ICS Dissolvable Agent
for SafeGuard
Alcatel-Lucent Release 2.2
ICS Release 4.0
Administration Guide
PART NUMBER: 005-0030 REV A1
UBLISHED: MARCH 2007
P
A
LCATEL-LUCENT
26801 WEST AGOURA ROAD
CALABASAS, CA 91301 USA
(818) 880-3500
WWW.ALCATEL-LUCENT.COM
Alcatel-Lucent Proprietary
Copyright © 2007 Alcatel-Lucent. All rights reserved. This document may not be reproduced in whole
or in part without the expressed written permission Alcatel-Lucent. Alcatel-Lucent ® and the AlcatelLucent logo are registered trademarks of Alcatel-Lucent. All other trademarks are the property of their
respective owners.
2
ICS Dissolvable Agent for SafeGuard Administration Guide
Contents
Preface
About this Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Related Publications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Chapter 1: Introduction
Integrity Clientless Security Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Integrity Clientless Security Scanner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
ICSInfo Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Supported Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Unsupported Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Chapter 2: Prerequisites
End Point Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Supported Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Supported Browsers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Java Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Chapter 3: General Administration Tasks
Planning for Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Security Scenario . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Vulnerabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Risks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
End Point Users and Disruption Tolerance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Sample Solution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Understanding Security Lifecycles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Supporting the End Point User. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Logging In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Configuration Workflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
General Administration Tasks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Configuring ICS to Fail Open. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Configuring Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
ICS Dissolvable Agent for SafeGuard Administration Guide
3
Contents
Chapter 4: Administering Security Scanner Policies
Understanding Integrity Clientless Security Scanner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Implementing Policies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Understanding Enforcement Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Enforcement Rule Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Firewall Application Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Creating a Firewall Application Rule. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Anti-virus Application Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Creating an Anti-virus Application Rule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Anti-Spyware Scan Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Creating an Anti-spyware Rule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Custom Application Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Custom Group Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Creating Custom Group Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Creating Policies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Activating Policies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Chapter 5: Reports
Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Generating Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Access Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Security Scan Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Spyware Found. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Rules Broken . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Anti-Keylogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Chapter 6: The ICSInfo Utility
Troubleshooting End Point User Issues. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Obtaining Anti-virus Application Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Obtaining Application Checksums . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4
ICS Dissolvable Agent for SafeGuard Administration Guide
Preface
In this preface:
■ About this Guide
■ Related Publications
Preface
About this Guide
This preface provides an overview of Integrity Clientless Security (ICS) documentation as
implemented and integrated into the Alcatel-Lucent OmniAccess SafeGuard OS solution.
The ICS Dissolvable Agent for SafeGuard Administration Guide provides:
■ Prerequisites
■ Administration information, including background and task-oriented
administrative procedures
■ Information about using the various utilities included with Integrity Clientless
Security
This guide is tailored for running ICS only under OmniAccess SafeGuard OS. If you are
using a version of ICS available directly from Check Point Technologies, you should use
the documentation available from their Web site.
Related Publications
For additional ICS information, see the Online Help. The online help provides the field-
level information you need to understand the UI elements in the ICS Administrator
Console. The online help includes detailed information about what each element does
and what entries are valid. Use the online help after reading the procedural information
in the ICS for SafeGuard Administrator Guide. You can access the help from any page in
the ICS Administrator Console by clicking the help link.
For information about configuring and managing the OmniAccess SafeGuard Controller,
refer to the following guides:
■
OmniAccess SafeGuard Controller Installation Guide
Describes the OmniAccess SafeGuard Controller. The guide provides detailed
installation instructions and technical specifications for the OmniAccess
SafeGuard Controller.
■
OmniVista SafeGuard Manager Administration Guide
Describes how to manage the OmniAccess SafeGuard Controller using the
OmniVista SafeGuard Manager software.
■
OmniAccess SafeGuard OS Administration Guide
Provides concepts and configuration instructions for the major features of
OmniAccess SafeGuard OS and its supported products, which includes End Point
Validation (EPV) the integral component for using ICS.
6
ICS Dissolvable Agent for SafeGuard Administration Guide
This guide uses the following formats to highlight special messages in the text:
NOTE: This format highlights information that is important or that has
special interest.
Preface
ICS Dissolvable Agent for SafeGuard Administration Guide
7
Preface
8
ICS Dissolvable Agent for SafeGuard Administration Guide
chapter
Introduction
1
In this chapter:
■ Integrity Clientless Security Features
■ Reports
■ ICSInfo Utility
■ Unsupported Features
Chapter 1: Introduction
Check Point Integrity™ Clientless Security (ICS) protects your network by scanning end
point computers. Use it to do the following:
■ Check end point computers for known spyware, worms, and other potential
threats
■ Check that end point computers are compliant with your anti-virus, firewall, and
other software policies
■ Protect data on end point computers from keyloggers
Integrity Clientless Security Features
ICS consists of several features, each providing a unique type of security protection. You
can choose which features to implement. This section provides an overview of these
features.
Integrity Clientless Security Scanner
Use the Integrity Clientless Security Scanner policies to make sure that end point
computers connecting to your network meet your security requirements. The Integrity
Clientless Security Scanner checks end point computers for applications according to the
enforcement rules you create. Enforcement rules either prohibit or require certain
applications. If the end point computer does not meet the requirements of the
enforcement rule, it is considered to be ‘non-compliant’. You can choose to restrict or
warn non-compliant users or simply log the event. For more detailed information about
enforcement rules, see Understanding Enforcement Rules on page 24.
