ES-6000
Email Server Appliance
ew generation of Mail Server Appliance,
AirLive ES-6000, is designed for the SMB
N
or enterprise that needs to install an easy
maintained and fully functional mail server. It
not only preserves the outstanding features
of ES-4000, but also supports Push Mail.
Therefore, you can receive email on your mobile
phone everywhere. The Multiple Domains allow
creating of several domain names within a mail
server; and the Anti-Spam helps to filter out the
increasing rubbish mail.
With complete mail server functions offering easy installation of mail service, mail security protection,
and mail backup system, AirLive ES-6000 is the excellent choice for the mail service.
POP3(s) SMTP(s) IMAP(s)
Push
Mail
Multiple
Domains
Web
Server
Web
Mail
Mail
Audit
Web
Disk
DNS
Server
Anti-
Spam
Mail
Backup
Anti-
Virus
HA
Easy installation and useful mail system
After few steps of installation, an useful mail server with POP3(s), SMTP(s), IMAP(s), Push Mail,
Web Mail and Web Disk function can be deployed and ready for use.
Push Mail
System will push email to user’s mobile phone, so users can receive and reply mail via mobile phone
on the go.
Web Mail
Sometimes users need to reach email in public computer; such as cyber cafe, but it might be not
allowed or proper to download private mail. Web mail function provides internet users to check mail via
web browser; hence, users will be able to read or send email only with internet connection.
Mail server transfer
It is very possible to lose mail during the period of a new mail server installation. ES-6000 provides
a mechanism to check new mail from old mail server even in the process of DNS synchronization, and
keep on receiving the mail.
5F, No.96, Min-ChuanRd, Hsin-tien City, Taipei, Taiwan
Page 2
Personal Web Disk
Instead of sending mail with attached large files, user can store the file in Personal web disk
and send out the address of hyperlink, and then Internet user will be able to download it without
authentication.
Multiple Domains
Up to 10 mail domains can be created on ES-6000 and work simultaneously. Each mail domain can
have its own mail account as well.
Anti-spam
Built-in with Bayesian, fingerprint, verifying sender account, checking sender IP in RBL and else
antispam system work to filter spam mail automatically.
Anti-virus
Built-in with Clam AV and Sophos scan engine ES-6000 can filter malicious program in mail content,
to prevent mail receiver from virus threat. The virus pattern can be updated regularly, and without any
license fee.
Mail Audit / Archive
User can define rule (such as keyword, sender, receiver, size…) for mail audit. When the incoming
or outgoing mail matches the rule, the system will handle such mail based on the rule to pass, delete,
inspect, delay, or copy to a specific account.
Mail Account Learning
Built-in with mail account learning system, such as Automatically Adding, Query Old Mail Server, or
LDAP, user can move mail account from old mail server, or create new mail account easily.
Shared Address Book
Shared Address Book function not only works for Web Mail users but also connects to mail client
software with LDAP service (such as Outlook Express) to search the destination address within Shared
Address Book.
Web Server
ES-6000 not only provides mail server function, but also offers web server function to allow user to
create company’s website on same device. So there is no need to purchase other software or hardware
for web service.
DNS
Built-in with DNS server, administrator can setup the domain name resolution by himself, and will not
need to spend money to deposit DNS service at ISP.
Remote Backup
ES-6000 will record every passing mail as the record, and backup the record to NAS or File Server
by schedule. Those mail records can also be retrieved from NAS or File Server via ES-6000.
HA
With built-in with HA (High Availability) function, the stored data can be synchronized with two
ES-6000 devices. This prevents loss of mail while mail server is damaged.
