SERVICE MANUAL

STEREO RADIO

CASSETTE PLAYER

• This Correction Service Manual is issued because of some errors in Service

Manual of MODEL NAME HS-RX308 (YZ) / HS-RX408 (YU,YL,YZ,YH,YJ), (S/M Code No. 09-002-425-5R1).

BASIC TAPE MECHANISM : CL-850-5 SIL

S/M Code No. 09-003-425-5C1

CORRECTION

DATA

TAPE MECHANISM EXPLODED VIEW 1 / 1

-2-

TAPE MECHANISM PARTS LIST 1 / 1

PART NO.

NO.

1 8A-HR8-003-010 FRAME CENTER 2 S8-505-240-000 GEAR SHAFT 3 S8-505-070-000 REEL GEAR T 4 S8-505-080-000 CLUTCH GEAR 5 S8-505-300-000 FELT

6 S8-505-200-000 CLUTCH SP 7 S8-505-120-000 REEL GEAR BUSH 8 S8-505-290-000 REFLECTING PLATE 9 S8-505-210-000 BRACK TENSHION SP 10 S8-000-100-000 REEL CAP

11 S8-505-090-000 FWD GEAR PLATE 12 S8-505-060-000 FWD GEAR 13 S8-505-250-000 GEAR PLATE PIN 14 S8-505-220-000 FWD GEAR SP 15 S8-505-050-000 CENTER GEAR

16 S1-2X2-5X0-25L L CUT W 17 S8-505-320-000 FF GEAR HOLDER 18 S8-505-330-000 FF GEAR 19 S8-505-310-000 GEAR HOLDER SP 20 S8-550-3K0-000 FLYWHEEL R ASSY

21 87-A91-563-010 MOTOR(IBIGB02) 22 S1-2X2-5X0-1LC L CUT W 23 SV-500-000-000 SUB BELT 24 SV-190-000-000 MAIN BELT 25 S8-505-100-000 FWD ARM

DESCRIPTIONREF. NO. KANRI

PART NO.

NO.

26 S8-505-110-000 REV ARM 27 S8-505-260-000 SUB CHASSIS 28 S8-505-160-000 REV SELECT 29 S8-505-190-000 SELECT SP 30 S8-505-020-000 HEAD BASE

31 S7-000-080-000 PINCH ROLLER 32 87-A91-019-010 HEAD ASSY(PH8ZM-3) 33 S8-550-4K0-000 FLYWHEEL L ASSY 34 S8-300-160-000 HEAD BASE SP 35 S8-300-170-000 PINCH SP FWD

36 S8-500-090-000 PINCH SP REV 37 8A-HR8-214-010 SPR-P CASS 38 S8-505-130-000 COVER A S1-PB1-7X5-500 SCREW 1.7-5.5 B S3-PY1-7X2-500 SCREW 1.7-2.5

C S3-PB1-7X3-000 SCREW

DESCRIPTIONREF. NO. KANRI

-3-

2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111

Printed in Singapore9630469 0251431

HS-RX308

HS-RX408

YU,YL,YZ,YH,YJ

SERVICE MANUAL

STEREO RADIO

CASSETTE PLAYER

• This Service Manual is the "Revision Publishing" and replaces "Simple Manual" (S/M Code No. 09-99C-425-5T1).

BASIC TAPE MECHANISM : CL-850-5 SIL

S/M Code No. 09-002-425-5R1

REVISION

DATA

SPECIFICATIONS

Frequency range: Reception area USA AM 530 – 1,710 kHz (10 kHz step)

Reception area EU AM 531 – 1,602 kHz (9 kHz step)

Reception area JP AM 531 – 1,629 kHz (9 kHz step) <EXCEPT YZ> FM1, FM2 76 – 108 MHz

Maximum output: 4 mW + 4 mW (EIAJ 16 ohms)<YZ>

Power sources: DC 3 V using two R6 (size AA) dry cell batteries

Maximum dimensions: 112.9 (W) x 84 (H) x 29.3 (D) mm (excluding

Weight: Approx.136 g (4.8 oz.) excluding batteries

• Design and specifications are subject to change without notice.

