Alcatel Hero 8 User Manual

Table of Contents

Safety and use ����������������������������������������������������������������������������� 4

General information ���������������������������������������������������������������� 11

1 Your device ������������������������������������������������������������������������13

1.1 Appearance illustration ............................................................................13

1.2 Getting started .......................................................................................... 15

1.3 Home screen ..............................................................................................16

2 Multi-window ���������������������������������������������������������������������� 27

3 Text input ���������������������������������������������������������������������������29

3.1 Using Onscreen Keyboard ......................................................................29

3.2 Text editing ................................................................................................. 30

4 Phone call, Call log and Contacts ������������������������������������ 31

4.1 Phone ...........................................................................................................31

4.2 Call log .........................................................................................................39

4.3 People ..........................................................................................................40

5 Messaging, Email ���������������������������������������������������������������46

5.1 Messaging ....................................................................................................46

5.2 Gmail/Email .................................................................................................54

5.3 Hangouts .....................................................................................................60

6 Calendar & Time ����������������������������������������������������������������� 63

6.1 Calendar ......................................................................................................63

6.2 Time .............................................................................................................65

7 Getting connected ������������������������������������������������������������67

7.1 Connecting to the Internet ....................................................................67

7.2 Browser .......................................................................................................70

7.3 Connecting to Bluetooth devices..........................................................77

7.4 Connecting to a computer .....................................................................78

7.5 Sharing your tablet's mobile data connection ....................................79

7.6 Connecting to virtual private networks ..............................................80

7.7 Connecting to TV using Peel Smart Remote ...................................... 82

7.8 Configuring Internet (SIP) calling ...........................................................82

8 Google Play Store �������������������������������������������������������������84

8.1 Locate the item you want to download and install ..........................84

8.2 Download and install ................................................................................85

8.3 Manage your downloads ..........................................................................87

9 Multimedia applications ���������������������������������������������������89

9.1 Camera ........................................................................................................89

9.2 Gallery ......................................................................................................... 93

9.3 YouTube ....................................................................................................... 95

9.4 Music ............................................................................................................96

9.5 Video Player ................................................................................................98

10 Google Maps ����������������������������������������������������������������������99

10.1 Get My Location .......................................................................................99

10.2 Search for a location ..............................................................................100

10.3 Star a location ..........................................................................................101

10.4 Get driving, public transportation or walking directions...............102

10.5 Arrangement of Layers ..........................................................................103

11 Others ������������������������������������������������������������������������������104

11.1 Calculator ..................................................................................................104

11.2 File Manager .............................................................................................105

11.3 Sound Recorder ......................................................................................106

11.4 Radio ..........................................................................................................106

11.5 Setup Wizard ...........................................................................................108

11.6 Alcatel Help ............................................................................................ 108

11.7 Other applications ..................................................................................108

1 2

12 Settings ����������������������������������������������������������������������������109

12.1 Wireless & networks .............................................................................109

12.2 Device ........................................................................................................111

12.3 Personal .....................................................................................................114

12.4 Accounts ...................................................................................................119

12.5 System ........................................................................................................120

13 Making the most of your tablet �������������������������������������126

13.1 Upgrade .....................................................................................................126

14 Tablet warranty ��������������������������������������������������������������� 128

15 Accessories ����������������������������������������������������������������������130

16 Troubleshooting ��������������������������������������������������������������� 131

17 Specifications �������������������������������������������������������������������� 136

This product meets applicable national SAR limits of

2.0W/kg. The specific maximum SAR values can be
found on page 7 of this user guide.

When carrying the product or using it while worn
on your body, either use an approved accessory such

www.sar-tick.com

as a holster or otherwise maintain a distance of 10
mm from the body to ensure compliance with RF
exposure requirements. Note that the product may be
transmitting even if you are not making a phone call.

3 4

Safety and use ������������������������������

We recommend that you read this chapter carefully before using your device. The
manufacturer disclaims any liability for damage, which may result as a consequence of
improper use or use contrary to the instructions contained herein.

• TRAFFIC SAFETY:

Given that studies show that using a device while driving a vehicle constitutes a real
risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to
refrain from using their device when the vehicle is not parked.

When driving, do not use your device and headphone to listen to music or to the
radio. Using a headphone can be dangerous and forbidden in some areas.
When switched on, your device emits electromagnetic waves that can interfere with
the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure
that there is no problem:

- do not place your device on top of the dashboard or within an airbag deployment
area,

- check with your car dealer or the car manufacturer to make sure that the dashboard
is adequately shielded from RF energy.

• CONDITIONS OF USE:

You are advised to switch off the device from time to time to optimise its
performance.
Switch the device off before boarding an aircraft.
Switch the device off when you are in health care facilities, except in designated
areas. As with many other types of equipment now in regular use, mobile devices
can interfere with other electrical or electronic devices, or equipment using radio
frequency.
Switch the device off when you are near gas or flammable liquids. Strictly obey all
signs and instructions posted in a fuel depot, petrol station, or chemical plant, or in
any potentially explosive atmosphere.
When the device is switched on, it should be kept at least 15 cm from any medical
device such as a pacemaker, a hearing aid or insulin pump, etc. In particular when using
the device, you should hold it against the ear on the opposite side to the device, if any.
Do not let children use the device and/or play with the device and accessories
without supervision.
Please note that your device is a unibody device, the battery is not removable. Do
not attempt to disassemble your device. If you disassemble your device the warranty
will not apply. Also disassembling the device may damage the battery, and may cause
leakage of substances that could create an allergic reaction.

Always handle your device with care and keep it in a clean and dust-free place.
Do not allow your device to be exposed to adverse weather or environmental
conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc). The
manufacturer’s recommended operating temperature range is -10°C to +55°C.
At over 55°C the legibility of the device’s display may be impaired, though this is
temporary and not serious.
Emergency call numbers may not be reachable on all cellular networks. You should
never rely only on your device for emergency calls.
Do not open, dismantle or attempt to repair your device yourself.
Do not drop, throw or bend your device.
Do not use the device if the glass made screen, is damaged, cracked or broken to
avoid any injury.
Do not paint it.
Use only batteries, batter y chargers, and accessories which are recommended by
TCT Mobile Limited and its affiliates and are compatible with your device model. TCT
Mobile Limited and its affiliates disclaim any liability for damage caused by the use of
other chargers or batteries.
Remember to make back-up copies or keep a written record of all important
information stored in your device.
Some people may suffer epileptic seizures or blackouts when exposed to flashing lights,
or when playing video games. These seizures or blackouts may occur even if a person
never had a previous seizure or blackout. If you have experienced seizures or blackouts,
or if you have a family history of such occurrences, please consult your doctor before
playing video games on your device or enabling a flashing-lights feature on your device.
Parents should monitor their children’s use of video games or other features that
incorporate flashing lights on the devices. All persons should discontinue use and
consult a doctor if any of the following symptoms occur: convulsion, eye or muscle
twitching, loss of awareness, involuntary movements, or disorientation. To limit the
likelihood of such symptoms, please take the following safety precautions:

- Do not play or use a flashing-lights feature if you are tired or need sleep.

- Take a minimum of a 15-minute break hourly.

- Play in a room in which all lights are on.

- Play at the farthest distance possible from the screen.

- If your hands, wrists, or arms become tired or sore while playing, stop and rest for
several hours before playing again.

- If you continue to have sore hands, wrists, or arms during or after playing, stop the
game and see a doctor.

When you play games on your device, you may experience occasional discomfort
in your hands, arms, shoulders, neck, or other parts of your body. Follow the
instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other
musculoskeletal disorders.

PROTECT YOUR HEARING

To prevent possible hearing damage, do not listen at high volume
levels for long periods. Exercise caution when holding your device
near your ear while the loudspeaker is in use.

• PRIVACY:

Please note that you must respect the laws and regulations in force in your jurisdiction
or other jurisdiction(s) where you will use your device regarding taking photographs
and recording sounds with your device. Pursuant to such laws and regulations, it
may be strictly forbidden to take photographs and/or to record the voices of other
people or any of their personal attributes, and duplicate or distribute them, as this
may be considered to be an invasion of privacy. It is the user's sole responsibility to
ensure that prior authorisation be obtained, if necessary, in order to record private or
confidential conversations or take a photograph of another person; the manufacturer,
the seller or vendor of your device (including the operator) disclaim any liability which
may result from the improper use of the device.

• BATTERY:

Please note your device is a unibody device, the battery is not removable. Observe
the following precautions:

- Do not attempt to open the back cover,

- Do not attempt to eject, replace and open battery,

- Do not punctuate the back cover of your device,

- Do not burn or dispose of your device in household rubbish or store it at
temperature above 60°C.

Device and battery as a unibody device must be disposed of in accordance with locally
applicable environmental regulations.

This symbol on your device, the battery and the accessories means that
these products must be taken to collection points at the end of their life:

- Municipal waste disposal centres with specific bins for these items of
equipment

- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.

5 6

In European Union countries:

These collection points are accessible free of charge.
All products with this sign must be brought to these collection points.

In non European Union jurisdictions:

Items of equipment with this symbol are not to be thrown into ordinary bins if your
jurisdiction or your region has suitable recycling and collection facilities; instead they
are to be taken to collection points for them to be recycled.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

• CHARGERS

Mains powered chargers will operate within the temperature range of: 0°C to 40°C.
The chargers designed for your device meet with the standard for safety of
information technology equipment and office equipment use. They are also compliant
to the ecodesign directive 2009/125/EC. Due to different applicable electrical
specifications, a charger you purchased in one jurisdiction may not work in another
jurisdiction. They should be used for this purpose only.

• RADIO WAVES:

Proof of compliance with international standards (ICNIRP) or with European
Directive 1999/5/EC (R&TTE) is required of all mobile device models before they can
be put on the market. The protection of the health and safety for the user and any
other person is an essential requirement of these standards or this directive.
THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO
WAVE S
Your mobile device is a radio transmitter and receiver. It is designed not to exceed
the limits for exposure to radio waves (radio frequency electromagnetic fields)
recommended by international guidelines. The guidelines were developed by an
independent scientific organization (ICNIRP) and include a substantial safety margin
designed to assure the safety of all persons, regardless of age and health.
The radio wave exposure guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg.
Tests for SAR are conducted using standard operating positions with the device
transmitting at its highest certified power level in all tested frequency bands. The
highest SAR values under the ICNIRP guidelines for this device model are:

Maximum SAR for this model and conditions under which it was recorded�

Body-worn SAR LTE Band 7+Wi-Fi 1.296 W/kg

During use, the actual SAR values for this device are usually well below the values
stated above. This is because, for purposes of system efficiency and to minimize
interference on the network, the operating power of your mobile device is
automatically decreased when full power is not needed for the call. The lower the
power output of the device, the lower its SAR value.
Body-worn SAR testing has been carried out at a separation distance of 10 mm.
To meet RF exposure guidelines during body-worn operation, the device should be
positioned at least this distance away from the body.
If you are not using an approved accessory ensure that whatever product is used is
free of any metal and that it positions the device the indicated distance away from
the body.
Organizations such as the World Health Organization and the US Food and Drug
Administration have stated that if people are concerned and want to reduce their
exposure they could use a hands-free device to keep the device away from the head
and body during phone calls, or reduce the amount of time spent on the device.
For more information you can go to www.alcatelonetouch.com
Additional information about electromagnetic fields and public health are available on
the following site: http://www.who.int/peh-emf.
Your device is equipped with a built-in antenna. For optimal operation, you should
avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions other than
against your ear. In such circumstances the device will be compliant with the guidelines
when used with headset or usb data cable. If you are using another accessory ensure
that whatever product is used is free of any metal and that it positions the device at
least 10 mm away from the body.

7 8

• Regulatory information

The following approvals and notices apply in specific regions as noted.

• LICENCES

The Bluetooth word mark and logos are owned by the Bluetooth SIG,
Inc. and any use of such marks by TCT Mobile Limited and its affiliates
is under license. Other trademarks and trade names are those of their
respective owners.

ALCATEL ONETOUCH D820X

Bluetooth Declaration ID D023492

The Wi-Fi Logo is a certification mark of the Wi-Fi Alliance. 5 GHz

The Android robot is reproduced or modified from work created and shared by
Google and used according to terms described in the Creative Commons 3.0
Attribution License (the text will show when you touch and hold Google legal in
Settings\About device\Legal information)
You have purchased a product which uses the open source (http://opensource.
org/) programs mtd, msdosfs, netfilter/iptables and initrd in object code and other
open source programs licensed under the GNU General Public License and Apache
License.
We will provide you with a complete copy of the corresponding source codes upon
request within a period of three years from the distribution of the product by TCT.
You may download the source codes from http://sourceforge.net/projects/alcatel/
files/. The provision of the source code is free of charge from internet.

Wi-Fi operation is for indoor use only.

Google, the Google logo, Android, the Android logo, Google Search TM,
MapsTM, Gmail TM, YouTube, Google Play Store, Google Latitude TM and

TM

Hangouts

are trademarks of Google Inc.

(1).

(1)

It may not be available according to the countries.

9 10

General information �������������������

•Internet address: www.alcatelonetouch.com

•Hot Line Number: see “TCT Mobile Services” leaflet or go to our

website.

•Address: Room 1910-12A, Tower 3, China HK City, 33 Canton Road,

Tsimshatsui, Kowloon, Hong Kong

•Electronic labeling (E-label) path: Touch settings / Regulatory

&safety or input “*#07#”, you can find more information about labeling

On our website, you will find our FAQ (Frequently Asked Questions) section. You can
also contact us by e-mail to ask any questions you may have.
An electronic version of this user guide is available in English and other languages
according to availability on our server:

www�alcatelonetouch�com

Your device is a transceiver that operates on GSM in quad-band with 850/900/1800/1900
MHz, UMTS in quad-band with 850/900/1900/2100 MHz or LTE in penta-band with
B1/B3/B7/B8/B20.

This equipment is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. The entire copy of the Declaration of Conformity
for your device can be obtained through our website: www.alcatelonetouch.com.

