Alcatel One Touch 505 User Guide
OT-305
OT-505
OT-508
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:00 Page 1
7 Settings ........................................................................32
7.1 Color ....................................................................................................32
7.2 Display..................................................................................................32
7.3 Clock ....................................................................................................33
7.4 Keys ......................................................................................................34
7.5 Home screen ......................................................................................34
7.6 Call register ........................................................................................35
7.7 More settings... ..................................................................................38
8 Bluetooth™ ..................................................................41
9 Tools..............................................................................43
9.1 Calendar ..............................................................................................43
9.2 Alarm....................................................................................................43
9.3 Calculator ............................................................................................43
9.4 Converter............................................................................................44
9.5 Voice memo........................................................................................44
9.6 Fake call................................................................................................45
9.7 Memory status....................................................................................45
9.8 My shortcuts ......................................................................................45
10 WAP..............................................................................46
10.1 Homepage ..........................................................................................46
10.2 Bookmarks ..........................................................................................46
10.3 Recent pages ......................................................................................46
10.4 Offline pages ......................................................................................46
10.5 Go to URL ..........................................................................................46
10.6 Profiles..................................................................................................46
11 File manager ................................................................48
11.1 My audios ............................................................................................48
11.2 My images ............................................................................................48
11.3 My creations ......................................................................................49
11.4 Unknown files ....................................................................................49
11.5 Managing audios and images ..........................................................49
11.6 Formats and compatibility ..............................................................50
11.7 Memory card ......................................................................................51
11.8 Memory status....................................................................................51
2
Table of contents........................
Safety and use......................................................................4
General information............................................................9
1 Your mobile..................................................................11
1.1 Keys ......................................................................................................12
1.2 Main screen icons..............................................................................14
2 Getting started ............................................................16
2.1 Set-up ..................................................................................................16
2.2 Power on your phone ......................................................................18
2.3 Power off your phone ......................................................................18
3 Calls ..............................................................................19
3.1 Making a call........................................................................................19
3.2 Calling your voicemail ......................................................................19
3.3 Receiving a call ..................................................................................20
3.4 During the call....................................................................................21
3.5 Conference calls ................................................................................22
3.6 Line switching (ALS) ........................................................................22
4 Menu..............................................................................23
5 Directory ......................................................................24
5.1 Consulting your directory ..............................................................24
5.2 Adding a contact................................................................................26
5.3 Available options................................................................................26
6 Messages ......................................................................28
6.1 Messages: Text/Multimedia message ............................................28
6.2 Voice message ....................................................................................30
6.3 Voicemail ............................................................................................30
6.4 Settings ................................................................................................30
1
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:00 Page 1
Safety and use ............................
We recommend that you read this chapter carefully before using your phone. The manufacturer
disclaims any liability for damage, which may result as a consequence of improper use or use
contrary to the instructions contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a mobile phone while driving a vehicle constitutes a real risk,
even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from
using their mobile when the vehicle is not parked.
When driving, do not use your phone and headphone to listen to music or to the radio. Using a
headphone can be dangerous and forbidden in some areas.
When switched on, your phone emits electromagnetic waves that can interfere with the vehicle's
electronic systems such as ABS anti-lock brakes or airbags. To ensure that there is no problem:
- do not place your phone on top of the dashboard or within an airbag deployment area,
- check with your car dealer or the car manufacturer to make sure that the dashboard is
adequately shielded from mobile phone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the telephone from time to time to optimise its performance.
Switch the phone off before boarding an aircraft.
Switch the phone off when you are in health care facilities, except in designated areas. As with
many other types of equipment now in regular use, mobile telephones can interfere with other
electrical or electronic devices, or equipment using radio frequency.
Switch the phone off when you are near gas or flammable liquids. Strictly obey all signs and
instructions posted in a fuel depot, petrol station, or chemical plant, or in any potentially explosive
atmosphere.
When the phone is switched on, it should be kept at least 15 cm from any medical device such as
a pacemaker, a hearing aid or insulin pump, etc. In particular when using the phone, you should
hold it against the ear on the opposite side to the device, if any.
To avoid hearing impairment, pick up the call before holding your phone to your ear. Also move
the handset away from your ear while using the "hands-free" mode because the amplified volume
might cause hearing damage.
