IPE6450KF
EN User Manual | Hob
Welcome to Electrolux! Thank you for choosing our appliance.
Get usage advice, brochures, trouble shooter, service and repair information:
www.electrolux.com/support
Subject to change without notice.
CONTENTS
1. SAFETY INFORMATION................................................................................ 2
2. SAFETY INSTRUCTIONS.............................................................................. 4
3. INSTALLATION...............................................................................................6
4. PRODUCT DESCRIPTION............................................................................. 7
5. DAILY USE......................................................................................................9
6. HINTS AND TIPS.......................................................................................... 13
7. CARE AND CLEANING................................................................................ 15
8. TROUBLESHOOTING.................................................................................. 15
9. TECHNICAL DATA....................................................................................... 17
10. ENERGY EFFICIENCY...............................................................................18
11. ENVIRONMENTAL CONCERNS................................................................18
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible
for any injuries or damage that are the result of incorrect
installation or usage. Always keep the instructions in a safe
and accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved. Children of less than 8 years of age and
persons with very extensive and complex disabilities shall
be kept away from the appliance unless continuously
supervised.
• Children should be supervised to ensure that they do not
play with the appliance.
2 ENGLISH
• Keep all packaging away from children and dispose of it
appropriately.
• WARNING: The appliance and its accessible parts become
hot during use. Keep children and pets away from the
appliance when in use and when cooling down.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
1.2 General Safety
• This appliance is for cooking purposes only.
• This appliance is designed for single household domestic
use in an indoor environment.
• This appliance may be used in, offices, hotel guest rooms,
bed & breakfast guest rooms, farm guest houses and other
similar accommodation where such use does not exceed
(average) domestic usage levels.
• WARNING: The appliance and its accessible parts become
hot during use. Care should be taken to avoid touching
heating elements.
• WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire.
• Smoke is an indication of overheating. Never use water to
extinguish the cooking fire. Switch off the appliance and
cover flames with e.g. a fire blanket or lid.
• WARNING: The appliance must not be supplied through an
external switching device, such as a timer, or connected to
a circuit that is regularly switched on and off by a utility.
• CAUTION: The cooking process has to be supervised. A
short term cooking process has to be supervised
continuously.
• WARNING: Danger of fire: Do not store items on the
cooking surfaces.
ENGLISH 3
• Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can get
hot.
• Do not use the appliance before installing it in the built-in
structure.
• Do not use a steam cleaner to clean the appliance.
• After use, switch off the hob element by its control and do
not rely on the pan detector.
• If the glass ceramic surface / glass surface is cracked,
switch off the appliance and unplug it from the mains. In
case the appliance is connected to the mains directly using
junction box, remove the fuse to disconnect the appliance
from power supply. In either case contact the Authorised
Service Centre.
• If the supply cord is damaged, it must be replaced by the
manufacturer, an authorized Service or similarly qualified
persons in order to avoid a hazard.
• WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as
suitable or hob guards incorporated in the appliance. The
use of inappropriate guards can cause accidents.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must install this
appliance.
WARNING!
Risk of injury or damage to the appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions supplied
with the appliance.
• Keep the minimum distance from other
appliances and units.
4 ENGLISH
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Seal the cut surfaces of the cabinet with a
sealant to prevent moisture from causing
swelling.
• Protect the bottom of the appliance from
steam and moisture.
• Do not install the appliance next to a door
or under a window. This prevents hot
cookware from falling from the appliance
when the door or the window is opened.
• Each appliance has cooling fans on the
bottom.
• If the appliance is installed above a
drawer:
– Do not store any small pieces or
sheets of paper that could be pulled in,
as they can damage the cooling fans
or impair the cooling system.
– Keep a distance of minimum 2 cm
between the bottom of the appliance
and parts stored in the drawer.
• Remove any separator panels installed in
the cabinet below the appliance.
2.2 Electrical Connection
WARNING!
Risk of fire and electric shock.
• All electrical connections should be made
by a qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Make sure the appliance is installed
correctly. Loose and incorrect electricity
mains cable or plug (if applicable) can
make the terminal become too hot.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable
tangle.
• Make sure that a shock protection is
installed.
