Thank you for buying ALCATEL ONETOUCH 6039Y. We hope you
will enjoy your high-quality mobile communication experience.
For more information about how to use your cellphone, please visit
www.alcatelonetouch.com to download the complete user manual.
From the website, you can consult the FAQ, perform software
upgrades, etc.
English - CJB34D0ALAAA
1
Table of contents
1 Your mobile ��������������������������������������������������������������������� 3
2 Text input ���������������������������������������������������������������������� 13
This product meets applicable national SAR
limits of 2.0W/kg. The specific maximum SAR
values can be found on page 30of this user
guide.
When carrying the product or using it while
worn on your body, either use an approved
www.sar-tick.com
2
accessory such as a holster or otherwise
maintain a distance of 15 mm from the body
to ensure compliance with RF exposure
requirements. Note that the product may
be transmitting even if you are not making a
phone call.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when holding
your device near your ear while the loudspeaker is in use.
Your mobile ������������������
1
1�1 Keys and connectors
Headset connector
LED indicator
Micro-USB Connector
Front camera
Touch screen
Back key
Home key
Menu key
3
Camera Flash/
Flashlight
Camera
Power
key
SIM card
slot/
microSD
card slot
Menu key
• Touch to view recently used applications.
Home key
• From any application or screen, touch to return to the
Home screen.
• Touch and hold to pop up Google search icon. Slide
your finger to the icon to open Google search.
Back key
• Touch to go back to the previous screen, or to close
a dialog box, options menu, the notification panel, etc.
These keys are visible when the phone is unlocked.
4
Volume
key
Power key
• Press: Lock the screen/Light up the screen.
• Press and hold: Show the pop-up menu to select from
Power off/Restart/Airplane mode.
• Press and hold the Powe r key and Volume up key
to reset.
• Press and hold the Powe r key and Volume down key
to capture a screenshot.
• Press and hold the power key for at least 10 seconds to
force reboot or hold it longer to power off.
Volume Keys
• In call mode, adjusts the earpiece or headset volume.
• In Music/Video/Streaming mode, adjusts the media
volume.
• In general mode, adjusts the ringtone volume.
• Mutes the ringtone of an incoming call.
• In camera preview mode, press Volume up or down
key to enter burst shoot.
5
1�2 Getting started
1�2�1 Set up
Inserting or removing the SIM/microSD card
You must insert your SIM card to make phone calls. You do not need
to power off your phone before inserting or removing the SIM card
as this phone can support hot swap.
Before you install or remove the SIM card or microSD card, use a pin
to press the small cavity until the card cassette pops out.
Your phone only supports micro-SIM cards. Do not
attempt to insert other SIM types like mini and nano cards;
otherwise this may cause damage to your phone.
Charging the battery
Connect the battery charger to your phone and wall socket
respectively, the LED indicator will light while charging.
To reduce power consumption and energy waste, when the
battery is fully charged, disconnect your charger; switch off
Wi-Fi, GPS, Bluetooth or background-running applications
when not in use; reduce the backlight time, etc .
6
1�2�2 Power on your phone
Hold down the Powe r key until the phone powers on. It will take a
few seconds before the screen lights up.
Set up your phone for the first time
The first time you power on the phone, you should set the following
options: Language, Google account, etc.
Even if no SIM card is installed, your phone will still power on and
you will be able to connect to a Wi-Fi network, sign into your Google
account and use some of the phone's features.
1�2�3 Power off your phone
Hold down the Power key from the Home screen until the phone
options appear, select Power off.
1�3 Home screen
You can move all of the items (applications, shortcuts, folders and
widgets) you use most frequently to your Home screen for quick
access. Touch the Home key to switch to the Home screen.
Status bar
• Status/Notification indicators
• Touch and drag down to open
the notification panel.
Search bar
• Touch to enter text search screen.
• Touch to enter voice search screen.
Touch an icon to open an application,
folder, etc.
Favourite tray applications
• Touch to enter the application.
• Touch and hold to move or
change applications.
Touch to enter application list.
The Home screen is provided in an extended format to allow more
space for adding applications, shortcuts etc. Slide the Home screen
horizontally left and right to get a complete view.
7
1�3�1 Using the touchscreen
Touch
To access an application, touch it with your finger.
Touch and Hold
Touch and hold the item to enter the available options.
Drag
Place your finger on the screen to drag an object to another location.
Slide/Swipe
Slide the screen up and down to scroll through the applications,
images, web pages, etc.
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place your fingers of one hand on the screen surface and draw them
apart or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to
landscape by turning the phone sideways to have a better view.
1�3�2 Status bar
From the status bar, you can view both phone status (to the right
side) and notification information (to the left side).
8
Status icons
GPRS connectedNo signal
GPRS in useAlarm is set
EDGE connectedBluetooth is on
EDGE in use
3G connected
3G in useRoaming
HSPA (3G+) connectedHeadset connected
HSPA (3G+) in useNo SIM card installed
HSPA+ connectedVibrate mode
HSPA+ in useBattery is very low
4G connectedBattery is low
4G in use
Signal strengthBattery is full
Wi-Fi is onBattery is charging
Connected to a Wi-Fi
network
Airplane mode
Connected to a
Bluetooth device
Speakerphone is on
Battery is partially
drained
GPS is on
9
Notification icons
New Gmail messageMissed call
New Email messageCall forwarding is on
New text or multimedia
message
Problem with SMS or
MMS delivery
New Google Hangouts
message
New voicemailUploading data
Upcoming eventDownload finished
Screenshot capturedSelect input method
Both USB tethering and
portable hotspot are on
USB tethering is on
Portable Wi-Fi hotspot
is on
More notifications are
hidden
Touch and drag down the Status bar to open the Quick setting panel
or Notification panel. Touch and drag up to close it. When there are
notifications, you can touch them to access notifications directly.
Song is playing
Connected to VPN
Radio is on
An open Wi-Fi network
is available
Phone is connected via
USB cable
System update available
Carrier data use
threshold approaching
or exceeded
10
Notification panel
When there are notifications, touch and drag down the Status bar
to open the Notification panel to read more detailed information.
Touch to switch to the quick setting panel.
Touch to clear all event–based
notifications (other ongoing
notifications will remain).
Quick setting panel
Touch and drag down the Notification panel or touch to open
the Quick setting panel. You can enable or disable functions or change
modes by touching the icons.
Touch to enter user screen.
Touch to access Settings, where you can
set more items.
11
1�3�3 Lock/Unlock your screen
To protect your phone and privacy, you can lock the phone screen by
creating a variety of patterns, PIN or password etc.
1�3�4 Personalise your Home screen
Add
You can touch and hold a folder, an application, or a widget to activate
tMove mode and drag the item to any Home screen you prefer.
Reposition
Touch and hold the item to be repositioned to activate Move mode,
drag the item to the desired position and then release. You can
move items both on the Home screen and the Favourite tray. Hold
the icon on the left or right edge of the screen to drag the item to
another Home screen.
Remove
Touch and hold the item to be removed to activate Move mode,
drag the item up to the top of the icon, and release after the
item turns red.
Create folders
To improve the organisation of items (shortcuts or applications) on
the Home screen, you can add them to a folder by stacking one item
on top of another. To rename a folder, open it and touch the folder’s
title bar to input the new name.
Wallpaper customisation
Touch Settings on the applications screen then touch Display\
Wallpaper to customise wallpaper.
1�3�5 Volume adjustment
You can set the ringer, media and phone ringtone volumes to your
preference by pressing the Volume up/down key, or touching Settings\Sound & notification\Media volume to set the volume.
12