Do not let children use the phone and/or play with the telephone and accessories without
supervision.
When replacing the cover please note that your phone may contain substances that could create
an allergic reaction.
Always handle your phone with care and keep it in a clean and dust-free place.
Do not allow your phone to be exposed to adverse weather or environmental conditions
(moisture, humidity, rai n, infiltra tion of liquids, dust, sea air , etc). The manufacturer's
recommended operating temperature range is -10° C to +55°C.
4
12 Music Player ................................................................52
12.1 Music ....................................................................................................52
12.2 Settings ................................................................................................53
13 FUN ..............................................................................54
13.1 Games ..................................................................................................54
13.2 FM radio ..............................................................................................54
13.3 File manager ........................................................................................55
13.4 Music player ........................................................................................55
14 Camera ........................................................................56
14.1 Access ..................................................................................................56
14.2 Camera ................................................................................................56
15 Profiles ..........................................................................58
15.1 General ................................................................................................58
15.2 Vibration ..............................................................................................59
15.3 Outdoor ..............................................................................................59
15.4 Silence ..................................................................................................59
15.5 Flight mode ........................................................................................59
16 Latin input mode ........................................................60
17 Telephone warranty ....................................................64
18 Accessories ..................................................................66
19 Troubleshooting ..........................................................67
3
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:00 Page 3
• PRIVACY:
Please note that you must respect the laws and regulations in force in your jurisdiction or other
jurisdiction(s) where you will use your mobile phone regarding taking photographs and recording
sounds with your mobile telephone. Pursuant to such laws and regulations, it may be strictly
forbidden to take photographs and/or to record the voices of other people or any of their personal
attributes, and duplicate or distribute them, as this may be considered to be an invasion of privacy.
It is the user's sole responsibility to ensure that prior authorisation be obtained, if necessary, in
order to record private or confidential conversations or take a photograph of another person; the
manufacturer, the seller or vendor of your mobile phone (including the operator) disclaim any
liability which may result from the improper use of the mobile phone.
• BATTERY:
Before removing the battery from your phone, please make sure that the phone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery,
- Do not burn or dispose of a used battery in household rubbish or store it at temperatures above
60 ° C.
Batteries must be disposed of in accordance with locally applicable environmental regulations. Only
use the battery for the purpose for which it was designed. Never use damaged batteries or those
not recommended by TCT Mobile Limited and/or its affiliates.
This symbol on your telephone, the battery and the accessories means that these
products must be taken to collection points at the end of their life:
- Municipal waste disposal centres with specific bins for these items of equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the environment, so that
their components can be reused.
In European Union countries:
These collection points are accessible free of charge.
All products with this sign must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not to be thrown into ordinary bins if your jurisdiction
or your region has suitable recycling and collection facilities; instead they are to be taken to
collection points for them to be recycled.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
• CHARGERS
Mains powered chargers will operate within the temperature range of: 0 ° C to 40 ° C.
The chargers designed for your mobile phone meet with the standard for safety of information
technology equipme nt and office equipme nt use. Due to differen t applica ble electrical
specifications, a charger you purchased in one jurisdiction may not work in another jurisdiction.
They should be used for this purpose only.
6
Over 55° C the legibility of the phone's display may be impaired, though this is temporary and not
serious.
Emergency call numbers may not be reachable on all cellular networks. You should never rely only
on your phone for emergency calls.
Do not open, dismantle or attempt to repair your mobile phone yourself.
Do not drop, throw or bend your mobile phone.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended by TCT Mobile
Limited and its affiliates and are compatible with your phone model (see Accessories List, page 66).
TCT Mobile Limited and its affiliates disclaim any liability for damage caused by the use of other
chargers or batteries.
Remember to make back-up copies or keep a written record of all important information stored
in your phone.
Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when
playing video games. These seizures or blackouts may occur even if a person never had a previous
seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history
of such occurrences, please consult your doctor before playing video games on your phone or
enabling a flashing-lights feature on your phone.
Parents should monitor their children's use of video games or other features that incorporate
flashing lights on the phones. All persons should discontinue use and consult a doctor if any of the
following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation. To limit the likelihood of such symptoms, please take the following
safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15-minute break hourly.
- Play in a room in which all lights are on.
- Play at the farthest distance possible from the screen.
