain substances that could create an allergic reaction.
Always handle your phone with care and keep it in a clean and dust-free place. Do not allow your phone to be exposed to adverse weather or environmental
conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc). The manufacturer’s recommended operating temperature range is -10°C to +50°C.
At over 50°C the legibility of the phone’s display may be impaired, though this is temporary and not serious.
Emergency call numbers may not be reachable on all cellular networks. You should never rely only on your phone for emergency calls.
Do not open, dismantle or attempt to repair your mobile phone yourself. Do not drop, throw or bend your mobile phone. Do not use the phone if the glass made screen, is damaged, cracked or broken to
avoid any injury. Do not paint it. Use only batteries, battery chargers, and accessories which are recommended by
TCT Mobile Limited and its affiliates and are compatible with your phone model. TCT Mobile Limited and its affiliates disclaim any liability for damage caused by the use of other chargers or batteries.
Remember to make back-up copies or keep a written record of all important information stored in your phone.
Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing-lights feature on your phone.
Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. To limit the likelihood of such symptoms, please take the following safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15-minute break hourly.
- Play in a room in which all lights are on.
- Play at the farthest distance possible from the screen.
5 6
- If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing, stop the game and see a doctor.
When you play games on your phone, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. Follow the instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use.
• PRIVACY:
Please note that you must respect the laws and regulations in force in your jurisdiction or other jurisdiction(s) where you will use your mobile phone regarding taking photographs and recording sounds with your mobile telephone. Pursuant to such laws and regulations, it may be strictly forbidden to take photographs and/or to record the voices of other people or any of their personal attributes, and duplicate or distribute them, as this may be considered to be an invasion of privacy. It is the user's sole responsibility to ensure that prior authorisation be obtained, if necessary, in order to record private or confidential conversations or take a photograph of another person; the manufacturer, the seller or vendor of your mobile phone (including the operator) disclaim any liability which may result from the improper use of the mobile phone.
• BATTERY:
Before removing the battery from your phone, please make sure that the phone is switched off. Observe the following precautions for battery use:
- Do not attempt to open the batter y (due to the risk of toxic fumes and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in household rubbish or store it at
temperatures above 60°C.
Batteries must be disposed of in accordance with locally applicable environmental regulations. Only use the batter y for the purpose for which it was designed. Never use damaged batteries or those not recommended by TCT Mobile Limited and/or its affiliates.
This symbol on your telephone, the battery and the accessories means that
these products must be taken to collection points at the end of their life:
- Municipal waste disposal centres with specific bins for these items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge. All products with this sign must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not to be thrown into ordinary bins if your jurisdiction or your region has suitable recycling and collection facilities; instead they are to be taken to collection points for them to be recycled.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
• CHARGERS
Mains powered chargers will operate within the temperature range of: 0°C to 40°C. The chargers designed for your mobile phone meet with the standard for safety of
information technology equipment and office equipment use.They are also compliant to the ecodesign directive 2009/125/EC. Due to different applicable electrical specifications, a charger you purchased in one jurisdiction may not work in another jurisdiction.They should be used for this purpose only.
• RADIO WAVES:
Proof of compliance with international standards (ICNIRP) or with European Directive 1999/5/EC (R&TTE) is required of all mobile phone models before they can be put on the market. The protection of the health and safety for the user and any other person is an essential requirement of these standards or this directive.
THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves (radio frequency electromagnetic fields) recommended by international guidelines. The guidelines were developed by an independent scientific organization (ICNIRP) and include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg.
7 8
Tests for SAR are conducted using standard operating positions with the device transmitting at its highest certified power level in all tested frequency bands. The highest SAR values under the ICNIRP guidelines for this device model are:
ALCATEL ONETOUCH 5050X:
Maximum SAR for this model and conditions under which it was recorded�
Head SAR GSM900+Bluetooth+Wi-Fi 0.896 W/kg
Body-worn SAR GSM900+Bluetooth+Wi-Fi 1.23 W/kg
ALCATEL ONETOUCH 5050Y:
Maximum SAR for this model and conditions under which it was recorded�
Head SAR GSM900+Bluetooth+Wi-Fi 1.02 W/kg
Body-worn SAR GSM900+Bluetooth+Wi-Fi 1.23 W/kg
During use, the actual SAR values for this device are usually well below the values stated above. This is because, for purposes of system efficiency and to minimize interference on the network, the operating power of your mobile device is automatically decreased when full power is not needed for the call. The lower the power output of the device, the lower its SAR value.