Reports
Use reports to monitor how ICS is protecting your network and to plan new policies. For
more information about reports, see Reports on page 36.
ICSInfo Utility
ICS includes the ICSInfo Utility. The ICSInfo utility collects program and other
information from end point computers that you can use when creating your policies or
troubleshooting user issues. See Troubleshooting End Point User Issues on page 40.
10
ICS Dissolvable Agent for SafeGuard Administration Guide
Supported Features
The ICS Dissolvable Agent has the following features:
■ Enforces software compliance
■ Detects browser plugins for adware
■ Tool for dialer hacking
■ Detects keystroke Logging
■ Detects undesirable software
■ Remote administration tool
■ Screen logging
■ Cookie tracking
■ Detects Trojans
■ Detects worms
Chapter 1: Introduction
■ Enforces anti-virus compliance for these vendors:
— Computer Associates VET
— Computer Associates eTrust InnoculateIT
— Kaspersky Antivirus
— McAfee VirusScan
— Trend Micro PC-cillin/OfficeScan
— Sophos AV
— Symantec Norton Antivirus
Unsupported Features
The following ICS features display in the product, but are not supported in the ICS
Dissolvable Agent for OmniAccess SafeGuard OS solution:
■ While the spyware module does detect key-logging, the Advanced Anti-
KeyLogger feature of ICS is not supported.
■ Integrity Secure Workspace
ICS Dissolvable Agent for SafeGuard Administration Guide
11
Chapter 1: Introduction
12
ICS Dissolvable Agent for SafeGuard Administration Guide
chapter
Prerequisites
2
In this chapter:
■ End Point Prerequisites
Chapter 2: Prerequisites
End Point Prerequisites
Use this chapter to plan your ICS implementation by ensuring that you meet the
requirements listed.
For end point computers to be successfully serviced by Integrity Clientless Security, they
must meet the end point requirements outlined in this section. When a user tries to access
your network without the proper browser or settings, an error message is displayed
detailing the browser requirements. You can choose to allow access for end point
computers that do not meet your requirements, however, those computers will not be
serviced by ICS.
Supported Operating Systems
For information about allowing access for end point computers that are running
unsupported operating systems see Configuring ICS to Fail Open on page 21.
For Integrity Security Scanner:
■ Windows 98/ME
■ Windows NT4 SP6
■ Windows 2000
■ Windows XP
Supported Browsers
■ Internet Explorer 5.01 or later configured to allow cookies, run ActiveX
components or Sun Java applets enabled or Microsoft Java VM enabled
■ Mozilla Firefox 1.0 or later configured to allow cookies and Sun Java applets
support enabled
■ Netscape Navigator 8.0 or later configured to allow cookies and Sun Java applets
support enabled
Java Requirements
ICS supports two Java implementations. End point computers must have one of the
following to be serviced by ICS:
14
■ Sun JRE version 1.4.2 or higher.
■ Microsoft JVM version 5.5.3810.0 or higher.
ICS Dissolvable Agent for SafeGuard Administration Guide
chapter
General Administration
3
Tasks
In this chapter:
■ Planning for Security
■ Logging In
■ Configuration Workflow
■ General Administration Tasks
Chapter 3: General Administration Tasks
Planning for Security
This chapter provides information about the general administration of ICS. Before you
start to configure and administer ICS, you should consider which security features you
want to use and how they will affect your users. You should balance security with the
ability of your users to access your network. If you implement a large number of security
requirements, then you will achieve high security; however, if the end point computers
do not comply, then your users will not be able to access your network. This can cause a
considerable support burden and negatively impact productivity. Alternatively, if you
configure ICS to be too lenient, you might not achieve the level of security you need.
When planning your implementation, be sure to take into account your particular
security situation. ICS provides a variety of features to suit different needs. Depending on
your security goals and your users, you may use only a portion of those features. Use the
information in Security Scenario on page 16, to determine which features are suitable for
your implementation.
Even if you find that you need a very secure, very restrictive security implementation, it
may not be a good idea to immediately impose it upon your users. The recommended
way to achieve high security with lower user impact is to start with a less demanding
configuration and then implement progressively more strict configurations in an iterative
manner. The process you use to manage these iterative configurations is called a ‘security
lifecycle’. For more information, see Understanding Security Lifecycles on page 17.
Security Scenario
ICS is designed to provide flexible configuration options that allow you to tailor its
protection to your security needs. When deciding which ICS security solutions to use you
should consider the following:
■ Security vulnerabilities
■ Threats
■ Type of end point users and disruption tolerance
Use the following full network access security scenario to help plan your
implementation. In this scenario, you are providing end point users with unlimited
access to your entire network.
Vulnerabilities
In this scenario, your entire network is vulnerable, including:
■ Network resources
■ File servers
■ Application servers
16
ICS Dissolvable Agent for SafeGuard Administration Guide
Chapter 3: General Administration Tasks
■ User accounts
■ End point computers
Your security goals are to provide data protection, session confidentiality, and protection
from network infection.
Risks
In this scenario, your organization’s intellectual property is threatened by:
■ Viruses
■ Trojans
■ Wor ms
■ Hackers
End Point Users and Disruption Tolerance
Your end point users are usually employees but they can also be guests and contractors.
Employees are professionals with a medium-to-high level of computer expertise. They
are more likely to understand the need for security and to tolerate a higher degree of
disruption while becoming compliant with your security implementation’s demands.