Protection against theft

Your device is identified by an IMEI (serial number) shown on the packaging label and
in the device’s memory. We recommend that you note the number the first time you
use your device by entering * # 0 6 # and keep it in a safe place. It may be requested
by the police or your operator if your device is stolen. This number allows your device
to be blocked preventing a third person from using it.

(2)

(1)

Disclaimer

There may be certain differences between the user manual description and the
device’s operation, depending on the software release of your device or specific
operator services.
TCT Mobile shall not be held legally responsible for such differences, if any, nor for
their potential consequences, which responsibility shall be borne by the operator
exclusively.This handset may contain materials, including applications and software
in executable or source code form, which is submitted by third parties for inclusion
in this handset (“Third Party Materials”). All third party materials in this handset are
provided “as is”, without warranty of any kind, whether express or implied, including

.

the implied warranties of merchantability, fitness for a particular purpose or use/
third party application, interoperability with other materials or applications of the
purchaser and non-infringement of copyright. The purchaser undertakes that TCT
Mobile has complied with all quality obligations incumbent upon it as a manufacturer
of mobile devices and handsets in complying with Intellectual Property rights. TCT
Mobile will at no stage be responsible for the inability or failure of the Third Party
Materials to operate on this handset or in interaction with any other devices of the
purchaser. To the maximum extent permitted by law, TCT Mobile disclaims all liability
for any claims, demands, suits or actions, and more specifically – but not limited to
– tort law actions, under any theory of liability, arising out of the use, by whatever
means, or attempts to use, such Third Party Materials. Moreover, the present Third
Party Materials, which are provided free of charge by TCT Mobile, may be subject
to paid updates and upgrades in the future; TCT Mobile waives any responsibility
regarding such additional costs, which shall be borne exclusively by the purchaser.
The availability of the applications may vary depending on the countries and the
operators where the handset is used; in no event shall the list of possible applications
and software provided with the handsets be considered as an undertaking from
TCT Mobile; it shall remain merely as information for the purchaser. Therefore,
TCT Mobile shall not be held responsible for the lack of availability of one or more
applications wished for by the purchaser, as its availability depends on the country
and the operator of the purchaser. TCT mobile reserves the right at any time to add
or remove Third Party Materials from its handsets without prior notice; in no event
shall TCT Mobile be held responsible by the purchaser for any consequences that
such removal may have on the purchaser regarding the use or attempt to use such
applications and Third Party Materials.

(1)

It depends on countries.

(2)

Contact your network operator to check service availability.

11 12

Your device ���������������������������

1

1�1 Appearance illustration

SIM/microSD card slot

Headphone jack

Front camera

Camera

Camera

Flash/

Flashlight

Inserting the microSD card

Power key

Volume up

Volume down

micro-USB

connector

13 14

1�2 Getting started

1�2�1 Power on your tablet

Hold down the Power key until the tablet powers on, unlock your tablet
(Slide, PIN, Password, Pattern, Face unlock or Voice unlock) if necessary and
confirm. The Home screen is displayed.

If you do not know your PIN code or if you have forgotten it, contact your
network operator. Do not leave your PIN code with your tablet. Store this
information in a safe place when not in use.

Set up your tablet for the first time

The first time you power on the tablet, you should set the following
options:

•Touch Get started..., then select the tablet's language.

•The device will search for service by itself. The process of activation will

take a few minutes

•Select your input keyboard, then touch Next.

•Select mobile data connection, then touch Next.

•Set your date and timezone, you can also choose Automatic time zone,

then touch Next.

• Setup your Google account: Touch Set up now. If you have a Google

Account, touch Sign in, then enter your user name and password. If you
forget your password, you can go to http://www.google.com/ to retrieve
it. Touch Next to skip to the next step.

•Select your Backup & reset option, then touch Next.

•Select your location mode and touch Next.

•The Setup complete screen will display, touch Finish to confirm.

When the tablet is powered on, you can connect to a Wi-Fi network,
without a SIM card inserted (refer to section "7�1�2 Wi-Fi"), to sign into
your Google account and to use some features.

1�2�2 Power off your tablet

Hold down the Power key until the pop-up menu appears, select Power
off to confirm.

1�3 Home screen

You can bring all the items (applications, shortcuts, folders and widgets) you
love or use most frequently to your Home screen for quick access. Touch
the Home key to switch to Home screen.

Status/Notification Bar

Google Search

Multi-window

Back

Home screen is provided in an extended format to allow more space for
adding applications, shortcuts etc. Slide the Home screen horizontally left
and right to get a complete view of the Home screen. The white short line
at the lower part of the screen indicates which screen you are viewing.

Voice Actions

Home
All Apps

Menu

15 16

1�3�1 Using the touchscreen

Touch

To access an application, touch it with your finger.

Touch and Hold

Touch and hold the home screen to access the available options for setting
the wallpaper.

Drag

Place your finger on any item to drag it to another location.

Slide/Swipe

Slide the screen to scroll up and down the applications, images, web
pages… at your convenience.

Flick

Similar to swiping, but flicking makes it move quicker.

Pinch/Spread

Place your fingers of one hand on the screen surface and draw them apart
or together to scale an element on the screen.

Rotate

Automatically change the screen orientation from portrait to landscape by
turning the device sideways to have a better view.

1�3�2 Gestures

You can go to Settings\Gestures to enable the following functions:

•Whenyourdeviceisinsleepmode:Ifnoscreenlockisset,doubletapto

access the Home screen. If screen lock is set, double tap to light up the
tablet and input your unlock instruction.

•WhenyourtabletshowstheHomeorlockedscreens:doubletaponthe

main screen to turn off display and put it into sleep mode.

•Draw"C"onthesleepscreentoenterCameramodequickly.

•Draw"M"onthesleepscreentoenterMusicmodequickly.

•Muteincomingcallsbyturningthedeviceover.

•Whenanalarmison,turnthedeviceovertostoporsnoozethealarm.

•Shakethedevicetoswitchtothenextsong.

1�3�3 Status bar

From status bar, you can view both device status and notification
information.

17 18

Status icons

Notification icons

GPRS connected No signal (gray)

GPRS in use Roaming

EDGE connected

EDGE in use Signal strength (blue)

3G connected Vibrate mode

3G in use Ringer is silenced

HSPA (3G+) connected Tablet microphone is mute

HSPA (3G+) in use Battery is very low

Connected to a Wi-Fi
network

Bluetooth is on Battery is partially drained

Connected to a Bluetooth
device

Airplane mode Battery is charging

Alarm is set Headset connected

No SIM card inserted

Battery is low

Battery is full

New text or multimedia
message

Problem with SMS or MMS
delivery

New Hangouts message Call forwarding is on

New voicemail Call in progress

Upcoming event Uploading data

Data is synchronizing Downloading data

Song is playing Select input method

Screenshot captured

USB tethering is on

Portable Wi-Fi hotspot
is on

Missed call

Call on hold

An open Wi-Fi network is
available

Tablet is connected via USB
cable

Radio is on

19 20

Touch and drag down the Status bar to open the Quick setting panel or
Notification panel. Touch and drag up to close it.

Quick setting panel

Touch and drag down the Status bar to open Quick setting panel, where
you may enable or disable functions or change modes by touching the
icons.

Touch to access Settings, where you
may set more items

Touch to switch to the notification
panel

Notification panel

When there are notifications, touch and drag down the Status bar to open
the Notification panel to read the detailed information.

Touch to clear all event–based
notifications (other ongoing
notifications will remain)

Touch to switch to the
quick setting panel

21 22

1�3�4 Search bar

The tablet provides a Search function which can be used to locate
information within applications, the tablet or the web.





1�3�5 Lock/Unlock your screen

To protect your tablet and privacy, you can lock the tablet screen by
choosing slide or creating a pattern, PIN or password, etc.

To create a screen unlock pattern (refer to section "Screen lock" for
detailed settings)

•Drag down the notification panel and touch and then the settings

icon to enter Settings, then touch Lock settings\Select screen
lock\Pattern.

•Draw your own pattern.

 Search by text

• Touch Search bar from the Home screen.

•Enter the text/phrase you want to search for.

•Touch on the keyboard if you want to search on the web.

 Search by voice

•Touch from Search bar to display a dialog screen.

•Speak the word/phrase you want to search for. A list of search results will

display for you to select from.

23 24

Draw your unlock pattern

Touch to confirm by drawing pattern again

To create a screen unlock PIN/Password

•Touch Settings\Lock settings\Select screen lock\PIN or Password�

•Set your PIN or password.

•To unlock your device with your face or voice, Touch Lock settings\Select

screen lock\Face unlock or Voice unlock.

•Follow the prompted instructions to set up your face or voice unlock

settings.

To lock tablet screen

Press the Powe r key once to lock the screen.

To unlock tablet screen

Press the power key once to light up the screen, draw the unlock pattern you
have created or enter PIN or password, etc. to unlock the screen.

If you have chosen Slide as the screen lock, touch and drag the screen
rightward to unlock the screen. Touch and drag the screen leftward to
open camera.

1�3�6 Personalize your Home screen

Add

You may touch and hold a folder, an application or a widget to activate the
Move mode, and drag the item to any Home screen as you prefer.

Reposition

Touch and hold the item to be repositioned to activate the Move mode,
drag the item to the desired position and then release. You can move items
both on the Home screen and the Favorite tray. Hold the icon on the left
or right edge of the screen to drag the item to another Home screen.

Remove

Touch and hold the item to be removed to activate the Move mode, drag
the item up to the top of Remove, and release after the item turns red.

Create folders

To improve the organization of items (shortcuts or applications) on the
Home screen, you can add them to a folder by stacking one item on top
of another.

Wallpaper customization

Touch Menu key then touch Wallpaper to customize wallpaper.

1�3�7 Volume adjustment

Using volume key

Press Volume key to adjust the volume. To activate the vibrate mode,
press the Volume down key until the tablet vibrates. Press the Volume

down key once more to activate the silent mode.

Using Settings menu

Drag down the notification panel and touch and then the settings icon

to enter Settings, then touch Sound, you can set the volume of calls

renting, notification, system and etc. to your preference.

25 26

Multi-window �������������������������

2

Touch to enable the multi-window function. With this function you can

The multi-window function can also be opened in a different way when
an APP is open.

view multiple windows on your home screen.

Touch to unfold the APPs. Select an icon from the list to start an APP
on the home screen. You can also drag the APP window to the place you
prefer.

Touch to minimize
the window.

Touch to close the APP.
Touch to keep the

Touch an

APP to

bring it to

the front.

27 28

window in the front.
Touch to maximize

the window.

Touch to view the

APP in the multi­window function.

Text input ������������������������������

3

3�1 Using Onscreen Keyboard

Onscreen Keyboard settings

From the home screen, select Settings\Language & input and tap the
Settings icon next to Android keyboard� A series of settings will be
available here.

Adjust the Onscreen Keyboard orientation

Turn the device sideways or upright to adjust the Onscreen Keyboard
orientation. You can also adjust it by touching AUTO ROTATE from the
quick setting panel.

3�1�1 Android keyboard

Touch to switch between
"abc/Abc" mode; Touch &

hold to switch between

"abc/ABC" mode.

Touch to switch

to symbol and

numeric keyboard.

Touch & hold to show input options;
when Wi-Fi or data connection is
on, touch to enter voice input.

Touch
to select
emoticons.

3�2 Text editing

You can edit the text you have entered.

•Touch and hold the text you would like to edit.

•Drag the tabs to change the highlighted selection.

•The following options will appear: Select all , Cut , Copy

and Paste .

•Touch the icon to confirm.

You can also insert new text

•Touch where you want to type, or touch and hold a blank space, the

cursor will blink and the tab will show. Drag the tab to move the cursor.

•If you have selected any text, touch the tab to show PASTE and

REPLACE��� icon which allows you to paste or replace with any text

you have previously copied.

29 30

Phone call, Call log

4

and Contacts �������������������������

International call

To dial an international call, touch and hold to enter "+", then enter
the international country prefix followed by the full phone number and
finally touch .

4�1 Phone �����������������������������������������������������������

4�1�1 Placing a call

You can easily launch a call using Phone. Touch on the home screen to
access Phone application.

Contacts

Touch and hold to
access voicemail

Call log

Touch to show the dialpad

Enter the desired number from the keyboard directly or select a contact
from People or Call log by sliding or touching tabs, then touch to
place the call.

The number you entered can be saved to People by touching Add to

Contacts�

To hang up a call, touch or the Pow er key

(1)

Make sure Power key ends call is marked in call settings.

31 32

(1)

.

Emergency call

If your tablet has network coverage, dial emergency number and touch

to make an emergency call. This works even without a SIM card and

without typing the PIN code.

4�1�2 Answering or rejecting a call

When you receive a call, slide the icon .

•Slide rightward to answer;

•Slide leftward to reject;

•Slide upward to reject the call by sending a preset message.

To mute the ringtone volume of an incoming call, press the Volume up/
down key or turn the tablet face down if Turn over to mute is activated.
To activate, touch Settings\Gestures\Turn over to mute.

4�1�3 Calling your voicemail

Your voicemail is provided by your network to avoid missing calls. It works
like an answering machine that you can consult at any time.

To access your voicemail, touch and hold on Phone tab.

To set your voicemail number, touch the Menu key and select Settings\

Call settings\Voice call\Voicemail�

If you receive a voicemail, a voicemail icon appears on the Status bar.
Open the Notification panel, touch New voicemail.

4�1�4 During a call

To adjust the volume during a call, press the Volume up/down key.

Touch to hold the current call. Touch this icon again to
retrieve the call.

Touch to display Dialpad.

Touch to add a call.

Touch to mute the current call. Touch this icon again to
unmute the call.

Touch to activate the speaker during the current call. Touch
this icon again to deactivate the speaker.

Touch to start recording and add call.

33 34

4�1�5 Managing multiple calls

With this tablet you can handle multiple calls at the same time.

Swap calls

When you accept two calls, touch icon , you can now switch between
two lines. The current call is put on hold and you have joined in the other
call.

Conference calls

You can set up a conference call.

•Place a call to the first participant of the conference call.

•Touch icon .

•Enter the phone number of the person you want to add to conference and

touch icon � You can also add participants from People or Call log.

