CamPro HD
64CH IP HD Camera
Management Software
User’s Manual
Copyright and Disclaimer
Copyright & Disclaimer
No part of this publication may be reproduced in any form or by any means, whether
electronic, mechanical, photocopying, or recording without the written consent of
OvisLink Corp.
OvisLink Corp. has made the best effort to ensure the accuracy of the information in
this user’s guide. However, we are not liable for the inaccuracies or errors in this guide.
Please use with caution. All information is subject to change without notice.
All Trademarks are properties of their respective holders.
AirLive CamPro HD User’s Manual i
Copyright and Disclaimer
FCC Statement
Federal Communication Commission Interference Statement This equipment has been
tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one of the following measures:
z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
z Consult the dealer or an experienced radio/TV technician for help.
FCC Caution
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation. For product available in the USA/Canada market, only
channel 1~11 can be operated. Selection of other channels is not possible.
This device and its antenna(s) must not be co-located or operation in conjunction with
any other antenna or transmitter.
IMPORTANT NOTE
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
AirLive CamPro HD User’s Manual ii
Table of Contents
Table of Contents
1. Overview.............................................................................................1
1.1 System Requirement........................................................................................1
1.2 Installation ........................................................................................................2
1.3 Quick Start........................................................................................................5
2. Main-console....................................................................................25
2.1 System status.................................................................................................26
2.2 Screen Division ..............................................................................................27
2.3 DI/O status .....................................................................................................28
2.4 Operation with sub-screen .............................................................................29
2.5 System setup .................................................................................................32
2.5.1 System page at System setup dialog ............................................................................32
2.5.2 Camera page at System setup dialog ...........................................................................36
2.5.3 User page at System setup dialog.................................................................................43
2.5.4 Address Book page at System setup dialog ..................................................................46
2.5.5 Notification page at System setup dialog ......................................................................47
2.5.6 Multi-Monitor at System setup dialog ............................................................................50
2.5.7 Joystick at System setup dialog ....................................................................................51
2.6 Schedule setup ..............................................................................................53
2.6.1 Schedule mode..............................................................................................................54
2.6.2 Select camera of Daily mode.........................................................................................55
2.6.3 Select weekday of Weekly mode...................................................................................55
2.6.4 Select camera of special day mode...............................................................................57
2.6.5 Add or remove special day .........................................................................................57
2.6.6 Add schedule time slice.................................................................................................58
2.6.7 Modify schedule time slice.............................................................................................58
2.6.8 Remove schedule time slice..........................................................................................59
2.6.9 Record Setup Page .......................................................................................................60
2.6.10 Record Mode ...............................................................................................................60
2.6.11 Record Setting: ............................................................................................................61
2.6.12 Motion Configuration....................................................................................................61
2.6.13 DI Record Setting .......................................................................................................62
2.6.14 Complete Schedule Setting .........................................................................................63
2.7 Start & Stop Monitor .......................................................................................64
2.7.1 Alarm Event Report........................................................................................................65
2.8 E-Map ............................................................................................................66
2.9 Two Way Audio...............................................................................................68
2.10 PTZ control...................................................................................................69
2.11 Alarm Setting ................................................................................................72
2.12 Server Setup ................................................................................................81
AirLive CamPro HD User’s Manual i
Table of Contents
2.13 Log Viewer ...................................................................................................83
2.14 Import / Export Setting .................................................................................85
3. Playback ...........................................................................................86
3.1 Search history recorded file(s) .......................................................................87
3.2 Playback control button(s)..............................................................................90
3.3 Convert to AVI file...........................................................................................92
3.4 Switch audio play mode .................................................................................94
3.5 Playback setting .............................................................................................94
3.6 Snapshot dialog .............................................................................................95
3.7 Backup history file(s)......................................................................................97
3.8 Playback status ..............................................................................................99
3.9 Operation with sub-screen ...........................................................................100
4. Remote Service..............................................................................107
5. Repair Database.............................................................................113
5.1 Repair database status ................................................................................ 114
6. Un-install.........................................................................................115
AirLive CamPro HD User’s Manual ii
1
1.1 System Requirement
1. Overview
1. Overview
FPS
(QVGA)
CPU Intel P4
RAM 512MB 512MB 1GB 2GB 2GB
Display Support1024x768 resolution or above
OS
Hard disk 60GB
Ethernet 100Mbps 1Gbps
Chipset Intel 945 or Intel 965 or above
＊ If you install the Cam Pro HD with the Vista, you should install more physical
memory into system.
~120 120~360 360~540 540~960 960~
2.4GHz
Intel P4
3.2GHz
Intel Pentium D
950
3.4GHZ
Support DirectX 9.0c or above
Intel 945G or Intel 965G or above
Windows XP，Vista＊, 7
Intel core 2 Duo
E8600
3.3GHZ
Intel core 2
Quad
Q9650
3.0GHZ
QVGA = 320 x 240 pixel
CIF ≒ QVGA, D1 ≒ VGA at mapping table below.
Image resolution mapping table
Resolution Compared with QVGA
QQVGA QQVGA = QVGA / 4
VGA VGA = QVGA x 4
SXGA SXGA = QVGA x 16
AirLive CamPro HD User’s Manual 1
1.2 Installation
z Before Installing the Software
1. Make sure your PC has installed DirectX 9.0c or above.
2. Run Cam Pro HD5xxx.exe, which is included in the enclosed Software CD.
z Starting the Installation
1. The Installation Wizard will start. Select your preferred language for the Cam
Pro HD.
1. Overview
2. The License Agreement window will be listed as belowt.
Click “I Agree” to continue if you want to install this software.
AirLive CamPro HD User’s Manual 2
3. Select the “Cam Pro HD Basic” , then click Next button.
1. Overview
4. The Choose Destination Location window will open next. Select the folder
which you wish to intall Cam Pro HD Basic to, and then click on Install button
to continue.
AirLive CamPro HD User’s Manual 3
1. Overview
5. The Installation Wizard Complete window will open next. Click on Close
button to complete the installation.
AirLive CamPro HD User’s Manual 4
1.3 Quick Start
z Install IP Camera(s)
1. Setup the IP camera(s) following by the instruction manual provided by the
manufacturer.
2. Check the network between the IP camera(s) and the system.
3. Add the IP camera(s) to the system following steps as below.
z Add IP Camera(s)
1. Click the Start → All Programs → Cam Pro HD_Basic_5.0 → Cam Pro HD.
2. Key-in User name and password to login Cam Pro HD
1. Overview
The default of user name is “admin” without password)
Checked the “Remember User” then login system, next time, will auto set the
username by login account this time.