Sample Solution
A recommended solution for full network access is to use the ICS Security Scanner. The
Security Scanner protects against network infection and known spyware through the
policy you configure. The Security Scanner policy should require an antivirus application
and a firewall on each end point computer. The policy should also prohibit all types of
spyware.
Although the final goal of this security solution is to have a rather demanding and
restrictive policy, you can minimize end point user disruption through the use of security
lifecycles. You can implement a limited number of security features at first and use more
lenient options while your users become compliant. Once users have begun to comply,
you can add more security features, and use the less permissive options. For more
information see Understanding Security Lifecycles.
Understanding Security Lifecycles
Security lifecycles allow you to gradually increase your security while maintaining
reasonable user access to your network. By using a security lifecycle, you can also keep
your system up to date, by implementing changes according to changes in your systems
security needs.
Consider starting out with a security configuration that is lenient. Strategies for creating
more lenient security configurations include:
ICS Dissolvable Agent for SafeGuard Administration Guide
17
Chapter 3: General Administration Tasks
■ Minimizing security features—Using only one or two features. To make these
features less disruptive, allow end point computers to connect, even if the
operating systems are not supported by the feature.
■ Minimizing enforcement rules—Only using enforcement rules for the most
important security requirements, such as requiring an antivirus application. To
make these enforcement rules even less disruptive, set them to ‘warn’ or
‘observe’.
Use the following steps in your security lifecycle:
1 Plan your security implementation.
Use the sample security scenario to help plan your implementation. See Security
Scenario on page 16. When planning your security implementation you should
consider the following:
— What applications do you want to prohibit?
— Commonly prohibited application types include IM clients, file system
indexers, games, and file sharing applications. For each prohibited application
you should consider whether you want to deny access for users who have it or
simply warn them that the application is prohibited. If you are unsure what
the user impact would be, you can choose to allow access without a warning.
This allows you to track incidents in your reports without troubling the user.
— What applications do you want to require?
— Commonly required applications include anti-virus applications and
firewalls.
— Do you want to protect against keyloggers?
— Do you want to allow access for end points that have unsupported operating
systems.
— What remediation information do you need to provide to your users so they
can become compliant with your policies?
2 Configure your security implementation.
Use the Integrity Advanced Server Administrator Console to configure your
security settings. See Configuration Workflow on page 20.
3 Monitor the results.
Use the reports to see how well ICS is protecting your network and to see its
impact on your end point users. See Security Scan Results on page 37.
4 Return to step 1.
Use the information you obtain from the reports to plan your next configuration.
18
ICS Dissolvable Agent for SafeGuard Administration Guide
Figure 1 Security Lifecycle
Supporting the End Point User
Chapter 3: General Administration Tasks
In order to ensure that your users will be able to have the access they need and are not
needlessly inconvenienced by your security policies, you should plan how to provide
support and education for them.
One of the most important things you can do to make your ICS implementation run
smoothly, is provide information to your users. If users understand your security rules
and why they are being scanned, you will greatly reduce the volume of unnecessary help
desk requests.
You can help your users to understand ICS and comply with your security requirements
by doing the following:
■ Providing remediation information—Always provide complete, clear remediation
Logging In
After you have finished installing ICS, you can log into the ICS Administrator Console.
This is the Web-based graphical user interface that allows you to set your security
configurations.
information and links if your enforcement rules are set to ‘warn’ or ‘restrict. This
allows users to deal with their own issues efficiently, without resorting to help
desk requests. See Understanding Enforcement Rules on page 24.
The ICS Administrator Console is located at:
http://myIP:31862/ics/bin/ctool.cgi
ICS Dissolvable Agent for SafeGuard Administration Guide
.
19
Chapter 3: General Administration Tasks
The default username and password is ‘icsadm/icsadm’. To add additional users and
passwords to the Alcatel-Lucent system, use the optional EPV configuration commands
described in the OmniAccess SafeGuard OS Administration Guide.
Configuration Workflow
After you plan your security configuration, you can begin to configure ICS. While you
may perform some configuration functions at any time, the following is the
recommended order for configuring your system:
1 Create enforcement rules.
Enforcement rules determine what applications your users must or must not have
on their computers. Enforcement rules are the basic building blocks of your
policies. You can use the same enforcement rules in multiple policies. For more
information, see Understanding Enforcement Rules on page 24.
2 Create policies.
Policies provide a convenient way to specify which enforcement rules you want
to use at the same time. For more information, see Creating Policies on page 32.
3 Activate your policy.
Choose the policy that you want to use. You can create as many different policies
as you want, but only one policy can be active at a time. See Activating Policies on
page 32.
4 Save.
After completing any configuration steps, you must always save to have your
changes take effect.
5 (Optional) Back up your ICS policy and portal configurations on the Alcatel-
Lucent device. See the section, Backing Up and Restoring ICS Policies and Rules in
the EPV chapter of the OmniAccess SafeGuard OS Administration Guide.
General Administration Tasks
Use this section to perform general configuration tasks, including:
20
■ Configuring ICS to Fail Open
■ Configuring Updates
ICS Dissolvable Agent for SafeGuard Administration Guide
Configuring ICS to Fail Open
If you want to minimize disruption to your users, you should configure ICS to ‘fail open.’
This means that end point users that are not running a supported operating systems can
still access your network, without being serviced by ICS.
