AirLive BT-302USB User Manual

Bluetooth 3.0 Mini USB Dong

User’s Manual

-302USB

Table of Contents

BT-302USB User’s Manual

No part of this publication may be reproduced in any form or by any means, whether electronic, mechanical, photocopying, or recording without the written consent of OvisLink Corp.

OvisLink Corp. has made the best effort to ensure the accuracy of the info rmation in this user’s guide. However, we are not liable for the inaccuracies or errors in this guide. Please use with caution. All information is subject to change without notice

All Trademarks are p rop erties of their respective holders.

BT-302USB User’s Manual 2

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable prote ction against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver.

3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio technician for help.

FCC Caution

This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance could void the authority to operate equipment.

3 BT-302USB User’s Manual

Federal Communication Commission (FCC) Radiation Exposure Statement

This EUT is compliance with SAR for general population/uncontrolled exposure limits in ANSI/IEEE C95.1-1999 and had been tested in accordance with the measurem ent methods and procedures specified in OET Bulletin 65 Supplement C.

R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE) The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications T ermin al Equipment and Satellite Earth St ation Equipment) As of April 8, 2000.

Safety

This equipment is designed with the utmost care for the safety of those who install and use it. However, spe cial attention must be paid to the dangers of electric shock and static electricity when working with electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all times to ensure the safe use of the equipment.

EU Countries Intended for Use

The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, the Netherlands, Portugal, Spain, Sweden, and the United Kingdom.

The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland.

EU Countries Not intended for use

None.

The specification is subject to change without notice.

BT-302USB User’s Manual 4

Table of Contents

1. Introduction ........................................................................................................1

1.1. System Requirements........................................................................... 2

1.2. Package Contents................................................................................. 2

1.3. Hardware Installation ............................................................................ 3

2. Software Installation...........................................................................................4

2.1. Configuration Utility............................................................................. 14

2.2. Bluetooth Configuration - General....................................................... 19

2.3. Bluetooth Configuration - Accessibility................................................ 20

2.4. Bluetooth Configuration – PIM Interface ............................................. 22

2.5. Bluetooth Configuration - Share.......................................................... 24

2.6. Bluetooth Configuration – Communications Port................................. 26

2.7. Bluetooth Configuration – Networking................................................. 27

2.8. Bluetooth Configuration - Diagnostics................................................. 28

3. Specifications...................................................................................................29

4. Wireless Netw ork Glossary .............................................................................30

BT-302USB User’s Manual

1. Introduction

Thank you for purchasing the AirLive BT-302USB Bluetooth 3.0 Mini USB Dongle. This ultra-compact USB adapter supports the latest Bluetooth 3.0 standard and lets you connect your desktop computer or notebook computer to mobile phone, PDA, notebooks, printers or headsets. This handy and mini adapter allows you to create your Personal Area Network (PAN) instantly. You will soon be able to enjoy these additional features by following the instruction in this manual.

y Extremely compact design Bluetooth 3.0 USB adapter y Universal Bluetooth connectivity for your computer y Effectively power saving, ultra low power consumption y Backward compatible with Bluetooth v1.2/2.0/2.1 y Supports A2DP stereo streaming, up to 3Mbps link speed

1 BT-302USB User’s Manual

1.1. System Requirements

y USB 2.0 port & CD-ROM drive y Windows XP/Vista/7 or Mac OS X 10.5/10.6 y At least 30MB of available disk space

Note: this device may not be able to work with USB 1.1 port

1. Introduction

1.2. Package Contents

Before installing the adapter , please check if there’ s anything missing in the package, and contact your dealer of purchase to claim for missing items:

y BT-302USB y Software CD

BT-302USB User’s Manual 2

1.3. Hardware Installation

y USB Connector y Link/Activity LED (Blue)

1. Introduction

LED Mode Status

Link/ Activity

Steady ON Connect to a USB port with power Flash Transferring data

Off Adapter un-plugged

With the computer switched on, insert the BT-302USB adapter into an empty USB

2.0 port.

Caution: Never use force to insert the adapter

3 BT-302USB User’s Manual

2. Software Installation

BEFORE INSTALLATION

Please remove any previous version of Widcomm Bluetooth software existing in your system. The remove procedures are as follows:

1. Click Start/Settings, and then select Control Panel

2. In the Control Panel window, double click Add/Remove programs icon

3. Find out the item Widcomm Bluetooth Software x.x.x.x then remove it

INSTALL WIDCOMM BLUETOOH SOFTWARE

Note: The following instruction were based on Windows XP, please follow the on-screen instruction if you have different operating system.

BT-302USB User’s Manual 4

2. Software Installation

Insert the enclosed software CD in the CDROM drive and click “Install Driver & Utility” from the autorun screen. If the autorun screen did not appear, run the

“Setup.exe” program in the “Driver” folder.

1. The system will detect and install the Microsoft Net Framework automatically.

5 BT-302USB User’s Manual