•Touch to end the conference call and disconnect all callers.

(1)

4�1�6 Call settings

Touch the Menu key and select Settings from Dial screen, the following
options are available:

Voice call

• Voicemail

Service Opens a dialog box where you can select your

carrier’s voicemail service or another service.

Voicemail settings If you are using your carrier’s voicemail service,

this opens a dialog box where you can enter the
phone number to use for listening to and managing
your voicemail. You can enter a comma (,) to insert
a pause into the number — for example, to add a
password after the phone number.

• IP prefix number

Touch to set your network operator prefix number for IP dialling.

• Call forwarding

Touch to configure how your calls are forwarded when you are busy,
unanswered or unreachable.

• Additional settings

(1)

Depending on your network operator.

Caller ID You are prompt to use default operator settings

to display your phone number in outgoing calls.

Call waiting Mark the checkbox to notify you of a new

incoming call.

Call waiting status Check the call waiting status of your tablet.

35 36

Video call

•Local video

replacement

(1)

You can pick a picture from your collection to
display when Camera is unreachable.

•Display peer video Select to display picture for replacing peer video

when it is unavailable.

•Peer video

replacement

•Enable back

Set a picture to display when peer video is
unavailable.

Select to enable switching cameras.

camera

•Peer video larger

Select to make peer video bigger than local video.

than local video

•Auto drop back Select to drop back to voice call connecting

automatically.

•Outgoing video

call

•Incoming video

call

Touch to display local video when you place a
call.

Touch to display local video when receiving an
incoming call.

•Call forwarding Touch to do video call forwarding settings.

•Additional settings Touch to make call waiting settings.

Internet call

For more information of Internet call, please refer to section 7�8
Configuring Internet (SIP) calling�

Other settings

• Fixed Dialing Numbers

Fixed Dialing Number (FDN) is a service mode of SIM, where outgoing
calls are restricted to a set of phone numbers. These numbers are added to
the FDN list. The most common practical application of FDN is for parents
to restrict the phone numbers which their children can dial.

For security reasons, you’ll be prompted to enable FDN by entering SIM
PIN2 which is usually acquired from your service provider or SIM maker.

• Minute reminder

Mark the checkbox to enable minute reminder at 50s of every minute during
a call.

• Power key ends call

Mark the checkbox to end a call by pressing the Powe r key.

• TYY mode

Mark the checkbox to enable, disable or change the TYY mode.

• Quick responses

Touch to edit quick responses which will be used when you reject a call
with messages.

• International dialing assist

Mark the checkbox to activate.

(1)

Depending on your model.

37 38

4�2 Call log

You can access your call memory by touching from the Dial screen.
Touch Call to place a call directly. There are three kinds of calls in Call log:

Missed calls

Outgoing calls

Incoming calls

Touch icons on top of call logs to change among different kinds.

Touch a contact or number to view information or perform further
operations.

You can view detailed information of a call, launch a new call or send
messages to a contact or number, or add numbers to People (only
available for unsaved phone numbers), etc.

Touch the photo to open the Quick Contact panel.

To clear the entire call memory, touch and select Delete, or touch .

To do any modification with number before call, touch and select Edit

number before call.

4�3 People������������������������������������������������������������

People enables quick and easy access to the people you want to reach.

You can view and create contacts on your tablet and synchronize these
with your Gmail contacts or other applications on the web or on your
tablet.

4�3�1 Consult your contacts

Touch to search
in People.

Touch to view your

contact groups and

favourite contacts.

Touch to view the

contact’s detailed

information.

Touch to add a
new contact.

Touch to add to your
favourite contacts.

Touch to send
a message to
the contact.

Touch to assign the
contact to a group.

39 40

Touch the Menu key to display contacts list option menu.

Following actions are enabled:

•Delete contact Select and delete unwanted contacts.

•Share visible

contacts

•Contacts to display Choose contacts to display.

•Import/Export Import or export contacts between tablet, SIM

•Accounts Manage the synchronization settings for different

•Settings Set contacts' display mode.

•Blocking incoming

calls directly

•Add to Home

screen

Share contacts with others by sending the
contact's vCard to them via Bluetooth, Email,
SMS,etc.

card, microSD card and tablet storage.

accounts.

Mark the checkbox to block incoming calls
from the contact.

Add the contact to Home screen.

4�3�2 Managing contact groups

The contact group helps you to improve the organization of your contacts.
You can add, remove and view groups in the Group screen.

Touch the icon to view local groups. To create a new group, touch the
icon , enter the new name and touch Done to confirm.

4�3�3 Adding a contact

Touch the icon in the contact list to create a new contact.

You are required to enter the contact's name and other contact information.
By scrolling up and down the screen, you can move from one field to another
easily.

Touch to save.

Touch to select a picture

Touch to add

a new label.

If you want to add more information, touch Add another field to add a
new category.

When finished, touch Done to save.

To exit without saving, you can touch Menu icon and choose Discard.

Add to/remove from Favourites

To add a contact to Favourites, you can touch a contact to view details
then touch to add the contact to Favourites (the star will turn grey
in colour).

To remove a contact from favourites, touch the grey star on contact
details screen.

Only phone contacts can be added to Favourites.

for the contact.

Touch to unfold the other
predefined labels of this

category.

41 42

4�3�4 Editing your contacts

To edit contact information, touch the Menu key on the contact details
screen, then touch Edit� When finished, touch Done.

Set ringtone for a contact

On the contact's detail screen, touch the Menu key to display contacts list
options menu, touch Set ringtone.

Delete a contact

To delete a contact, touch the Menu key and select Delete from contact
details screen.

The contact you have deleted will also be removed from other
applications on the tablet or web the next time you synchronize
your tablet.

4�3�5 Communicating with your contacts

From the contacts list, you can communicate with your contacts by making
a call or exchanging messages.

To launch a call to a contact, touch the contact to enter the detail screen,
then touch the number.

To send a message to a contact, touch the contact to enter the detail
screen, then touch the icon on the right side of the number.

The icons available on Quick Contact panel depend on the information
you have for the contact and the applications and accounts on your tablet.

4�3�6 Contacts importing, exporting and sharing

This tablet enables you to import or export contacts between device, SIM
card, microSD card and device storage.

From Contacts screen, touch     to open options menu, touch Import/
export, to import/export contacts from/to SIM card, Tablet, Tablet storage,
etc.

To import/export a single contact from/to SIM card, choose an account
and target SIM card(s), select the contact you want to import/export, and
touch OK to confirm.

To import/export all contacts from/to SIM card, choose an account and
target SIM card(s) mark Select all and touch OK to confirm.

You can share a single contact or contacts with others by sending the
contact's vCard to them via Bluetooth, Gmail, etc.

Touch a contact you want to share, touch the Menu key, and select Share
from contact details screen, then select the application to perform this
action.

4�3�7 Displaying contacts

You can configure which group of contacts, for each account you want to
display in the contacts list. Touch the Menu key and select Contacts to
display from contacts list screen, then you can choose contacts to display.

Touch the Menu key and select Settings, you can sort list by the Given
name or Family name, as well as view contact names as Given/Family name
first.

4�3�8 Joining/Separating contacts

To avoid duplication, you can add any new contact information to existing
contacts in a single action.

Touch the contact which you want to add information to, touch the Menu
key and select Edit, then touch the Menu key again and touch Join.

(1)

(1)

Only applicable for phone contacts.

43 44

At this time, you are required to select the contact whose information
you want to join with the first contact. The information from the second
contact is added to the first one, and the second contact will no longer be
displayed in the Contacts list.

4�3�9 Accounts

Contacts, data or other information can be synchronized from multiple
accounts, depending on the applications installed on your tablet.

To add an account, drag down the notification panel and touch to enter
Settings, then touch Add account.

You are required to select the kind of account you are adding, like Google,
Corporate, etc.

As with other account set-ups, you need to enter detailed information, like
username, password, etc.

You can remove an account to delete it and all associated information
from the tablet. Open the Settings screen, touch the account you want to
delete, touch the Menu key and select Remove account, then confirm.

Turn on/off the sync & Auto-sync

Touch an account to enter the account screen, mark/unmark the
checkbox(s) to turn on/off the account’s auto-sync. When activated,
all changes to information on the tablet or online will be automatically
synchronized to each other.

Sync manually

You can also synchronize an account manually on Accounts screen, touch
an account in the list, then touch the Menu key and select Sync now.

Messaging, Email �������������������

5

5�1 Messaging �����������������������������������������������������

You can create, edit and receive SMS and MMS with this tablet.
To access this feature, touch from the Home screen.

5�1�1 Write message

On message list screen, touch the new message icon to write text/
multimedia messages.

Touch to create a new message.
Touch to search in all messages.

•Touch to view the whole message

thread.

•Touch and hold to Delete

thread or Add shortcut.

All messages you receive or send out can be saved in device
memory or SIM card. To consult the SMS messages stored in SIM
card, touch from Messaging screen, then touch Settings\Text
message(SMS)\Manage SIM card messages.

45 46

Sending a text message

Attach options:

Enter the mobile phone number of the recipient or touch to add
recipients, touch Type text message bar to enter the text of the

message. When finished, touch to send the text message.

An SMS message of more than 160 characters will be charged as several
SMS. A counter will appear upon the Send option of the text box to remind
you how many characters are allowed to be entered in one message.

Specific letters (accent) will increase the size of the SMS, which may
cause multiple SMS to be sent to your recipient.

Sending a multimedia message

MMS enables you to send video clips, images, photos, animations, slides and
sounds to other compatible mobiles and e-mail addresses.

An SMS will be converted to MMS automatically when media files (image,
video, audio, slides, etc.) are attached or subject or email addresses are
added.

To send a multimedia message, enter the recipient's phone number or

touch , touch Type text message bar to enter the text of the
message, touch the Menu key to open the option menu, select Add
subject to insert a subject, and touch to attach picture, video, audio
and so on.

When finished, touch to send the multimedia message.

•Pictures Access Gallery application or File manager to

select a picture as attachment.

•Capture picture Access Camera to capture a new picture for

attaching.

•Videos Access Gallery application or File manager to

select a video as attachment.

•Capture video Access Camcorder to record a new video for

attaching.

•Audio Access to select an audio file as attachment.

•Record audio Enter Sound Recorder to record a voice message

for attaching.

•Slideshow Enter Edit slide show screen, touch Add slide to

create a new slide, and touch currently existing
slide to edit it (see following picture). Touch the
Menu key to get more actions, like setting the
slide duration, adding music, etc.

•Contact Access People application to select one or

more contact(s) to attach.

•Calendar Access Calendar application to select one or

more event(s) to attach.

•Add subject Touch to add a subject to the message.

•Insert quick text Access quick text library, select one or more

quick texts to attach.

47 48

Touch to go to previous or next slide.
Touch to preview the current slide.

Touch to edit the title of this slide.

5�1�2 Manage messages

When receiving a message, an icon will appear on status bar as
notification. Drag down the status bar to open the Notification panel,
touch the new message to open and read it. You can also access the
Messaging application and touch the message to open.

Messages are displayed in conversational order.

To reply to a message, touch the current message to enter message­composing screen, enter the text, then touch .

Touch and hold an SMS in message details screen. The following message
options are available for selection:

•Copy This option displays when the message is an SMS.

•Forward Touch to forward the message to another recipient.

•Delete Delete the current message.

•Lock/Unlock Touch to lock/unlock the message so it can't/

•Add number to

contact

•View details Touch to view details of the message.

•Select text Touch to select the message text to copy, cut, add

•Save message to

SIM card

Copy the current message content. You can paste
it to the enter bar of the new message you are
going to compose.

can be deleted if you reach maximum number of
stored messages.

Touch to save this number to People.

to dictionary, etc.
This option displays when the message is an SMS.

Touch to save the message to SIM card.

5�1�3 Adjust message settings

You can adjust a set of message settings. From Messaging application
screen, touch the Menu key and select Settings.

49 50

Text message (SMS)

•Delivery reports Select to request a delivery report for each text

•Manage SIM card

messages

•Edit quick text Touch to add or edit message templates.

•SMS service

center

•SMS validity

period

•SMS storage

location

Multimedia message (MMS)

•Group messaging Mark the checkbox to send a single message to

•Delivery reports Select to request a delivery report for each

•Read reports Select to request a report on whether each

•Send read report Select to request a report on whether the

•Auto-retrieve Select to download the full MMS message

message you send.

Touch to manage messages stored on your SIM
card.

Touch to set the service center.

Touch to set the validity period of messages.

Touch to select device or SIM card to store
messages.

multiple recipients.

multimedia message you send.

recipient has read a multimedia message sent by
you.

multimedia message is sent out.

(including message body and attachment)
automatically to your tablet. Otherwise,
download only the MMS message header.

•Roaming auto-

retrieve

•Creation mode Touch to select MMS creation mode.

•Maximum

message size

•Priority Touch to set the priority of MMS.

Notifications

•Notifications Select to display message notifications in status

•Mute Touch to mute or select the time interval of

•Select ringtone Touch to select a ringtone as a new message

Select to download the full MMS message
(including message body and attachment)
automatically when roaming. Otherwise,
download only the MMS message header to
avoid extra charges.

Select to edit the message size, but it should not
be more than 300KB.

bar.

notification sound.

notification tone.

51 52

General

• Chat wallpaper Touch to select wallpaper for message

•Message font size Touch to select message font size.

•Show email

address

•Delete old

messages

• Text message limit Touch to set the number of text messages to be

•Multimedia

message limit

•Cell broadcast Touch to choose a SIM card and configure cell.

•Enable CB

ringtone

•Select CB

ringtone

•Cell broadcast Touch to choose a SIM card and configure cell.

•Enable WAP

PUSH

background.

Mark the checkbox to include email address in
contact results.

Select to delete old messages when the maximum
number of stored messages is reached.

saved per conversation.

Touch to set the number of multimedia
messages to be saved per conversation.

Mark the checkbox to enable CB ringtone.

Touch to select a ringtone for cell broadcast
messages.

Mark the checkbox to enable to receive WAP
PUSH.

5�2 Gmail/Email

The first time you set up your tablet, you can select to use an existing
Gmail or to create a new Email account.