1 Log into the ICS Administrator Console.
2 Go to the Gateway Configuration tab.
3 In the section Settings for end points running a non-supported OS select Allow
access to end points running a non-supported OS
4 Click Save.
This procedure causes those unsupported users to bypass all the scans and
security features of ICS. These unsupported end point users are not protected by
ICS. Users with supported operating systems are still protected.
Configuring Updates
Chapter 3: General Administration Tasks
.
Check Point periodically releases updates to client components, such as support for new
anti-virus providers. When updated versions of the client components are available, you
can download them. Client components include the following:
■ Security Scanner
■ Enforcement agent
■ Java and ActiveX launchers
It is recommended that you update your system once a week. If you do not update ICS,
your system will be out-of-date and you will not have the best protection available.
How to Update Your ICS System:
1 Log into the ICS Administrator Console by supplying the default user ID and
password.
There are a number of methods to locating and logging into the ICS
Administrator Console from within the OmniVista SafeGuard Manager. For
example, you can select ICS Admin from the Other Actions pull-down menu. See
the OmniVista SafeGuard Manager Administration Guide for details.
NOTE: You must have a DNS server configured in order to update
ICS. See Configuring for Domain Name Service (DNS) Server in the
OmniAccess SafeGuard OS Administration Guide.
ICS Dissolvable Agent for SafeGuard Administration Guide
21
Chapter 3: General Administration Tasks
2 Click Update Client Components at the bottom of the page.
If an update is available, a new window opens and displays the latest package.
3 Click the box, Proceed to Update.
A message appears to show the status of your update.
4 When the update is complete, click Finish to continue.
22
ICS Dissolvable Agent for SafeGuard Administration Guide
chapter
Administering Security
4
Scanner Policies
In this chapter
■ Understanding Integrity Clientless Security Scanner
■ Implementing Policies
■ Understanding Enforcement Rules
■ Activating Policies
Chapter 4: Administering Security Scanner Policies
This chapter contains information about how to administer your policies using the ICS
Administrator Console. Policies control what the Integrity Clientless Security Scanner
checks for on your end point computers. Policies consist of collections of enforcement
rules, which specify whether to prohibit or require certain applications, and what action
to take if the end point computer is out of compliance with the rule.
Understanding Integrity Clientless Security Scanner
Integrity Clientless Security Scanner requires no pre-installed software on end point
computers, except a supported browser. The Security Scan is performed by a Java or
ActiveX component that is deployed from your Web server to each end point computer
that requests access.
Implementing Policies
This section describes all the steps you need in order to use policies to secure your end
points. If you do not complete all these steps, your policies will not be enforced.
NOTE: If you do not want to create your own policies, you can use the
sample policies included with ICS. ICS includes high, medium, and low
sample policies that you can activate. You can also edit these rules to
customize them.
To Implement policies
1 Create your enforcement rules. See Understanding Enforcement Rules on page 24.
2 Use the enforcement rules to create a policy. See Creating Policies on page 32.
3 Activate the policy. See Activating Policies on page 32.
4 Save your configuration.
Understanding Enforcement Rules
Use the Enforcement Rule page in the ICS Administrator Console to manage your
enforcement rules. You must add an enforcement rule to a policy and make that policy
the active policy for the rule to take effect. Any changes you make to an enforcement rule
affects all the policies that contain that rule. When you delete an enforcement rule, it is
removed from all your policies. You are warned when you delete an enforcement rule
that is currently being used in a policy.
24
Each enforcement rule consists of the following parts:
ICS Dissolvable Agent for SafeGuard Administration Guide
Chapter 4: Administering Security Scanner Policies
■ Conditions—Use the conditions area to indicate the criteria that the end point
computer must meet. For instance, that it must have a certain file running.
■ Action—Use the action area to indicate what ICS should do when the end point
computer is out of compliance with the rule.
Actions affect the user experience as described in Tab l e 1 .
Table 1 Action behaviors
Option Behavior
Restrict Prevents the users from logging on. ICS displays the scan report and
any remediation information you have specified. Users must become
compliant before being allowed to proceed.
Warn Does not prevent users from logging on. ICS displays the scan report
and any remediation information you have specified. Users may
proceed without becoming compliant. Users are asked to become
compliant every time they are scanned by ICS.
Observe Does not prevent users from logging on. ICS records the violation in the
log. This option does not display the scan report to end users but is
useful for gathering information about potential issues w ith your
network before you restrict end point connections.
Allow ICS does not check for spyware you have set to ‘allow’. This action is
only available for Anti-spyware scan rules.
■ Remediation — Use the remediation area to specify resources and information
that the end point users need to become compliant with the enforcement rule. For
example, if the rule requires an anti-virus program, you should provide a link to a
location where the end point user can download the application and instructions
on how to install it. Because users might be repeatedly warned, or even denied
access if they do not comply, it is important to make sure you provide sufficient
and clear remediation resources.
In Alcatel-Lucent’s End Point Validation (EPV) feature, a bypass policy is required
to perform remediation. See the section, Creating Global Bypass Policies, in the End
Point Validation chapter of the OmniAccess SafeGuard OS Administration Guide for
further details.
Enforcement Rule Types
Use enforcement rules to control which applications your users must, or must not have
on their computer when they connect to your network. There are the following types of
enforcement rules:
ICS Dissolvable Agent for SafeGuard Administration Guide
25
Chapter 4: Administering Security Scanner Policies
■ Firewall Application — Use firewall application rules to require a certain firewall
application. See Firewall Application Rules on page 26.