• Use the strain relief clamp on the cable.
• Make sure the mains cable or plug (if
applicable) does not touch the hot
appliance or hot cookware, when you
connect the appliance to a socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug (if applicable) or to the mains
cable. Contact our Authorised Service
Centre or an electrician to change a
damaged mains cable.
• The shock protection of live and insulated
parts must be fastened in such a way that
it cannot be removed without tools.
• Connect the mains plug to the mains
socket only at the end of the installation.
Make sure that there is access to the
mains plug after the installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
2.3 Use
WARNING!
Risk of injury, burns and electric shock.
• Do not change the specification of this
appliance.
• Remove all the packaging, labelling and
protective film (if applicable) before first
use.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay unattended
during operation.
• Set the cooking zone to “off” after each
use.
• Do not put cutlery or saucepan lids on the
cooking zones. They can become hot.
• Do not operate the appliance with wet
hands or when it has contact with water.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is cracked,
disconnect immediately the appliance from
the power supply. This to prevent an
electrical shock.
• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the
appliance is in operation.
• When you place food into hot oil, it may
splash.
• Do not use aluminum foil or other
materials between the cooking surface
and the cookware, unless otherwise
specified by the manufacturer of this
appliance.
• Use only accessories recommended for
this appliance by the manufacturer.
ENGLISH 5
WARNING!
Risk of fire and explosion.
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases can
cause spontaneous combustion.
• Used oil, that can contain food remnants,
can cause fire at a lower temperature than
oil used for the first time.
• Do not put flammable products or items
that are wet with flammable products in,
near or on the appliance.
WARNING!
Risk of damage to the appliance.
• Do not keep hot cookware on the control
panel.
• Do not put a hot pan cover on the glass
surface of the hob.
• Do not let cookware boil dry.
• Be careful not to let objects or cookware
fall on the appliance. The surface can be
damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Cookware made of cast iron or with a
damaged bottom can cause scratches on
the glass / glass ceramic. Always lift these
objects up when you have to move them
on the cooking surface.
2.4 Care and cleaning
• Clean the appliance regularly to prevent
the deterioration of the surface material.
• Switch off the appliance and let it cool
down before cleaning.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Use only neutral detergents. Do not
use abrasive products, abrasive cleaning
pads, solvents or metal objects, unless
otherwise specified.
2.5 Service
• To repair the appliance contact the
Authorised Service Centre. Use original
spare parts only.
• Concerning the lamp(s) inside this product
and spare part lamps sold separately:
These lamps are intended to withstand
extreme physical conditions in household
appliances, such as temperature,
vibration, humidity, or are intended to
signal information about the operational
status of the appliance. They are not
intended to be used in other applications
and are not suitable for household room
illumination.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your local authority for information
on how to dispose of the appliance.
• Disconnect the appliance from the mains
supply.
• Cut off the mains electrical cable close to
the appliance and dispose of it.
3. INSTALLATION
WARNING!
Refer to Safety chapters.
3.1 Before the installation
Before you install the hob, write down the
information below from the rating plate. The
rating plate is on the bottom of the hob.
Serial number ...........................
6 ENGLISH
3.2 Built-in hobs
Only use the built-in hobs after you assemble
the hob into correct built-in units and work
surfaces that align to the standards.
3.3 Connection cable
• The hob is supplied with a connection
cable.
• To replace the damaged mains cable, use
min.
50mm
min.
500mm
min. 12min.
60
min.
28
www.youtube.com/electrolux
www.youtube.com/aeg
How to install your Electrolux
Induction Hob - Worktop installation
1 1
2
1
1
the cable type: H05V2V2-F which
withstands a temperature of 90 °C or
higher. Speak to your local Service
Centre.
3.4 Assembly
If you install the hob under a hood, please
see the installation instructions of the hood
for the minimum distance between the
appliances.
If the appliance is installed above a drawer,
the hob ventilation can warm up the items
stored in the drawer during the cooking
process.
4. PRODUCT DESCRIPTION
4.1 Cooking surface layout
Induction cooking zone
1
Control panel
2
ENGLISH 7
4.2 Control panel layout
6 742 3
8
1
11 910
5
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which
functions operate.