Body-worn SAR testing has been carried out at a separation distance of 1.0 cm. To meet RF exposure guidelines during body-worn operation, the device should be positioned at least this distance away from the body.
If you are not using an approved accessory ensure that whatever product is used is free of any metal and that it positions the phone the indicated distance away from the body.
Organizations such as the World Health Organization and the US Food and Drug Administration have stated that if people are concerned and want to reduce their exposure they could use a hands-free device to keep the phone away from the head and body during phone calls, or reduce the amount of time spent on the phone.
For more information you can go to www.alcatelonetouch.com Additional information about electromagnetic fields and public health are available on
the following site: http://www.who.int/peh-emf. Your telephone is equipped with a built-in antenna. For optimal operation, you should
avoid touching it or degrading it. As mobile devices offer a range of functions, they can be used in positions other than
against your ear. In such circumstances the device will be compliant with the guidelines when used with headset or usb data cable. If you are using another accessory ensure that whatever product is used is free of any metal and that it positions the phone at least 1.0 cm away from the body.
• Regulatory information
The following approvals and notices apply in specific regions as noted. ALCATE ONETOUCH 5050X:
ALCATE ONETOUCH 5050Y:
9 10
• LICENCES
microSD Logo is a trademark.
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by TCT Mobile Limited and its affiliates is under license. Other trademarks and trade names are those of their respective owners.
ALCATEL ONETOUCH 5050X
ALCATEL ONETOUCH 5050Y
Bluetooth Declaration ID D022040
The Wi-Fi Logo is a certification mark of the Wi-Fi Alliance.
Google, the Google logo, Android, the Android logo, Google SearchTM, Google MapsTM, GmailTM, YouTube, Google Play Store, Google LatitudeTM and Hangouts
The Android robot is reproduced or modified from work created and shared by Google and used according to terms described in the Creative Commons 3.0 Attribution License (the text will show when you touch and hold Google legal in Settings\About phone\Legal information).
You have purchased a product which uses the open source (http://opensource. org/) programs mtd, msdosfs, netfilter/iptables and initrd in object code and other open source programs licensed under the GNU General Public License and Apache License.
We will provide you with a complete copy of the corresponding source codes upon request within a period of three years from the distribution of the product by TCT.
You may download the source codes from http://sourceforge.net/projects/alcatel/ files/. The provision of the source code is free of charge from internet.
TM
are trademarks of Google Inc.
(1)
General information �������������������
•Internet address: www.alcatelonetouch.com
•Hot Line Number: see “TCT Mobile Services” leaflet or go to our
website.
•Address: Room 1910-12A, Tower 3, China HK City, 33 Canton Road,
Tsimshatsui, Kowloon, Hong Kong
On our website, you will find our FAQ (Frequently Asked Questions) section. You can also contact us by e-mail to ask any questions you may have.
An electronic version of this user guide is available in English and other languages according to availability on our ser ver:
www�alcatelonetouch�com
Your telephone is a transceiver that operates on GSM in quad-band (850/900/1800/1900MHz), UMTS in tri-band (850/900/2100MHz), LTE in five-band (B1/B3/B7/B8/B20).
This equipment is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The entire copy of the Declaration of Conformity for your telephone can be obtained through our website: www.alcatelonetouch.com.
Protection against theft
Your telephone is identified by an IMEI (phone serial number) shown on the packaging label and in the phone’s memory. We recommend that you note the number the first time you use your telephone by entering * # 0 6 # and keep it in a safe place. It may be requested by the police or your operator if your telephone is stolen. This number allows your mobile telephone to be blocked preventing a third person from using it, even with a different SIM card.