■ Anti-Virus Application — Use anti-virus application rules to require a supported
anti-virus application. If you want to require an anti-virus application that is not
supported, use the custom application rule. See Anti-virus Application Rules on
page 27.
■ Anti-Spyware Scan — Use anti-spyware scan rules to prohibit certain spyware
types. See Anti-Spyware Scan Rules on page 29.
■ Custom Application — Use custom application rules to prohibit or require any
application. See Custom Application Rules on page 30.
■ Custom Group — Use Custom Group rules to bundle custom application
enforcement rules into one rule. When you put enforcement rules in a group, the
end point computer must meet at least one of the conditions in order to be in
compliance. See Custom Group Rules on page 31.
Firewall Application Rules
Firewall application rules determine which firewall applications end point computers
must have when they are logged onto your network. You can use this feature to require
that end point users obtain the latest version of an Integrity client when they connect to
your gateway.
Creating a Firewall Application Rule
The steps below give an overview of creating a firewall application rule. For detailed
information about individual user interface elements, and how to complete the page, see
the online help.
To Create a Firewall Application Rule:
1 Log into the ICS Administrator Console and click Enforcement Rules.
2 On the Enforcement Rules page click New Rule and choose Firewall Application.
3 Select the firewalls you want to require.
This sets the conditions for the rule. If end point computers violate these
conditions they are considered to be out of compliance.
26
4 Select the action you want ICS to take if the end point user is not in compliance
with this rule.
5 Use the remediation area to specify any information or resources you want to
provide to end point users to help them to become compliant with this rule.
ICS Dissolvable Agent for SafeGuard Administration Guide
6 Click Save Rule.
Anti-virus Application Rules
It is important to protect your network from viruses. Every time an end point user logs in,
your network is exposed to any viruses that the end point computer is infected with.
Users who access your network through a gateway are particularly likely to be infected,
since they are more likely to use their computers for personal uses, which put them at risk
for viruses.
In order to protect your organization from viruses, you should require your users to have
anti-virus protection. Effective anti-virus protection requires not only having the correct
anti-virus software on your end point computers, but also having a recent version of that
software and up-to-date software definitions. If end point users have out-of-date
software definitions, they will not be protected against the latest viruses.
Anti-virus application rules determine which anti-virus applications your end point
computers must have when they are logged into your network. Since users can
sometimes disable their anti-virus software, all anti-virus applications rules require that
the application be running. For your convenience, anti-virus enforcement rules are pre-
configured with supported anti-virus providers.
Chapter 4: Administering Security Scanner Policies
NOTE: If you want to create an enforcement rule for an anti-virus
provider not supported by the anti-virus applications rules, you can do so
Y
by creating a custom software rule to require the application. See Custom
Application Rules on page 30.
If you want to require that your end point computers have a supported form of anti-virus
protection, create an anti-virus enforcement rule for your policy. It is recommended that
you require an anti-virus application with a DAT file no older than 14 days. In the case of
a virus outbreak, you should require that the DAT file be no more than 24 hours old.
Creating an Anti-virus Application Rule
The steps below give an overview of creating an anti-virus application rule. For detailed
information about individual user interface elements, and how to complete the page, see
the online help.
To create an anti-virus application rule:
1 Log into the ICS Administrator Console and click Enforcement Rules.
2 On the Enforcement Rules page click New Rule and choose Anti-Virus
Application.
ICS Dissolvable Agent for SafeGuard Administration Guide
27
Chapter 4: Administering Security Scanner Policies
3 Select the anti-virus applications you want to require.
The end point computer must have at least one of these anti-virus applications to
be in compliance with the rule.
4 You can optionally edit the conditions for each application.
For each anti-virus application you can specify more detailed criteria and
remediation information that is specific to the application.
A Click Edit.
The Anti-Virus Application Details page appears.
B Specify the operating system that this anti-virus application is required for.
C Specify the application conditions.
It is recommended that you require a recent version of the application and a
DAT file no older than 14 days. This ensures that your end point computers
have up-to-date protection against viruses.
NOTE: The format of these entries is important and formats
vary from one anti-virus provider to another. To obtain the
Y
engine version, DAT file version, and DAT age information for
your supported anti-virus software in the correct format, run
the ICSInfo utility included with Integrity Clientless Security
on your reference computer. For more information, see
Obtaining Anti-virus Application Information on page 41.
D Specify the remediation information and resources.
This remediation information is specific to the application.
E Click Save Rule.
You return to the Anti-Virus Enforcement Rule Settings page.
5 Select the action you want ICS to take if the end point user is not in compliance
with this rule.
6 Use the remediation area to specify any information or resources you want to
provide to end point users to help them to become compliant with this rule.
This remediation information is for all the anti-virus applications and should be
more generic than the remediation information you provided for the specific
applications.
28
7 Click Save Rule.
ICS Dissolvable Agent for SafeGuard Administration Guide
Anti-Spyware Scan Rules
The term ‘spyware’ refers to applications that collect user data on host computers for
either commercial or malicious purposes.
Spyware may do any of the following:
■ Aid hackers in circumventing your security and spreading malicious code.
Spyware can introduce worms, dial out to toll lines, and introduce other serious
security breaches.
■ Send information about a user, the user’s behavior, the computer system or the
computer system’s use without requesting permission from the user to do so. This
can be a serious breach of security for your users and your organization.
