Aiwa CSD-ED87 User Manual [en, es, fr]
COM P A Q DI S C S T ER E O R AD I O C AS S ET T E R EC O RD E R
RAD I O CA S ET E E ST É RE O C O N R E PR O DU Q OR DE
RAD I O -C A SS E HE LE C TE U R D E C D S TE R EO
CSD-ED87
OPERATING INSTRUQIONS
See pa^e 2.
■
MANUAL DE INSTRUCCIONES í
Ver la página 8.
MODE D'EMPLOI
Voir page 14. ^
8Z-CHE-905-01
981205AAO-I-B
DIGITAL AUDIO
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
“CAUTION: TO REDUCE THE RISK OF
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
Explanation of Graphical Symbols;
ELECTRIC SHOCK,
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.”
5 Objects and liquid entry - Take care that objects or
liquids do not get inside the unit through the ventilation
openings.
6 Carts and stands - When placed or
mounted on a stand or cart, the unit should
be moved with care. ■ •IM I
Quick stops, excessive force, and uneven
surfaces may cause the unit or cart to
overturn or fall.
7 Condensation - Moisture may form on the CD pickup
lens when:
- The unit is moved from a cold spot to a warm spot
- The heating system has just been turned on
- The unit is used in a very humid room
- The unit is cooled by an air conditioner
When this unit has condensation inside, it may not
function normally. Should this occur, leave the unit for a
few hours, then try to operate again.
8 Wall or ceiling mounting - The unit should not be
mounted on a wall or ceiling, unless specified in the
Operating Instructions.
The lightning flash with arrowhead symbol, within
an equiiaterai triangie, is intended to alert the user
to the presence of uninsulated “dangerous volt
age” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral trian
gle is Intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
OWNER’S RECORD
For your convenience, record the model number (you will find it at the
bottom of the unit) and serial number (you will find it in the battery
compartment) in the space provided below. Please refer to them when
you contact your AIWA dealer in case of difficulty.
Model No. Serial No.
Precautions
Read the Operating Instructions carefully and completely
before operating the unit. Be sure to keep the Operating
Instructions for future reference. All warnings and cautions in
the Operating Instructions and on the unit should be strictly
followed, as well as the safety suggestions below.
Installation
1 Water and moisture - Do not use this unit near water,
such as near a bathtub, washbowl, kitchen sink, laundry
tub, in a wet basement, swimming pool, or the like.
2 Heat - Do not use this unit near sources of heat, including
heating vents, stoves, or other appliances that generate
heat.
It also should not be placed in temperatures less than 5°C
(41 °F) or greater than 35°C (95°F).
3 Mounting surface - Place the unit on a flat, even surface.
4 Ventilation - The unit should be situated with adequate
space around it so that proper heat ventilation is assured.
Allow 10 cm (4 in.) clearance from the rear and the top of
the unit and 5 cm (2 in.) from each side.
- Do not place the unit on a bed, rug, or similar surface
that may block the ventilation openings.
- Do not install the unit in a bookcase, cabinet, or airtight
rack where ventilation may be impeded.
2 ENGLISH
Electric Power
1 Power sources - Use on batteries or AC house current,
as specified in the Operating Instructions and marked on
the unit.
2 Polarization - As a safety feature, some units are
equipped with polarized AC power plugs which can only
be inserted one way into a power outlet. If it is difficult or
impossible to insert the AC power plug into an outlet, turn
the plug over and try again. If it still does not easily insert
into the outlet, please call a qualified service technician to
service or replace the outlet. To avoid defeating the
safety feature of the polarized plug, do not force it into a
power outlet.
3 AC power cord
- When disconnecting the AC power cord, pull it out by
the AC power plug. Do not pull the cord itself.
- Never handle the AC power plug with wet hands, as this
could result in fire or shock.
- Power cords should be firmly secured to avoid being
bent, pinched, or walked upon. Pay particular attention
to the cord from the unit to the power socket.
- Avoid overloading AC power plugs and extension cords
beyond their capacity, as this could result in fire or
shock.
4 Extension cord - To help prevent electric shock, do not
use a polarized AC power plug with an extension cord,
receptacle, or other outlet unless the polarized plug can
be completely inserted to prevent exposure of the blades
of the plug.
5 When not in use - Unplug the AC power cord from the
AC outlet or remove all the batteries if the unit will not be
used for several months or more. When the cord is
plugged in, a small amount of current continues to flow to
the unit, even when the power is turned off.
Maintenance
Clean the unit only as recommended in the Operating
Instructions.
Damage Requiring Service
Have the units serviced by a qualified service technician if:
- The AC power cord or plug has been damaged
- Foreign objects or liquid have got inside the unit
- The unit has been exposed to rain or water
- The unit does not seem to operate normally
- The unit exhibits a marked change in performance
- The unit has been dropped, or the cabinet has been
damaged
DO NOT ATTEMPT TO SERVICE THE UNIT YOURSELF.