5F, No.96, Min-ChuanRd, Hsin-tien City, Taipei, Taiwan
Page 3
Hardware Specification Comparison of ES-4000 v2 and ES-6000
ES-4000 v2
CPU Celeron 1.2 GHz Celeron 1.5 GHz
DRAM DDR 512 MB SOD 1GB
HDD
HDD replaceable
Max. HDD drive size
Interface
Console
Power
Dimension
Rack Mount
Weight
IDE 160 GB IDE 500 GB
Yes Yes
IDE 350 GB IDE 750 GB
1 Mail Port + 1 HA Port
(RJ-45 Giga Port)
DB9 RS-232 DB9 RS-232
100 ~ 250 VAC 100 ~ 240 VAC
43 x 27.2 x 4.2 cm 43 x 24.5 x 4.2 cm
Yes Yes
4.25 kg 3.8 kg
ES-6000
1 Mail Port + 1 HA Port
(RJ-45 Giga Port)
Software Specification Comparison of ES-4000 v2 and ES-6000 (1)
-- Mail Server
Mail Protocol
ES-4000 v2
1. POP3(s)
2. SMTP(s)
3. IMAP(s)
ES-6000
1. POP3(s)
2. SMTP(s)
3. IMAP(s)
Web Mail HTTP, HTTPS HTTP, HTTPS
Push Mail
Web Disk
Multiple Domain
Domain Alias
1. Automatically Learning
Mail Account Management
Mail Quota Limitation
Shared Address Book
Mail Archive / Audit
Anti-Spam
Anti-Spam Filter
Whitelist / Blacklist No Yes
Spam Learning No Yes
Anti-Virus Clam AV Clam AV + Sophos
Quarantine No Anti-Spam, Anti-Virus
Updated License Free Free
Max. Mail Account Unlimited Unlimited
2. Query Old Mail Server
3. Import from LDAP Server
4. Manually Adding
Mail Box, Mail Size,
No Yes
Yes Yes
No Yes, up to 10
Yes Yes
1. Automatically Learning
2. Query Old Mail Server
3. Import from LDAP Server
4. Manually Adding
Mail Box, Mail Size,
Web Disk,
Yes Yes
No Yes
No Yes
No
Web Disk, Push Mail
1. Fingerprint
2. Bayesian
3. Check Sender IP in RBL
5F, No.96, Min-ChuanRd, Hsin-tien City, Taipei, Taiwan
Page 4
Software Specification Comparison of ES-4000 v2 and ES-6000 (2)
-- Else function and operating system
Web Server
DNS Server Yes Yes
Remote Backup to NAS or
File Server
Schedule Backup
HA (High Availability)
Report delivered by mail
Specifi cations
Hardware
- Processor: Celeron 1.5 GHz
- Memory: 1GB DRAM
- Hard Disk: IDE 500GB, ext3 file system
- Ethernet Port: 2 x RJ-45 Giga port
- Console: DB9 RS-232 port for checking status
or reset default
- Power: 90~264 VAC ( Auto-sensing )
- Power consumption: 85 Watts
- Dimension: 43 x 24.5 x 4.2 cm
ES-4000 v2
Yes Yes
Full Backup Based on Mail Archive rule
Yes Yes
Yes Yes
Yes Yes
ES-6000
Mail Account Management
- Automatically Learning
- Query Old Mail Serve
- Import from LDAP Server
- Manually Adding
- Quota limitation
- Mailbox
- Mail size
- Web Disk
- Push Mailbox
Mail System
- POP3(s), SMTP(s), IMAP(s)
- Web Mail, Web Disk
- Push Mail
- Multiple Domains
- Shared Address Book
- DNS Server
- Web Server
Mail Security
- Anti-Spam filtering system
- Fingerprint
- Bayesian
- Check sender IP address in RBL
- Greylist
- Whitelist
- Blacklist
- Spam mail and ham mail training
- Anti-Virus
- Anti-Virus scan engine: Clam AV, Sophos
- Virus pattern update: Automatically, Manually
- Zero license fees
- Mail Audit / Archive
Mail Backup
- HA (High Availability)
- Remote backup to NAS or file Server
- Mail Copier
Mail Report
- Mail Statistic
- Mail Log
- Export Mail Report by Mail
- Yearly report
- Monthly report
- Weekly report
- Daily report
Mail Log
- Connection Track
- System info
- Event Log
5F, No.96, Min-ChuanRd, Hsin-tien City, Taipei, Taiwan
Page 5
System Management and Maintenance
- Web-based management
- Firmware upgrade
- Export or Import configuration file
- Export or Import Account database
Environment
- Operating Temperature: 5 ~ 40
- Operating Humidity: 5 ~ 90
℃
℃
Ordering Information:
AirLive ES-6000 Email Server Appliance
Certification
- CE, FCC