AirLive CamPro HD User’s Manual 5
3. Click System setup
1. Overview
AirLive CamPro HD User’s Manual 6
1. Overview
4. Select Camera page and key-in camera’s configuration, then click “Add”
button.
Camera configuration:
Click “Auto Detect” button to detect camera, system will check and set model
automatically.
Please confirm the “Vendor” and “Model” setting is matched to the camera, or
may cause the camera not functional properly.
AirLive CamPro HD User’s Manual 7
1. Overview
If you need to change the Camera Parameters, click Camera parameter
button.
Select the Video codec, Resolution, protocol, and streaming port for the
current connection.
AirLive CamPro HD User’s Manual 8
1. Overview
Checked the “Enable Audio” if you need to receive Audio streaming.
If you need to record audio into file, you must checked “Enable Audio” and
“Enable Audio Record” both.
5. Click the “Search” button to search the camera(s) installed in LAN, waiting for
searching complete then select the cameras as your need, and click “OK”
button to finish this job.
AirLive CamPro HD User’s Manual 9
6. Confirm all added camera’s setting parameter.
1. Overview
7. Click “OK” button.
8. Now you can preview live stream at main page.
AirLive CamPro HD User’s Manual 10
− Configuration of schedule recording
1. Click “Schedule Setup” button.
1. Overview
AirLive CamPro HD User’s Manual 11
2. Select the Schedule type that you need.
1. Overview
Daily mode: Setup each camera’s recording time and type on every day.
Weekly mode: Setup each camera’s recording time and type in each
weekday.
Special day mode: Setup each camera’s recording time and type on
specified day.
If the Special day schedule was set , when the system time matched the
Special day setting, system will execute this special day setting
immediately as top priority, even system has the same time period
setting of daily or weekly schedule setup.
AirLive CamPro HD User’s Manual 12
3. Select one camera for schedule configuration.
1. Overview
4. Select one of weekday for setup schedule(weekly mode).
AirLive CamPro HD User’s Manual 13
1. Overview
5. If you want to modify a specified schedule period, Select the period first from
time period list or time period bar, or skip this step.
6. Modify the time period from time-select control or drag the period bar below.
AirLive CamPro HD User’s Manual 14
1. Overview
7. After setting with time period, if you want to add a new schedule, click “Add”
button, or you want to modify a selected schedule, click the “Edit” button.
8. Choose the Round-the-clock or Motion detection or DI detection record mode.
AirLive CamPro HD User’s Manual 15
1. Overview
9. If you select the Motion detection mode, you have to configure the detection
area, or use default setting.
Add detection area: Click “Add” button, and then drag a rectangle window
on the preview image.
Remove detection area: Click “Delete” button, then drag a rectangle
window on the preview image.
Recover to default area: Click the “Default” button.
The red transparent window is the monitored area, otherwise will not be
monitored.
AirLive CamPro HD User’s Manual 16
10. DI Record Mode:
1. Overview
(1) Select trigger recording and specify the DI input source.
(2) Set trigger recording depend on whether status of DI is open or close.
AirLive CamPro HD User’s Manual 17
11. Start schedule monitor.
Click the “Monitor” button and checked the Start Monitor all or Start Monitor
Schedule.
1. Overview
AirLive CamPro HD User’s Manual 18
− Playback
1. Click “Playback” button to launch playback panel.
1. Overview
AirLive CamPro HD User’s Manual 19
2. Click “Search” button to approach search dialog.
1. Overview
AirLive CamPro HD User’s Manual 20
3. Click on the date that you want to search recorded files.
1. Overview
AirLive CamPro HD User’s Manual 21
1. Overview
4. Choose Record mode(s) that you need (Round the clock , Motion , Alarm)
5. Click “Search” button.
6. System will display recorded file(s) status in control list below.
Blue: Round the clock recorded file.
Green: Motion detection recorded file.
Red: DI triggered recorded file.
AirLive CamPro HD User’s Manual 22
7. Drag mouse cursor on the list control to select playback time period.
1. Overview
8. Select the camera(s) to playback recorded file(s).
System allows maximum 16 cameras playback at once.
AirLive CamPro HD User’s Manual 23
9. Click “OK” button to finish search recorded files for playback job.
1. Overview
10. Click “play” button to start playback procedure.
AirLive CamPro HD User’s Manual 24
2. Main-console
2. Main-console
2
This is the main console of the system, to provide live stream preview, system
setup, E-Map, schedule setup, playback, start or stop monitor, PTZ controls, and so
on.
AirLive CamPro HD User’s Manual 25
2.1 System status
2. Main-console
System
Status
Exit:
Exit
1. Logout: Logout current User
2. Minimize: Minimize the main console to taskbar
3. Exit: Shutdown CamPro HD
4. Version: Display version number.
System status:
1. System Date
2. System Time
3. Weekly day
4. Schedule and Alarm Monitor status, if monitor
stop , it will show nothing
5. Hard disk available free size
The system status can configure at system setting. Please refer to “Setup page”.
Hard Disk available free size has three color types, they mean:
1. Green: normal
2. Yellow: recycle job executing
3. Red: system can’t found available free space any more.
AirLive CamPro HD User’s Manual 26
2.2 Screen Division
Assign the preview screen to preferred layout division by clicking these buttons.
To switch to single camera display, just double click on a particular sub-screen.
Double click on the screen again to restore previous screen division layout.
2. Main-console
Divide to 1 Screen Divide to 4 Screen(s)
Divide to 6 Screen(s) Divide to 9 Screen(s)
Divide to 16 Screen(s) Divide to 32 Screen(s)
Divide to 64 Screen(s) Divide to NxN Screen(s)
Switch to Full screen mode Start Rotate sub-screen(s)
Stop Rotate sub-screen(s)
AirLive CamPro HD User’s Manual 27
2.3 DI/O status
Display real-time status of focused camera’s DI/O, and switch DO status by click
DO button.
Amount of DI/O button(s) depend on focused camera, it’s varied by camera.
2. Main-console
The system default is set to NC status (normal close). So, if DI status becomes
to open, the icon will show as red light.
DI is opening
DI is closed
When DO showed as , it means the DO is opening .
If DO showed as , it means the DO is closed.
You can click on the DO icon to change DO status. If after you clicked the DO
icon, but the status doesn’t be set correctly. It means that fails to set new DO
status. Please check network status or camera status.
AirLive CamPro HD User’s Manual 28
2. Main-console
2.4 Operation with sub-screen
z Define display camera(s) sequence
1. To switch display sequence in sub-screen(s), press and hold mouse left button
on source sub-screen, then drag to target sub-screen and release mouse left
button.
2. To switch current sub-window to another camera, click mouse right button on
the sub-screen, then choose the live camera you needed.