(1)
(1)
It may not available according to the countries.
11 12
(1)
Contact your network operator to check service availability.
Disclaimer
There may be certain differences between the user manual description and the phone’s operation, depending on the software release of your telephone or specific operator services.
TCT Mobile shall not be held legally responsible for such differences, if any, nor for their potential consequences, which responsibility shall be borne by the operator exclusively.
This handset may contain materials, including applications and software in executable or source code form, which is submitted by third parties for inclusion in this handset (“Third Party Materials”). All third party materials in this handset are provided “as is”, without warranty of any kind, whether express or implied, including the implied warranties of merchantability, fitness for a particular purpose or use/third party application, interoperability with other materials or applications of the purchaser and non-infringement of copyright. The purchaser undertakes that TCT Mobile has complied with all quality obligations incumbent upon it as a manufacturer of mobile devices and handsets in complying with Intellectual Property rights. TCT Mobile will at no stage be responsible for the inability or failure of the Third Party Materials to operate on this handset or in interaction with any other devices of the purchaser. To the maximum extent permitted by law, TCT Mobile disclaims all liability for any claims, demands, suits or actions, and more specifically – but not limited to – tort law actions, under any theory of liability, arising out of the use, by whatever means, or attempts to use, such Third Party Materials. Moreover, the present Third Party Materials, which are provided free of charge by TCT Mobile, may be subject to paid updates and upgrades in the future; TCT Mobile waives any responsibility regarding such additional costs, which shall be borne exclusively by the purchaser. The availability of the applications may vary depending on the countries and the operators where the handset is used; in no event shall the list of possible applications and software provided with the handsets be considered as an undertaking from TCT Mobile; it shall remain merely as information for the purchaser. Therefore, TCT Mobile shall not be held responsible for the lack of availability of one or more applications wished for by the purchaser, as its availability depends on the country and the operator of the purchaser. TCT Mobile reserves the right at any time to add or remove Third Party Materials from its handsets without prior notice; in no event shall TCT Mobile be held responsible by the purchaser for any consequences that such removal may have on the purchaser regarding the use or attempt to use such applications and Third Party Materials.
Your mobile ���������������������������
1

1�1 Keys and connectors

Headset connector
LED indicator
Touch screen
Menu key
Home key
Back key
Micro-USB Connector
Power key
Front camera
Volume key
13 14
Camera
Camera Flash/Flashlight
Back key
•Touch to go back to the previous screen, or to close a dialog
box, options menu, the notification panel, etc.
Home key
•Touch to return to the Home screen from any other screen
or application.
Menu key
•Touch to access settings options.
•Touch and hold to open a list of thumbnail images of apps
you've worked with recently.
These keys are visible when the screen lights up.
Power key
•Press: Lock the screen/Light up the screen.
•Press and hold: Show the pop-up menu to select from Power off/
Restart/Airplane mode/Quick start.
•Press the Power key for more than 9s to restart.
•Press the Power key and Volume up key to reset.
•Press the Power key and Volume down key to capture a
screenshot.
Volume Keys
•In call mode, adjusts the earpiece or headset volume.
•In Music/Video/Streaming mode, adjusts the media volume.
•In general mode, adjusts the ringtone volume.
•Mutes the ringtone of an incoming call.
15 16

1�2 Getting started

1�2�1 Set-up
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Please power off your phone before inserting or removing the SIM card.
To install, place the SIM card with the chip facing downwards into the housing, and then slide it into its slot. Make sure that it is correctly inserted. Slide it out to remove the SIM card.
Installing and removing the microSD card
Insert the microSD card with the golden contact facing downwards into the slot. Slide it out to remove the microSD card.
To avoid data loss and SD card damage, before removing the SD
card, please ensure that the SD card is unmounted (Settings\ Storage\Unmount SD card).
17 18
Installing or removing the battery
•To install, insert and click the battery into place, then close the phone
cover.
•To remove the battery, first power the phone off. Then unclip the cover
and remove the battery.