FM1, FM2 87.5 – 108.1 MHz (200 kHz step)

FM1, FM2 87.5 – 108 MHz (50 kHz step)

(100 kHz step in 76 – 90 MHz, 50 kHz step in 90 – 108 MHz)

5 mW + 5 mW (EIAJ 32 ohms)<YU,YL,YH,YJ>

AC house current using the optional AC adaptor Aiwa AC-D302

projecting parts and controls)

/2 x 33/8 x 13/

in.)

ELECTRICAL MAIN PARTS LIST

PART NO. KANRI

NO.

87-002-677-080 IC,TA2002F 87-A21-407-040 C-IC,TA2104BFN 87-A20-904-080 C-IC,TK11823MTL 87-A20-532-140 C-IC,LB1977M-TLM 87-A21-564-010 C-IC,TC9318FA-058

87-A21-566-040 C-IC,S-80820ANNP

TRANSISTOR

87-026-262-080 C-TR,RN1407 89-342-153-080 TR,2SC4215 87-026-414-080 C-TR,RN1307 89-508-804-080 C-FET,2SK880 89-341-165-080 C-TR,2SC4116

89-113-625-080 C-TR,2SA1362

DIODE

87-A40-822-040 C-DIODE,CRS01 87-A40-360-080 C-DIODE,MA786 87-001-166-080 DIODE,1SS301 87-017-779-080 C-DIODE,1SS355

MAIN C.B

BPF201 87-A90-601-010 FLTR,BPF GFWB7 C101 87-012-275-080 C-CAP,U 1200P-50 K B C102 87-012-275-080 C-CAP,U 1200P-50 K B C103 87-012-275-080 C-CAP,U 1200P-50 K B C104 87-012-275-080 C-CAP,U 1200P-50 K B

C105 87-A10-952-080 C-CAP,TN 22-4 M A MCM C106 87-A10-952-080 C-CAP,TN 22-4 M A MCM C107 87-012-276-080 CAP, CHIP SS 1500 PBK C108 87-012-276-080 CAP, CHIP SS 1500 PBK C109 87-010-757-080 C.CAP,U 0.047-25F

C110 87-010-757-080 C.CAP,U 0.047-25F C111 87-A10-262-080 C-CAP,U 1-10 ZF C112 87-A10-262-080 C-CAP,U 1-10 ZF C113 87-012-274-080 CHIP CAP,U 1000P-50B C114 87-012-274-080 CHIP CAP,U 1000P-50B

C115 87-A10-263-080 C-CAP,U 0.1-16ZF C116 87-A10-263-080 C-CAP,U 0.1-16ZF C117 87-010-852-080 C-CAP,E 100-4<EXCEPT 308YZ> C118 87-010-852-080 C-CAP,E 100-4<EXCEPT 308YZ> C119 87-A10-263-080 C-CAP,U 0.1-16ZF

C120 87-A10-952-080 C-CAP,TN 22-4 M A MCM C121 87-016-563-080 C-CAP,TN 10-10 SV A C122 87-A10-952-080 C-CAP,TN 22-4 M A MCM C123 87-A10-263-080 C-CAP,U 0.1-16ZF C124 87-A10-262-080 C-CAP,U 1-10 ZF

C125 87-A10-262-080 C-CAP,U 1-10 ZF C126 87-010-503-010 CAP,E 220-4 GAS C130 87-A10-262-080 C-CAP,U 1-10 ZF C135 87-010-503-010 CAP,E 220-4 GAS C151 87-A10-263-080 C-CAP,U 0.1-16ZF

C152 87-A10-263-080 C-CAP,U 0.1-16ZF C201 87-012-156-080 C-CAP,S 220P-50 CH C202 87-012-274-080 C-CAP,U 1000P-50 KB C203 87-012-274-080 C-CAP,U 1000P-50 KB C204 87-012-286-080 CAP, U 0.01-25

C205 87-012-286-080 CAP, U 0.01-25 C206 87-012-158-080 C-CAP,S 390P-50 CH C210 87-010-321-080 CHIP CAPACITOR,82P(J) C212 87-012-286-080 CAP, U 0.01-25 C213 87-012-160-080 C-CAP,U 50P-50 CK

C215 87-010-787-080 CAP, U 0.022-25 C216 87-A10-263-080 C-CAP,U 0.1-16ZF C217 87-010-574-080 C-CAP,S 470P-50 J UJ

DESCRIPTIONREF. NO. KANRI

REF. NO. DESCRIPTIONPART NO.