3. To remove camera display, click the mouse right button and click Remove
Camera display on popup menu.
z Digital Zoom at sub-screen
1. Click mouse right button on sub-screen, and checked Digital Zoom.
AirLive CamPro HD User’s Manual 29
2. Main-console
2. Move mouse cursor to the position that you want to zoom-in.
3. Roll mouse wheel forward to zoom-in.
4. Roll mouse wheel backward to zoom-out.
5. Press and hold mouse left button to drag the image at sub-screen onto the
position in which you preferred.
6. To cancel digital zoom mode, click mouse right button and un-checked Digital
Zoom.
z Switch to Full screen
1. Click mouse right button and check Full screen on popup menu to switch Full
screen mode.
2. Click “Esc” button or un-check “Full screen” on popup menu to return normal
display mode.
z Snapshot of sub-screen
1. Click mouse right button and choose Snapshot on popup menu.
2. Configure with the image by Snapshot dialog as below.
3. Click Save button and choose the folder that you want to save to.
AirLive CamPro HD User’s Manual 30
Snapshot dialog:
2. Main-console
Bright: 50 = Maximum brightness, -50 = Maximum dark
Contrast: 50 = Maximum strong with Contrast, -50 = Minimum value of Contrast.
Grayscale: Click to switch image to grayscale mode.
Sharp: Click Sharp button to increase image sharp level.
Soft: Click Soft button to increase image soft level.
Reset: Click Reset button to restore image to original image.
Print: Click Print button to print out image to printer.
Save: Click “Save” button and then choose folder and file name to save the
snapshot.
Exit: Close Snapshot dialog.
z Restore quad default
Reset division setting to default.
AirLive CamPro HD User’s Manual 31
2. Main-console
2.5 System setup
Click system setup button and select “System Setup” to approach System setup
dialog.
2.5.1 System page at System setup dialog
AirLive CamPro HD User’s Manual 32
z Start up configuration
Auto start:
Auto start main console while system is
booting up.
Auto monitor all:
Auto monitors all cameras when main
console booted up
Auto Full Screen:
Auto configure as full screen when main console booted up.
Minimized at started:
2. Main-console
Auto minimized main console when system booted up.
Auto login:
Auto login main console when system
booted up. It must configure “Auto login”
information.
z Language configuration
Click on the combo box of language, and
select the language that you preferred. System will change language immediately.
z Auto scan
Set the screen rotation interval by
seconds.
AirLive CamPro HD User’s Manual 33
z Storage configuration
1. Click “Add” button to select a new folder for recording work.
2. Main-console
2. Click “Delete” button to remove selected folder from list.
3. Click Move up and Move down button to change priority of recording folders.
Top of list is the first priority of recording work.
4. Set “Keep space over” in MB , it means when the hard disk free space less
than the setting number , system will recycle to kill the oldest recorded files.
5. Must click “Edit” button after modified “Keep space over” value.
z System status
Select status item(s) for display on system s
tatus
window.
Checked means this status will be displayed on
main console status window. Otherwise, it will display
nothing.
If “Hide when minimized” is checked, when
the main console is minimized, the icon will move
to system tray at right-down corner. Click the icon
console.
Host Name field is define this Cam Pro HD system’s name for the other
integration system.
AirLive CamPro HD User’s Manual 34
at system tray to restore main
z HDD status
The main console will display free space of hard
disk(s) by choosing “Show available size” or display
percentage of free space by choosing “Show available
percentage”.
z NxN Division
Set the N of NxN division. When user click NxN
division button, main console will divide the
sub-screen(s) by this value.
For examples,
If this value is set to 1, the divided sub-screen(s) is one sub-screen,
2. Main-console
If this value is set to 2, the divided sub-screen(s) is four sub-screens.
If this value is set to 3, the divided sub-screen(s) is nine sub-screens,
And so on …
AirLive CamPro HD User’s Manual 35
2.5.2 Camera page at System setup dialog
2. Main-console
z Camera list
List all camera(s) installed at system. It is listed by camera index.
Check each camera to enable them. If you need to disable some of these
camera(s), please un-check them by clicking check box.
AirLive CamPro HD User’s Manual 36
Clone Camera setting:
1. Select one camera and click “Copy”
button, or click mouse right button and
select “Copy” on pop-up menu.
2. Copy only camera’s configuration,
camera’s parameter or both of them.
3. Select a target camera and click
“Paste” button to update the settings
was copied.
4. (Or click mouse right button on target camera, and select “Paste” on pop-up
menu)
2. Main-console
5. Click “Apply all” button will toggle update all cameras setting with the copied
setting.
z OSD Configuration
System could show some information on the
sub-screen.
Checked the check box before the information
to enable displayed this one. The information will
display on the preview screen at left-upper corner.
Show Date: Display system date.
Show Time: Display system time.
Show Camera Name: Display this Camera name.
Show Frame per second: Display the frame per second of this channel.
Show Bitrate: Display the bit-rate per second of this channel.
AirLive CamPro HD User’s Manual 37
z Camera Configuration
2. Main-console
Vendor: Select Vendor name of this camera. If the selected Vender is not identical
to the camera, this channel may not work correctly.
General: For all supported IP cameras.
NVR: For backup streaming from another Cam Pro HD NVR.
Model: Select Model name of this camera. If the selected Model is not identical to
the camera, this channel may not work correctly.
Camera name: Set this channel’s camera name to identify this camera in system.
IP: Set this camera’s IP.
Port: Set this camera’s HTTP port.
DIPS: Set this camera’s DIPS ID
User: Set the User name for this camera. This User name must have the authority
to login the specified camera.
Password: Set the Password for this camera. This system will use the User name
and Password to login specified camera.
When camera has fixed IP or DNS set IP for connect camera ※
directly , if camera use dynamic IP , set DIPS ID for connect to
camera by DIPS service.
AirLive CamPro HD User’s Manual 38
2. Main-console
“Add” button: Insert camera configuration to system.
“Delete” button: Remove camera configuration from system.
“Edit” button: Modify the configuration from system.
“Clear” button: Clear all field for a new setting.
Must click “Edit” button after modified camera’s
configuration or the system will not save the modified
configuration.
“Search” button: Click the “Search” button to search the cameras at LAN.
System will popup a dialog and display all found cameras in the
list.
Wait for search completed and checked the cameras which you
need.
AirLive CamPro HD User’s Manual 39
z Search Page
2. Main-console
“Select all” button: Auto checked all cameras in the list.
“Cancel all” button: Auto un-check all cameras in the list.
“OK” button: Confirm all selected camera and close this page.
“Cancel” button: Cancel all actions and close this page.
Configure detail button:
Click “Config detail” button to access web page of the
selected camera.