- If your hands, wrists, or arms become tired or sore while playing, stop and rest for several hours
before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing, stop the game and
see a doctor.
When you play games on your phone, you may experience occasional discomfort in your hands,
arms, shoulders, neck, or other parts of your body. Follow the instructions to avoid problems such
as tendinitis, carpal tunnel syndrome, or other musculoskeletal disorders.
Prolonged exposure to music at full volume on the music player may damage the listener's
hearing.
Set your phone volume safely. Use only headphones recommended by TCT Mobile Limited and its
affiliates.
5
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:00 Page 5
The highest tested SAR value for this mobile phone for use at the ear and compliance against the
standard is 1.2 W/kg (OT-305/OT-505). While there may be differences between the SAR levels
on various phones and at various positions, they all meet the relevant International guidelines and
EU requirements for RF (radio-waves) exposure.
The World Health Organisation (WHO) considers that present scientific information does not
indicate the need for any special precautions for use of mobile phones. If individuals are concerned,
they might choose to limit their own or their children's RF exposure by limiting the length of calls,
or using "hands-free" devices to keep mobile phones away from the head and body (fact sheet n°
193). Additional information about electromagnetic fields and public health are available on the
following site: http://www.who.int/peh-emf.
Although no danger relating to the use of telephone was ever proved, the World Health
Organisation advises as a precautionary measure to use your telephone with a good level of
network reception as indicated on the telephone display (4 to 5 bars). It is also advised to keep
the telephone, during communications, away from the belly of pregnant women and from the
lower abdomen for teenagers.
Your telephone is equipped with a built-in antenna. For optimal operation, you should avoid
touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions other than against your
ear. In such circumstances the device will be compliant with the guidelines when used with headset
or usb data cable. If you are using another accessory ensure that whatever product is used is free
of any metal and that it positions the phone at least 2cm away from the body.
• LICENCES
Obigo® is a registered trademark of Obigo AB.
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by TCT Mobile Limited and its affiliates is under
license. Other trademarks and trade names are those of their respective
owners.
OT-505/OT-508 Bluetooth QD ID B013793
eZiText™and Zi™ are trademarks of Zi Corporation and/or its Affiliates.
8
• RADIO WAVES:
Proof of compliance with international standards (ICNIRP) or with European Directive 1999/5/EC
(R&TTE) is required of all mobile phone models before they can be put on the market. The
protection of the health and safety for the user and any other person is an essential requirement
of these standards or this directive.
THIS MOBILE PHON E COMPL IES WIT H INTERNATIONAL AND EUROPEAN
REQUIREMENTS REGARDING EXPOSURE TO RADIO WAVES.
Your mobile phone is a radio transmitter/receiver. It was designed and manufactured to comply
with the radiofrequency (RF) exposure thresholds recommended by international requirements
(ICNIRP)
(1)
and by the Council of the European Union (Recommendation 1999/519/EC)
(2)
.
These limits are part of a set of requirements and establish authorised radiofrequency levels for
the public. These limits were established by independent groups of experts on the basis of regular
and detailed scientific assessments. They include a significant safety margin intended to ensure the
safety of all, regardless of age or state of health.
The exposure standard for mobile phones is determined by a measurement unit known as the
Specific Absorption Rate or "SAR". The SAR limit is set by international requirements or by the
Council of the European Union at 2 watts/kilogram (W/kg) averaged over 10 grams of body tissue.
The tests used to determine SAR levels were carried out on the basis of standard usage modes
with the phones transmitting at their maximum power level over the entire range of frequency
bands.
Although the SAR was established at the highest certified level, the actual SAR level for the mobile
phone during use is generally much lower than the maximum values. In fact, since mobile phones
are designed to operate at many different power levels, they only use the minimum level of power
required to provide a connection to the network. In theory, the closer you are to a base station
antenna, the lower the power level required by the mobile phone.
7
(1)
The ICNIRP requirements are applicable in the following regions: Central
America (except Mexico), South America, North and South Africa, Pacific Asia
(except Korea), Australia.
(2)
The European recommendation (1999/519/EC) is applicable in the following
regions: Europe, Israel.
