Safety warnings
For the User
The cooker hood is designed to extract unpleasant odours from the kitchen, it will not
extract steam.
Always cover lighted elements, to prevent excess heat from damaging the
appliance. In the case of oil, gas and coal fired cookers it is essential to avoid
open flames.
Also, when frying, keep the deep frying pan on the cooker top/cooker under
careful control.
The hot oil in the frying pan might ignite due to overheating.
The risk of self-ignition increases when the oil being used is dirty.
It is extremely important to note that overheating can cause a fire.
Never carry out any flambé cooking under the hood.
Always disconnect the unit from the power supply before carrying out any
work on the hood, including replacing the light bulb (take the cartridge fuse
out of the fuse holder or switch off the automatic circuit breaker).
It is very important to clean the hood and replace the filter at the
recommended intervals. Failure to do so could cause grease deposits to
build up, resulting in a fire hazard.
The appliance is not intended for use by young children or infirm persons without
supervision.
Young children should be supervised to ensure that they do not play with the
appliance.
WARNING - Ensure that the appliance is switched off before replacing the lamp to
avoid the possibility of electric shock.
For the Installer
When used as an extractor unit, the hood must be fitted with a 150mm diameter
hose.
Should there already be a pipe with a diameter of 125mm that ducts to the outside
through the wall or roof, it is possible to use the 150/125 mm reduction flange
provided. In this case the hood will be slightly noisier.
When installing the hood, make sure you respect the following minimum
distance from the top edge of the cooking hob/ring surfaces:
electric cookers 500 mm
gas cookers 650 mm
coal and oil cookers 700 mm min.
The hood can be installed above these heights but for optimum performance it should
be installed at the distance quoted for the appropriate heat source.
62
The national Standard on fuel-burning systems specifies a maximum depression of
0.04 mbar in such rooms.
The air outlet must not be connected to chimney flues or combustion gas ducts. The
air outlet must under no circumstances be connected to ventilation ducts for rooms in
which fuel-burning appliances are installed.
The air outlet installation must comply with the regulations laid down by the
relevant authorities.
When the unit is used in its extractor version, a sufficiently large ventilation hole
must be provided, with dimensions that are approximately the same as the outlet
hole.
National and regional building regulations impose a number of restrictions on
using hoods and fuel-burning appliances connected to a chimney, such as coal or
oil room-heaters and gas fires, in the same room.
Hoods can only be used safely with appliances connected to a chimney if the
room and/or flat (air/environment combination) is ventilated from outside using a
suitable ventilation hole approximately 500-600 cm2 large to avoid the possibility
of a depression being created during operation of the hood.
If you have any doubts, contact the relevant controlling authority or building
inspectors office.
Since the rule for rooms with fuel burning appliances is outlet hole of the same
size as the ventilation hole, a hole of 500-600 cm2, which is to say a larger hole,
could reduce the performance of the extractor hood.
If the hood is used in its filtering function, it will operate simply and safely in the
above conditions without the need for any of the aforementioned measures.
When the hood is used in its extractor function, the following rules must be
followed to obtain optimal operation:
short and straight outlet hose
keep bends in outlet hose to a minimum
never install the hoses with an acute angle, they must always follow a gentle curve.
keep the hose as large as possible (preferably the same diameter as the outlet
hole).
Failure to observe these basic instructions will drastically reduce the performance
and increase the noise levels of the extractor hood.
63
Description of the Appliance
The hood is supplied as an extractor unit and can also be used with a filtering function
by fitting one charcoal filter.
You will need an original AEG charcoal filter for this function (Available from your
local AEG Service Force Centre).
Only for CHDI 8820: The cooker hood is supplied ready for use as a recirculation
hood and may be used for extraction by
removing the charcoal filter which has been fitted
inside the cooker hood.
Extraction
In this version fumes are extracted to the
outside via a hose connected to the coupling
ring A. Fig. 1.
In order to obtain the best performance the
hose should have a diameter equal to the outlet
hole.
Should there already be a pipe with a diameter
of 125mm that ducts to the outside through the
wall or roof, it is possible to use the 150/125
mm reduction flange provided. In this case the
hood will be slightly noisier.
Fig. 1
A
Recirculation
The air is filtered through a charcoal filter and returned to the kitchen.
You will need an original AEG charcoal filter for the filtering function. (See Special
Accessories).
Fix the deflector using 4 screws Ø 3.5x6.5 mm. Fig. 2.
F
Fig. 2
64
Control Panel
Best results are obtained by using a low speed for normal conditions and a high
speed when odours are more concentrated.
Turn the hood on a few minutes before you start cooking, you will then get an
under pressure in the kitchen. The hood should be left on after cooking for about
15 minutes or until all the odours have disappeared. The control switches are
located on the units front panel.
a
b
123 456
Fig. 3
1 - Mains switch, ON/OFF
Press for less than 1 1/2 seconds and the cooker hood goes into the "stand by"
position (point "b" is illuminated).
Press for more than 1 1/2 seconds and the cooker hood turns off, ALL the
controls (except the light push button) are disabled (the display is off).
Press again for more than 1 1/2 seconds to reset the cooker hood to "stand
by".
2 - Light ON/OFF
3 - Display
4 - Start and choice of motor speed 1-2-3-1-2.........
5 - Intensive speed on/off. The Intensive speed runs for 5 minutes:
If the hood is on when the Intensive speed is activated, the hood will revert to
previous speed after 5 minutes.
If the hood is off when the Intensive speed is activated, the hood will
automatically turn off after 5 minutes.
To interrupt the Intensive speed, press button 1 or 4.
The letter P appears on the display and the remaining time (the point a is
flashing), if interrupted an acoustic signal is heard.
6 - Self-Timer: times all the speed levels (the point b is flashing), and then the
cooker hood switches off:
The self-timer is set as follows: 1st speed level 20 minutes
2nd speed level 15 minutes
3rd speed level 10 minutes
The display shows the remaining operation time, at the end of the time an
acoustic signal is heard. Depressing the push-button again exits the function.
Should the hood or the controls fail to operate: disconnect the power supply for at
least 5 seconds. After reconnecting the power supply wait 15 seconds and then
check that the cooker hood is now operating
correctly.
65
Control device for grease and charcoal filters
This hood is fitted with a device that signals when it is necessary to clean the grease
filter or the charcoal filter (if the hood is used in the recirculation version with a
charcoal filter).
On delivery, the hood is not supplied with a charcoal filter, so the saturation indicator
will be disabled.
If the hood is to be used with a charcoal filter, the saturation
indicator light must be enabled as follows:
Press buttons 4 and 5 simultaneously and hold them for 3 seconds. At first only the
grease filter LED F will illuminate, but when the charcoal filter LED C illuminates the
saturation indicator will be enabled.
To disable it: Press buttons 4 and 5 again simultaneously and hold
them for 3 seconds, until the charcoal filter LED C goes out.
Grease filter LED (F)
LED F will start to flash when it is time to clean the grease filter.
Cleaning will be necessary after 40 working hours. Always comply with the
maintenance instructions for the grease filter.
Charcoal filter LED (C)
The charcoal filter LED C will start to flash when the charcoal filter needs to be
replaced.
This operation is necessary after approximately 160 working hours.
Resetting the saturation indicator
After cleaning or replacing the filters, press button 1 for 3 seconds until the grease
filter LED F or the charcoal filter LED C stops flashing.
Warning! The resetting of the saturation indicator MUST be done in stand-by, never
disconnect the hood from the mains.
66