Camera parameter button:
Click “Camera parameter” button to approach channel
parameter page.
AirLive CamPro HD User’s Manual 40
1. Channel parameter Page(general):
2. Main-console
Video Configuration:
Video codec: Select the Video codec which system will receive from
camera.
Resolution: Select the Resolution which system will receive from camera.
Note. The codec and resolution capability depend on camera.
Network Configuration:
Protocol: Select which protocol which system connects to camera.
RTSP Port: Specify RTSP port for connecting to camera.
AirLive CamPro HD User’s Manual 41
2. Main-console
Audio Configuration:
Enable Audio: Set Audio enabled to receive audio streaming form camera.
If you need to listen live audio, this function must be
enabled.
Enable Audio Record: Check this box to save audio data into recorded
file.
Note. The Audio Record must Enabled with “Enable Audio” value
both.
“OK” button: Save the connecting configuration, and return previous page.
“Cancel” button: Cancel the configuration in this page, and return previous
page.
2. Channel parameter Page(NVR):
Channel: Select which channel for backup.
Network config: Set RTSP connection port.
Enable Audio: Set Audio enabled to receive audio streaming form NVR. If you
need to listen for live audio, this function must be enabled.
Enable Audio Record: Check this box to save audio data into recorded file.
AirLive CamPro HD User’s Manual 42
2.5.3 User page at System setup dialog
2. Main-console
z User Privilege
User Privilege tree is to define user’s
privilege of each function of system. Checked
box means user can use this function and
un-checked means user can’t use it.
Main console:
It controls the main functions of the system.
User must have some of these privileges at
least or user can not do anything with system.
Start and Stop Monitor:
This function means user can start or s
system monitor work (schedule
recording).
top
Schedule Setup:
The privilege of user can access
schedule setup page.
AirLive CamPro HD User’s Manual 43
2. Main-console
System Setup:
The privilege of user can access system setup page.
EMap:
The privilege of user can use E-Map function.
Preview Quad control:
The privilege of user can change division of sub-screen.
PTZ control:
The privilege of user can control Pan, Tilt, and Zoom functions of camera.
Playback:
The privilege of user can playback recorded files.
Two way audio start:
The privilege of user can enable two-way audio with camera.
Remote Login:
This user could login remote service or not.
Preview: The privilege of user can preview live streaming.
User can preview the live streaming of checked cameras.
z Account list
Display all users’ information of system.
If you want to modify user’s configuration or delete user account, please click on
e user name in the list first. When you have modified user’s information (add, edit or
th
delete), please confirm the data is appeared in the list.
AirLive CamPro HD User’s Manual 44
2. Main-console
“admin” account: This user will own privilege of system administrator.
“logout” account: This is a special account when
system is under logout status.
z U
ser configuration
Configuration of user’s information.
User:
User name.
Group: Select the group of user. The admin group has all privilege of system by
default and
the user group only has main console privilege by default.
Password: The password of user for login system.
Confirm
Description: User can specify some description for
Disable User: Check this box to disable the
“Add” button: Key-in user’s information and checked user’s privil
password: Retype the password.
click “Add” button to add new user to the list
this account.
user account.
ege first, then
.
“Edit” button: Click on the user name of the list first, and then modify the data o
this account. After modified data, you must
click the “Edit”
button to confirm it.
“Delete” butto on
n: Click on the user name of the list, and then click “Delete” butt
to remove user accou
nt from list.
“Clear” button: Clear all field of setting.
f
AirLive CamPro HD User’s Manual 45
.5.4 Address Book page at System setup dialog
2
Setting address book for sending event mail or query phone from here.
Add address book record:
Key-in contact information, and then click the “Add” button.
2. Main-console
Delete address book record
Click on the contact list which you want to delete, then click
:
“Delete” button.
Edit address book record:
1. Select the record which you want to modify.
2. Modify the information
Cha
nge photo of contact:
a picture to replace it.
Click the “▽” button blow of photo, and then select
, then click “Edit” button.
AirLive CamPro HD User’s Manual 46
2.5.5 Notification page at System setup dialog
2. Main-console
Configure the Notification information for event notice.
z SMTP Setting
Key-in the SMTP server connection
information for sending event notice mail.
Server: SMTP provider IP address or DNS.
Port: Mail Server’s SMTP port.
User Name: Login SMTP server’s user
account.
Password: Login SMTP server’s password.
From: The “From” field of E-Mail.
AirLive CamPro HD User’s Manual 47
Account Authentication: Check this box for the SMTP server which need
authentication
Secure Connection (SSL): Connect to SMTP with SSL authentication.
Send Test: Click “Send test” button for send a test mail.
z Mail Content
Set the “Subject” and “Body” of event
notice mail.
2. Main-console
z Alarm Setting
Configure the attached
snapshot picture rule of
event notice mail.
Pre-Alarm: Set for how many snapshot pictures should be captured before event
is triggered.
Post-Alarm: Set for how many snapshot images should be captured after event is
triggered.
Snapshot interval: Set the interval betweens of each snapshot.
Send Interval: Set the interval betweens of each send-out notice mail.
Picture Temp Folder: Select a folder for store snapshot pictures, these pictures
will delete when system is shutdown.
AirLive CamPro HD User’s Manual 48
z FTP Config
FTP Server: Set the FTP site’s IP for system upload image when event is
triggered.
Port: The FTP server’s port.
User Name: The account to login FTP server.
2. Main-console
Password: The password for login FTP server.
Path: System will upload images to defined folder.
Allow Create Folder: If checked this field, system will create folder automatically
for new event’s upload process.
If un-checked this field, system will only upload image to
define folder.
z Send to Config
Select the mail accounts for send schedule record notification mail.
AirLive CamPro HD User’s Manual 49
2.5.6 Multi-Monitor at System setup dialog
2. Main-console
Monitor list tab-control:
Select which monitor to be configuration.
Monitor Status:
Display monitor information.
Run at Start:
Enable which functions will be run at selected monitor on system start.
Show Live Camera: Display extra live preview window on selected monitor.
EMap: Display E-Map on selected monitor.
Playback: Execute Playback on selected monitor.
Alarm-Report: Display Alarm status report on selected monitor.
Application Display:
Definition when user click application buttons on Main-console, the application will
display on which monitor.
System will auto※ -detect monitor connect status, If you can’t find-out extra-monitor,
please check monitor connect status and re-open setup page.
AirLive CamPro HD User’s Manual 50
2.5.7 Joystick at System setup dialog
2. Main-console
Display first joystick was found at system, and you could define each button’s
function with drop-down list.
Cam Pro HD support all kinds of joystick by Microsoft Direct-Input, please
confirm install joystick driver first.