5�2�1 Gmail �������������������������������������������������������������������

As Google's web-based email service, Gmail is configured when you first
set up your tablet. Gmail on your tablet can be automatically synchronized
with your Gmail account on the web. Unlike other kinds of email account,
each message and its replies in Gmail are grouped in your inbox as a single
conversation; all emails are organized by labels instead of folders.

To access Gmail

Gmail displays messages and conversations from one single Gmail account
at a time, if you own more than one account, you can add a new one by
touching the Menu key and selecting Settings from Home screen, then
touch ADD ACCOUNT. When finished, you can switch accounts by
touching the account name from Inbox screen, and touch the account you
want to view.

To create and send emails

•Touch the icon from Inbox screen.

•Enter recipient(s)’s email address in To field, and if necessary, touch +

CC/BCC to add a copy or a blind copy to the message.

•Enter the subject and the content of the message.

•Touch the Menu key and select Attach file or touch the zip icon next

to the Subject row to add an attachment.

•Finally, touch the icon to send.

•If you do not want to send the mail out right away, you can touch the

Menu key and select Save draft or touch Back key to save a copy. To
view the draft, touch the icon , then select Drafts.

53 54

If you do not want to send or save the mail, you can touch the Menu key
and then select Discard.

To add a signature to emails, touch the Menu key and select Settings
from inbox screen, choose an account, then touch Signature.

To receive and read your emails

When a new email arrives, you will be notified by a ringtone or vibration,
and an icon will appear on Status bar.

Touch and drag down the Status bar to display the Notification panel, touch
the new email to view it. Or you can also access the Gmail Inbox label and
touch the new mail to read it.

You can search for an email by sender, receiver, subject, etc.

•Touch the icon from Inbox screen.

•Enter the keyword you want to search for in the searching box and touch

in the soft keyboard.

To reply or forward emails

•Reply

•Reply all

•Forward

•Favourite

When viewing an email, touch to reply the
sender of this mail.

Touch and select "Reply all" to send message to
all people in a mail loop.

Touch to forward the received mail to other
people.

Touch to assign a star and add the mail to the
favourite.

Managing Gmails by Labels

To conveniently manage conversations and messages, you can organize
them using a Label.

To view conversations by labels when viewing your inbox or another
conversation list, touch the icon , then touch a label to view a list of
conversations with that label.

To manage labels, touch Menu key and select Manage labels�

Mark the checkbox to select email to activate batch mode, and
generate the following options:

•

•

•

•

•Change labels Touch to add or change the label of the email

•Mark as (not)

important

•Mute To mute the entire conversation. When muted,

•Report spam To report the email message/conversation as spam.

•Report phishing To report the email message/conversation as phishing.

Touch to archive the email message. To display the
archived messages, you can touch in Inbox screen
then touch All mail.

Touch to delete the email message.

Touch to mark an email message as read or unread.

Touch to move the email to another labeled folder.

message or conversation.

To mark the email as important or not important.

new mails related to this conversation will not be
displayed in Inbox, but archived.

55 56

Gmail settings

To manage Gmail settings, touch the Menu key and select Settings in Inbox
screen.

General settings

•Confirm before

deleting

•Confirm before

archiving

•Confirm before

sending

•Reply all Mark the checkbox to make the default

•Auto-fit messages Mark the checkbox to zoom in/out the

•Auto-advance Touch to select which screen to show after

•Sender image Mark the checkbox to show beside name

•Archive & delete

actions

•Swipe to archive Mark the checkbox to enable archive the

Mark the checkbox to confirm before
deleting emails.

Mark the checkbox to confirm before
archiving emails.

Mark the checkbox to confirm before
sending emails.

responding to messages.

messages to fit the screen.

you delete or archive a conversation.

in conversation list.

Touch to change the archive and delete
actions.

mail by swiping in the conversation list.

Touch an account, the following settings will show:

•Inbox type To set this inbox as the default one or priority

•Inbox catergories Touch to set the inbox catergories.

•Notifications Select to activate notification when a new email

•Inbox sound Touch to set Sound, Vibrate and Notify once.

•Signature To add a signature text to the end of each mail

•Vacation

responder

•Sync Gmail Touch to turn on/off Gmail sync.

•Days of mail to

sync

•Manage labels Touch to open the Label screen, where you can

•Download

attachments

•Images Touch to show or hide the images.

one.

arrives.

you send.

Touch to set the automatic respond during preset
vacation period.

Touch to set the duration of days for mail sync.

manage synchronization and notifications.

Mark the checkbox to auto download attachments
to recent messages via Wi-Fi.

57 58

5�2�2 Email ���������������������������������������������������������������������

Besides your Gmail account, you can also set up external POP3 or IMAP
email accounts in your tablet.

To access this function, touch Email from Home screen.

An email wizard will guide you through the steps to set up an email
account.

•Enter the email address and password of the account you want to set up.

•Touch Next. If the account you entered is not provided by your service

provider in the tablet, you will be prompted to go to the email account
settings screen to enter settings manually. Or you can touch Manual
setup to directly enter the incoming and outgoing settings for the email
account you are setting up.

•Enter the account name and display name in outgoing emails.

•To add another email account, you can touch Menu key and Settings.

Touch Add account to create.

To create and send emails

•Touch the icon from Inbox screen.

•Enter recipient(s) email address(es) in To field.

•If necessary, touch + CC/BCC to add a copy or a blind copy to the

message.

•Enter the subject and the content of the message.

•Touch Menu key , touch Attach file to add an attachment.

•Finally, touch to send�

•If you do not want to send the mail right away, you can touch Menu key

and Save draft or touch Back key to save a copy.

5�3 Hangouts�����������������������������������������������������

Google's instant messaging service, Google Hangouts, lets you communicate
with your friends whenever they are connected to this service.

To access this feature and sign in, touch Application tab from the Home
screen, then touch Hangouts. All friends added by using Google Hangouts
from the web or tablet will be displayed in your friends list.

5�3�1 Chatting with your friends

To start a chat, touch the name of a friend in your Friends list, then enter
your message and finally touch .

You can invite other friends to join in a group chat by touching key
then selecting the friend you want to add.

5�3�2 To add a new friend

From Friends list, touch the icon to add a new friend.

Enter the name, email, number or Circle of the friend you want to add, and
if the friend is not yet on Hangouts, the system will require to send invite
by telling the friend via SMS or Gmail. A notification with this invitation will
be showed in your friend’ messaging or Gmail.

If your friends invite you to do video talk or they send you message in the
first time, you could select Decline or Reply in response by touching Menu
key and Hangout requests.

59 60

5�3�3 To start and close a chat

Touch one friend from friends list, you could send messages to your friends
or have a video call;

After you join Google+, you could send pictures to everyone in the Google
Hangouts.

When you want to end a chat, touch back key from Chatting screen
directly.

If you want to sign out, touch Menu key and Settings\Sign out.

5�3�4 To manage your friends

Besides adding new friends to your friends list, the following actions are
available for your choice:

•To view all friends By default, all your friends are displayed in

Friends list. Touch your friend could start the
conversation directly. Touch and hold the friend
to activate archive and delete.

5�3�5 Settings

A series of settings are available for your selection by touching Menu key
and Settings from Friends list screen, and choose an account.

•Profile photo Touch to set or change your Google + profile

•Share your status Touch to set the hangouts status with friends.

•Hangouts

messages & invites

•Video Calls Touch to set the notification type when

•Hidden contacts Touch to view hidden people.

•Sign out Touch to remove your accounts.

•Improve Hangout Mark the checkbox to report usage data to help

photo.

Mark the checkbox to activate the notification
type when receiving Hangouts requests.

receiving a video call.

improve Hangouts.

61 62

Calendar & Time ���������������������

6

6�1 Calendar ������������������������������������������������������

Use Calendar to keep track of important meetings, appointments, etc.

6�1�1 Multimode view

You can display the Calendar in weekly, monthly, yearly or agenda view.

Touch the Month/Week/Agenda label on the bottom of the screen to
change your Calendar view, Touch the icon to return to Today's view.

Year view

In Agenda or Week
view touch an event
to view its details.

Agenda view

Touch a day in Month
view to open that day's
events.

Week view

Month view

6�1�2 To create new events

You can add new events from any Calendar view.

•Touch the icon to access new event edit screen.

•Fill in all required information for this new event. If it is a whole-day

event, you can select All day.

•Invite guests to the event. Enter the email addresses of the guests you

want to invite with commas to separate. The guests will receive an
invitation from Calendar and Email.

•When finished, touch DONE from the top of the screen.

To quickly create an event from Week view screen, touch and hold an
empty spot or an event to open Option menu, then touch New event to
enter the event details screen of the time you have previously selected. Or
you can also touch the empty spot to select the target area which will turn
blue, and tap again to create the new event.

6�1�3 To delete or edit an event

To share, delete or edit an event, touch the event to enter details screen,
touch the icon to share the event to other people by Bluetooth, Email
and messaging, etc., touch the icon to edit the event, and touch the
icon to delete, you can also assign a color to specific event by touching
the icon .

63 64

6�1�4 Event reminder

If a reminder is set for an event, the upcoming event icon will appear on
Status bar as a notification when the reminder time arrives.

Touch and drag down the status bar to open the notification panel, touch
event name to view Calendar notification list.

Touch Snooze to turn off all event reminders for 5 minutes.

Touch Back key to keep the reminders pending on the status bar and the
notification panel.

Important options by touching the Menu key from Calendar main screen:

•Refresh To refresh the calendar

•Search To search in the calendar

•Calendars to display To show or hide, remove or add calendars

•Settings To make a series of Calendar settings

•Clear events To clear the selected events

•Go to To jump to the date you set

6�2 Time �������������������������������������������������������������

Time application includes four applications – World clock, Alarm,
Timer and Countdown.

Touch Alarm to add or set an alarm.

6�2�1 To set an alarm

From Time screen, touch to enter Alarm screen, touch to add a
new alarm. Following options will show:

•Label Touch to set a name for the alarm

•Repeat Touch to select days you want alarm to work

•Ringtone Touch to select a ringtone for the alarm

•Time Scroll to set time.

When finished, touch OK to confirm.

Touch and hold on a currently existing alarm and touch Delete alarm to
delete the selected alarm.

6�2�2 To adjust alarm settings

Touch Menu icon from Alarm screen. The following options can now
be adjusted:

•Alarm in silent

mode

•Snooze duration Touch to set temporary turn off time of an alarm

•Volume buttons Touch to set side Volume up/down key

•Turn over to

activate

Select to play alarm with sound or vibration
even when the tablet is in Silent mode

behaviors when alarm sounds: None, Snooze
or Dismiss

Touch to choose the status Snooze or
Dismiss. Touch the switch to turn on/off
snoozing or dismissing the alarm by turning
over the tablet

65 66

Getting connected ����������������

7

To connect to the internet with this tablet, you can use GPRS/EDGE/
WCDMA/LTE networks or Wi-Fi, whichever is most convenient.

7�1 Connecting to the Internet

7�1�1 GPRS/EDGE/WCDMA/LTE

The first time you turn on your tablet with SIM card inserted, it will
automatically configure network service: GPRS, EDGE WCDMA or LTE.
If the network is not connected, you can touch on quick setting panel.

To check the network connection you are using, then touch Settings\

More���\Mobile networks\Access Point Names or Network
operators�

To create a new access point

A new GPRS/EDGE/WCDMA/LTE network connection can be added to
your tablet with the following steps:

•Drag down notification panel and touch to access Settings.

•Touch More���\Mobile networks\Access Point Names

•Touch Menu key and select New APN.

•Enter the required APN information.

•When finished, touch the Menu key and select Save.

To activate/deactivate Data roaming

When roaming, you can decide to connect/disconnect to a data service.

•Drag down notification panel and touch to access Settings.

•Touch SIM management\Roaming\Data roaming�

•Touch to select from popup options: Disable, National Roaming only

and All Networks.

•When Data roaming is deactivated, you can still perform data exchange

with a Wi-Fi connection (refer to "7�1�2 Wi-Fi").

7�1�2 Wi-Fi

Using Wi-Fi, you can connect to the Internet when your tablet is within
range of a wireless network. Wi-Fi can be used on your tablet even without
a SIM card inserted.

To turn Wi-Fi on and connect to a wireless network

•Touch on quick setting panel to get to Settings.

•Touch the switch beside Wi-Fi to turn on/off Wi-Fi.

•Touch Wi-Fi, the detailed information of detected Wi-Fi networks is

displayed in the Wi-Fi networks section.

•Touch a Wi-Fi network to connect. If the network you selected is

secured, you are required to enter a password or other credentials (you
may contact your network operator for details). When finished, touch
Connect.

67 68

To activate notification when a new network is detected

When Wi-Fi is on and the network notification is activated, the Wi-Fi icon
will appear on the status bar whenever the tablet detects an available
wireless network within range. The following steps activate the notification
function when Wi-Fi is on:

•Drag down notification panel and touch to access Settings.

•Touch Wi-Fi. Then touch the Menu key and select Advanced from

Wi-Fi screen.

•Mark/Unmark the Network notification checkbox to activate/

deactivate this function.

To add a Wi-Fi network

When Wi-Fi is on, you may add new Wi-Fi networks according to your
preference.

•Drag down notification panel and touch to access Settings.

•Touch Wi-Fi, and then touch .

•Enter the name of the network and any required network information.

•Touch Save.

When successfully connected, your tablet will be connected automatically
the next time you are within range of this network.

To forget a Wi-Fi network

The following steps prevent automatic connections to networks which you
no longer wish to use.

•Turn on Wi-Fi, if it’s not already on.

•In the Wi-Fi screen, touch & hold the name of the saved network.

•Touch Forget network in the dialog that opens.

7�2 Browser ���������������������������������������������������������

Using Browser, you can enjoy surfing the Web.

To access this function, touch from Home screen and then touch
Browser icon .

To go to a web page

On Browser screen, touch the URL box at the top, enter the address of
the web page, then touch to confirm.

Touch to delete all contents.
Touch choose from bookmarks.
Touch to go to the

suggested web site.

The URL bar will hide after a few seconds. To show the URL bar, you can
touch and slide down the screen.