■ Present advertising, often without notification, to the users without any
additional benefit. This is a less serious threat, but is annoying to users and can
have a serious impact on productivity.
For more information about types of spyware and the risks they present, see the online
help for the Anti-Spyware Enforcement rules.
Chapter 4: Administering Security Scanner Policies
Use anti-spyware scan rules to protect your end points from spyware. Anti-spyware scan
rules allow you to control gateway access for users who have spyware software on their
end point computers. ICS comes preconfigured with software definitions for many types
of known spyware, organized by type. Through anti-spyware enforcement rules you can
protect your organization, and encourage or require your users to remove spyware
residing on their computers.
For each type of spyware, you can set the action you would like ICS to take when that
spyware type is detected on an end point computer. You can also create exceptions for
specific spyware programs you consider benign and want to allow.
If you want to protect your Gateway and your end point users from spyware, create an
anti-spyware enforcement rule for your policy. You can only use one Anti-spyware scan
rule for each policy, though you may wish to use different rules in different policies. Only
the rule included in your active policy will be enforced for your users.
Creating an Anti-spyware Rule
The steps below give an overview of creating an Anti-spyware scan rule. For detailed
information about individual user interface elements, and how to complete the page, see
the online help.
To Create an Anti-spyware Rule:
1 Log into the ICS Administrator Console and click Enforcement Rules.
2 On the Enforcement Rules page click New Rule and choose Anti-Spyware Scan.
ICS Dissolvable Agent for SafeGuard Administration Guide
29
Chapter 4: Administering Security Scanner Policies
3 Enter a Name and Description for the rule.
4 For each screened software type, choose the action you want ICS to take when it
detects this kind of spyware.
If you warn or restrict the end point computer, it is recommended that you
include a Remedy Message, informing the user of what they need to do to treat
the spyware.
5 If you want ICS to ignore certain spyware applications, add them to the
exclusions list.
6 Optionally, you can select Display SmartDefense Advisor article link.
Selecting this option will display a Check Point article to the end point users that
will explain what the spyware is and offer treatment advice. It is highly
recommended that you select this option.
SECURITY: If you elect to present this information to end users, you
must configure an EPV bypass policy to allow the users access to
smartdefense.checkpoint.com. Configuration of bypass policies are
discussed in the EPV chapter of the OmniAccess SafeGuard OS
Administration Guide.
7 Click Save Rule.
Custom Application Rules
While most of the common applications that you might want to control are governed by
the other types of rules, you might wish to prohibit or require other applications.
If you wish to prohibit or require an application not covered by any of the other rule
types, use a custom application rule. A typical use of a custom application rule is to create
a rule requiring an anti-virus application that is not supported by the preconfigured
antivirus application rules.
To Create a Custom Application Rule:
1 Log into the ICS Administrator Console and click Enforcement Rules.
2 On the Enforcement Rules page click New Rule and choose Custom Application.
3 Enter a Name and a Description for the rule.
4 Choose the end point computer operating system you want this rule to apply to.
30
5 Specify the conditions for this rule.
ICS Dissolvable Agent for SafeGuard Administration Guide
Chapter 4: Administering Security Scanner Policies
If you are creating a rule requiring an anti-virus application, it is recommended
that you require that the application be running, to prevent users from disabling
the application. You should also require that it be modified no more than a week
ago, to ensure that end point computers are getting virus definition updates
regularly. During a virus outbreak, you will want to require that the file be
modified no more than 24 hours ago.
NOTE: To obtain the checksum for your custom application, run
the ICSInfo utility included with Integrity Clientless Security on
Y
your reference computer. For more information, see Obtaining
Application Checksums on page 41.
6 Select the action you want ICS to take if the end point user is not in compliance
with this rule.
7 Use the remediation area to specify any information or resources you want to
provide to end point users to help them to become compliant with this rule.
8 Click Save Rule.
Custom Group Rules
Use custom group rules to group together custom application enforcement rules. End
point computers have to be compliant with at least one rule in the group. For example,
you may want to make a rule group that requires a certain security patch or a certain
service pack, if having either one would fulfill your organization’s security requirements.
Creating Custom Group Rules
To Create a Custom Group:
1 Log into the ICS Administrator Console and click Enforcement Rules.
2 On the Enforcement Rules page click New Rule and choose Custom Group.
3 Enter a Name and a Description for the rule.
4 Choose the enforcement rules you want to include in the group.
End point users will have to be compliant with at least one of these rules. You can
only add custom application rules to a group rule.
5 Select the action you want ICS to take if the end point user is not in compliance
with this rule.
ICS Dissolvable Agent for SafeGuard Administration Guide
31
Chapter 4: Administering Security Scanner Policies
6 Use the remediation area to specify any information or resources you want to
provide to end point users to help them to become compliant with this rule.
This remediation information is for all the enforcement rules in the group and
should be more generic than the remediation information you provided for
specific enforcement rules.
7 Click Save Rule.
Creating Policies
Policies are made up of Enforcement rules. When an end point computer is scanned, its
state is compared to all the enforcement rules in the currently active policy. If you have
more than one enforcement rule in a policy, the end point users must comply with all of
the rules. If you need to enforce compliance with just one rule out of a group, create a
custom group rule out of the rules.
To Create a Policy:
1 Log into the ICS Administrator Console and click Policies.
2 On the Policies page, click New Policy.
3 Enter a Name and Description for the policy.
4 In the Rules selected for this policy table, select the enforcement rules you want
in this policy.