Button’s function list:
1. Full-Screen:
Switch current display mode to full-screen or normal.
2. PTZ Up/Down/Left/Right/Up-Left/Up-Right/Down-Left/Down-Right/Home:
Move Pan-Tilt camera direction.
3. Switch to next division / Switch to previous division / Switch to One division:
Change sub-screen division.
4. Switch to next window / Switch to previous window:
Change focus camera window.
5. Auto Scan Start / Auto Scan Stop:
Start auto scan or stop.
AirLive CamPro HD User’s Manual 51
2. Main-console
6. Auto Focus:
Trigger focus camera auto focus function.
7. Zoom in / Zoom out:
Trigger focus camera zoom-in or zoom-out.
8. Auto IRIS:
Trigger focus camera auto-IRIS function.
9. Preset 1~16:
Change focus camera direction to preset position.
How many buttons will display on setting page is depend on joystick ※ driver, each
button can define one function in above list.
System will auto※ -detect joystick connect status, If you can’t find-out your joystick,
please check the joystick connect status and re-open setup page.
AirLive CamPro HD User’s Manual 52
2.6 Schedule setup
Click schedule setup button to approach Schedule setup dialog.
2. Main-console
AirLive CamPro HD User’s Manual 53
Schedule setup dialog:
2. Main-console
2.6.1 Schedule mode
Select the schedule mode of system.
The Daily and Weekly mode is exclusive to e
other.
Daily mode:
Set schedule time slice by day.
Weekly mode:
Set schedule time slice by weekday.
ach
AirLive CamPro HD User’s Manual 54
2. Main-console
2.6.2 Select camera of Daily mode
When you choose Daily mode or click on “Daily”
tab of camera list tree, the list tree will display all
installed cameras of system.
Click on the camera name which you want to modify. The schedule configuration
of this camera will display at left of dialog.
System defaults the schedule from 00:00 to 23:59 round the clock recording mode.
User could modify it for your own schedule.
Clone setting:
1. Select one camera and click “Copy” button to copy camera’s schedule setting.
2. Select a camera and click “Paste” button to update schedule setting with
copied data.
3. Click “Apply all” button to update all
cameras with copied setting.
※ You can click mouse right button on camera to bring up pop-up menu, and clone
settings as above.
2.6.3 Select weekday of Weekly mode
When you choose Weekly mode or click on
“Weekly” tab of camera list tree, the list tree will
display all installed cameras of system.
Click on the camera name which you want to
modify. The schedule configuration of this camera will
display at left of dialog.
System defaults the schedule from 00:00 to 23:59
round the clock recording setting. User could modify it
for your own schedule
Clone Setting (copy setting from a camera):
1. Select a camera and click “Copy” button to copy selected all weekday schedule
setting.
AirLive CamPro HD User’s Manual 55
2. Main-console
2. Click “Paste” button and select “Paste” will update selected camera all
weekday’s schedule setting.
3. Click “Paste” button and select “Paste on Monday to Friday” will update
selected camera’s Monday to Friday schedule setting as same as copied
Monday to Friday setting.
4. Click “Paste” button and select “Paste on
Saturday to Sunday” will update selected camera’s Saturday and Sunday
setting as same as copied Saturday and Sunday setting.
5. If select a weekday , and Click “Paste” button , then select “Paste to all camera
on Selected Weekday” will update all camera’s selected weekday setting as
same as copied camera weekday.
6. Click “Apply all” button to update all camera’s setting as same as copied
camera.
Clone Setting (copy setting from a weekday):
1. Select a weekday of one camera and click “Copy” button to copy selected
weekday schedule setting.
2. Select a camera and click “Paste” button, select “Paste” on pop-up menu will
update same weekday’s setting of selected camera.
3. Select a weekday of camera, click “Paste” button and select “Paste” on pop-up
menu will update selected weekday’s setting from copied data.
4. Click “Paste” button and select “Paste on Monday to Friday” will update
selected camera’s Monday to Friday schedule setting as same as copied
Weekday setting.
5. Click “Paste” button and select “Paste on Saturday to Sunday” will update
selected camera’s Saturday and Sunday setting as same as copied Weekday
setting.
6. If select a weekday , and Click “Paste” button , then select “Paste to all camera
on Selected Weekday” will update all camera’s selected weekday setting as
same as copied camera weekday.
7. Click “Apply all” button to update all camera’s all weekday settings as same as
copied Weekday.
AirLive CamPro HD User’s Manual 56
2.6.4 Select camera of special day mode
When you choose Special Day mode” or click
“Special Day” tab of camera list tree, the list tree will
display all installed cameras of system.
Click on the camera name which you want to
modify. The schedule configuration of this camera will
display at left of dialog.
System defaults the schedule from 00:00 to 23:59 round the clock recording
setting. User could modify it for your own schedule
Clone Setting:
1. Select one date or camera and click “Copy” button.
2. Main-console
2. If copy setting from a date, click “Paste” button will update all cameras of
selected target date by copied setting.
3. If copy setting from a camera of some special date , click “Paste” button with
selected a date to update the camera schedule setting.
4. Copy a camera schedule setting and paste to another camera by click “Paste”
button with selected a camera.
2.6.5 Add or remove special day
If you want to add a new special day into
system, choose a day from date-time picker
control, then click the “Add” button.
If you want to remove a special day from system, click the special day on the tree
control at right of dialog, then click the “Delete” button.
AirLive CamPro HD User’s Manual 57
2.6.6 Add schedule time slice
You can define a time slice as below:
1. Select Start time and End time from
date-time picker control:
Click on the hour section or minute section, then key in the time value, or click
the “▲” or “▼” to increase or decrease the time value.
2. Drag time slice bar from time table:
Move mouse cursor to the
2. Main-console
empty zone on time table in which
you want to add. Press and hold
mouse left button, drag cursor to
right until touch the End time
which you need, then release the left button of mouse.
After drag action, a new gray bar was show on the time table. The left end of the
time bar means this slice’s Begin time and right end means End time.
The mouse cursor must drag on empty zone, or this action will be not
successful.
After time slice define completed, system will popup the “Record Setup” dialog.
Please refer to “Record Setup Page” as below.
2.6.7 Modify schedule time slice
1. Selected the Camera’s name (daily mode) or weekday (weekly mode) from the
tree control at left of dialog.
AirLive CamPro HD User’s Manual 58
2. Main-console
2. Click on the slice in the list which you want to modify.
The other way, you can click on the slice bar on the time bar control.
3. Click on the hour section or minute section on the date-time picker control, then
key-in the time value, or click the “▲” or “▼” to increase or decrease the time
value.
Or you can move mouse cursor to edge of slice bar on time bar control, then
the cursor will become to “ ” , and drag the edge to the position where you
need.