To set homepage

•Touch the Menu key from Browser screen to display option menu, touch

Settings\General\Set home page.

•Choose a page or most visited website as your homepage.

•If you choose Other, enter the URL of the website you want to set as

your homepage, touch OK to confirm.

69 70

7�2�1 Viewing web pages

When opening a website, you can navigate on web pages by sliding your
finger on the screen in any direction to locate the information you want
to view.

To zoom in/out of a web page

Pinch/Spread your finger on the screen to zoom out/in of the web page.

To quickly zoom into a section of a web page, double-tap on the section
you want to view. To return to normal zoom level, double-tap again.

To find text on a web page

• Touch the Menu key from web page screen, then select Find on page.

•Enter the text or phrase you want to find.

•The first word with matching characters will be highlighted on the

screen, and subsequent matches will be boxed.

•Touch the up or down arrow to switch to the previous or next matching

items.

•When finished, you can touch or the Back key to close the search

bar.

Further operations for the text on a web page

You can copy, share or search the text from a web page:

•Touch and hold the text to highlight the text.

•Move the two tabs to select the text.

•Touch to select all words in this web screen.

•Touch to copy the selected text.

•Touch to show further actions, including find, share and search on the

page or the web.

•When finished, touch or the Back key to deactivate the mode.

Other options:

•Refresh To refresh the current page.

•Stop To stop opening the current page.

•Home page To get back to the home page you set.

•Close To close all tabs and exit.

•Share page To share the current page with your friends via various

•Find on page To input contents you want to find on the current

•Request

desktop site

•New tab To open a new tab.

•Page info To check the detailed web page information.

•Version To see the version of browser.

Touch the icon on the left of the URL, you can view more
information about the current page.

ways, like Messaging, Email, Bluetooth, etc.

page.
To enable/disable computer version websites.

7�2�2 Manage links, history and downloads

To manage a link, phone number or address displayed on a web
page

•Link Touch the link to open the web page.

Touch and hold the link to open options for further
operation, like open in new window, save link, copy
link URL, etc.

•Phone number Touch to call the phone number.

•Address Touch to open Google Maps and locate the address.

71 72

To view Browser history

•Touch the from Browser screen.

•Touch Bookmarks tab to view the bookmarks.

•Touch History tab to view browser history.

To download a web application/view your downloads

Before downloading a web application, you need to enable your tablet to
install web applications (touch the Menu key from the Home screen, touch
Settings\Security, mark the checkbox of Unknown sources, finally
touch OK to confirm).

To download an item, touch the item or the link you want to download.

To cancel a download, touch the downloaded item from the Notification
panel, select the item to be cancelled, and touch to confirm.

To view items you have downloaded, touch the application Downloaded.

Manage bookmarks

To bookmark a web page

•Open the web page you want to bookmark.

•Touch the star beside the URL.

•Enter the Label and the location if needed and touch OK to confirm.

To open a bookmark

•Touch the icon to enter the Bookmarks/History screen.

•Touch the bookmark you want to open.

•You can also touch and hold to display the options screen, then touch

Open or Open in new tab�

To edit a bookmark

•Touch the icon to enter the Bookmarks\History screen.

•Touch and hold the bookmark you want to edit.

•Touch Edit bookmark, and input your changes.

•When finished, touch OK to confirm.

Touch and hold a bookmark in the bookmark list to view these
additional options:

•Add shortcut to

Home

•Share link To share the bookmark.

•Copy link URL To copy the bookmark link.

•Delete bookmark To delete a bookmark.

•Set as homepage To set this page as the homepage.

To add a bookmark shortcut to the Home
screen.

7�2�3 Settings

A series of settings are available for your adjustment. To access Browser
settings, touch the Menu key from Browser screen, and select Settings.

General

•Set home page Touch to set homepage.

Privacy & security

•Clear cache Touch to clear locally cached content and

•Clear history Touch to clear the browser history.

•Show security

warnings

•Accept cookies Mark to allow sites to save and read cookie data.

databases.

Mark the checkbox to show warning if there is a
problem with a site’s security.

73 74

•Clear all cookie

data

•Remember form

data

•Clear form data Touch to clear all the saved form data.

•Enable location Mark the checkbox to allow sites to request

•Clear location

access

•Remember

passwords

•Clear passwords Touch to clear all saved passwords.

Accessibility

•Preview To preview the text size.

•Text scaling Slide to change the size of the text display.

•Zoom on double-

tap

•Minimum font size Slide to change the minimum font size.

Advanced

•Set search engine Touch to select a search engine.

•Open in

background

•Enable JavaScript Mark the checkbox to enable JavaScript.

•Enable plug-ins Mark the checkbox to enable plug-ins.

Touch to clear all browser cookies.

Mark the checkbox to remember data in forms
for later use.

access to your location.

Touch to clear location access for all websites.

Mark the checkbox to save usernames and
passwords for websites.

Slide to change the magnification level when
double-tapping the page.

Mark the checkbox to open new windows behind
the current one.

•Website settings Touch to view advanced settings for individual

•Open pages

in overview

•Auto-fit pages Mark the checkbox to format web pages to fit

•Block pop-up

windows

•Text encoding Touch to select the character-encoding standard.

•Reset to default Touch to clear all browser data and to reset all

Bandwidth management

•Search result

preloading

•Web page

preloading

•Load images Mark the checkbox to display images on web

Labs

•Quick controls Mark the checkbox to enable quick controls and

websites.

Mark the checkbox to open web pages zoomed
out, in an overview.

the screen.

Mark the checkbox to prevent pop-up windows.

settings to default.

Touch to enable/disable browser to preload
search results in the background.

Touch to enable/disable browser to preload the
linked web pages in the background.

pages.

hide app and URL bars.

75 76

7�3 Connecting to Bluetooth devices

(1)

Bluetooth is a short-range wireless communication technology that you
can use to exchange data, or connect to other Bluetooth devices for
various uses.

To access this function, drag down notification panel and touch to
access Settings. Then touch Bluetooth, your device and other available
ones will display on the screen.

To turn on Bluetooth

•Drag down notification panel and touch to access Settings.

•Touch to activate/deactivate this function.

To make your tablet more recognizable, you can change your tablet name
which is visible to others.

•Drag down notification panel and touch to access Settings.

•Touch Bluetooth.

•Touch the Menu key and select Rename tablet.

•Enter a name, and touch Rename to confirm.

To make device visible

•Drag down notification panel and touch to access Settings.

•Touch Bluetooth.

•Touch your device to make it visible or invisible.

•Touch the Menu key and select Visibility timeout to select the visible

time.

(1)

You are recommended to use ALCATEL ONETOUCH Bluetooth headsets,

which have been tested and proved compatible with tablet. You can go to www.
alcatelonetouch.com for more information about ALCATEL ONETOUCH
Bluetooth headset.

77 78

To pair/connect your tablet with a Bluetooth device

To exchange data with another device, you need to turn Bluetooth on
and pair your tablet with the Bluetooth device with which you want to
exchange data.

•Drag down notification panel and touch to access Settings.

•Touch Bluetooth.

•Touch SEARCH FOR DEVICES.

•Touch a Bluetooth device you want to be paired with in the list.

•A dialog will popup, touch Pair to confirm.

•If the pairing is successful, your tablet connects to the device.

To disconnect/unpair from a Bluetooth device

•Touch the Settings icon beside the device you want to unpair.

•Touch Unpair to confirm.

7�4 Connecting to a computer

With the USB cable, you can transfer media files and other files between
microSD card/internal storage and computer.

Before using MTP or PTP you should firstly mark USB debugging.

•To access this function, touch Settings\About device, then touch

Build number 7 times. Now you may touch Settings\Developer
options\USB debugging.

To connect/disconnect your tablet to/from the computer:

•Use the USB cable that came with your tablet to connect the tablet to a

USB port on your computer. You will receive a notification that the USB
is connected.

•If you use mass storage, touch USB storage, then open the Notification

panel and touch USB connected, then touch Mount in the dialog that
opens to confirm that you want to transfer files.

•If you use MTP or PTP, your tablet will be automatically connected.

To disconnect (from mass storage):

•Unmount the microSD card on your computer.

•Open the Notification panel and touch Turn off.

For the operating system Windows XP or lower, you should
download and install Windows Media Player 11 on your computer
from the following link: http://windows.microsoft.com/zh-CN/
windows/download-windows-media-player.

To locate the data you have transferred or downloaded in the internal
storage, touch File Manager, all data you have downloaded is stored in
File Manager, where you can view media files (videos, photos, music and
others), rename files, install applications into your tablet, etc.

To format a microSD card

•Drag down notification panel and touch to access Settings.

•Touch Storage�

•Touch Erase SD card. A screen warns you that erasing the microSD

card will loose all the data on the card, touch if you confirm.
Then touch Erase everything.

7�5 Sharing your tablet's mobile data connection

You can share your tablet's mobile data connection with a single computer
via a USB cable (USB tethering) or with up to eight devices at once by
turning your tablet into a portable Wi-Fi hotspot.

The functions below may incur additional network charges from
your network operator. Extra fees may also be charged in roaming
areas.

To share your tablet's data connection via USB

Use the USB cable that along with your tablet to connect the tablet to a
USB port on your computer.

•Drag down notification panel and touch to access Settings.

•Touch More���\Tethering & portable hotspot.

79 80

•Mark\Unmark the checkbox of USB tethering to activate/deactivate

this function.

To share your tablet's data connection as a portable Wi-Fi hotspot

•Drag down notification panel and touch to access Settings.

•Touch More���\Tethering & portable hotspot.

•Touch the switch beside Wi-Fi hotspot to activate/deactivate

this function.

To rename or secure your portable hotspot

When Portable Wi-Fi hotspot is activated, you could change the name of
your tablet's Wi-Fi network (SSID) and secure its Wi-Fi network.

•Drag down notification panel and touch to access Settings.

•Touch More���\Tethering & portable hotspot\Wi-Fi hotspot.

•Touch Set up Wi-Fi hotspot to change the network SSID or set your

network security.

•Touch Save.

7�6 Connecting to virtual private networks

Virtual private networks (VPNs) allow you to connect to the resources
inside a secured local network from outside that network. VPNs are
commonly deployed by corporations, schools, and other institutions so
that their users can access local network resources when not inside that
network, or when connected to a wireless network.

To add a VPN

•Drag down notification panel and touch to access Settings.

•Touch More���\VPN and then touch .

•In the screen that opens, follow the instructions from your network

administrator to configure each component of the VPN settings.

•Touch Save.

The VPN is added to the list on the VPN settings screen.

Before adding a VPN, you should set a lock screen pattern, PIN
code or password for your tablet.

To connect/disconnect to a VPN

To connect to a VPN:

•Drag down notification panel and touch to access Settings.

•Touch More���\VPN.

•VPNs you have added are listed; touch the VPN you want to connect with.

•In the dialog that opens, enter any requested credentials and touch

Connect.

To disconnect:

•Open the Notification panel and touch the resulting notification for the

VPN disconnection.

To edit/delete a VPN

To edit a VPN:

•Drag down notification panel and touch to access Settings.

•Touch More���\VPN.

•VPNs you have added are listed; touch & hold the VPN you want to edit.

•Touch Edit profile.

•After finished, touch Save.

To delete:

•Touch and hold the VPN you want to delete, in the dialog that opens,

touch Delete profile.

7�7 Connecting to TV using Peel Smart Remote

With Peel Smart Remote, you can easily find and watch your favorite
television programs. Peel Smart Remote will recommend new shows based
on past programs you have viewed. Watch TV shows by genres, share
what you are watching with your friends, and control playback, volume, or
navigation with the built-in gestures.

From the Home screen touch , follow the on-screen instructions to
set up Peel Smart Remote.

Touch to select
show time.

Touch to search,

browse programs

and make

additional settings.

Touch to select or
add rooms.

Touch to show the
remote control. You need
to configure before use.

7�8 Configuring Internet (SIP) calling

You can place/receive voice calls via the Internet when connected to a
Wi-Fi network, rather than via your mobile network. You should configure
a valid internet account before using this feature. Refer to section 4�1�1
Placing a call to learn more about placing an internet call.

81 82

To add an internet calling account

•Select Phone from the Home screen.

•Touch the Menu key and then select Settings\Internet call\Use

Internet calling�

•Mark the checkbox to enable Internet calling.

•Touch Accounts, then touch ADD ACCOUNT tab.

•In the screen that opens, follow the instructions from your internet

calling service provider to configure the settings for your account.

•When finished, touch SAVE to confirm or touch DISCARD to cancel.

To edit/remove an internet calling account

To edit:

•Select Phone from the Home screen.

•Touch the Menu key and then select Settings\Internet call\Accounts.

•Accounts you have added are listed; touch the account you want to edit.

•Edit your chosen settings. When finished, touch SAVE.

To remove:

•Touch the account you want to remove.

•Touch the Menu key and select Remove account.

Google Play Store

8

Google Play Store is an online software store, where you can download
and install applications and games to your Android Powered Tablet.

To open Google Play Store:

•Touch Google Play Store from Home screen.

•For the first time you access Google Play Store, a screen with terms of

service pops up for your attention, touch Accept to continue.

Touch and then select Help to enter Google Play Store help page for
more information on this function.

(1)

���������

8�1 Locate the item you want to download

and install

Google Play Store home page provides several ways to find applications. It
shows applications and games in categorized listings.

Touch and select My apps to see all your downloads.

Touch to search in Google Play Store.

To configure your tablet to receive Internet calls

Receiving Internet incoming calls is off by default to reduce power
consumption.

•Select Phone from the Home screen.

•Touch Settings\Internet call\Accounts\Receive incoming calls.

•Mark/Unmark the checkbox to activate/deactivate this function.

83 84

Slide up and down to see all categories.

(1)

Depending on your country and operator.

Touch a category on Google Play Store screen to browse its contents. You
can also select a subcategory if there is any. Within each category you can
select to view items sorted by Top free, Top new free, Trending, etc

Touch the Google Play Store icon on the top left of the screen or
touch Back key to return to the previous screen.