Charging the battery
Connect the battery charger to your phone and mains socket respectively, the LED indicator will light while charging.
•Make sure the battery is correctly inserted before connecting the
charger.
•When using your telephone for the first time, charge the battery fully
(approximately 3 hours).
You are advised to fully charge the battery ( ). Charging status is indicated by a percentage displayed on screen while the phone is powered off. The percentage increases as the phone is charged.
To reduce power consumption and energy waste when the battery
is fully charged, disconnect your charger from the plug; switch off Wi-Fi, GPS, Bluetooth or background-running applications when not in use; reduce the backlight time, etc.
1�2�2 Power on your phone
Hold down the Power key until the phone powers on, unlock your phone (Slide, PIN, Password, Pattern or Face unlock) if necessary and confirm. The Home screen is displayed.
If you do not know your PIN code or if you have forgotten it, contact your network operator. Do not leave your PIN code with your phone. Store this information in a safe place when not in use.
Set up your phone for the first time
The first time you power on the phone, you should set the following options:
•Select the phone's language, then touch .
•Select the input method, then touch .
•Set your Mobile Data Connection, then touch .
•Set your Date & time, then touch .
19 20
• Setup Google Account: If you want to set your Google Account, touch
Setup Now. If you have a Google Account, touch Existing, then enter your Email address and password. If you've forgotten your password, you can go to http://www.google.com to retrieve it. If you don’t own a Google Account, you are prompted to create one by touching New.
•The Setup complete screen will display, touch to confirm.
Even if no SIM card is installed, your phone will still power on and you will be able to connect to a Wi-Fi network, (refer to section “6�1�2 Wi-Fi”), sign into your Google account and use some features.
The Home screen is provided in an extended format to allow more space for adding applications, shortcuts etc. Slide the Home screen horizontally left and right to get a complete view.
1�3�1 Using the touchscreen
Touch
To access an application, touch it with your finger.
1�2�3 Power off your phone
Hold down the Power key from the Home screen until the phone options appear, select Power off.

1�3 Home screen

You can bring all the items (applications, shortcuts, folders and widgets) you love or use most frequently to your Home screen for quick access. Touch the Home key to switch to the Home screen.
Status bar
• Status/Notification indicators
• Touch and drag down to open the notification panel.
Touch an icon to open an application, folder, etc.
Favourite tray applications
• Touch to enter the application.
• Touch and hold to move or change applications.
Application tab
• Touch to open main menu.
21 22
Touch and Hold
To enter the available options for an item, touch and hold the item. For example, select a contact in Contacts, touch and hold this contact, an options list will then appear on screen.
Drag
Place your finger on the screen to drag an object to another location.
Slide/Swipe
Slide the screen to scroll up and down the applications, images, web pages… at your convenience. You can slide the screen horizontally too.
The device also supports one finger zooming in the Messaging, Browser, Email, Camera and Gallery functions. Double tap the screen then slide with one finger to zoom in/out.
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place the fingers of one hand on the screen surface and draw them apart or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to landscape by turning the phone sideways to have a better screen view.
1�3�2 Status bar
From the status bar, you can view both phone status and notification information.
Status icons
GPRS connected Airplane mode
GPRS in use Alarm is set
EDGE connected Speakerphone is on
EDGE in use Roaming
3G connected Signal strength
3G in use No signal
HSPA (3G+) connected No SIM card installed
HSPA (3G+) in use Vibrate mode
HSPAP connected Ringer is silenced
HSPAP in use Phone microphone is muted
4G connected Battery is very low
4G in use Battery is low
Wi-Fi is on Battery is partially drained
Connected to a Wi-Fi network
Bluetooth is on Battery is charging
Connected to a Bluetooth device
NFC is on (Only 5050Y supports)
Battery is full
/
Headset connected
23 24
Notification icons
New Gmail message Missed call
Touch and drag down the Status bar to open the Quick setting panel or Notification panel. Touch and drag up to close it. When there are notifications, touching them allows you to access their information directly.