Power Supply
OPE/BATT
Remote Control
Insert two R6 (size AA) batteries.
The OPE/BATT indicator lights up while electric current flows
to the unit.
Using on AC House Current
Connect the AC cord as illustrated below.
CAUTION
Use only the supplied AC cord. Use with other cords may
result in the risk of fire.
Using on Batteries
Open the lid of the battery compartment on the rear and
insert eight R14 (size C) batteries, not supplied, with the O
and © marks correctly aligned. Then close the lid.
To switch from AC power supply to battery power
supply, disconnect the AC cord from the AC inlet.
When the reach of the remote control signal is less than 5
meters (16 feet), replace the batteries.
The remote control may not operate correctly when:
- The unit is exposed to intense light, such as direct sunlight
- Objects block the remote control signal to the unit
To use the buttons on the remote control
Buttons on the remote control and the main unit with identical
indications have the same functions.
To turn the power on
Press POWER to turn on the display.
When using the unit on the batteries, this button will not turn
the power on.
To turn the power off
Press POWER to turn off the display.
When one of the deck operation buttons is pressed, this
button will not turn the power off.
To use the FUNCTION button
Each time FUNCTION is pressed while the power is on, the
function is selected cyclically.
CD
* applicable when one of the deck operation buttons is
pressed
RADIO
‘TAPE
When to replace the batteries
The OPE/BATT indicator becomes dim, the tape speed
slows down, volume decreases, or sound is distorted during
operation.
Notes on batteries
• Do not mix different types of batteries or old batteries with
new ones.
• When the unit is not to be used for a long period, remove
the batteries to prevent needless battery wear.
• Never recharge the batteries, apply heat to them or take
them apart.
• Remove dead batteries.
If liquid leaks from the batteries, wipe thoroughly to remove.
• FUNCTION
POWER
ENGLISH
□□
E5Q
play/pause/preset
REPEAT/
FM MODE/
ose
□
TUNER OPERATION
Press *RADIO/BAND repeatedly to select the
1
desired band.
I—> FM —> AM —I
The power is turned on and the previously tuned
station is received.
The RADIO indicator lights up.
* or BAND on the remote control (applicable when the
AC cord is connected)
2 Press {+, - TUNING) to select a
station. ^^
During FM stereo reception, I STEREO] is displayed.
After listening, press POWER 6 STANDBY to turn the
power off.
For better reception
FM
£
STOP/MEMORY taiddd
- TUNING +
POWER Ò STANDBY BAND
TAPE
NOTE
If the unit picks up noise from other electrical appliances
nearby, like a TV or fluorescent lights, move the unit.
RADIO
3
CD J
PRESETTING STATIONS
You can preset up to 15 stations in each band.
1
Select a station.
Press *■ STOP/MEMORY once so that “M” is
2
displayed to store the station.
A station is assigned a preset number, beginning from 1
in consecutive order for each band.
“M” may not be displayed if the button is kept pressed for
more than 0.5 second.
Preset number
Extend the FM antenna and The AM antenna is inside
orient it for the best reception. the unit. Position the unit
for the best reception.
For quick tuning
Keep +, — TUNING pressed until the tuner starts
searching for a station. When a station is tuned to, the
search stops.
If the broadcast signal is weak, it does not stop. To stop
the search manually, press + or —.
*REPEAT/FM MODE/OSC
- If an FM stereo broadcast contains noise, press the
button so that IMONOI is displayed.
Noise is reduced, although reception is monaural.
To restore stereo reception, press the button again.
- If a high-pitched sound is heard during AM recording,
press the button repeatedly until the noise is reduced. Its
position can be checked by being on or off the display.
* or MODE on the remote control
To change the AM tuning interval
The default setting of the AM tuning interval is 10 kFIz/step.
If you use this unit in an area where the frequency
allocation system is 9 kHz/step, change the interval as
follows.
1 Press RADIO/BAND to display FM.
2 Press ■ while pressing RADIO/BAND to display the
AM frequency.
When the AM tuning interval is changed, the preset
stations are cleared.
4 ENGLISH
(am
MHz
Frequency
* or ■ on the remote control
3 Repeat steps 1 and 2.
The next station will not be stored if a total of 15 preset
stations have already been stored for a band.
To listen to preset stations
Select a band then press ►!! PLAY/PAUSE/PRESET
repeatedly.
► PLAY on the remote control is also available.
To select a preset number directly with the remote control
Press the numbered buttons 0-9 and -hIO.
Example:
To select number 15, press +10 and 5.
To select number 10, press +10 and 0.