8�2 Download and install

To download & install:

•Navigate to the item you want to download, and select to enter the

details screen from which you can read its description, overall rating or
comments, view developer’s information, etc.

•Touch Install to preview the functions and data the application can

access on your tablet if you install it.

•Touch Accept.

•The progress of the download will show on the details screen, touch

to stop downloading the item. You can also access this screen through
Notification panel.

•After download and installation have finished, you will see a notification

icon on the status bar.

Be especially cautious with applications that have access to many
functions or to a significant amount of your data. Once you accept,
you are responsible for results of using this item on your tablet.

To open the application you have downloaded:

•On Google Play Store screen, touch and select My apps.

•Touch the installed application in the list, then touch Open.

To buy an application

(1)

On Google Play Store, some applications are labeled as free, while some
of them are to be paid for before downloading and installing.

•Touch the application you want to buy.

•Touch the price on the up-right of the screen to preview the functions

and data the application can access on your tablet if you install it.

•Touch Accept to confirm.

•When making your first purchase, you are required to input your credit

card information and to log in to Google payment and billing service.

•If your account has multiple credit card accounts, select one to proceed.

•Select the Terms of service link and read the document. When finished,

touch Back ke y.

•Mark the checkbox if you agree with the terms of service.

•Touch Buy now at the bottom of the screen.

When finished, Android downloads the application.

To request a refund

If you are not satisfied with the application, you can ask for a refund within
15 minutes of the purchase. Your credit card will not be charged and the
application will be removed. If you change your mind, you can install the
application again, but you will not be able to request a refund.

•Touch and select My apps from Google Play Store screen.

•Touch the application that you want to uninstall and refund.

•Touch Refund to uninstall the application and refund. If the button

becomes Uninstall, your trial period has expired.

•In the survey form, select the answer that best matches your reason,

and touch OK.

(1)

Google Paid applications may not be available to users in some countries.

85 86

8�3 Manage your downloads

After you downloaded and installed an application, the following further
operations are available for your selection.

View

On Google Play Store screen, touch and select My apps.

Uninstall

On Google Play Store screen, touch and select My apps. Touch
the application you want to uninstall to enter the details screen, touch

Uninstall, and finally touch OK to confirm.

Refund

On Google Play Store screen, touch and select My apps. Touch the
application you want to uninstall for a refund, touch Refund, and finally
touch OK to confirm.

Update notification

On Google Play Store screen, touch select Settings\Notifications to
enable update notification.

Auto update

To auto update all installed applications, touch and select Settings\
Auto-update apps to enable this function.

To auto update one specific application, touch the Menu key from the
Apps tab, and mark the checkbox of Auto-update.

Rate and review

Open the details screen for the downloaded application, touch the stars

under Rate this app to award and input comments,

touch Submit to confirm.

Flag

You can report an inappropriate application to Google Play Store by
flagging it. Open the details screen for the downloaded application, scroll
to the bottom and touch Flag as inappropriate, select the reason and
finally touch Submit.

87 88

Multimedia applications �������

9

9�1 Camera �������������������������������������������������������

Your tablet is fitted with a Camera for taking photos and shooting videos.

Before using the Camera, please be sure to open the protective lens cover
before use to avoid it affecting your picture quality.

Touch to switch

between on, off or

automatic mode.

Touch the screen

to set a focus.

Double-tap or

pinch two or

more fingers

together or

spread them

apart to zoom

in/out.

Touch to take a picture.

Touch to show settings

Touch to switch
between front/back
camera

Slide to view pictures
or videos you have
taken.

Slide to switch
between camera and
camcorder.

To take a picture

The screen acts as the viewfinder. First position the object or landscape in
the viewfinder, touch the screen to focus if necessary, touch icon to

take the picture which will be automatically saved.

You can also press the Volume key or touch and hold the viewfinder until
the picture is taken.

To shoot a video

First position the object or landscape in the viewfinder, and touch icon
to start recording. Touch to pause recording, touch again or press
the Back key to save the video.

Further operations when viewing a picture/video you have taken

•Slide the screen rightward to access Gallery.

•Touch the photo, and touch the icons below to share, edit, set as

wallpaper/contact photo, and view the photo as slide show.

•Touch the video, and touch the icons below to share the video you have

taken.

9�1�1 Settings in framing mode

Before taking a photo/shooting a video, touch the icon to adjust a
number of settings in framing mode.

Back camera shooting mode

Touch the Menu key to access camera settings and below options will
display for your choice:

•Full screen Touch to turn on/off full screen preview mode.

•Shutter sound Touch to turn on/off shutter sound.

89 90

•Settings Touch to do advanced settings like GPS location

info, Face detection, Picture size, Timer, ISO and
Exposure.

•Restore defaults Touch to restore default settings.

•HDR Touch to turn on HDR (High-Dynamic Range)

function. HDR photos can better reflect
the visual effects people have in the real
environment by synthesizing images under
different exposure time. The tablet will then
automatically save the original photos and
HDR ones.

•Panorama Touch to turn on panorama function. Press the

Shutter button or the Volume key, you can
also touch and hold the viewfinder to start
taking panoramic photo and move the tablet
towards your capture direction and overlap
the two lines. Once the nine slots below the
screen are filled, the tablet will automatically
save the photo.

•Night Touch to turn on night function. In this mode,

it can better reflect the visual effects when in
the night environments.

•Sports Touch to turn on sports function. In this

mode, it can better reflect the visual effects
when in the moving environments.

•Filter Touch to choose a desired effect. The screen

displays a variety of effects for taking a picture.

•QR Scan Touch to turn on QR code scanning function.

Hold up the camera and point at the code, the
scan automatically recognizes and displays the
information the QR code contains.

Front camera shooting mode

Switch to front camera, touch the Menu key to access camera settings and
below options will display for your choice:

•Face beauty Touch to turn on/off face beauty function.

•Beauty 4 Touch to turn on Beauty 4 function. Touch the

Shutter button or Volume key to capture 4
different expressions. Once four photos taken,
the photos will be automatically synthesized
and saved in one picture.

•Filter Touch to choose a desired effect. The screen

displays a variety of effects for taking a picture.

91 92

9�2 Gallery ���������������������������������������������������������

Gallery acts as a media player for you to view photos and playback videos.
In addition, a set of further operations to pictures and videos are available
for your choice.

Touch to select

categories: Albums,

Locations, Times.

Touch to open camera.

Touch to stitch and edit
pictures.

Touch the album to
spread it apart.

Slide left or right to
view more albums.

Working with pictures

You can work with pictures by editing them, sharing them with friends,
setting them as contact photo or wallpaper, etc.

Touch Edit from full-screen picture view, more options will display for
you to choose.









To view a picture/play a video

Pictures and videos are displayed by albums in Gallery.

•Touch an album and all pictures or videos will spread the screen.

•Touch the picture/video directly to view or play it.

•Slide left/right to view previous or next pictures/videos.

93 94

 Touch to go back to picture display screen.
 Touch to undo the previous modification.
 Touch to redo the previous modification.
 Touch to save the modified picture.

Batch operation

Gallery provides a multi-select function, so that you can work with
pictures/videos in batches.

Open the main Album window, touch the Menu key and select Select
item to activate batch operation mode (you can also touch and hold one
album/picture), then touch albums/pictures you want to work on. Touch

icon to delete selected ones. Touch to share selected ones.

9�3 YouTube �������������������������������������������������������

YouTube is an online video-sharing service where the user can download,
share and view videos. It supports a streaming function that allows you to
start watching videos almost as soon as they begin downloading from the
Internet.

As an online video service, your tablet must have a network
connection to access YouTube.

All videos in YouTube are grouped into several categories, like Most
Popular, Most Discussed, Featured Videos, etc.

Touch to search for a video.

Touch to play the video and
to show more information.

By touching the Menu key from YouTube by touching Settings. screen, you
can set General settings and Search settings for YouTube.For details about

these features, please visit the YouTube website: www.YouTube.com.

9�3�1 Watch videos

Touch a video to play it. In the Playing screen, you can view information and
video comments, and also browse links to related videos.You can also rate,
share, label as favorite, create a new playlist, etc from this screen.

To exit video playing screen, touch Back key to return to the video list.

9�4 Music ������������������������������������������������������������

Using this menu, you can play music files stored on the microSD card or
the tablet storage. Music files can be downloaded from computer to tablet
using a USB cable.

You will find four categories in which all songs are classified: Artists,

Albums, Songs and Playlists. Slide left and right to view all. Touch the
Menu key and select Shuffle all to shuffle all songs; select Partly shuffle

to shuffle parts of the songs; select Sound effects to change the sound
effects.

95 96

9�4�1 Playing music

Touch a song to play it.







 Touch to play the current playlist in shuffle mode (tracks are played in

random order).

 Touch to skip to the previous track in the album, playlist, or shuffle.
 Touch to pause/resume playback.
 Touch to skip to the next track in the album, playlist, or shuffle.
 Touch to select repeat mode: Repeating all songs, Repeating current

song, or Repeat is off.

 Touch to add the song to the favourite.

While playing songs with Play Music, the operation of pause, play or
skip is still available even if the screen is locked.

Adjust sound effects

Touch the Menu key and select Sound effects from Now playing screen
to enable and adjust sound effects.







9�4�2 Working with playlists

Playlists allow you to conveniently organize all songs stored in the SD card
or tablet storage.

You can create a new playlist, add a song to the list, and delete or rename
a playlist.

To create a playlist

Touch Recently added from Playlists screen, touch the Menu key and
then select Save as playlist, enter the name and finally touch Save.

To delete a playlist

Touch and hold a playlist to show the menu, then touch Delete.

To rename a playlist

Touch and hold a playlist to show the menu, then touch Rename. When
finished, touch Save to confirm.

9�5 Video Player ������������������������������������������������

Video player is a small built-in video player that lists all your videos.

Touch an item from the list to play. While playing, use Pause, or touch a
point on the timeline to jump to and play from.

97 98

10

Google Maps ����������������

10�1 Get My Location

10�1�1 Choose a data source to decide My Location

Drag down notification panel and touch to access Settings, touch
Location.

Select the application under LOCATION SERVICES, switch the button
to turn on/off the location reporting service.

You can change the method to determine location by selecting Mode.

10�1�2 Open Maps and view My Location

Touch Maps from the main menu screen.

Touch icon on the map to view My Location.

The map will then center on a blue dot with a blue circle around. Your
actual position is within the blue circle.

To move the map, drag the map with your finger.

To zoom in and out of a map, pinch or spread your fingers, or you can also
zoom in by double-tapping a location on screen.

To clear the map history, touch and Settings, select Maps history,
then touch .

10�2 Search for a location

While viewing a map, touch the search icon to activate search function.

In the search box, enter an address, a city or a local business.

Touch the search icon to search, and in a while your search results will
appear on the map as red dots.

99 100

10�3 Star a location

Just like bookmarking a web address on the Internet, you can star any
position on the map for later use.

10�3�1 How to star (or unstar) a location

Touch a location on a map

Touch the address rectangle that opens

Touch the blue star under the address to save the location. (Or touch a
gold star to unsave that location.)

10�3�2 View a list of starred items

Touch the menu icon at the upper-left corner, and touch Your places in
the box that opens.

The list of your saved places open.

Touch a location in the list to view it.

10�4 Get driving, public transportation or walking

directions

10�4�1 Get suggested routes for your trip

•Touch enter bar to edit your start point by one of the following methods:

entering an address, using Your Location, Choose on map, selecting a
starred item, selecting an address from search history.

•Do likewise for your end point.

•To reverse directions, touch .

•A couple of suggested routes will appear in a list. Touch any routes to

view their respective detailed directions.

To get reverse directions for a route you’ve already made, simply open that
route’s directions window and touch . No need to enter your start
point and end point again.

10�4�2 Preview suggested routes and decide on a route

more preferable or feasible to you

You can preview each turn in your route in Navigation, Satellite, and other
views.

•Touch a left or right arrow to preview the next or previous leg of your

route.

•You can view turn-by-turn directions, estimated distance and possible

arrival time in the direction list below. touch Back key to return to
map view.

101 102

When selecting a more preferable or feasible route, distance and time
will be the two most important factors for your evaluation. Distance and
estimated time will be displayed at the top of the directions screen.

10�4�3 Search for locations along your route

Please refer to "10�2 Search for a location" for detailed information.

10�5 Arrangement of Layers

Layers allow you to view locations and additional information overlaid on
the map. You can add multiple layers or remove only certain layers so you
control exactly what information you want visible on the map at one time.

10�5�1 To view multiple layers

Touch icon from Maps screen. All available layers are listed (like Traffic,
Satellite, etc), select one to view.

10�5�2 To clear the map

After you get directions or search on a map, you can clear the markers/
layers that have been drawn: touch and Settings, select Maps history,
then touch .

11

Others ���������������������������������

11�1 Calculator �����������������������������������������������������

With Calculator, you can solve many mathematical problems.

To access this function, touch from Home screen and then touch .

There are two calculators available: Basic calculator and Scientific
calculator.

To switch between calculators, touch the Menu key and select the
desired calculator.

You can also rotate the screen to switch between Basic calculator and
Scientific calculator if AUTO ROTATE function is enabled.

103 104

Enter a number and the arithmetic operation to be performed, enter the
second number, then touch "=" to display the result. Touch to delete
digits one by one.

When some numbers or operations have been entered, touch and hold the
entering bar to open a menu offering these further operations:

(1)

11�3 Sound Recorder �������������������������������������������

To access this function, touch from Home screen and then touch .

Sound Recorder allows you to record voice/sound for seconds/hours.

•Cut To cut selected text

•Copy To copy selected text

•Paste To paste what you have previously copied to the

entering bar

11�2 File Manager �������������������������������������������������

To access this function, touch from Home screen and then touch .

File Manager works with both external SD card and internal storage.

File Manager displays all data stored on both microSD card and internal

storage, including applications, media files; videos, pictures or audios you
have captured; other data transferred via Bluetooth, USB cable, etc.

When you download an application from PC to microSD card, you can
locate the application on File Manager, then touch it to install it in your
tablet.

File Manager allows you to perform and be really efficient with the
following common operations: create (sub) folder, open folder/file, view,
rename, move, copy, delete, play, share, etc.