NO.

C218 87-012-191-080 CHIP CAP 68 PF C219 87-012-247-080 C-CAP,U 18P-50JUJ C220 87-012-172-080 CAPACITOR CHIP U 10P CH C221 87-012-286-080 CAP, U 0.01-25 C222 87-012-195-080 C-CAP,U 100P-50CH

C223 87-012-199-080 C-CAP,U 220P-50CH C224 87-012-274-080 CHIP CAP,U 1000P-50B C225 87-A10-262-080 C-CAP,U 1-10 ZF C226 87-A10-263-080 C-CAP,U 0.1-16ZF C227 87-A10-262-080 C-CAP,U 1-10 ZF

C228 87-A10-263-080 C-CAP,U 0.1-16ZF C229 87-012-286-080 CAP, U 0.01-25 C230 87-A10-707-080 C-CAP,U 0.47U-16 F Z C231 87-A10-262-080 C-CAP,U 1-10 Z F C232 87-016-562-080 C-CAP,TN 4.7-10 SV A

C233 87-010-785-080 C-CAP,U0.015-25BK C234 87-010-785-080 C-CAP,U0.015-25BK C235 87-010-502-010 CAP GAS 100-4 C236 87-012-273-080 C-CAP,U 820P-50 B C237 87-010-959-080 CHIP CAP,U 0.056-16F

C238 87-010-959-080 CHIP CAP,U 0.056-16F C239 87-012-286-080 CAP, U 0.01-25 C301 87-012-286-080 CAP, U 0.01-25 C302 87-012-286-080 CAP, U 0.01-25 C303 87-010-787-080 CAP, U 0.022-25

C304 87-A11-282-080 C-CAP,S 1-16 K B C305 87-012-167-080 C-CAP,U 5P-50 CH C306 87-012-170-080 C-CAP,U 8P-50 CH C307 87-012-191-080 CHIP CAP 68 PF C308 87-010-501-010 CAP,E 47-4 M KS

C309 87-A10-263-080 C-CAP,U 0.1-16ZF C310 87-A10-263-080 C-CAP,U 0.1-16ZF C311 87-A10-263-080 C-CAP,U 0.1-16ZF C351 87-A10-263-080 C-CAP,U 0.1-16ZF C353 87-A10-263-080 C-CAP,U 0.1-16ZF

C355 87-010-196-080 CHIP CAPACITOR,0.1-25 C401 87-A10-828-080 C-CAP,U 0.33-6.3 K B C402 87-016-462-080 C-CAP,U 1-16 Z F C403 87-A10-827-080 C-CAP,U 0.47-6.3 K B C404 87-A10-504-080 C-CAP,U 0.047-16 K B

C405 87-A10-504-080 C-CAP,U 0.047-16 K B C406 87-A10-504-080 C-CAP,U 0.047-16 K B C407 87-A10-504-080 C-CAP,U 0.047-16 K B C408 87-A10-263-080 C-CAP,U 0.1-16ZF C409 87-A10-263-080 C-CAP,U 0.1-16ZF

C410 87-A11-797-080 C-CAP,S 2.2-16 Z F C501 87-A10-263-080 C-CAP,U 0.1-16ZF C502 87-A10-262-080 C-CAP,U 1-10 ZF C503 87-A10-262-080 C-CAP,U 1-10 ZF C504 87-A10-262-080 C-CAP,U 1-10 ZF

C505 87-012-180-080 C-CAP,U 22P-50 J CH C506 87-012-180-080 C-CAP,U 22P-50 J CH C507 87-A10-706-080 C-CAP,U 0.33U-16 F Z C508 87-A10-263-080 C-CAP,U 0.1-16ZF C509 87-A10-263-080 C-CAP,U 0.1-16ZF