4. After complete the time slice, click the “Edit” button to approach “Record Setup”
dialog.
2.6.8 Remove schedule time slice
1. Select the Camera’s name (daily mode) or weekday (weekly mode) from the
tree control at left of dialog.
2. Click on the time slice in the list which you want to modify.
The other way, you can click on the time slice bar on the time bar control
3. Click the “Delete” button at right of dialog.
AirLive CamPro HD User’s Manual 59
2.6.9 Record Setup Page
2. Main-console
2.6.10 Record Mode
Round the Clock:
When system time reach the schedule
begin time, system will start recording work
immediately and continually until the system
time reach the end time.
Motion detection:
When system time reach the schedule begin time and motion alarm is
triggered, system will start recording work immediately and continually until the
system time is over the post-alarm seconds.
AirLive CamPro HD User’s Manual 60
2. Main-console
DI Detection:
When system time reach the schedule begin time and DI alarm is triggered,
system will start recording work immediately and continually until the system time
is over the post-alarm seconds.
If the pre-alarm seconds is set, when motion detection has been triggered, the
recorded file will include pre-alarm seconds by setting.
2.6.11 Record Setting:
When set to Motion detection or DI detection
record mode, user can set the Pre-Alarm second(s)
which the recorded file will keep a slice of image
defined as the setting second(s) before event was
triggered.
Set the Post-Alarm second(s) which the recorded file will keep a slice of image
defined as the setting second(s) after the event was triggered.
2.6.12 Motion Configuration
Motion detect area:
Default button:
Select the full image for motion detection.
AirLive CamPro HD User’s Manual 61
Add button:
Define a rectangle area on the image first, then click “Add” button to add
a new region.
Delete button:
Define a rectangle area on the image first, then click “Delete” button to
remove the region that was defined.
Sensitivity:
Set sensitivity level of motion detection. Level 5 means the highest motion
detection sensitivity. On the contrary, level 1 is the lowest level of sensitivity.
Motion Interval:
Set this value to define the interval of motion detection. If set longer value,
means system will use less CPU computing power to check motion detection.
2. Main-console
Display Motion detection status:
Checked the check box to
display the area(s) where motion
detection is triggered.
Preview window:
Red area is the motion
detection area. The other areas are
non-motion detection region.
The yellow rectangles are
triggered regions of motion
detection areas.
2.6.13 DI Record Setting
When you set the DI record mode, select the DI input from
the combo box, and select the DI as open or close to trigger
recording.
AirLive CamPro HD User’s Manual 62
2. Main-console
2.6.14 Complete Schedule Setting
To finished configuration job of schedule setting, must click “OK” button to confirm.
If you want to abort this setting, please click “Cancel” button instead.
When you set the DI record mode, select the DI input from the combo box, and
select the DI as open or close to trigger recording.
AirLive CamPro HD User’s Manual 63
2.7 Start & Stop Monitor
Click Start & Stop Monitor button to control system monitor job.
2. Main-console
Start Monitor All:
Check it to start all type of monitor job.
Start Monitor Schedule:
Check it to start the schedule recording job.
Start Monitor Alarm:
Check it to start the Alarm monitor job.
If “Start Monitor All” is checked, system will execute all monitor jobs automatically.
Create Extra Preview:
Create an extra preview window to preview more different channel and division.
You could drag the extra preview window to another monitor.
AirLive CamPro HD User’s Manual 64
2. Main-console
2.7.1 Alarm Event Report
Alarm Event Report dialog is display all triggered and wasn’t stop or canceled
events.
Alarm time: The Event was triggered time.
Event Type: The Event trigger type.
Remark: The description of this event.
Cancel Event: Select the events and click the “Cancel Event” button to stop alarm
actions, and reset event status.
Cancel All Event: Stop all event action and reset all event status.
AirLive CamPro HD User’s Manual 65
2.8 E-Map
Click E-MAP button to approach E-MAP dialog.
2. Main-console
E-MAP dialog:
AirLive CamPro HD User’s Manual 66
2. Main-console
z Camera list
List all installed camera(s) in system by
camera index and name.
z Add camera to Map
Drag a camera name from camera list onto the Map.
If the dragging camera is exist in Map, the cursor will become to “ “, and not
allow to add this camera.
z Make camera as a focus camera
Double click on the camera icon which you want this camera be focused.
When the camera is focused, the system will be popup a window to display live
preview of this camera.
z Move camera on Map
You can move the camera position by two ways as below.
1. Press mouse left button and hold on the camera icon which you want to move,
and then drag it onto the position where you preferred.
2. Double click on the camera, make it as a focus camera, and then click “Move”
button. Move the mouse cursor to the new position and click mouse left button.
z Rotate camera on Map
You can rotate camera direction by two ways as below.
1. Press and hold the mouse right button on the camera icon, then rotate the
camera icon until you preferred.
2. Make camera as a focus camera, then click the “Rotation” button until you
preferred.
z Delete camera on Map
Make the camera as a focus camera, then click the “Delete” button.
z Change Map
Click the “Change Map” button, and then select a new picture to replace the
old one.
AirLive CamPro HD User’s Manual 67
2.9 Two Way Audio
Click Two Way Audio button to switch Two-way Audio status.
2. Main-console
When Two-way audio is on, system will transmit local microphone’s voice to
remote camera.
Start Two Way Audio.
Stop Two Way Audio.
Two-Way Audio function depends on camera’s capability. This button is only
enabled when the focused camera is with two-way audio capability.
If the channel’s two way audio was enabled by remote service , system will
reject enable this channel’s two way audio job until remote’s two way audio job
stop.
AirLive CamPro HD User’s Manual 68
2.10 PTZ control
2. Main-console
If the focused camera is with PTZ capability, the panel will show PTZ control
button(s). A PTZ camera will enable all control buttons but a PT camera will enable PT
control buttons only.
z Speed control
Move the slider’s thumb to right to make faster speed and move the thumb to left to
make slower speed. Speed value works with direction control, zoom, and auto pan.
z Direction control
Up button: Move camera up.
Down button: Move camera down.
Left button: Move camera to left.
Right button: Move camera to right.
Left-up button: Move camera to left-up.
AirLive CamPro HD User’s Manual 69
Right-up button: Move camera to right-up.
Left-down button: Move camera to left-down.
Right-down button: Move camera to right-down.
If you need to continue direction action, please press and hold the direction
button down until the camera move to your target position.
Home button: Return camera direction to default position.
z Tour control
Select a Tour setting from combo box first, and then
2. Main-console
click the “GO” button to start this tour.