New Email message Call forwarding is on
New text or multimedia message
Problem with SMS or MMS delivery
New Google Hangouts message
Song is playing
Connected to VPN
Disconnected from VPN
New voicemail Radio is on
Upcoming event Uploading data
Screenshot error Downloading data
Screenshot captured Download finished
microSD card is full Select input method
Safe to remove SD card
Phone is connected via USB cable
Preparing SD card System update available
Both USB tethering and portable hotspot are on
Carrier data use threshold approaching or exceeded
USB tethering is on GPS is on
Portable Wi-Fi hotspot is on
Receiving location data from GPS
An open Wi-Fi network is available
Quick setting panel
Touch and drag down the Status bar to open the Quick setting panel, where you can enable or disable functions or change modes by touching the icons.
Touch to switch to the notification panel.
Touch to access Settings, where you can set more items.
Notification panel
When there are notifications, touch and drag down the Status bar to open the Notification panel and read their information in detail.
Touch to open quick settings bar and enable/disable functions or change modes.
Touch to clear all event–based notifications (other ongoing notifications will remain).
25 26
1�3�3 Search bar
The phone provides a Search function which can be used to locate information within applications, the phone or the web.
Search by text
• Touch the Search bar from the Home screen.
•Enter the text/phrase you want to search for.
•Touch the icon on the keyboard if you want to search on the web.
Search by voice
•Touch from the Search bar to display a dialog screen.
•Speak the word/phrase you want to search for. A list of search results
will display for you to select from.
1�3�4 Lock/Unlock your screen
To protect your phone and privacy, you can lock the phone screen by choosing slide or creating a variety of patterns, PIN or password, etc.
To create a screen unlock pattern (refer to section "Screen lock" for detailed settings)
•Touch the Menu key from the Home screen, then touch Settings\
Security\Screen lock\Pattern.
•Draw your own pattern.
Draw your unlock pattern
Touch to confirm by drawing pattern again
To create a screen unlock PIN/Password
•Touch the Menu key from the Home screen, then touch Settings\
Security\Screen lock\PIN or Password�
•Set your PIN or password.
To lock the phone screen
Press the Power key once to lock the screen.
To unlock the phone screen
Press the power key once to light up the screen, draw the unlock pattern you have created or enter your PIN or password, etc. to unlock the screen.
27 28
If you have chosen Slide as the screen lock, you can:
•double tap the screen to unlock it if it is dark (when Settings\Lock
settings\Screen lock\Double click screen is active);
•press the Power key to light up the screen first, then slide right to unlock
the screen or slide left to enter Camera mode.
1�3�5 Personalize your Home screen
Add
You can touch and hold a folder, an application or a widget to activate the Move mode, and drag the item to your preferred Home screen.
Reposition
Touch and hold the item to be repositioned to activate the Move mode, drag the item to the desired position and then release. You can move items both on the Home screen and the Favourite tray. Hold the icon on the left or right edge of the screen to drag the item to another Home screen.
Create folders
To improve the organization of items (shortcuts or applications) on the Home screen and the Favourite tray, you can add them to a folder by stacking one item on top of another. To rename a folder, open it and touch the folder’s title bar to input the new name.
Wallpaper customization
Touch the Menu key on the Home screen then touch Set wallpaper to customize wallpaper.
1�3�6 Widgets and recently-used applications
Consult widgets
Touch and hold an empty area in the Home screen to display all widgets at the bottom of the Home screen.
Touch the empty area to return to the original Home screen view.
Consult recently-used applications
To consult recently-used applications, touch and hold the Menu key from the Home screen. Touch a thumbnail in the window to open the related application.
Remove
Touch and hold the item to be removed to activate the Move mode, drag the item up to the top of the icon, and release after the item turns red.
29 30
Slide horizontally to view all thumbnails of recently-used applications.
Touch one thumbnail and slide it upwards to delete it and downwards to lock the thumbnail.
Touch the icon at the bottom of the screen to activate the system's one key boost which clears memory used by recent applications. If a thumbnail is locked its memory will not be cleared.