C510 87-A10-263-080 C-CAP,U 0.1-16ZF C513 87-A10-263-080 C-CAP,U 0.1-16ZF C514 87-012-274-080 CHIP CAP,U 1000P-50B C551 87-A10-263-080 C-CAP,U 0.1-16ZF CF201 87-A91-162-010 FLTR,PFS450A7

CF202 87-A90-991-010 FLTR,SFE10.7 MS239-A

CF203 87-A91-094-010 FLTR,CDA10.7 MG80A D201 87-A40-655-080 C-VARI-CAP,HVU200A D203 87-A40-799-040 C-VARI-CAP,KV1610S

J101 87-A60-438-010 JACK,3.5 BLK ST <308YZ>

J101 87-A60-437-010 JACK,3.5BLKST4p<EXCEPT 308YZ>

J351 87-A61-124-010 JACK,DC DIA2.75 BLK TC

L101 87-A50-581-080 C-COIL,S FCM2012H 252705

L102 87-A50-581-080 C-COIL,S FCM2012H 252705

L103 87-A50-581-080 C-COIL,S FCM2012H 252705

PART NO. KANRI

NO.

L104 87-A50-582-080 C-COIL,S 0.22UH K FCI2012C L105 87-A50-581-080 C-COIL,SFCM2012H<EXCEPT 308YZ> L201 8A-HR8-604-010 COIL,FM RF L202 87-A50-512-080 C-COIL,100NH G LQN21A L203 87-HRA-603-010 BAR-ANT,MW

L204 87-003-226-010 COIL, 100UH L205 87-005-788-080 C-IFT,AM (450K) L206 87-A50-597-080 C-COIL,S 10UH LQG21F100N L301 87-A50-597-080 C-COIL,S 10UH LQG21F100N L302 87-A50-037-080 C-COIL,D-D 5CDLU

L351 87-A50-597-080 C-COIL,S 10UH LQG21F100N LCD501 8A-HR8-605-010 LCD,AHR-8 LED181 87-A91-355-040 C-LED,SML-210VT RED PS551 87-A90-440-010 SNSR,PHOTO GP2S24N2R506 87-022-245-080 C-RES U 18K-1/16WF

R508 87-022-245-080 C-RES U 18K-1/16WF S101 87-A90-050-010 SW, SL 2-2-2 NS (BLK) S151 87-A90-050-010 SW, SL 2-2-2 NS (BLK) S501 87-036-379-180 C-SW,SL1-1-2 SS350 S502 87-A91-365-080 C-SW,PUSH 1-1-1 SPVG21

CHIP RESISTOR PART CODE

DESCRIPTIONREF. NO. KANRI

REF. NO. DESCRIPTIONPART NO.

S503 87-A91-737-280 C-SW,TACT B3B-2002

S504 87-A90-665-280 C-SW,TACT LS7A2M

S505 87-A90-665-280 C-SW,TACT LS7A2M

S506 87-A90-665-280 C-SW,TACT LS7A2M

S507 87-A90-665-280 C-SW,TACT LS7A2M

S508 87-A90-665-280 C-SW,TACT LS7A2M

S509 87-A90-665-280 C-SW,TACT LS7A2M

S510 87-A90-665-280 C-SW,TACT LS7A2M

S511 87-A90-665-280 C-SW,TACT LS7A2M

SFR401 87-A91-653-040 C-SFR,K 33K H RH03AEC

TC201 87-A91-183-080 C-TRIMMER,CER 10P TZC03

TH401 87-A91-675-080 C-THMS,NTH5G16P39B472K 07TH

VR101 87-A91-650-010 VR,RTRY 50KCX2 H XV0102G

X501 87-A70-082-010 VIB,XTAL 75KHZ CFV206

HEAD ASSY C.B

PH1 87-A91-019-010 HEAD ASSY,PH 8ZM-3

Chip Resistor Part Coding

NO.