Click “Stop” button to stop this tour job.
z Preset control
Select a preset from combo box, the focus camera
will move to preset position immediately.
z Auto pan control
Click “Auto Pan” button to start auto pan job
(navigation).
Click “Stop” button to stop auto pan job.
z Zoom control
Click the zoom-in button to force camera lens
zoom-in.
Click the zoom-out button to force camera lens zoom-out.
z Focus control
Click “Focus Auto” to force camera auto adjust
focus status.
Click plus button to increase camera focus position.
Click minus button to decrease camera focus position.
AirLive CamPro HD User’s Manual 70
z IRIS control
Click “IRIS Auto” to force camera auto adjust IRIS
status.
Click plus button to increase camera IRIS level.
Click minus button to decrease camera IRIS level.
2. Main-console
AirLive CamPro HD User’s Manual 71
2.11 Alarm Setting
Click system Setup button and select “Alarm Setup” to approach Alarm setup
dialog.
2. Main-console
AirLive CamPro HD User’s Manual 72
z Event Setting / Add Event
2. Main-console
1. Select the camera which you want to add event.
2. Click “Add” button to approach Alarm Event Selection dialog.
AirLive CamPro HD User’s Manual 73
2. Main-console
3. Select the Event that you want to add, then click OK button, or double-click on
the Event to add it.
4. The selected Event will add into the specified camera.
z Event Setting / Edit Event
1. Select the Event which you want to modify.
2. Click the “Edit” button or double-click the Event which was selected.
3. Configure the event setting, then click OK button to save setting, or click
cancel button to cancel edit job.
Please refer the sections below to check detail information of event setting.
AirLive CamPro HD User’s Manual 74
− Event Setting/ Edit Event / Basic Setting
2. Main-console
Auto Stop Type:
1. Alarm Stop by Manual:
Once event was triggered, it would keep alarm until user cancels it from
Event Report dialog.
2. Alarm Stop after Second:
Once event was triggered, it would automatically stop alarm after setting
seconds.
Event Detect Period:
1. Always Detect::
When Alarm Monitor is activated, the detection job will always execute.
2. Detect by Schedule:
The detection job will execute when Alarm Monitor is activated and match
the schedule setting.
Remark: The System accepts maximum 10 detection schedule settings.
AirLive CamPro HD User’s Manual 75
− Event Setting/ Edit Event / Advance Setting/ Motion
1. Define motion detection area:
Click “Default” button to select
all image for motion detection.
Select “Add” and use mouse to
specify a rectangle window to add a
detection area.
Select “Delete” and use mouse
to specify a rectangle window to
remove a detection area.
The area covered by
transparent red color is motion
detection area.
2. Main-console
2. Set motion detection sensitivity:
Set the motion detection
sensitivity level between 1 and 5.
Level 5 means the highest motion
detection sensitivity.
3. Set detection interval:
Set this value to define the
interval of motion detection. If set longer value, means system will use less CPU
computing power to check motion detection.
4. Adjust parameter by detection result:
When motion detection event is triggered, system will display “M” at left-up
corner and you can adjust these two parameters by checking detection result to
get best settings.
− Event Setting/ Edit Event / Advance Setting/ Digital Input
In this mode, system will
check status of Digital Input
periodically. Select “Open”
or “Close” to define which
status will trigger an event.
AirLive CamPro HD User’s Manual 76
− Event Setting/ Edit Event / Advance Setting/ Block Detect
Block detection could
detec
t camera is blocked
2. Main-console
by something, detect area
is set to full image.
Set Sensitivity with
higher level to trigger block
alarm easier, otherwise set lower level to prevent false alarm.
− Event Setting/ Edit Event / Advance Setting/ Blur Detect
Blur detection could
detec
t image lost focus
(blur), detect area is set to
full image.
Set Sensitivity with
higher level to trigger blur
alarm easier, otherwise set
l
ower level to prevent false alarm.
−
Event Setting/ Edit Event / Advance Setting/ Camera Move Detect
Camera move
detection could detect
camera direction is moved,
detect area is set to full
image.
Set Sensitivity with
higher level to trigger cam
era
move alarm easier, otherwise set lower level to
prevent false alarm.
z Event Setting / Delete Event
Select an event which you wan
delet
e this event.
z Event Setting / Add Action
Select an event which you wa
approach Action selection dialog as below.
t to delete, and then click “Delete” button to
nt to add actions, and then click “Add” button to
AirLive CamPro HD User’s Manual 77
2. Main-console
Select an action which you want to add and click OK button, or double-click
the action to add it. You could repeat this procedure to add more actions for the
same camera.
z Event Setting / Edit Action
Select an action from the Action
list then click “Edit” button or
double-click on the action to enter
action setting dialog.
− Event Setting/ Edit Action / Display on image
Select the channels which you want to display
alarm message when event is triggered.
The default selected channel is the event detection
channel.
AirLive CamPro HD User’s Manual 78
− Event Setting/ Edit Action
/ Send Mail
Select the mail accounts
which you want to send a
notice mail when event is
triggered.
2. Main-console
Mail account list is s
etting
by system / address book
page.
− Event Setting/ Edit Action / Play Alarm sound
Select a Wav file to play once event was triggered.
− Event Setting/ Edit Action / Trigger Digital
Output
Select a digital output which you want to take
an action once event was triggered.
Select “Close” or “Open” status of digital
output action.
AirLive CamPro HD User’s Manual 79
− Event Setting/ Edit Action / Upload to FTP
When event is triggered, system will upload images by setting in system setup
page.
z Event Setting / Delete Action
Select an action which you want to delete, and then click the “Delete” button
to remove this action.
z Event Setting / Clone Event setting
Select an event and click “Copy” button or pop-up menu, then select the
2. Main-console
camera you need clone to, click “Paste” button to paste on target.
You can apply copied setting to all cameras by click “Apply all” button.
AirLive CamPro HD User’s Manual 80
2.12 Server Setup
Click system Setup button and select “Server Setup” to approach server setup
dialog.
2. Main-console
z Autorun Server
Once the “Autorun Server” was
checked, the remote service will start
automatically while Cam Pro HD is
running.
z Start Server
Click “Start” button to start the
remote service which the HTTP and
RTSP service will start working.
AirLive CamPro HD User’s Manual 81
z Stop Server
Click “Stop” button to stop the remote service which the HTTP and RTSP
service will stop working.
z HTTP Port
In case you need to change HTTP port, please stop remote service first and
then key-in new port value.
The default HTTP port is 80.
z RTSP Port
If you need to change RTSP port, please stop remote service first and then
key-in new port value.
The default RTSP port is 554.
2. Main-console
z Remote Playback Port
If you need to change Remote playback port, please stop remote service first
and then key-in new port value.