5 Click Save Policy.
NOTE: This policy will not be enforced until you activate it.
Activating Policies
You can create as many policies as you need, but only one is enforced at a time. You must
activate your policy in order to have it be enforced. You may also set the scan interval.
To Activate a Policy:
32
1 Log into the ICS Administrator Console and click Gateway Configuration.
ICS Dissolvable Agent for SafeGuard Administration Guide
Chapter 4: Administering Security Scanner Policies
2 Select your policy in the Integrity Security Scanner Policy drop down list.
3 Optionally, you can select to enforce a scan interval.
Use a scan interval to require that the end point computers be re-scanned while
they are connected to your network. If a user is connected to your network, and
then directs a browser to another location, they may become infected with
spyware after the original scan. Use the scan interval to trigger a periodic re-scan
to help ensure that your end point users remain free of spyware while connected.
The re-scans are silent to the user and are performed in the background. If the
enforcement rule's action is set to warn or observe and the user becomes
contaminated, the user remains compliant until aged-out of the posture table.
However, if the enforcement rule's action is set to restrict and the user become
contaminated, the user falls out of compliance and should follow the remediation
action. Depending on your trigger policy and remediation action, the user’s
network access might be disrupted.
NOTE: The recommended scan interval is 15 minutes.
4 Click Save.
ICS Dissolvable Agent for SafeGuard Administration Guide
33
Chapter 4: Administering Security Scanner Policies
34
ICS Dissolvable Agent for SafeGuard Administration Guide
chapter
Reports
5
In this chapter:
■ Reports
Chapter 5: Reports
Use this chapter to understand how to use reports to enhance your implementation.
Reports
Use the ICS reports to monitor security events occurring on your network. Use the
information in these reports to improve your policies, provide better remediation for
users, and observe how ICS is protecting your network.
ICS includes the following major reports, you can also drill down to detail-level reports:
■ Access Statistics on page 37
■ Security Scan Results on page 37
■ Spyware Found on page 37
■ Rules Broken on page 37
■ Anti-Keylogger on page 37
■ Errors on page 38
Generating Reports
All ICS report pages use the same method to generate reports. Use the following
instructions to generate reports, then see the section on that report.
To Generate a Report:
1 Log into the ICS Administrator Console.
2 Click Reports.
3 Choose your report.
4 Set the date range for the report and click Generate Report.
The report is generated for the time period you specify.
NOTE: The reports database holds a maximum of two days data, after
which the data is rotated.
36
ICS Dissolvable Agent for SafeGuard Administration Guide
Access Statistics
Use the Access Statistics report to see what the results were for all the users who
attempted to connect to your gateway. Attempted user connections are counted per
session, with the session determined by the persistence of the cookie. If a user connects to
your gateway, disconnects and reconnects again, that is counted as one connection
attempt, unless the cookie has expired.
This report shows how many users were compliant with your security rules and what
happened to those who were not compliant. Use the legend to see details about the users
in each category.
You can use the information in this report to refine your policies. If an excessive amount
of users are being warned, or even restricted, your rules may be too strict or you may not
be providing enough remediation information. Use the Rules Broken report to see which
rules your end point users are having the most trouble with. Once most users are
compliant, you can increase your security requirements.
Security Scan Results
Chapter 5: Reports
The Security Scan Results report shows the total numbers of enforcement rules broken
and the total amount of spyware found for each user’s scan. You can use this report to
find out why a user was warned or restricted. Using this information, you can then
provide remediation information to the user.
Spyware Found
Use the Spyware Found report to see how often particular spyware applications were
found on your end point computers. If you find that ICS is scanning for a particular
spyware application that you want to allow, you can add it to the ignore list. See Anti-
Spyware Scan Rules on page 29.
Rules Broken
Use the Rules Broken report to determine which rules are causing your end point users
the most trouble. This report includes rules that are set to ‘observe’. If a rule is
consistently being broken at a high rate, that may indicate the rule is too strict or that you
are not providing enough remediation information for that rule.
Anti-Keylogger
The Anti-Keylogger report shows processes that were flagged by ICS as potentially being
keyloggers. This reports shows you how ICS protects your network and end point users
from keyloggers.
ICS Dissolvable Agent for SafeGuard Administration Guide
37
Chapter 5: Reports
Errors
Use the Errors report to view the ICS errors that end point users are experiencing when
they attempt to connect to your gateway. This report only shows errors when the user
connects to the ICS server. To diagnose connection issues due to end point configuration,
use the ICSInfo utility. See Troubleshooting End Point User Issues on page 40.
38
ICS Dissolvable Agent for SafeGuard Administration Guide
chapter
The ICSInfo Utility
6
In this chapter:
■ Troubleshooting End Point User Issues
Chapter 6: The ICSInfo Utility
The ICSInfo utility collects program and other information from end point computers
that you can use when creating your policies or troubleshooting user issues.
Troubleshooting End Point User Issues
If your users are unable to connect to your network, you may need to help them to
become compliant. Have your users run the ICSInfo utility to determine what is wrong.
The ICSInfo utility provides the following information for supported operating systems:
■ Host—Processor, Memory, OS
■ User—User Name, Profile location, Groups
■ Java—MS-JVM and Sun-JRE versions (and if they are installed)
■ Browser—IE version (and if JRE is enabled), current default browser location and
version
■ Internet Options—The options set in the Internet Options of Internet Explorer
(per zone).