Sensor
field
1
2
3
- Heat setting display To show the heat setting.
4
- Timer indicators of cooking zones To show for which zone you set the time.
5
- Timer display To show the time in minutes.
6
7
8
9
/
10
- Control bar To set a heat setting.
11
4.3 Heat setting displays
Display Description
-
Function Comment
ON / OFF To activate and deactivate the hob.
Lock / Child Safety Device To lock / unlock the control panel.
Pause To activate and deactivate the function.
Hob²Hood To activate and deactivate the manual mode of the
- To select the cooking zone.
- To increase or decrease the time.
PowerBoost To activate the function.
The cooking zone is deactivated.
The cooking zone operates.
Pause operates.
Automatic Heat Up operates.
function.
8 ENGLISH
Display Description
PowerBoost operates.
+ digit
/ /
There is a malfunction.
OptiHeat Control (3 step Residual heat indicator): continue cooking / keep warm / resid‐
ual heat.
Lock / Child Safety Device operates.
Incorrect or too small cookware or no cookware on the cooking zone.
Automatic Switch Off operates.
4.4 OptiHeat Control (3 step Residual heat indicator)
WARNING!
/ / There is a risk of burns from
residual heat.
The indicators show the level of the residual
heat for the cooking zones you are currently
5. DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Activating and deactivating
Touch for 1 second to activate or
deactivate the hob.
5.2 Automatic Switch Off
The function deactivates the hob
automatically if:
• all cooking zones are deactivated,
• you do not set the heat setting after you
activate the hob,
• you spill something or put something on
the control panel for more than 10
seconds (a pan, a cloth, etc.). An acoustic
signal sounds and the hob deactivates.
Remove the object or clean the control
panel.
using. The indicators may also come on for
the neighbouring cooking zones even if you
are not using them.
The induction cooking zones produce the
heat necessary for the cooking process
directly in the bottom of the cookware. The
glass ceramic is heated by the heat of the
cookware.
• the hob gets too hot (e.g. when a
saucepan boils dry). Let the cooking zone
cool down before you use the hob again.
• you use incorrect cookware. The symbol
comes on and the cooking zone
deactivates automatically after 2 minutes.
• you do not deactivate a cooking zone or
change the heat setting. After some time
comes on and the hob deactivates.
The relation between the heat setting and
the time after which the hob deactivates:
Heat setting The hob deactivates
, 1 - 3
4 - 7 5 hours
8 - 9 4 hours
10 - 14 1.5 hour
after
6 hours
ENGLISH 9
5.3 The heat setting
To set or change the heat setting:
Touch the control bar at the correct heat
setting or move your finger along the control
bar until you reach the correct heat setting.
5.4 Using the cooking zones
Place the cookware in the centre of the
selected zone. Induction cooking zones adapt
to the dimension of the bottom of the
cookware automatically.
To deactivate the function: change the heat
setting.
5.7 Timer
• Count Down Timer
You can use this function to set the length of
a single cooking session.
First set the heat setting for the cooking zone,
then set the function.
To set the cooking zone: touch
repeatedly until the indicator of a cooking
zone appears.
To activate the function: touch of the
timer to set the time (00 - 99 minutes). When
the indicator of the cooking zone starts to
flash, the time counts down.
5.5 Automatic Heat Up
Activate this function to get a desired heat
setting in a shorter time. When it is on, the
zone operates on the highest setting in the
beginning and then continues to cook at the
desired heating setting.
To activate the function the cooking zone
must be cold.
To activate the function for a cooking
zone: touch ( comes on). Immediately
touch a desired heat setting. After 3 seconds
comes on.
To deactivate the function: change the heat
setting.
5.6 PowerBoost
This function makes more power available to
the induction cooking zones. The function can
be activated for the induction cooking zone
only for a limited period of time. After this time
the induction cooking zone automatically sets
back to the highest heat setting.
Refer to “Technical data” chapter.
To activate the function for a cooking
zone: touch . comes on.
To see the remaining time: touch to set
the cooking zone. The indicator of the
cooking zone starts to flash. The display
shows the remaining time.
To change the time: touch
cooking zone. Touch or .