1�3�7 Volume adjustment
Using the Volume key
Press the Volume key to adjust the volume. To active the vibrate mode, press the Volume down key until the phone vibrates. Press the Volume
down key once more to activate silent mode.
Using Settings menu
Touch the Menu key from the Home screen, then touch Settings\ Sound\Volumes to set the volume of media, ringtone, alarm, etc. to your
preference.
Text input ������������������������������
2

2�1 Using the Onscreen Keyboard

Onscreen Keyboard settings Touch the Menu key from the Home screen, select Settings\Language
& input, touch the Settings icon on the right of Android keyboard,
and a series of settings will become available for your selection.
Adjust the Onscreen Keyboard orientation
Turn the phone sideways or upright to adjust the Onscreen Keyboard orientation. You can also adjust it by changing the settings (touch the Menu key on the Home screen, then touch Settings\Display\Auto-rotate
screen).
2�1�1 Android keyboard
Touch to enter text or numbers.
Touch to switch between
"abc/Abc" mode;
Touch & hold to switch
to "abc/ABC" mode.
Touch to switch
between symbol and
numeric keyboard.
Touch to enter voice input; touch & hold to show input options.
Touch & hold to select symbols/emoticons.
31 32

2�2 Text editing

You can edit the text you have entered.
•Touch and hold or double-tap within the text you would like to edit.
•Drag the tabs to change the highlighted selection.
•The following options will appear: Select all , Cut , Copy
and Paste .
•Touch the icon to go back without any action.
Phone call, Call log and
3
Contacts ��������������������������������
3�1 Phone �����������������������������������������������������������
3�1�1 Placing a call
You can easily launch a call by using Phone. Touch the icon on the home screen to access the Phone application.
You can also insert new text if preferred
•Touch where you want to type, or touch and hold the blank area. The
cursor will blink and the tab will appear. Drag the tab to move the cursor.
•If you have selected any text, touch the tab to show the PASTE and
REPLACE icon which allows you to complete pasting immediately.
33 34
Display the suggested
Enter the desired number from the keyboard directly or select a contact from Contacts or Call log by sliding or touching tabs, then touch
The number you entered can be saved to Contacts by touching the key and touching Create new contact.
If you make a mistake, you can delete the incorrect digits by touching .
To hang up a call, touch or the Power key (when the Call settings\Power key ends call option is activated).
number(s).
Touch and hold to
access voicemail.
Touch to hide/
display keyboard
to place the call.
Touch to call the previewed number
Slide to access Call log and Contacts.
Speed dial settings
You can access this setting screen by touching the Menu key and then touching Speed dial on the Dial screen. Select contacts to define the 2-9 screen keys as a speed dialer.
International call
To dial an international call, touch and hold to enter “+”, then enter the international country prefix followed by the full phone number and finally touch .
Emergency call
If your phone has network coverage, dial the emergency number and touch
to make an emergency call. This works even without a SIM card
and without typing the PIN code.
To mute the ringtone volume of an incoming call, press the Volume up/
down key or turn over the phone (when the Call settings\Turn over to mute option is activated).
3�1�3 Calling your voicemail
Your voicemail is provided by your network to avoid missing calls. It works like an answering machine that you can consult at any time.
To access your voicemail, touch and hold on the Phone tab.
To set your voicemail number, touch the Menu key from the Dial screen, then touch Settings\Voicemail\Voicemail settings\Voicemail number.
If you receive a voicemail, a voicemail icon appears on the Status bar. Open the Notification panel and touch New voicemail.
3�1�2 Answering or rejecting a call
When you receive a call:
•Slide the icon to the right to answer;
•Slide the icon to the left to reject;
•Slide the icon upwards to reject the call by sending a preset message.
35 36
3�1�4 During a call
To adjust the volume during a call, press the Volume up/down key.
Touch to end the current call.
Touch to display the Dialpad.
Touch to activate the speaker during the current call. Touch this icon again to deactivate the speaker.
Touch to mute the current call. Touch this icon again to unmute the call.
