DISCREET ACOUSTICS MODULAR SERIES PLUS
PHANTOM POWER ADAPTER
PAESP M
Pos. LED Basscut Switch
0 off off on/off
1 off off ptt
2 off off ptm
3 off off –
4 off on on/off
5 off on ptt
6 off on ptm
7 off on –
8 on off on/off
9 on off ptt
A on off ptm
B on off –
C on on on/off
D on on ptt
E on on ptm
F on on –
Disconnect XL R-plug before c hanging setti ngs!
PAE M / PAE5 M
LED sw it ch n ot i n function wi th PA E5 M .
on/off toggle
ptt push to talk
ptm push to mute
– without a ny function
OF F
ON
BasscutLED
MF M
ø 50m m / 2in ch
PAE M / PAE5 M
DISCREET ACOUSTICS MODULAR SERIES PLUS
SYSTEM OVERVIEW
MK150 ML
PAE M
3pin XLR
GN15 M
GN30 M
MK150 M
PAE5 M 5pin XLR
PAESP M
GN50 M
HM1000 M
MF M
CS5 Adapter M
GN155 M
UWA9 M