Resistor Code

Chip resistor

Wattage Type Tolerance

1/16W 1005 5% CJ

1/16W

1/10W

1/8W

1608

2125

3216

TRANSISTOR ILLUSTRATION

RN1307 RN1407 2SC4215 2SA1362 2SC4116

2SK880

Symbol

Figure

Value of resistor

Form

Dimensions (mm)

0.55

Resistor Code

108

118

128

LW t

1.0 0.5 0.35 104

1.6 0.8 0.45

2 1.25 0.45

3.2

1.6

: A : A

LCD, AHR-8

GRID ASSIGNMENT

ANODE CONNECTION

IC BLOCK DIAGRAMLCD DISPLAY

IC,S-80820ANNP

IC,TA2002F

IC,TA2104BFN

IC,LB1977M-TLM

WIRING

14 13 12 11 10 9 8 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14

SCHEMATIC DIAGRAM

109

IC DESCRIPTION

MAIN C.B

PHONES

J101

VR101

VOLUME

SFR 401

L203

(BAR-ANT)

L205

GND

L201

TC201

TP1 (VT)

IC101

TP2 (DET)

IC501

Note : * : On the other soldering pattern side.

IC, TC9318FA-058

Pin No. Pin Name I/O Description

1 ~ 3 COM1 ~ COM3 O LCD driver common output.

4 ~ 18 SEG1 ~ SEG15 O LCD driver output.

ADJUSTMENT

19 SEG16 / KR7 O

LCD driver / Key matrix timing output.

20 SEG17 / KR6 O

SEG18 / KR5 ~

21 ~ 26

– Not used.

SEG23 / KR0

27 ~ 30 K0 ~ K3 I Key matrix input.

31 MOT ON O Motor control terminal. H : ON, L : OFF.

32 MOT HI O Motor speed control terminal. H : HI, L : LO.

33 MOT DIR O Motor rotation control terminal. H : CCW, L : CW.

34 BRAKE O Motor brake control terminaal. H : ON, L : OFF.

35 LOAD CTL O Output battery level checking singal. H : ON.

36 AM OUT O FM / AM control signal. H : AM, L : FM.

37 F / R CTL O FWD / REV control terminal. H : FWD, L : REV.

38 MOT CH I Motor rotate detection terminal.

39 L. V. STOP I Input low voltage detectin signal. L : Low voltage.

40 P–SNSR I Input photo sensor signal.

41 C–SW I Input cassette detectoion switch. L : Exist cassette.

42 MAIN I Input terminal from main unit key.

43 REMOTE I Input terminal from remote controller key.

44 EJECT SW I Input cassette eject switch. L : Eject.

45 HOLD I Input hold switch from main unit key. H : ON.

46 BUZR O Output buzzer.

47 POWER MUTE O Output mute signal. H : ON, L : OFF.

48 TEST I Input test mode control. (Connected to ground).

49 WAKE I Input backup detection signal.

50 IF IN I Input IF counter.

51 TU OUT O Tuner operation control terminal. H : TU OFF, L : TU ON.

52 PLL OUT O Phase comparator output.

53 GND – Connected to ground.

54 FM IN I Input FM programmable counter.

55 AM IN I Input AM programmable counter.

56 VDD – Power supply.

57 RESET – Input system reset signal.

58 X OUT

59 X IN

60 VXT – Power supply for crystal oscillation.

61 VLCD – Reference voltage for LCD drive.

62 C1

– Connected to crystal oscillator.

– Double voltage booster for LCD drive.

63 C2

1. AM IF Adjustment

L205 ...................................................................... 450 kHz

6. Tape Speed Adjustment Settings : • Test tape : TTA–100

• Test point : Phones Jack (J101)

2. AM VT Check Settings : • Test point : TP1 (VT) Method : Set to AM 530 kHz and check that the test point

is 1.2 V ± 0.3 V. Then set to AM 1710 kHz and check that the test point is less than 10 V.