■ ICS Component—The ICS components currently on the end point computer
■ Anti-Virus—The anti-virus application information
■ Applications/Modules—The applications currently found on the end point
computer
■ Network Preferences—The settings for the installed network adapters
How to Troubleshoot End Point User Issues:
1 Have your end point user obtain the ICSinfo.exe file.
The ICSInfo utility is available at:
http://myIP:31862/ics/components/icsinfo.exe
You might want to make this utility accessible to your users from your
remediation server. To do so, save the file locally and hosting it on the remediation
server.
2 Have your end point user run the ICSinfo.exe file.
3 Have your end point user perform the following steps to obtain the icsinfo.xml
file:
40
A Run the ICSinfo.exe file.
B When prompted, click Browse and select a location to save the icsinfo.xml file.
ICS Dissolvable Agent for SafeGuard Administration Guide
C Click Run.
The ICSInfo utility runs and the file is saved to the specified location.
4 Have the end point user send the icsinfo.xml file to you for analysis.
Obtaining Anti-virus Application Information
When creating anti-virus enforcement rules, you need to use the correct format for your
anti-virus provider information. This format varies from provider to provider. Use the
ICSinfo utility to scan a reference computer to obtain the information for all the installed
anti-virus programs in the correct format.
To Obtain Anti-virus Application Information:
1 Set up a reference computer with your anti-virus applications installed.
Be sure to obtain the updates for your anti-virus providers.
Chapter 6: The ICSInfo Utility
2 Obtain the ICSinfo.exe file and copy it to your reference computer.
The ICSInfo utility is available at:
http://myIP:31862/ics/components/icsinfo.exe
3 Run the ICSInfo.exe file
Using a command prompt run
utility using this parameter, the ICSInfo utility produces an icsinfo.xml file that
contains only anti-virus application information.
4 Check the icsinfo.xml file for the application information.
ICSInfo.exe -avinfo
Obtaining Application Checksums
Use the ICSInfo utility to obtain checksums for applications. Use these checksums when
creating custom application enforcement rules. Since checksum are unique, verifying a
file by checksum prevents another file from masquerading as that file.
To Obtain Application Checksums:
. When you run the ICSInfo
1 Set up a reference computer with a trusted copy of the application.
2 Obtain the ICSinfo.exe file and copy it to your reference computer, to the same
location as your application.
ICS Dissolvable Agent for SafeGuard Administration Guide
41
Chapter 6: The ICSInfo Utility
The ICSInfo utility is available at:
http://myIP:31862/ics/components/icsinfo.exe
3 Run the ICSInfo.exe file
Using a command prompt run
ICSInfo.exe -fileinfo
. When you run the
ICSInfo.exe file using this parameter the ICSInfo utility produces an icsinfo.xml
file that contains the version, size, checksum and vendor information for each dll
and exe file in the folder.
4 Open the icsinfo.xml file and use the information to create your custom
application enforcement rules.
42
ICS Dissolvable Agent for SafeGuard Administration Guide
Index
A
Access Statistics report . . . 37
Activating
Policies . . . 32
Admin console
logging in to . . . 19
Anti-Keylogger report . . . 37
application information
obtaining application checksums . . . 41
obtaining for anti-virus application . . . 41
C
checksums
obtaining for applications . . . 41
Configuring
updates to ICS client components . . . 21
Configuring ICS
overview . . . 20
Creating
Custom Group Rule . . . 31
Policies . . . 32
Custom Group Rule
creating . . . 31
Customization
overview . . . 11
D
Enforcement rules
defined . . . 24
definition of types . . . 25
Errors report, overview . . . 38
F
Fail open configuration
ICS . . . 21
G
Generating
Reports . . . 36
I
ICS
configuring client updates . . . 21
fail open configuration . . . 21
logging in to admin console . . . 19
overview of configuration . . . 20
ICSInfo Utility overview . . . 10
installation
prerequisites . . . 14
Integrity Clientless Security Scanner
overview . . . 24
J
Java requirements for end point computers . . .
14
Documentation . . . 6
E
Educating end point users . . . 19
end point computers
Java version requirements . . . 14
supported browsers . . . 14
supported operating systems . . . 14
troubleshooting issues . . . 40
ICS Dissolvable Agent for SafeGuard Administration Guide
L
Logging in to ICS . . . 19
O
operating systems
supported for end point computers . . . 14
P
Planning, security . . . 16
43
Index
Policies
activating . . . 32
creating . . . 32
instructions for implementing . . . 24
prerequisites, installation . . . 14
Providing information to end point users . . . 19
R
Reports
Access Statistics . . . 37
Anti-keylogger . . . 37
errors, overview . . . 38
instructions for generating . . . 36
overview . . . 10
Rules Broken . . . 37
Security Scan Results . . . 37
Spyware Found . . . 37
Rules
creating Custom Group . . . 31
definition of enforcement types . . . 25
enforcement, defined . . . 24
Rules Broken report, overview . . . 37
S
Security Lifecycles
overview . . . 17
Security planning overview . . . 16
Security Scan Results report, overview . . . 37
Spyware Found report, overview . . . 37
Supporting end point users . . . 19
T
troubleshooting
end point user issues . . . 40
U
Updates
to ICS components . . . 21
Utilities
ICSInfo, overview . . . 10
W
Web browsers
supported for end point computers . . . 14
ICS Dissolvable Agent for SafeGuard Administration Guide 44
Loading...