(1)

Option will not appear unless copy or cut operation has been made.

105 106

11�4 Radio ������������������������������������������������������������

Your tablet is equipped with a radio
traditional radio with saved channels or with parallel visual information
related to the radio program on the display if you turn to stations that
offer Visual Radio service.

To access this function, touch from Home screen and then touch .

To use it, you must plug in your headset, which works as an antenna
connected with your tablet.

Touch to decrease

0.1MHz Touch and

hold to search and go

to the nearest lower

frequency channel

Touch to go to previous

saved channel

Touch to search for

all available stations

automatically

Touch to play/stop

(1)

The quality of the radio depends on the coverage of the radio station in that

particular area.

(1)

. You can use the application as a

Touch to add the current
station to favourites.

Touch to increase 0.1MHz

Touch to go to next saved
channel

Touch to open and view
the saved channels list

Available options:

•Save channel Save the current tuned station to the channels

list.

•Audio mode Listen to the radio using loudspeaker or headset.

•Delete Delete the channel

•Enter frequency Enter the frequency manually.

•RDS settings Touch to select Channel information and

Alternative frequency.

•Record FM Record video voice of the current channel.

•Exit Turn off the radio.

11�5 Setup Wizard ��������������������������������������������

To access this function, touch from Home screen and then touch .

Setup Wizard helps set up your tablet in multiple ways: language, input
method, mobile data connection, account setup and synchronization, etc.
This will also be performed the first time you power on your tablet.

11�6 Alcatel Help �����������������������������������������������

To access this function, touch from Home screen and then touch .

Help Me provides help when you have questions or need assistance when
using the tablet.

11�7 Other applications

The previous applications in this section are preinstalled on your tablet.
To read a brief introduction of the preinstalled 3rd party applications,
please refer to the leaflet provided with the tablet. You can also download
thousands of 3rd party applications by going to Google Play Store on your
tablet.

(1)

Application availability depends on country and operator.

107 108

(1)

������������������������������������������

12

Drag down notification panel and touch to access Settings.

Settings �������������������������

12�1 Wireless & networks

12�1�1 Wi-Fi

Using Wi-Fi you can now surf the Internet without using your SIM card
whenever you are in range of a wireless network. The only thing you
have to do is to enter the Wi-Fi screen and configure an access point to
connect your tablet to the wireless network.

For detailed instructions on using Wi-Fi, please refer to "7�1�2 Wi-Fi".

12�1�2 Bluetooth

Bluetooth allows your tablet to exchange data (videos, images, music,
etc.) in a small range with another Bluetooth supported device (tablet,
computer, printer, headset, car kit, etc.).

For more information on Bluetooth, please refer to "7�3 Connecting to

Bluetooth devices".

12�1�3 Data usage

To enable/disable mobile data by touching the switch .

Mark the checkbox of Set mobile data limit, then you can drag the limit
line and the warning line according to your limitation. Your mobile data
connection will be disabled when the specified limit is reached. You can also
choose a data usage cycle to view the statistics and related applications of
used data by your tablet.

Touch the Menu key, and you can view more settings related to your data
usage.

Data usage is measured by your tablet, and your carrier may count
differently. Please consider using a conservative limit.

12�1�4 Airplane mode

Mark the checkbox of Airplane mode to simultaneously disable all
wireless connections including Wi-Fi, Bluetooth and more.

12�1�5 VPN

A mobile virtual private network (mobile VPN or mVPN) provides mobile
devices with access to network resources and software applications on
their home network, when they connect via other wireless or wired
networks. Mobile VPNs are used in environments where workers need to
keep application sessions open at all times, throughout the working day,
as the user connects via various wireless networks, encounters gaps in
coverage, or suspend-and-resumes their devices to preserve battery life. A
conventional VPN cannot survive such events because the network tunnel
is disrupted, causing applications to disconnect, time out, fail, or even the
computing device itself to crash.

For more information on VPN, please refer to "7�6 Connecting to
virtual private networks".

109 110

12�1�6 Tethering & portable hotspot

This function allows you to share your tablet's mobile data connection via
USB or as a portable Wi-Fi access point (Please refer to "7�5 Sharing

your tablet's mobile data connection").

12�1�7 Mobile networks

• Data connection

Touch to turn on/off data connection.

• Preferences

Touch to view/edit/delete preferences.

• Access Point Names

You can select your preferred network with this menu.

• Network operators

You can select a network operator.

12�2 Device

12�2�1 Gestures

Mark the checkbox to enable the following gestures: Turn over to mute,
Turn over to activate, Shake to switch music, etc.

12�2�2 Sound

Use the Sound settings to configure volume and ringtones for different
events and environments.

Volume

Volume settings can make user adjust the volume of ringtone, notifications,

music, video and alarms, etc., or directly set the incoming calls to vibration
or silence.

•Silent mode Mark the checkbox to silence tablet for incoming

•Ringtone Slide to change the volume of the ringtone.

•Notifications Slide to change the volume of the notifications.

•System Slide to change the volume of the system.

•Music, video,

games and other
media

•Alarms Slide to change the volume of the alarm.

Ringtone & Notifications

•Phone ringtone Touch to set your default phone ringtone.

•Crescendo

ringtone

•Notification sound Touch to set your default notification sound.

calls.

Slide to change the volume of the music, video,
games and other media.

Mark the checkbox to activate crescendo
ringtone.

111 112

System

•Dial pad touch

tones

•Audible selection Mark the checkbox to enable playing sound when

•Screen lock sound Mark the checkbox to enable sounds to play

•Power on sound Set your default power on ringtone.

•Power off sound Set your default shut down ringtone.

Mark the checkbox to enable playing tones when
using dial pad.

making screen selection.

when locking and unlocking the screen.

12�2�3 Display

•Lock screen

notifications

•Brightness Touch to adjust the brightness of the screen.

•Screen module Touch to adjust screen module.

•Wallpaper Touch to set the wallpaper.

•Automatic

brightness

•Sleep Touch to set screen timeout.

•Color

Configuration

•Screen saver Touch to set the screen saver.

•Font size Touch to set the fond size.

•TV Link Touch to switch on/off the TV link.

Mark the checkbox to show notifications on lock
screen.

Mark the checkbox to enable automatic brightness
adjustment.

Slide to adjust the temperature and saturation.

12�2�4 Storage

Use these settings to monitor the total and available space on your tablet
and on your microSD card; to manage your microSD card.

If a warning message comes up saying that device memory is
limited, you are required to free up space by deleting some
unwanted applications, downloaded files, etc.

12�2�5 Battery

In battery management screen you can view the battery usage data since
you last connected the tablet to a power source. The screen also shows
your battery status and how long it has been used since last charging. Touch
one category, then you can learn its specific power consumption.

You can adjust power use via the screen brightness or screen timeout in
Display screen.

12�2�6 Apps

You use the Applications settings to view details about the applications
installed on your tablet, to manage their data and force them to stop, and
to set whether you want to permit installation of applications that you
obtain from web sites and emails.

12�3 Personal

12�3�1 Security

Encrypt tablet

You can encrypt your accounts, settings,download apps and their data,
media and other files by touching Encrypt tablet.

113 114

Make passwords visible

Mark the checkbox to show passwords as you type.

Device administrators

Touch to view or deactivate device administrators.

Unknown sources

Mark the checkbox to permit installation of applications that you obtain
from web sites, emails, or other locations other than Google Play Store.

To protect your tablet and personal data, download applications only from
trusted sources, such as Google Play Store.

Verify apps

Mark the checkbox to disallow or warn before installing apps which may
cause harm.

Storage type

Show the storage type of the tablet (Software only).

Trusted credentials

Touch to display trusted CA certificates.

Install from Memory

Touch to install encrypted certificates from the tablet memory.

Clear credentials

Touch to remove all credentials.

12�3�2 Language & input

Use the Language & input settings to select the language for the text
on your tablet and for configuring the onscreen keyboard. You can also
configure voice input settings and the pointer speed.

Language

Touch to select the language and the region you want.

Spell checker

Mark the checkbox to enable the system to show suggested words.

User dictionary

Touch to open a list of the words you’ve added to the dictionary. Touch a
word to edit or delete it. Touch the add button (+) to add a word.

Default

Touch to select a default input method. Touch Configure input methods
to show all input methods. Touch the settings icon to configure a
certain input method.

Android Keyboard (AOSP)

The Android keyboard settings apply to the onscreen keyboard that is
included with your tablet. The correction and capitalization features affect
only the English version of the keyboard. Available options are as follows:

•Input languages

Touch to set input language.

•Auto-capitalization

Mark the checkbox to have the onscreen keyboard automatically capitalize
the first letter of the first word after a period, the first word in a text field,
and each word in name fields.

115 116

•Sound on keypress

Mark the checkbox to play a brief sound each time you touch a key on the
onscreen keyboard.

•Add-on dictionaries

Touch to view or delete the add-on dictionaries.

•Block offensive words

Mark the checkbox to block offensive words while typing.

•Auto correction

Touch to turn on/off auto correction, or you can also adjust the sensitivity
of correction.

•Show correction suggestions

Touch to show or not the correction suggestions while typing.

•Next word prediction

Mark the checkbox to popup word prediction.

•Advanced settings

Touch to view more advanced settings for android keyboard, such as

Suggest Contact names, Key long press delay, etc.

Voice search

Touch to view settings about voice search, such as Language, Speech
output, etc.

Text-to-speech output

•Preferred engine

Touch to choose a preferred text-to-speech engine, touch the settings icon

to show more choices for each engine.

•Speech rate

Touch to open a dialog where you can select how quickly you want the
synthesizer to speak.

•Listen to an example

Touch to play a brief sample of the speech synthesizer, using your current
settings.

•Default language status

It shows the default language status.

Pointer speed

Touch to open a dialog where you can change the pointer speed, touch

OK to confirm.

12�3�3 Backup and reset

Back up my data

Mark the checkbox to back up your tablet’s settings and other application
data to Google Servers, with your Google Account. If you replace your
tablet, the settings and data you’ve backed up are restored onto the new
tablet for the first time you sign in with your Google Account. If you mark
this option, a wide variety of settings and data are backed up, including your
Wi-Fi passwords, bookmarks, a list of the applications you’ve installed, the
words you’ve added to the dictionary used by the onscreen keyboard, and
most of the settings that you configure with the Settings application. If you
unmark this option, you stop backing up your settings, and any existing
backups are deleted from Google Servers.

Back up account

Touch to back up your account.

117 118

Automatic restore

Mark the checkbox to restore your backed up settings or other data when
you reinstall an application.

DRM reset

Touch to delete all DRM licenses.

Factory data reset

Reset tablet will erase all of your personal data from internal tablet storage,
including information about your Google Account, any other accounts,
your system and application settings, and any downloaded applications.
Resetting the tablet does not erase any system software updates you’ve
downloaded or any files on your microSD card, such as music or photos.
If you mark the checkbox - Reserve the content in internal storage before
touching Reset tablet, any files stored on your tablet storage will not be
erased. If you reset the tablet in this way, you’re prompted to re-enter the
same kind of information as when you first started Android.

When you are unable to power on your tablet, there is another way to
perform a factory data reset by using hardware keys. Press the Volume up
key and the power key at same time until the screen lights up.

12�4 Accounts

Use the settings to add, remove, and manage your Email and other
supported accounts. You can also use these settings to control how and
whether all applications send, receive, and synchronize data on their
own schedules, and whether all applications can synchronize user data
automatically.

12�5 System

12�5�1 Date & time

Use Date & Time settings to customize your preferences for how date and
time are displayed.

Automatic date & time

Touch to select Use network/GPS provided time or Off.

Mark the checkbox to use network provided time or use GPS provided
time.

Automatic time zone

Mark the checkbox to use network-provided time zone. Or unmark to set
all values manually.

Set date

Touch to open a dialog where you can manually set the tablet’s date.

Set time

Touch to open a dialog where you can manually set the tablet’s time.

Select time zone

Touch to open a dialog where you can set the tablet’s time zone.

Use 24-hour format

Mark the checkbox to display the time using 24-hour clock format.

Select date format

Touch to open a dialog where you can select the format for displaying
dates.

119 120

12�5�2 Scheduled power on & off

Touch to set the power on & off time for every day or specified days.

12�5�3 Accessibility

You use the Accessibility settings to configure any accessibility plug-ins you
have installed on your tablet.

TalkBack

Touch to switch on/off the function. When TalkBack is on, your device
provides spoken feedback to help blind and low-vision users.

Captions

Touch to change the caption language, text size and caption style.

Magnification gestures

Touch to turn on/off to activate/deactivate zoom in/out function by triple­tapping the screen.

Speak passwords

Mark the checkbox to speak passwords while typing.

Accessibility shortcut

Touch to turn on/off to enable/disable accessibility features.

Touch & hold delay

Touch to adjust the duration of touch and hold delay. This function enables
your tablet to differ touch and touch & hold, which may avoid incorrect
operations.

12�5�4 Developer options

To access this function, touch Settings\About device, then touch Build
number 7 times. Now Developer options is available.

The Developer options screen contains settings that are useful for developing
Android applications. For full information, including documentation of the
Android applications and development tools, see the Android developer
web site (http://developer.android.com).

Take bug report

Touch to select to collect information about your current device state and
send as an email message.

Desktop backup password

Touch to set/change/remove desktop full backup password.

Stay awake

Mark the checkbox to prevent the screen from dimming and locking when
the tablet is connected to a charger or to a USB device that provides
power. Don’t use this setting with a static image on the tablet for long
periods of time, or the screen may be marked with that image.

USB debugging

Mark the checkbox to permit debugging tools on a computer to
communicate with your tablet via a USB connection.

Power menu bug report

Mark the checkbox to select to include option in power menu for
submitting a bug report.

121 122

Allow mock locations

Mark the checkbox to permit a development tool on a computer to
control where the tablet believes it is located, rather than using the tablet’s
own internal tools for this purpose.

Select debug app

Touch to select debug app.

Verify apps over USB

Mark the checkbox to check apps over USB.

TV Link certification

Mark the checkbox to show options for TV Link certification.