Method : Play back the test tape and adjust SFR401 for

• Adjustment location : SFR401

• Volume : MAX

• S-Bass : OFF

• Tape selector : Normal

3015 Hz ± 10 Hz (FWD) and 3015 Hz ± 45 Hz

3. FM VT Adjustment

(REV). Then confirm WOW is less than 0.52%. Settings : • Test point : TP1 (VT) Method : Set to 76 MHz <YU,YL>, FM 87.5 MHz

<YZ,YH,YJ>. and check that the test point is

1.2 V ± 0.3 V <YU,YL>, 2.7 V ± 0.5 V <YZ,YH,YJ>. Then set to FM 108.0 MHz <YU,YL>, FM 108.1 MHz <YZ,YH,YJ> and check that the test point is less than 11V.

4. AM Tracking Adjustment

L203 ...................................................................... 630 kHz

TC201 .................................................................. 1440 kHz

5. FM Tracking Adjustment

L201 ....................................................................87.5 MHz

64 VEE – 1.5V voltage supply for LCD drive.

11 12

MECHANICAL EXPLODED VIEW 1 / 1 MECHANICAL PARTS LIST 1 / 1

PART NO. KANRI

NO.

PRATE, HEAD SIL

DESCRIPTIONREF. NO. KANRI

REF. NO. DESCRIPTIONPART NO. DESCRIPTIONREF. NO. KANRI

NO.

LBL,SPEC

FRAME,CENTER

PART NO. KANRI

NO.

1 8A-HR8-001-010 LID,CASS R8 SIL<[S]YU,[S]YLB,[S]YH,308[S]YZ> 1 8A-HR8-023-010 LID,CASS R8 SIL EG<308[S]YZ1B,408[S]YZ1B,[S]YJ , [S]YL > 2 8A-HR8-002-010 WINDOW,CASS 3 8A-HR8-213-010 SPR-T,CASS 4 8A-HR8-015-010 CABI,REAR 408 SIL EG<408[S]YZ1B,[S]Y J>

4 8A-HR8-013-010 CABI,REAR 308 SIL EG<308[S]YZ1B,[S]Y L> 4 8A-HR8-014-010 CABI,REAR 408 SIL<[S]YU,[S]YLB,[S]YH,308[S]YZ1> 5 8A-HR8-603-010 RBN-CORD,4P MOTOR 6 8A-HR8-216-010 HLDR,DC 7 8A-HR8-210-010 SPR-T,LOCK

8 8A-HR8-208-010 PLATE,LOCK

9 8A-HR8-201-010 LEVER,ASSY REV 10 8A-HR8-211-010 SPR-T,RTRY 11 8A-HR8-005-010 KNOB,SL OPEN 12 8A-HR8-212-010 SPR-E,EJECT

13 8A-HR8-215-010 HLDR,HP 14 8A-HR8-218-010 BAT-CONTACT,M 15 8A-HR8-217-010 BAT-CONTACT,P 16 8A-HR8-008-010 LID,BAT SIL 17 8A-HR8-010-010 KEY,PRESET RV

18 8A-HR8-009-010 KEY,CONT 19 8A-HR8-012-010 LENS,LED R 20 8A-HR8-011-010 KNOB,SL 21 8A-HR8-007-010 WINDOW,LCD

A 87-067-535-010 SCREW VT+1.4-3.5

B 87-067-388-010 SCREW

REF. NO. DESCRIPTIONPART NO.

NO.

BAR ANT

COLOR NAME TABLE

P.C.B

LCD

Basic color Color Basic color Color Basic color Color

symbol symbol symbol

B Black C Cream D Orange G Green H Gray L Blue

LT Transparent Blue N Gold P Pink

R Red S Silver ST Titan Silver T Brown V Violet W White

WT Transparent White Y Yellow YT Transparent Yellow LM Metallic Blue LL Light Blue GT Transparent Green

LD Dark Blue DT Transparent Orange GM Metallic Green

YM Metallic Yellow

HS-RX308 YZISF (FileName:EXP.EPS) 1999/12/24 AHR-8

13 14

TAPE MECHANISM EXPLODED VIEW 1 / 1 TAPE MECHANISM PARTS LIST 1 / 1

PART NO. KANRI

NO.