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:00 Page 7
Protection against theft
(1)
Your telephone is identified by an IMEI (phone serial number) shown on
the packaging label and in the product's memory. We recommend that
you note the number the first time you use your telephone by entering
* # 0 6 # and keep it in a safe place. It may be requested by the police or
your operator if your telephone is stolen. This number allows your mobile
telephone to be blocked preventing a third person from using it, even with
a different SIM card.
Disclaimer
There may be certain differences between the user manual description
and the phone's operation, depending on the software release of your
telephone or specific operator services.
10
(1)
Contact your network operator to check service availability.
General information ..................
• Internet address: www.alcatel-mobilephones.com
• Hot Line Number: see "TCT Mobile Services" leaflet or go to our
Internet site.
On our Internet site, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you may
have.
An electronic version of this user guide is available in English and other
languages according to availability on our server: www.alcatelmobilephones.com
Your telephone is a transceiver that operates on GSM networks with 900
and 1800 MHz bands.
This equipment is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC. The entire copy of the
Declaration of Conformity for your telephone can be obtained through
our website: www.alcatel-mobilephones.com.
9
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:00 Page 9
1.1 Keys
Navigation key
(1)
Confirm an option (press the middle of the key)
Access wallpaper settings (long keypress)
Pick up
Send a call
Access call memory (Redial) (short keypress)
Switch on/Switch off the telephone (long keypress)
End call
Return to the main screen
Left softkey
Right softkey
1211
1
Your mobile ..........................
OT-305 OT-505/OT-508
1
2
3
4
5
6
7
Left softkey
Pick up/Send call
Call memory
Voicemail
Right softkey
Switch on/Switch off
End call
Vibration alert
Navigation key
(1) (2)
:
Menu/Confirm an option
Directory
Profiles
Camera
Calendar
Lock/Unlock
Switch on LED torch (long keypress)
Switch off LED torch (press any key)
Activate fake call (long keypress)
10
9
8
2
7
6
5
4
3
1
(1)
Depending on your network operator.
(2)
Disabled when "Homescreen" is on.
8
1
2
3
4
5
6
7
8
10
9
10
9
(1)
Depending on your network operator.
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:01 Page 11
1.2 Main screen icons
(1)
Battery charge level.
Vibration alert: your phone vibrates, but neither rings nor
beeps except for the alarms (see page 59).
Bluetooth is active
(3)
.
Bluetooth connected to an audio device
(3)
.
Headset connected.
Call forwarding activated: your calls are forwarded (see page
36).
Alarm clock programmed (see page 43).
Voicemail message arrived.
FM radio is on.
Missed calls.
WAP alerts
(2)
.
Roaming.
Line switching
(2)
: indicates the selected line.
GPRS active connection status (Blue - Activated).
Shown only in no ciphering mode while calling, sending/receiving
SMS.
14
(1)
The icons and illustrations in this guide are provided for
informational purposes only.
(2)
Depending on your network operator.
(3)
OT-505/OT-508 only.
Access your voicemail (long keypress)
In Edit mode:
- Short keypress: change input methods
- Long keypress: access the Symbols table
From main screen
- Short keypress: #
- Long keypress: activate/deactivate the vibrator
In Edit mode:
- Short keypress: (space)
- Long keypress: add a word
Camera key
(1)
: access "Camera" (short keypress)
Music key
(2)
: access "Music player" (short keypress)
13
(1)
OT-305 only.
(2)
OT-505 only.
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:01 Page 13
2
Getting started ....................
2.1 Set-up
Removing/Replacing the back cover
16
Level of network reception.
Reception of a message in progress.
Sending a message.
Silence mode: your phone neither rings, beeps nor vibrates
except for the alarms (see page 59).
Message unread.
Message list is full: your terminal cannot accept any new
messages. You must access the message list and delete at least one
message on your SIM card.
SIM card unavailable.
Memory card scanning in progress.
Memory card scanning completed.
Flight mode.
15
Installing/Removing the battery
Insert and click the battery into place, then close the telephone cover.
Unclip the cover, then remove the battery.
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:01 Page 15
• The charging may take about 20 minutes to start if the battery is flat.
• Be careful not to force the plug into the socket.
• Make sure the battery is correctly inserted before connecting the
charger.
• The mains socket must be near to the phone and easily accessible
(avoid electric extension cables).
