Beautifully incorporating access control and security
Styluscom
sales@aesglobalonline.com Tel: +44(0)288 639 0 693

Beautifully incorporating access control and security
Styluscom
sales@aesglobalonline.com Tel: +44(0)288 639 0 693

Motion detection recording* (from one device)
sales@aesglobalonline.com Tel: +44(0)288 639 0 693
Styluscom
Beautifully incorporating access control and security
Combine up to 2 CCTV cameras for home/entrance security
Industry leading 300m super long range over CAT5 cable
SD card inside
Voicemail feature for missed callers

sales@aesglobalonline.com Tel: +44(0)288 639 0 693
Styluscom
Beautifully incorporating access control and security
Gate 1
Gate 2
Cam1
Cam2
Master
Slave
Slave
Monitor mounting Flush or Surface
Recording 8Gb Micro SD card included, 32Gb Max
Capacity Over 50 x 10 second clips (200 on 32Gb card)
Recording type Motion detection video algorithm
Recording channels 1 (can choose to record from door, or camera)
Recording options 10-60 second video, or still image
Recording resolution 720 x 288 pixels
Screen size 4.3 inch
Scree resolution 480 x 272
Camera type Colour CCD analogue
Night vision Yes, with IR illumination (2m range)
Lens 110 degree viewing angle
Resolution 800 TVL
Relays per door station 2
Door stations per system 2
Monitors per system 4
Keypad Optional, with 3 relays & 1200 codes
Door station construction Marine grade stainless steel & gloss black acrylic trim
Door station mounting Surface, flush, and pedestal options available
IP rating 55, suitable for exposed locations
Backlighting Illuminated keypad, button and back lighting
MICRO SD
Slave
CAT5 distance (2 power supplies) 300m / yards
Poly Poly cable (2 power supplies) Up to 150m / yards aprox
CAT5 distance (1 power supply) Up to 50m / yards
Poly Poly cable (1 power supply) Up to 50m / yards