FLY WHEEL R

FW PLATE

DESCRIPTIONREF. NO. KANRI

CAPSTAN SHAFT

REF. NO. DESCRIPTIONPART NO. DESCRIPTIONREF. NO. KANRI

NO.

FLY WHEEL L

FW PLATE

CAPSTAN SHAFT

PART NO. KANRI

NO.

1 S8-HR8-003-010 FRAME CENTER

2 S8-505-240-000 GEAR SHAFT

3 S8-505-070-000 REEL GEA R T

4 S8-505-080-000 CLUTCH GEAR

5 S8-505-300-000 FELT

6 S8-505-200-000 CLUTCH SP

7 S8-505-120-000 REEL GEAR BUSH

8 S8-505-290-000 REFLECTING PLATE

9 S8-505-210-000 BRACK TENSHION SP 10 S8-000-100-000 REEL CAP

11 S8-505-090-000 FWD GEAR PLATE 12 S8-505-060-000 FWD GEAR 13 S8-505-250-000 GEAR PLATE PIN 14 S8-505-220-000 FWD GEAR SP 15 S8-505-050-000 CENTER GEAR

16 S1-2X2-5X0-25L L CUT W 17 S8-505-320-000 FF GEAR HOLDER 18 S8-505-330-000 FF GEAR 19 S8-505-310-000 GEAR HOLDER SP 21 S8-7A9-156-310 MOTOR(IBIGB02)

22 S1-2X2-5X0-1LC L CUT W 23 SV-500-000-000 SUB BELT 24 SV-190-000-000 MAIN BELT 25 S8-505-100-000 FWD ARM 26 S8-505-110-000 REV ARM

27 S8-505-260-000 SUB CHASSIS 28 S8-505-160-000 REV SELECT 29 S8-505-190-000 SELECT SP 30 S8-505-020-000 HEAD BASE 31 S7-000-080-000 PINCH ROLLER

32 S8-7A9-119-100 HEAD ASSY(PH8ZM-3) 33 8A-HR8-219-010 PLATE EARTH MOT 34 S8-300-160-000 HEAD BASE SP 35 S8-300-170-000 PINCH SP FWD 36 S8-500-090-000 PINCH SP REV

37 8A-HR8-214-010 SPR-P CASS 38 S8-505-130-000 COVER

A S1-PB1-7X5-500 SCREW 1.7-5.5

B S3-PY1-7X2-500 SCREW 1.7-2.5

C S3-PB1-7X3-000 SCREW

REF. NO. DESCRIPTIONPART NO.

NO.

CL-850-5 (FileName:MECH.EPS)

2000/1/14 AHR-8

ACCESSORIES / PACKAGE LIST

PART NO. KANRI

NO.

1 8A-HR8-902-010 IB,YHJ(ECC) 408 S<YH,YJ> 1 8A-HR8-904-010 IB,YL(3L) 408 S<YLB,YL> 1 8A-HR8-901-010 IB,YU(3L)S<YU> 1 8A-HR8-915-010 IB,YZ(EGF) 308S<308YZ> 1 8A-HR8-905-010 IB,YZ(EGF) 408 S<408YZ>

1 8A-HR8-917-010 IB,YZ(PHNCZ) 308 S<308YZ> 1 8A-HR8-907-010 IB,YZ(PHNCZ) 408 S<408YZ> 1 8A-HR8-916-010 IB,YZ(SID) 308 S<308YZ> 1 8A-HR8-906-010 IB,YZ(SID) 408 S<408YZ> 2 87-B30-254-010 HEADPHONE,HP-M007B(T)<308YZ>

2 87-B30-336-010 HEADPHONE,HP-M041(S)<YH,308YZ,408YZ,YJ,YL> 2 87-B30-333-010 HEADPHONE,HP-M051(S)<YLB> 2 87-B30-335-010 HEADPHONE,HP-M053(S)<YU> 3 8A-HR8-951-010 RC UNIT,RC408<EXCEPT 308YZ>

DESCRIPTIONREF. NO. KANRI

REF. NO. DESCRIPTIONPART NO.

NO.

2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111

Printed in Singapore9630469 0251431

Aiwa HS-RX308, HS-RX408 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