• When using your telephone for the first time, charge the battery fully
(approximately 3 hours). You are advised to fully charge the battery
( ).
The charge is complete when the animation stops. Only use
Alcatel chargers.
2.2 Power on your phone
Hold down the key until the telephone powers on, type in your PIN
code if necessary and then confirm with the key. The main screen is
displayed.
If you don't know your PIN code or if you have forgotten it,
contact your network operator. Do not leave your PIN code
near your telephone, and store your card in a safe place when
not in use.
If cell broadcast messages are displayed, use the key to browse
through them in full or press the right softkey to return to the main
screen.
While the phone is searching for a network, "Searching/Emergency"
will be displayed.
2.3 Power off your phone
Hold down the key from the main screen.
18
Charging the battery
Connect the battery charger
17
(1)
Check with your network operator to make sure that your SIM card
is 3V compatible. The old 5 Volt cards can no longer be used. Please
contact your operator.
Inserting/Removing the the SIM card
You must insert your SIM card
(1)
to make phone calls.
Place the SIM card with the chip facing downwards and slide it
into its housing. Make sure that it is correctly inserted.
To remove the card, press it and slide it out.
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:01 Page 17
If the access number for your operator's voicemail service does not work,
dial the number that you were given. To change this number at a later
date, refer to "My numbers" (see page 35).
To use your voicemail service from abroad, contact your
network operator before leaving.
3.3 Receiving a call
When you receive an incoming call, press the key to talk and then hang
up using the key.
If the icon is displayed, the vibrator is activated and there is no
ringtone. If the icon is displayed, the phone neither rings nor vibrates.
The caller's number is displayed if it is transmitted by the
network (contact your network operator to check service
availability).
Muting the ringtone
Press the right softkey once while the telephone is ringing. Answer the call
by pressing the key.
Rejecting a call
Press the key once or the right softkey twice.
20
3
Calls ......................................
3.1 Making a call
Dial the desired number then press the key to place the call. If you
make a mistake, you can delete the incorrect digits by pressing the right
softkey.
To hang up the call, press the key.
To enter characters "+", "W" (for tonewait) or "P" (used to store
a number with extension number), hold down the key (the
following characters will scroll by: 0, +, P, W).
Making an emergency call
If your phone is covered by the network, dial emergency number and
press the key to make an emergency call. This works even without a
SIM card and without typing the PIN code or unlocking the keypad.
3.2 Calling your voicemail
(1)
Your voicemail is provided by your network to avoid missing calls. It
works like an answering machine that you can consult at any time. To
access your voicemail, hold down the key.
19
(1)
Contact your network operator to check service availability.
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:01 Page 19
3.5 Conference calls
(1)
Your phone allows you to talk to several people at the same time (up to
5). If you are on a double call, press "Options" and select "Conference"
then confirm with the key. If a third call comes in, answer it by pressing
the key and speak with your new correspondent.
This correspondent becomes a member of the conference if you press
"Options" and select "Add to conference", and then confirm by
pressing . Pressing disconnects the current call.
To end the conference call, press "Options" and select "End
conference".
3.6 Line switching (ALS)
(1)
Your SIM card can contain two distinct telephone numbers. Under "Call
register", choose "Line switching" and then select a default line; all
your outgoing calls will be made from this number. Incoming calls,
however, will continue to use the two lines.
The services programmed on the default line do not impact those
selected on the other line.
22
(1)
Contact your network operator to check service availability.
3.4 During the call
Available functions
During a call, you can use your directory, your diary, short messages, etc.
without losing your correspondent by pressing the key.
Call on hold
Ongoing call
Handsfree
WARNING: move the handset away from your ear while using
the "handsfree" option because the amplified volume might
cause hearing damage.
Directory
Messages
Calendar
Services
(1)
Sound recorder (record your current call).
Besides, you can switch the audio speech from handset to BT device when
connected.
Adjusting the volume
You can adjust the sound level during a call using the key.
Handling two calls
• Answering a second call (Ensure that "Call waiting" is activated, see
page 35).
• To call a second party during a call, dial the number directly.
21
(1)
Contact your network operator to check service availability.
IP2801_305_505_508_UM_EASY_Eng_GB_24_100125:303-360-363-383_UM_GB_14-04-09 2010-1-25 Tina10:01 Page 21
Loading...