To clear a preset station
Display the preset number first. Then, press ■ while the
preset number is displayed.
The higher numbers in the band are decreased by one.
0-9, +10
BAND
II PAUSE
□ □ g
o o o
o o o
o o o
ü
MODE
STOP
m
CD OPERATION
7 Press CD.
The power is turned on and the CD indicator iights up.
2 Press OPEN to open the disc compartment.
Place a disc with the printed side up and
close the disc compartment.
Total number of tracks and total playing time are
displayed.
Press *►!! PLAY/PAUSE/PRESET to start
play.
The number of the track being played and elapsed
playing time are displayed.
* or ► PLAY on the remote control
STOP/MEMORY - Stops play.
► II PLAY/PAUSE/PRESET - Pauses play. To resume
play, press again.
* or II PAUSE on the remote control
►W SKIP/SEARCH - Searches for a particular point
during playback. Keep or ►>! pressed and then
release it.
- Skips to the beginning of a track. Press or
repeatedly.
*REPEAT/FM MODE/OSC - Repeats a single track or all
tracks. Select as follows.
CZ! 1: A single track is played repeatedly. Select a track
with or ►►!.
CZ : All tracks are played repeatedly.
* or REPEAT on the remote control
To start play when the power is off, press CD. The
power is turned on and play of the loaded disc begins
(Direct Play Function).
If you load a disc while the CD indicator flashes in step 2,
play starts without pressing ►!!.
After listening, press POWER Ó STANDBY to turn the
power off.
NOTE
• Do not use irreguiar shape CDs (example: heart-shaped,
octagonal ones).
It may result in malfunctions.
• Do not place more than one disc in the disc compartment.
• Do not try to open the disc compartment during play.
• Do not touch the lens. Doing so may cause malfunctions.
PROGRAMMED PLAY
Up to 30 tracks can be programmed from the disc.
1 In stop mode, keep *■ STOP/MEMORY
pressed until “M” flashes in the display.
* or ■ on the remote control
2 Press !◄◄, ►M to select a track, then press
■ STOP/MEMORY to store it.
Track number
Programmed number
To select a track with the remote control
Press the numbered buttons 0-9 and +10.
Repeat step 2 to program other tracks.
3
4
Press ►!! to start play.
To check the program, press
To clear the program, press I
disappears in the display.
To change the programmed tracks, clear the program and
repeat all the steps again.
in stop mode so that “M”
or in stop mode,
To select a track directly with the remote control, press
the numbered buttons 0-9 and +10. CD play starts from
the selected track and continues to the last track.
Example:
To select number 25, press +10, +10 and 5.
To select number 10, press +10 and 0.
To listen with the headphones
Connect headphones with a stereo mini plug to the 0 jack.
ENGLISH 5
POWER6 STANDBY/
TAPE
VOLUME
REPEAT/
FM MODE/OSC
Eiigg-]
3-MODE EQUALIZER
T-BASS
QSOUND
PE OPERAT!
Use Type I (normal) tapes only.
INSERTING A TAPE
Press ■/± STOP/EJECT to open the cassette holder and insert a tape with the exposed side up and the side to be played facing out.
Push the cassette holder to close.
STOP/MEMORY MljjJ
PAUSE STOP/EJECT F FWD REWIND PLAY REC
RECORDING
Note that recording is done on only one side of the tape.
7 Insert a tape with the side to be recorded facing
out.
"2. Get ready to record from the source.
To record from a CD, press CD and load the disc.
To record from a radio broadcast, press RADIO/
BAND and tune to a station.
3 Press # REC to start recording.
◄ PLAY is pressed simultaneously.
When the selected function is CD, CD play and
recording starts simultaneously.
PLAYING A TAPE
Press ◄ PLAY while the power is off.
The power is turned on and play of the Inserted tape
begins.
The volume level Is displayed during tape operation.
■/A STOP/EJECT - Stops play. The power will be
automatically turned off.
II PAUSE - Pauses play. To resume play, press again.
REWIND/^^ F FWD - Rewinds/fast forwards. To
stop the winding, press H/^.
To record oniy the selected tracks of a CD
1 Follow steps 1 to 3 of PROGRAMMED PLAY on page 5
to program tracks.
2 Press • REC.
To stop recording, press STOP/EJECT.
When recording from a CD, play pauses. To stop CD play,
press ■ STOP/MEMORY.
To pause recording, press II PAUSE. To resume
recording, press again.
To erase recording, press • REC while the power is off.
After recording, press POWER 6 STANDBY to turn the
power off.
To prevent accidental erasure
Break off the plastic tabs on the cassette tape with a
screwdriver or other pointed tool after recording.
To record on the tape again
Cover the tab openings with adhesive tape, etc.
6 ENGLISH
Side A
Tab for side A
Loading...