To deactivate the function: touch to set
the cooking zone and then touch
remaining time counts down to 00. The
indicator of the cooking zone disappears.
When the countdown ends, an acoustic
signal sounds and 00 flashes. The
cooking zone deactivates.
To stop the sound: touch .
• CountUp Timer
You can use this function to monitor how long
the cooking zone operates.
To set the cooking zone: touch
repeatedly until the indicator of a cooking
zone appears.
To activate the function: touch of the
timer. appears. When the indicator of the
cooking zone starts to flash, the time counts
up. The display switches between
counted time (in minutes).
to set the
. The
and the
10 ENGLISH
To see how long the cooking zone
operates: touch to set the cooking zone.
The indicator of the cooking zone starts to
flash. The display shows how long the zone
operates.
To deactivate the function: touch and
then touch
cooking zone disappears.
• Minute Minder
You can use this function when the hob is
activated and the cooking zones do not
operate. The heat setting display shows .
To activate the function: touch and then
touch
When the time finishes, an acoustic signal
sounds and 00 flashes.
To stop the sound: touch .
The function has no effect on the
operation of the cooking zones.
or . The indicator of the
or of the timer to set the time.
5.8 Pause
This function sets all cooking zones that
operate to the lowest heat setting.
When the function operates, all other symbols
on the control panels are locked.
The function does not stop the timer
functions.
Touch
1.
To deactivate the function, touch . The
previous heat setting comes on.
to activate the function.
comes on. The heat setting is lowered to
5.9 Lock
You can lock the control panel while cooking
zones operate. It prevents an accidental
change of the heat setting.
Set the heat setting first.
To activate the function: touch .
comes on for 4 seconds. The Timer stays on.
To deactivate the function: touch . The
previous heat setting comes on.
When you deactivate the hob, you also
deactivate this function.
5.10 Child Safety Device
This function prevents an accidental
operation of the hob.
To activate the function: activate the hob
with . Do not set any heat setting. Touch
for 4 seconds. comes on. Deactivate
the hob with .
To deactivate the function: activate the hob
. Do not set any heat setting. Touch
with
for 4 seconds. comes on. Deactivate
the hob with .
To override the function for only one
cooking time: activate the hob with .
comes on. Touch for 4 seconds. Set the
heat setting in 10 seconds. You can
operate the hob. When you deactivate the
hob with the function operates again.
5.11 OffSound Control (Deactivating
and activating the sounds)
Deactivate the hob. Touch for 3 seconds.
The display comes on and goes out. Touch
for 3 seconds. or comes on. Touch
of the timer to choose one of the following:
• - the sounds are off
- the sounds are on
•
To confirm your selection wait until the hob
deactivates automatically.
When the function is set to you can hear
the sounds only when:
• you touch
• Minute Minder comes down
• Count Down Timer comes down
• you put something on the control panel.
ENGLISH 11
5.12 Power management
• Cooking zones are grouped according to
the location and number of the phases in
the hob. See the illustration.
• Each phase has a maximum electricity
loading of 3700 W.
• The function divides the power between
cooking zones connected to the same
phase.
• The function activates when the total
electricity loading of the cooking zones
connected to a single phase exceeds
3700 W.
• The function decreases the power to the
other cooking zones connected to the
same phase.
• The heat setting display of the reduced
zones alternates between the chosen heat
setting and the reduced heat setting. After
some time the heat setting display of the
reduced zones stays on the reduced heat
setting.
5.13 Hob²Hood
It is an advanced automatic function which
connects the hob to a special hood. Both the
hob and the hood have an infrared signal
communicator. Speed of the fan is defined
automatically on basis of mode setting and
temperature of the hottest cookware on the
hob. You can also operate the fan from the
hob manually.
For most of the hoods the remote system
is originally deactivated. Activate it before
you use the function. For more
information refer to hood user manual.
Operating the function automatically
To operate the function automatically set the
automatic mode to H1 – H6. The hob is
originally set to H5. The hood reacts
whenever you operate the hob. The hob
recognizes temperature of the cookware
automatically and adjusts the speed of the
fan.