Show touches

Mark the checkbox to show visual feedback for touches.

Pointer location

Mark the checkbox to show current touch data.

Show layout bounds

Mark the checkbox to show clip bounds, margins, etc.

Show GPU view updates

Mark the checkbox to show GPU view updates.

Show hardware layers updates

Mark the checkbox to show hardware layers updates.

123 124

Show GPU overdraw

Mark the checkbox to show GPU overdraw.

Window animation scale

Touch to adjust the animation scale for your window.

Transition animation scale

Touch to adjust the animation scale while performing transition.

Animator duration scale

Touch to adjust the animation duration scale.

Disable HW overlays

Mark the checkbox to select to always use GPU for screen compositing.

Force GPU rendering

Mark the checkbox to forcely use 2D hardware acceleration in applications.

Force 4x MSAA

Mark the checkbox to enable 4x MSAA.

Strict mode enabled

Mark the checkbox to enable strict mode. After enabled, the screen will
flash when applications do long operations on the main thread.

Show CPU usage

Mark the checkbox to show current CPU usage.

Profile GPU rendering

Mark the checkbox to use 2D hardware acceleration in applications.

Enable OpenGL traces

Touch to adjust OpenGL traces.

Don't keep activities

Mark the checkbox to destroy all activities as soon as you leave.

Background process limit

Touch to change the limit for background processes.

Show all ANRs

Mark the checkbox to show "Application Not Responding" dialog for
background applications.

12�5�5 About device

This contains information about things ranging from Legal information,
Model number, Firmware version, Baseband version, Kernel version, Build
number to those listed below:

System updates

Touch to check for system updates.

System udpates (storage)

Touch to check for system udpates (storage).

Status

This contains the status of the Battery status, Battery level, SIM status, IP
address, etc.

13

Making the most of your
tablet �����������������������������������

You can download software upgrade for free from the website (www.
alcatelonetouch.com).

13�1 Upgrade

You can use Mobile Upgrade tool or FOTA Upgrade tool to update your
tablet's software.

13�1�1 Mobile Upgrade

Download Mobile Upgrade from ALCATEL ONETOUCH website
(www.alcatelonetouch.com) and install it on your computer. Launch the
tool and update your tablet by following the step by step instructions (refer
to the User Guide provided together with the tool).

Your tablet’s software will now have the latest software.

All personal information will be permanently lost following the
update process. We recommend you backup your personal data
using ONETOUCH Center before upgrading.

Legal information

Touch to view legal information.

125 126

13�1�2 FOTA Upgrade

Using FOTA Upgrade tool you can update your tablet's software.

To access System Updates, please open Settings\About device\
System updates. Touch Check for updates, and the tablet will search
for the latest software. If you want to update the system, please touch the
button Download, after it done please touch Install to complete the
upgrade. Now your tablet's software will have the latest version.

You should turn on data connection before searching for updates. Settings
for auto-check intervals and reminders about upgrades are also available
once you restart the tablet.

If you have chosen auto-check, when the system discovers the new version,
the icon will appear in the status bar. Touch the notification to access
the System Updates directly.

During FOTA downloading or updating, to avoid errors in locating
the correct update packages, do not change your default storage
location.

127 128

14

Your tablet is warranted against any defect or malfunctioning which may
occur in conditions of normal use during the warranty period of twelve
(12) months

Batteries
against any defect which may occur during the first six (6) months
the date of purchase as shown on your original invoice.

In case of any defect of your tablet which prevents you from normal use
thereof, you must immediately inform your vendor and present your tablet
with your proof of purchase.

If the defect is confirmed, your tablet or part thereof will be either
replaced or repaired, as appropriate. Repaired tablet and accessories
are entitled to a one (1) month warranty for the same defect. Repair or
replacement may be carried out using reconditioned components offering
equivalent functionality.

This warranty covers the cost of parts and labor but excludes any other
costs.

(1)

The warranty period may vary depending on your country.

(2)

The life of a rechargeable tablet battery in terms of conversation time standby

Tablet warranty �����������������

(1)

from the date of purchase as shown on your original invoice.

(2)

and accessories sold with your tablet are also warranted

time, and total service life, will depend on the conditions of use and network
configuration. Batteries being considered expendable supplies, the specifications
state that you should obtain optimal performance for your tablet during the
first six months after purchase and for approximately 200 more recharges.

(1)

from

This warranty shall not apply to defects to your tablet and/or accessory
due to (without any limitation):

1) Non-compliance with the instructions for use or installation, or with
technical and safety standards applicable in the geographical area where
your tablet is used,

2) Connection to any equipment not supplied or not recommended by
TCT Mobile Limited,

3) Modification or repair performed by individuals not authorised by TCT
Mobile Limited or its affiliates or your vendor,

4) Modification, adjustment or alteration of software or hardware
performed by individuals not authorized by TCT Mobile Limited,

5) Inclement weather, lightning, fire, humidity, infiltration of liquids or foods,
chemical products, download of files, crash, high voltage, corrosion,
oxidation…

Your tablet will not be repaired in cases where labels or serial numbers
(IMEI) have been removed or altered.

There are no express warranties, whether written, oral or implied, other
than this printed limited warranty or the mandatory warranty provided by
your country or jurisdiction.

In no event shall TCT Mobile Limited or any of its affiliates be liable for
indirect, incidental or consequential damages of any nature whatsoever,
including but not limited commercial or financial loss or damage, loss of
data or loss of image to the full extent those damages can be disclaimed
by law.

Some countries/states do not allow the exclusion or limitation of indirect,
incidental or consequential damages, or limitation of the duration of
implied warranties, so the preceding limitations or exclusions may not
apply to you.

15

The latest generation of ALCATEL ONETOUCH tablets offers a built-in
handsfree feature that allows you to use the tablet from a distance, placed
on a table for example. For those who prefer to keep their conversations
confidential, an earpiece is also available known as the headset.

1. Charger

2. USB cable

3. Stereo headset

Accessories ������������������������

Only use your tablet with the ALCATEL ONETOUCH, chargers
and accessories in your box.

129 130

16

Before contacting the service centre, you are advised to follow the
instructions below:

•You are advised to fully charge ( ) the battery for optimal operation.

•Avoid storing large amounts of data in your tablet as this may affect its

performance.

•Use Factory date reset and the upgrade tool to perform tablet

formatting or software upgrading (to reset factory data, hold down the
Power key and the Volume up key at the same time). ALL User tablet
data: contacts, photos, messages and files, downloaded applications will
be lost permanently. It is strongly advised to fully backup the tablet data
and profile via Android Manager before doing formatting and upgrading.

and carry out the following checks:

My tablet cannot be switched on or is frozen

•When the tablet cannot be switched on, charge for at least 20 minutes to

ensure the minimum battery power needed, then try to switch on again.

•When the tablet falls into a loop during power on-off animation and the

user interface cannot be accessed, press and hold the Volume down
key to enter Safe Mode. This eliminates any abnormal OS booting issues
caused by 3rd party APKs.

•If neither method is effective, please reset the tablet using the Power key

and the Volume up key (holding both together).

My tablet has not responded for several minutes

•Restart your tablet by pressing and holding the Powe r k ey.

Troubleshooting �����������������

My tablet turns off by itself

•Check that your screen is locked when you are not using your tablet, and

make sure the Powe r key is not mis-contacted due to unlocked screen.

•Check the battery charge level.

My tablet cannot charge properly

•Make sure that your battery is not completely discharged; if the battery

power is empty for a long time, it may take around 20 minutes to display
the battery charger indicator on the screen.

•Make sure charging is carried out under normal conditions (0°C to

+40°C).

•When abroad, check that the voltage input is compatible.

My tablet cannot connect to a network or "No service" is
displayed

•Try connecting in another location.

•Verify the network coverage with your operator.

•Check with your operator that your SIM card is valid.

•Try selecting the available network(s) manually (see "12�1�7 Mobile

networks")

•Try connecting at a later time if the network is overloaded.

My tablet cannot connect to the Internet

•Check that the IMEI number (press *#06#) is the same as the one

printed on your warranty card or box.

•Make sure that the internet access service of your SIM card is available.

•Check your tablet's Internet connecting settings.

•Make sure you are in a place with network coverage.

•Try connecting at a later time or another location.

Invalid SIM card

•Make sure the SIM card has been correctly inserted (see "Inserting or

removing the SIM card").

•Make sure the chip on your SIM card is not damaged or scratched.

•Make sure the service of your SIM card is available.

131 132

Unable to make outgoing calls

•Make sure you have dialed a valid number and have touched Call.

•For international calls, check the country and area codes.

•Make sure your tablet is connected to a network, and the network is not

overloaded or unavailable.

•Check your subscription status with your operator (credit, SIM card

valid, etc.).

•Make sure you have not barred outgoing calls.

•Make sure that your tablet is not in airplane mode.

Unable to receive incoming calls

•Make sure your tablet is switched on and connected to a network (check

for overloaded or unavailable network).

•Check your subscription status with your operator (credit, SIM card

valid, etc.).

•Make sure you have not forwarded incoming calls.

•Make sure that you have not barred certain calls.

•Make sure that your tablet is not in airplane mode.

The caller’s name/number does not appear when a call is received

•Check that you have subscribed to this service with your operator.

•Your caller has concealed his/her name or number.

I cannot find my contacts

•Make sure your SIM card is not broken.

•Make sure your SIM card is inserted properly.

•Import all contacts stored in SIM card to tablet.

The sound quality of the calls is poor

•You can adjust the volume during a call by pressing the Volume Up/

Down key.

•Check the network strength .

•Make sure that the receiver, connector or speaker on your tablet is clean.

I am unable to use the features described in the manual

•Check with your operator to make sure that your subscription includes

this service.

•Make sure this feature does not require an ALCATEL ONETOUCH

accessory.

When I select a number from my contacts, the number cannot
be dialed

• Make sure that you have correctly recorded the number in your file.

• Make sure that you have selected the country prefix when calling a foreign

country.

I am unable to add a contact in my contacts

•Make sure that your SIM card contacts are not full; delete some files or

save the files in the phone contacts (i.e. your professional or personal
directories).

My callers are unable to leave messages on my voicemail

•Contact your network operator to check service availability.

I cannot access my voicemail

•Make sure your operator’s voicemail number is correctly entered in

"Voicemail number".

•Try later if the network is busy.

I am unable to send and receive MMS

•Check your tablet memory availability as it might be full.

•Contact your network operator to check service availability and check

MMS parameters (see "5�1�3 Adjust message settings").

•Verify the server centre number or your MMS profile with your operator.

•The server centre may be swamped, try again later.

SIM card PIN locked

•Contact your network operator to obtain the PUK code (Personal

Unblocking Key).

I am unable to connect my tablet to my computer

•Install ALCATEL ONETOUCH Center.

•Check that your USB driver is installed properly.

133 134

•Open the Notification panel to check if the Android Manager Agent has

been activated.

•Check that you have marked the checkbox of USB debugging.

To access this function, touch Settings\About device, then touch Build
number for 7 times. Now you may touch Settings\USB debugging\
USB debugging.

•Check that your computer meets the requirements for ALCATEL

ONETOUCH Center Installation.

•Make sure that you’re using the right cable from the box.

I am unable to download new files

•Make sure there is sufficient tablet memory for your download.

•Check your subscription status with your operator.

The tablet cannot be detected by others via Bluetooth

•Make sure that Bluetooth is turned on and your tablet is visible to other

users (see "7�3 Connecting to Bluetooth devices").

•Make sure that the two devices are within Bluetooth’s detection range.

How to make your battery last longer

•Make sure you follow the complete charge time (minimum 2.5 hours).

•After a partial charge, the battery level indicator may not be exact. Wait

for at least 20 minutes after removing the charger to obtain an exact
indication.

•Adjust the brightness of screen as appropriate

•Extend the email auto-check interval for as long as possible.

•Update news and weather information on manual demand, or increase

their auto-check interval.

•Exit background-running applications if they are not being used for a

long time.

•Deactivate Bluetooth, Wi-Fi, or GPS when not in use.

The tablet will become warm following prolonged calls, game
playing, internet surfing or running other complex applications�

•This heating is a normal consequence of the CPU handling excessive

data. Ending above actions will make your tablet return to normal
temperatures.

17

Processor MTK MT8392+MTK MT6290

Platform Android™ 4.4

Memory 2G RAM + 16G ROM

Dimensions
(LxWxT)

Weight 330 grams with battery

Display 8-inch IPS touchscreen with 1920 x 1200

Network GSM:

GPS Assisted GPS/Internal GPS antenna

Connectivity •Bluetooth V4.0

Camera •5 MPxl back camera

Specifications ���������������������

209 x 122 x 7.55mm

Quad-band 850/900/1800/1900 MHz

UMTS:

Quad-band 850/900/1900/2100 MHz

LTE:

CSFB B1/B3/B7/B8/B20

(Band frequency and data speed are operator
dependent.)

•Wi-Fi IEEE 802.11 a/b/g/n

•3.5 mm audio jack

•micro-USB

•2 Mpxl front camera

135 136

Audio supported
formats

Video supported
formats

(1)

Battery

MP3, MP2, AMR, MIDI, Vorbis, APE, AAC, AAC+,
FLAC

H.265, H.264, H.263, MPEG-4, XVID, VP8, VC-1,
MKV, MOV, MEPG, AVI

•Rechargeable Lithium-ion battery

•Capacity: 4060mAh

Expansion Slot microSD™ memory card

(Availability of microSD card depends on
market)

Special Features • G-sensor

•Light Sensor

•E-compass

•IrDA

Note: Specifications are subject to change without prior notice.

ALCATEL is a trademark of Alcatel-Lucent

and is used under license by

TCT Mobile Limited.

© Copyright 2014 TCT Mobile Limited

All rights reserved

TCT Mobile Limited reserves

the right to alter material

or technical specification

without prior notice.

(1) (2)

All "Signature" ringtones embedded in this tablet have been composed,
arranged and mixed by NU TROPIC (Amar Kabouche).

(1)

The original battery has undergone rigorous safety inspections to meet

qualification standards, the use of non-original batteries may be dangerous.

137 138

English - CJA33W0ALAAA