Touch to hold the current call. Touch this icon again to retrieve the call.
Touch to start recording.
Touch to add a call, find Contacts or open Bluetooth mode.
To avoid accidental operation of the touchscreen during a call, the
screen will be locked automatically when you put the cellphone close to your ear; it will be unlocked when the cellphone is taken away from your ear.
3�1�5 Managing multiple calls
With this phone you can handle multiple calls at the same time.
Swap calls
When you accept two calls, touch the icon, you can now switch between two lines. The current call will be put on hold and you are able to join the other call.
Conference calls
You can set up a conference call as follows:
•Place a call to the first participant of the conference call.
(1)
•Touch the icon .
•Touch Add call to type a number. Then touch the icon and
click and Merge calls to start the conference.
•Touch to end the conference call and disconnect all callers.
3�1�6 Call settings
Touch the Menu key from the dial screen, then touch Settings. The following options are available:
Voicecall settings
• Call forwarding: Touch to configure how your calls are forwarded
when you are busy, unanswered or unreachable.
• Additional settings:
Caller ID: Touch to use default operator settings to display your number in outgoing calls.
Call waiting: Mark the check box to notify you of new incoming calls during a call.
Call waiting status: Check the call waiting status of your phone.
Voicemail settings
• Voicemail
Voicemail service: Opens a dialog box where you can select your carrier’s voicemail service or another service.
Voicemail settings: If you are using your carrier’s voicemail service, this opens a dialog box where you can enter the phone number to use for listening to and managing your voicemail. You can enter a comma (,) to insert a pause into the number — for example, to add a password after the phone number.
(1)
Depending on your network operator.
37 38
Other call settings
• Fixed Dialing Numbers: Fixed Dialing Number (FDN) is a SIM service
mode, where outgoing calls are restricted to a set of phone numbers. These numbers are added to the FDN list. The most common practical application of FDN is for parents to restrict the phone numbers to which their children can dial. For security reasons, you’ll be prompted to enable FDN by entering SIM PIN2 which is usually acquired from your service provider or SIM maker.
• Service Dialing Numbers: You can place a call from the SDN list.
• Dial pad touch tones: Mark the checkbox to enable playing tones
when using dial pad.
• Quick responses: Touch to edit quick responses which will be used
when you reject a call with messages.
• Vibrate reminder: Mark the checkbox to enable vibration when the
call is connected.
• Turn over to mute: Marking the checkbox lets you mute the incoming
calls by turning the phone over.
• Power key ends call: Mark the checkbox to end a call by pressing the
Power key during the call.
• Hearing aids: Hearing aid mode can be used by people who are deaf,
have poor hearing or speech impairments. After connecting the phone and Hearing aid device, calls are linked to a relay service, which converts incoming speech to text for the person using the Hearing aid and converts outgoing text from the Hearing aid machine to a spoken voice for the person on the other end of the conversation.
• Noise Cancellation: Mark the checkbox to reduce the background
noise.
• Pocket mode: Mark the checkbox to increase ringtone volume and
active vibrate mode when device is in a pocket or bag.
• TTY mode: TTY mode can be used by people who are deaf, have poor
hearing or speech impairments.

3�2 Call log

You can access your call memory by touching from the Dial screen. Touch on the right side of a contact/number to place a call directly.
Touch a contact or number to view information or further operations.
You can view detailed information of a call, launch a new call or send messages to a contact or number, or add numbers to Contacts, etc.
To clear the entire call memory, touch the Menu key and Clear call log.
3�3 Contacts�������������������������������������������������������
Contacts enables quick and easy access to the people you want to reach.
You can view and create contacts on your phone and synchronize these with your Gmail contacts or other applications on the web or on your phone.
3�3�1 Consult your Contacts
To access this feature, touch from the Home screen, then select Contacts.
Touch to view your
contact groups
Touch image to open Quick Contact panel.
Touch to search in
Contacts
Touch to view your favourite contacts.
Touch to view the contact’s detailed information.
Touch to add new contact.
39 40
Loading...
+ 49 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