Automatic modes
Automat‐
Mode H0 Off Off Off
Mode H1 On Off Off
Mode H2
Mode H3 On Off Fan speed
Mode H4 On Fan speed1Fan speed
Mode H5 On Fan speed1Fan speed
Mode H6 On Fan speed2Fan speed
1)
The hob detects the boiling process and activates
fan speed in accordance with automatic mode.
2)
The hob detects the frying process and activates fan
speed in accordance with automatic mode.
3)
This mode activates the fan and the light and does
not rely on the temperature.
ic light
On Fan speed1Fan speed
3)
Boiling1)Frying
2)
1
1
1
2
3
Changing the automatic mode
1. Deactivate the appliance.
2. Touch
for 3 seconds. The display
comes on and goes off.
3. Touch for 3 seconds.
4. Touch a few times until comes on.
5. Touch of the Timer to select an
automatic mode.
To operate the hood directly on the hood
panel deactivate the automatic mode of
the function.
12 ENGLISH
When you finish cooking and deactivate
the hob, the hood fan may still operate
for a certain period of time. After that time
the system deactivates the fan
automatically and prevents you from
accidental activation of the fan for the
next 30 seconds.
Operating the fan speed manually
You can also operate the function manually.
To do that touch when the hob is active.
This deactivates automatic operation of the
function and allows you to change the fan
speed manually. When you press you
raise the fan speed by one. When you reach
an intensive level and press
again you will
6. HINTS AND TIPS
set fan speed to 0 which deactivates the hood
fan. To start the fan again with fan speed 1
touch .
To activate automatic operation of the
function, deactivate the hob and activate
it again.
Activating the light
You can set the hob to activate the light
automatically whenever you activate the hob.
To do so set the automatic mode to H1 – H6.
The light on the hood deactivates 2
minutes after deactivating the hob.
WARNING!
Refer to Safety chapters.
6.1 Cookware
For induction cooking zones a strong
electro-magnetic field creates the heat in
the cookware very quickly.
Use the induction cooking zones with suitable
cookware.
• The bottom of the cookware must be as
thick and flat as possible.
• Ensure pan bases are clean and dry
before placing on the hob surface.
• In order to avoid scratches, do not slide or
rub the pot across the ceramic glass.
Cookware material
• correct: cast iron, steel, enamelled steel,
stainless steel, multi-layer bottom (with a
correct marking from a manufacturer).
• not correct: aluminium, copper, brass,
glass, ceramic, porcelain.
Cookware is suitable for an induction hob
if:
• water boils very quickly on a zone set to
the highest heat setting.
• a magnet pulls on to the bottom of the
cookware.
Cookware dimensions
• Induction cooking zones adapt to the
dimension of the bottom of the cookware
automatically.
• The cooking zone efficiency is related to
the diameter of the cookware. The
cookware with a diameter smaller than the
minimum receives only a part of the power
generated by the cooking zone.
• For both safety reasons and optimal
cooking results, do not use cookware
larger than indicated in "Cooking zones
specification". Avoid keeping cookware
close to the control panel during the
cooking session. This might impact the
functioning of the control panel or
accidentally activate hob functions.
Refer to "Technical data".
6.2 The noises during operation
If you can hear:
• crack noise: cookware is made of different
materials (a sandwich construction).
• whistle sound: you use a cooking zone
with a high power level and the cookware
ENGLISH 13
is made of different materials (a sandwich
construction).
• humming: you use a high power level.
• clicking: electric switching occurs.
• hissing, buzzing: the fan operates.
The noises are normal and do not indicate
any malfunction.
6.3 Öko Timer (Eco Timer)
To save energy, the heater of the cooking
zone deactivates before the count down timer
sounds. The difference in the operation time
depends on the heat setting level and the
length of the cooking operation.
6.4 Examples of cooking
applications
The correlation between the heat setting of a
zone and its consumption of power is not
linear. When you increase the heat setting, it
is not proportional to the increase of the
consumption of power. It means that a
cooking zone with the medium heat setting
uses less than a half of its power.
The data in the table is for guidance only.
Heat setting Use to: Time
Hints
(min)
- 1
1 - 3 Hollandaise sauce, melt: butter, choco‐
1 - 3 Solidify: fluffy omelettes, baked eggs. 10 - 40 Cook with a lid on.