AirLive CamPro HD User’s Manual 82
2. Main-console
2.13 Log Viewer
Click system setup button and select “Log Viewer” to approach Log Viewer dialog.
Log Viewer dialog:
System Log page:
1. Select Log Type
2. Select Log time period.
3. Click Search to list Logs.
4. Click Export to export search result to
TXT file.
AirLive CamPro HD User’s Manual 83
2. Main-console
Event Log page:
1. Select event triggered by which device,
or list all
2. Select event type or list all.
3. Select event triggered by which input
source (Digital Input Event)
4. Specify search time period.
5. Click Search button to list event logs.
6. Click Export button to export search
result to TXT file.
7. Double click on the event log record, system will bring up a playback window,
and playback 10 second record video (pre-alarm 5 second, post-alarm 5
second).
Playback job must be waiting for record file closed.
Error Log page:
1. Select Log Type
2. Specify Log time period.
3. Click Search to list Logs.
4. Click Export to export search result to
TXT file.
AirLive CamPro HD User’s Manual 84
2.14 Import / Export Setting
2. Main-console
Import Setting: Select a history export setting file by open file dialog, and then click
“OK”, system will restore setting by selected file.
Export Setting: Select a file from save file dialog, then click “OK”, system will create a
setting file to destination folder.
AirLive CamPro HD User’s Manual 85
3. Playback
3. Playback
3
Playback is to search, playback, backup, and converts file format on history
recorded file(s).
User could find out the critical image in minutes by playback tools, and backup
these images to user assigned storage by selected period and length.
Click Exit button to leave playback application.
AirLive CamPro HD User’s Manual 86
3.1 Search history recorded file(s)
Click the Search button on Playback page.
3. Playback
z Search history file(s) dialog
Select the time period and camera(s) within the search dialog.
AirLive CamPro HD User’s Manual 87
z Select a day to search history file(s)
Click , buttons to select the month
which you want to search history file(s).
Click on the date to choose a day to search.
z Select record mode(s) / Event Type
Check the modes which you want to
search. System will search recorded files
within these modes only.
Check Event types which you want to
3. Playback
display, system will display event triggered
time on list.
You could define display color for each
record modes and events by color select
dialog.
Click button to approach color select dialog.
z Start search
Click the “Search” button to start search procedure. Please wait a moment for
the search result which will appear on the list control.
z Review history record file(s) in search period
The list control will
display the result of
search procedure.
Blue section: Round the clock recorded file(s).
Green section: Motion detection recorded file(s).
Red section: Alarm recorded file(s).
AirLive CamPro HD User’s Manual 88
z Assign time period of search result
1. You can drag mouse cursor on the list control to assign a time period to
playback.
2. Choose a time period by the begin time and end time picker control manually.
3. The selected time period will display as blue
section on the list control.
z Select the camera(s) to playback
Select the camera(s) which you want to playback.
The system can select maximum 16 camera(s) to playback at once.
3. Playback
z Start playback history file(s)
Click the “OK” button to finish search procedure and start playback, or click
“Cancel” button to abort this job and return to Playback main page.
AirLive CamPro HD User’s Manual 89
3. Playback
3.2 Playback control button(s)
These buttons are used to control playback start, pause, backward play and the
other operations. User can control playback functions by these buttons.
z Play button
Click play button to play the selected history file(s).
z Pause button
Click pause button to pause playback stream. Some operations must
entry pause mode first.
z Backward play button
Click backward play button to playback stream direction to backward
mode.
z Stop button
Click stop button to stop playback stream and return to the beginning
position of stream.
z Next frame button
When playback is in the pause mode, click the next frame button to
seek next frame.
z Previous frame button
When playback is in the pause mode, click the previous frame button
to seek previous frame.
AirLive CamPro HD User’s Manual 90
z Playback speed control
Turn the speed button to select playback speed.
1X: Normal speed.
2X: Double of normal speed
4X: 4X normal speed.
8X: 8X normal speed.
16X: 16X normal speed.
32X: 32X normal speed.
1/2X: Half of normal speed.
1/4X: Quarter of normal speed.
3. Playback
z Division control buttons
Divide to 1 screen. Divide to 4 screen(s).
Divide to 6 screen(s). Divide to 9 screen(s).
Divide to 16 Screen(s) Full screen mode.
AirLive CamPro HD User’s Manual 91
3.3 Convert to AVI file
Click Convert file button to approach Covert file dialog.
3. Playback
z Convert file dialog
Select time slice and camera to convert to AVI file by the convert file dialog.
The AVI file can play on most PC with current codec installed.
AirLive CamPro HD User’s Manual 92
z Select a day to covert history file(s)
Click , buttons to select the month
that wanted to convert history file(s).
Click on the date to choose a day to convert file(s).
z Assign time slice to convert job
Choose a time slice by the Start time and End
time picker control, or drag mouse cursor on record list
to define convert period.
z Select cameras to convert job
Checked camera’s IDs from list to convert job.
z Select a folder to save converted file
3. Playback
Click the brows button to select a folder which will save the converted file.
z Start converting job
Click the OK button to start convert job. When convert job finished, system
will p generate a file into assigned folder.
Click Cancel button to abort convert job.
The name rule of converted file is as below:
CHXXXYYYYMMDDHHmmssnnn.avi
XXX: camera ID.
YYYY: Execute convert year.
MM: Execute convert month.
DD: Execute convert day.
HH: Execute convert hour.
mm: Execute convert minute.
ss: Execute convert second.
nnn: Execute convert million-second.
Ex:
CH00220090914140253150.avi
AirLive CamPro HD User’s Manual 93
3.4 Switch audio play mode
Click Audio mode button to popup the menu of audio mode.
Select the audio mode from the popup menu. The
checked item means the current mode of audio playback
now.
Mute: No audio data will play.
Live: Play the live audio stream.
Playback: Play the playback audio stream.
3. Playback
3.5 Playback setting
Click the Setting button to popup the menu of playback
setting.
Check the item(s) to change OSD status on the image while the recorded file is
playing back.
Display Date: Display the date of recorded file on the image.
Display Time: Display the time of recorded file on the image.
Display camera name: Display the camera name on the image.
AirLive CamPro HD User’s Manual 94
3. Playback
3.6 Snapshot dialog
Click the snapshot button to approach snapshot dialog. This function is used to
take a snapshot of the playing history file.
z Snapshot all dialog
The snapshot all dialog will display all snapshot images on the dialog. You
can choose which image will be saved and assign the file format and folder.
z Select snapshot image
The dialog displays all
snapshot images with the
camera ID, resolution, and
camera name.
Check the check box if you
want to save this image.
AirLive CamPro HD User’s Manual 95
Loading...