3 - 5 Simmer rice and milkbased dishes,
5 - 7 Steam vegetables, fish, meat. 20 - 45 Add a couple of tablespoons of liquid.
7 - 9 Steam potatoes. 20 - 60 Use max. ¼ l of water for 750 g of po‐
7 - 9 Cook larger quantities of food, stews
9 - 12 Gentle fry: escalope, veal cordon bleu,
12 - 13 Heavy fry, hash browns, loin steaks,
14 Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.
6.5 Hints and Tips for Hob²Hood
When you operate the hob with the function:
• Protect the hood panel from direct
sunlight.
Keep cooked food warm. as neces‐
late, gelatine.
heat up ready-cooked meals.
and soups.
cutlets, rissoles, sausages, liver, roux,
eggs, pancakes, doughnuts.
steaks.
Boil large quantities of water. PowerBoost is activated.
sary
5 - 25 Mix from time to time.
25 - 50 Add at least twice as much liquid as
60 - 150 Up to 3 l of liquid plus ingredients.
as neces‐
sary
5 - 15 Turn halfway through.
• Do not interrupt the signal between the
hob and the hood (e.g. with the hand, a
cookware handle or a tall pot). See the
picture.
The hood in the picture is only exemplary.
Put a lid on the cookware.
rice, mix milk dishes halfway through
the procedure.
tatoes.
Turn halfway through.
• Do not spot halogen light on the hood
panel.
• Do not cover the hob control panel.
14 ENGLISH
7. CARE AND CLEANING
Other remotely controlled appliances
may block the signal. Do not use any
such appliances near to the hob while
Hob²Hood is on.
Cooker hoods with the Hob²Hood function
To find the full range of cooker hoods which
work with this function refer to our consumer
website. The Electrolux cooker hoods that
work with this function must have the symbol
.
WARNING!
Refer to Safety chapters.
7.1 General information
• Clean the hob after each use.
• Always use cookware with a clean base.
• Scratches or dark stains on the surface
have no effect on how the hob operates.
• Use a special cleaner suitable for the
surface of the hob.
• Use a special scraper for the glass.
7.2 Cleaning the hob
• Remove immediately: melted plastic,
plastic foil, sugar and food with sugar,
otherwise, the dirt can cause damage to
the hob. Take care to avoid burns. Use a
special hob scraper on the glass surface
at an acute angle and move the blade on
the surface.
• Remove when the hob is sufficiently
cool: limescale rings, water rings, fat
stains, shiny metallic discoloration. Clean
the hob with a moist cloth and a nonabrasive detergent. After cleaning, wipe
the hob dry with a soft cloth.
• Remove shiny metallic discoloration:
use a solution of water with vinegar and
clean the glass surface with a cloth.
8. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
8.1 What to do if...
Problem Possible cause Remedy
You cannot activate or operate
the hob.
The hob is not connected to an elec‐
trical supply or it is connected incor‐
rectly.
Check if the hob is correctly connected
to the electrical supply.
ENGLISH 15
Problem Possible cause Remedy
The fuse is blown. Make sure that the fuse is the cause of
You do not set the heat setting for
You touched 2 or more sensor fields
Pause operates. Refer to "Daily use".
There is water or fat stains on the
An acoustic signal sounds and
the hob deactivates.
An acoustic signal sounds when
the hob is deactivated.
The hob deactivates. You put something on the sensor
Residual heat indicator does not
come on.
Hob²Hood does not work. You covered the control panel. Remove the object from the control
You use a very tall pot which blocks
Automatic Heat Up does not op‐
erate.
The highest heat setting is set. The highest heat setting has the same
The heat setting changes be‐
tween two levels.
The sensor fields become hot. The cookware is too large or you put
There is no sound when you
touch the panel sensor fields.
comes on.
comes on.
The cookware is unsuitable. Use suitable cookware. Refer to "Hints
The diameter of the bottom of the
10 seconds.
at the same time.
control panel.
You put something on one or more
sensor fields.
field .
The zone is not hot because it oper‐
ated only for a short time or the sen‐
sor is damaged.
the signal.
The zone is hot. Let the zone become sufficiently cool.
Power management operates. Refer to "Daily use".
it too near to the controls.
The sounds are deactivated. Activate the sounds. Refer to "Daily
Child Safety Device or Lock oper‐
ates.
There is no cookware on the zone. Put cookware on the zone.
cookware is too small for the zone.
the malfunction. If the fuse is blown
again and again, contact a qualified
electrician.
Activate the hob again and set the
heat setting in less than 10 seconds.
Touch only one sensor field.
Clean the control panel.
Remove the object from the sensor
fields.
Remove the object from the sensor
field.
If the zone operated sufficiently long to
be hot, speak to an Authorised Service
Centre.
panel.
Use a smaller pot, change the cooking
zone or operate the hood manually.
power as the function.
Put large cookware on the rear zones,
if possible.
use".
Refer to "Daily use".
and tips".
Use cookware with correct dimen‐
sions. Refer to "Technical data".
16 ENGLISH
Problem Possible cause Remedy
and a number come on.
You can hear a constant beep
noise.
There is an error in the hob. Deactivate the hob and activate it
again after 30 seconds. If comes
on again, disconnect the hob from the
electrical supply. After 30 seconds,
connect the hob again. If the problem
continues, speak to an Authorised
Service Centre.
The electrical connection is incor‐
rect.
Disconnect the hob from the electrical
supply. Ask a qualified electrician to
check the installation.
8.2 If you cannot find a solution...
If you cannot find a solution to the problem
yourself, contact your dealer or an Authorised
Service Centre. Give the data from the rating
plate. Give also three digit letter code for the
glass ceramic (it is in the corner of the glass
surface) and an error message that comes
on. Make sure, you operated the hob
correctly. If not the servicing by a service
technician or dealer will not be free of charge,
also during the warranty period. The
instructions about the Service Centre and
conditions of guarantee are in the guarantee
booklet.
9. TECHNICAL DATA
9.1 Rating plate
Model IPE6450KF PNC 949 596 754 00
Typ 61 B4A 00 AA 220 - 240 V / 400 V 2N 50 - 60 Hz
Induction 7.35 kW Made in Germany
Ser.Nr. ................. 7.35 kW
ELECTROLUX
9.2 Cooking zones specification
Cooking zone Nominal power
(maximum heat
setting) [W]
Left front 2300 3700 10 125 - 210
Left rear 1800 2800 10 145 - 180
Right front 1400 2500 4 125 - 145
Right rear 1800 2800 10 145 - 180
PowerBoost [W] PowerBoost
maximum dura‐
tion [min]
Cookware diame‐
ter [mm]
The power of the cooking zones can be
different in some small range from the data in
the table. It changes with the material and
dimensions of the cookware.
For optimal cooking results use cookware no
larger than the diameter in the table.
ENGLISH 17
10. ENERGY EFFICIENCY
10.1 Product information according to EU 66/2014 valid for EU market only
Model identification IPE6450KF
Type of hob Built-In Hob
Number of cooking zones 4
Heating technology Induction
Diameter of circular cooking zones (Ø) Left front
Energy consumption per cooking zone (EC electric
cooking)
Energy consumption of the hob (EC electric hob) 180.2 Wh / kg
Left rear
Right front
Right rear
Left front
Left rear
Right front
Right rear
21.0 cm
18.0 cm
14.5 cm
18.0 cm
178.4 Wh / kg
174.4 Wh / kg
183.2 Wh / kg
184.9 Wh / kg
EN 60350-2 - Household electric cooking
• If it is possible, always put the lids on the
appliances - Part 2: Hobs - Methods for
measuring performance
10.2 Energy saving
You can save energy during everyday
cooking if you follow below hints.
• When you heat up water, use only the
• Before you activate the cooking zone put
• Put the smaller cookware on the smaller
• Put the cookware directly in the centre of
• Use the residual heat to keep the food
amount you need.
11. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it.
Help protect the environment and human
health by recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol with
the household waste. Return the product to
your local recycling facility or contact your
municipal office.
cookware.
the cookware on it.
cooking zones.
the cooking zone.
warm or to melt it.
18 ENGLISH
*
867346024-E-412023
Loading...
